蜜蜂免移虫技术研究与应用

doi:10.3864/j.issn.0578-1752.2018.22.016

Abstract

Abstract:

【Objective】 In the beekeeping industry, beekeepers need to conduct artificial larvae grafting either for royal jelly harvesting or for rearing queens artificially. Artificially grafting larvae requires beekeepers to have good eyesight and high proficiency. Especially with the increase of labor cost and the aging of beekeepers, artificially grafting larvae is a technical limitation that needs to be solved in the production of beekeeping. Under the support of the National Bee Industry Technology System for ten consecutive years, our team has been engaged in the research of non-grafting larvae technology. The objective of this study is to remove the limitation of artificially grafting larvae and to provide technical support for scientific beekeeping.【Method】Based on the biological characteristics of bees and the principle of bionics, a food-grade plastic worker comb foundation with regular holes was designed. The holes in the plastic worker comb foundation allow the assembly of larvae supporting devices or single queen cell bases. The idea was to assemble the hollow plastic worker comb foundation and the larvae supporting device or queen cell bases together to make a complete comb foundation firstly, and then to let the workers build the comb. Next, the queen is allowed to lay eggs in the cells of the comb. This is followed by removing the larvae supporting device or queen cell bases and assembling them into the queen cell bar with regular holes. In this way, royal jelly production or breeding queens can be achieved. This study tested the feasibility of the improved 10th generation of the non-grafting larvae technique of royal jelly harvesting and rearing queens, using the Italian bee (Apis mellifera ligustica) as the experimental system. Firstly, the number of combs in a colony which is about to swarm was reduced, and then the workers were allowed to build 10-12 pieces of combs based on the hollow plastic comb foundation, then the effect of royal jelly harvesting or rearing queens without larvae grafting was investigated. The experiment of royal jelly harvesting without artificially grafting larvae mainly measured the oviposition rate of one queen, two queens, multi-queen (four queens). The acceptance rate of newly assembled queen cells by nursing bees during royal jelly production was also measured. In the experiment of breeding queens without artificially grafting larvae, a single queen was allowed to lay eggs for 6 h. Then the birth weight and the number of ovarioles of the newly bred queens that developed from the eggs were measured. The methods of rearing queens without and with artificially grafting larvae were compared.【Result】Worker bees can build a complete comb based on the plastic hollow comb foundation, and the queen can lay eggs on the newly built comb. The oviposition rate of a single queen, double queens, multi-queen was 91.24%, 92.45% and 91.29%, respectively. The acceptance rate of newly assembled queen cells during royal jelly harvesting was 91.12%, 92.63% and 90.19%, respectively. There was no significant difference among them (P>0.05). The weight of the newly queens using the method of egg-based rearing queens without artificially grafting larvae and the method of grafting larvae based rearing queens was (256.31±3.75) mg and (243.43±2.05) mg, respectively. The number of ovarioles in unilateral ovary was (163.87±9.40) and (154.77±6.74), respectively. There was a significant difference between the two methods (P<0.05).【Conclusion】This study showed that the improved 10th generation of non-grafting larvae oviposition device can be used in royal jelly production and for rearing queens. It is worth popularizing and applying in the beekeeping industry.

Key words: honeybee, non-grafting larvae, royal jelly harvesting, queen rearing

ZHANG Bo,WU XiaoBo,LIAO ChunHua,HE XuJiang,YAN WeiYu,ZENG ZhiJiang. Research and Application of Honeybee Non-Grafting Larvae Technology[J].Scientia Agricultura Sinica, 2018, 51(22): 4387-4394.

0
/ / Recommend

Add to citation manager EndNote|Reference Manager|ProCite|BibTeX|RefWorks

URL: https://www.chinaagrisci.com/EN/10.3864/j.issn.0578-1752.2018.22.016

https://www.chinaagrisci.com/EN/Y2018/V51/I22/4387

Figures/Tables 10

Fig. 1

Fig. 2

Fig. 3

Fig. 4

Fig. 5

Fig. 6

Fig. 7

Table 1

Table 2

Fig. 8

References 30

[1]	曾志将 . 养蜂学. 3版. 北京: 中国农业出版社, 2017.
	ZENG Z J. Apiculture. 3rd ed. Beijing: China Agriculture Press, 2017. ( in Chinese)
[2]	曾志将 . 蜂王浆机械化生产技术. 北京: 中国农业出版社, 2013.
	ZENG Z J. Technique for Mechanized Production of Royal Jelly. Beijing: China Agriculture Press, 2013. ( in Chinese)
[3]	陈盛禄, 林雪珍, 胡福良, 苏松坤, 方章明 . 浙农大A系意蜂王浆高产试验. 中国农业科学, 1995,28(5):89-93.
	CHEN S L, LIN X Z, HU F L, SU S K, FANG Z M . An experiment on the high royal jelly production of Zhenongda A line queens. Scientia Agricultura Sinica, 1995,28(5):89-93. (in Chinese)
[4]	金水华 . 中国平湖意蜂研究. 杭州: 浙江大学出版社, 2008.
	JIN S H. Study on China Pinghu Italian Bee. Hangzhou: Zhejiang University Press, 2008. ( in Chinese)
[5]	陈盛禄, 林雪珍 . 新型高产全塑台基条的研制. 中国养蜂, 1987,38(2):9-10.
	CHEN S L, LIN X Z . Design and application of new plastic queen cells for gathering royal jelly. Apiculture of China, 1987,38(2):9-10. (in Chinese)
[6]	杨多福 . 生产蜂王浆机械化. 蜜蜂杂志, 1990,10(7):22-25.
	YANG D F . Mechanized production of royal jelly. Journal of Bee, 1990,10(7):22-25. (in Chinese)
[7]	金汤东 . 快速离心式移虫技术研究初报. 中国蜂业, 2005,25(3):6-7.
	JIN T D . Initial report on spin-off larval transplantation technology. Apiculture of China, 2005,25(3):6-7. (in Chinese)
[8]	何世钧 . 用摇蜜机可取浆、移虫. 蜜蜂杂志, 2009,29(6):16-17.
	HE S J . Getting royal jelly and grafting larvae by honey extractor. Journal of Bee, 2009,29(6):16-17. (in Chinese)
[9]	甘海燕, 田柳青, 颜伟玉 . 蜂王卵巢切片及染色技术. 蜜蜂杂志, 2012,32(2):9. doi: 10.3969/j.issn.1003-9139.2012.02.006
	GAN H Y, TIAN L Q, YAN W Y . Ovarian sectioning and staining of the queen. Journal of Bee, 2012,32(2):9. (in Chinese) doi: 10.3969/j.issn.1003-9139.2012.02.006
[10]	WOYKE J . Correlations between the age at which honeybee brood was grafted, characteristics of the resultant queens, and results of insemination. Journal of Apicultural Research, 1971,10(1):45-55. doi: 10.1080/00218839.1971.11099669
[11]	RANGEL J, KELLER J J, TARPY D R . The effects of honey bee (Apis mellifera L.) queen reproductive potential on colony growth. Insectes Sociaux, 2013,60(1):65-73. doi: 10.1007/s00040-012-0267-1
[12]	HE X J, ZHOU L B, PAN Q Z, BARRON A B, YAN W Y, ZENG Z J . Making a queen: an epigenetic analysis of the robustness of the honey bee (Apis mellifera) queen developmental pathway. Molecular Ecology, 2017,26(6):1598-1607. doi: 10.1111/mec.13990 pmid: 28026884
[13]	刘光楠, 曾志将, 吴小波, 颜伟玉 . 免移虫生产蜂王浆技术研究. 蜜蜂杂志, 2009,29(10):3-6. doi: 10.3969/j.issn.1003-9139.2009.10.001
	LIU G N, ZENG Z J, WU X B, YAN W Y . Study on the technique of royal jelly production without grafting larvae. Journal of Bee, 2009,29(10):3-6. (in Chinese) doi: 10.3969/j.issn.1003-9139.2009.10.001
[14]	曾志将, 吴小波, 张飞, 刘光楠, 颜伟玉, 王子龙 . 蜂王浆机械化生产关键技术研究与应用(Ⅰ): 蜜蜂仿生免移虫生产器设计. 江西农业大学学报, 2013,35(4):842-847. doi: 10.3969/j.issn.1000-2286.2013.04.031
	ZENG Z J, WU X B, ZHANG F, LIU G N, YAN W Y, WANG Z L . Research and application of key technique for mechanized production of royal jelly (Ⅰ): A design of bionic non-grafting larvae ovipositor. Acta Agriculturae Universitatis Jiangxiensis, 2013,35(4):842-847. (in Chinese) doi: 10.3969/j.issn.1000-2286.2013.04.031
[15]	张飞, 吴小波, 颜伟玉, 王子龙, 曾志将 . 蜂王浆机械化生产关键技术研究与应用(Ⅱ): 蜜蜂仿生免移虫蜂王浆生产技术. 江西农业大学学报, 2013,35(5):1036-1041. doi: 10.3969/j.issn.1000-2286.2013.05.025
	ZHANG F, WU X B, YAN W Y, WANG Z L, ZENG Z J . Research and application of key technique for mechanized production of royal jelly (Ⅱ): A bionic non-grafting larvae technique for royal jelly production. Acta Agriculturae Universitatis Jiangxiensis, 2013,35(5):1036-1041. (in Chinese) doi: 10.3969/j.issn.1000-2286.2013.05.025
[16]	张飞, 吴小波, 颜伟玉, 王子龙, 曾志将 . 蜂王浆机械化生产关键技术研究与应用(Ⅲ): 仿生免移虫生产蜂王浆蜂群配套饲养技术. 江西农业大学学报, 2013,35(6):1261-1265.
	ZHANG F, WU X B, YAN W Y, WANG Z L, ZENG Z J . Research and application of key technique for mechanized royal jelly production (Ⅲ): Supporting breeding technology with honeybee colony breeding for bionic non-grafting larvae royal jelly production. Acta Agriculturae Universitatis Jiangxiensis, 2013,35(6):1261-1265. (in Chinese)
[17]	潘其忠, 林金龙, 吴小波, 周林斌, 张飞, 颜伟玉, 曾志将 . 蜂王浆机械化生产关键技术研究与应用(Ⅳ): 机械化取浆器设计及应用. 江西农业大学学报, 2013,35(6):1266-1271. doi: 10.3969/j.issn.1000-2286.2013.06.026
	PAN Q Z, LIN J L, WU X B, ZHOU L B, ZHANG F, YAN W Y, ZENG Z J . Research and application of key technique for mechanized production of royal jelly (Ⅳ): Design and application of a machine for gathering royal jelly. Acta Agriculturae Universitatis Jiangxiensis, 2013,35(6):1266-1271. (in Chinese) doi: 10.3969/j.issn.1000-2286.2013.06.026
[18]	邹垂彬, 周林斌, 胡景华, 席芳贵, 袁芳, 颜伟玉 . 免移虫育王和两种酯类幼虫信息素对中华蜜蜂蜂王质量的影响. 中国农业科学, 2016,49(18):3662-3670. doi: 10.3864/j.issn.0578-1752.2016.18.020
	ZOU C B, ZHOU L B, HU J H, XI F G, YUAN F, YAN W Y . Effects of queen-rearing without larvae-grafting and two esters of brood pheromone on the queen quality of Apis cerana cerana. Scientia Agricultura Sinica, 2016,49(18):3662-3670. (in Chinese) doi: 10.3864/j.issn.0578-1752.2016.18.020
[19]	杜亚丽, 张中印, 潘建芳, 王树杰, 杨爽, 赵慧婷, 姜玉锁 . 中华蜜蜂气味结合蛋白基因AcerOBP14的克隆及时空表达. 中国农业科学, 2016,49(19):3852-3862. doi: 10.3864/j.issn.0578-1752.2016.19.016
	DU Y L, ZHANG Z Y, PAN J F, WANG S J, YANG S, ZHAO H T, JIANG Y S . Cloning and expression analysis of odorant binding protein gene AcerOBP14 from Apis cerana cerana. Scientia Agricultura Sinica, 2016,49(19):3852-3862. (in Chinese) doi: 10.3864/j.issn.0578-1752.2016.19.016
[20]	秦明, 王红芳, 刘振国, 王颖, 王帅, 郗学鹏, 刘春蕾, 张卫星, 胥保华 . 中华蜜蜂和意大利蜜蜂耐寒性能差异比较. 中国农业科学, 2017,50(12):2380-2388. doi: 10.3864/j.issn.0578-1752.2017.12.018
	QIN M, WANG H F, LIU Z G, WANG Y, WANG S, CHI X P, LIU C L, ZHANG W X, XU B H . Comparison of different cold resistance between Apis cerana cerana and Apis mellifera ligustica. Scientia Agricultura Sinica, 2017,50(12):2380-2388. (in Chinese) doi: 10.3864/j.issn.0578-1752.2017.12.018
[21]	谭静, 宋欣密, 傅晓斌, 唐明珠, 吴帆, 华启云, 李红亮 . 中华蜜蜂化学感受蛋白CSP1的功能模式分析及亚细胞定位. 中国农业科学, 2017,50(15):3052-3062. doi: 10.3864/j.issn.0578-1752.2017.15.019
	TAN J, SONG X M, FU X B, TANG M Z, WU F, HUA Q Y, LI H L . Functional mode and immunocytochemical localization of chemosensory protein 1 (CSP1) in Apis cerana cerana. Scientia Agricultura Sinica, 2017,50(15):3052-3062. (in Chinese) doi: 10.3864/j.issn.0578-1752.2017.15.019
[22]	江武军, 吴小波, 刘光楠, 何旭江, 颜伟玉, 曾志将 . 天然蜂粮生产技术研究与应用. 中国农业科学, 2017,50(19):3828-3836. doi: 10.3864/j.issn.0578-1752.2017.19.019
	JIANG W J, WU X B, LIU G N, HE X J, YAN W Y, ZENG Z J . Research and application of production technology of natural honeybee bread. Scientia Agricultura Sinica, 2017,50(19):3828-3836. (in Chinese) doi: 10.3864/j.issn.0578-1752.2017.19.019
[23]	李爽, 李建科 . 蜂王浆高产蜜蜂与意大利蜜蜂工蜂上颚腺磷酸化蛋白质组分析. 中国农业科学, 2017,50(23):4656-4670.
	LI S, LI J K . Comparative analysis of phosphoproteome between mandibular glands of high royal jelly producing bees and italian bees. Scientia Agricultura Sinica, 2017,50(23):4656-4670. (in Chinese)
[24]	BEGNA D, FANG Y, FENG M, LI J K . Mitochondrial proteins differential expression during honeybee (Apis mellifera L.) queen and worker larvae caste determination. Journal of Proteome Research, 2011,10(9):4263-4280.
[25]	CHEN X, HU Y, ZHENG H Q, CAO L F, NIU D F, YU D L, SUN Y Q, HU S N, HU F L . Transcriptome comparison between honey bee queen- and worker-estined larvae. Insect Biochemistry and Molecular Biology, 2012,42(9):665-673. doi: 10.1016/j.ibmb.2012.05.004 pmid: 22659440
[26]	GUO X Q, SU S K, SKOGERBOE G, DAI S J, LI W F, LI Z G, LIU F, NI R F, GUO Y, CHEN S L, ZHANG S W, CHEN R S . Recipe for a busy bee: microRNAs in honey bee caste determination. PLoS ONE, 2013,8(12):e81661. doi: 10.1371/journal.pone.0081661 pmid: 24349106
[27]	SHI Y Y, HUANG Z Y, ZENG Z J, WANG Z L, WU X B, YAN W Y . Diet and cell size both affect queen-worker differentiation through DNA methylation in honey bees (Apis mellifera, Apidae). PLoS ONE, 2011,6(4):e18808. doi: 10.1371/journal.pone.0018808 pmid: 3082534
[28]	SHI Y Y, YAN W Y, HUANG Z Y, WANG Z L, WU X B, ZENG Z J . Genome wide analysis indicates that queen larvae have lower methylation levels in the honey bee (Apis mellifera). Naturwissenschaften, 2013,100(2):193-197. doi: 10.1007/s00114-012-1004-3 pmid: 23238637
[29]	SHI Y Y, ZHENG H J, PAN Q Z, WANG Z L, ZENG Z J . Differentially expressed microRNAs between queen and worker larvae of honey bee (Apis mellifera). Apidologie, 2015,46(1):35-45. doi: 10.1007/s13592-014-0299-9
[30]	SHI Y Y, LIU H, QIU Y F, MA Z Y, ZENG Z J . DNA methylation comparison between 4-day-old queen and worker larvae of honey bee. Journal of Asia-Pacific Entomology, 2017,20(1):299-303. doi: 10.1016/j.aspen.2017.01.014

Metrics

Viewed

Full text

Abstract

Cited

Shared

Discussed

Comments

Recommended 0

No Suggested Reading articles found!

产卵方法 Oviposition method	产卵时间 Oviposition duration (h)	空巢房数（个） Number of empty cells	产卵效率 Oviposition efficiency (%)	王台接受率 Acceptance rate of queen cells (%)
单王群Colony with one queen	15	1024	91.24±4.25a	91.12±4.06a
双王群Colony with two queens	15	2048	92.45±3.03a	92.63±2.91a
多王群Colony with multiple queens	8	2048	91.29±3.08a	90.91±3.31a

育王方法 Queen rearing method	育王数量（只） Number of emerged queens (individuals)	蜂王初生重 Birth weight of queens (mg)	单侧卵巢管数（条） Number of ovarioles in one ovary
免移虫以卵育王 Egg-based queen rearing without artificially grafting larvae	32	256.31±3.75a	163.87±9.40b
人工移虫育王 Artificially grafting larvae based queen rearing	44	243.43±2.05b	154.77±6.74a
