东北黑土区长缓坡耕地横坡垄作与地形对土壤可蚀性的交互作用

doi:10.3864/j.issn.0578-1752.2023.23.012

摘要/Abstract

摘要：

【目的】东北黑土区坡耕地土壤侵蚀日益加重，研究横坡垄作与地形对土壤可蚀性K值的交互作用，为东北黑土区坡耕地水土流失的精准防控提供科学依据。【方法】选取黑龙江省北安市红星农场内典型坡耕地为研究对象，在横坡垄作方向与顺坡水线方向共布设25个采样点，并计算相应样点的土壤可蚀性K值，采用单因素方差分析（One-way ANOVA）检验土壤可蚀性K值的差异性，并使用地理探测器模型探讨土壤可蚀性K值的影响因子及其交互作用。【结果】横坡垄作方向，土壤可蚀性K值在垄台呈现从坡顶到坡足逐渐减小的变化趋势，坡足比坡顶减小幅度为6.2%；在垄沟呈现从坡肩到坡足逐渐减小的变化趋势，坡足比坡肩减小幅度为5.8%。顺坡水线方向，由于垄台对地表径流的阻挡作用，垄台和垄沟土壤可蚀性K值沿着坡面并没有明显的变化趋势。地理探测器分析表明，横坡垄作对土壤可蚀性K值的影响最大，其垄台和垄沟的解释率分别达51%和18%以上；横坡垄作与其他因子的交互作用增强了对土壤可蚀性K值的解释能力，特别是横坡垄作与地形的交互作用尤为明显。【结论】黑土区坡耕地土壤可蚀性K值具有明显的空间变异性，横坡垄作与地形对土壤可蚀性的影响存在明显的交互作用，横坡垄作可以显著拦蓄径流，减少土壤侵蚀，但因黑土区坡耕地横坡垄作的坡缓而长，在坡足处易于汇集径流，依然有“断垄”潜在风险。

关键词: 土壤可蚀性, 横坡垄作, 顺坡水线, 地形, 交互作用, 黑土区坡耕地

Abstract:

【Objective】The soil erosion of slope farmland in Chinese black soil region is becoming more and more serious. This study mainly focused on the interaction between transverse ridge tillage and topography on soil erodibility, which could provide a scientific theoretical basis for precise prevention of soil erosion of slope farmland in black soil region. 【Method】A typical slope farmland in the Hongxing farm in Beian city of Heilongjiang Province was selected as research object. A total of 25 sampling points were designed along both the transverse ridge tillage direction and longitudinal waterline direction. The soil erodibility K values of the corresponding sample points were calculated and tested by One-way ANOVA method. The influence factors of soil erodibility K value were analyzed by using the geographic detector model. 【Result】In the transverse ridge tillage direction, the ridge soil erodibility decreased gradually from the top to the foot of slope, and the K value decreased by 6.2%. The furrow soil erodibility decreased gradually from the shoulder to the foot of slope, and the K value decreased by 5.8%. In the waterline direction, due to the blocking effect of ridge terrace on surface runoff, soil erodibility K value of ridge and furrow did not change significantly along the slope. Geodetector analysis showed that the influence of the transverse ridge tillage on soil erodibility K value was the greatest, and its interpretation rate was more than 51% and 18% in the ridge and furrow, respectively. The transverse ridge tillage and other factors had a significant interaction enhancement effect on K value, particularly the interaction between the transverse ridge tillage and topography. 【Conclusion】 The soil erodibility K value of slope farmland in the black soil region had obvious spatial variability. There was significant interaction between the transverse ridge tillage and topography on soil erodibility. The transverse ridge tillage could significantly intercept runoff and reduce soil erosion. Due to the long slope in the transverse ridge tillage, it was easy to collect runoff at the foot of the slope, and increase the potential risk of ridge failure.

Key words: soil erodibility, transverse ridge tillage, longitudinal waterline, topography, interaction, slope farmland of black soil region

于博威, 张晴雯, 郝卓, 石玉龙, 李雪亮, 李孟妮, 荆雪锴. 东北黑土区长缓坡耕地横坡垄作与地形对土壤可蚀性的交互作用[J]. 中国农业科学, 2023, 56(23): 4706-4716.

YU BoWei, ZHANG QingWen, HAO Zhuo, SHI YuLong, LI XueLiang, LI MengNi, JING XueKai. Interaction Between Transverse Ridge Tillage and Topography on Soil Erodibility Along the Long Gentle Slope in a Typical Black Soil Region of Northeast China[J]. Scientia Agricultura Sinica, 2023, 56(23): 4706-4716.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2023.23.012

https://www.chinaagrisci.com/CN/Y2023/V56/I23/4706

图/表 10

图1

图2

表1

表2

图3

图4

图5

图6

表3

表4

参考文献 32

[1]	刘兴土, 阎百兴. 东北黑土区水土流失与粮食安全. 中国水土保持, 2009(1): 17-19.
	LIU X T, YAN B X. Soil erosion and food security in black soil region of Northeast China. Soil and Water Conservation in China, 2009(1): 17-19. (in Chinese)
[2]	范昊明, 蔡强国, 王红闪. 中国东北黑土区土壤侵蚀环境. 水土保持学报, 2004, 18(2): 66-70.
	FAN H M, CAI Q G, WANG H S. Condition of soil erosion in phaeozem region of northeast China. Journal of Soil Water Conservation, 2004, 18(2): 66-70. (in Chinese)
[3]	AN J A, ZHENG F L, LU J A, LI G F. Investigating the role of raindrop impact on hydrodynamic mechanism of soil erosion under simulated rainfall conditions. Soil Science, 2012, 177(8): 517-526. doi: 10.1097/SS.0b013e3182639de1
[4]	陈雪, 蔡强国, 王学强. 典型黑土区坡耕地水土保持措施适宜性分析. 中国水土保持科学, 2008, 6(5): 44-49.
	CHEN X, CAI Q G, WANG X Q. Suitability of soil and water conservation measures on sloping farmland in typical black soil regions of Northeast China. Science of Soil and Water Conservation, 2008, 6(5): 44-49. (in Chinese)
[5]	CHEN S Q, ZHANG G H, ZHU P Z, WANG C S, WAN Y Q. Impact of slope position on soil erodibility indicators in rolling hill regions of northeast China. Catena, 2022, 217: 106475. doi: 10.1016/j.catena.2022.106475
[6]	YANG X H, GRAY J, CHAPMAN G, ZHU Q, TULAU M, MCINNES-CLARKE S. Digital mapping of soil erodibility for water erosion in New South Wales, Australia. Soil Research, 2018, 56(2): 158. doi: 10.1071/SR17058
[7]	刘宝元, 张科利, 焦菊英. 土壤可蚀性及其在侵蚀预报中的应用. 自然资源学报, 1999, 14(4): 345-350.
	LIU B Y, ZHANG K L, JIAO J Y. Soil erodibility and its use in soil erosion prediction model. Journal of Natural Resources, 1999, 14(4): 345-350. (in Chinese) doi: 10.11849/zrzyxb.1999.04.010
[8]	娄义宝, 康宏亮, 王文龙, 沙小燕, 冯兰茜, 聂慧莹, 史倩华. 黄土高原沟壑区沟头植被根系垂直分布及其对土壤抗侵蚀性的影响. 中国农业科学, 2023, 56(1): 90-103. doi: 10.3864/j.issn.0578-1752.2023.01.007.
	LOU Y B, KANG H L, WANG W L, SHA X Y, FENG L Q, NIE H Y, SHI Q H. Vertical distribution of vegetation roots and its influence on soil erosion resistance of gully heads on the gullied loess plateau. Scientia Agricultura Sinica, 2023, 56(1): 90-103. doi: 10.3864/j.issn.0578-1752.2023.01.007. (in Chinese)
[9]	魏慧, 赵文武, 王晶. 土壤可蚀性研究述评. 应用生态学报, 2017, 28(8): 2749-2759. doi: 10.13287/j.1001-9332.201708.011
	WEI H, ZHAO W W, WANG J. Research progress on soil erodibility. Chinese Journal of Applied Ecology, 2017, 28(8): 2749-2759. (in Chinese) doi: 10.13287/j.1001-9332.201708.011
[10]	GUO M M, CHEN Z X, WANG W L, WANG T C, WANG W X, CUI Z Q. Revegetation induced change in soil erodibility as influenced by slope situation on the Loess Plateau. Science of the Total Environment, 2021, 772: 145540. doi: 10.1016/j.scitotenv.2021.145540
[11]	陈卓鑫, 王文龙, 郭明明, 王天超, 郭文召, 王文鑫, 康宏亮, 杨波, 赵满. 黄土高塬沟壑区植被恢复对不同地貌部位土壤可蚀性的影响. 自然资源学报, 2020, 35(2): 387-398. doi: 10.31497/zrzyxb.20200211
	CHEN Z X, WANG W L, GUO M M, WANG T C, GUO W Z, WANG W X, KANG H L, YANG B, ZHAO M. Effects of vegetation restoration on soil erodibility on different geomorphological locations in the loess-tableland and gully region of the Loess Plateau. Journal of Natural Resources, 2020, 35(2): 387-398. (in Chinese) doi: 10.31497/zrzyxb.20200211
[12]	王文鑫, 王文龙, 郭明明, 王天超, 康宏亮, 杨波, 赵满, 陈卓鑫. 黄土高塬沟壑区植被恢复对沟头土壤团聚体特征及土壤可蚀性的影响. 中国农业科学, 2019, 52(16): 2845-2857. doi:10.3864/j.issn.0578-1752.2019.16.010.
	WANG W X, WANG W L, GUO M M, WANG T C, KANG H L, YANG B, ZHAO M, CHEN Z X. Effects of natural vegetation restoration on characteristics of soil aggregate and soil erodibility of gully heads in gully region of the loess plateau. Scientia Agricultura Sinica, 2019, 52(16): 2845-2857. doi:10.3864/j.issn.0578-1752.2019.16.010. (in Chinese)
[13]	王亚娟, 陈云明, 孙亚荣, 赵敏. 宁南山区侵蚀沟不同部位土壤理化性质及可蚀性研究. 水土保持学报, 2023, 37(2): 11-18.
	WANG Y J, CHEN Y M, SUN Y R, ZHAO M. Study on physical and chemical properties and erodibility of soil in different parts of erosion gully in the mountainous area of South Ningxia. Journal of Soil and Water Conservation, 2023, 37(2): 11-18. (in Chinese)
[14]	张琪, 崔佳慧, 李绒萱, 刘博, 仝如强, 王宇. 吉林省中东部耕地土壤可蚀性因子的演变. 吉林农业大学学报, 2021, 43(1): 82-85.
	ZHANG Q, CUI J H, LI R X, LIU B, TONG R Q, WANG Y. Evolution of arable soil erodibility factor in central and eastern Jilin Province. Journal of Jilin Agricultural University, 2021, 43(1): 82-85. (in Chinese)
[15]	孔亚平, 张科利, 杨红丽. 土壤可蚀性模拟研究中的坡长选定问题. 地理科学, 2005, 25(3): 3374-3378.
	KONG Y P, ZHANG K L, YANG H L. Selecting on slope length of the soil erodibility simulation. Scientia Geographica Sinica, 2005, 25(3): 3374-3378. (in Chinese)
[16]	张永勤. 武夷山山地土壤可蚀性K值的垂直分异及成因分析. 亚热带水土保持, 2012, 24(3): 19-22.
	ZHANG Y Q. Analysis on the vertical differentiation & affected factors of soil erodibility K value in mountain soils of Wuyi Mountain. Subtropical Soil and Water Conservation, 2012, 24(3): 19-22. (in Chinese)
[17]	刘宝元, 阎百兴, 沈波, 王志强, 魏欣. 东北黑土区农地水土流失现状与综合治理对策. 中国水土保持科学, 2008, 6(1): 1-8.
	LIU B Y, YAN B X, SHEN B, WANG Z Q, WEI X. Current status and comprehensive control strategies of soil erosion for cultivated land in the Northeastern black soil area of China. Science of Soil and Water Conservation, 2008, 6(1): 1-8. (in Chinese)
[18]	王磊, 何超, 郑粉莉, 边锋, 覃超, 徐锡蒙. 黑土区坡耕地横坡垄作措施防治土壤侵蚀的土槽试验. 农业工程学报, 2018, 34(15): 141-148.
	WANG L, HE C, ZHENG F L, BIAN F, QIN C, XU X M. Soil-Bin experiment on effects of contour ridge tillage for controlling hillslope soil erosion in black soil region. Transactions of the Chinese Society of Agricultural Engineering, 2018, 34(15): 141-148. (in Chinese)
[19]	HOU T Y, FILLEY T R, TONG Y N, ABBAN B, SINGH S, THANOS PAPANICOLAOU A N, WACHA K M, WILSON C G, CHAUBEY I. Tillage-induced surface soil roughness controls the chemistry and physics of eroded particles at early erosion stage. Soil and Tillage Research, 2021, 207: 104807. doi: 10.1016/j.still.2020.104807
[20]	温云浩, 王立新, 刘铁军. 东北黑土区不同垄作坡面产流产沙过程. 水土保持研究, 2022, 29(5): 8-13, 20.
	WEN Y H, WANG L X, LIU T J. Process of runoff and sediment generation on different slopes with ridged cropping in the black soil area of northeast China. Research of Soil and Water Conservation, 2022, 29(5): 8-13, 20. (in Chinese)
[21]	AN J, WU Y Z, WU X Y, WANG L Z, XIAO P Q. Soil aggregate loss affected by raindrop impact and runoff under surface hydrologic conditions within contour ridge systems. Soil and Tillage Research, 2021, 209: 104937. doi: 10.1016/j.still.2021.104937
[22]	SHARPLEY A N, WILLIAMS J R. EPIC-erosion/productivity impact calculator: 1. Model documentation. Beltsville, MD: U.S. Department of Agriculture Technical Bulletin, No.1768.
[23]	WANG J F, LI X H, CHRISTAKOS G, LIAO Y L, ZHANG T, GU X, ZHENG X Y. Geographical detectors-based health risk assessment and its application in the neural tube defects study of the Heshun region, China. International Journal of Geographical Information Science, 2010, 24(1): 107-127. doi: 10.1080/13658810802443457
[24]	刘华征, 贾燕锋, 范昊明, 王佳楠, 韩文宁. 东北松嫩典型黑土区长缓坡耕地土壤侵蚀沿坡长变化规律及其对土壤质量的影响. 自然资源学报, 2022, 37(9): 2292-2305. doi: 10.31497/zrzyxb.20220907
	LIU H Z, JIA Y F, FAN H M, WANG J N, HAN W N. Variation of soil erosion intensity along the long gentle farming slopes and its influence on soil quality in the typical mollisol region, Songnen Plain, Northeast China. Journal of Natural Resources, 2022, 37(9): 2292-2305. (in Chinese) doi: 10.31497/zrzyxb.20220907
[25]	张明礼, 杨浩, 高明, 杨九东, 刘晓海. 利用¹³⁷Cs示踪技术研究滇池流域土壤侵蚀. 土壤学报, 2008, 45(6): 1017-1025.
	ZHANG M L, YANG H, GAO M, YANG J D, LIU X H. Study on soil erosion in Dianchi Catchment using ¹³⁷Cs tracer. Acta Pedologica Sinica, 2008, 45(6): 1017-1025. (in Chinese)
[26]	谭贞学, 王占礼, 马春艳, 刘俊娥, 袁殷. 黄土坡面下坡位土壤侵蚀过程的模拟试验. 中国水土保持科学, 2009, 7(2): 12-17, 28.
	TAN Z X, WANG Z L, MA C Y, LIU J E, YUAN Y. Simulated- rainfall experimental research on soil erosion processes on downslope segment of loess hillslope. Science of Soil and Water Conservation, 2009, 7(2): 12-17, 28. (in Chinese)
[27]	XU X M, ZHENG F L, WILSON G V, HE C, LU J, BIAN F. Comparison of runoff and soil loss in different tillage systems in the Mollisol region of Northeast China. Soil and Tillage Research, 2018, 177: 1-11. doi: 10.1016/j.still.2017.10.005
[28]	盖浩, 刘平奇, 张梦璇, 陈柏旭, 王迎春, 王立刚. 黑土坡耕地横坡垄作对减少径流及土壤有机碳流失的作用. 水土保持学报, 2022, 36(2): 300-304, 311.
	GAI H, LIU P Q, ZHANG M X, CHEN B X, WANG Y C, WANG L G. Effects of ridge planting on reducing runoff and soil organic carbon loss in black soil slope. Journal of Soil and Water Conservation, 2022, 36(2): 300-304, 311. (in Chinese)
[29]	宋鸽, 史东梅, 蒋光毅, 江娜, 叶青, 张健乐. 土壤管理措施对坡耕地侵蚀退化耕层的恢复作用. 中国农业科学, 2021, 54(8): 1702-1714. doi: 10.3864/j.issn.0578-1752.2021.08.010.
	SONG G, SHI D M, JIANG G Y, JIANG N, YE Q, ZHANG J L. Effects of different fertilization methods on restoration of eroded and degraded cultivated-layer in slope farmland. Scientia Agricultura Sinica, 2021, 54(8): 1702-1714. doi: 10.3864/j.issn.0578-1752.2021.08.010. (in Chinese)
[30]	水利部, 中国科学院, 中国工程院. 中国水土流失防治与生态安全-东北黑土区卷. 北京: 科学出版社, 2010.
	Ministry of Water Resources, Chinese Academy of Sciences, Chinese Academy of Engineering. Soil Erosion Control and Ecological Security in China Black Soil Region of Northeast China Volume Beijing: Science Press, 2010. (in Chinese)
[31]	王小康, 谷举, 刘刚, 师宏强. 横、顺坡垄作对黑土坡面侵蚀-沉积周期规律的影响. 土壤学报, 2022, 59(2): 430-439.
	WANG X K, GU J, LIU G, SHI H Q. The influence of transverse and longitudinal ridge tillage on soil erosion and deposition cycles for mollisol slope. Acta Pedologica Sinica, 2022, 59(2): 430-439. (in Chinese)
[32]	牟廷森, 沈海鸥, 贺云锋, 李春丽, 郭聃, 刘殿民. 黑土区垄作方式对坡耕地土壤侵蚀的调控效果. 水土保持通报, 2022, 42(2): 22-30.
	MOU T S, SHEN H O, HE Y F, LI C L, GUO D, LIU D M. Effects of ridge tillage patterns on soil erosion of sloping croplands in black soil region of northeastern China. Bulletin of Soil and Water Conservation, 2022, 42(2): 22-30. (in Chinese)

交互作用类型 Interaction	判断准则 Judgement criteria
双因子增强 Double-factor enhancement	q(x₁∩x₂)>Max(q(x₁), q(x₂))
非线性增强 Nonlinear enhancement	q(x₁∩x₂)>q(x₁) + q(x₂)
单因子非线性减弱 Single-factor nonlinear weakening	Min[q(x₁), q(x₂)]>q(x₁∩x₂)>Max[q(x₁), q(x₂)]
非线性减弱 Nonlinear weakening	q(x₁∩x₂)>Min[q(x₁), q(x₂)]
独立 Independent	q(x₁∩x₂)=q(x₁) + q(x₂)

影响因子 Influencing factor	级别 Level	级别说明 Level description
横坡垄作 Transverse ridge tillage	1-5	1.坡顶 2.坡肩 3.坡背 4.坡脚 5.坡足 1. Top 2. Shoulder 3. Back 4. Foot 5. Toe
顺坡水线 Longitudinal waterline	1-5	1.上坡 2.中上坡 3.中坡 4.中下坡 5.下坡 1. Upper 2. Mid-upper 3. Middle 4. Mid-lower 5. Lower
土壤容重 Soil density	1-4	通过ArcGIS 10.2的自然间断点方法提取 Extracted by natural breaks method in ArcGIS 10.2
土壤有机碳 Soil organic carbon	1-4	通过ArcGIS 10.2的自然间断点方法提取 Extracted by natural breaks method in ArcGIS 10.2
高程 Elevation	1-4	通过ArcGIS 10.2的自然间断点方法提取 Extracted by natural breaks method in ArcGIS 10.2
坡度 Slope	1-4	通过ArcGIS 10.2的自然间断点方法提取 Extracted by natural breaks method in ArcGIS 10.2

影响因子 Influencing factor	横坡垄作 Transverse ridge tillage	顺坡水线 Longitudinal waterline	土壤容重 Soil density	土壤有机碳 Soil organic carbon	高程 Elevation	坡度 Slope
横坡垄作 Transverse ridge tillage	0.511
顺坡水线 Longitudinal waterline	1.000*	0.040
土壤容重 Soil density	0.761*	0.468*	0.081
土壤有机碳 Soil organic carbon	0.774*	0.270*	0.467*	0.070
高程 Elevation	0.898*	0.321*	0.590*	0.241^#	0.148
坡度 Slope	0.712*	0.460*	0.439*	0.555*	0.574*	0.169

影响因子 Influencing factor	横坡垄作 Transverse ridge tillage	顺坡水线 Longitudinal waterline	土壤容重 Soil density	土壤有机碳 Soil organic carbon	高程 Elevation	坡度 Slope
横坡垄作 Transverse ridge tillage	0.185
顺坡水线 Longitudinal waterline	1.000*	0.084
土壤容重 Soil density	0.758*	0.485*	0.103
土壤有机碳 Soil organic carbon	0.740*	0.281*	0.373*	0.059
高程 Elevation	0.901*	0.123^#	0.396*	0.267*	0.079
坡度 Slope	0.500*	0.453*	0.434*	0.463*	0.414*	0.067
