基于数据挖掘技术的高光谱土壤质地分类研究

doi:10.3864/j.issn.0578-1752.2020.21.013

Abstract

Abstract:

【Objective】 The aim of this study was to find the reflection law of Vis-NIR spectra of different soil texture types in red soil region, and to quickly and accurately predict the soil texture type by the spectrum. 【Method】 Taking the north of Fengxin County in Jiangxi Province as the research area, 245 soil samples were taken as the research objects. Under the 4 groups and 12 levels of international soil texture classification standards, the spectral reflectance of different soil texture types was analyzed first, then the data mining models combining 9 mathematical transformation methods and 5 machine learning algorithms were used to classify the soil texture, and finally analysis of the confusion matrix with the highest modeling accuracy and the triangular coordinate distribution map of prediction results. 【Result】 (1) There were many overlaps and overlaps in the spectral reflectance between different soil textures, and the law between the soil texture and the spectral reflectance was more complicated. (2) Fractional derivative transformation was an extension of the integer derivative, which was helpful for the classification of soil texture, but the original spectral data had more abundant feature information and was more suitable for the classification of soil texture. (3) Both ensemble learning methods and neural network methods were good choices when modeling unbalanced data sets. (4) It was difficult to distinguish the categories near the boundary of soil texture by using the model. Among them, clay loam group was the most likely to be predicted wrongly under the four classification standards, and clay loam and loamy clay were the two most likely to be predicted wrongly under the 12 classification standards. (5) Among the four groups of classification standards, the highest prediction accuracy (at 0.68) was obtained by the combination of normalization treatment and MLP model, and the prediction accuracy of clay loam group could reach 0.84. After subdivision to 12 levels classification, the best classification result came from combination of original data and MLP model, and the classification accuracy of loamy clay was 0.89. 【Conclusion】 The results of this study could provide a reference for soil texture classification by using hyperspectral data.

Key words: red soil region, Vis-NIR spectroscopy, soil texture, classification, data mining technology

ZHONG Liang,GUO Xi,GUO JiaXin,HAN Yi,ZHU Qing,XIONG Xing. Soil Texture Classification of Hyperspectral Based on Data Mining Technology[J].Scientia Agricultura Sinica, 2020, 53(21): 4449-4459.

0
/ / Recommend

Add to citation manager EndNote|Reference Manager|ProCite|BibTeX|RefWorks

URL: https://www.chinaagrisci.com/EN/10.3864/j.issn.0578-1752.2020.21.013

https://www.chinaagrisci.com/EN/Y2020/V53/I21/4449

Figures/Tables 11

Fig. 1

Fig. 2

Table 1

Fig. 3

Fig. 4

Table 2

Table 3

Fig. 5

Table 4

Table 5

Fig. 6

References 53

[1]	GREVE M H, KHEIR R B, GREVE M B, BØCHER P K. Quantifying the ability of environmental parameters to predict soil texture fractions using regression-tree model with GIS and LIDAR data: The case study of Denmark. Ecological Indicators, 2012,18:1-10.
[2]	SHAHRIARI M, DELBARI M, AFRASIAB P, PAHLAVAN-Rad M R. Predicting regional spatial distribution of soil texture in floodplains using remote sensing data: A case of southeastern Iran. Catena, 2019,182:104149.
[3]	吴克宁, 赵瑞. 土壤质地分类及其在我国应用探讨. 土壤学报, 2019,56(1):227-241.
	WU K N, ZHAO R. Soil texture classification and its application in China. Acta Pedologica Sinica, 2019,56(1):227-241. (in Chinese)
[4]	张娜, 张栋良, 李立新, 屈忠义. 基于高光谱的区域土壤质地预测模型建立与评价——以河套灌区解放闸灌域为例. 干旱区资源与环境, 2014,28(5):67-72.
	ZHANG N, ZHANG D L, LI L X, QU Z Y. Establishment and evaluation of model for predicting soil texture based on hyperspectral data—Case study of Jiefangzha irrigation area in Hetao irrigation district. Journal of Arid Land Resources and Environment, 2014,28(5):67-72. (in Chinese)
[5]	乔天, 吕成文, 肖文凭, 吕凯, 水宏伟. 基于遗传算法的土壤质地高光谱预测模型研究. 土壤通报, 2018,49(4):773-778.
	QIAO T, LÜ C W, XIAO W P, LÜ K, SHUI H W. Hyperspectral prediction modeling of soil texture based on genetic algorithm. Chinese Journal of Soil Science, 2018,49(4):773-778. (in Chinese)
[6]	于雷, 洪永胜, 周勇, 朱强, 徐良, 李冀云, 聂艳. 高光谱估算土壤有机质含量的波长变量筛选方法. 农业工程学报, 2016,32(13):95-102.
	YU L, HONG Y S, ZHOU Y, ZHU Q, XU L, LI J Y, NIE Y. Wavelength variable selection methods for estimation of soil organic matter content using hyperspectral technique. Transactions of the Chinese Society of Agricultural Engineering, 2016,32(13):95-102. (in Chinese)
[7]	史舟, 王乾龙, 彭杰, 纪文君, 刘焕军, 李曦. 中国主要土壤高光谱反射特性分类与有机质光谱预测模型. 中国科学:地球科学, 2014,44(5):978-988.
	SHI Z, WANG Q L, PENG J, JI W J, LIU H J, LI X. Classification of hyperspectral reflectance characteristics and prediction model of organic matter spectra of main soils in China. Scientia Sinica (Terrae), 2014,44(5):978-988. (in Chinese)
[8]	MÜLLER B BERNHARDT M, JACKISCH C, SCHULZ K. Estimating spatially distributed soil texture using time series of thermal remote sensing & ndash: A case study in central Europe. Hydrology and Earth System Sciences, 2016,20(9):3765-3775.
[9]	SAYAO V M, DEMATTÊJÉA M. Soil texture and organic carbon mapping using surface temperature and reflectance spectra in Southeast Brazil. Geoderma Regional, 2018,14:e174.
[10]	ZHAI Y S, THOMASSON J A, BOGGESS J E, SUI R X. Soil texture classification with artificial neural networks operating on remote sensing data. Computers and Electronics in Agriculture, 2006,54(2):53-68.
[11]	ZHAO Z Y, CHOW T L, REES H W, YANG Q, XING Z S, MENG F R. Predict soil texture distributions using an artificial neural network model. Computers & Electronics in Agriculture, 2009,65(1):36-48.
[12]	CHUNG S O, CHO K H, KONG J W, JUNG K Y. Soil Texture classification algorithm using RGB characteristics of soil images. IFAC Proceedings Volumes, 2010,43(26):34-38.
[13]	BARMAN U, CHOUDHURY R D. Soil texture classification using multi class support vector machine. Information Processing in Agriculture, 2020,7(2):318-332.
[14]	WU W, LI A D, HE X H, MA R, LIU H B, LÜ J K. A comparison of support vector machines, artificial neural network and classification tree for identifying soil texture classes in southwest China. Computers and Electronics in Agriculture, 2018,144:86-93.
[15]	ADHIKARI K, KHEIR R B, GREVE M B, BØCHER P K, MALONE B P, MINASNY B, MCBRATNEY A B, GREVE M H. High-resolution 3-D mapping of soil texture in denmark. Soil Science Society of America Journal, 2013,77(3):860-876.
[16]	LIE M, GLASER B, HUWE B. Uncertainty in the spatial prediction of soil texture. Geoderma, 2012,170:70-79.
[17]	孙艳俊, 张甘霖, 杨金玲, 赵玉国. 基于人工神经网络的土壤颗粒组成制图. 土壤, 2012,44(2):312-318.
	SUN Y J, ZHANG G L, YANG J L, ZHAO Y G. Mapping of soil particle composition based on artificial neural network. Soils, 2012,44(2):312-318. (in Chinese)
[18]	SILVA S H G, WEINDORF D C, PINTO L C, FARIA W M, JUNIOR F W A, GOMIDE L R, MELLO J M D, JUNIOR A L D P, SOUZA I A D, TEIXEIRA A F D S, GUILHERME L R G, CURI N. Soil texture prediction in tropical soils: A portable X-ray fluorescence spectrometry approach. Geoderma, 2020,362:114136.
[19]	BAO N S, LIU S J, ZHOU Y C. Predicting particle-size distribution using thermal infrared spectroscopy from reclaimed mine land in the semi-arid grassland of North China. Catena, 2019,183:104190.
[20]	PENG Y, KNADEL M, GISLUM RÉ, SCHELDE K, THOMSEN A, GREVE M H. Quantification of SOC and clay content using visible Near-Infrared Reflectance-Mid-Infrared reflectance spectroscopy with Jack-Knifing partial least squares regression. Soil Science, 2014: 179(7):325-332.
[21]	王德彩, 蔚霖, 张俊辉, 杨红震, 黄家荣, 孙孝林. 基于正交信号校正的Vis-NIR光谱土壤质地预测. 河南农业大学学报, 2017(3):408-413.
	WANG D C, WEI L, ZHANG J H, YANG H Z, HUANG J R, SUN X L. Prediction of soil texture using Vis-NIR spectra based on orthogonal signal correction. Journal of Henan Agricultural University, 2017(3):408-413. (in Chinese)
[22]	王德彩, 邬登巍, 赵明松, 张甘霖. 平原区土壤质地的反射光谱预测与地统计制图. 土壤通报, 2012,43(2):257-262.
	WANG D C, WU D W, ZHAO M S, ZHANG G L. Prediction and mapping of soil texture of a plain area using reflectance spectra and geo-statistics. Chinese Journal of Soil Science, 2012,43(2):257-262. (in Chinese)
[23]	沈掌泉, 单英杰, 王珂. 田间行走式测定的红外光谱数据与土壤质地之间的相关性研究. 光谱学与光谱分析, 2009,29(6):1526-1530.
	SHEN Z Q, DAN Y J, WANG K. Study on relationship between on-the-go near-infrared spectroscopy and soil texture. Spectroscopy and Spectral Analysis, 2009,29(6):1526-1530. (in Chinese)
[24]	AMIRIAN-CHAKAN A MINASNY B, TAGHIZADEH-MEHRJARDI R, AKBARIFAZLI R, DARVISHPASAND Z, KHORDEHBIN S. Some practical aspects of predicting texture data in digital soil mapping. Soil and Tillage Research, 2019,194:104289.
[25]	LARK R M, BISHOP T F A. Cokriging particle size fractions of the soil. European Journal of Soil Science, 2007,58(3):763-774.
[26]	曾庆猛, 孙宇瑞, 严红兵. 土壤质地分类的近红外光谱分析方法研究. 光谱学与光谱分析, 2009,29(7):1759-1763.
	ZENG Q M, SUN Y R, YAN H B. NIR spectral analysis for soil textural classification. Spectroscopy and Spectral Analysis, 2009,29(7):1759-1763. (in Chinese)
[27]	胡晓艳, 宋海燕. 基于支持向量机和近红外光谱特性的土壤质地分类. 山西农业科学, 2017,45(10):1643-1645.
	HU X Y, SONG H Y. Soil texture classification based on support vector machine and near infrared spectral characteristics. Journal of Shanxi Agricultural Sciences, 2017,45(10):1643-1645. (in Chinese)
[28]	白燕英, 魏占民, 刘全明, 郭桂莲, 刘霞. 基于高光谱的河套灌区农田表层土壤质地反演研究. 地理与地理信息科学, 2013,29(5):68-71.
	BAI Y Y, WEI Z M, LIU Q M, GUO G L, LIU X. Surface soil texture of field inverted using hyper-spectrum in Hetao irrigation. Geography and Geo-Information Science, 2013,29(5):68-71. (in Chinese)
[29]	SALAZAR D F U, DEMATT JÉA M, VICENTE L E, GUIMARAES C C B, SAYAO V M, CERRI C E P, PADILHA M C D C, MENDES W D S. Emissivity of agricultural soil attributes in southeastern Brazil via terrestrial and satellite sensors. Geoderma, 2020,361:114038.
[30]	黄明祥, 程街亮, 王珂, 龚建华, 李洪义, 史舟. 海涂土壤高光谱特性及其砂粒含量预测研究. 土壤学报, 2009,46(5):932-937.
	HUANG M X, CHENG J L, WANG K, GONG J H, LI H Y, SHI Z. Coastal soil hyperspectral characteristics and soil sand content prediction. Acta Pedologica Sinica, 2009,46(5):932-937. (in Chinese)
[31]	王德彩, 张俊辉. 基于Vis-NIR光谱的土壤质地BP神经网络预测. 天津农业科学, 2015,21(8):6-9.
	WANG D C, ZHANG J H. Estimation of soil texture based on Vis-NIR spectroscopy and BP neural network. Tianjin Agricultural Sciences, 2015,21(8):6-9. (in Chinese)
[32]	李春蕾, 许端阳, 陈蜀江. 基于高光谱遥感的新疆北疆地区土壤砂粒含量反演研究. 干旱区地理, 2012,35(3):473-478.
	LI C L, XU D Y, CHEN S J. Soil sand content retrieving of bare soil in north Xinjiang based on hyper-spectral remote sensing. Arid Land Geography, 2012,35(3):473-478. (in Chinese)
[33]	TONG P J, DU Y P, ZHENG K Y, WU T, WANG J J. Improvement of NIR model by fractional order Savitzky-Golay derivation(FOSGD) coupled with wavelength selection. Chemometrics and Intelligent Laboratory Systems, 2015,143:40-48.
[34]	王敬哲, 塔西甫拉提·特依拜, 丁建丽, 张东, 刘巍. 基于分数阶微分预处理高光谱数据的荒漠土壤有机碳含量估算. 农业工程学报, 2016,32(21):161-169.
	WANG J Z, TASHPOLAT TIYIP, DING J L, ZHANG D, LIU W. Estimation of desert soil organic carbon content based on hyperspectral data preprocessing with fractional differential. Transactions of the Chinese Society of Agricultural Engineering, 2016,32(21):161-169. (in Chinese)
[35]	XU Z, ZHAO X M, GUO X, GUO J X. Deep learning application for predicting soil organic matter content by Vis-NIR spectroscopy. Computational Intelligence and Neuroscience, 2019,2019:1-11.
[36]	纪文君, 李曦, 李成学, 周银, 史舟. 基于全谱数据挖掘技术的土壤有机质高光谱预测建模研究. 光谱学与光谱分析, 2012(9):91-96.
	JI W J, LI X, LI C X, ZHOU Y, SHI Z. Using different data mining algorithms to predict soil organic matter based on visible-near infrared spectroscopy. Spectroscopy and Spectral Analysis, 2012(9):91-96. (in Chinese)
[37]	ESHEL G, LEVY G J, MINGELGRIN U, SINGER M J. Critical evaluation of the use of laser diffraction for particle-size distribution analysis. Soil Science Society of America Journal, 2004,68(3):736.
[38]	杨金玲, 张甘霖, 李德成, 潘继花. 激光法与湿筛-吸管法测定土壤颗粒组成的转换及质地确定. 土壤学报, 2009(5):22-30.
	YANG J L, ZHANG G L, LI D C, PAN J H. Relationships of soil particle size distribution between sieve-pipetie and laser diffraction methods. Acta Pedologica Sinica, 2009(5):22-30. (in Chinese)
[39]	李学林, 李福春, 陈国岩, 谢昌仁, 王金平, 李文静. 用沉降法和激光法测定土壤粒度的对比研究. 土壤, 2011(1):132-136.
	LI X L, LI M C, CHEN G Y, XIE C R, WANG J P, LI W J. Comparative study on grain-size measured by laser diffraction and sedimentation techniques. Soils, 2011(1):132-136. (in Chinese)
[40]	史舟. 土壤地面高光谱遥感原理与方法. 北京: 科学出版社, 2014: 61-63.
	SHI Z. Principle and Method of Hyperspectral Remote Sensing of Soil Surface. Beijing: Science Press, 2014: 61-63. (in Chinese)
[41]	HU Y G, JIANG T, SHEN A G, LI W, WANG X, HU J. A background elimination method based on wavelet transform for Raman spectra. Chemometrics & Intelligent Laboratory Systems, 2007,85(1):94-101.
[42]	马翠红, 刘立业. 基于小波分析的光谱数据处理. 冶金分析, 2012,32(1):34-37.
	MA C H, LIU L Y. Spectral data processing based on wavelet analysis. Metallurgical Analysis(China), 2012,32(1):34-37. (in Chinese)
[43]	BENKHETTOU N, CRUZ A M C B D, TORRES D F M. A fractional calculus on arbitrary time scales: Fractional differentiation and fractional integration. Signal Processing, 2015,107:230-237.
[44]	丁世飞, 齐丙娟, 谭红艳. 支持向量机理论与算法研究综述. 电子科技大学学报, 2011,40(1):2-10.
	DING S F, QI B J, TAN H Y. An overview on theory and algorithm of support vector machines. Journal of University of Electronic Science and Technology of China, 2011,40(1):2-10. (in Chinese)
[45]	刘勇洪, 牛铮, 王长耀. 基于MODIS数据的决策树分类方法研究与应用. 遥感学报, 2005(4):405-412.
	LIU Y H, NIU Z, WANG C Y. Research and application of the decision tree classification using MODIS data. Journal of Remote Sensing, 2005(4):405-412. (in Chinese)
[46]	李勇, 刘战东, 张海军. 不平衡数据的集成分类算法综述. 计算机应用研究, 2014,31(5):1287-1291.
	LI Y, LIU Z D, ZHANG H J. Review on ensemble algorithms for imbalanced data classification. Application Research of Computers, 2014,31(5):1287-1291. (in Chinese)
[47]	孙志军, 薛磊, 许阳明, 王正. 深度学习研究综述. 计算机应用研究, 2012,29(8):2806-2810.
	SUN Z J, XUE L, XU Y M, WANG Z. Overview of deep learning. Application Research of Computers, 2012, 29(8):2806-2810. (in Chinese)
[48]	XU J F, ZHANG Y J, MIAO D Q. Three-way confusion matrix for classification: A measure driven view. Information Sciences, 2020,507:772-794.
[49]	赵小敏, 杨梅花. 江西省红壤地区主要土壤类型的高光谱特性研究. 土壤学报, 2018,55(1):31-42.
	ZHAO X M, YANG M H. Hyper-spectral characteristics of major types of soils in red soil region of Jiangxi Province, China. Acta Pedologica Sinica, 2018,55(1):31-42. (in Chinese)
[50]	国佳欣, 赵小敏, 郭熙, 徐喆, 朱青, 江叶枫. 基于PLSR-BP复合模型的红壤有机质含量反演研究. 土壤学报, 2020,57(3):636-645.
	GUO J X, ZHAO X M, GUO X, XU Z, ZHU Q, JIANG Y F. Inversion of organic matter content in red soil based on PLSR-BP composite model. Acta Pedologica Sinica, 2020,57(3):636-645. (in Chinese)
[51]	方匡南, 吴见彬, 朱建平, 谢邦昌. 随机森林方法研究综述. 统计与信息论坛, 2011,26(3):32-38.
	FANG K N, WU J B, ZHU J P, XIE B C. A review of technologies on random forests. Statistics & Information Forum, 2011,26(3):32-38. (in Chinese)
[52]	叶志飞, 文益民, 吕宝粮. 不平衡分类问题研究综述. 智能系统学报, 2009,4(2):148-156.
	YE Z F, WEN Y M, LÜ B L. A survey of imbalanced pattern classification problems. CAAI Transactions on Intelligent Systems, 2009, 4(2):148-156. (in Chinese)
[53]	CHAWLA N V, JAPKOWICZ N, KOTCZ A. Editorial: Special issue on learning from imbalanced data sets. Acm Sigkdd Explorations Newsletter, 2004,6(1):1-6.

Metrics

Viewed

Full text

Abstract

Cited

Shared

Discussed

Comments

Recommended 0

No Suggested Reading articles found!

4组分类 4 groups of classifications	12级分类 12 levels of classifications	全部样本 All samples	训练样本 Training samples	验证样本 Validation samples
壤土组 Loam group	砂质壤土 Sandy loam	29	21	8
壤土组 Loam group	壤土 Loam	9	6	3
黏壤土组 Clay loam group	砂质黏壤土 Sandy clay loam	22	16	6
	黏壤土 Clay loam	81	60	21
	粉砂质黏壤土 Silty clay loam	16	12	4
黏土组 Clay group	粉砂质黏土 Silty clay	13	9	4
黏土组 Clay group	壤质黏土 Loamy clay	75	56	19
合计 Total		245	180	65

Method	SVM	DT	AdaBoost	RF	MLP
R	0.63	0.60	0.63	0.60	0.65
Normalization	0.57	0.54	0.63	0.60	0.68
Standardization	0.60	0.55	0.63	0.60	0.62
FOD（0.5）	0.65	0.52	0.55	0.58	0.66
FOD（1）	0.52	0.55	0.62	0.55	0.63
FOD（1.5）	0.57	0.57	0.60	0.65	0.65
FOD（2）	0.54	0.57	0.60	0.60	0.63
ILR	0.51	0.58	0.63	0.63	0.63
LDR	0.52	0.58	0.58	0.55	0.62

4组分类 4 groups of classifications	壤土组 Loam group	黏壤土组 Clay loam group	黏土组 Clay group	合计 Total
壤土组 Loam group	4	7	0	11
黏壤土组 Clay loam group	1	26	4	31
黏土组 Clay group	0	9	14	23
合计 Total	5	42	18	65

Method	SVM	DT	AdaBoost	RF	MLP
R	0.48	0.46	0.52	0.51	0.55
Normalization	0.49	0.48	0.49	0.51	0.52
Standardization	0.46	0.48	0.51	0.51	0.52
FOD（0.5）	0.48	0.46	0.43	0.42	0.51
FOD（1）	0.40	0.42	0.48	0.46	0.49
FOD（1.5）	0.43	0.49	0.49	0.49	0.51
FOD（2）	0.42	0.42	0.46	0.48	0.49
ILR	0.45	0.49	0.51	0.46	0.49
LDR	0.40	0.46	0.49	0.48	0.49

12级分类 12 levels of classifications	砂质壤土 Sandy loam	砂质黏壤土 Sandy clay loam	黏壤土 Clay loam	粉砂质黏土 Silty clay	壤质黏土 Loamy clay	合计 Total
砂质壤土 Sandy loam	3	0	3	1	1	8
壤土 Loam	1	0	2	0	0	3
砂质黏壤土 Sandy clay loam	0	1	2	1	2	6
黏壤土 Clay loam	1	0	14	3	3	21
粉砂质黏壤土 Silty clay loam	0	0	4	0	0	4
粉砂质黏土 Silty clay	0	0	2	1	1	4
壤质黏土 Loamy clay	0	0	2	0	17	19
合计 Total	5	1	29	6	24	65
