小麦条锈菌效应蛋白Hasp83在条锈菌致病性中的功能分析

doi:10.3864/j.issn.0578-1752.2023.05.005

摘要/Abstract

摘要：

【背景】条锈病是小麦上的重大病害，由条形柄锈菌小麦专化型（Puccinia striiformis f. sp. tritici，Pst）侵染引起。条锈菌是活体营养型寄生真菌，在侵染过程中形成吸器，通过吸器从寄主植物汲取营养。同时，吸器分泌效应蛋白调控寄主免疫，促进侵染过程。【目的】明确条锈菌效应蛋白的功能及其作用机理，为揭示条锈菌的致病机制打下基础。【方法】比较分析条锈菌夏孢子、芽管和吸器转录组，获得在吸器诱导表达的分泌蛋白基因Hasp83，在本氏烟叶片细胞中瞬时表达观察是否能抑制由BAX引起的细胞坏死；利用qRT-PCR分析该基因在条锈菌侵染小麦不同阶段的表达水平。借助荧光假单胞菌Ⅲ型分泌系统和寄主诱导的基因沉默（host-induced gene silencing，HIGS）分析Hasp83在条锈菌侵染过程中的功能。利用酵母双杂交系统筛选小麦中与Hasp83互作的蛋白，免疫共沉淀技术进一步在烟草细胞中共表达验证Hasp83及其候选靶标蛋白的互作。【结果】Hasp83开放阅读框全长522 bp，编码173个氨基酸，蛋白N端1—29位氨基酸为信号肽，无保守结构域，在本氏烟叶片细胞中瞬时表达能抑制由BAX引起的细胞坏死。qRT-PCR分析显示，Hasp83在条锈菌侵染时期上调表达；利用细菌Ⅲ型分泌系统在小麦水源11品种中瞬时表达Hasp83能够抑制荧光假单胞菌引起的胼胝质积累，在接种条锈菌无毒性小种CYR23后，瞬时表达Hasp83株系产生的活性氧积累面积和过敏性坏死面积相比对照减少19.35%—38.62%；利用HIGS技术在接种条锈菌毒性小种CYR31的小麦水源11中沉默Hasp83，发现条锈菌的产孢量、菌丝长度、菌丝扩展面积和吸器数目减少，致病力降低。酵母双杂交结果表明，效应蛋白Hasp83与其小麦中候选靶标过敏性坏死诱导蛋白Tahir1互作。免疫共沉淀进一步证明Hasp83及其候选靶标Tahir1存在互作。【结论】条锈菌效应蛋白Hasp83可抑制寄主由非致病细菌和无毒性条锈菌生理小种引起的小麦防卫反应，增强病原菌的致病力。

关键词: 小麦条锈病, 吸器, 效应蛋白, 转录组分析, 靶标蛋白鉴定

Abstract:

【Background】Wheat stripe rust is a serious disease on wheat, which is caused by Puccinia striiformis f. sp. tritici (Pst). Pst is an obligate biotrophic fungus, which can form haustorium during infection and absorb nutrients from the host plants via haustorium. Moreover, Pst secretes effectors through haustorium to regulate host immunity and promotes the infection process.【Objective】The objective of this study is to clarify the function and mechanism of Pst effectors, and to reveal the pathogenicity mechanism of Pst.【Method】By comparing the transcriptome of Pst urediospore, germinated tube and haustorium, Hasp83 encoding secreted protein was identified to be significantly induced in haustorium, and whether it could inhibit the cell death caused by BAX on Nicotiana benthamiana leaves was observed through Agrobacterium-mediated transient expression. qRT-PCR was used to detect the expression level of Hasp83 during different Pst infection stages in wheat. The type Ⅲ secretion system (T3SS) of Pseudomonas fluorescens EtHan and host induced gene silencing (HIGS) were carried out to investigate the function of Hasp83 during Pst infection. The yeast two-hybrid (Y2H) system was used to screen the proteins interacting with Hasp83 in wheat, and co-inmunoprecipitation (Co-IP) assay was used to further verify the interaction by co-expressing Hasp83 and its candidate target proteins in N. benthamiana cells.【Result】The open reading frame (ORF) of Hasp83 is 522 bp, encoding 173 amino acids. Hasp83 contains no conserved domain, and the N-terminal 1-29 amino acids encode a signal peptide, which could inhibit the cell death caused by BAX on N. benthamiana leaves through Agrobacterium-mediated transient expression. qRT-PCR analysis revealed that Hasp83 was up-regulated during Pst infection in wheat. Transient expression of Hasp83 in wheat via T3SS could inhibit callose accumulation caused by P. fluorescens, and lead to 19.35%-38.62% decrease of reactive oxygen species (ROS) accumulation area and necrotic cell area caused by the avirulent Pst race CYR23 in wheat. Silencing of Hasp83 by HIGS in Suwon11 wheat leaves infected with the virulent Pst race CYR31 significantly reduced pathogenicity of Pst compared to controls, resulting in less urediospore sporulation, shorter infection hyphal length, smaller infection area, and decreased haustorium number. Y2H result showed that the effector Hasp83 interacted with wheat hypersensitive-induced reaction (HIR) protein, Tahir1. The interaction between Hasp83 and Tahir1 was further confirmed by Co-IP assay in N. benthamiana.【Conclusion】Pst effector Hasp83 can suppress wheat immunity caused by the non-pathogenic bacteria and avirulent Pst, and enhance the pathogenicity of Pst.

Key words: wheat stripe rust, haustorium, effector, transcriptome analysis, identification of target protein

王建锋, 成嘉欣, 舒伟学, 张艳茹, 王晓杰, 康振生, 汤春蕾. 小麦条锈菌效应蛋白Hasp83在条锈菌致病性中的功能分析[J]. 中国农业科学, 2023, 56(5): 866-878.

WANG JianFeng, CHENG JiaXin, SHU WeiXue, ZHANG YanRu, WANG XiaoJie, KANG ZhenSheng, TANG ChunLei. Functional Analysis of Effector Hasp83 in the Pathogenicity of Puccinia striiformis f. sp. tritici[J]. Scientia Agricultura Sinica, 2023, 56(5): 866-878.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2023.05.005

https://www.chinaagrisci.com/CN/Y2023/V56/I5/866

图/表 10

表1

图1

图2

图3

图4

图5

图6

图7

图8

图9

参考文献 43

[1]	陈万权, 徐世昌, 吴立人. 中国小麦条锈病流行体系与持续治理研究回顾与展望. 中国农业科学, 2007, 40(增刊1): 177-183.
	CHEN W Q, XU S C, WU L R. Epidemiology and sustainable management of wheat stripe rust caused by Puccinia striiformis West. in China: A historical retrospect and prospect. Scientia Agricultura Sinica, 2007, 40 (Suppl. 1): 177-183.(in Chinese)
[2]	陈万权, 康振生, 马占鸿, 徐世昌, 金社林, 姜玉英. 中国小麦条锈病综合治理理论与实践. 中国农业科学, 2013, 46(20): 4254-4262. doi: 10.3864/j.issn.0578-1752.2013.20.008
	CHEN W Q, KANG Z S, MA Z H, XU S C, JIN S L, JIANG Y Y. Integrated management of wheat stripe rust caused by Puccinia striiformis f. sp. tritici in China. Scientia Agricultura Sinica, 2013, 46(20): 4254-4262.(in Chinese)
[3]	WAN A M, ZHAO Z H, CHEN X M, HE Z H, JIN S L, JIA Q Z, YAO G, YANG J X, WANG B T, LI G B, BI Y Q, YUAN Z Y. Wheat stripe rust epidemic and virulence of Puccinia striiformis f. sp. tritici in China in 2002. Plant Disease, 2004, 88(8): 896-904. doi: 10.1094/PDIS.2004.88.8.896
[4]	CHEN W Q, WU L R, LIU T G, XU S C, JIN S L, PENG Y L, WANG B T. Race dynamics, diversity, and virulence evolution in Puccinia striiformis f. sp. tritici, the causal agent of wheat stripe rust in China from 2003 to 2007. Plant Disease, 2009, 93(11): 1093-1101. doi: 10.1094/PDIS-93-11-1093
[5]	WAN A M, CHEN X M, HE Z H. Wheat stripe rust in China. Australian Journal of Agricultural Research, 2007, 58(6): 605-619. doi: 10.1071/AR06142
[6]	LINE R F. Stripe rust of wheat and barley in North America: A retrospective historical review. Annual Review of Phytopathology, 2002, 40: 75-118. pmid: 12147755
[7]	FISHER M C, HENK D A, BRIGGS C J, BROWNSTEIN J S, MADOFF L C, MCCRAW S L, GURR S J. Emerging fungal threats to animal, plant and ecosystem health. Nature, 2012, 484(7393): 186-194. doi: 10.1038/nature10947
[8]	JONES J D G, DANGL J L. The plant immune system. Nature, 2006, 444(7117): 323-329. doi: 10.1038/nature05286
[9]	YU X, FENG B M, HE P, SHAN L B. From chaos to harmony: Responses and signaling upon microbial pattern recognition. Annual Review of Phytopathology, 2017, 55: 109-137. doi: 10.1146/annurev-phyto-080516-035649 pmid: 28525309
[10]	HE Q, MCLELLAN H, BOEVINK P C, BIRCH P R J. All roads lead to susceptibility: The many modes of action of fungal and oomycete intracellular effectors. Plant Communications, 2020, 1(4): 100050. doi: 10.1016/j.xplc.2020.100050
[11]	STAPLES R C. Nutrients for a rust fungus: The role of haustoria. Trends in Plant Science, 2001, 6(11): 496-498. pmid: 11701352
[12]	GIRALDO M C, VALENT B. Filamentous plant pathogen effectors in action. Nature Reviews. Microbiology, 2013, 11(11): 800-814.
[13]	CATANZARITI A M, DODDS P N, ELLIS J G. Avirulence proteins from haustoria-forming pathogens. FEMS Microbiology Letters, 2007, 269(2): 181-188. pmid: 17343675
[14]	GARNICA D P, NEMRI A, UPADHYAYA N M, RATHJEN J P, DODDS P N. The ins and outs of rust haustoria. PLoS Pathogens, 2014, 10(9): e1004329.
[15]	ZHENG W M, HUANG L L, HUANG J Q, WANG X J, CHEN X M, ZHAO J, GUO J, ZHUANG H, QIU C Z, LIU J, et al. High genome heterozygosity and endemic genetic recombination in the wheat stripe rust fungus. Nature Communications, 2013, 4: 2673. doi: 10.1038/ncomms3673 pmid: 24150273
[16]	XU Q, TANG C L, WANG L K, ZHAO C C, KANG Z S, WANG X J. Haustoria-arsenals during the interaction between wheat and Puccinia striiformis f. sp. tritici. Molecular Plant Pathology, 2020, 21(1): 83-94. doi: 10.1111/mpp.v21.1
[17]	XU Q, WANG J F, ZHAO J R, XU J H, SUN S T, ZHANG H F, WU J J, TANG C L, KANG Z S, WANG X J. A polysaccharide deacetylase from Puccinia striiformis f. sp. tritici is an important pathogenicity gene that suppresses plant immunity. Plant Biotechnology Journal, 2020, 18(8): 1830-1842. doi: 10.1111/pbi.v18.8
[18]	XU Q, TANG C L, WANG X D, SUN S T, ZHAO J R, KANG Z S, WANG X J. An effector protein of the wheat stripe rust fungus targets chloroplasts and suppresses chloroplast function. Nature Communications, 2019, 10(1): 5571. doi: 10.1038/s41467-019-13487-6 pmid: 31804478
[19]	WANG X D, ZHAI T, ZHANG X M, TANG C L, ZHUANG R, ZHAO H B, XU Q, CHENG Y L, WANG J F, DUPLESSIS S, KANG Z S, WANG X J. Two stripe rust effectors impair wheat resistance by suppressing import of host Fe-S protein into chloroplasts. Plant Physiology, 2021, 187(4): 2530-2543. doi: 10.1093/plphys/kiab434 pmid: 34890460
[20]	许强. 小麦条锈菌效应蛋白Pst_A23调控植物pre-mRNA可变剪切抑制植物免疫[D]. 杨凌: 西北农林科技大学, 2020.
	XU Q. Pre-mRNA regulation mediated by Puccinia striiformis effector Pst_A23 suppresses plant immunity[D]. Yangling: Northwest A&F University, 2020.(in Chinese)
[21]	WEI J P, WANG X D, HU Z Y, WANG X J, WANG J L, WANG J F, HUANG X L, KANG Z S, TANG C L. The Puccinia striiformis effector Hasp98 facilitates pathogenicity by blocking the kinase activity of wheat TaMAPK4. Journal of Integrative Plant Biology, 2023, 65(1): 249-264. doi: 10.1111/jipb.v65.1
[22]	WANG N, TANG C L, FAN X, HE M Y, GAN P F, ZHANG S, HU Z Y, WANG X D, YAN T, SHU W X, et al. Inactivation of a wheat protein kinase gene confers broad-spectrum resistance to rust fungi. Cell, 2022, 185(16): 2961-2974. doi: 10.1016/j.cell.2022.06.027
[23]	WAN C P, LIU Y, TIAN S X, GUO J, BAI X X, ZHU H C, KANG Z S, GUO J. A serine-rich effector from the stripe rust pathogen targets a Raf-like kinase to suppress host immunity. Plant Physiology, 2022, 190(1): 762-778. doi: 10.1093/plphys/kiac218
[24]	PFAFFL M W. A new mathematical model for relative quantification in real-time RT-PCR. Nucleic Acids Research, 2001, 29(9): 2002-2007.
[25]	HOLZBERG S, BROSIO P, GROSS C, POGUE G P. Barley stripe mosaic virus-induced gene silencing in a monocot plant. The Plant Journal, 2002, 30(3): 315-327. doi: 10.1046/j.1365-313X.2002.01291.x
[26]	LACOMME C, CRUZ S S. Bax-induced cell death in tobacco is similar to the hypersensitive response. Proceedings of the National Academy of Sciences of the United States of America, 1999, 96(14): 7956-7961.
[27]	ABRAMOVITCH R B, KIM Y J, CHEN S R, DICKMAN M B, MARTIN G B. Pseudomonas type III effector AvrPtoB induces plant disease susceptibility by inhibition of host programmed cell death. The EMBO Journal, 2003, 22(1): 60-69. doi: 10.1093/emboj/cdg006
[28]	JAMIR Y, GUO M, OH H S, PETNICKI-OCWIEJA T, CHEN S R, TANG X Y, DICKMAN M B, COLLMER A, ALFANO J R. Identification of Pseudomonas syringae type III effectors that can suppress programmed cell death in plants and yeast. The Plant Journal, 2004, 37(4): 554-565. doi: 10.1046/j.1365-313X.2003.01982.x
[29]	YIN C T, HULBERT S. Prospects for functional analysis of effectors from cereal rust fungi. Euphytica, 2011, 179(1): 57-67. doi: 10.1007/s10681-010-0285-x
[30]	XIN X F, HE S Y. Pseudomonas syringae pv. tomato DC3000: A model pathogen for probing disease susceptibility and hormone signaling in plants. Annual Review of Phytopathology, 2013, 51: 473-498. doi: 10.1146/phyto.2013.51.issue-1
[31]	QI T, GUO J, PENG H, LIU P, KANG Z S, GUO J. Host-induced gene silencing: A powerful strategy to control diseases of wheat and barley. International Journal of Molecular Sciences, 2019, 20(1): 206. doi: 10.3390/ijms20010206
[32]	KOCH A, WASSENEGGER M. Host-induced gene silencing— Mechanisms and applications. New Phytologist, 2021, 231(1): 54-59. doi: 10.1111/nph.v231.1
[33]	NOWARA D, GAY A, LACOMME C, SHAW J, RIDOUT C, DOUCHKOV D, HENSEL G, KUMLEHN J, SCHWEIZER P. HIGS: Host-induced gene silencing in the obligate biotrophic fungal pathogen Blumeria graminis. The Plant Cell, 2010, 22(9): 3130-3141. doi: 10.1105/tpc.110.077040
[34]	於立刚, 齐晓晚, 魏晋萍, 王婷, 王晓杰, 康振生, 汤春蕾. 条形柄锈菌吸器特异效应蛋白Hasp68抑制寄主免疫并与小麦组织蛋白酶B互作. 菌物学报, 2020, 39(10): 1905-1919.
	YU L G, QI X W, WEI J P, WANG T, WANG X J, KANG Z S, TANG C L. A haustorium-specific effector protein Hasp68 of Puccinia striiformis suppresses wheat immunity by targeting wheat cathepsin B TaCTSB. Mycosystema, 2020, 39(10): 1905-1919.(in Chinese)
[35]	季森, 赵梦鑫, 徐静华, 汤春蕾, 康振生, 王晓杰. 小麦条锈菌效应蛋白HASP2抑制寄主免疫反应. 植物病理学报, 2019, 49(3): 326-333.
	JI S, ZHAO M X, XU J H, TANG C L, KANG Z S, WANG X J. Wheat stripe rust effector HASP2 inhibits host immune response. Acta Phytopathologica Sinica, 2019, 49(3): 326-333.(in Chinese)
[36]	赵聪聪, 盛丽梅, 许强, 汤春蕾, 康振生, 王晓杰. 小麦条锈菌细胞质效应子Hasp8抑制植物基础免疫. 植物保护学报, 2020, 47(3): 537-545.
	ZHAO C C, SHENG L M, XU Q, TANG C L, KANG Z S, WANG X J. Cytoplasmic effector Hasp8 of Puccinia striiformis f. sp. tritici inhibits plant immunity. Journal of Plant Protection, 2020, 47(3): 537-545.(in Chinese)
[37]	QI T, GUO J, LIU P, HE F X, WAN C P, ISLAM M A, TYLER B M, KANG Z S, GUO J. Stripe rust effector PstGSRE1 disrupts nuclear localization of ROS-promoting transcription factor TaLOL2 to defeat ROS-induced defense in wheat. Molecular Plant, 2019, 12(12): 1624-1638. doi: 10.1016/j.molp.2019.09.010
[38]	YANG Q, HUAI B Y, LU Y X, CAI K Y, GUO J, ZHU X G, KANG Z S, GUO J. A stripe rust effector Pst18363 targets and stabilises TaNUDX23 that promotes stripe rust disease. New Phytologist, 2020, 225(2): 880-895. doi: 10.1111/nph.16199 pmid: 31529497
[39]	LIU C, WANG Y Q, WANG Y F, DU Y Y, SONG C, SONG P, YANG Q, HE F X, BAI X X, HUANG L L, GUO J, KANG Z S, GUO J. Glycine-serine-rich effector PstGSRE4 in Puccinia striiformis f. sp. tritici inhibits the activity of copper zinc superoxide dismutase to modulate immunity in wheat. PLoS Pathogens, 2022, 18(7): e1010702.
[40]	NADIMPALLI R, YALPANI N, JOHAL G S, SIMMONS C R. Prohibitins, stomatins, and plant disease response genes compose a protein superfamily that controls cell proliferation, ion channel regulation, and death. The Journal of Biological Chemistry, 2000, 275(38): 29579-29586. doi: 10.1074/jbc.M002339200
[41]	ROSTOKS N, SCHMIERER D, KUDRNA D, KLEINHOFS A. Barley putative hypersensitive induced reaction genes: Genetic mapping, sequence analyses and differential expression in disease lesion mimic mutants. Theoretical and Applied Genetics, 2003, 107(6): 1094-1101. doi: 10.1007/s00122-003-1351-8 pmid: 12928776
[42]	QI Y P, TSUDA K, NGUYEN L V, WANG X, LIN J S, MURPHY A S, GLAZEBROOK J, THORDAL-CHRISTENSEN H, KATAGIRI F. Physical association of Arabidopsis hypersensitive induced reaction proteins (HIRs) with the immune receptor RPS2. The Journal of Biological Chemistry, 2011, 286(36): 31297-31307. doi: 10.1074/jbc.M110.211615
[43]	ZHOU L, CHEUNG M Y, LI M W, FU Y P, SUN Z X, SUN S M, LAM H M. Rice hypersensitive induced reaction protein 1 (OsHIR1) associates with plasma membrane and triggers hypersensitive cell death. BMC Plant Biology, 2010, 10: 290. doi: 10.1186/1471-2229-10-290 pmid: 21192820

用途 Use	引物名称 Primer name	引物序列 F Primer sequence F (5′-3′)	引物序列 R Primer sequence R (5′-3′)
分泌系统载体构建 Construction of secretion system vector	pEDV6-Hasp83^∆sp	GGGGACAAGTTTGTACAAAAAAGCAGG CTTCATGCATAAAGCCCTGAACC	GGGGACCACTTTGTACAAGAAAGCTGGGTC TCCTCGATGTGAAATACC
沉默载体构建 Construction of silent vector	γ-Hasp 83-1	TTAATTAACGGAAACTCATCTGTCAATCA	GCGGCCGCGAGGAAAGGGAAAATGGAGA
沉默载体构建 Construction of silent vector	γ-Hasp 83-2	TTAATTAATCCATTACCTTGTCGTTCTCA	GCGGCCGCATACCGCCAGTCGTCCTTA
酵母载体构建 Construction of yeast-expression vector	pGBKT7-Hasp83^∆sp	CGGAATTCATGCATAAAGCCCTGAACC	CGGGATCCTTATCCTCGATGTGAAATACC
酵母载体构建 Construction of yeast-expression vector	pGADT7-Tahir1	CGGAATTCATGGGTGGGGTACTTGGT	CGGGATCCTCAAACCATCCTGCCCT
瞬时表达载体构建 Construction of transient overexpression vector	pGR106-Hasp83^∆sp	GGCATCGATATGCATAAAGCCCTGAACC	CATGCTGACTTATCCTCGATG
	pBinGFP2-Hasp83^∆sp	GACGAGCTGTACAAGGGTACCATGCATAAA GCCCTGAACC	TCTAGTTCATCTAGAGGATCCTCCTCGATGTGAAATACC
	pICH86988-Tahir1-HA	TTACAATTATCGATACAATGTACCCATACGA CGTCCCAGACTACGCTATGGGTGGGGTACTTGGT	CTCATTAAAGCAGGACAAGCAACCATCCTGCCCTGGA
实时荧光定量PCR qRT-PCR	qHasp83-1	CGGAAACTCATCTGTCAATCA	GAGGAAAGGGAAAATGGAGA
	qHasp83-2	TCCATTACCTTGTCGTTCTCA	ATACCGCCAGTCGTCCTTA
	Pst EF	TTCGCCGTCCGTGATATGAGACAA	ATGCGTATCATGGTGGTGGAGTGA
	Ta EF	TGGTGTCATCAAGCCTGGTATGGT	ACTCATGGTGCATCTCAACGGACT
