葡萄SAP家族的鉴定与表达分析

doi:10.3864/j.issn.0578-1752.2019.14.009

摘要/Abstract

摘要：

【目的】通过生物信息学分析明确SAP（Stress Associated Protein）家族在葡萄基因组中的数量、结构,利用qRT-PCR技术分析SAP家族的生物节律和在激素、非生物胁迫处理下的表达模式,为进一步探究SAP家族在葡萄中的作用奠定基础。【方法】在前期从山葡萄‘双优’（Vitis amurensis cv. Shuangyou）和欧洲葡萄‘红地球’（Vitis vinifera cv. Red Globe）0℃寒胁迫下转录组数据库中筛选出表达量明显上调的基因SAP15基础上,利用NCBI和葡萄基因组数据库中的BLAST功能,根据SAP家族的保守结构域,鉴定葡萄基因组中的SAP。利用生物信息学软件DNAMAN5.0、MEME、GSDS2.0、ExPASy和MEGA6等对VvSAPs序列、基因结构、蛋白质结构、理化性质、染色体定位和进化树等进行分析。采用qRT-PCR方法检测VvSAP家族的生物节律和在激素、逆境处理下的表达特征。【结果】从葡萄（Vitis vinifera）全基因组中鉴定得到15个SAP家族成员,均含有AN1保守结构域,大多含有A20保守结构域。按照其保守结构域和在染色体上的位置,依次命名为VvSAP1—VvSAP15,可分为Class Ⅰ、Class Ⅱ和Class Ⅲ三类。理化性质分析表明,VvSAP家族编码氨基酸数目介于109—293,理论等电点分布在7.99—9.68。染色体定位分析发现,该基因家族的15个基因分布于葡萄的9条染色体上,其中第8条染色体上分布最多,有3个VvSAP。亚细胞定位分析表明,VvSAP家族主要在细胞核、叶绿体和细胞骨架中进行表达。VvSAP家族的二级结构主要以无规则卷曲和α-螺旋为主。基因结构分析表明,VvSAP1—VvSAP12的DNA序列中均无内含子,VvSAP13—VvSAP15的DNA序列中有1个内含子,基因结构高度保守。qRT-PCR分析结果表明,在VvSAP家族成员中,VvSAP1和VvSAP9在无处理和各处理下（激素和非生物胁迫）均表达极低或不表达,初步鉴定为假基因。除VvSAP10在400 mmol·L ^-1 NaCl处理下呈下调表达,其余基因均在50 μmol·L ^-1 ABA、100 μmol·L ^-1SA和400 mmol·L ^-1NaCl处理下呈上调表达,其中,VvSAP10—VvSAP14显著响应50 μmol·L ^-1 ABA胁迫,处理24 h后相对表达量分别上调为0 h的37.19、36.63、21.69、58.34和267.35倍;VvSAP8和VvSAP11在NaCl处理4 h后相对表达量最高,分别为0 h的13.16和12.42倍;在4℃低温胁迫下,相对表达量上调最高的是VvSAP15,处理后8 h相对表达量为0 h的35.90倍。【结论】从葡萄基因组中共鉴定出15个SAP家族成员,初步鉴定得出VvSAP1和VvSAP9为假基因,15个基因分别分布于9条染色体上,并且结构进化高度保守。所有成员均相响应逆境,且均有昼夜节律变化,但该基因家族成员在不同逆境胁迫下的响应程度和在不同时间点的表达模式存在一定的差异。

关键词: 葡萄, SAP家族, 生物节律, 激素, 非生物胁迫, 表达分析

Abstract:

【Objective】The aim of this paper was to identify the Stress Associated Protein (SAP) family genes of grape (Vitis vinifera L.) genome and to know the profile of SAP family regarding the number and structure of genes. The biological rhythm of SAP family and its expression pattern under different hormones and abiotic stress were analyzed by qRT-PCR. The study would provide theoretical basis for further exploring the roles of SAP family genes in grapevine. 【Method】SAP15, a gene selected from the transcriptome database of Vitis amurensis cv. ‘Shuangyou’ and Vitis vinifera cv. ‘Red Globe’, had a significantly up-regulated expression under the cold treatment. According to the conserved structural domains, the SAPs in grape genome-wide were identified by BLAST of NCBI and grape genome database. DNAMAN5.0, MEME, GSDS2.0, ExPASy and MEGA6 software were used for various bioinformatics analysis of VvSAPs, including the study of nucleotide sequences, gene structure, protein structure, physical and chemical properties, chromosome localization and phylogeny. Quantitative real-time PCR (qRT-PCR) was employed to detect the circadian rhythm of VvSAPs and their relative expression levels under hormone and abiotic stress.【Result】In total, 15 SAPs with conservative domains of AN1 were identified from grape genome and most of them contained A20 conservative domain. They could be classified into Class Ⅰ, Class Ⅱ and Class Ⅲ based on their conservative structure domain and the location on chromosome in grape. Analysis of physical and chemical properties of VvSAP family showed that the numbers of amino acids were between 109 and 293, and the theoretical equivalence points were between 7.99 and 9.68. Localization of genes on the chromosome revealed that 15 VvSAPs were distributed on 9 chromosomes of the grape, and there were 3 SAPs on chromosome 8. By the sub-cellular location analysis, we noticed that VvSAPs were mainly expressed in nucleus, chloroplast and cytoskeleton in grape. The secondary structure of VvSAP were mainly irregular crimp and α-helix. The gene structures were highly conserved, and VvSAP1-VvSAP12 had no intron, while VvSAP13-VvSAP15 contained one intron. The results of qRT-PCR analysis showed that VvSAP1 and VvSAP9 had extremely low expression or no expression under hormone and abiotic treatment, so they were preliminarily identified as pseudogenes. While VvSAP10 was proved to be down-regulated under 400 mmol·L ^-1NaCl treatment, the remaining genes were up-regulated under 50 μmol·L ^-1 ABA, 100 μmol·L ^-1SA and 400 mmol·L ^-1NaCl treatment, respectively. VvSAP10-VvSAP14 were highly responsive to 50 μmol·L ^-1ABA treatment, and their relative expressions were improved by 37.19, 36.63, 21.69, 58.34 and 267.35 times, respectively, after 24 hours treatment. After 4 hours under NaCl treatment, VvSAP8 and VvSAP11 had the highest relative expression level, which were 13.16 and 12.42 times higher than those without NaCl treatment, respectively. The VvSAP15 had the highest response towards 4℃ treatment, and its relative expression level was 35.90 times after 8 hours treatment comparing to the 0 hour.【Conclusion】15 VvSAPs family were identified from the grape genome, of which VvSAP1 and VvSAP9 were preliminarily identified as pseudogenes. These members were localized across 9 chromosomes of the grape, and the evolution of VvSAP was highly conservative. All members of VvSAP family responded to adversity and had circadian rhythm, However, the expression pattern of VvSAPs was varied under different stress.

Key words: grape, SAP family, circadian rhythm, hormone, abiotic stress, expression analysis

丁兰,顾宝,李培楹,舒欣,张剑侠. 葡萄SAP家族的鉴定与表达分析[J]. 中国农业科学, 2019, 52(14): 2500-2514.

DING Lan,GU Bao,LI PeiYing,SHU Xin,ZHANG JianXia. Genome-Wide Identification and Expression Analysis of SAP Family in Grape[J]. Scientia Agricultura Sinica, 2019, 52(14): 2500-2514.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2019.14.009

https://www.chinaagrisci.com/CN/Y2019/V52/I14/2500

图/表 10

表1

图1

表2

表3

表4

图2

图3

图4

图5

图6

参考文献 39

[1]	贺普超 . 葡萄学. 北京: 中国农业出版社, 1999: 60-61.
	HE P C. Enology. Beijing: China Agriculture Press, 1999: 60-61. (in Chinese)
[2]	康天兰, 郑平生, 王艳玲, . 甘肃葡萄栽培的历史、现状与未来发展趋势. 中外葡萄与葡萄酒, 2009(5):77-79.
	KANG T L, ZHENG P S, WANG Y L . History, present situation and future progress of viticulture in Gansu.Chinese and Foreign Grapes and Wine, 2009(5):77-79. (in Chinese)
[3]	何红红, 马宗桓, 张元霞, 张娟, 卢世雄, 张志强, 赵鑫, 吴玉霞, 毛娟 . 葡萄LBD基因家族的鉴定与表达分析. 中国农业科学, 2018,51(21):4102-4118.
	HE H H, MA Z H, ZHANG Y X, ZHANG J, LU S X, ZHANG Z Q, ZHAO X, WU Y X, MAO J . Identification and expression analysis of LBD gene family in grape. Scientia Agricultura Sinica, 2018,51(21):4102-4118. (in Chinese)
[4]	丁林云, 张微, 王晋成, 田亮亮, 李妮娜, 郭琪, 杨淑明, 何曼林, 郭旺珍 . 过量表达棉花GhSAP1提高转基因烟草的耐盐性. 中国农业科学, 2014,47(8):1458-1470. doi: 10.3864/j.issn.0578-1752.2014.08.002
	DING L Y, ZHANG W, WANG J C, TIAN L L, LI N N, GUO Q, YANG S M, HE M L, GUO W Z . Overexpression of a Gossypium hirsutum stress-associated protein gene( GhSAP1) improves salt stress tolerance in transgenic tobacco. Scientia Agricultura Sinica, 2014,47(8):1458-1470. (in Chinese) doi: 10.3864/j.issn.0578-1752.2014.08.002
[5]	OPIPARI A W, BOGUSKI M S, DIXIT V M . The A20 cDNA induced by tumor necrosis factor α encodes a novel type of zinc finger protein. The Journal of Biological Chemistry, 1990,265(25):14705-14708.
[6]	HEYNINCK K, BEYAERT R . A20 inhibits NF-kB activation by dual ubiquitin-editing functions. Trends in Biochemical Sciences, 2005,30(1):1-4. doi: 10.1016/j.tibs.2004.11.001
[7]	HUANG J, TENG L, LI L X, LIU T, LI L Y, CHEN D Y, XU L G, ZHAI Z H, SHU H B . ZNF216 is an A20-like and IkB kinase γ-interacting inhibitor of NFκB activation. The Journal of Biological Chemistry, 2004,279(16):16847-16853. doi: 10.1074/jbc.M309491200
[8]	DANSANA P K, KOTHARI K S, VIJ S, TYAGI A K . OsiSAP1 overexpression improves water-deficit stress tolerance in transgenic rice by affecting expression of endogenous stress-related genes. Plant Cell Reports, 2014,33(9):1425-1440.
[9]	DIXIT A, TOMAR P, VAINE E, ABDULLAH H, HAZEN S, DHANKHER O P . A stress-associated protein, AtSAP13, from Arabidopsis thaliana provides tolerance to multiple abiotic stresses. Plant, Cell & Environment, 2018,41(5):1171-1185.
[10]	SOLANKE A U, SHARMA M K, TYAGI A K, SHARMA A K . Characterization and phylogenetic analysis of environmental stress- responsive SAP gene family encoding A20/AN1 zinc finger proteins in tomato. Molecular Genetics and Genomics, 2009,282(2):153-164.
[11]	李晓君, 蔡文伟, 张树珍, 许莉萍, 陈萍, 王俊刚 . 甘蔗锌指蛋白基因ShSAP1的克隆与表达模式. 生物工程学报, 2011,27(6):868-875.
	LI X J, CAI W W, ZANG S Z, XU L P, CHEN P, WANG J G . Cloning and expression pattern of a zinc finger protein gene ShSAP1 in Saccharum officinarum. Chinese Journal of Biotechnology, 2011,27(6):868-875. (in Chinese)
[12]	SREEDHARAN S, SHEKHAWAT U K, GANAPATHI T R . MusaSAP1, a A20/AN1 zinc finger gene from banana functions as a positive regulator in different stress responses. Plant Molecular Biology, 2012,80(4/5):503-517.
[13]	LIU J Y, YANG X N, YANG X Z, XU M Y, LIU J, XUE M M, MA P D . Isolation and characterization of LcSAP, a Leymus chinensis gene which enhances the salinity tolerance of Saccharomyces cerevisiae. Molecular Biology Reports, 2017,44(1):5-9.
[14]	SHARMA G, GIRI J, TYAGI A K . Rice OsiSAP7 negatively regulates ABA stress signalling and imparts sensitivity to water-deficit stress in Arabidopsis. Plant Science, 2015,237:80-92.
[15]	KANNEGANTI V, GUPTA A K . Overexpression of OsiSAP8, a member of stress associated protein (SAP) gene family of rice confers tolerance to salt, drought and cold stress in transgenic tobacco and rice. Plant Molecular Biology, 2008,66(5):445-462.
[16]	WANG Y H, ZHANG L R, ZHANG L L, XING T, PENG J Z, SUN S L, CHEN G, WANG X J . A novel stress-associated protein SbSAP14 from Sorghum bicolor confers tolerance to salt stress in transgenic rice. Molecular Breeding, 2013,32(2):437-449.
[17]	GHNEIM T, SELVARAJ M G, MEYNARD D, FABRE D, PENA A, BEN ROMDHANE W, BEN S R, OGAWA S, REBOLLEDO M C, ISHITANI M, TOHME J, AL-DOSS A, GUIDERDONI E, HASSAIRI A . Expression of the Aeluropus littoralis AlSAP gene enhances rice yield under field drought at the reproductive stage. Frontiers in Plant Science, 2017,8:994.
[18]	ZHANG Z B, ZHANG J W, CHEN Y J, LI R F, WANG H Z, WEI J H . Genome-wide analysis and identification of HAK potassium transporter gene family in maize( Zea mays L.). Molecular Biology Reports, 2012,39(8):8465-8473.
[19]	HORTON P, PARK K J, OBAYASHI T, FUJITA N, HARADA H, ADAMS-COLLIER C J, NAKAI K . WoLF PSORT: Protein localization predictor. Nucleic Acids Research, 2007,35:W585-587. doi: 10.1093/nar/gkm259
[20]	YU D D, ZHANG L H, ZHAO K, NIU R X, ZHAI H, ZHANG J X . VaERD15, a transcription factor gene associated with cold-tolerance in Chinese wild Vitis amurensis. Frontiers in Plant Science, 2017,8(e63064):297.
[21]	陈代, 李德美, 战吉宬, 黄卫东 . 温度和日照时间对河北怀来霞多丽葡萄成熟度指标的影响. 中国农业科学, 2011,44(3):545-551.
	CHEN D, LI D M, ZHAN J C, HUANG W D . Temperature and duration of sunshine on maturity indices of chardonnay in Huailai county of Hebei province. Scientia Agricultura Sinica, 2011,44(3):545-551. (in Chinese)
[22]	刘辉, 李德军 . 植物应答低温胁迫的转录调控网络研究进展. 中国农业科学, 2014,47(18):3523-3533. doi: 10.3864/j.issn.0578-1752.2014.18.001
	LIU H, LI D J . Advances in research of transcriptional regulatory network in response to cold stress in plants. Scientia Agricultura Sinica, 2014,47(18):3523-3533. (in Chinese) doi: 10.3864/j.issn.0578-1752.2014.18.001
[23]	XU W R, JIAO Y T, LI R M, ZHANG N B, XIAO D M, DING X L, WANG Z P . Chinese wild-growing Vitis amurensis ICE1 and ICE2 encode MYC-type bHLH transcription activators that regulate cold tolerance in Arabidopsis. PLoS ONE, 2014,9(7):e102303.
[24]	YIN X J, HUANG L, ZHANG X M, GUO C L, WANG H, LI Z, WANG X P . Expression patterns and promoter characteristics of the Vitis quinquangularis VqSTS36 gene involved in abiotic and biotic stress response. Protoplasma, 2017,254(6):2247-2261.
[25]	秦玲, 康文怀, 齐艳玲, 蔡爱军 . 盐胁迫对酿酒葡萄叶片细胞结构及光合特性的影响. 中国农业科学, 2012,45(20):4233-4241. doi: 10.3864/j.issn.0578-1752.2012.20.013
	QIN L, KANG W H, QI Y L, CAI A J . Effects of salt stress on mesophyll cell structures and photosynthetic characteristics in leaves of wine grape (Vitis spp.). Scientia Agricultura Sinica, 2012,45(20):4233-4241. (in Chinese) doi: 10.3864/j.issn.0578-1752.2012.20.013
[26]	LINNEN J M, BAILEY C P, WEEKS D L . Two related localized mRNAs from Xenopus laevis encode ubiquitin-like fusion proteins. Gene, 1993,128(2):181-188.
[27]	DUAN W, SUN B G, LI T W, TAN B J, LEE M K, TEO T S . Cloning and characterization of AWP1, a novel protein that associates with serine/threonine kinase PRK1 in vivo. Gene, 2000,256(1/2):113-121.
[28]	EVANS P C, OVAA H, HAMON M, KILSHAW P E, HAMM S, BAUER S, PLOEGH H L, SMITH T S . Zinc-finger protein A20, a regulator of inflammation and cell survival, has de-ubiquitinating activity. Biochemical Journal, 2004,378(Pt 3):727-734. doi: 10.1042/bj20031377
[29]	CHEN Z J . Ubiquitin signaling in the NF-κB pathway. Nature Cell Biology, 2005,7(8):758-765. doi: 10.1038/ncb0805-758
[30]	HISHIYA A, IEMURA S, NATSUME T, TAKAYAMA S, IKEDA K, WATANABE K . A novel ubiquitin-binding protein ZNF216 functioning in muscle atrophy. The EMBO Journal, 2006,25(3):554-564. doi: 10.1038/sj.emboj.7600945
[31]	VIJ S, TYAGI A K . Genome-wide analysis of the stress associated protein (SAP) gene family containing A20/AN1 zinc-finger(s) in rice and their phylogenetic relationship with Arabidopsis. Molecular Genetics and Genomics, 2006,276(6):565-575.
[32]	JIA H X, LI J B, ZHANG J, REN Y Q, HU J J, LU M Z . Genome-wide survey and expression analysis of the stress-associated protein gene family in desert poplar, Populus euphratica. Tree Genetics & Genomes, 2016,12(4):78.
[33]	CANNON S B, MITRA A, BAUMGARTEN A, YOUNG N D, MAY G . The roles of segmental and tandem gene duplication in the evolution of large gene families in Arabidopsis thaliana. BMC Plant Biology, 2004,4(1):10.
[34]	WANG G, LOVATO A, POLVERARI A, WANG M, LIANG Y H, MA Y C, CHENG Z M . Genome-wide identification and analysis of mitogen activated protein kinase kinase kinase gene family in grapevine (Vitis vinifera). BMC Plant Biology, 2014,14(1):219.
[35]	HU W, HOU X W, HUANG C, YAN Y, TIE W W, DING Z H, WEI Y X, LIU J H, MIAO H X, LU Z W, LI M Y, XU B Y, JIN Z Q . Genome-wide identification and expression analyses of aquaporin gene family during development and abiotic stress in banana . International Journal of Molecular Sciences, 2015,16(8):19728-19751. doi: 10.3390/ijms160819728
[36]	GIRI J, DANSANA P K, KOTHARI K S, SHARMA G, VIJ S, TYAGI A K . SAPs as novel regulators of abiotic stress response in plants. BioEssays, 2013,35(7):639-648. doi: 10.1002/bies.201200181
[37]	JEFFARES D C, PENKETT C J, BÄHLER J . Rapidly regulated genes are intron poor. Trends in Genetics, 2008,24(8):375-378. doi: 10.1016/j.tig.2008.05.006
[38]	KAMAKSHI S K, PRASANT K D, JITENDER G, AKHILESH K T . Rice stress associated protein 1 (OsSAP1) interacts with aminotransferase (OsAMTR1) and pathogenesis-related 1a protein (OsSCP) and regulates abiotic stress responses. Frontiers in Plant Science, 2016,7(18):1057.
[39]	STROHER E, WANG X J, ROLOFF N, KLEIN P, HUSEMANN A, DIETZ K J . Redox-dependent regulation of the stress-induced zinc-finger protein SAP12 in Arabidopsis thaliana. Molecular Plant, 2009,2(2):357-367.

基因Gene	上游引物（5′-3′）Forward primer（5′-3′）	下游引物（5′-3′） Reverse primer（5′-3′）
VvSAP1	TCCACGAAGAAGTCGGAGCA	GCAAACGATGCTTCCCACAG
VvSAP2	TGAGCTGCAACAAGAAGGTG	TCAGCCTTAACCACCGGATT
VvSAP3	ATTGTCGATGCGGTCACCTT	CCTTGACAACAGGGTTGGCT
VvSAP4	CTGCAATTCTCTGCGCCAAT	CTTCCTCGATTCCCGAACC
VvSAP5	GCGGCCAATGAAATCACTGTT	ACAGAACGTGATCCCACACC
VvSAP6	AGTCCAAGGTCAAGGAGGGA	TGCAGCAGTCCGGTAATCAA
VvSAP7	TTCTGCGCTGAGCATCGGTA	CAGACTCTCACGATCTTCGCA
VvSAP8	TTGTGCTTCACCAAGCGAGA	CGGTCCTGTAGTCGAATGGG
VvSAP9	GGTGTGGGAGTATGTTCT	CATAACCTTCCTGGTAACTTC
VvSAP10	TTGTTACCTCCATGACTCAATTATC	ACATACTTCCACATCGGCACTT
VvSAP11	CATGAGCTGCAACAAGAAGG	AGCCTTAACCACCGGATTAG
VvSAP12	CCGAAACTCTAACCCTATGCG	TTCACCTCCCTCCTTCTCACA
VvSAP13	GAGGGAGGTGAACTGGTGCT	GTCCTGCCGCCTTGTAATCG
VvSAP14	GATGGAGTGGGACAGAGCAG	CTTACAGCAGCTCGGTTGGA
VvSAP15	ACTGCGACCCGTCAAAGAAA	AACCGATGCTTGAGGCAGAA

基因 Gene	基因号 Gene ID	氨基酸数 Amino acid number	等电点 Theoretical pI	分子量 Molecular weight (Da)	不稳定指数 Instability index	脂溶指数 Aliphatic index	总平均疏水指数 Average of hydropathicity (GRAVY)
VvSAP1	LOC100266326	152	9.10	17119.98	33.30	55.52	-0.600
VvSAP2	LOC100259845	172	8.77	18460.83	46.68	46.05	-0.494
VvSAP3	LOC100267237	172	7.99	18502.95	27.15	56.80	-0.500
VvSAP4	LOC100242410	141	8.28	15277.21	36.57	54.75	-0.509
VvSAP5	LOC100264822	161	8.92	17192.68	49.44	66.21	-0.300
VvSAP6	LOC100243583	172	7.99	18153.57	30.43	68.72	-0.327
VvSAP7	LOC100852428	172	8.95	18359.69	32.98	57.50	-0.486
VvSAP8	LOC100852460	172	8.22	18504.11	46.99	61.40	-0.371
VvSAP9	LOC100265156	153	9.10	17153.98	38.56	50.39	-0.699
VvSAP10	LOC100265151	152	8.77	16850.54	21.92	58.36	-0.558
VvSAP11	LOC100852756	109	9.23	11757.33	54.13	43.85	-0.471
VvSAP12	LOC100251836	126	9.13	14293.29	54.43	53.41	-0.901
VvSAP13	LOC10085429	126	9.68	14575.89	41.04	53.41	-0.904
VvSAP14	LOC100255506	293	8.56	32457.78	40.16	58.84	-0.614
VvSAP15	LOC100245574	189	8.74	21133.11	49.61	47.99	-0.800

基因 Gene	细胞核 Nucleus	叶绿体 Chloroplast	细胞外 Extracellular	细胞骨架 Cytoskeleton	线粒体 Mitochondria	过氧化物酶体 Peroxisome	细胞质和细胞核 Cyto_nucl	质膜 Plasma membrane
VvSAP1	6	4	2	1	1	-	-	-
VvSAP2	8	1	2	1	2	-	-	-
VvSAP3	9	1	-	4	-	-	-	-
VvSAP4	3	10	-	1	-	-	-	-
VvSAP5	4	3	-	3	4	-	-	-
VvSAP6	5	4	2	3	-	-	-	-
VvSAP7	4	6	1	1	2	-	-	-
VvSAP8	8	2	1	3	-	-	-	-
VvSAP9	2.5	4	-	1.5	-	6	2.5	-
VvSAP10	2.5	3	-	2.5	-	6	3	-
VvSAP11	4	2	2	3	3	-	-	-
VvSAP12	5	6	1	1	1	-	-	-
VvSAP13	8	2	1	1	1	-	-	1
VvSAP14	14	-	-	-	-	-	-	-
VvSAP15	13	-	-	-	-	-	-	1

蛋白名称 Protein name	α-螺旋 Alpha helix (%)	拓展链结构 Extended strand (%)	β-转角 Beta turn (%)	无规则卷曲 Random coil (%)
VvSAP1	30.26	11.18	4.61	53.95
VvSAP2	26.74	11.05	2.91	59.30
VvSAP3	31.40	12.21	3.49	52.91
VvSAP4	29.79	12.77	3.55	53.90
VvSAP5	25.47	10.56	4.35	59.63
VvSAP6	29.65	11.05	3.49	55.81
VvSAP7	23.84	12.21	4.07	59.88
VvSAP8	23.84	12.79	5.23	58.14
VvSAP9	23.53	11.11	5.23	60.13
VvSAP10	34.87	11.84	3.29	50.00
VvSAP11	15.60	23.85	10.09	50.46
VvSAP12	17.46	20.63	3.97	57.94
VvSAP13	27.78	17.46	7.14	47.62
VvSAP14	24.91	10.92	2.05	62.12
VvSAP15	11.11	11.11	4.76	73.02
