长期不同施肥下紫色土-作物体系镉累积及安全性评估

doi:10.3864/j.issn.0578-1752.2018.18.010

摘要/Abstract

摘要：

【目的】利用连续施肥23年（1991—2014）的稻麦长期定位试验,研究长期不同施肥对土壤-小麦/水稻轮作体系镉（Cd）累积的影响,为西南紫色土地区农产品质量安全和合理施肥提供科学依据。【方法】利用8个长期不同施肥处理：（1） CK（不施肥对照）;（2）N（只施氮肥）;（3）NK（只施氮、钾肥）;（4）NPK（施氮、磷、钾肥）;（5）NPK+M（化肥+猪、牛粪）;(6) NPK+S（化肥+稻草还田）;（7）1.5NPK+S（1.5倍化肥+稻草还田）;（8）(NK)_ClP+S（含氯化肥+稻草还田）。分别测定不同年际间土壤中全镉和有效镉含量以及作物中的镉含量,并评估镉的累积程度。【结果】随着施肥年限的增加,土壤全镉含量逐年提高;长期不施磷肥的CK、N、和NK处理土壤全镉累积提升较慢,施用磷肥、有机肥及含氯化肥处理提升较快,其中以NPK+M、1.5NPK+S和(NK)_ClP+S 处理土壤全镉含量提升最快,23年后分别增加了1.18、1.18、1.15 mg·kg^-1;除不施磷肥处理外,其他所有处理土壤全镉含量均超过土壤环境质量农用地土壤污染风险管控标准（GB15618—2018）中的土壤镉污染风险筛选值0.6 mg·kg^-1。长期施肥处理的土壤有效镉含量均明显高于不施肥对照,其中长期施用N、(NK)_ClP+S和1.5NPK+S处理土壤有效镉含量提升幅度较大。随着试验年份的增加各施肥处理水稻籽粒中镉含量呈上升趋势,但均未超过食品安全国家标准（GB 2762—2017,Cd≤0.2 mg·kg^-1）;小麦籽粒中镉含量在不同年际间没有明显变化,除长期施用含氯化肥(NK)_ClP+S处理籽粒中镉含量超过食品中污染物限量标准外（GB 2762—2017,Cd≤0.1 mg·kg^-1）,其他处理均未超标。【结论】本试验条件下,长期不同施肥、特别是施用磷肥和猪、牛粪有机肥均提高了土壤全镉含量,增加了其生态风险;而长期施用含氯化肥因使土壤pH下降而提高了有效镉含量,并导致小麦籽粒中镉含量超标。因此,防止镉因施肥等途径进入农田,是保证农产品安全生产的重要环节。

关键词: 长期施肥, 紫色土, 小麦, 水稻, 镉累积

Abstract:

【Objective】 This study focused on cadmium (Cd) accumulation in soil and availability in crop induced by 23 years (1997-2013) fertilization to evaluate the extent of soil Cd contamination and the safety threshold, so that which could offer suggestions to the fertilization strategy and soil Cd safety standard of Southwest China. 【Method】 Eight fertilization treatments were employed, including only nitrogen (N), nitrogen and potassium (NK), nitrogen plus phosphorus and potassium (NPK), chemical fertilizer plus pig manure (NPK+M), chemical fertilizer plus rice straw (NPK+S), 1.5 times chemical fertilizer plus rice straw (1.5NPK+S), chloride-based fertilizers plus rice straw ((NK)_ClP+S), as well as no fertilizer control (CK). Soil available Cd, soil total Cd concentration and Cd uptake by crop among different years were measured to evaluate the Cd accumulation. 【Result】 The results showed that the soil total Cd increased with the extension of fertilization time, the total Cd accumulation in soil treated with CK, N and NK for a long time without phosphorus fertilizer increased slowly, the total Cd accumulation in soil treated with phosphate fertilizer, organic fertilizer and chlorinated fertilizer increased rapidly, and NPK+M, 1.5NPK+S and (NK)_ClP+S had more accumulation, increasing 1.18, 1.18 and 1.15 mg·kg^-1 after 23 years fertilization, respectively. Except for without phosphate fertilizer treatments, the total Cd accumulation of all the other soils above 0.6 mg·kg^-1 had the soil environmental quality risk control standard for soil contamination of agricultural land. The soil available Cd was significantly higher under all fertilization treatments than that under CK, thereinto, the content of soil available Cd increased significantly with long-term application of N, (NK)_ClP+S and 1.5NPK+S. The Cd concentration in rice grain was all raised with the increasing of fertilization time, while it didn’t exceed the national food safety standard of China (Cd≤0.2 mg·kg^-1). There were no obvious changes of wheat grain Cd concentration among different years, but only the Cd concentration in grain of (NK)_ClP+S treatment exceeded the pollutant limit standards of food of China (Cd≤0.1 mg·kg^-1). 【Conclusion】 Under the conditions of this experiment, long-term different fertilization, especially the application of phosphate fertilizer and swine manure organic manure, increased the soil total Cd content and increased the ecological risk; The long-term application of chlorinated fertilizers increased the soil available Cd content because of the decrease of soil pH, and reduced the Cd content in wheat grains. Therefore, preventing Cd from entering farmland by fertilization is an important link to ensure the safe production of agricultural products.

Key words: long-term fertilization, purple soil, wheat, rice, Cd accumulation

王珂, 徐春丽, 张宇亭, 郑志斌, 王定勇, 石孝均. 长期不同施肥下紫色土-作物体系镉累积及安全性评估[J]. 中国农业科学, 2018, 51(18): 3542-3550.

Ke WANG, ChunLi XU, YuTing ZHANG, ZhiBin ZHENG, DingYong WANG, XiaoJun SHI. Cd Accumulation and Safety Assessment of Soil-Crop System Induced by Long-Term Different Fertilization[J]. Scientia Agricultura Sinica, 2018, 51(18): 3542-3550.

图/表 6

图1

图2

图3

表1

图4

表2

参考文献 38

[1]	XU W H, LI Y R, HE J P, MA Q F, ZHANG X J, CHEN G Q, WANG H X, ZHANG H B.Cd uptake in rice cultivars treated with organic acids and EDTA. Journal of Environmental Sciences, 2010, 22(3): 441-447. doi: 10.1016/S1001-0742(09)60127-3
[2]	SATARUG S, BAKER J R, URBENJAPOL S,HASWELL-ELKINS M, REILLY P E B, WILLIAMS D J, MOORE M R. A global perspective on cadmium pollution and toxicity in non-occupationally exposed population. Toxicology Letters, 2003, 137(1/2): 65-83. doi: 10.1016/S0378-4274(02)00381-8 pmid: 12505433
[3]	WEI S H, ZHOU Q X.Phytoremediation of cadmium-contaminated soils by Rorippa globosa using two-phase planting. Environmental Science and Pollution Research, 2006, 13(3): 151-155. doi: 10.1065/espr2005.06.269 pmid: 16758704
[4]	MAPANDA F, MANGWAYANA E N, NYAMANGARA J, GILLER K E.The effect of long-term irrigation using wastewater on heavy metal contents of soils under vegetables in Harare, Zimbabwe. Agriculture Ecosystems and Environment, 2005, 107(2/3): 151-165. doi: 10.1016/j.agee.2004.11.005
[5]	WANG Y Q, XIAO L Z, LI S Y, GUO Y, CAI X D.Effects of combined pollution of Pb and Cd on growth and yield of rice. Agricultural Science and Technology, 2010, 11(5): 168-170.
[6]	朱志勇, 李友军, 郝玉芬, 蒋瑞婕, 刘晓红, 刘露露, 张晓雯. 镉对小麦(Triticum aestivum)干物质积累、转移及籽粒产量的影响. 农业环境科学学报, 2012, 31(2): 252-258.
	ZHU Z Y, LI Y J, HAO Y F, JIANG R J, LIU X H, LIU L L, ZHANG X W.Effects of Cd on accumulations and translocation of biomasses and yield of different wheat (Triticum aestivum) cultivars. Journal of Agro-Environment Science, 2012, 31(2): 252-258. (in Chinese)
[7]	卢鑫, 胡文友, 黄标, 李元, 祖艳群, 湛方栋, 邝荣禧. 基于UNMIX模型的矿区周边农田土壤重金属源解析. 环境科学, 2018(3): 1-18.
	LU X, HU W Y, HUANG B, LI Y, ZU Y Q, ZHAN F D, KUANG R X.Source apportionment of soil heavy metals in farmland soils around mining area based on UNMIX model. Environment Science, 2018(3): 1-18. (in Chinese)
[8]	董騄睿,胡文友, 黄标, 刘刚, 瞿明凯, 邝荣禧. 基于正定矩阵因子分析模型的城郊农田土壤重金属源解析. 中国环境科学, 2015, 35(7): 2103-2111. doi: 10.3969/j.issn.1000-6923.2015.07.031
	DONG L R, HU W Y, HUANG B, LIU G, QV M K, KUANG R X.Source appointment of heavy metals in suburban farmland soils based on positive matrix factorization. China Environmental Science, 2015, 35(7): 2103-2111. (in Chinese) doi: 10.3969/j.issn.1000-6923.2015.07.031
[9]	戴彬, 吕建树, 战金成, 张祖陆, 刘洋, 周汝佳. 山东省典型工业城市土壤重金属来源、空间分布及潜在生态风险评价. 环境科学, 2015, 36(2): 507-515. doi: 10.13227/j.hjkX.2015.02.018
	DAI B, LÜ J S, ZHAN J C, ZHANG Z L, LIU Y, ZHOU R J.Assessment of sources, spatial distribution and ecological risk of heavy metals in soils in a typical industry-based city of Shandong Province, Eastern China. Environmental Science, 2015, 36(2): 507-515. (in Chinese) doi: 10.13227/j.hjkX.2015.02.018
[10]	徐一兰, 金自力, 刘唐兴, 程爱武, 李永, 李益锋, 何炜, 黄新杰, 皮俊, 许晓玲. 不同施肥措施对双季稻田土壤和大麦植株镉累积的影响. 生态环境学报, 2017, 26(7): 1235-1241. doi: 10.16258/j.cnki.1674-5906.2017.07.021
	XU Y L, JIN Z L, LIU T X, CHENG A W, LI Y, LI Y F, HE W, HUANG X J, PI J, XU X L.Effects of long-term fertilization on heavy metal Cd accumulation in the surface soil and barley plant of double-cropping paddy rice system. Ecology and Environmental Sciences, 2017, 26(7): 1235-1241. (in Chinese) doi: 10.16258/j.cnki.1674-5906.2017.07.021
[11]	张继舟, 王宏韬, 倪红伟, 马献发, 袁磊. 我国农田土壤重金属污染现状、成因与诊断方法分析. 土壤与作物, 2012, 1(4): 212-218.
	ZHANG J Z, WANG H T, NI H W, MA X F, YUAN L.Current situation, sources and diagnosis method analysis of heavy metal contamination in agricultural soils. Soil and Crop, 2012, 1(4): 212-218. (in Chinese)
[12]	白玲玉, 曾希柏, 李莲芳, 彭畅, 李树辉. 不同农业利用方式对土壤重金属累积的影响及原因分析. 中国农业科学, 2010, 43(1): 96-104.
	BAI L Y, ZENG X B, LI L F, PENG C, LI S H.Effects of land use on heavy metal accumulation in soils and source analysis. Scientia Agricultura Sinica, 2010, 43(1): 96-104. (in Chinese)
[13]	何梦媛, 董同喜, 茹淑华, 苏德纯. 畜禽粪便有机肥中重金属在土壤剖面中积累迁移特征及生物有效性差异. 环境科学, 2017, 38(4): 1576-1586. doi: 10.13227/j.hjkx.201609227
	HE M Y, DONG T X, RU S H, SU D C.Accumulation and migration characteristics in soil profiles and bioavailability of heavy metals from livestock manure. Environment Science, 2017, 38(4): 1576-1586. (in Chinese) doi: 10.13227/j.hjkx.201609227
[14]	曾希柏, 徐建明, 黄巧云, 唐世荣, 李永涛, 李芳柏, 周东美, 武志杰.中国农田重金属问题的若干思考. 土壤学报, 2013(1): 186-194.
	ZENG X B, XU J M, HUANG Q Y, TANG S R, LI Y T, LI F B, ZHOU D M, WU Z J.Some deliberations on the issues of heavy metals in farmlands of China. Acta Pedologica Sinica, 2013, 50(1): 186-194. (in Chinese)
[15]	HAO X Y, CHANG C.Does long-term heavy cattle manure application increase salinity of a clay loam soil in semi-arid southern Alberta. Agriculture Ecosystems and Environment, 2003, 94(1): 89-103. doi: 10.1016/S0167-8809(02)00008-7
[16]	宋波, 陈同斌, 郑袁明, 黄泽春, 郑国砥, 罗金发. 北京市菜地土壤和蔬菜镉含量及其健康风险分析. 环境科学学报, 2006, 26(8): 1343-1353.
	SONG B, CHEN T B, ZHENG Y M, HUANG Z C, ZHENG G D, LUO J F.A survey of cadmium concentrations in vegetables and soils in Beijing and the potential risks to human health. Acta Scientiae Circumstantiae, 2006, 26(8):1343-1353. (in Chinese)
[17]	陈芳, 董元华, 安琼, 钦绳武. 长期肥料定位试验条件下土壤中重金属的含量变化. 土壤, 2005, 37(3): 308-311. doi: 10.3321/j.issn:0253-9829.2005.03.015
	CHEN F, DONG Y H, AN Q, QIN S W.Variation of soil heavy metal contents in a long-term fertilization experiment soils. Soils, 2005, 37(3): 308-311. (in Chinese) doi: 10.3321/j.issn:0253-9829.2005.03.015
[18]	鲁如坤. 土壤-植物营养学原理和施肥. 北京: 化学化工出版社, 1998: 438-439.
	LU R K.Soil- Plant Nutrition Theory and Fertilization. Beijing: Chemical Industry Press, 1998: 438-439. (in Chinese)
[19]	TORBERT H A, DANIEL T C, LEMUNYON J L, JONES R M.Relationship of soil test phosphorus and sampling depth to runoff phosphorus in calcareous and noncalcareous soils. Journal of Environmental Quality, 2002, 31:1380-1387. doi: 10.2134/jeq2002.1380 pmid: 12175059
[20]	闫湘, 王旭, 李秀英, 于兆国. 我国水溶肥料中重金属含量、来源及安全现状. 植物营养与肥料学报, 2016, 22(1): 8-18. doi: 10.11674/zwyf.14443
	YAN X, WANG X, LI X Y, YU Z G.Contents, source and safety status of major heavy metals in water-soluble fertilizers in China. Journal of Plant Nutrition and Fertilizer, 2016, 22(1): 8-18. (in Chinese) doi: 10.11674/zwyf.14443
[21]	李本银, 黄绍敏, 张玉亭, 周东美, 吴晓晨, 沈阿林, 徐建明, 李忠佩. 长期施用有机肥对土壤和糙米铜、锌、铁、锰和镉积累的影响. 植物营养与肥料学报, 2010, 16(1): 129-135. doi: 10.11674/zwyf.2010.0119
	LI B Y, HUANG S M, ZHANG Y T, ZHOU D M, WU X C, SHEN A L, XU J M, LI Z P.Effect of long-term application of organic fertilizer on Cu, Zn, Fe, Mn and Cd in soil and brown rice. Plant Nutrition and Fertilizer Science, 2010, 16(1): 129-135. (in Chinese) doi: 10.11674/zwyf.2010.0119
[22]	汤文光, 肖小平, 唐海明, 张海林, 陈阜, 陈中督, 薛建福, 杨光立. 长期不同耕作与秸秆还田对土壤养分库容及重金属Cd的影响. 应用生态学报, 2015, 26(1):168-176.
	TANG W G, XIAO X P, TANG H M, ZHANG H L, CHEN F, CHEN Z D, XUE J F, YANG G L.Effects of long-term tillage and rice straw returning on soil nutrient pools and Cd concentration. Chinese Journal of Applied Ecology, 2015, 26(1):168-176. (in Chinese)
[23]	彭玉龙, 王永敏, 覃蔡清, 王定勇. 重庆主城区降水中重金属的分布特征及其沉降量. 环境科学, 2014, 35(7): 2490-2496. doi: 10.13227/j.hjkx.2014.07.008
	PENG Y L, WANG Y M, QIN C Q, WANG D Y.Concentrations and deposition fluxes of heavy metals in precipitation in core urban areas of Chongqing. Environmental Science, 2014, 35(7): 2490-2496. (in Chinese) doi: 10.13227/j.hjkx.2014.07.008
[24]	周世伟, 徐明岗. 磷酸盐修复重金属污染土壤的研究进展. 生态学报, 2007(7): 3043-3050. doi: 10.3321/j.issn:1000-0933.2007.07.046
	ZHOU S W, XU M G. The progress in phosphate remediation of heavy metal contaminated soils. Acta Ecologica Sinica, 2007(7): 3043-3050. (in Chinese) doi: 10.3321/j.issn:1000-0933.2007.07.046
[25]	刘昭兵, 纪雄辉, 彭华, 田发祥, 吴家梅, 石丽红. 磷肥对土壤中镉的植物有效性影响及其机理. 应用生态学报, 2012, 23(6): 1585-1590.
	LIU Z B, JI X H, PENG H, TIAN F X, WU J M, SHI L H.Phosphate fertilizer plants effectively influence and mechanism of cadmium in soil. Chinese Journal of Applied Ecology, 2012, 23(6):1585-1590. (in Chinese)
[26]	黄化刚, 李廷强, 朱治强, 王凯, 杨肖娥. 可溶性磷肥对重金属复合污染土壤东南景天提取锌/镉及其养分积累的影响. 植物营养与肥料学报, 2012,18(2): 382-389. doi: 10.11674/zwyf.2012.11294
	HUANG H G, LI T Q, ZHU Z Q, WANG K, YANG X E.Effects of soluble phosphate fertilizer on Zn /Cd phytoextraction and nutrient accumulation ofSedum alfredii H. in co-contaminated soil. Plant Nutrition and Fertilizer Science, 2012, 18(2): 382-389. (in Chinese) doi: 10.11674/zwyf.2012.11294
[27]	董元彦, 罗厚庭, 李学垣. 黄棕壤和红壤吸附磷酸根后对Zn2+和Cd2+次级吸附的动力学. 环境化学, 1995, 14(4): 300-305.
	DONG Y Y, LUO H T, LI X Y.Kinetics of Zn2+ and Cd2+ secondary adsorption on yellow brown soil and red soil pretreated with phosphate. Environmental Chemistry, 1995, 14(4): 300-305. (in Chinese)
[28]	方雅瑜, 邹慧玲, 尹晓辉, 陈楠, 杨登, 魏祥东. 赤泥和有机肥对镉、铅在水稻中吸收分布的影响. 农业资源与环境学报, 2016, 33(5): 466-476. doi: 10.13254/j.jare.2016.0080
	FANG Y Y, ZOU H L, YIN X H, CHEN N, YANG D, WEI X D.Effects of red-mud and organic fertilizer on cadmium and lead absorption and distribution in rice. Journal of Agricultural Resources and Environment, 2016, 33(5): 466-476. (in Chinese) doi: 10.13254/j.jare.2016.0080
[29]	马铁铮, 马友华, 付欢欢, 王强, 徐露露, 聂静茹, 于倩倩. 生物有机肥和生物炭对Cd和Pb污染稻田土壤修复的研究. 农业资源与环境学报, 2015, 32(1):14-19.
	MA T Z, MA Y H, FU H H, WANG Q, XU L L, NIE J R, YU Q Q.Remediation of biological organic fertilizer and biochar in paddy soil contaminated by Cd and Pb. Journal of Agricultural Resources and Environment, 2015, 32(1):14-19. (in Chinese)
[30]	ZENG F R, ALI S, ZHANG H T, OUYANG Y B, QIU B Y, WU F B, ZHANG G P.The influence of pH and organic matter content in paddy soil on heavy metal availability and their uptake by rice plants. Environmental Pollution, 2011, 159(1): 84-91. doi: 10.1016/j.envpol.2010.09.019 pmid: 20952112
[31]	王浩, 章明奎. 污染土壤中有机质和重金属互相作用的模拟研究. 浙江大学学报(农业与生命科学版), 2009, 35(4): 460-466. doi: 10.3785/j.issn.1008-9209.2009.04.017
	WANG H, ZHANG M K.Simulated study on interactions between heavy metals and organic matter in contaminated soil. Journal of Zhejiang University (Agriculture and Life Science ), 2009, 35(4): 460-466. (in Chinese) doi: 10.3785/j.issn.1008-9209.2009.04.017
[32]	钟晓兰, 周生路, 黄明丽, 赵其国. 土壤重金属的形态分布特征及其影响因素. 生态环境学报, 2009, 18(4):1266-1273.
	ZHONG X L, ZHOU S L, HUANG M L, ZHAO Q G.Chemical form distribution characteristic of soil heavy metals and its influencing factors. Ecology and Environmental Sciences, 2009, 18(4):1266-1273. (in Chinese)
[33]	ALVARENGA P, GONCALVES A P, FERNANDES R M, DE VARENNES A, VALLINI G, DUARTE E, CUNHA-QUEDA A C. Organic residues as immobilizing agents in aided phytostabilization:(I) Effects on soil chemical characteristics. Chemosphere, 2009, 74(10): 1292-1300. doi: 10.1016/j.chemosphere.2008.11.063 pmid: 19118864
[34]	贾乐, 朱俊艳, 苏德纯. 秸秆还田对镉污染农田土壤中镉生物有效性的影响. 农业环境科学学报, 2010, 29(10):1992-1998.
	JIA L, ZHU J Y, SU D C.Effects of crop straw return on soil cadmium availability in different cadmium contaminated soil. Journal of Agro-Environment Science, 2010, 29(10): 1992-1998. (in Chinese)
[35]	张亚丽, 沈其荣, 姜洋. 有机肥料对镉污染土壤的改良效应. 土壤学报, 2001, 38(2): 212-218. doi: 10.11766/trxb200003240209
	ZHANG Y L, SHEN Q R, JIANG Y.Effect of organic manure on the amelioration of Cd-pollution soil. Acta Pedologica Sinica, 2001, 38((2): 212-218. (in Chinese) doi: 10.11766/trxb200003240209
[36]	杨林生, 张宇亭, 黄兴成, 张跃强, 赵亚南, 石孝均. 长期施用含氯化肥对稻-麦轮作体系土壤生物肥力的影响. 中国农业科学, 2016, 49(4): 686-694. doi: 10.3864/j.issn.0578-1752.2016.04.008
	YANG L S, ZHANG Y T, HUANG X C, ZHANG Y Q, ZHAO Y N, SHI X J.Effects of ling-term application of chloride containing fertilizers on biological fertility of purple soil under a rice-wheat rotation system. Scientia Agricultura Sinica, 2016, 49(4): 686-694. (in Chinese) doi: 10.3864/j.issn.0578-1752.2016.04.008
[37]	ZHANG Y, THOMASE B W, VRIES W D, SHI X, HAO X.Impacts of long-term nitrogen fertilization on acid buffering rates and mechanisms of a slightly calcareous clay soil. Geoderma, 2016, 305: 92-99. doi: 10.1016/j.geoderma.2017.05.021
[38]	GANIJIR B L, DHOOT L N.How soil pH affects the availability of plant nutrients. Farmer and Parliament, 1981, 16(9): 13-14.

处理 Treatment	年吸收量 Annual uptake (mg?hm^-2·a^-1)		年吸收总量 Total annual uptake (mg?hm^-2·a^-1)
处理 Treatment	籽粒 Grain	秸秆 Straw	年吸收总量 Total annual uptake (mg?hm^-2·a^-1)
CK	47.3	55.3	102.6
N	165.3	259.4	424.7
NK	206.2	220.5	426.7
NPK	234.5	240.9	475.5
NPK+M	313.2	227.3	540.5
NPK+S	247.2	258.7	505.9
1.5NPK+S	239.5	356.7	596.1
(NK)_ClP+S	367.8	450.7	818.5

处理 Treatment	年吸收量 Annual uptake (mg?hm^-2·a^-1)		年吸收总量 Total annual uptake (mg?hm^-2·a^-1)
处理 Treatment	籽粒Grain	秸秆Straw	年吸收总量 Total annual uptake (mg?hm^-2·a^-1)
CK	61.7	260.8	322.4
N	94.5	449.2	543.7
NK	101.6	505.0	606.7
NPK	310.1	939.6	1249.7
NPK+M	293.0	1115.5	1408.5
NPK+S	233.3	769.7	1003.1
1.5NPK+S	380.3	1520.4	1900.8
(NK)_ClP+S	547.1	2247.7	2794.7
