山东夏玉米土壤干旱阈值研究与影响评价

doi:10.3864/j.issn.0578-1752.2020.21.007

摘要/Abstract

摘要：

【目的】确定山东夏玉米土壤水分的适宜阈值范围与干旱胁迫阈值,定量化评估不同程度干旱对夏玉米生长发育和产量形成的影响,从而为提高农业水资源利用效率,缓解干旱胁迫的不利影响等提供依据。【方法】基于水分控制试验结果,确定夏玉米苗期、穗期与花粒期的土壤水分适宜与不适宜阈值范围;以土壤相对湿度驱动WOFOST作物机理模型,明确无旱、轻旱、中旱与重旱的阈值指标;通过设置不同干旱程度与持续天数,完成定量化的干旱影响评价。【结果】（1）夏玉米苗期、穗期与花粒期的土壤水分适宜阈值范围分别为62%—91%、66%—92%与68%—94%,不适宜阈值范围分别为<62%、<66%及<68%;（2）苗期无旱、轻旱、中旱与重旱阈值指标分别为53%、50%、45%与40%,穗期各程度干旱阈值指标分别为58%、48%、43%与37%,花粒期各程度干旱阈值指标分别为57%、52%、49%与45%;（3）苗期干旱对夏玉米总叶重、总茎重与最大叶面积指数的影响最大,穗期与花粒期干旱对总穗重影响最大,其中穗期重旱将导致不能形成最终产量。【结论】确定了夏玉米不同发育期的土壤水分阈值指标,夏玉米穗期与花粒期干旱对于产量形成的影响更为显著。

关键词: 夏玉米, 干旱, 阈值, 土壤湿度

Abstract:

【Objective】This study was aimed to determine the suitable range and the drought stress thresholds of soil water on summer maize in Shandong Province, and to evaluate the effects of different drought degrees on growth and development and yield formation of summer maize quantitatively. So as to provide a basis for improving the utilization efficiency of agricultural water resources and alleviating the adverse impacts of drought stress. 【Method】Based on the data from field experiments, the suitable and unsuitable ranges of soil moisture were determined for the seedling stage, ear stage and grain stage of summer maize. By the model of WOFOST, the drought stress thresholds were analyzed with the relative water content as the driving factor. And the drought effects were assessed quantitatively through different drought degrees and their duration days. 【Result】(1) The suitable ranges of soil water during seedling stage, ear stage and grain stage of summer maize were 62%-91%, 66%-92% and 68%-94%, respectively. And the unsuitable ranges were less than 62%, 66% and 68%, respectively. (2) The thresholds of no drought, light drought, medium drought and severe drought during seedling stage were 53%, 50%, 45% and 40%, respectively. The thresholds of different drought degrees during ear stage were 58%, 48%, 43% and 37%, respectively. The thresholds of different drought degrees during grain stage were 57%, 52%, 49% and 45%, respectively. (3) The drought happened during seedling stage had the greatest effects on the total leaf weight, total stem weight and maximum leaf area index. The drought happened during ear stage and grain stage had the greatest effects on the total ear weight. And the severe drought during ear stage would result in the failure of final yield formation. 【Conclusion】The suitable ranges of soil water and the drought thresholds of summer maize were brought to light in Shandong. The drought happened during ear stage and grain stage of summer maize had more significant impacts on yield formation.

Key words: summer maize, drought, thresholds, soil moisture

董智强,李曼华,李楠,薛晓萍,陈辰,张继波,赵红,侯英雨,潘志华. 山东夏玉米土壤干旱阈值研究与影响评价[J]. 中国农业科学, 2020, 53(21): 4376-4387.

DONG ZhiQiang,LI ManHua,LI Nan,XUE XiaoPing,CHEN Chen,ZHANG JiBo,ZHAO Hong,HOU YingYu,PAN ZhiHua. The Thresholds of Soil Drought and Its Impacts on Summer Maize in Shandong Province[J]. Scientia Agricultura Sinica, 2020, 53(21): 4376-4387.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2020.21.007

https://www.chinaagrisci.com/CN/Y2020/V53/I21/4376

图/表 11

表1

图1

图2

图3

表2

图4

表3

表4

表5

表6

表7

参考文献 56

[1]	山东省统计局, 国家统计局山东调查总队. 山东统计年鉴. 北京: 中国统计出版社, 2017.
	Shandong Provincial Bureau of Statistics, Shandong Survey Team of National Bureau of Statistics. Shandong Statistical Yearbook. Beijing: China Statistics Press, 2017. (in Chinese)
[2]	国家统计局. 中国统计年鉴. 北京: 中国统计出版社, 2017.
	National Bureau of Statistics. China Statistical Yearbook. Beijing: China Statistics Press, 2017. (in Chinese)
[3]	GRAYSON M. Agriculture and drought. Nature, 2013,501(7468):S1. doi: 10.1038/501S1a pmid: 24067757
[4]	国家统计局. 中国统计年鉴. 北京: 中国统计出版社, 2013.
	National Bureau of Statistics. China Statistical Yearbook. Beijing: China Statistics Press, 2013. (in Chinese)
[5]	王丽君. 黄淮海平原夏玉米季干旱、高温的发生特征及对产量的影响[D]. 北京: 中国农业大学, 2018.
	WANG L J. Spatiol-temporal characteristics of drought, heat and its effect on yield for summer maize in Huang-Huai-Hai Plain, China[D]. Beijing: China Agricultural University, 2018. (in Chinese)
[6]	薛昌颖, 马志红, 胡程达. 近40a黄淮海地区夏玉米生长季干旱时空特征分析. 自然灾害学报, 2016,25(2):1-14.
	XUE C Y, MA Z H, HU C D. Spatiotemporal characteristics of drought during summer maize growing season in Huang-Huai-Hai area for recent 40 years. Journal of Natural Disasters, 2016,25(2):1-14. (in Chinese)
[7]	邱玉芳, 张丽娟, 郝甜甜, 张琳霞. 不同程度的干旱对华北夏玉米生物量的影响. 自然灾害学报, 2017,26(1):176-183.
	QIU Y F, ZHANG L J, HAO T T, ZHANG L X. Effects of different degrees of drought on biomass of summer maize in north China. Journal of Natural Disasters, 2017,26(1):176-183. (in Chinese)
[8]	庄严, 梅旭荣, 龚道枝, 郝卫平, 栗雨勤, 柳斌辉, 武雪萍. 华北平原不同基因型夏玉米水分—产量响应关系. 中国农业气象, 2010,31(1):65-68.
	ZHUANG Y, MEI X R, GONG D Z, HAO W P, LI Y Q, LIU B H, WU X P. Yield response of different genotypic maize to water in North China Plain. Chinese Journal of Agrometeorology, 2010,31(1):65-68. (in Chinese)
[9]	万能涵, 杨晓光, 刘志娟, 何斌, 孙爽. 气候变化背景下中国主要作物农业气象灾害时空分布特征(Ⅲ): 华北地区夏玉米干旱. 中国农业气象, 2018,39(4):209-219.
	WAN N H, YANG X G, LIU Z J, HE B, SUN S. Temporal and spatial variations of agro-meteorological disasters of main crops in China in a changing climate (Ⅲ): Drought of summer maize in North China Plain. Chinese Journal of Agrometeorology, 2018,39(4):209-219. (in Chinese)
[10]	孙景生, 肖俊夫, 段爱旺, 张淑敏, 张寄阳. 夏玉米耗水规律及水分胁迫对其生长发育和产量的影响. 玉米科学, 1999(2):46-49, 52.
	SUN J S, XIAO J F, DUAN A W, ZHANG S M, ZHANG J Y. The effect of water consuming law and water stress on growth, development and yield of summer maize. Journal of Maize Sciences, 1999(2):46-49, 52. (in Chinese)
[11]	肖俊夫, 刘战东, 陈玉民. 中国玉米需水量与需水规律研究. 玉米科学, 2008,16(4):21-25.
	XIAO J F, LIU Z D, CHEN Y M. Study on the water requirement and water requirement regulation of maize in China. Journal of Maize Sciences, 2008,16(4):21-25. (in Chinese)
[12]	白莉萍, 隋方功, 孙朝晖, 葛体达, 吕银燕, 周广胜. 土壤水分胁迫对玉米形态发育及产量的影响. 生态学报, 2004,24(7):1556-1560.
	BAI L P, SUI F G, SUN C H, GE T D, LV Y Y, ZHOU G S. Effects of soil water stress on morphological development and yield of maize. Acta Ecologica Sinica, 2004,24(7):1556-1560. (in Chinese)
[13]	纪瑞鹏, 车宇胜, 朱永宁, 梁涛, 冯锐, 于文颖, 张玉书. 干旱对东北春玉米生长发育和产量的影响. 应用生态学报, 2012,23(11):3021-3026.
	JI R P, CHE Y S, ZHU Y N, LIANG T, FENG R, YU W Y, ZHANG Y S. Impacts of drought stress on the growth and development and grain yield of spring maize in Northeast China. Chinese Journal of Applied Ecology, 2012,23(11):3021-3026. (in Chinese)
[14]	马旭凤, 于涛, 汪李宏, 石喜, 郑灵祥, 王密侠, 姚雅琴, 蔡焕杰. 苗期水分亏缺对玉米根系发育及解剖结构的影响. 应用生态学报, 2010,21(7):1731-1736.
	MA X F, YU T, WANG L H, SHI X, ZHENG L X, WANG M X, YAO Y Q, CAI H J. Effects of water deficit at seedling stage on maize root development and anatomical structure. Chinese Journal of Applied Ecology, 2010,21(7):1731-1736. (in Chinese)
[15]	陆伟婷, 于欢, 曹胜男, 陈长青. 近20 年黄淮海地区气候变暖对夏玉米生育进程及产量的影响. 中国农业科学, 2015,48(16):3132-3145.
	LU W T, YU H, CAO S N, CHEN C Q. Effects of climate warming on growth process and yield of summer maize in Huang-Huai-Hai Plain in last 20 years. Scientia Agricultura Sinica, 2015,48(16):3132-3145. (in Chinese)
[16]	齐伟, 张吉旺, 王空军, 刘鹏, 董树亭. 干旱胁迫对不同耐旱性玉米杂交种产量和根系生理特性的影响. 应用生态学报, 2010,21(1):48-52.
	QI W, ZHANG J W, WANG K J, LIU P, DONG S T. Effects of drought stress on the grain yield and root physiological traits of maize varieties with different drought tolerance. Chinese Journal of Applied Ecology, 2010,21(1):48-52. (in Chinese)
[17]	何海军, 寇思荣, 王晓娟. 干旱胁迫对不同株型玉米光合特性及产量性状的影响. 干旱地区农业研究, 2011,29(3):63-66.
	HE H J, KOU S R, WANG X J. Effects of drought stress on photosynthetic characteristics and yield components of different plant types of corn. Agricultural Research in the Arid Areas, 2011,29(3):63-66. (in Chinese)
[18]	李清芳, 马成仓, 尚启亮. 干旱胁迫下硅对玉米光合作用和保护酶的影响. 应用生态学报, 2007,18(3):531-536.
	LI Q F, MA C C, SHANG Q L. Effects of silicon on photosynthesis and antioxidative enzymes of maize under drought stress. Chinese Journal of Applied Ecology, 2007,18(3):531-536. (in Chinese)
[19]	赵丽英, 邓西平, 山仑. 持续干旱及复水对玉米幼苗生理生化指标的影响研究. 中国生态农业学报, 2004,12(3):59-61.
	ZHAO L Y, DENG X P, SHAN L. Effects of progressive drying and rewatering on physiological and biochemical indicators in maize seedlings. Chinese Journal of Eco-Agriculture, 2004,12(3):59-61. (in Chinese)
[20]	陈家宙, 王石, 张丽丽, 吕国安. 玉米对持续干旱的反应及红壤干旱阈值. 中国农业科学, 2007,40(3):532-539.
	CHEN J Z, WANG S, ZHANG L L, LV G A. Response of maize to progressive drought and red soil’s drought threshold. Scientia Agricultura Sinica, 2007,40(3):532-539. (in Chinese)
[21]	SADRAS V O, MILROY S P. Soil-water thresholds for the responses of leaf expansion and gas exchange: A review. Field Crops Research, 1996,47:253-266.
[22]	孟兆江, 卞新民, 刘安能, 庞鸿宾, 王和洲. 调亏灌溉对夏玉米光合生理特性的影响. 水土保持学报, 2006,20(3):182-186.
	MENG Z J, BIAN X M, LIU A N, PANG H B, WANG H Z. Effect of regulated deficit irrigation on physiological and photosynthetic characteristics of summer maize and its optimized combination of agronomic techniques. Journal of Soil and Water Conservation, 2006,20(3):182-186. (in Chinese)
[23]	杨平, 张丽娟, 赵艳霞, 姜蓝齐, 乔赛男, 张晓慧. 黄淮海地区夏玉米干旱风险评估与区划. 中国生态农业学报, 2015,23(1):110-118.
	YANG P, ZHANG L J, ZHAO Y X, JIANG L Q, QIAO S N, ZHANG X H. Risk assessment and zoning of drought for summer maize in the Huang-Huai-Hai region. Chinese Journal of Eco-Agriculture, 2015,23(1):110-118. (in Chinese)
[24]	肖俊夫, 刘战东, 刘祖贵, 南纪琴. 不同时期干旱和干旱程度对夏玉米生长发育及耗水特性的影响. 玉米科学, 2011,19(4):54-58, 64.
	XIAO J F, LIU Z D, LIU Z G, NAN J Q. Effects of drought at different growth stages and different water availabilities on growth and water consumption characteristics of summer maize. Journal of Maize Sciences, 2011,19(4):54-58, 64. (in Chinese)
[25]	麻雪艳, 周广胜. 夏玉米苗期主要生长指标的土壤水分临界点确定方法. 生态学杂志, 2017,36(6):1761-1768.
	MA X Y, ZHOU G S. A method to determine the critical soil moisture of growth indicators of summer maize in seedling stage. Chinese Journal of Ecology, 2017,36(6):1761-1768. (in Chinese)
[26]	薛昌颖, 刘荣花, 马志红. 黄淮海地区夏玉米干旱等级划分. 农业工程学报, 2014,30(16):147-156.
	XUE C Y, LIU R H, MA Z H. Drought grade classification of summer maize in Huang-Huai-Hai area. Transactions of the Chinese Society of Agricultural Engineering, 2014,30(16):147-156. (in Chinese)
[27]	米娜, 张玉书, 蔡福, 高莉莉, 纪瑞鹏, 于文颖, 郭宁. 土壤干旱胁迫对作物影响的模拟研究进展. 生态学杂志, 2016,35(9):2519-2526.
	MI N, ZHANG Y S, CAI F, GAO L L, JI R P, YU W Y, GUO N. Progress in the simulation of drought stress effect on crop production. Chinese Journal of Ecology, 2016,35(9):2519-2526. (in Chinese)
[28]	吴泽新, 王永久, 李曼华, 薛晓萍. 干旱胁迫对鲁西北夏玉米生长发育及产量的影响. 山东农业大学学报(自然科学版), 2015,46(6):817-821.
	WU Z X, WANG Y J, LI M H, XUE X P. The effect of drought stress on the development and yield of summer maize in Northwest Shandong province. Journal of Shandong Agricultural University (Natural Science Edition), 2015,46(6):817-821. (in Chinese)
[29]	刘建栋, 于强, 闵庆文, 李世奎, 毕建杰. 水分胁迫对黄淮海夏玉米农业气候资源利用的影响——Ⅱ. 水分胁迫对区域生产力影响. 资源科学, 2002(3):92-95.
	LIU J D, YU Q, MIN Q W, LI S K, BI J J. Impacts of water stress on agroclimatic resources of summer maize in Huange Huai Hai plain of China: Impact on regional productivity. Resources Science, 2002(3):92-95. (in Chinese)
[30]	徐英, 李曼华, 李辉, 姜鹏. 不同发育期的干旱对华北地区夏玉米生长发育及产量的影响. 气象与环境学报, 2017,33(1):108-112.
	XU Y, LI M H, LI H, JIANG P. Effects of drought on the growth and yield of maize at different stages over the North China plain. Journal of Meteorology and Environment, 2017,33(1):108-112. (in Chinese)
[31]	国家气象局. 农业气象观测规范(上卷). 北京: 气象出版社, 1993.
	State Meteorological Administration. Specifications for Agrometeorological Observation (volume 1). Beijing: Meteorological Press, 1993. (in Chinese)
[32]	马玉平, 孙琳丽, 俄有浩. 黄淮海夏玉米不同发育阶段对旱涝灾害的敏感性. 自然灾害学报, 2015,24(6):90-96.
	MA Y P, SUN L L, E Y H. Sensitivity of summer maize in different developmental stages in Huang-Huai-Hai plain to drought and waterlogging. Journal of Natural Disasters, 2015,24(6):90-96. (in Chinese)
[33]	黄振喜, 王永军, 王空军, 李登海, 赵明, 柳京国, 董树亭, 王洪军, 王军海, 杨京胜. 产量15000 kg⋅ha^-1以上夏玉米关键期间的光合特性. 中国农业科学, 2007,40(9):1898-1906.
	HUANG Z X, WANG Y J, WANG K J, LI D H, ZHAO M, LIU J G, DONG S T, WANG H J, WANG J H, YANG J S. Photosynthetic characteristics during grain filling stage of summer maize hybrids with high yield potential of 15000 kg⋅ha^-1. Scientia Agricultura Sinica, 2007,40(9):1898-1906. (in Chinese)
[34]	DONG Z Q, PAN Z H, AN P L, ZHANG J T, ZHANG J, PAN Y Y, HUANG L, ZHAO H, HAN G L, WU D, WANG J L, FAN D L, GAO L, PAN X B. A quantitative method for risk assessment of agriculture due to climate change. Theoretical and Applied Climatology, 2018,131:653-659.
[35]	曲曼丽. 农业气候实习指导. 北京: 北京农业大学出版社, 1991.
	QU M L. The Practice Guidance of Agricultural Climate. Beijing: Beijing Agricultural University Press, 1991. (in Chinese)
[36]	董智强, 王萌萌, 李鸿怡, 薛晓萍, 潘志华, 侯英雨, 陈辰, 李楠, 李曼华. WOFOST模型对山东省夏玉米发育期与产量模拟的适用性评价. 作物杂志, 2019(5):159-165.
	DONG Z Q, WANG M M, LI H Y, XUE X P, PAN Z H, HOU Y Y, CHEN C, LI N, LI M H. Applicability assessment of WOFOST model of growth and yield of summer maize in Shandong province. Crops, 2019(5):159-165. (in Chinese)
[37]	王锐, 李亚飞, 张丽娟, 王建林, 王志伟. 土壤湿度驱动WOFOST模型及其适应性. 中国农业气象, 2015,36(3):263-271.
	WANG R, LI Y F, ZHANG L J, WANG J L, WANG Z W. WOFOST model based on soil moisture driven and its adaptability. Chinese Journal of Agrometeorology, 2015,36(3):263-271. (in Chinese)
[38]	马玉平, 王石立, 王馥堂. 作物模拟模型在农业气象业务应用中的研究初探. 应用气象学报, 2005,16(3):293-303.
	MA Y P, WANG S L, WANG F T. A preliminary study on the application of crop simulation models in agrometeorological services. Journal of Applied Meteorological Science, 2005,16(3):293-303. (in Chinese)
[39]	PENNING D V F W T, JANSEN D M, TEN B H F M, BAKEMA A. Simulation of Ecophysiological Processes of Growth in Several Annual Crop. Wageningen: Centre for Agricultural Publishing and Documentation, 1989.
[40]	BOOGAARD H L, DIEPEN C A, ROETTER R P, CABRERA J M C A, LAAR H H V. User's Guide for the WOFOST 7.1 Crop Growth Simulation Model and WOFOST Control Center 1.5. DLO Wageningen: Winand Staring Centre, 1998: 1-40.
[41]	杨妍辰, 王建林, 宋迎波. WOFOST作物模型机理及使用介绍. 气象科技进展, 2013,3(5):29-35.
	YANG Y C, WANG J L, SONG Y B. Introduction of WOFOST crop growth simulation model mechanism and its use. Advances in Meteorological Science and Technology, 2013,3(5):29-35. (in Chinese)
[42]	陈思宁, 赵艳霞, 申双和, 黎贞发. 基于PyWOFOST作物模型的东北玉米估产及精度评估. 中国农业科学, 2013,46(14):2880-2893.
	CHEN S N, ZHAO Y X, SHEN S H, LI Z F. Study on maize yield estimation and accuracy assessment based on PyWOFOST crop model in Northeast China. Scientia Agricultura Sinica, 2013,46(14):2880-2893. (in Chinese)
[43]	栾庆祖, 叶彩华, 莫志鸿, 李超. 基于WOFOST模型的玉米干旱损失评估: 以北京为例. 中国农业气象, 2014,35(3):311-316.
	LUAN Q Z, YE C H, MO Z H, LI C. Maize yield loss assessment for drought based on WOFOST model: A case study in Beijing. Chinese Journal of Agrometeorology, 2014,35(3):311-316. (in Chinese)
[44]	武荣盛, 吴瑞芬, 孙小龙, 田磊, 侯琼, 张超, 孙琳丽. 不同程度干旱对春玉米生物量和产量影响的模拟. 生态学杂志, 2015,34(9):2482-2488.
	WU R S, WU R F, SUN X L, TIAN L, HOU Q, ZHANG C, SUN L L. Simulating the impact of drought on spring maize biomass and yield. Chinese Journal of Ecology, 2015,34(9):2482-2488. (in Chinese)
[45]	KUNSTMANN H, JUNG G, WAGNER S, CLOTTEY H. Integration of atmospheric sciences and hydrology for the development of decision support systems in sustainable water management. Physics and Chemistry of the Earth, 2007,33(1):165-174.
[46]	王富强, 王雷, 陈希. 郑州市土壤相对湿度变化特征及影响因素分析. 节水灌溉, 2015(2):8-11.
	WANG F Q, WANG L, CHEN X. Analysis of relative soil moisture variation characteristics and influencing factors in Zhengzhou City. Water Saving Irrigation, 2015(2):8-11. (in Chinese)
[47]	ZHU G F, SHI P J, PU T, HE Y Q, ZHANG T, WANG P Z, PAN M H. Changes of surface soil relative moisture content in Hengduan Mountains, China, during 1992-2010. Quaternary International, 2013,298(7):161-170.
[48]	吴霞, 王培娟, 公衍铎, 杨建莹. 1961—2015年黄淮海平原夏玉米干旱识别及时空特征分析. 农业工程学报, 2019,35(18):189-199.
	WU X, WANG P J, GONG Y D, YANG J Y. Analysis of drought identification and spatio-temporal characteristics for summer corn in Huang-Huai-Hai Plain in year of 1961-2015. Transactions of the Chinese Society of Agricultural Engineering, 2019,35(18):189-199. (in Chinese)
[49]	曹言, 王杰, 李尤亮, 王树鹏, 戚娜. 基于作物水分亏缺指数的云南省夏玉米不同生育期干旱时空特征分析. 灌溉排水学报, 2019,38(8):97-106.
	CAO Y, WANG J, LI Y L, WANG S P, QI N. The spatial and temporal characteristics of drought during summer maize at different growth stages in Yunnan province based on crop water deficit index. Journal of Irrigation and Drainage, 2019,38(8):97-106. (in Chinese)
[50]	刘二华, 周广胜, 周莉. 不同干旱条件下夏玉米全生育期冠层吸收光合有效辐射比的高光谱遥感反演. 应用生态学报, 2019,30(6):2021-2029.
	LIU E H, ZHOU G S, ZHOU L. Fraction of absorbed photosynthetically active radiation over summer maize canopy estimated by hyperspectral remote sensing under different drought conditions. Chinese Journal of Applied Ecology, 2019,30(6):2021-2029. (in Chinese)
[51]	张文丽, 张彤, 吴冬秀, 张岁岐, 山仑. 土壤逐渐干旱下玉米幼苗光合速率与蒸腾速率变化的研究. 中国生态农业学报, 2006,14(2):72-75.
	ZHANG W L, ZHANG T, WU D X, ZHANG S Q, SHAN L. The changes of photosynthetic rate and transpiration rate of maize seedling under soil progressive drought. Chinese Journal of Eco-Agriculture, 2006,14(2):72-75. (in Chinese)
[52]	潘汉雄, 朱国锋, 张昱, 郭慧文, 雍磊磊, 万巧卓, 马惠莹, 李森. 中国耕地土壤相对湿度时空分异. 地理学报, 2019,74(1):117-130.
	PAN H X, ZHU G F, ZHANG Y, GUO H W, YONG L L, WAN Q Z, MA H Y, LI S. Spatial and temporal variations of relative soil moisture in China's farmland. Acta Geographica Sinica, 2019,74(1):117-130. (in Chinese)
[53]	姚永明, 陈玉琪, 张啟祥, 陈若礼. 淮北夏玉米生育期气候资源特点和增产栽培技术. 中国农业气象, 2009,30(S2):205-209.
	YAO Y M, CHEN Y Q, ZHANG Q X, CHEN R L. Climate resources characteristics and the cultivated practice of increase yield of summer corn in the growth period in Huaibei. Chinese Journal of Agrometeorology, 2009,30(S2):205-209. (in Chinese)
[54]	WHITE J W, HOOGENBOOM G, KIMBALL B A, WALL G W. Methodologies for simulating impacts of climate change on crop production. Field Crops Research, 2011,124(3):357-368.
[55]	WANDAKA L M, MARIARA J K, KIMUYU P. Economic impact of climate change on maize production in Kenya. American Journal of Agriculture, 2017,1(1):37-50.
[56]	番聪聪. 黄淮海地区夏玉米干旱灾害风险评估及预估[D]. 南京: 南京信息工程大学, 2018.
	FAN C C. Drought risk assessment and prediction of summer maize in the Huang-Huai-Hai Region[D]. Nanjing: Nanjing University of Information & Technology, 2018. (in Chinese)

年份 Year	生育时期 Growth stage	处理Treatment
年份 Year	生育时期 Growth stage	T1	T2	T3	T4	T5
2013	苗期Seedling stage	>60%	>60%	40%-60%	>60%	自然状态Natural state
	穗期Ear stage	>60%	>60%	>60%	>60%	自然状态Natural state
	花粒期Grain stage	≤40%	40%-60%	40%-60%	>60%	自然状态Natural state
2014	苗期Seedling stage	≤40%	40%-60%	40%-60%	60%-80%	>80%
	穗期Ear stage	>60%	>60%	40%-60%	60%-80%	>80%
	花粒期Grain stage	>60%	>60%	>60%	60%-80%	>80%
2015	苗期Seedling stage	>60%	>60%	>60%	60%-80%	>80%
	穗期Ear stage	≤40%	40%-60%	40%-60%	60%-80%	>80%
	花粒期Grain stage	>60%	>60%	40%-60%	60%-80%	>80%

生育时期 Growth stage	年份 Year	适宜 Suitable threshold	不适宜 Unsuitable threshold
苗期 Seedling stage	2013	62-93	<62
	2014	61-91	<61
	阈值范围 Threshold range	62-91	<62
穗期 Ear stage	2014	66-95	<66
	2015	64-92	<64
	阈值范围 Threshold range	66-92	<66
花粒期 Grain stage	2013	64-95	<64
	2015	68-94	<68
	阈值范围 Threshold range	68-94	<68

生育时期 Growth stage	干旱程度 Degree of drought	阈值指标 Threshold indexes
苗期 Seedling stage	无旱No drought	53
	轻旱Light drought	50
	中旱Medium drought	45
	重旱Severe drought	40
穗期 Ear stage	无旱No drought	58
	轻旱Light drought	48
	中旱Medium drought	43
	重旱Severe drought	37
花粒期 Grain stage	无旱No drought	57
	轻旱Light drought	52
	中旱Medium drought	49
	重旱Severe drought	45

生育时期 Growth period	日序区间 Interval of day of year
苗期Seedling stage	177-196
穗期Ear stage	214-233
花粒期Grain stage	243-262

干旱程度 Drought degree	干旱持续时间 Duration days of drought	TAGP	TWSO	TWLV	TWST	MAXLAI
轻旱 Light drought	3 d	-3.2	-2.9	-3.9	-3.7	-3.0
轻旱 Light drought	5 d	-3.7	-2.9	-5.7	-5.1	-4.4
	10 d	-4.5	-2.7	-8.6	-7.7	-6.9
	15 d	-6.1	-2.7	-13.8	-12.2	-11.3
	20 d	-8.5	-3.0	-20.7	-18.4	-17.6
中旱 Medium drought	3 d	-1.7	0.1	-5.7	-4.8	-3.9
中旱 Medium drought	5 d	-3.0	0.0	-9.6	-8.2	-7.2
	10 d	-5.9	-0.5	-17.7	-15.3	-14.5
	15 d	-10.4	-2.2	-28.5	-25.1	-24.7
	20 d	-17.0	-6.1	-40.8	-36.6	-37.1
重旱 Severe drought	3 d	-2.4	0.0	-7.8	-6.7	-5.5
重旱 Severe drought	5 d	-4.5	-0.2	-14.1	-12.1	-11.1
	10 d	-10.0	-1.9	-27.6	-24.3	-23.9
	15 d	-18.7	-7.2	-43.6	-39.2	-39.7
	20 d	-31.8	-18.8	-60.1	-55.3	-56.8
