基于转录组分析油菜素内酯对高温胁迫下酿酒葡萄花色苷合成及果实品质的调控机制

doi:10.3864/j.issn.0578-1752.2023.06.010

摘要/Abstract

摘要：

【目的】分析高温胁迫下参与油菜素内酯调控葡萄花色苷及果实品质合成的相关基因，探讨油菜素内酯调控果实花色苷及品质合成的机制。【方法】以酿酒葡萄‘赤霞珠’为试材，转色前一周利用红外辐射器模拟高温环境，并全树喷施0.6 mg∙L^-1的2,4-表油菜素内酯（2,4-Epibrassinolide，EBR），测定花色苷、总糖及相关品质指标，选择转色中期（花后70 d）的果实进行转录组测序，从分子水平阐述EBR对高温胁迫下花色苷合成的影响。【结果】从转色开始，各处理花色苷含量逐渐升高；成熟时，高温组（HT）花色苷总量显著低于对照组（CK），高温油菜素内酯组（HTE）花色苷含量高于HT组。总糖、还原糖、蔗糖变化规律与花色苷相似，HT组含量均在成熟期时低于CK组，成熟期各种糖含量为CK组>HTE组>HT组。分析3种处理下‘赤霞珠’果实基因水平的差异，通过GO和KEGG富集发现了14个与蔗糖和淀粉代谢途经相关的差异基因，其中HT和HTE处理显著上调了10个基因，显著下调了4个基因；苯丙氨酸代谢途径有11个差异基因，其中有7个参与花色苷合成的基因在HT处理中上调，有4个参与木质素合成的基因在HT处理下表达量显著上调，说明高温可能促进了木质素合成，从而降低了花色苷的积累量；内源激素信号转导途径的差异表达基因11个，其中ABA信号转导受体基因PP2C及激酶SnRK2的表达量在高温胁迫下显著提高，其可能与EBR共同参与调控高温胁迫下葡萄花色苷的合成。对部分差异基因的表达模式进行实时荧光定量（qRT-PCR）验证，证实了转录组数据的准确性。【结论】EBR通过改变糖代谢、花色苷合成及内源激素信号转导过程中相关基因的表达模式，缓解了高温胁迫对葡萄花色苷积累的抑制作用，提高了果实品质。

关键词: 酿酒葡萄‘赤霞珠’, 2,4-表油菜素内酯, 高温, 花色苷, 转录组

Abstract:

【Objective】 The aims of the study were to analyze the genes involved in the regulation of grape anthocyanin accumulation and fruit quality by 2,4-Epibrassinolide (EBR) under high-temperature stress, and to explore the molecular mechanism of EBR regulation anthocyanin accumulation in grapes under high-temperature stress. 【Method】 Cabernet Sauvignon grapes were treated with high-temperature stress using infrared emitter, and sprayed 0.6 mg∙L^-1 of EBR before the veraison. The content of total anthocyanins, total sugar, reducing sugar and sucrose were quantified using the ultraviolet visible spectrophotometer. The mechanism of EBR-mediated accumulation of anthocyanin under high-temperature stress was analyzed by transcriptome sequencing. 【Result】 Starting from veraison, the anthocyanin content increased gradually under various treatments. At maturity, the total anthocyanin content in the high temperature group (HT) was significantly lower than that in the control group (CK), and the anthocyanin content in the high temperature and EBR group (HTE) was higher than that in the HT group, but lower than CK group. Under HT treatment, the accumulation pattern of total sugar, reducing sugar and sucrose was similar to that of anthocyanins and lower than those of CK group at maturity stage. Compared with HT group, the contents of various sugars in HTE group were increased. The differences in transcriptome levels of Cabernet Sauvignon fruits under the three treatments were analyzed. Through GO and KEGG enrichment, 14 differential genes related to sucrose and starch metabolic pathways, among which 10 genes were significantly up-regulated and 4 genes were significantly down-regulated under HT and HTE treatments. The expressions of 11 genes were different in the phenylpropane metabolic pathway. Seven genes involved in anthocyanin synthesis were up-regulated under the HT treatment, and 4 genes involved in lignin synthesis were significantly up-regulated under the HT treatment, indicating that high temperature might promote lignin synthesis and reduce the accumulation of anthocyanins. In the endogenous hormone signaling pathway, the expression of the ABA signaling receptor genes PP2C and SnRK2 was significantly increased under high-temperature stress, and might be involved in regulating the synthesis of grape anthocyanin under high-temperature stress together with EBR. The expression patterns of some differential genes were verified by qRT-PCR, which confirmed the accuracy of transcriptome data. 【Conclusion】 EBR alleviated the inhibitory effect of high temperature stress on grapevine anthocyanin accumulation, probably due to the fact that EBR reduced the expression of lignin-related genes and changed the expression pattern of grape endogenous hormone signal transduction genes.

Key words: Vitis vinifera L. cv Cabernet Sauvignon, 2,4-Epibrassinolide, high-temperature, anthocyanin, RNA-seq

汪月宁, 代红军, 贺琰, 魏强, 郭学良, 刘妍, 殷梦婷, 王振平. 基于转录组分析油菜素内酯对高温胁迫下酿酒葡萄花色苷合成及果实品质的调控机制[J]. 中国农业科学, 2023, 56(6): 1139-1153.

WANG YueNing, DAI HongJun, HE Yan, WEI Qiang, GUO XueLiang, LIU Yan, YIN MengTing, WANG ZhenPing. Regulation Mechanism of Brassinolide on Anthocyanins Synthesis and Fruit Quality in Wine Grapes Under High Temperature Stress Based on Transcriptome Analysis[J]. Scientia Agricultura Sinica, 2023, 56(6): 1139-1153.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2023.06.010

https://www.chinaagrisci.com/CN/Y2023/V56/I6/1139

图/表 12

表1

图1

表2

表3

图2

图3

图4

图5

图6

图7

表4

图8

参考文献 40

[1]	Stocker T F, Qin D, Plattner G K, Tignor M M B, Allen S K, Boschung J, Nauels A, Xia Y, Bex V, M. M. P. Climate Change 2013:The physical science basis. contribution of working group I to the fifth assessment report of IPCC the intergovernmental panel on climate change. 2014.
[2]	吴久赟, 廉苇佳, 曾晓燕, 刘志刚, 毛亮, 刘勇翔, 姜建福. 不同品种葡萄对高温的生理响应及耐热性评价. 西北植物学报, 2019, 39(6): 1075-1084.
	WU J Y, LIAN W J, ZENG X Y, LIU Z G, MAO L, LIU Y X, JIANG J F. Physiological response to high temperature and heat tolerance evaluation of different grape cultivars. Acta Botanica Boreali- Occidentalia Sinica, 2019, 39(6): 1075-1084. (in Chinese)
[3]	CORTELL J M, HALBLEIB M, GALLAGHER A V, RIGHETTI T L, KENNEDY J A. Influence of vine vigor on grape (Vitis vinifera L. cv. Pinot Noir) anthocyanins. 2. Anthocyanins and pigmented polymers in wine. Journal of Agricultural and Food Chemistry, 2007, 55(16): 6585-6595. doi: 10.1021/jf070196n
[4]	WANG H, CAO G H, PRIOR R L. Oxygen radical absorbing capacity of anthocyanins. Journal of Agricultural and Food Chemistry, 1997, 45(2): 304-309. doi: 10.1021/jf960421t
[5]	ZHANG J L, NIU J P, DUAN Y, ZHANG M X, LIU J Y, LI P M, MA F W. Photoprotection mechanism in the ‘Fuji’ apple peel at different levels of photooxidative sunburn. Physiologia Plantarum, 2015, 154(1): 54-65. doi: 10.1111/ppl.2015.154.issue-1
[6]	钟海霞. 葡萄果实糖分积累机制及关键基因挖掘[D]. 乌鲁木齐: 新疆农业大学, 2021.
	ZHONG H X. Sugar accumulation mechanism and key gene mining in grape fruit[D]. Urumqi: Xinjiang Agricultural University, 2021. (in Chinese)
[7]	CARBONELL-BEJERANO P, SANTA MARÍA E, TORRES-PÉREZ R, ROYO C, LIJAVETZKY D, BRAVO G, AGUIRREOLEA J, SÁNCHEZ-DÍAZ M, ANTOLÍN M C, MARTÍNEZ-ZAPATER J M. Thermotolerance responses in ripening berries of Vitis vinifera L. cv Muscat hamburg. Plant and Cell Physiology, 2013, 54(7): 1200-1216. doi: 10.1093/pcp/pct071
[8]	黄敬寒, 温可睿, 潘秋红, 段长青, 王军. 环境条件和栽培技术对葡萄花色苷生物合成的影响(上): 环境条件对葡萄花色苷生物合成的影响. 中外葡萄与葡萄酒, 2011(9): 71-76.
	HUANG J H, WEN K R, PAN Q H, DUAN C Q, WANG J. Effects of environmental conditions and cultivation techniques on anthocyanin biosynthesis in grape (Ⅰ)-Effects of environmental conditions on anthocyanin biosynthesis in grape. Sino-Overseas Grapevine and Wine, 2011(9): 71-76. (in Chinese)
[9]	BAJGUZ A, HAYAT S. Effects of brassinosteroids on the plant responses to environmental stresses. Plant Physiology and Biochemistry: PPB, 2009, 47(1): 1-8.
[10]	JIN S H, LI X Q, WANG G G, ZHU X T. Brassinosteroids alleviate high-temperature injury in Ficus concinna seedlings via maintaining higher antioxidant defence and glyoxalase systems. AoB Plants, 2015, 7: plv009.
[11]	DING H D, ZHU X H, ZHU Z W, YANG S J, ZHA D S, WU X X. Amelioration of salt-induced oxidative stress in eggplant by application of 24-epibrassinolide. Biologia Plantarum, 2012, 56(4): 767-770. doi: 10.1007/s10535-012-0108-0
[12]	AGHDAM M S, MOHAMMADKHANI N. Enhancement of chilling stress tolerance of tomato fruit by postharvest brassinolide treatment. Food and Bioprocess Technology, 2014, 7(3): 909-914. doi: 10.1007/s11947-013-1165-x
[13]	杨艺琳, 张正敏, 李美琳, 赵立艳, 金鹏, 郑永华. 2, 4-表油菜素内酯对葡萄果实采后灰霉病的抑制作用机理. 食品科学, 2019, 40(15): 231-238.
	YANG Y L, ZHANG Z M, LI M L, ZHAO L Y, JIN P, ZHENG Y H. Modes of action of 2, 4-epibrassionolide against postharvest gray mold decay of grapes. Food Science, 2019, 40(15): 231-238. (in Chinese) doi: 10.1111/jfds.1975.40.issue-2
[14]	KAGALE S, DIVI U K, KROCHKO J E, KELLER W A, KRISHNA P. Brassinosteroid confers tolerance in Arabidopsis thaliana and Brassica napus to a range of abiotic stresses. Planta, 2007, 225(2): 353-364. doi: 10.1007/s00425-006-0361-6
[15]	NIE W F, WANG M M, XIA X J, ZHOU Y H, SHI K, CHEN Z X, YU J Q. Silencing of tomato RBOH1 and MPK2 abolishes brassinosteroid-induced H₂O₂ generation and stress tolerance. Plant, Cell & Environment, 2013, 36(4): 789-803.
[16]	ZHOU J, WANG J, LI X, XIA X J, ZHOU Y H, SHI K, CHEN Z X, YU J Q. H₂O₂ mediates the crosstalk of brassinosteroid and abscisic acid in tomato responses to heat and oxidative stresses. Journal of Experimental Botany, 2014, 65(15): 4371-4383. doi: 10.1093/jxb/eru217
[17]	YIN Y L, QIN K Z, SONG X W, ZHANG Q H, ZHOU Y H, XIA X J, YU J Q. BZR1 transcription factor regulates heat stress tolerance through FERONIA receptor-like kinase-mediated reactive oxygen species signaling in tomato. Plant and Cell Physiology, 2018, 59(11): 2239-2254.
[18]	YUAN L B, PENG Z H, ZHI T T, ZHO Z, LIU Y, ZHU Q, XIONG X Y, REN C M. Brassinosteroid enhances cytokinin-induced anthocyanin biosynthesis in Arabidopsis seedlings. Biologia Plantarum, 2015, 59(1): 99-105. doi: 10.1007/s10535-014-0472-z
[19]	冯晓雪. 油菜素内酯对红地球葡萄生理生化特性和品质的影响[D]. 兰州: 甘肃农业大学, 2014.
	FENG X X. Effects of brassinolide on physiological and biochemical characteristics and quality of Red Globe grape[D]. Lanzhou: Gansu Agricultural University, 2014. (in Chinese)
[20]	王爱玲, 白世践, 赵荣华, 蔡军社. 油菜素内酯对火焰无核葡萄着色的影响. 天津农业科学, 2019, 25(1): 34-35, 42.
	WANG A L, BAI S J, ZHAO R H, CAI J S. Effects of brassinolide on colour of flame seedless grape. Tianjin Agricultural Sciences, 2019, 25(1): 34-35, 42. (in Chinese)
[21]	张睿佳, 李瑛, 虞秀明, 娄玉穗, 许文平, 张才喜, 赵丽萍, 王世平. 高温胁迫与外源油菜素内酯对‘巨峰’葡萄叶片光合生理和果实品质的影响. 果树学报, 2015, 32(4): 590-596.
	ZHANG R J, LI Y, YU X M, LOU Y S, XU W P, ZHANG C X, ZHAO L P, WANG S P. Effects of heat stress and exogenous brassinolide on photosynthesis of leaves and berry quality of ‘Kyoho’ grapevine. Journal of Fruit Science, 2015, 32(4): 590-596. (in Chinese)
[22]	栾丽英, 张振文, 惠竹梅, 房玉林, 霍珊珊. 脱落酸处理对赤霞珠和烟73葡萄果皮花色苷组分的影响. 食品科学, 2014, 35(18): 110-114.
	LUAN L Y, ZHANG Z W, XI Z M, FANG Y L, HUO S S. Effect of abscisic acid on anthocyanin composition of grape skins from Yan 73 and cabernet sauvignon. Food Science, 2014, 35(18): 110-114. (in Chinese)
[23]	李璐, 徐玉娟, 吴继军, 余元善, 邹波, 彭健. 华中地区不同品种树莓果实成熟过程中特征活性物质的变化. 现代食品科技, 2021, 37(10): 145-152.
	LI L, XU Y J, WU J J, YU Y S, ZOU B, PENG J. Ripening-induced changes in characteristic active compounds of different raspberry (Rubus idaeus) cultivars sourced from central China. Modern Food Science & Technology, 2021, 37(10): 145-152. (in Chinese)
[24]	李利梅, 王秀芹, 杨培培, 黄卫东, 战吉宬. 赤霞珠葡萄果实糖积累与糖代谢相关酶的关系. 中外葡萄与葡萄酒, 2011(7): 24-27.
	LI L M, WANG X Q, YANG P P, HUANG W D, ZHAN J C. Relationship between sugar accumulation and sugar metabolism related enzymes during Cabernet Sauvignon berries development. Sino-Overseas Grapevine & Wine, 2011(7): 24-27. (in Chinese)
[25]	COHEN S D, TARARA J M, KENNEDY J A. Assessing the impact of temperature on grape phenolic metabolism. Analytica Chimica Acta, 2008, 621(1): 57-67. doi: 10.1016/j.aca.2007.11.029 pmid: 18573371
[26]	马立娜. 油菜素内酯和脱落酸调控葡萄果实成熟与花色苷合成的研究[D]. 杨凌: 西北农林科技大学, 2012.
	MA L N. Study on brassinolide and abscisic acid regulating grape fruit ripening and anthocyanin synthesis[D]. Yangling: Northwest A & F University, 2012. (in Chinese)
[27]	GAMBETTA G A, MATTHEWS M A, SHAGHASI T H, MCELRONE A J, CASTELLARIN S D. Sugar and abscisic acid signaling orthologs are activated at the onset of ripening in grape. Planta, 2010, 232(1): 219-234. doi: 10.1007/s00425-010-1165-2 pmid: 20407788
[28]	ZHANG K, WU Z D, TANG D B, LUO K, LU H X, LIU Y Y, DONG J, WANG X, LV C W, WANG J C, LU K. Comparative transcriptome analysis reveals critical function of sucrose metabolism related-enzymes in starch accumulation in the storage root of sweet potato. Frontiers in Plant Science, 2017, 8: 914. doi: 10.3389/fpls.2017.00914 pmid: 28690616
[29]	WINTER H, HUBER S C. Regulation of sucrose metabolism in higher plants: Localization and regulation of activity of key enzymes. Critical Reviews in Plant Sciences, 2000, 19(1): 31-67. doi: 10.1080/07352680091139178
[30]	林雪茜, 彭淼, 吴少平, 易干军, 董涛, 钟晓红, 高慧君. ‘中蕉9号’与‘巴西蕉’果实后熟过程中可溶性糖积累差异的原因分析. 果树学报, 2019, 36(11): 1524-1539.
	LIN X Q, PENG M, WU S P, YI G J, DONG T, ZHONG X H, GAO H J. A comparative analysis of the differences in starch degradation and soluble sugar accumulation between ‘Zhongjiao No.9’ and ‘Baxijiao’ during fruit ripening. Journal of Fruit Science, 2019, 36(11): 1524-1539. (in Chinese)
[31]	靳文斌, 李克文, 胥九兵, 张友亮, 肖兆玲, 张倩, 刘开昌, 龚魁杰. 海藻糖的特性、功能及应用. 精细与专用化学品, 2015, 23(1): 30-33.
	JIN W B, LI K W, XU J B, ZHANG Y L, XIAO Z L, ZHANG Q, LIU K C, GONG K J. The character and function of trehalose and its application. Fine and Specialty Chemicals, 2015, 23(1): 30-33. (in Chinese)
[32]	SPARVOLI F, MARTIN C, SCIENZA A, GAVAZZI G, TONELLI C. Cloning and molecular analysis of structural genes involved in flavonoid and stilbene biosynthesis in grape (Vitis vinifera L.). Plant Molecular Biology, 1994, 24(5): 743-755. doi: 10.1007/BF00029856
[33]	LUAN L Y, ZHANG Z W, XI Z M, HUO S S, MA L N. Brassinosteroids regulate anthocyanin biosynthesis in the ripening of grape berries. South African Journal of Enology and Viticulture, 2013, 34(2): 196-203.
[34]	XI Z M, ZHANG Z W, HUO S S, LUAN L Y, GAO X, MA L N, FANG Y L. Regulating the secondary metabolism in grape berry using exogenous 24-epibrassinolide for enhanced phenolics content and antioxidant capacity. Food Chemistry, 2013, 141(3): 3056-3065. doi: 10.1016/j.foodchem.2013.05.137
[35]	陈素丽, 彭瑜, 周华, 于波, 董彦君, 滕胜. 植物海藻糖代谢及海藻糖-6-磷酸信号研究进展. 植物生理学报, 2014, 50(3): 233-242.
	CHEN S L, PENG Y, ZHOU H, YU B, DONG Y J, TENG S. Research advances in trehalose metabolism and trehalose-6-phosphate signaling in plants. Plant Physiology Journal, 2014, 50(3): 233-242. (in Chinese) doi: 10.1111/ppl.1980.50.issue-3
[36]	陈乃钰, 张国香, 张力爽, 安逸民, 杜家欢, 王丹, 郭长虹. ABF转录因子在植物响应非生物胁迫中的作用. 植物遗传资源学报, 2021, 22(4): 930-938.
	CHEN N Y, ZHANG G X, ZHANG L S, AN Y M, DU J H, WANG D, GUO C H. The role of ABF transcription factors in response to abiotic stress in plant. Journal of Plant Genetic Resources, 2021, 22(4): 930-938. (in Chinese)
[37]	HU Y X, BAO F, LI J Y. Promotive effect of brassinosteroids on cell division involves a distinct CycD3-induction pathway in Arabidopsis. The Plant Journal: for Cell and Molecular Biology, 2000, 24(5): 693-701. doi: 10.1046/j.1365-313x.2000.00915.x
[38]	林树钦. 脱落酸和表油菜素内酯对月季切花叶片气孔开放和水孔蛋白基因表达的影响[D]. 广州: 仲恺农业工程学院, 2019.
	LIN S Q. Effects of abscisic acid and epibrassinolide on stomatal opening and aquaporin gene expression in cut rose leaves[D]. Guangzhou: Zhongkai University of Agriculture and Engineering, 2019. (in Chinese)
[39]	CRUPI P, ALBA V, MASI G, CAPUTO A R, TARRICONE L. Effect of two exogenous plant growth regulators on the color and quality parameters of seedless table grape berries. Food Research International, 2019, 126: 108667. doi: 10.1016/j.foodres.2019.108667
[40]	BABALIK Z, DEMIRCI T, AŞCI Ö A, BAYDAR N G. Brassinosteroids modify yield, quality, and antioxidant components in grapes (Vitis vinifera cv. Alphonse Lavallée). Journal of Plant Growth Regulation, 2020, 39(1): 147-156. doi: 10.1007/s00344-019-09970-5

基因名称 Gene name	正向引物 Forward primer (5′-3′)	反向引物 Reverse Primer (5′-3′)	NCBI登录号 Accession number
VvActin	CTTGCATCCCTCAGCACCTT	TCCTGTGGACAATGGATGGA	NB000705
VvF3′5′H	ACTAAGCCACAGGAAACTAA	AAACCGCTCAGACCAAAACC	LOC100243414
VvSS	CCAGCCAACGTCATTAGCCT	CCATGACTTGTGGCCTTCCT	LOC100252799
VvLDOX	GCCTAAGACACCAAGCGACTACG	CAACCCAAGCGATAGCACCGATAG	LOC100233142
VvLAR	TGCTTTTGTGATTTTGTTAGAGG	CCCTTCCCCGATTGAGAGTA	LOC100232982
VvINV	CCAGAAAACTTGTAGAAGCACC	GTTGACGCATTCCTTAAGGATC	LOC100232951
VvBZR1	GCACGCCATCTTGCTCCAT	AAGCTCCAGATCATCCAAACCTA	LOC100262472
VvF3′H	GGTGATGTTAGGCAGGAGAGTGTTC	GCTCCACCACCATCTCTTTGAACTC	LOC100232896
VvPP2C	CCACGCTTCCCTCAAACCCTCCCA	CATCCACCACTCCATCATCCCCGC	LOC100242943
VvSnRK2	CAATGCATGCTTTGAAAGTGTG	GCCAAACTGCAGTCTGATTTTA	LOC100260262

时间 Time	处理 Treatment	花色苷 Anthocyanins (mg∙L^-1)	总糖 TotalSugar (mg∙g^-1)	还原糖 Reducing sugar (mg∙g^-1)	蔗糖 Sucrose (mg∙g^-1)
7.20	CK	0.2±0.51a	14.61±1.92a	8.90±0.02a	7.12±0.15a
	HT	0.2±0.14a	14.56±2.02a	9.13±0.18a	7.35±0.26a
	HTE	0.2±0.28a	14.22±1.80a	9.14±0.74a	7.12±.028a
8.10	CK	12.91±0.86c	143.72±5.14a	20.71±1.61a	15.64±0.65b
	HT	14.30±0.79ab	124.72±3.52b	29.88±1.14a	16.56±0.48ab
	HTE	15.09±0.24a	137.35±6.55a	36.30±3.02a	16.92±0.54a
8.30	CK	35.24±2.11ab	199.21±4.55a	127.68±2.36a	23.85±5.48a
	HT	32.61±2.59c	174.96±0.52b	118.02±2.18b	19.92±2.61c
	HTE	36.04±2.98a	199.30±6.63a	124.29±9.47ab	22.34±0.69ab
9.20	CK	49.10±3.07a	225.87±4.19a	128.04±11.85a	26.67±6.93bc
	HT	39.33±2.75c	216.42±4.57b	108.17±15.81c	27.07±6.21b
	HTE	41.19±2.64b	222.41±5.16a	121.40±10.70b	29.43±5.35a

样品名称 Sample	原始序列数据 Raw reads (M)	原始序列长度 Raw bases (G)	过滤后数据 Clean reads (M)	过滤后序列长度 Clean bases (G)	比对率 Valid bases (%)	Q30 (%)	GC (%)
CK1	50.55	7.58	49.83	7.26	95.71	91.50	47.66
CK2	47.78	7.17	47.06	6.86	95.75	92.75	47.52
CK3	47.30	7.10	46.61	6.79	95.68	91.75	47.55
HT1	48.07	7.21	47.37	6.88	95.37	89.64	47.94
HT2	49.42	7.41	48.66	7.08	95.49	92.00	47.56
HT3	49.86	7.48	49.12	7.16	95.69	91.16	47.17
HTE1	48.84	7.33	48.09	7.01	95.71	92.44	47.45
HTE2	51.05	7.66	50.31	7.31	95.52	91.53	47.74
HTE3	50.46	7.57	49.75	7.25	95.78	92.67	47.37

处理 Treatment	差异转录因子个数 Transcription factor number	上调 Up	下调 Down	转录因子家族 Transcription factor family
HT vs CK	95	74	21	AP2、bHLH、bZIP、C2H2、Dof、ERF、HD-ZIP、LBD、MIKC-MADS、MYB、NAC、WRKY
HTE vs CK	57	44	13	bHLH、bZIP、Dof、ERF、HD-ZIP、LBD、MYB、NAC、WRKY
HT vs HTE	6	1	5	MYB
