‘鲁丽’×‘红1#’苹果杂交群体全基因组KASP标记开发及验证

doi:10.3864/j.issn.0578-1752.2023.05.010

Abstract

Abstract:

【Objective】 A series of kompetitive allele-specific PCR (KASP) markers for traits related to apple leaves were developed to provide a reference to effectively utilize light in apple breeding using a Luli ×Red No. 1 hybrid population as materials. 【Method】This study investigated the leaf trait phenotypic data (including leaf length, width, contents of chlorophyll and anthocyanin, photosynthetic rate and chlorophyll fluorescence parameters) of Luli, a type I red-fleshed apple, Red No. 1, and 134 hybrids. Whole-genome resequencing was conducted on an Illumina HiSeq 2500 platform. The clean sequencing reads were mapped to the apple reference genome using BWA software. GATK software was used to identify single nucleotide polymorphisms (SNPs). 【Result】A total of 164 776 660, 149 482 876, and 3 927 370 200 clean reads were obtained by whole-genome resequencing from Luli, Red No. 1 and 134 hybrid individuals, respectively. The data were aligned to the reference genome sequences with mapping rates of 98.77%, 98.89%, and 97.79%, respectively. A total of 6 445 766 SNPs were identified. The SNPs were then filtered, and 94 208 accurate and high-quality SNPs were selected for subsequent KASP primer design. Finally, 5 802 KASP markers were developed based on a high-throughput whole-genome resequencing approach. The average polymorphism information content (PIC) of these KASP markers was 0.31, and there were 30.13% PICs>0.35. The Simpson genetic diversity index ranged from 0.01 to 0.67, with an average value of 0.53. The mean observed heterozygosity was 0.32. A Kyoto Encyclopedia of Genes and Genomes enrichment analysis of the genes for KASP marker revealed that “one carbon pool by folate” was the most significant pathway. An analysis of the phenotypic data of leaf-related traits in both the parents and individuals from the Luli ×Red No. 1 cross showed that there were significant differences in the phenotypic values of leaf net photosynthetic rate, stomatal conductance (Gs) and other traits between the parents Luli and Red No. 1. The F1 generation exhibited a wide phenotypic variation, and the most traits segregated extensively. Α detailed study of the phenotypic data of leaf traits of the hybrid population with the genotype and annotations of the KASP markers finally resulted in the development of 21 KASP markers, which was correlated with leaf-related traits, including chlorophyll content, Gs and leaf length and width.【Conclusion】Use of the whole-genome resequencing data of Luli, Red No. 1 and 134 hybrid individuals resulted in the development of 5 802 KASP. A total of 21 of these KASP markers significantly correlated with leaf traits, which provided a theoretical reference for the high utilization of light energy in apple breeding.

Key words: apple, whole-genome resequencing, leaf-related traits, KASP marker

ZHENG WenYan, CHANG YuanSheng, HE Ping, HE XiaoWen, WANG Sen, GAO WenSheng, LI LinGuang, WANG HaiBo. Development and Validation of KASP Markers Based on a Whole- Genome Resequencing Approach in a Hybrid Population of Luli × Red No. 1[J].Scientia Agricultura Sinica, 2023, 56(5): 935-950.

0
/ / Recommend

Add to citation manager EndNote|Reference Manager|ProCite|BibTeX|RefWorks

URL: https://www.chinaagrisci.com/EN/10.3864/j.issn.0578-1752.2023.05.010

https://www.chinaagrisci.com/EN/Y2023/V56/I5/935

Figures/Tables 12

Fig. 1

Table 1

Table 2

Fig. 2

Fig. 3

Fig. 4

Fig. 5

Fig. 6

Fig. 7

Fig. 8

Table 3

Table 4

References 57

[1]	王金政, 毛志泉, 丛佩华, 吕德国, 马锋旺, 任小林, 束怀瑞, 李保华, 郭玉蓉, 郝玉金, 姜远茂, 张新忠, 杨欣, 曹克强, 赵政阳, 韩振海, 霍学喜, 魏钦平. 新中国果树科学研究70年: 苹果. 果树学报, 2019, 36(10): 1255-1263.
	WANG J Z, MAO Z Q, CONG P H, LÜ D G, MA F W, REN X L, SHU H R, LI B H, GUO Y R, HAO Y J, JIANG Y M, ZHANG X Z, YANG X, CAO K Q, ZHAO Z Y, HAN Z H, HUO X X, WEI Q P. Fruit scientific research in New China in the past 70 years: Apple. Journal of Fruit Science, 2019, 36(10): 1255-1263.(in Chinese)
[2]	李民吉, 张强, 李兴亮, 周贝贝, 杨雨璋, 张军科, 周佳, 魏钦平. 4种矮化砧木对再植苹果幼树生长、产量和品质的影响. 中国农业科学, 2020, 53(11): 2264-2271. doi: 10.3864/j.issn.0578-1752.2020.11.012. doi: 10.3864/j.issn.0578-1752.2020.11.012
	LI M J, ZHANG Q, LI X L, ZHOU B B, YANG Y Z, ZHANG J K, ZHOU J, WEI Q P. Effects of 4 dwarfing rootstocks on growth, yield and fruit quality of ‘fuji’ sapling in apple replant orchard. Scientia Agricultura Sinica, 2020, 53(11): 2264-2271. doi: 10.3864/j.issn.0578-1752.2020.11.012.(in Chinese) doi: 10.3864/j.issn.0578-1752.2020.11.012
[3]	陈学森, 韩明玉, 苏桂林, 刘凤之, 过国南, 姜远茂, 毛志泉, 彭福田, 束怀瑞. 当今世界苹果产业发展趋势及我国苹果产业优质高效发展意见. 果树学报, 2010, 27(4): 598-604.
	CHEN X S, HAN M Y, SU G L, LIU F Z, GUO G N, JIANG Y M, MAO Z Q, PENG F T, SHU H R. Discussion on today’s world apple industry trends and the suggestions on sustainable and efficient development of apple industry in China. Journal of Fruit Science, 2010, 27(4): 598-604.(in Chinese)
[4]	赵德英, 程存刚, 仇贵生, 董雅凤, 张彩霞, 李壮, 张怀江, 胡国君, 厉恩茂. 苹果高质量发展技术创新途径. 中国果树, 2021(8): 1-5.
	ZHAO D Y, CHENG C G, QIU G S, DONG Y F, ZHANG C X, LI Z, ZHANG H J, HU G J, LI E M. Technological innovation approach of high quality development in apple industry. China Fruits, 2021(8): 1-5.(in Chinese)
[5]	GANAL M W, POLLEY A, GRANER E M, PLIESKE J, WIESEKE R, LUERSSEN H, DURSTEWITZ G. Large SNP arrays for genotyping in crop plants. Journal of Biosciences, 2012, 37(5): 821-828. pmid: 23107918
[6]	THOMSON M J. High-throughput SNP genotyping to accelerate crop improvement. Plant Breeding and Biotechnology, 2014, 2(3): 195-212. doi: 10.9787/PBB.2014.2.3.195
[7]	SEMAGN K, BABU R, HEARNE S, OLSEN M. Single nucleotide polymorphism genotyping using kompetitive allele specific PCR (KASP): Overview of the technology and its application in crop improvement. Molecular Breeding, 2014, 33(1): 1-14. doi: 10.1007/s11032-013-9917-x
[8]	MACKAY I J, BANSEPT-BASLER P, BARBER T, BENTLEY A R, COCKRAM J, GOSMAN N, GREENLAND A J, HORSNELL R, HOWELLS R, O’SULLIVAN D M, ROSE G A, HOWELL P J. An eight-parent multiparent advanced generation inter-cross population for winter-sown wheat: Creation, properties, and validation. G3: Genes\|Genomes\|Genetics, 2014, 4(9): 1603-1610. doi: 10.1534/g3.114.012963
[9]	PHAM A T, HARRIS D K, BUCK J, HOSKINS A, SERRANO J, ABDEL-HALEEM H, CREGAN P, SONG Q J, BOERMA H R, LI Z L. Fine mapping and characterization of candidate genes that control resistance to Cercospora sojina K. Hara in two soybean germplasm accessions. PLoS ONE, 2015, 10(5): e0126753.
[10]	BAUMGARTNER I O, KELLERHALS M, COSTA F, DONDINI L, PAGLIARANI G, GREGORI R, TARTARINI S, LEUMANN L, LAURENS F, PATOCCHI A. Development of SNP-based assays for disease resistance and fruit quality traits in apple (Malus × domestica Borkh.) and validation in breeding pilot studies. Tree Genetics & Genomes, 2016, 12(35): 1-21.
[11]	JIA D J, SHEN F, WANG Y, WU T, XU X F, ZHANG X Z, HAN Z H. Apple fruit acidity is genetically diversified by natural variations in three hierarchical epistatic genes: MdSAUR37, MdPP2CH and MdALMTII. The Plant Journal: for Cell and Molecular Biology, 2018, 95(3): 427-443. doi: 10.1111/tpj.2018.95.issue-3
[12]	WANG H B, ZHAO S, MAO K, DONG Q L, LIANG B W, LI C, WEI Z W, LI M J, MA F W. Mapping QTLs for water-use efficiency reveals the potential candidate genes involved in regulating the trait in apple under drought stress. BMC Plant Biology, 2018, 18(1): 136. doi: 10.1186/s12870-018-1308-3 pmid: 29940853
[13]	SHEN F, HUANG Z Y, ZHANG B G, WANG Y, ZHANG X, WU T, XU X F, ZHANG X Z, HAN Z H. Mapping gene markers for apple fruit ring rot disease resistance using a multi-omics approach. G3: Genes\|Genomes\|Genetics, 2019, 9(5): 1663-1678. doi: 10.1534/g3.119.400167
[14]	ZHENG W Y, SHEN F, WANG W Q, WU B, WANG X, XIAO C, TIAN Z D, YANG X L, YANG J, WANG Y, WU T, XU X F, HAN Z H, ZHANG X Z. Quantitative trait loci-based genomics-assisted prediction for the degree of apple fruit cover color. The Plant Genome, 2020, 13(3): e20047.
[15]	WU B, SHEN F, WANG X, ZHENG W Y, XIAO C, DENG Y, WANG T, HUANG Z Y, ZHOU Q, WANG Y, WU T, XUE F X, HAN Z H, ZHANG X Z. Role of MdERF3 and MdERF118 natural variations in apple flesh firmness/crispness retainability and development of QTL-based genomics-assisted prediction. Plant Biotechnology Journal, 2021, 19(5): 1022-1037. doi: 10.1111/pbi.v19.5
[16]	LIU J, SHEN F, XIAO Y, FANG H C, QIU C P, LI W, WU T, XU X F, WANG Y, ZHANG X Z, HAN Z H. Genomics-assisted prediction of salt and alkali tolerances and functional marker development in apple rootstocks. BMC Genomics, 2020, 21(1): 550. doi: 10.1186/s12864-020-06961-9 pmid: 32778069
[17]	MILLER B A, TILLMAN J R, HOWARD N P, KOSTICK S A, EVANS K M, LUBY J J. A DNA test for high incidence of soft scald and soggy breakdown postharvest disorders in Malus domestica Borkh. Molecular Breeding, 2021, 41: 57. doi: 10.1007/s11032-021-01245-w
[18]	WINFIELD M, BURRIDGE A, ORDIDGE M, HARPER H, WILKINSON P, THOROGOOD D, COPAS L, EDWARDS K, BARKER G. Development of a minimal KASP marker panel for distinguishing genotypes in apple collections. PLoS ONE, 2020, 15(11): e0242940.
[19]	SIMKIN A J, LÓPEZ-CALCAGNO P E, RAINES C A. Feeding the world: improving photosynthetic efficiency for sustainable crop production. Journal of Experimental Botany, 2019, 70(4): 1119-1140. doi: 10.1093/jxb/ery445 pmid: 30772919
[20]	JIN F L, ZHANG F W, YUE X, LI M, AO X X. Correlation between leaf size and fruit quality of Kiwi. Agricultural Basic Science and Technology, 2016, 17 (11): 2472-2488.
[21]	MAEDA H, AKAGI T, TAO R. Quantitative characterization of fruit shape and its differentiation pattern in diverse persimmon (Diospyros kaki) cultivars. Scientia Horticulturae, 2018, 228: 41-48. doi: 10.1016/j.scienta.2017.10.006
[22]	江锡兵, 章平生, 杨龙, 吴强, 吴聪连, 吴小云, 龚榜初, 赖俊声. 板栗和锥栗种间杂交F₁代叶片表型及其遗传变异研究. 园艺学报, 2019, 46(11): 2129-2142.
	JIANG X B, ZHANG P S, YANG L, WU Q, WU C L, WU X Y, GONG B C, LAI J S. Genetic variation of leaf phenotypic traits in F1 progeny of interspecific cross between Castanea mollissima and C. henryi. Acta Horticulturae Sinica, 2019, 46(11): 2129-2142.(in Chinese)
[23]	张小猜, 赵政阳, 樊红科, 党志国, 张志敏. 苹果杂种F₁代叶片性状分离及早期选择研究. 西北农业学报, 2009, 18(5): 228-231.
	ZHANG X C, ZHAO Z Y, FAN H K, DANG Z G, ZHANG Z M. Study on the leaf trait segregation of apple hybrid seedlings and application in pre-selection. Acta Agriculturae Boreali-Occidentalis Sinica, 2009, 18(5): 228-231.(in Chinese)
[24]	刘遵春, 苗卫东, 刘大亮, 陈学森. 苹果叶片相关性状的QTL定位及其遗传效应分析. 西北植物学报, 2014, 34(3): 481-487.
	LIU Z C, MIAO W D, LIU D L, CHEN X S. Identification of quantitative trait loci associated with leaf traits in apple and analysis of their genetic effects. Acta Botanica Boreali-Occidentalia Sinica, 2014, 34(3): 481-487.(in Chinese)
[25]	张兴平, 钱前, 张嘉楠, 邓兴旺, 万建民, 徐云碧. 分子植物育种助推南繁种业转型升级. 中国农业科学, 2021, 54(18): 3789-3804. doi: 10.3864/j.issn.0578-1752.2021.18.001. doi: 10.3864/j.issn.0578-1752.2021.18.001
	ZHANG X P, QIAN Q, ZHANG J N, DENG X W, WAN J M, XU Y B. Transforming and upgrading off-season breeding in Hainan through molecular plant breeding. Scientia Agricultura Sinica, 2021, 54(18): 3789-3804. doi: 10.3864/j.issn.0578-1752.2021.18.001.(in Chinese) doi: 10.3864/j.issn.0578-1752.2021.18.001
[26]	吕天星, 伊凯, 刘志, 王冬梅, 闫忠业, 姜孝军, 王铭. 苹果实生苗叶片叶绿素含量遗传趋势. 西北农业学报, 2013, 22(12): 91-95.
	LÜ T X, YI K, LIU Z, WANG D M, YAN Z Y, JIANG X J, WANG M. Genetic trend of leaf chlorophyll content in apple seedling plant. Acta Agriculturae Boreali-Occidentalis Sinica, 2013, 22(12): 91-95.(in Chinese)
[27]	姜卫兵, 庄猛, 沈志军, 宋宏峰, 曹晶, 李刚. 不同季节红叶桃、紫叶李的光合特性研究. 园艺学报, 2006, 33(3): 577-582.
	JIANG W B, ZHUANG M, SHEN Z J, SONG H F, CAO J, LI G. Study on the photosynthetic characteristics of red-leaf peach and purpleleaf plum in different seasons. Acta Horticulturae Sinica, 2006, 33(3): 577-582.(in Chinese)
[28]	CHEN X S, FENG T, ZHANG Y M, HE T M, FENG J R, ZHANG C Y. Genetic diversity of volatile components in Xinjiang Wild Apple (Malus sieversii). Journal of Genetics and Genomics, 2007, 34(2): 171-179. doi: 10.1016/S1673-8527(07)60018-6 pmid: 17469789
[29]	VAN NOCKER S, BERRY G, NAJDOWSKI J, MICHELUTTI R, LUFFMAN M, FORSLINE P, ALSMAIRAT N, BEAUDRY R, NAIR M F, ORDIDGE M. Genetic diversity of red-fleshed apples (Malus). Euphytica, 2012, 185: 281-293. doi: 10.1007/s10681-011-0579-7
[30]	GIUSTI M M, WROLSTAD R E. Characterization and measurement of anthocyanins by UV-visible spectroscopy. Current Protocols in Food Analytical Chemistry, 2001, (1): F1.2.1-1.2.13.
[31]	HOSSEINIAN F S, LI W D, BETA T. Measurement of anthocyanins and other phytochemicals in purple wheat. Food Chemistry, 2008, 109(4): 916-924. doi: 10.1016/j.foodchem.2007.12.083 pmid: 26050008
[32]	ARNON D I. Copper enzymes in isolated chloroplasts. polyphenoloxidase in beta Vulgaris. Plant Physiology, 1949, 24(1): 1-15. doi: 10.1104/pp.24.1.1
[33]	DOBRÁNSZKI J, MENDLER-DRIENYOVSZKI N. Cytokinin- induced changes in the chlorophyll content and fluorescence of in vitro apple leaves. Journal of Plant Physiology, 2014, 171(16): 1472-1478. doi: 10.1016/j.jplph.2014.06.015
[34]	LI H, DURBIN R. Fast and accurate short read alignment with Burrows-Wheeler transform. Bioinformatics, 2009, 25(14): 1754-1760. doi: 10.1093/bioinformatics/btp324 pmid: 19451168
[35]	MCKENNA A, HANNA M, BANKS E, SIVACHENKO A, CIBULSKIS K, KERNYTSKY A, GARIMELLA K, ALTSHULER D, GABRIEL S, DALY M, DEPRISTO M A. The Genome Analysis Toolkit: A MapReduce framework for analyzing next-generation DNA sequencing data. Genome Research, 2010, 20(9): 1297-1303. doi: 10.1101/gr.107524.110 pmid: 20644199
[36]	CINGOLANI P, PLATTS A, WANG L L, COON M, NGUYEN T, WANG L, LAND S J, LU X Y, RUDEN D M. A program for annotating and predicting the effects of single nucleotide polymorphisms, SnpEff: SNPs in the genome of Drosophila melanogaster strain w1118; iso-2; iso-3. Fly, 2012, 6(2): 80-92. doi: 10.4161/fly.19695
[37]	WEINER J, PARIDA S K, MAERTZDORF J, BLACK G F, REPSILBER D, TELAAR A, MOHNEY R P, ARNDT-SULLIVAN C, GANOZA C A, FAÉ K C, WALZL G, KAUFMANN S H E. Biomarkers of inflammation, immunosuppression and stress with active disease are revealed by metabolomic profiling of tuberculosis patients. PLoS ONE, 2012, 7(7): e40221. doi: 10.1371/journal.pone.0040221
[38]	PRICE M N, DEHAL P S, ARKIN A P. FastTree 2: Approximately maximum-likelihood trees for large alignments. PLoS ONE, 2010, 5(3): e9490. doi: 10.1371/journal.pone.0009490
[39]	HANSON A D, ROJE S. One-carbon metabolism in higher plants. Annual Review of Plant Physiology and Plant Molecular Biology, 2001, 52: 119-137. pmid: 11337394
[40]	CHRISTENSEN K E, MACKENZIE R E. Mitochondrial one-carbon metabolism is adapted to the specific needs of yeast, plants and mammals. BioEssays: News and Reviews in Molecular, Cellular and Developmental Biology, 2006, 28(6): 595-605.
[41]	YIN X R, XIE X L, XIA X J, YU J Q, FERGUSON I B, GIOVANNONI J J, CHEN K S. Involvement of an ethylene response factor in chlorophyll degradation during citrus fruit degreening. The Plant Journal: for Cell and Molecular Biology, 2016, 86(5): 403-412. doi: 10.1111/tpj.2016.86.issue-5
[42]	LI S J, XIE X L, LIU S C, CHEN K S, YIN X R. Auto- and mutual-regulation between two CitERFs contribute to ethylene- induced citrus fruit degreening. Food Chemistry, 2019, 299: 125163. doi: 10.1016/j.foodchem.2019.125163
[43]	HAN Z Y, HU Y N, LV Y D, ROSE J K C, SUN Y Q, SHEN F, WANG Y, ZHANG X Z, XU X F, WU T, HAN Z H. Natural variation underlies differences in ETHYLENE RESPONSE FACTOR17 activity in fruit peel degreening. Plant Physiology, 2018, 176(3): 2292-2304. doi: 10.1104/pp.17.01320 pmid: 29431631
[44]	SHI Y, LIU X N, ZHAO S S, GUO Y. The PYR-PP2C-CKL2 module regulates ABA-mediated actin reorganization during stomatal closure. The New Phytologist, 2022, 233(5): 2168-2184. doi: 10.1111/nph.v233.5
[45]	曹柳青. 赤霉素对冬枣光合作用和内源激素的影响[D]. 保定: 河北农业大学, 2006.
	CAO L Q. Effects of gibberellin on photosynthesis and endogenous hormones of Dongzao jujube[D]. Baoding: Hebei Agricultural University, 2006.(in Chinese)
[46]	AHAMMED G J, GAO C J, OGWENO J O, ZHOU Y H, XIA X J, MAO W H, SHI K, YU J Q. Brassinosteroids induce plant tolerance against phenanthrene by enhancing degradation and detoxification in Solanum lycopersicum L. Ecotoxicology and Environmental Safety, 2012, 80: 28-36. doi: 10.1016/j.ecoenv.2012.02.004
[47]	王延玲. 新疆红肉苹果红色发育机理的初步研究[D]. 泰安: 山东农业大学, 2011.
	WANG Y L. Preliminary study on the red development mechanism of Xinjiang red meat apple[D]. Tai’an: Shandong Agricultural University, 2011.(in Chinese)
[48]	CHAGNÉ D, CARLISLE C M, BLOND C, VOLZ R K, WHITWORTH C J, ORAGUZIE N C, CROWHURST R N, ALLAN A C, ESPLEY R V, HELLENS R P, GARDINER S E. Mapping a candidate gene (MdMYB10) for red flesh and foliage colour in apple. BMC Genomics, 2007, 8: 212. pmid: 17608951
[49]	ESPLEY R V, BRENDOLISE C, CHAGNÉ D, KUTTY-AMMA S, GREEN S, VOLZ R, PUTTERILL J, SCHOUTEN H J, GARDINER S E, HELLENS R P, ALLAN A C. Multiple repeats of a promoter segment causes transcription factor autoregulation in red apples. The Plant Cell, 2009, 21(1): 168-183. doi: 10.1105/tpc.108.059329
[50]	UMEMURA H, OTAGAKI S, WADA M, KONDO S, MATSUMOTO S. Expression and functional analysis of a novel MYB gene, MdMYB110a_JP, responsible for red flesh, not skin color in apple fruit. Planta, 2013, 238(1): 65-76. doi: 10.1007/s00425-013-1875-3
[51]	LAMBERT P, PASCAL T. Mapping Rm2 gene conferring resistance to the green peach aphid (Myzus persicar Sulzer) in the peach cultivar ‘Rubira®’. Tree Genetics and Genomes, 2011, 7(5): 1057-1068. doi: 10.1007/s11295-011-0394-2
[52]	周晖. 桃花青苷着色及原花青素合成的调控机制研究[D]. 武汉: 中国科学院研究生院(武汉植物园), 2015.
	ZHOU H. Mechanisms underlying the regulation of anthocyanin coloration and proanthocyanidin synthesis in peach[D]. Wuhan: Wuhan Botanical Garden, Chinese Academy of Sciences, 2015.(in Chinese)
[53]	GOULD K S, VOGELMANN T C, HAN T, CLEARWATER M J. Profiles of photosynthesis within red and green leaves of Quintinia serrata. Physiologia Plantarum, 2002, 116(1): 127-133. doi: 10.1034/j.1399-3054.2002.1160116.x
[54]	HATIER J H B, CLEARWATER M J, GOULD K S. The functional significance of black-pigmented leaves: Photosynthesis, photoprotection and productivity in Ophiopogon planiscapus ‘Nigrescens’. PLoS ONE, 2013, 8(6): e67850. doi: 10.1371/journal.pone.0067850
[55]	HUGHES N M, MORLEY C B, SMITH W K. Coordination of anthocyanin decline and photosynthetic maturation in juvenile leaves of three deciduous tree species. The New Phytologist, 2007, 175(4): 675-685. doi: 10.1111/nph.2007.175.issue-4
[56]	周振翔, 李志康, 陈颖, 王志琴, 杨建昌, 顾骏飞. 叶绿素含量降低对水稻叶片光抑制与光合电子传递的影响. 中国农业科学, 2016, 49(19): 3709-3720. doi: 10.3864/j.issn.0578-1752.2016.19.004 doi: 10.3864/j.issn.0578-1752.2016.19.004
	ZHOU Z X, LI Z K, CHEN Y, WANG Z Q, YANG J C, GU J F. Effects of reduced chlorophyll content on photoinhibition and photosynthetic electron transport in rice leaves. Scientia Agricultura Sinica, 2016, 49(19): 3709-3720. doi: 10.3864/j.issn.0578-1752.2016.19.004.(in Chinese) doi: 10.3864/j.issn.0578-1752.2016.19.004
[57]	李卫星, 杨舜博, 何智冲, 金飚. 植物叶色变化机制研究进展. 园艺学报, 2017, 44(9): 1811-1824.
	LI W X, YANG S B, HE Z C, JIN B. Research advances in the regulatory mechanisms of leaf coloration. Acta Horticulturae Sinica, 2017, 44(9): 1811-1824.(in Chinese)

Metrics

Viewed

Full text

Abstract

Cited

Shared

Discussed

Comments

Recommended 0

No Suggested Reading articles found!

样品 Sample	Reads数 Clean reads	碱基数 Bases (bp)	Q30百分比Q30 (%)	GC含量 GC (%)
‘鲁丽’ Luli	164776660	24684144730	93.59	38.64
‘红1#’ Red No. 1	149482876	22391415716	94.24	38.72
杂交后代 Offsprings	3927370200	588153323320	92.87	38.61
总计 Total	4241629736	635228883766	92.88	38.61

染色体Chromosome	染色体长度 Length of chromosome (Mb)	SNP数 SNP number	SNP密度（个/Mb） SNP density (No./Mb)	过滤后SNP数 SNP number after filtration	过滤后SNP密度（个/Mb） SNP density after filtration (No./Mb)
Chr01	32.625	278600	8539	3216	99
Chr02	37.578	404259	10758	5965	159
Chr03	37.524	372841	9936	5747	153
Chr04	32.302	331145	10252	5380	167
Chr05	47.952	486261	10141	6655	139
Chr06	37.137	291836	7858	3291	89
Chr07	36.691	352192	9599	5113	139
Chr08	31.609	302356	9566	4445	141
Chr09	37.605	373414	9930	5601	149
Chr10	41.762	442804	10603	6965	167
Chr11	43.060	406159	9432	5570	129
Chr12	33.050	366784	11098	6256	189
Chr13	44.340	417525	9416	6019	136
Chr14	32.513	329508	10135	4574	141
Chr15	54.945	525072	9556	7431	135
Chr16	41.389	406794	9829	5892	142
Chr17	34.749	358216	10309	6088	175

性状 Traits	亲本 Parents		杂交后代 Hybrids
性状 Traits	鲁丽 Luli	红1# Red No. 1	范围 Range	平均值±标准差 Mean±SD	变异系数 CV (%)	正态性检验 Shapiro-Wilk test
Ci	206a	212a	105-245	184±30	16.47	Normal
Pn	20.42a	14.68b	8.20-24.50	17.40±3.37	19.22	Non
Gs	178a	145b	77-226	147±36	24.64	Normal
Tr	4.68a	3.95b	2.00-5.10	3.60±0.70	18.47	Normal
VPD	2.96a	3.06a	2.00-3.30	2.70±0.20	7.57	Non
WUE	4.38a	3.72b	2.90-8.40	4.90±1.20	24.17	Non
Vc	0.10a	0.07a	0.04-0.19	0.10±0.03	33.90	Normal
Chla	0.27a	0.20b	0.11-0.27	0.18±0.03	17.83	Normal
Chlb	0.11a	0.06b	0.03-0.11	0.06±0.01	22.35	Normal
Chl(a+b)	0.38a	0.26b	0.14-0.38	0.24±0.05	18.74	Normal
Anthocyanin	0.09b	0.31a	0.00-0.55	0.20±0.13	64.17	Non
Area	31.25a	29.49a	11.20-44.13	29.81±6.03	20.10	Normal
Length	11.95a	11.15b	6.25-14.94	11.12±1.41	12.57	Normal
Width	4.61a	4.85a	3.01-5.79	4.76±0.49	10.17	Non
Perimeter	30.99a	27.87a	17.44-39.09	30.23±3.47	11.43	Normal
Fv/Fm	0.81a	0.82a	0.30-0.84	0.73±0.09	11.77	Non
ABS/RC	1.09b	1.17a	1.05-4.75	1.81±0.67	36.78	Non
DIo/RC	0.20a	0.22a	0.17-3.19	0.58±0.49	84.19	Non
TRo/RC	0.89b	0.96a	0.88-2.08	1.25±0.24	18.78	Normal
ETo/RC	0.55a	0.51b	0.44-0.94	0.63±0.08	12.92	Non
ABS/CSo	6146a	6202a	5921-10932	7746±1090	14.01	Non
DIo/CSo	1143a	1137a	973-6117	2212±1051	7.35	Non
TRo/CSo	5003b	5065a	4251-6912	5575±343	6.12	Non
ETo/CSo	3097a	2700b	1669-3586	2929±347	11.81	Normal

KASP名称 KASP name	变异 Variation type	性状 Traits	亲本基因型 Parental genotype		杂交后代基因型 Hybrid genotype		卡方检验 χ ²
KASP名称 KASP name	变异 Variation type	性状 Traits	鲁丽 Luli	红1# Red No. 1	20个高表型极端个体 20 extremely high-phynotype individuals	20个低表型极端个体 20 extremely low-phynotype individuals	卡方检验 χ ²
KASP3343	C/A	Anthocyanin	CA	CA	CC:CA:AA=12:2:4	CC:CA:AA=3:2:13	10.17**
KASP5095	A/C	Chlb	AC	AA	AA:AC=8:6	AA:AC=15:1	5.59*
KASP5105	G/A	Chla	GA	GG	GA:GG=8:6	GA:GG=15:1	5.59*
KASP3508	C/T	Chlb	CT	CT	CC:CT:TT=3:9:2	CC:CT:TT=10:1:6	11.99**
KASP2936	T/C	Gs	TT	TC	TT:TC=8:9	TT:TC=14:3	4.64*
KASP3022	A/G	Gs	AG	GG	AG:GG=0:15	AG:GG=6:7	8.81**
KASP2608	A/T	Length	TT	AT	AT:TT=4:11	AT:TT=9:4	5.07*
KASP2718	T/A	Length	TT	TA	TT:TA=7:11	TT:TA=11:4	3.92*
KASP2744	G/A	Length	GG	GA	GG:GA=7:11	GG:GA=11:4	3.92*
KASP4678	A/T	Length	TT	AT	AT:TT=6:7	AT:TT=1:13	5.34*
KASP3350	A/G	Width	AG	AA	AA:AG=10:2	AA:AG=5:7	4.44*
KASP4591	G/T	Width	GT	GG	GG:GT=14:2	GG:GT=7:7	5.00*
KASP1587	T/C	Width	TC	TC	TT:TC:CC=9:6:3	TT:TC:CC=6:2:10	6.37*
KASP1588	C/T	Width	CT	CT	CC:CT:TT=12:2:5	CC:CT:TT=4:6:7	6.24*
KASP1584	G/T	ETo/CSo	GT	GG	GG:GT=6:5	GG:GT=17:1	6.62*
KASP1586	T/C	ETo/CSo	TC	TT	TT:TC=6:9	TT:TC=14:2	7.63**
KASP1589	C/T	ETo/CSo	CT	CC	CC:CT=7:9	CC:CT=13:3	4.80*
KASP1587	T/C	ETo/CSo	TC	TC	TT:TC:CC=4:4:9	TT:TC:CC=12:2:2	9.10**
KASP1588	C/T	ETo/CSo	CT	CT	CC:CT:TT=4:5:10	CC:CT:TT=11:4:1	10.56**
KASP1592	G/T	ETo/CSo	GT	TT	GT:TT=2:17	GT:TT=8:6	8.29**
KASP4533	G/A	ETo/CSo	GA	AA	GA:AA=2:14	GA:AA=6:6	4.73*

Development and Validation of KASP Markers Based on a Whole- Genome Resequencing Approach in a Hybrid Population of Luli × Red No. 1
