水稻CSSL-Z481代换片段携带的穗部性状QTL分析及次级代换系培育

doi:10.3864/j.issn.0578-1752.2023.07.003

摘要/Abstract

摘要：

【背景】粮食安全是保障国家安全的重要基础，水稻是人民赖以生存的主要粮食作物，提高其产量是重要的育种目标。水稻产量由每株有效穗数、每穗实粒数和粒重等性状构成，其中，粒重与籽粒形状、充实程度等密切相关。但这些性状都是由多基因控制，遗传基础复杂。染色体片段代换系(CSSL)可将这些复杂性状的QTL较准确地分解为单个孟得尔因子研究，且与育种工作紧密衔接，因而是理想的遗传研究和育种材料。【目的】前期以4代换片段的水稻染色体片段代换系Z481精细定位了一个易落粒基因SH6，但Z481与受体日本晴间还存在多个显著差异的穗部性状。明晰控制这些差异性状的QTL在代换片段上如何分布，并分解为单片段代换系，对目标QTL的图位克隆及应用于水稻分子设计育种有重要应用价值。【方法】利用受体亲本日本晴与Z481杂交构建的次级F₂分离群体以SAS9.3统计软件的混合线性模型（mixed linear model，MLM）法进行穗部性状QTL定位（P<0.05），然后，根据基因型和表型，从F₂选择42个单株在F₃株系利用MAS法培育单片段及双片段代换系，并利用IBM SPSS Statistics 25.0的ONE-WAY ANOVA和TWO-WAY ANOVA分析及LSD和Duncans多重比较（P<0.05）分析这些单片段代换系（SSSL）和双片段代换系（DSSL）的QTL加性和上位性效应。【结果】以日本晴/Z481构建的次级F₂群体共定位出12个控制水稻穗部性状的QTL，并培育出相应QTL的11个单片段代换系（S1—S11）和3个双片段代换系（D1—D3）。其中，有8个QTL（qGL1、qGL3、qGL6、qGW1、qGW3、qRLW1、qRLW3和qRLW6）可被单片段代换系所验证，表明这些QTL遗传稳定。此外，利用单片段代换系鉴定到qGL1-2、qGL1-3、qGL3-2等33个QTL。其中，qNSB1-1等15个可能为新鉴定的QTL。且利用3个DSSL分析了非等位QTL间的上位性效应，结果表明，不同QTL聚合会产生不同的上位性效应，如qGL3（a=1.26）和qGL6-2（a=0.86）聚合产生了-0.77的上位性效应，据DSSL遗传模型，D2的粒长遗传效应（1.35）产生了更长的粒长表型；qGWT3-2（a=3.18）和qGWT6-2（a=3.39）聚合产生了-5.46的上位性效应，则D2的千粒重遗传效应（1.11）产生了更小的籽粒。【结论】 Z481的4个代换片段上共携带45个水稻穗部性状的QTL，并进一步分解到11个次级单片段代换系上，单片段代换系具有比F₂群体更高的QTL检测效率。利用SSSL和DSSL解析的水稻穗部性状QTL的加性效应和上位性效应，有助于根据这些遗传信息预测设计基因型的表型，从而选择合适的SSSL进行育种设计。

关键词: 水稻, 穗部性状, QTL, 染色体代换片段, 加性效应, 上位性效应

Abstract:

【Background】 Food safety is key for ensuring national security. Rice is the staple food crop upon which people life depend. It is an important breeding target to improve its yield. Rice yield is composed of panicle number per plant, grain number per panicle and grain weight, among which grain weight relates closely to grain size and filling degree. However, these traits are controlled by multiple genes, and their genetic basis are complex. Chromosome segment substitution lines (CSSLs) can accurately dissect QTL for complex trait into a single Mendel’s factor, which is closely linked with the breeding work, so they are ideal materials for genetic research and breeding. 【Objective】 In the early stage, we fine-mapped a seed shattering gene SH6 using a rice chromosome segment substitution line Z481 carrying four substitution segments, However, there are still some significant differences in the panicle traits between Z481 and its recipient parent Nipponbare. It is important to understand how to distribute for these QTLs controlling panicle traits on 4 substitution segments of Z481 and then to dissect them into single segment substitution lines (SSSLs) for map-cloning of target QTL in theory meaning and for rice breeding by design in application value.【Method】 Here, the secondary F₂population constructed by crossing Nipponbare with Z481 was used to map QTL for these traits by mixed linear model (MLM) method in SAS9.3 statictic shoftware (P<0.05), and then by MAS method to develop SSSLs and dual-segment substitution lines (DSSLs) in F₃ derived from 42 F₂ indiviuals according to their genotypes and phynotypes. Finally, the additive effect and epistasis effect of QTL were analyzed using these SSSLs and DSSLs by ONE-WAY ANOVA,TWO-WAY ANOVA, LSD and Duncan’s multiple comparasion (P<0.05) in IBM SPSS Statistics 25.0.【Result】 12 QTLs controlling rice panicle traits are mapped from the secondary F₂ population constructed by Nipponbare/Z481, and 11 single segment substitution lines (S1-S11) and 3 dual-segment substitution lines (D1-D3) with each corresponding single substitution segment are developed. Among them, 8 QTLs (qGL1, qGL3, qGL6, qG-W1, qGW3, qRLW1, qRLW3, qRLW6) can be verified by 11 SSSLs, indicating that these QTLs are genetically stable. In addition, 33 QTLs such as qGL1-2, qGL1-3, qGL3-2 etc. are only detected by 11 single segment substitution lines. Among them, 15 QTLs such as qNSB1-1 etc. might be novel QTLs identified in the study. Furthermore, the epistasis effect between non-allelic QTLs was analyzed by three DSSLs and corresponding SSSLs, the results showed that pyramid of different QTL produce various epistasis effect. For example, the pyramid of qGL3 (a=1.26) and qGL6-2(a=0.86) yield epistasis effect of -0.77, according to the genetic model of DSSL, D2 with the genetic effect of 1.35 produce longer grain length than any of two SSSLs with qGL3 or qGL6-2; the pyramid of qGWT3-2 (a=3.18) and qGWT6-2 (a=3.39) produce epistasis effect of -5.46, making the 1000-grain weight of D2 significantly smaller than that of the corresponding SSSLs due to its genetic effect of 1.11.【Conclusion】 In total 45 QTLs for rice panicle traits are deteted on the 4 substitution segments of Z481 and then further dissected into 11 secondary SSSLs. SSSL have higher efficiency for QTL detection than the F₂ population. The additive effect and epistasis effect of these QTLs detected by SSSL and DSSL are necessary for breeders to predict the phenotype of the designed genotype according to these genetic informations and then to screen favorable SSSLs to breed by design.

Key words: rice, panicle traits, QTL, chromosome segment substitution line, additive effect, epistasis effect

李儒香, 周恺, 王大川, 李巧龙, 向奥妮, 李璐, 李苗苗, 向思茜, 凌英华, 何光华, 赵芳明. 水稻CSSL-Z481代换片段携带的穗部性状QTL分析及次级代换系培育[J]. 中国农业科学, 2023, 56(7): 1228-1247.

LI RuXiang, ZHOU Kai, WANG DaChuan, LI QiaoLong, XIANG AoNi, LI Lu, LI MiaoMiao, XIANG SiQian, LING YingHua, HE GuangHua, ZHAO FangMing. Analysis of QTLs and Breeding of Secondary Substitution Lines for Panicle Traits Based on Rice Chromosome Segment Substitution Line CSSL-Z481[J]. Scientia Agricultura Sinica, 2023, 56(7): 1228-1247.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2023.07.003

https://www.chinaagrisci.com/CN/Y2023/V56/I7/1228

图/表 7

图1

图2

图3

表1

表2

图4

表3

参考文献 60

[1]	GUO T, CHEN K, DONG N Q, SHI C L, YE W W, GAO J P, SHAN J X, LIN H X. Grain size and NUMBER 1 negatively regulates the OsMKKK10-OsMKK4-OsMPK6 cascade to coordinate the trade-off between grain number per panicle and grain size in rice. The Plant Cell, 2018, 30(4): 871-888. doi: 10.1105/tpc.17.00959
[2]	ZHAO M Z, MA Z B, WANG L L, TANG Z Q, MAO J, LIANG C B, GAO H, ZHANG L Y, HE N, FU L, WANG C H, SUI G M, ZHANG W J. SNP-based QTL mapping for panicle traits in the japonica super rice cultivar Liaoxing 1. The Crop Journal, 2020, 8(5): 769-780. doi: 10.1016/j.cj.2020.07.002
[3]	SEPTININGSIH E M, PRASETIYONO J, LUBIS E, TAI T h, TJUBARYAT T, MOELJOPAWIRO S, MCCOUCH S R. Identification of quantitative trait loci for yield and yield components in an advanced backcross population derived from the Oryza sativa variety IR64 and the wild relative O-rufipogon. Theoretical and Applied Genetics, 2003, 107(8): 1419-1432. doi: 10.1007/s00122-003-1373-2
[4]	曾瑞珍, Akshay TALUKDAR, 刘芳, 张桂权. 利用单片段代换系定位水稻粒形QTL. 中国农业科学, 2006, 39(4): 647-654.
	ZENG R Z, TALUKDAR A, LIU F, ZHANG G Q. Mapping of the QTLs for grain shape using single segment substitution lines in rice. Scientia Agricultura Sinica, 2006, 39(4): 647-654. (in Chinese)
[5]	WENG J F, GU S H, WAN X Y, GAO H, GUO T, SU N, LEI C L, ZHANG X, CHENG Z J, GUO X P, WANG J L, JIANG L, ZHAI H Q, WAN J M. Isolation and initial characterization of GW5, a major QTL associated with rice grain width and weight. Cell Research, 2008, 18(12): 1199-1209. doi: 10.1038/cr.2008.307 pmid: 19015668
[6]	DESHMUKH R, SINGH A, JAIN N, ANAND S, GACCHE R, SINGH A, GAIKWAD K, SHARMA T, MOHAPATRA T, SINGH N. Identification of candidate genes for grain number in rice (Oryza sativa L.). Functional & Integrative Genomics, 2010, 10(3): 339-347.
[7]	BIAN J M, HE H H, LI C J, SHI H, ZHU C L, PENG X S, FU J R, HE X P, CHEN X R, HU L F, OUYANG L J. Identification and validation of a new grain weight QTL in rice. Genetics and Molecular Research, 2013, 12(4): 5623-5633. doi: 10.4238/2013.November.18.11 pmid: 24301931
[8]	高方远, 罗正良, 任鄄胜, 吴贤婷, 陆贤军, 苏相文, 吕建群, 任光俊. 水稻粒厚主效位点qGT8精细定位和候选基因分析. 中国农业科学, 2015, 48(24): 4859-4871. doi: 10.3864/j.issn.0578-1752.2015.24.001
	GAO F Y, LUO Z L, REN J S, WU X T, LU X J, SU X W, LÜ J Q, REN G J. Fine mapping and candidate gene analysis of the main effect locus qGT8, a major QTL for grain thickness in rice. Scientia Agricultura Sinica, 2015, 48(24): 4859-4871. (in Chinese)
[9]	刘颖, 叶生鑫, 彭强, 张大双, 吴健强, 王际凤, 黄培英, 朱速松. 水稻穗长和有效穗数的QTL定位分析. 江苏农业科学, 2016, 44(4): 86-89.
	LIU Y, YE S X, PENG Q, ZHANG D S, WU J Q, WANG J F, HUANG P Y, ZHU S S. QTL mapping analysis of panicle length and effective panicle number in rice. Jiangsu Agricultural Sciences, 2016, 44(4): 86-89. (in Chinese)
[10]	陈昊. 水稻穗粒数基因GN2的克隆与功能分析[D]. 北京: 中国农业大学, 2017.
	CHEN H. Cloning and functional analysis of a novel gene, GN2, controlling grain number of rice (Oriyza sativa)[D]. Beijing: China Agricultural University, 2017. (in Chinese)
[11]	HU Z J, CAO L M, SUN X J, ZHU Y, ZHANG T Y, JIANG L, LIU Y H, DONG S Q, SUN D Y, YANG J S, HE H H, LUO X J. Fine mapping of a major quantitative trait locus, qgnp7(t), controlling grain number per panicle in African rice (Oryza glaberrima S.). Breeding Science, 2018, 68(5): 606-613. doi: 10.1270/jsbbs.18084
[12]	张健, 杨靖, 王豪, 李冬秀, 杨瑰丽, 黄翠红, 周丹华, 郭涛, 陈志强, 王慧. 基于高密度遗传图谱定位水稻籽粒大小相关性状QTL. 中国农业科学, 2020, 53(2): 225-238. doi: 10.3864/j.issn.0578-1752.2020.02.001
	ZHANG J, YANG J, WANG H, LI D X, YANG G L, HUANG C H, ZHOU D H, GUO T, CHEN Z Q, WANG H. QTL mapping for grain size related traits based on a high-density map in rice. Scientia Agricultura Sinica, 2020, 53(2): 225-238. (in Chinese) doi: 10.3864/j.issn.0578-1752.2020.02.001
[13]	WANG D C, ZHOU K, XIANG S Q, ZHANG Q L, LI R X, LI M M, LIANG P X, FARKHANDA N, HE G H, LING Y H, ZHAO F M. Identification pyramid and candidate genes of QTLs for associated traits based on a dense erect panicle rice CSSL-Z749 and five SSSLs, three DSSLs and one TSSL. Rice, 2021, 14(1): 55. doi: 10.1186/s12284-021-00496-7
[14]	LIANG P X, WANG H, ZHANG Q L, ZHOU K, LI M M, LI R X, XIANG S Q, ZHANG T, LING Y H, YANG Z L, HE G H, ZHAO F M. Identification and pyramiding of QTLs for rice grain size based on short-wide grain CSSL-Z563 and fine-mapping of qGL3-2. Rice, 2021, 14(1): 35. doi: 10.1186/s12284-021-00477-w
[15]	宋博文, 王朝欢, 赵哲, 陈淳, 黄明, 陈伟雄, 梁克勤, 肖武名. 基于高密度遗传图谱对水稻粒形QTL定位及分析. 作物学报, 2022, 48(11): 2813-2829. doi: 10.3724/SP.J.1006.2022.12069
	SONG B W, WANG C H, ZHAO Z, CHEN C, HUANG M, CHEN W X, LIANG K Q, XIAO W M. QTL Mapping and analysis of QTLs for grain size in rice based on high density genetic map. Acta Agronomica Sinica, 2022, 48(11): 2813-2829. (in Chinese)
[16]	ZHANG T, WANG S M, SUN S F, ZHANG Y, LI J, YOU J, SU T, CHEN W B, LING Y H, HE G H, ZHAO F M. Analysis of QTL for grain size in a rice chromosome segment substitution line Z1392 with long grains and fine mapping of qGL-6. Rice, 2020, 13(1): 40. doi: 10.1186/s12284-020-00399-z
[17]	MA F Y, ZHU X Y, WANG H, WANG S M, CUI G Q, ZHANG T, YANG Z L, HE G H, LING Y H, WANG N, ZHAO F M. Identification of QTL for kernel number-related traits in a rice chromosome segment substitution line and fine mapping of qSP1. The Crop Journal, 2019, 7(4): 494-503. doi: 10.1016/j.cj.2018.12.009
[18]	MA F Y, DU J, WANG D C, WANG H, ZHAO B B, HE G H, YANG Z L, ZANG T, WU R H, ZHAO F M. Identification of long-grain chromosome segment substitution line Z744 and QTL analysis for agronomic traits in rice. Journal of Integrative Agriculture, 2020, 19(5): 1163-1169. doi: 10.1016/S2095-3119(19)62751-6
[19]	WANG S M, CUI G Q, WANG H, MA F Y, XIA S S, LI Y F, YANG Z L, LING Y H, ZHANG C W, HE G H, ZHAO F M. Identification and QTL mapping of Z550, a rice backcrossed inbred line with increased grains per panicle. Journal of Integrative Agriculture, 2019, 18(3): 526-531. doi: 10.1016/S2095-3119(18)61996-3
[20]	LI N, XU R, DUAN P G, LI Y H. Control of grain size in rice. Plant Reproduction, 2018, 31(3): 237-251. doi: 10.1007/s00497-018-0333-6 pmid: 29523952
[21]	HUANG J, LI Z Y, ZHAO D Z. Deregulation of the OsmiR160 target gene OsARF18 causes growth and developmental defects with an alteration of auxin signaling in rice. Scientific Reports, 2016, 6: 29938. doi: 10.1038/srep29938
[22]	XU Y X, XIAO M Z, LIU Y, FU J L, HE Y, JIANG D A. The small auxin-up RNA OsSAUR45 affects auxin synthesis and transport in rice. Plant Molecular Biology, 2017, 94(1/2): 97-107. doi: 10.1007/s11103-017-0595-7
[23]	ASHIKARI M, SAKAKIBARA H, LIN S Y, YAMAMOTO T, TAKASHI T, NISHIMURA A, ANGELES E R, QIAN Q, KITANO H, MATSUOKA M. Cytokinin oxidase regulates rice grain production. Science, 2005, 309: 741-745. doi: 10.1126/science.1113373 pmid: 15976269
[24]	LI S Y, ZHAO B R, YUAN D Y, DUAN M J, QIAN Q, TANG L, WANG B, LIU X Q, ZHANG J, WANG J, SUN J Q, LIU Z, FENG Y Q, YUAN L P, LI C Y, Rice zinc finger protein DST enhances grain production through controlling Gn1a/OsCKX2 expression. Proceedings of the National Academy of Sciences of the United States of America, 2013, 110(8): 3167-3172.
[25]	WU Y, WANG Y, MI X F, SHAN J X, LI X M, XU J L, LIN H X. The QTL GNP1 Encodes GA20ox1, which increases grain number and yield by increasing cytokinin activity in rice panicle meristems. PLoS Genetics, 2016, 12(10): e1006386. doi: 10.1371/journal.pgen.1006386
[26]	FANG N, XU R, HUANG L J, ZHANG B L, DUAN P G, LI N, LUO Y H, LI Y H. SMALL GRAIN 11 controls grain size, grain number and grain yield in rice. Rice, 2016, 9(1): 64. doi: 10.1186/s12284-016-0136-z
[27]	WU Y Z, FU Y C, ZHAO S S, GU P, ZHU Z F, SUN C Q, TAN L B. CLUSTERED PRIMARY BRANCH 1, a new allele of DWARF 11, controls panicle architecture and seed size in rice. Plant Biotechnology Journal, 2016, 14(1): 377-386. doi: 10.1111/pbi.12391
[28]	QIAO S L, SUN S Y, WANG L L, WU Z H, LI C X, LI X M, WANG T, LENG L N, TIAN W S, LU T G, WANG X L. The RLA1/SMOS1 transcription factor functions with OsBZR1 to regulate brassinosteroid signaling and rice architecture. The Plant Cell, 2017, 29(2): 292-309. doi: 10.1105/tpc.16.00611
[29]	HUANG X Z, QIAN Q, LIU Z B, SUN H Y, HE S Y, LUO D, XIA G M, CHU C C, LI J Y, FU X D. Natural variation at the DEP1 locus enhances grain yield in rice. Nature Genetics, 2009, 41(4): 494-497. doi: 10.1038/ng.352
[30]	LI S, LIU W, ZHANG X, LIU Y, LI N, LI Y. Roles of the Arabidopsis G protein gamma subunit AGG3 and its rice homologs GS3 and DEP1 in seed and organ size control. Plant Signaling Behavior, 2012, 7(10): 1357-1359. doi: 10.4161/psb.21620
[31]	LI F, LIU W B, TANG J Y, CHEN J F, TONG H N, HU B, LI C L, FANG J, CHEN M S, CHU C C. Rice DENSE AND ERECT PANICLE 2 is essential for determining panicle outgrowth and elongation. Cell Research, 2010, 20(7): 838-849. doi: 10.1038/cr.2010.69
[32]	QIAO Y L, PIAO R H, SHI J X, LEE S I, JIANG W Z, KIM B K, LEE J, HAN L Z, MA W B, KOH H J. Fine mapping and candidate gene analysis of dense and erect panicle 3, DEP3, which confers high grain yield in rice (Oryza sativa L.). Theoretical and Applied Genetics, 2011, 122(7): 1439-1449. doi: 10.1007/s00122-011-1543-6
[33]	YANG T F, ZHANG S H, ZHAO J L, LIU Q, HUANG Z H, MAO X X, DONG J F, WANG X F, ZHANG G Q, LIU B. Identification and pyramiding of QTLs for cold tolerance at the bud bursting and the seedling stages by use of single segment substitution lines in rice (Oryza sativa L.). Molecular Breeding, 2016, 36(7): 1-10. doi: 10.1007/s11032-015-0425-z
[34]	ZHOU Y L, XIE Y H, CAI J L, LIU C B, ZHU H T, JIANG R, ZHONG Y Y, ZHANG G L, TAN B, LIU G F, FU X L, LIU Z Q, WANG S K, ZHANG G Q, ZENG R Z. Substitution mapping of QTLs controlling seed dormancy using single segment substitution lines derived from multiple cultivated rice donors in seven cropping seasons. Theoretical and Applied Genetics, 2017, 130(6): 1191-1205. doi: 10.1007/s00122-017-2881-9 pmid: 28283703
[35]	LI Z H, RIAZ A, ZHANG Y X, ANIS G B, ZHU A K, CAO L Y, CHENG S H. Quantitative trait loci mapping for rice yield-related traits using chromosomal segment substitution lines. Rice Science, 2019, 26(5): 261: 264. doi: 10.1016/j.rsci.2019.02.001
[36]	BALAKRISHNAN D, SURAPANENI M, MESAPOGU S, NEELAMRAJU S. Development and use of chromosome segment substitution lines as a genetic resource for crop improvement. Theoretical and Applied Genetics, 2019, 132(1): 1-25. doi: 10.1007/s00122-018-3219-y pmid: 30483819
[37]	YUAN H, GAO P, HU X L, YUAN M, XU Z Y, JIN M Y, SONG W C, ZHAN S J, ZHU X B, TU B, LI T, WANG Y P, MA B T, QIN P, CHEN W L, LI S G. Fine mapping and candidate gene analysis of qGSN5, a novel quantitative trait locus coordinating grain size and grain number in rice. Theoretical and Applied Genetics, 2022, 135(1): 51-64. doi: 10.1007/s00122-021-03951-7
[38]	张桂权. 基于SSSL文库的水稻设计育种平台. 遗传, 2019, 41(8): 754-760.
	ZHANG G Q. The platform of breeding by designbased on the SSSL library in rice. Hereditas, 2019, 41(8): 754-760. (in Chinese)
[39]	郑丽媛, 魏霞, 周可, 向佳, 李燕, 刘宝玉, 何光华, 凌英华赵芳明. 携带主效落粒基因的水稻染色体片段代换系Z481的鉴定及和SH6(t)的定位. 科学通报, 2016, 61(7): 748-758.
	ZHENG L Y, WEI X, ZHOU K, XIANG J, LI Y, LIU B Y, HE G H, LING Y H, ZHAO F M. Identification of a rice chromosome segment substitution line Z481 carrying a major gene for seed shattering and mapping of SH6 (t). Chinese Science Bulletin, 2016, 61(7): 748-758. (in Chinese)
[40]	WANG H, ZHANG J Y, Naz F, LI J, SUN S F, HE G H, ZHANG T, LING Y H, ZHAO F M. Identification of rice QTLs for important agronomic traits with long-kernel CSSL-Z741 and three SSSLs. Rice Science, 2020, 27(5): 414-422. doi: 10.1016/j.rsci.2020.04.008
[41]	MCCOUCH S R, KOCHERT G, YU Z H, WANG Z Y, KHUSH G S, COFFMAN W R, TANKSLEY S D. Molecular mapping of rice chromosomes. Theoretical and Applied Genetics, 1988, 76(6): 815-829.
[42]	ZHAO F M, TAN Y, ZHENG L Y, ZHOU K, HE G H, LING Y H, ZHANG L H, XU S Z. Identification of rice chromosome segment substitution line Z322-1-10 and mapping QTL for agronomic traits from the F₃ population. Cereal Research Communications, 2016, 44(3): 370-380. doi: 10.1556/0806.44.2016.022
[43]	SAS Institute. 2009. SAS/STAT: Users’ guide. version 9.3. http://suport.sus.com/publishing.
[44]	YANG W F, LIANG J Y, HAO Q W, LUAN X, TAN Q Y, LIN S W, ZHU H T, LIU G F, LIU Z P, BU S H, WANG S K, ZHANG G Q. Fine mapping of two grain chalkiness QTLs sensitive to high temperature in rice. Rice, 2021, 14(1): 33. doi: 10.1186/s12284-021-00476-x pmid: 33792792
[45]	LI J, YANG H X, XU G Y, DENG K L, YU J J, XIANG S Q, ZHOU K, ZHANG Q L, LI R X, LI M M, LING Y H, YANG Z L, HE G H, ZHAO F M. QTL analysis of Z414, a chromosome segment substitution line with short, wide grains, and substitution mapping of qGL11 in rice. Rice, 2022, 15(1): 25. doi: 10.1186/s12284-022-00571-7
[46]	张分云, 李宏, 周向阳, 王重荣, 周德贵, 赖穗春, 陈立云, 周少川. 水稻产量分子设计育种研究进展. 分子植物育种, 2013, 11(6): 663-672.
	ZHANG F Y, LI H, ZHOU X Y, WANG C R, ZHOU D G, LAI S C, CHEN L Y, ZHOU S C. Approach to rice breeding by molecular design in grain yield. Molecular Plant Breeding, 2013, 11(6): 663-672. (in Chinese)
[47]	赵芳明, 张桂权, 曾瑞珍, 杨正林, 凌英华, 桑贤春, 何光华. 利用单片段代换系研究水稻产量相关性状QTL加性及上位性效应. 作物学报, 2012, 38(11): 2007-2014. doi: 10.3724/SP.J.1006.2012.02007
	ZHAO F M, ZHANG G Q, ZENG R Z, YANG Z L, LING Y H, SANG X C, HE G H. Study on the additive and epistasis effects of QTL in rice yield related traits using single segment substitution lines. Acta Agronomica Sinica, 2012, 38(11): 2007-2014. (in Chinese) doi: 10.3724/SP.J.1006.2012.02007
[48]	ZHAO F M, ZHU H T, ZENG R Z, ZHANG G Q, XU S Z. Detection of additive and additive × environment interaction effects of QTLs for yield component traits of rice using single segment substitution lines (SSSLs). Plant Breeding, 2016, 135(4): 452-458. doi: 10.1111/pbr.2016.135.issue-4
[49]	ESHED Y, ZAMIR D. An introgression line population of Lycopersicon pennellii in the cultivated tomato enables the identification and fine mapping of yield-associated QTL. Genetics, 1995, 141(3): 1147-1162. doi: 10.1093/genetics/141.3.1147
[50]	CHAN A N, WANG L L, ZHU Y J, FAN Y Y, ZHUANG J Y, ZHANG Z H. Identification through fine mapping and verification using CRISPR/Cas9-targeted mutagenesis for a minor QTL controlling grain weight in rice. Theoretical and Applied Genetics, 2021, 134(1): 327-337. doi: 10.1007/s00122-020-03699-6 pmid: 33068118
[51]	SUN W, XU X H, LI Y P, XIE L X, HE Y N, LI W, LU X B, SUN H W, XIE X Z. OsmiR530 acts downstream of OsPIL15 to regulate grain yield in rice. New Phytologist, 2020, 226(3): 823-837. doi: 10.1111/nph.16399 pmid: 31883119
[52]	TAO Y J, MIAO J, WANG J, LI W Q, XU Y, WANG F Q, JIANG Y J, CHEN Z H, FAN F J, XU M B, ZHOU Y, LIANG G H, YANG J. RGG1, involved in the cytokinin regulatory pathway, controls grain size in rice. Rice, 2020, 13(1): 76. doi: 10.1186/s12284-020-00436-x pmid: 33169285
[53]	QI P, LIN Y S, SONG X J, SHEN J B, HUANG W, SHAN J X, ZHU M Z, JIANG L W, GAO J P, LIN H X. The novel quantitative trait locus GL3.1 controls rice grain size and yield by regulating Cyclin-T1;3. Cell Research, 2012, 22(12): 1666-1680. doi: 10.1038/cr.2012.151
[54]	LI C N, ZHU S S, ZHANG H, CHEN L P, CAI M H, WANG J C, CHAI J T, WU F Q, CHENG Z J, GUO X P, ZHANG X, WAN J M. OsLBD37 and OsLBD38, two class II type LBD proteins, are involved in the regulation of heading date by controlling the expression of Ehd1 in rice. Biochemical and Biophysical Research Communications, 2017, 486(3): 720-725. doi: 10.1016/j.bbrc.2017.03.104
[55]	沈文强, 赵冰冰, 于国玲, 李凤菲, 朱小燕, 马福盈李云峰, 何光华, 赵芳明. 优良水稻染色体片段代换系Z746的鉴定及重要农艺性状QTL定位及其验证. 作物学报, 2021, 47(3): 451-461. doi: 10.3724/SP.J.1006.2021.92002
	SHEN W Q, ZHAO B B, YU G L, LI F F, ZHU X Y, MA F Y, LI Y F, HE G H, ZHAO F M. Identification and QTL mapping of important agronomic traits of an excellent rice chromosome fragment substitution line Z746. Acta Agronomica Sinica, 2021, 47(3): 451-461 (in Chinese) doi: 10.3724/SP.J.1006.2021.92002
[56]	SUN S F, XIANG S Q, LV M, ZHOU K, LI J, LIANG P X, LI M M, LI R X, LING Y H, HE G H, ZHAO F M. Identifcation, pyramid, and candidate gene of QTL for yield‑related traits based on rice CSSLs in indica Xihui18 background. Molecular Breeding, 2022, 42(4): 19. doi: 10.1007/s11032-022-01284-x
[57]	ZHANG D P, ZHANG M Y, LIANG J S. RGB1 regulates grain development and starch accumulation through its effect on OsYUC11- mediated auxin biosynthesis in rice endosperm cells. Frontiers in Plant Science, 2021, 12: 585174. doi: 10.3389/fpls.2021.585174
[58]	LI Y, LI T T, HE X R, ZHU Y, FENG Q, YANG X M, ZHOU X H, LI G B, JI Y P, ZHAO J H, ZHAO Z X, PU M, ZHOU S X, ZHANG J W, HUANG Y Y, FAN J, WANG W M. Blocking Osa-miR1871 enhances rice resistance against Magnaporthe oryzae and yield. Plant Biotechnology Journal, 2022, 20(4): 646-659. doi: 10.1111/pbi.v20.4
[59]	崔国庆, 王世明, 马福盈, 汪会, 向朝中, 李云峰, 何光华, 张长伟, 杨正林, 凌英华, 赵芳明. 水稻高秆染色体片段代换系Z1377的鉴定及重要农艺性状QTL定位. 作物学报, 2018, 44(10): 1477-1484. doi: 10.3724/SP.J.1006.2018.01477
	CUI G Q, WANG S M, MA F Y, WANG H, XIANG C Z, LI Y F, HE G H, ZHANG C W, YANG Z L, LING Y H, ZHAO F M. Identification and QTL mapping of important agronomic traits in rice Z1377. Acta Agronomica Sinica, 2018, 44(10): 1477-1484. (in Chinese) doi: 10.3724/SP.J.1006.2018.01477
[60]	YANG X F, ZHAO X L, DAI Z Y, MA F L, MIAO X X, SHI Z Y. OsmiR396/growth regulating factor modulate rice grain size through direct regulation of embryo-specific miR408. Plant Physiology, 2021, 186(1): 519-533. doi: 10.1093/plphys/kiab084 pmid: 33620493

性状 Trait	QTL	染色体 Chr.	临近连锁标记 Near liked- marker	加性效应 Additive effect	贡献率 Var. (%)	P值 P-value
二次枝梗数NSB	qNSB6	6	RM3183	2.32	10.53	0.0106
每穗实粒数GPP	qGPP6	6	RM3183	9.10	5.76	0.0482
粒长GL (mm)	qGL1	1	RM5501	0.12	10.15	0.0317
	qGL3	3	RM6266	0.20	26.67	<.0001
	qGL6	6	RM276	0.10	7.00	0.0199
粒宽GW (mm)	qGW1	1	RM5501	-0.05	9.30	0.0464
粒宽GW (mm)	qGW3	3	RM6266	-0.04	5.90	0.0375
长宽比RLW	qRLW1	1	RM5501	0.16	89.81	<.0001
	qRLW3	3	RM6266	0.11	46.66	<.0001
	qRLW6	6	RM276	0.06	11.25	0.0436
千粒重GWT (g)	qGWT3	3	RM6266	0.43	4.66	0.0403
千粒重GWT (g)	qGWT6	6	RM276	0.41	4.15	0.0430

性状 Trait	粒长GL	粒宽GW	长宽比RLW	二次枝梗数NSB	千粒重GWT	每穗实粒数GPP
粒长GL	1
粒宽GW	-0.062	1
长宽比RLW	0.751**	-0.699**	1
二次枝梗数NSB	0.114	-0.394**	0.345**	1
千粒重GWT	0.220*	0.213*	0.025	-0.128	1
实粒数GPP	0.133	-0.423**	0.380**	0.876**	-0.054	1

性状 Trait	模型Model			代换系 Substitution line
性状 Trait	座位1 Q1	座位2 Q2	座位1×座位2 Q1×Q2	代换系 Substitution line
粒长GL	-(P=0.237)	qGL6-2(P=0.000)	-×qGL6-2(P=0.000)	D1
	qGL3(P=0.000)	qGL6-2(P=0.000)	qGL3×qGL6-2(P=0.000)	D2
	qGL3-2(P=0.000)	qGL6 (P=0.000)	qGL3-2×qGL6 (P=0.000)	D3
粒宽GW	qGW1-3(P=0.000)	-(P=0.134)	qGW1-3×-(P=0.002)	D1
	qGW3(P=0.000)	-(P=0.134)	qGW3×-(P=0.082)	D2
	qGW3-2(P=0.000)	-(P=0.156)	qGW3-2×-(P=0.000)	D3
长宽比RLW	qRLW1-3(P=0.003)	qRLW6-2(P=0.000)	qRLW1-3×qRLW6-2(P=0.000)	D1
	qRLW3(P=0.000)	qRLW6-2(P=0.000)	qRLW3×qRLW6-2(P=0.000)	D2
	qRLW3-2(P=0.000)	qRLW6(P=0.001)	qRLW3-2×qRLW6 (P=0.000)	D3
千粒重GWT	-(P=0.209)	qGWT6-2(P=0.000)	-×qGWT6-2(P=0.000)	D1
	qGWT3-2(P=0.000)	qGWT6-2(P=0.000)	qGWT3-2×qGWT6-2(P=0.000)	D2
	qGWT3-2(P=0.000)	-(P=0.291)	qGWT3-2×-(P=0.002)	D3
穗长PL	-(P=0.574)	-(P=0.235)	-×- (P=0.000)	D1
	qPL3(P=0.000)	-(P=0.235)	qPL3×-(P=0.020)	D2
	qPL3-2(P=0.023)	qPL6-2(P=0.007)	qPL3-2×qPL6-2(P=0.418)	D3
一次枝梗数NPB	qNPB1(P=0.019)	-(P=0.098)	qNPB1×-(P=0.432)	D1
	qNPB3(P=0.000)	-(P=0.098)	qNPB3×-(P=0.001)	D2
	-(P=0.946)	qNPB6-2(P=0.000)	-×qNPB6-2(P=0.706)	D3
二次枝梗数NSB	-(P=0.109)	-(P=0.042)	-×-(P=0.000)	D1
	qNSB3(P=0.000)	-(P=0.042)	qNSB3×-(P=0.000)	D2
	qNSB3-2(P=0.001)	qNSB6-2(P=0.000)	qNSB3-2×qNSB6-2(P=0.000)	D3
每穗实粒数GPP	-(P=0.446)	-(P=0.455)	-×-(P=0.424)	D1
	qGPP3(P=0.026)	-(P=0.455)	qGPP3×-(P=0.239)	D2
	-(P=0.094)	-(P=0.398)	-×-(P=0.863)	D3
