糜子绿豆间作模式下糜子光合物质生产及水分利用效率

doi:10.3864/j.issn.0578-1752.2019.22.018

摘要/Abstract

摘要：

【目的】探索不同间作系统对糜子光合物质生产及水分利用的影响,筛选适于西北旱作农业区糜子与绿豆最佳间作模式,以期为糜子高产高效生产及生态环境保护提供依据。【方法】于2017—2018年连续2个作物生长季,在陕西榆林小杂粮试验示范站设置4种间作模式,包括2行糜子间作2行绿豆间作（2P2M）、4行糜子间作2行绿豆间作（4P2M）、4行糜子间作4行绿豆间作（4P4M）、2行糜子间作4行绿豆间作（2P4M）,单作糜子（SP）和单作绿豆（SM）作为对照,研究不同糜子绿豆间作系统下糜子地上叶片光合特性和叶绿素荧光参数、地下土壤水分分布和利用效率,分析糜子产量效益。【结果】与单作糜子相比,间作处理使开花期糜子旗叶叶绿素相对含量、净光合速率、气孔导度和蒸腾速率分别增加2.9%—13.5%、5.0%—32.3%、1.3%—6.3%和2.1%—8.7%,2P4M和2P2M处理使其达到最大值,提高了糜子叶片光合物质生产能力;糜子//绿豆显著增加糜子旗叶光系统Ⅱ的最大光化学效率（Fv/Fm）、光化学淬灭系数（qL）及实际光化学效率（Φ_PSII）,降低非光化学淬灭系数（NPQ）,使其间作糜子增强对光能的捕获和转化能力,减少无效的漏光损失和热量损耗,提高对高光的利用能力。间作复合系统降低糜子土壤含水量,且中层（60—140 cm）土壤含水量的降低幅度明显高于上层（0—40 cm）与下层（160—200 cm）,这与复合群体作物根系深浅搭配具有直接关系。间作有利于提高糜子的水分利用效率,2年间2P2M、4P2M、4P4M和2P4M处理平均分别比单作增加11.5%、2.3%、20.8%和30.1%,促使水分利用最大化;间作处理下的糜子生物量和产量也显著上升,4P2M间作模式下的产量比单作增加6.7%,2P4M间作模式下的产量比单作增加36.8%,增产效果明显,且间作绿豆作为劣势作物产量降低幅度较小,所创造出的土地利用率最大。【结论】糜子与绿豆间作能够增强糜子地上光合物质生产能力,延缓叶片衰老,同时改善西北旱作农业区糜子地下土壤水分利用环境,提高农田土地和水分生产力。2P4M间作模式具有最高的土地生产力和水分利用效率优势,适合于西北旱作农业区推广应用。

关键词: 糜子, 间作, 光合特性, 叶绿素荧光, 水分利用效率

Abstract:

【Objective】The propose of this study was to select the suitable proso millet-mung bean intercropping patterns in semi-arid region of northwest through studying the effects of different intercropping systems on the photosynthetic production and water use efficiency of proso millet, which can provide the basis for high yield, high efficiency production and ecological environmental protection.【Method】Field experiments were conducted in 2017 and 2018 in Yulin Modern Agriculture Demonstration Garden, Shaanxi. Four intercropping patterns were designed, 2 rows proso millet and 2 rows mung bean (2P2M), 4 rows proso millet and 2 rows mung bean (4P2M), 4 rows proso millet and 4 rows mung bean (4P4M), 2 rows proso millet and 4 rows mung bean (2P4M). The treatments containing proso millet (SP) and mung bean (SM) served as the controls. Photosynthetic characteristics and chlorophyll fluorescence parameters of leaves of proso millet as well as soil water distribution and utilization efficiency were conducted and the yield benefit was analyzed.【Result】The chlorophyll content, net photosynthesis rate, stomatal conductance, and transpiration rate of the flag leaf at anthesis stage was increased by 2.9%-13.5%, 5.0%-32.3%, 1.3%-6.3%, and 2.1%-8.7% than the single-plant systems, and thus the production capacity in the leaves of proso millet was improved. Meanwhile, proso millet//mung bean intercropping significantly increased the maximal photochemical efficiency of photosystem II (PSII) (Fv/Fm), the photochemical quenching coefficient (qL), the actual PSII efficiency (Φ_PSII) and decreased non-photochemical quenching coefficient (NPQ). This led to enhance the ability to capture and transform light energy, reducing ineffective light leakage loss and heat loss, and improving the utilization ability of high intensity light for intercropping systems. The soil water content was significantly reduced and the reduction in the middle layer (60-140 cm) was significantly higher than that in the upper layer (0-40 cm) and the lower layer (160-200 cm). The changes in soil deep structure were related to the root depth collocation. Intercropping could improve the water use efficiency, and 2P2M, 4P2M, 4P4M and 2P4M increased by 11.5%, 2.3%, 20.8% and 30.1% compared with monoculture, respectively. Further, the biomass and yield of proso millet under intercropping were also significantly increased. The yield under 4P2M and 2P4M intercropping was 6.7% and 36.8% higher than the monoculture.【Conclusion】Photosynthetic production capacity of proso millet could be promoted by proso millet//mung bean intercropping, and land use efficiency in the semi-arid region of northwest could be improved. Under this experimental condition, 2P4M intercropping system was the suitable combination for the northwest dry farming areas to promote the application.

Key words: proso millet, intercropping, photosynthesis characteristics, chlorophyll fluorescence, water use efficiency

宫香伟,党科,李境,罗艳,赵冠,杨璞,高小丽,高金锋,王鹏科,冯佰利. 糜子绿豆间作模式下糜子光合物质生产及水分利用效率[J]. 中国农业科学, 2019, 52(22): 4139-4153.

GONG XiangWei,DANG Ke,LI Jing,LUO Yan,ZHAO Guan,YANG Pu,GAO XiaoLi,GAO JinFeng,WANG PengKe,FENG BaiLi. Effects of Different Intercropping Patterns on Photosynthesis Production Characteristics and Water Use Efficiency of Proso Millet[J]. Scientia Agricultura Sinica, 2019, 52(22): 4139-4153.

图/表 12

图1

图2

表1

表2

表3

图3

图4

图5

图6

图7

图8

表4

参考文献 41

[1]	屈洋, 苏旺, 李翠, 高金锋, 高小丽, 王鹏科, 冯佰利, 柴岩 . 陕北半干旱区沟垄覆膜集水模式下糜子边际效应及生理特性. 应用生态学报, 2014,25(3):776-782.
	QU Y, SU W, LI C, GAO J F, GAO X L, WANG P K, FENG B L, CHAI Y . Border effect and physiological characteristics of broomcorn millet under film mulching on ridge-furrow for harvesting rainwater model in the semi-arid region of Northern Shaanxi, China. Chinese Journal of Applied Ecology, 2014,25(3):776-782. (in Chinese)
[2]	王延平, 邵明安 . 陕北黄土丘陵沟壑区人工草地的土壤水分植被承载力. 农业工程学报, 2012,28(18):134-141.
	WANG Y P, SHAO M A . Vegetation soil water carrying capacity of artificial pasture in loess region in Northern Shaanxi, China. Chinese Society of Agricultural Engineering, 2012,28(18):134-141. (in Chinese)
[3]	DUCHENE O, VIAN J F, CELETTE F . Intercropping with legume for agroecological cropping systems: Complementarity and facilitation processes and the importance of soil microorganisms. A review. Agriculture, Ecosystems and Environment, 2017,240:148-161.
[4]	ZHANG L, VAN DER WERF W, ZHANG S, LI B, SPIERTZ J . Growth, yield and quality of wheat and cotton in relay strip intercropping systems. Field Crops Research, 2007,103(3):178-188.
[5]	强小嫚, 孙景生, 刘浩, 宁慧峰, 吴晓磊 . 滴灌定额对西瓜/棉花间作产量及水分生产效率的影响. 农业工程学报, 2016,32(19):113-119.
	ZHANG X M, SUN J S, LIU H, NING H F, WU X L . Effects of drip irrigation quota on yield and water productivity in watermelon-cotton intercropping system. Chinese Society of Agricultural Engineering, 2016,32(19):113-119. (in Chinese)
[6]	柴强, 杨彩红, 黄高宝 . 交替灌溉对西北绿洲区小麦间作玉米水分利用的影响. 作物学报, 2011,37(9):1623-1630.
	CHAI Q, YANG C H, HUANG G B . Water use characteristics of alternately irrigated wheat/maize intercropping in oasis region of northwestern China. Acta Agronomica Sinica, 2011,37(9):1623-1630. (in Chinese)
[7]	LI B, LI Y Y, WU H M, ZHANG F F, LI C J, LI X X, LAMBERS H, LI L . Root exudates drive interspecific facilitation by enhancing nodulation and N₂ fixation. Proceedings of the National Academy of Sciences of the United States of America, 2016,113(23):6496-6501
[8]	王小林, 徐伟洲, 张雄, 张岁岐 . 黄土塬区夏玉米物质生产及水分利用对品种间作竞争的响应. 中国生态农业学报, 2018,26(3):377-387.
	WANG X L, XU W Z, ZHANG X, ZHANG S Q . Responses of dry matter distribution and water use of summer maize ( Zea mays L.) to intercropped cultivars competition on the Loess Plateau of China. Chinese Journal of Eco-Agriculture, 2018,26(3):377-387. (in Chinese)
[9]	REN Y Y, LIU J J, WANG Z L, ZHANG S Q . Planting density and sowing proportions of maize-soybean intercrops affected competitive interactions and water-use efficiencies on the Loess Plateau, China. European Journal of Agronomy, 2016,72:70-79.
[10]	高砚亮, 孙占祥, 白伟, 冯良山, 杨宁, 蔡倩, 冯晨, 张哲 . 辽西半干旱区玉米与花生间作对土地生产力和水分利用效率的影响. 中国农业科学, 2017,50(19):3702-3713.
	GAO Y L, SUN Z X, BAI W, FENG L S, YANG N, CAI Q, FENG C, ZHANG Z . Productivity and water use efficiency of maize-peanut intercropping systems in the semi-arid region of western Liaoning Province. Scientia Agricultura Sinica, 2017,50(19):3702-3713. (in Chinese)
[11]	牛伊宁, 刘冬梅, 罗珠珠, 柴强 . 不同供水水平对玉米/豌豆间作系统作物耗水特征的影响. 干旱地区农业研究, 2018,36(1):83-88.
	NIU Y N, LIU D M, LUO Z Z, CHAI Q . Characteristics of crop water consumption under maize/pea intercropping systems with different irrigation levels. Agricultural Research in the Arid Areas, 2018,36(1):83-88. (in Chinese)
[12]	吕越, 吴普特, 陈小莉, 王玉宝, 赵西宁 . 地上部与地下部作用对玉米/大豆间作优势的影响. 农业机械学报, 2014,45(1):129-136.
	LÜ Y, WU P T, CHEN X L, WANG Y B, ZHAO X N . Effect of above-and below-ground interactions on maize/soybean intercropping advantage. Chinese Society for Agricultural Machinery, 2014,45(1):129-136. (in Chinese)
[13]	YANG F, LIAO D P, WU X L, GAO R C, FAN Y F, RAZA M A, WANG X C, YONG T W, LIU W G, LIU J, DU J B, SHU K, YANG W Y . Effect of aboveground and belowground interactions on the intercrop yields in maize-soybean relay intercropping systems. Field Crops Research, 2017,203:16-23.
[14]	焦念元, 宁堂原, 赵春, 王芸, 史忠强, 侯连涛, 付国占, 江晓东, 李增嘉 . 玉米花生间作复合体系光合特性的研究. 作物学报, 2006,32(6):917-923.
	JIAO N Y, NING T Y, ZHAO C, WANG Y, SHI Z Q, HOU L T, FU G Z, JIANG X D, LI Z J . Characters of photosynthesis in intercropping system of maize and peanut. Acta Agronomica Sinica, 2006,32(6):917-923. (in Chinese)
[15]	冯晓敏, 杨永, 任长忠, 胡跃高, 曾昭海 . 豆科-燕麦间作对作物光合特性及籽粒产量的影响. 作物学报, 2015,41(9):1426-1434.
	FENG X M, YANG Y, REN C Z, HU Y G, ZENG Z H . Effects of legumes intercropping with oat on photosynthesis characteristics of and grain yield. Acta Agronomica Sinica, 2015,41(9):1426-1434. (in Chinese)
[16]	柴岩 . 中国小杂粮产业发展报告. 北京: 中国农业科学技术出版社, 2007.
	CHAI Y. Report for Chinese Minor Grain Crops Industry Development. Beijing: China Agricultural Science and Technology Press, 2007. (in Chinese)
[17]	柴岩, 冯佰利, 孙世贤 . 中国小杂粮品种. 北京: 中国农业科学技术出版社, 2007.
	CHAI Y, FENG B L, SUN S X. Varieties of Minor Grain Crops in China. Beijing: China Agricultural Science and Technology Press, 2007. (in Chinese)
[18]	宫香伟, 韩浩坤, 张大众, 李境, 王孟, 薛志和, 杨璞, 高小丽, 冯佰利 . 氮肥运筹对糜子生育后期干物质积累与转运及叶片氮素代谢的调控效应. 中国农业科学, 2018,51(6):1045-1056.
	GONG X W, HAN H K, ZHANG D Z, LI J, WANG M, XUE Z H, YANG P, GAO X L, FENG B L . Effects of nitrogen fertilizer on dry matter accumulation, transportation and nitrogen metabolism in functional leaves of broomcorn millet at late growth stage. Scientia Agricultura Sinica, 2018,51(6):1045-1056. (in Chinese)
[19]	LIU Y X, ZHANG W P, SUN J H, Li X F, CHRISTIE P, LI L . High morphological and physiological plasticity of wheat roots is conducive to higher competitive ability of wheat than maize in intercropping systems. Plant and Soil, 2015,397(1/2):387-399.
[20]	ZHANG W P, LIU G C, SUN J H, ZHANG L Z, WEINER J, LI L . Growth trajectories and interspecific competitive dynamics in wheat/maize and barley/maize intercropping. Plant and Soil, 2015,397(1/2):227-238.
[21]	XIA H Y, ZHAO J H, SUN J H, XUE Y F, EAGLING T, BAO X G, ZHANG F S, Li L . Maize grain concentrations and above-ground shoot acquisition of micronutrients as affected by intercropping with turnip, faba bean, chickpea, and soybean. Science China-Life Sciences, 2014,56:823-834.
[22]	MAXWELL K, JOHNSON G N . Chlorophyll fluorescence-a practical guide. Journal of Experimental Botany, 2000,51:659-668.
[23]	WANG Z K, WU P T, ZHAO X N, GAO Y, CHEN X L . Water use and crop coefficient of the wheat-maize strip intercropping system for an arid region in northwestern China. Agricultural Water Management, 2015,161:77-85.
[24]	ZHANG D S, ZHANG L Z, LIU J G, Han S, WANG Q, EVERS J C, LIU J, VAN DER W, LI L . Plant density affects light interception and yield in cotton grown as companion crop in young jujube plantations. Field Crops Research, 2014,169:132-139.
[25]	宫香伟, 刘春娟, 冯乃杰, 郑殿峰, 王畅 . S₃₃₀₇和DTA-6对大豆不同冠层叶片光合特性及产量的影响. 植物生理学报, 2017,53(10):1867-1876.
	GONG X W, LIU C J, FENG N J, ZHENG D F, WANG C . Effects of plant growth regulators S₃₃₀₇ and DTA-6 on photosynthetic characteristics and yield in soybean canopy. Plant Physiology Journal, 2017,53(10):1867-1876. (in Chinese)
[26]	焦念元, 李亚辉, 杨潇, 尹飞, 马超, 齐付国, 刘领, 熊瑛 . 玉米/花生间作行比和施磷对玉米光合特性的影响. 应用生态学报, 2016,27(9):2959-2967.
	JIAO N Y, LI Y H, YANG X, YIN F, MA C, QI F G, LIU L, XIONG Y . Effects of maize /peanut intercropping row ratio and phosphate fertilizer on photosynthetic characteristics of maize. Chinese Journal of Applied Ecology, 2016,27(9):2959-2967. (in Chinese)
[27]	滕菲, 李盛有, 饶德民, 姚兴东, 张惠君, 敖雪, 王海英, MARTIN S S, 谢甫绨 . 超高产大豆砧木对不同年代育成品种光合生理指标和产量性状的影响. 中国农业科学, 2016,49(23):4531-4543.
	TENG F, LI S Y, RAO D M, YAO X D, ZHANG H J, AO X, WANG H Y, MARTIN S S, XIE F T . Effects of super-high-yield soybean cultivars as rootstock on some physiological and yield traits of cultivars released in different decades. Scientia Agricultura Sinica, 2016,49(23):4531-4543. (in Chinese)
[28]	FARQUHAR G D, SHARKEY T D . Stomatal conductance and photosynthesis. Annual Review of Plant Physiology, 1982,33(1):317-345.
[29]	焦念元, 宁堂原, 杨萌珂, 付国占, 尹飞, 徐国伟, 李增嘉 . 玉米花生间作对玉米光合特性及产量形成的影响. 生态学报, 2013,33(14):4324-4330.
	JIAO N Y, NING T Y, YANG M K, FU G Z, YIN F, XU G W, LI Z J . Effects of maize‖peanut intercropping on photosynthetic characters and yield forming of intercropped maize. Acta Ecologica Sinica, 2013,33(14):4324-4330. (in Chinese)
[30]	CORDON G, LAGORIO M G, PARUELO J M . Chlorophyll fluorescence, photochemical reflective index and normalized difference vegetative index during plant senescence. Journal of Plant Physiology, 2016,199:100-110.
[31]	LI Y B, SONG H, ZHOU L, XU Z Z, ZHOU G S . Tracking chlorophyll ﬂuorescence as an indicator of drought and rewatering across the entire leaf lifespan in a maize field. Agricultural Water Management, 2019,211:190-201.
[32]	贾曼曼, 肖靖秀, 汤利, 郑毅 . 不同施氮量对小麦蚕豆间作作物产量及其光合特征的影响. 云南农业大学学报(自然科学), 2017,32(2):350-357.
	JIA M M, XIAO J X, TANG L, ZHENG Y . Effects of nitrogen supply on yields and photosynthesis characteristics of crops in wheat and broad bean intercropping. Journal of Yunnan Agricultural University (Natural Science), 2017,32(2):350-357. (in Chinese)
[33]	杜成凤, 李潮海, 刘天学, 赵亚丽 . 遮荫对两个基因型玉米叶片解剖结构及光合特性的影响. 生态学报, 2011,31(21):6633-6640.
	DU C F, LI C H, LIU T X, ZHAO Y L . Response of anatomical structure and photosynthetic characteristics to low light stress in leaves of different maize genotypes. Acta Ecologica Sinica, 2011,31(21):6633-6640. (in Chinese)
[34]	毕焕改, 王美玲, 姜振升, 董绪兵, 艾希珍 . 亚适温弱光对黄瓜幼苗光合酶活性和基因表达的影响. 应用生态学报, 2011,22(11):2894-2900.
	BI H G, WANG M L, JIANG Z S, DONG X B, AI X Z . Impacts of suboptimal temperature and low light intensity on the activities and gene expression of photosynthetic enzymes in cucumber seedling leaves. Chinese Journal of Applied Ecology, 2011,22(11):2894-2900. (in Chinese)
[35]	张凤云, 吴普特, 赵西宁, 成雪峰 . 间套作提高农田水分利用效率的节水机理. 应用生态学报, 2012,23(5):1400-1406.
	ZHANG F Y, WU P T, ZHAO X N, CHENG X F . Water-saving mechanisms of intercropping system in improving cropland water use efficiency. Chinese Journal of Applied Ecology, 2012,23(5):1400-1406. (in Chinese)
[36]	赵英, 张斌, 王明珠 . 农林复合系统中物种间水肥光竞争机理分析与评价. 生态学报, 2006,26(6):1792-1801.
	ZHAO Y, ZHANG B, WANG M Z . Assessment of competition for water, fertilizer and light between components in the alley cropping system. Acta Ecologica Sinica, 2006,26(6):1792-1801. (in Chinese)
[37]	SHEN Y F, ZHANG Y, LI S Q . Nutrient effects on diurnal variation and magnitude of hydraulic lift in winter wheat. Agricultural Water Management, 2011,98:1589-1594.
[38]	宫香伟, 李境, 马洪驰, 陈光华, 王孟, 杨璞, 高金锋, 冯佰利 . 黄土高原旱作区糜子-绿豆带状种植农田小气候特征与产量效应. 应用生态学报, 2018,29(10):3256-3266.
	GONG X W, LI J, MA H C, CHEN G H, WANG M, YANG P, GAO J F, FENG B L . Field microclimate and yield for proso millet intercropping with mung bean in the dryland of Loess Plateau, China. Chinese Journal of Applied Ecology, 2018,29(10):3256-3266. (in Chinese)
[39]	WANG Q S, SUN D B, HAO H, ZHAO X J, HAO W P, LIU Q . Photosynthetically active radiation determining yields for an intercrop of maize with cabbage. European Journal of Agronomy, 2015,69:32-40.
[40]	YIN W, CHEN G P, FENG F X, GUO Y, HU F L, CHEN G D, ZHAO C, YU A Z, CHAI Q . Straw retention combined with plastic mulching improves compensation of intercropped maize in arid environment. Field Crops Research, 2017,204:42-51.
[41]	WANG D Y, XU C M, CHEN S, TIAO L X, ZHANG X F . Photosynthesis and dry matter accumulation in different chlorophyll- deficient rice lines. Journal of Integrative Agriculture, 2012,11(3):397-404.

年份 Year	处理 Treatment	单株穗数 Panicles number (No./plant)	穗长 Panicle length (cm)	单株粒重 Grain weight (g/plant)	千粒重 1000-grain weight(g)	产量 Grain yield (kg·hm^-2)
2017	SP	4.0±0.7d	39.2±1.3cd	24.0±1.9e	8.61±0.0d	4448.6±135.5d
	2P2M	4.8±0.8bc	41.2±2.1c	35.3±1.1c	8.89±0.1bc	4968.9±87.2bc
	4P2M	4.3±0.4c	40.1±1.0c	32.5±1.6d	8.81±0.0c	4696.2±76.8c
	4P4M	4.9±0.2b	42.2±0.8b	40.9±0.4b	8.92±0.1b	5131.6±73.5b
	2P4M	5.8±0.4a	44.0±1.8a	46.6±2.5a	9.02±0.0a	5367.8±56.8a
2018	SP	3.4±0.9b	46.4±2.2a	29.0±1.3d	8.66±0.1c	4205.7±257.7d
	2P2M	4.6±2.0ab	47.0±2.5a	41.8±0.8b	9.00±0.0b	5153.8±150.7b
	4P2M	4.4±1.1ab	46.6±2.6a	36.7±0.7c	9.03±0.1ab	4539.8±144.6c
	4P4M	5.2±1.5ab	47.2±1.9a	43.2±0.7b	9.10±0.1ab	5249.6±147.3b
	2P4M	6.2±1.1a	47.2±1.6a	50.4±1.2a	9.18±0.0a	6471.2±236.6a
变异来源Variation source
年份Year		NS	**	**	**	*
处理Treatment		**	*	**	**	*
年份×处理Year × Treatment		NS	NS	NS	NS	NS

年份 Year	处理 Treatment	分枝数 Branch number (No./plant)	荚数 Pods number (No./plant)	单株粒重 Grain weight (g/plant)	百粒重 100-grain weight (g)	产量 Grain yield (kg·hm^-2)
2017	SM	14.3±2.2a	32.4±1.8a	11.6±0.7a	6.39±0.7a	1297.3±140.3a
	2P2M	8.6±1.8cd	22.1±1.7c	4.9±0.3d	6.01±1.3a	607.2±38.8d
	4P2M	7.6±1.2d	19.8±1.5d	4.2±0.3e	5.95±0.6a	573.1±79.6e
	4P4M	10.6±0.7bc	23.7±1.1c	6.0±0.2c	6.11±0.6a	722.3±67.5c
	2P4M	11.9±0.4b	27.8±1.3b	7.3±0.2b	6.23±0.4a	845.5±43.7b
2018	SM	15.3±2.4a	52.3±9.6a	16.3±1.8a	7.13±0.2a	1483.7±36.5a
	2P2M	11.8±1.7b	35.3±8.8b	10.0±1.0bc	6.99±0.3ab	920.5±56.3b
	4P2M	10.8±1.5b	31.5±11.7b	8.6±1.2c	6.30±0.2b	908.3±64.0b
	4P4M	12.5±1.7ab	37.8±4.1b	10.3±1.5bc	6.41±0.6ab	957.6±59.5b
	2P4M	12.0±2.8ab	42.8±5.9ab	11.2±2.2b	6.65±0.8ab	973.5±57.6b
变异来源Variation source
年份Year		NS	**	**	NS	**
处理Treatment		**	**	**	NS	**
年份×处理Year × Treatment		NS	NS	NS	NS	*

年份Year	处理 Treatment	经济效益Economic benefits				土地当量比 Land equivalent ratio
年份Year	处理 Treatment	农资总投入 Total material input (Yuan/hm²)	总产值 Output value (Yuan/hm²)	经济效益 Economic benefit (Yuan/hm²)	产投比 Input-output ratio	土地当量比 Land equivalent ratio
2017	SP	900	10676.4±325.3a	9776.4±325.3a	11.9±0.4a	—
	SM	1500	10378.8±83.0b	8878.8±83.0c	6.9±0.1f	—
	2P2M	1200	9385.3±122.6d	8185.3±122.6d	7.8±0.1d	1.59±0.03c
	4P2M	1100	10294.5±167.2bc	9194.5±167.2b	9.4±0.2b	1.50±0.02d
	4P4M	1200	10037.7±93.6c	8873.7±93.6c	8.4±0.1c	1.71±0.04b
	2P4M	1300	9519.0±68.1d	8219.0±68.1d	7.3±0.1e	1.86±0.02a
2018	SP	850	10934.8±670.0bc	10084.8±670.0a	12.9±0.8a	—
	SM	1700	11869.7±292.1a	10169.7±292.1a	7.0±0.2d	—
	2P2M	1275	10842.0±346.7bc	9567.0±346.7a	8.5±0.3c	1.86±0.18b
	4P2M	1133	10593.9±415.3c	9460.9±415.3a	9.4±0.4b	1.71±0.20b
	4P4M	1275	11133.62±365.7bc	9858.6±365.7a	8.7±0.3bc	1.91±0.18ab
	2P4M	1558	11449.3±522.5ab	9891.3±522.5a	7.3±0.3d	2.22±0.29a

指标 Index	叶绿素相对含量 SPAD	净光合速率 Pn	最大光化学效率 Fv/Fm	实际光化学效率 Φ_PSⅡ	生物量 Biomass	水分利用效率 WUE
单株穗数Panicles number	0.734**	0.612*	0.618*	0.723**	0.642*	0.570*
穗长Panicle length	0.573*	0.657*	0.577*	0.530*	0.614*	0.567*
单株粒重Grain weight	0.946**	0.958**	0.917**	0.956**	0.982**	0.941**
千粒重1000-grain weight	0.820**	0.822**	0.720**	0.820**	0.838**	0.716*
产量Grain yield	0.940**	0.945**	0.895**	0.908**	0.964**	0.975**
