黑土区保护性耕作土壤有机碳动态的模型模拟研究

doi:10.3864/j.issn.0578-1752.2024.10.008

摘要/Abstract

摘要：

【目的】保护性耕作是恢复和提高土壤肥力的重要措施，土壤有机碳在保持土壤肥力、维持作物生长与保护土壤环境方面具有非常重要的作用。然而，目前国内仍然缺少研究长期耕作的监测平台，因此采用模型的方法有助于研究长期保护性耕作下土壤有机碳的动态。【方法】依托东北黑土地保护性耕作长期定位试验地，选取免耕（NT）、秋翻（MP）、垄作（RT）3种处理下的土壤为研究对象，优化过程模型（RothC、AMG模型）与统计模型（MLPNN模型）的结构与参数，对比模拟长期保护性耕作下土壤有机碳储量的动态变化，评估不同模型对保护性耕作土壤有机碳动态模拟与预测的效果，并揭示东北黑土有机碳对保护性耕作的长期响应及其影响因素。【结果】优化有机碳在模型中各碳库的分配系数后，RothC与AMG模型模拟误差显著降低。保护性耕作实施的前11年（2001—2012），RothC与AMG过程模型对土壤有机碳的动态变化模拟效果没有显著差异，说明过程模型复杂的结构对持续时间相对较短的试验模拟效果没有显著影响，统计模型MLPNN的模拟结果与过程模型相似，验证了统计模型在田块与样地等小空间尺度内的应用效果。未来100年RothC与AMG模型预测的MP处理土壤有机碳变化趋势相同，但RothC模型预测结果得出，NT与RT处理土壤有机碳表现出先增长后达到平衡的趋势，但AMG模型模拟的结果却是有机碳一直处于增长趋势，这可能与土壤碳饱和效应与耕作处理的影响有关。RothC与AMG模型对碳投入都具有很高的灵敏度，但对气候因素与土壤因素变化的响应却存在差异。【结论】模型模拟长期保护性耕作土壤有机碳动态时需要因地制宜选择合适的预测模型。在预测保护性耕作土壤有机碳的短期变化时可以采用结构较为简单的AMG过程模型；在进行长期预测时，可以采用结构较为复杂的RothC模型。在特定条件下，统计模型MLPNN在田块与样地等小空间尺度上对土壤有机碳的模拟与过程模型具有相近的效果。

关键词: 土壤有机碳, 保护性耕作, 模型模拟, 黑土, 过程模型, 统计模型, 东北

Abstract:

【Objective】 Conservation tillage is an important measure for restoring and enhancing soil fertility, and soil organic carbon (SOC) plays a crucial role in maintaining soil fertility, supporting crop growth, and protecting soil environment. However, there is currently a lack of long-term monitoring platforms for conservation tillage in China, so using modeling methods can help study SOC dynamics under long-term conservation tillage. 【Method】 A long-term tillage experiment was established in the black soil region in 2001 with three treatments: no-tillage (NT), moldboard plow (MP), and ridge-tillage (RT). The structures and parameters of process-based models (RothC, AMG model) and statistical models (MLPNN model) were optimized. The changes in SOC under long-term conservation tillage were simulated and compared. The effectiveness of different models in simulating and predicting the SOC dynamics under conservation tillage was evaluated, and the long-term response and influencing factors of SOC in black soil in Northeast China to conservation tillage were revealed. 【Result】 After optimizing parameters for carbon pool allocation, errors of the RothC and AMG models were significantly reduced. During the first 11 years (2001-2012) of conservation tillage, there was no significant difference in the simulation of SOC between RothC and AMG models, indicating that the structural complexity of process models does not have significant impacts on the simulation results for relatively short term. The simulation results of the statistical model MLPNN were similar to process models, proving the application of statistical models in small-scale regions. Over the next 100 years, RothC and AMG models predicted similar trends in SOC changes, but AMG model significantly overestimated the increase in SOC stocks, which may be attributed to SOC saturation and the influence of tillage practices. Both RothC and AMG models showed high sensitivity to carbon input, but they responded differently to climate and soil factor changes. 【Conclusion】 It is necessary to choose appropriate models based on local conditions while using models to simulate SOC in long-term conservation tillage. For short-term prediction of SOC under conservation tillage, a relatively simple AMG modelcan be used, while for long-term prediction, a more complex RothC model can be used. Under specific conditions, statistical models show similar effects to process models in simulating soil organic carbon at a small-scale regions, such as plots and fields.

Key words: soil organic carbon, conservation tillage, model simulation, black soil, process-based model, statistical model, Northeast China

王文俊, 梁爱珍, 张延, 陈学文, 黄丹丹. 黑土区保护性耕作土壤有机碳动态的模型模拟研究[J]. 中国农业科学, 2024, 57(10): 1943-1960.

WANG WenJun, LIANG AiZhen, ZHANG Yan, CHEN XueWen, HUANG DanDan. Model Simulation Research of Soil Organic Carbon Dynamics of Long-Term Conservation Tillage in Black Soil[J]. Scientia Agricultura Sinica, 2024, 57(10): 1943-1960.

图/表 13

图1

图2

表1

表2

图3

表3

图4

表4

图5

图6

图7

图8

图9

参考文献 50

[1]	苑亚茹, 李禄军, 李娜, 尤孟阳, 韩晓增. 长期施肥对东北黑土不同活性有机碳库的影响. 生态学杂志, 2016, 35(6): 1435-1439.
	YUAN Y R, LI L J, LI N, YOU M Y, HAN X Z. Effect of long-term fertilization on soil organic carbon pools in Mollisols of Northeast China. Chinese Journal of Ecology, 2016, 35(6): 1435-1439. (in Chinese)
[2]	马超. 黑龙江省黑土地保护性耕作实施基本情况及问题研究. 中国农学通报, 2022, 38(17): 143-147. doi: 10.11924/j.issn.1000-6850.casb2022-0092
	MA C. Basic situation and problems of conservation tillage in black soil in Heilongjiang Province. Chinese Agricultural Science Bulletin, 2022, 38(17): 143-147. (in Chinese) doi: 10.11924/j.issn.1000-6850.casb2022-0092
[3]	CAMPBELL E E, PAUSTIAN K. Current developments in soil organic matter modeling and the expansion of model applications: A review. Environmental Research Letters, 2015, 10(12): 123004.
[4]	SHI Z, CROWELL S, LUO Y Q, MOORE B. Model structures amplify uncertainty in predicted soil carbon responses to climate change. Nature Communications, 2018, 9: 2171. doi: 10.1038/s41467-018-04526-9 pmid: 29867087
[5]	高崇升, 杨国亭, 王建国, 张兴义. 利用Century模型模拟不同农业经营模式下黑土农田土壤有机碳的演变. 生态学杂志, 2008, 27(6): 911-915.
	GAO C S, YANG G T, WANG J G, ZHANG X Y. The changing trend of organic carbon in black soil under different farming systems: A prediction by using Century model. Chinese Journal of Ecology, 2008, 27(6): 911-915. (in Chinese)
[6]	LI S M, LI J M, LI C S, HUANG S M, LI X Y, LI S X, MA Y B. Testing the RothC and DNDC models against long-term dynamics of soil organic carbon stock observed at cropping field soils in North China. Soil and Tillage Research, 2016, 163: 290-297.
[7]	ODEBIRI O, ODINDI J, MUTANGA O. Basic and deep learning models in remote sensing of soil organic carbon estimation: A brief review. International Journal of Applied Earth Observation and Geoinformation, 2021, 102: 102389.
[8]	ZHANG L J, SHAO Z, LIU J C, CHENG Q. Deep learning based retrieval of forest aboveground biomass from combined LiDAR and landsat 8 data. Remote Sens, 2019, 11: 1459.
[9]	GAO C, GOVIND R, TABAK H H. Predicting soil sorption coefficients of organic chemicals using a neural network model. Environmental Toxicology and Chemistry, 1996, 15(7): 1089-1096.
[10]	WERE K, BUI D T, DICK Ø B, SINGH B R. A comparative assessment of support vector regression, artificial neural networks, and random forests for predicting and mapping soil organic carbon stocks across an Afromontane landscape. Ecological Indicators, 2015, 52: 394-403.
[11]	杨学明, 张晓平, 方华军, 朱平, 任军, 王立春, 梁爱珍. 用RothC-26.3模型模拟玉米连作下长期施肥对黑土有机碳的影响. 中国农业科学, 2003, 36(11): 1318-1324.
	YANG X M, ZHANG X P, FANG H J, ZHU P, REN J, WANG L C, LIANG A Z. RothC-26.3 model simulating long-term effects of fertilization on changes of soil organic carbon in continuous cultivation of corn in northeast China. Scientia Agricultura Sinica, 2003, 36(11): 1318-1324. (in Chinese)
[12]	赵雅雯. RothC模型在我国北方农田作物残体提升土壤有机碳中的应用[D]. 北京: 中国农业科学院, 2017.
	ZHAO Y W. RothC model simulation of soil organic carbon on farmland crop residue in North China[D]. Beijing: Chinese Academy of Agricultural Sciences, 2017. (in Chinese)
[13]	AYANABA A, JENKINSON D S. Decomposition of carbon-14 labeled ryegrass and maize under tropical conditions. Soil Science Society of America Journal, 1990, 54(1): 112-115.
[14]	SHIRATO Y, YOKOZAWA M. Acid hydrolysis to partition plant material into decomposable and resistant fractions for use in the Rothamsted carbon model. Soil Biology and Biochemistry, 2006, 38(4): 812-816.
[15]	ANDRIULO A, MARY B, GUERIF J. Modelling soil carbon dynamics with various cropping sequences on the rolling pampas. Agronomie, 1999, 19(5): 365-377.
[16]	SAFFIH-HDADI K, MARY B. Modeling consequences of straw residues export on soil organic carbon. Soil Biology and Biochemistry, 2008, 40(3): 594-607.
[17]	张杨航, 吕锋, 李锋军, 张雷雷, 苏建新. 基于网格搜索与交叉验证的SVR大型拖拉机销量预测. 农业科技与装备, 2022(5): 34-37, 41.
	ZHANG Y H, LÜ F, LI F J, ZHANG L L, SU J X. Large tractor sales prediction of SVR based on grid search and cross validation. Agricultural Science & Technology and Equipment, 2022(5): 34-37, 41. (in Chinese)
[18]	CHESHMBERAH F, FATHIZAD H, PARAD G A, SHOJAEIFAR S. Comparison of RBF and MLP neural network performance and regression analysis to estimate carbon sequestration. International Journal of Environmental Science and Technology, 2020, 17(9): 3891-3900.
[19]	陈磊, 王金洲, 郝小雨, 马星竹, 魏丹, 周磊, 刘荣乐, 汪洪. DayCent模型模拟黑土长期施肥下土壤碳氮变化. 黑龙江农业科学, 2021(10): 23-31.
	CHEN L, WANG J Z, HAO X Y, MA X Z, WEI D, ZHOU L, LIU R L, WANG H. Using DayCent model to simulate black soil organic carbon and total nitrogen dynamics under long-term different fertilization. Heilongjiang Agricultural Sciences, 2021(10): 23-31. (in Chinese)
[20]	CLIVOT H, MOUNY J C, DUPARQUE A, DINH J L, DENOROY P, HOUOT S, VERTÈS F, TROCHARD R, BOUTHIER A, SAGOT S, MARY B. Modeling soil organic carbon evolution in long-term arable experiments with AMG model. Environmental Modelling & Software, 2019, 118: 99-113.
[21]	LIANG A Z, ZHANG X P, FANG H J, YANG X M, DRURY C F. Short-term effects of tillage practices on organic carbon in clay loam soil of northeast China. Pedosphere, 2007, 17(5): 619-623.
[22]	ZHANG Y, LI X J, GREGORICH E G, MCLAUGHLIN N B, ZHANG X P, GUO Y F, LIANG A Z, FAN R Q, SUN B J. No-tillage with continuous maize cropping enhances soil aggregation and organic carbon storage in Northeast China. Geoderma, 2018, 330: 204-211.
[23]	ELLERT B H, BETTANY J R. Calculation of organic matter and nutrients stored in soils under contrasting management regimes. Canadian Journal of Soil Science, 1995, 75(4): 529-538.
[24]	COLEMAN K, JENKINSON D S. ROTHC-26. 3: A Model for the Turnover of Carbon in Soil Model Description and Windows Users’ Guide: Lawes Agricultural Trust, 1999.
[25]	TRAJKOVIC S, GOCIC M, PONGRACZ R, BARTHOLY J. Adjustment of Thornthwaite equation for estimating evapotranspiration in Vojvodina. Theoretical and Applied Climatology, 2019, 138(3): 1231-1240.
[26]	韩其晟, 任宏刚, 刘建军. 秦岭主要森林凋落物中易分解和难分解植物残体含量及比值研究. 西北林学院学报, 2012, 27(5): 6-10.
	HAN Q S, REN H G, LIU J J. Contents and ratios of the decomposable and resistant plant material in the litters of the main trees in Qinling Mountains. Journal of Northwest Forestry University, 2012, 27(5): 6-10. (in Chinese)
[27]	赵雅雯, 王金洲, 王士超, 武红亮, 黄绍敏, 卢昌艾. 潮土区小麦、玉米残体对土壤有机碳的贡献: 基于改进的RothC模型. 中国农业科学, 2016, 49(21): 4160-4168. doi: 10.3864/j.issn.0578-1752.2016.21.010.
	ZHAO Y W, WANG J Z, WANG S C, WU H L, HUANG S M, LU C A. Contributions of wheat and corn residues to soil organic carbon under fluvo-aquic soil area—Based on the modified RothC model. Scientia Agricultura Sinica, 2016, 49(21): 4160-4168. doi: 10.3864/j.issn.0578-1752.2016.21.010. (in Chinese)
[28]	LEVAVASSEUR F, MARY B, CHRISTENSEN B T, DUPARQUE A, FERCHAUD F, KÄTTERER T, LAGRANGE H, MONTENACH D, RESSEGUIER C, HOUOT S. The simple AMG model accurately simulates organic carbon storage in soils after repeated application of exogenous organic matter. Nutrient Cycling in Agroecosystems, 2020, 117(2): 215-229.
[29]	NICOLARDOT B, RECOUS S, MARY B. Simulation of C and N mineralisation during crop residue decomposition: a simple dynamic model based on the C: N ratio of the residues. Plant and Soil, 2001, 228(1): 83-103.
[30]	ESCAMILLA-GARCÍA A, SOTO-ZARAZÚA G M, TOLEDANO- AYALA M, RIVAS-ARAIZA E, GASTÉLUM-BARRIOS A. Applications of artificial neural networks in greenhouse technology and overview for smart agriculture development. Applied Sciences, 2020, 10(11): 3835.
[31]	GUO W W, XUE H R. Crop yield forecasting using artificial neural networks: A comparison between spatial and temporal models. Mathematical Problems in Engineering, 2014, 2014: 1-7.
[32]	POEPLAU C. Estimating root: shoot ratio and soil carbon inputs in temperate grasslands with the RothC model. Plant and Soil, 2016, 407(1): 293-305.
[33]	于永强, 黄耀, 张稳. 华东地区农田土壤有机碳动态模拟研究: 模型的验证与灵敏度分析. 地理与地理信息科学, 2006, 22(6): 83-88, 93.
	YU Y Q, HUANG Y, ZHANG W. Modeling farmland soil organic carbon dynamics in eastern China: Model validation and sensitivity analysis. Geography and Geo-Information Science, 2006, 22(6): 83-88, 93. (in Chinese)
[34]	王金州, 卢昌艾, 张金涛, 单鹤翔, 张文菊, 黄绍敏, 徐明岗. RothC模型模拟华北潮土区的土壤有机碳动态. 中国土壤与肥料, 2010(6): 16-21, 49.
	WANG J Z, LU C A, ZHANG J T, SHAN H X, ZHANG W J, HUANG S M, XU M G. RothC model simulation of soil organic carbon dynamics of fluvo-aquic soil in Northern China. Soil and Fertilizer Sciences in China, 2010(6): 16-21, 49. (in Chinese)
[35]	GUPTA CHOUDHURY S, SRIVASTAVA S, SINGH R, CHAUDHARI S K, SHARMA D K, SINGH S K, SARKAR D. Tillage and residue management effects on soil aggregation, organic carbon dynamics and yield attribute in rice-wheat cropping system under reclaimed sodic soil. Soil and Tillage Research, 2014, 136: 76-83.
[36]	彭娟, 符卓旺, 朱洁, 慈恩, 高明, 谢德体. 耕作制度对紫色水稻土有机碳累积及矿化动态的影响. 水土保持学报, 2011, 25(4): 175-178, 182.
	PENG J, FU Z W, ZHU J, CI E, GAO M, XIE D T. Effects of tillage systems on accumulation and mineralization of organic carbon in purple paddy soil. Journal of Soil and Water Conservation, 2011, 25(4): 175-178, 182. (in Chinese)
[37]	熊瑛, 王龙昌, 杜娟, 赵琳璐, 周泉, 张赛. 垄作秸秆覆盖下西南地区蚕豆田土壤呼吸与有机碳特征. 环境科学, 2017, 38(5): 2102-2110.
	XIONG Y, WANG L C, DU J, ZHAO L L, ZHOU Q, ZHANG S. Characteristics of soil respiration and soil organic carbon in fava bean farmland under ridge tillage and straw mulching in southwest China. Environmental Science, 2017, 38(5): 2102-2110. (in Chinese)
[38]	SZOPLIK J. Forecasting of natural gas consumption with artificial neural networks. Energy, 2015, 85: 208-220.
[39]	ALJARAH I, FARIS H, MIRJALILI S. Optimizing connection weights in neural networks using the whale optimization algorithm. Soft Computing, 2018, 22(1): 1-15.
[40]	苏子友, 杨正礼, 王德莲, 蔡典雄, 姚宇卿, 吕军杰, 张洁. 豫西黄土坡耕地保护性耕作保水效果研究. 干旱地区农业研究, 2004, 22(3): 6-8, 18.
	SU Z Y, YANG Z L, WANG D L, CAI D X, YAO Y Q, LÜ J J, ZHANG J. Effect of conservation tillage on water conserving on loess slope-land in West Henan Province. Agricultural Research in the Arid Areas, 2004, 22(3): 6-8, 18. (in Chinese)
[41]	肖霜霜, 叶莹莹, 陈武荣, 肖丹, 毛兵, 张伟, 王克林. 翻耕扰动下喀斯特耕地N₂O排放规律及影响因素. 农业现代化研究, 2022, 43(4): 738-746.
	XIAO S S, YE Y Y, CHEN W R, XIAO D, MAO B, ZHANG W, WANG K L. N₂O emission law and its affecting factors under tillage disturbance in cultivated land of Karst region. Research of Agricultural Modernization, 2022, 43(4): 738-746. (in Chinese)
[42]	YANG M H, XU D Y, CHEN S C, LI H Y, SHI Z. Evaluation of machine learning approaches to predict soil organic matter and pH using vis-NIR spectra. Sensors, 2019, 19(2): 263.
[43]	李悦, 郭李萍, 谢立勇, 黄树青, 徐玉秀, 赵迅. 不同农作管理措施对东北地区农田土壤有机碳未来变化的模拟研究. 中国农业科学, 2015, 48(3): 501-513. doi: 10.3864/j.issn.0578-1752.2015.03.10.
	LI Y, GUO L P, XIE L Y, HUANG S Q, XU Y X, ZHAO X. Modeling the future changes of soil organic carbon under different management practices in upland soils of northeast China. Scientia Agricultura Sinica, 2015, 48(3): 501-513. doi: 10.3864/j.issn.0578-1752.2015.03.10. (in Chinese)
[44]	STEWART C E, PAUSTIAN K, CONANT R T, PLANTE A F, SIX J. Soil carbon saturation: evaluation and corroboration by long-term incubations. Soil Biology and Biochemistry, 2008, 40(7): 1741-1750.
[45]	STEWART C E, PLANTE A F, PAUSTIAN K, CONANT R T, SIX J. Soil carbon saturation: Linking concept and measurable carbon pools. Soil Science Society of America Journal, 2008, 72(2): 379-392.
[46]	CARUSO T, DE VRIES F T, BARDGETT R D, LEHMANN J. Soil organic carbon dynamics matching ecological equilibrium theory. Ecology and Evolution, 2018, 8(22): 11169-11178. doi: 10.1002/ece3.4586 pmid: 30519434
[47]	RIGGERS C, POEPLAU C, DON A, BAMMINGER C, HÖPER H, DECHOW R. Multi-model ensemble improved the prediction of trends in soil organic carbon stocks in German croplands. Geoderma, 2019, 345: 17-30.
[48]	WANG G S, POST W M, MAYES M A. Development of microbial- enzyme-mediated decomposition model parameters through steady- state and dynamic analyses. Ecological Applications: A Publication of the Ecological Society of America, 2013, 23(1): 255-272.
[49]	LIPSON D A, SCHMIDT S K. Seasonal changes in an alpine soil bacterial community in the Colorado rocky mountains. Applied and Environmental Microbiology, 2004, 70(5): 2867-2879. doi: 10.1128/AEM.70.5.2867-2879.2004 pmid: 15128545
[50]	CLIVOT H, MARY B, VALÉ M, COHAN J P, CHAMPOLIVIER L, PIRAUX F, LAURENT F, JUSTES E. Quantifying in situ and modeling net nitrogen mineralization from soil organic matter in arable cropping systems. Soil Biology and Biochemistry, 2017, 111: 44-59.

模型参数Model parameter	数值Value
月均温度 Monthly temperature (℃)	-14.1（一月 January），-9.4（二月 February），-1.6（三月 March）,8.8（四月 April），16.4（五月 May），21.7（六月 June），23.4（七月 July），22.6（八月 August），17.1（九月 September），8.9（十月 October），-2.4（十一月 November），-12.3（十二月 December）
月降水量 Monthly precipitation (mm)	3.3（一月 January），6.1（二月 February），15.3（三月 March），26.8（四月 April），56（五月 May），100.7（六月 June），183（七月 July），127.5（八月 August），32.9（九月 September），27.6（十月 October），21.6（十一月 November），9.5（十二月 December）
月蒸散量 Monthly evaporation (mm)	0（一月 January），0（二月 February），2.45（三月 March），55.83（四月 April），101.85（五月 May），133.34（六月 June），143.44（七月 July），138.84（八月 August），106.11（九月 September），56.65（十月 October），0.031（十一月 November），0（十二月 December）
黏粒含量Clay content (%)	36.03（实测值 Measured value）
DPM/RPM	1.44（默认值 Default value）
年碳投入量 Plant residue input (t C·hm^-2)	4.34（NT），4.25（MP），4.37（RT），由（2）式计算得来 4.34（NT），4.25（MP），4.37（RT），calculated from equation (2)
有机肥料月投入量 Manure input (FYM)	全年为0 0 for the whole year
取样深度 Depth of soil sample (cm)	0-20
土壤覆盖 Soil cover	详见1.2 不同耕作处理秸秆覆盖情况 Straw covering in different tillage treatments in 1.2

模型参数 Model parameter	含义Meaning
T	年平均气温 Average temperature (℃)
a₁	温度函数参数，取20 Temperature function parameter, take 20
b₁	温度函数参数，取0.120 K^-1 Temperature function parameter, take 0.120 K^-1
T_ref	对照温度，取15 ℃ Control temperature, take 15 ℃
A	土壤黏粒含量 Soil clay content (g·kg^-1)
a₂	黏土函数参数，取2.519×10^-3 Clay function parameter, take 2.519×10^-3
H	土壤湿度，取降水量P和灌溉水量IW之和与潜在蒸散量PET的差值 Soil moisture, taken as the difference between the sum of precipitation P and irrigation water IW and the potential evapotranspiration PET (mm)
a₃	湿度函数参数，取 3.0×10^-2Moisture function parameter, take 3.0×10^-2
b₃	湿度函数参数，取5.247 m^-1 Moisture function parameter, take 5.247 m^-1
CaCO₃	土壤CaCO₃含量 Soil CaCO₃ content (g·kg^-1)
a₄	碳酸钙函数参数，取1.50×10^-3 CaCO₃ function parameter, take 1.50×10^-3
pH	土壤pH Soil pH
a₅	pH函数参数，取0.112 pH function parameter, take 0.112
b₅	pH函数参数，取8.5 pH function parameter, take 8.5
C/N	土壤碳氮比 Soil carbon to nitrogen ratio
a₆	C/N函数参数，取0.060 C/N function parameter, take 0.060
b₆	C/N函数参数，取11 C/N function parameter, take 11

参数类型 Type of parameter	参数 Parameter
土壤因素 Soil factor	土壤氮含量 Soil nitrogen content (t C·hm^-2)
土壤因素 Soil factor	年碳投入量 Carbon input per year (t C·hm^-2)
养分投入因素 Nutrient factor	氮施入量 Nitrogen input (t C·hm^-2)
	磷施入量Phosphorus input (t C·hm^-2)
	钾施入量 Potassium input (t C·hm^-2)
气候因素 Climate factor	平均温度 Average temperature (℃)
	平均降水 Average precipitation (mm)
	平均蒸散量 Average evaporation (mm)

处理 Treatment	参数 Parameter	默认值Default value	优化值 Optimized value	RMSE	RMSE₀
NT	Cs/C₀	0.65	0.65	2.388597	2.393864
	k₀	0.29	0.26
	h₀	0.21	0.21
MP	Cs/C₀	0.65	0.175	1.204417	2.681656
	k₀	0.29	0.2925
	h₀	0.21	0.2075
RT	Cs/C₀	0.65	0.75	2.754996	3.008224
	k₀	0.29	0.175
	h₀	0.21	0.2175
