小麦吸浆虫小热激蛋白基因Hsp21.9的克隆及在滞育过程与温度胁迫下的表达特性

doi:10.3864/j.issn.0578-1752.2023.01.006

摘要/Abstract

摘要：

【目的】小麦吸浆虫（Sitodiplosis mosellana）是最重要的小麦害虫之一，滞育使其度过酷暑和严寒。本研究旨在探讨小麦吸浆虫小热激蛋白（small heat shock protein，sHsp）基因Hsp21.9在滞育中的作用。【方法】利用RACE和RT-PCR技术从小麦吸浆虫滞育前幼虫中克隆Hsp21.9全长cDNA序列；利用生物信息学软件对其核苷酸和编码蛋白特性进行分析；采用RT-qPCR技术分析Hsp21.9在滞育进程（滞育前、滞育、滞育后静息期和滞育后发育）不同阶段幼虫及夏滞育幼虫在短期（≤120 min）极端高温（35—50℃) 和越冬幼虫在短期（≤120 min）极端低温（0—-15℃）胁迫下的表达模式；通过大肠杆菌原核表达系统诱导表达及纯化其编码蛋白，采用吸光值法测定重组蛋白抑制猪心苹果酸脱氢酶（malate dehydrogenase，MDH）热聚沉的能力。【结果】克隆获得了cDNA全长为1 087 bp的小麦吸浆虫Hsp21.9，命名为SmHsp21.9（GenBank登录号：KT749988），其开放阅读框长度为582 bp，编码193个氨基酸，其中谷氨酸含量最高（12.4%），半胱氨酸含量最低（0.5%）；预测的蛋白分子量为21.9 kD，等电点为5.67。SmHsp21.9氨基酸序列具有小热激蛋白家族典型的α-晶体结构域，该结构域由6个β-折叠组成，其在空间上形成β-三明治结构。蛋白序列相似性和系统进化分析表明，SmHsp21.9蛋白与长角亚目昆虫摇蚊（Chironomus riparius）Hsp27的相似性最高、亲缘关系最近。RT-qPCR分析结果表明，小麦吸浆虫滞育不同时期幼虫SmHsp21.9表达量存在显著差异，进入滞育后表达量显著降低，10月后逐渐升高，滞育后静息阶段的12月和翌年1月显著高于其他季节。与未处理的对照相比，35—45℃高温、-5—-10℃低温处理可显著诱导越夏、越冬幼虫SmHsp21.9的表达，以30—60 min处理诱导效果较明显；高于50℃或低于-15℃诱导效果不明显。获得的SmHsp21.9重组蛋白可显著抑制MDH在高温（43℃）下聚集，具有显著的分子伴侣活性。【结论】小麦吸浆虫SmHsp21.9的表达不仅受滞育发育影响，而且受环境温度的调控，其可能参与滞育的启动和终止，且与滞育期间的耐热和耐寒性相关。

关键词: 小麦吸浆虫, Hsp21.9, 基因克隆, 滞育, 温度胁迫, 基因表达

Abstract:

【Objective】The wheat blossom midge Sitodiplosis mosellana (Diptera: Cecidomyiidae), one of the most important wheat pests, undergoes obligatory larval diapause to survive adverse temperature extremes during hot summers and cold winters. This study aims to explore the potential roles of small heat shock protein (sHsp) gene Hsp21.9 in diapause process of S. mosellana. 【Method】 RACE and RT-PCR technologies were used to clone the full-length cDNA of Hsp21.9 from S. mosellana pre-diapause larvae. Bioinformatics programs were used to characterize the nucleotide and amino acid sequence of cloned Hsp21.9. Real-time quantitative PCR (RT-qPCR) was used to determine the mRNA expression level of Hsp21.9 in pre-diapause, diapause, post-diapause quiescent and developing larvae of S. mosellana, as well as over-summering larvae exposed to short-term (≤120 min) heat stress (35-50℃) and over-wintering larvae exposed to short-term (≤120 min) cold stress (0 to -15℃). The recombinant Hsp21.9 protein was expressed by Escherichia coli prokaryotic expression technology, and then purified. The activity of bacterially expressed recombinant proteins to suppress thermal aggregation of pig heart mitochondrial malate dehydrogenase (MDH) was determined by colorimetry. 【Result】The full-length cDNA of S. mosellana Hsp21.9 (SmHsp21.9) obtained was 1 087 bp (GenBank accession number: KT749988), which contained a 582 bp open reading frame (ORF). The predicted ORF encoded a protein of 193 amino acids of which the content of glutamic acid (12.4%) was the most, and the content of cysteine (0.5%) was the least. The estimated molecular weight and isoelectric point were 21.9 kD and 5.67, respectively. The amino acid sequence of SmHsp21.9 contains typical α-crystallin domain of the sHsp family. The domain consists of six β-sheets, which forms a β-sandwich structure. Sequence alignment and phylogenetic analysis suggested that SmHsp21.9 displayed the highest amino acid identity and the closest relationship to Hsp27 from the Nematocera Chironomus riparius. RT-qPCR indicated that SmHsp21.9 expression differed significantly among different diapause stages. The expression level was decreased after the initiation of diapause, gradually increased in October, and peaked in early-to-mid phase of post-diapause (December and January). Compared with the untreated control, the expression level of SmHsp21.9 was significantly induced in over-summering larvae exposed to heat stress (35-45℃) or over-wintering larvae exposed to cold stressed (-5 to -10℃), but temperature extremes i.e. as high as 50℃ or as low as -15℃ failed to do so. The treatment duration also affected transcript levels of SmHsp21.9, with the maximum value at 30-60 min. Recombinant SmHsp21.9 proteins obtained significantly prevented heat-induced (43℃) aggregation of MDH, suggesting its significant molecular chaperone functionality. 【Conclusion】The expression of SmHsp21.9 is regulated not only by diapause development, but also by environmental temperature. SmHsp21.9 might be involved in initiation and termination of diapause, and heat/cold tolerance during diapause in S. mosellana.

Key words: Sitodiplosis mosellana, Hsp21.9, gene cloning, diapause, temperature stress, gene expression

古丽旦,刘洋,李方向,成卫宁. 小麦吸浆虫小热激蛋白基因Hsp21.9的克隆及在滞育过程与温度胁迫下的表达特性[J]. 中国农业科学, 2023, 56(1): 79-89.

GU LiDan,LIU Yang,LI FangXiang,CHENG WeiNing. Cloning of Small Heat Shock Protein Gene Hsp21.9 in Sitodiplosis mosellana and Its Expression Characteristics During Diapause and Under Temperature Stresses[J]. Scientia Agricultura Sinica, 2023, 56(1): 79-89.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2023.01.006

https://www.chinaagrisci.com/CN/Y2023/V56/I1/79

图/表 9

表1

图1

图2

图3

图4

图5

图6

图7

图8

参考文献 39

[1]	SHRESTHA G, REDDY G V P. Field efficacy of insect pathogen, botanical, and jasmonic acid for the management of wheat midge Sitodiplosis mosellana and the impact on adult parasitoid Macroglenes penetrans populations in spring wheat. Insect Science, 2019, 26(3): 523-535. doi: 10.1111/1744-7917.12548
[2]	WANG Q, LIU X B, LIU H, FU Y, CHENG Y M, ZHANG L J, SHI W P, ZHANG Y, CHEN J L. Transcriptomic and metabolomic analysis of wheat kernels in response to the feeding of orange wheat blossom midges (Sitodiplosis mosellana) in the field. Journal of Agricultural and Food Chemistry, 2022, 70(5): 1477-1493. doi: 10.1021/acs.jafc.1c06239
[3]	王越, 龙治任, 冯安荣, 成卫宁. 虫口基数、小麦品种和降水对麦红吸浆虫危害程度的影响. 西北农业学报, 2015, 24(10): 165-171.
	WANG Y, LONG Z R, FENG A R, CHENG W N. Effects of initial population number, wheat varieties and precipitation on infestation of Sitodiplosis mosellana (Diptera: Cecidomyiidae). Acta Agriculture Boreali-Occidentalis Sinica, 2015, 24(10): 165-171. (in Chinese)
[4]	CHENG W N, LONG Z R, ZHANG Y D, LIANG T T, ZHU- SALZMAN K Y. Effects of temperature, soil moisture and photoperiod on diapause termination and post-diapause development of the wheat blossom midge, Sitodiplosis mosellana (Géhin)(Diptera: Cecidomyiidae). Journal of Insect Physiology, 2017, 103: 78-85. doi: 10.1016/j.jinsphys.2017.10.001
[5]	GU J, HUANG L X, SHEN Y, HUANG L H, FENG Q L. Hsp70 and small Hsps are the major heat shock protein members involved in midgut metamorphosis in the common cutworm, Spodoptera litura. Insect Molecular Biology, 2012, 21(5): 535-543. doi: 10.1111/j.1365-2583.2012.01158.x pmid: 22957810
[6]	SHEN Q D, ZHAO L N, XIE G Q, WEI P, YANG M M, WANG S G, ZHANG F, TANG B. Cloning three Harmonia axyridis (Coleoptera: Coccinellidae) heat shock protein 70 family genes: Regulatory function related to heat and starvation stress. Journal of Entomological Science, 2015, 50(3): 168-185. doi: 10.18474/JES14-30.1
[7]	FRANCK E, MADSEN O, VAN RHEEDE T, RICARD G, HUYNEN M A, DE JONG W W. Evolutionary diversity of vertebrate small heat shock proteins. Journal of Molecular Evolution, 2004, 59(6): 792-805. pmid: 15599511
[8]	KAPPÉ G, FRANCK E, VERSCHUURE P, BOELENS W C, LEUNISSEN J A, DE JONG W W. The human genome encodes 10 alpha-crystallin-related small heat shock proteins: HspB1-10. Cell Stress & Chaperones, 2003, 8(1): 53-61. doi: 10.1379/1466-1268(2003)8<53:THGECS>2.0.CO;2
[9]	LI Z, LI X, YU Q Y, XIANG Z H, KISHINO H, ZHANG Z. The small heat shock protein (sHSP) genes in the silkworm, Bombyx mori, and comparative analysis with other insect sHSP genes. BMC Evolutionary Biology, 2009, 9: 215. doi: 10.1186/1471-2148-9-215
[10]	汪慧娟, 赵静, 施佐堃, 邱玲玉, 王甦, 张帆, 王世贵, 唐斌. 异色瓢虫3个小分子热激蛋白序列及低温诱导表达分析. 中国农业科学, 2017, 50(16): 3145-3154.
	WANG H J, ZHAO J, SHI Z K, QIU L Y, WANG S, ZHANG F, WANG S G, TANG B. Sequence analysis and induced expression of three novel small heat shock proteins mediating cold-hardiness in Harmonia axyridis. Scientia Agricultura Sinica, 2017, 50(16): 3145-3154. (in Chinese)
[11]	ZHANG Y Y, LIU Y L, GUO X L, LI Y L, GAO H R, GUO X Q, XU B H. sHsp22.6, an intronless small heat shock protein gene, is involved in stress defence and development in Apis cerana cerana. Insect Biochemistry and Molecular Biology, 2014, 53: 1-12. doi: 10.1016/j.ibmb.2014.06.007
[12]	ZAHUR M, MAQBOOL A, IRFAN M, BAROZAI M Y K, QAISER U, RASHID B, HUSNAIN T, RIAZUDDIN S. Functional analysis of cotton small heat shock protein promoter region in response to abiotic stresses in tobacco using Agrobacterium-mediated transient assay. Molecular Biology Reports, 2009, 36(7): 1915-1921. doi: 10.1007/s11033-008-9399-9
[13]	ZHANG A G, LU Y L, LI C H, ZHANG P, SU X R, LI Y, WANG C L, LI T W. A small heat shock protein (sHSP) from Sinonovacula constricta against heavy metals stresses. Fish & Shellfish Immunology, 2013, 34(6): 1605-1610.
[14]	HUANG L H, WANG C Z, KANG L. Cloning and expression of five heat shock protein genes in relation to cold hardening and development in the leafminer, Liriomyza sativa. Journal of Insect Physiology, 2009, 55(3): 279-285. doi: 10.1016/j.jinsphys.2008.12.004 pmid: 19133268
[15]	XIE J, HU X X, ZHAI M F, YU X J, SONG X W, GAO S S, WU W, LI B. Characterization and functional analysis of hsp18.3 gene in the red flour beetle, Tribolium castaneum. Insect Science, 2019, 26(2): 263-273. doi: 10.1111/1744-7917.12543
[16]	RINEHART J P, LI A Q, YOCUM G D, ROBICH R M, HAYWARD S A L, DENLINGER D L. Up-regulation of heat shock proteins is essential for cold survival during insect diapause. Proceedings of the National Academy of Sciences of the United States of America, 2007, 104(27): 11130-11137.
[17]	SI F L, HE Z B, CHEN B. Cloning and expression profiling of heat shock protein DaHSP23 gene in the winter and summer diapause pupae of the onion maggot, Delia antiqua (Diptera: Anthomyiidae). Acta Entomologica Sinica, 2016, 59(4): 402-410.
[18]	LU Y X, XU W H. Proteomic and phosphoproteomic analysis at diapause initiation in the cotton bollworm, Helicoverpa armigera. Journal of Proteome Research, 2010, 9(10): 5053-5064. doi: 10.1021/pr100356t
[19]	ZHANG B, ZHENG J C, PENG Y, LIU X X, HOFFMANN A A, MA C S. Stress responses of small heat shock protein genes in lepidoptera point to limited conservation of function across phylogeny. PLoS ONE, 2015, 10(7): e0132700.
[20]	TACHIBANA S I, NUMATA H, GOTO S G. Gene expression of heat-shock proteins (Hsp23, Hsp70 and Hsp90) during and after larval diapause in the blow fly Lucilia sericata. Journal of Insect Physiology, 2005, 51(6): 641-647. doi: 10.1016/j.jinsphys.2004.11.012
[21]	GOTO S G, KIMURA M T. Heat-shock-responsive genes are not involved in the adult diapause of Drosophila triauraria. Gene, 2004, 326(1): 117-122. doi: 10.1016/j.gene.2003.10.017
[22]	ZHAO J J, HUANG Q T, ZHANG G J, ZHU-SALZMAN K Y, CHENG W N. Characterization of two small heat shock protein genes (Hsp17.4 and Hs20.3) from Sitodiplosis mosellana, and their expression regulation during diapause. Insects, 2021, 12: 119. doi: 10.3390/insects12020119
[23]	CHENG W N, LI D, WANG Y, LIU Y, ZHU-SALZMAN K Y. Cloning of heat shock protein genes (hsp70, hsc70 and hsp90) and their expression in response to larval diapause and thermal stress in the wheat blossom midge, Sitodiplosis mosellana. Journal of Insect Physiology, 2016, 95: 66-77. doi: 10.1016/j.jinsphys.2016.09.005
[24]	DOANE J F, OLFERT O. Seasonal development of wheat midge, Sitodiplosis mosellana (Géhin) (Diptera: Cecidomyiidae), in Saskatchewan, Canada. Crop Protection, 2008, 27(6): 951-958. doi: 10.1016/j.cropro.2007.11.016
[25]	LIVAK K J, SCHMITTGEN T D. Analysis of relative gene expression data using real-time quantitative PCR and the 2^-ΔΔCT method. Methods, 2001, 25(4): 402-408. doi: 10.1006/meth.2001.1262
[26]	CHENG W N, ZHANG Y D, LIU W, LI G W, ZHU-SALZMAN K Y. Molecular and functional characterization of three odorant-binding proteins from the wheat blossom midge, Sitodiplosis mosellana. Insect Science, 2020, 27(4): 721-734. doi: 10.1111/1744-7917.12677
[27]	PÉREZ-MORALES D, OSTOA-SALOMA P, ESPINOZA B. Trypanosoma cruzi SHSP16: Characterization of an α-crystallin small heat shock protein. Experimental Parasitology, 2009, 123: 182-189. doi: 10.1016/j.exppara.2009.06.019
[28]	FU X, LI W, MAO Q, CHANG Z. Disulfide bonds convert small heat shock protein Hsp16.3 from a chaperone to a non-chaperone: Implications for the evolution of cysteine in molecular chaperones. Biochemical and Biophysical Research Communications, 2003, 308(3): 627-635. pmid: 12914797
[29]	JACOBSEN J V, SHAW D C. Heat-stable proteins and abscisic acid action in barley aleurone cells. Plant Physiology, 1989, 91(4): 1520-1526. doi: 10.1104/pp.91.4.1520 pmid: 16667211
[30]	BAGNERIS C, BATEMAN O A, NAYLOR C E, CRONIN N, BOELENS W C, KEEP N H, SLINGSBY C. Crystal structures of α-crystallin domain dimers of αB-crystallin and Hsp20. Journal of Molecular Biology, 2009, 392: 1242-1252. doi: 10.1016/j.jmb.2009.07.069
[31]	SUN Y, MACRAE T H. Small heat shock proteins: Molecular structure and chaperone function. Cellular and Molecular Life Sciences, 2005, 62(21): 2460-2476. doi: 10.1007/s00018-005-5190-4 pmid: 16143830
[32]	GKOUVITSAS T, KONTOGIANNATOS D, KOURTI A. Differential expression of two small Hsps during diapause in the corn stalk borer Sesamia nonagrioides (Lef.). Journal of Insect Physiology, 2008, 54(12): 1503-1510. doi: 10.1016/j.jinsphys.2008.08.009
[33]	KOKOLAKIS G, TATARI M, ZACHAROPOULOU A, MINTZAS A C. The hsp27 gene of the Mediterranean fruit fly, Ceratitis capitata: Structural characterization, regulation and developmental expression. Insect Molecular Biology, 2008, 17(6): 699-710. doi: 10.1111/j.1365-2583.2008.00840.x
[34]	LIU Z H, YAO P B, GUO X Q, XU B H. Two small heat shock protein genes in Apis cerana cerana: Characterization, regulation, and developmental expression. Gene, 2014, 545(2): 205-214. doi: 10.1016/j.gene.2014.05.034
[35]	SHEN Y, GU J, HUANG L H, ZHENG S C, LIU L, XU W H, FENG Q L, KANG L. Cloning and expression analysis of six small heat shock protein genes in the common cutworm, Spodoptera litura. Journal of Insect Physiology, 2011, 57(7): 908-914. doi: 10.1016/j.jinsphys.2011.03.026 pmid: 21510953
[36]	成卫宁, 李建军, 李怡萍, 李修炼, 仵均祥, 王洪亮. 小麦吸浆虫成虫和幼虫滞育过程中蜕皮激素的定量分析. 植物保护学报, 2009, 36(2): 163-167.
	CHENG W N, LI J J, LI Y P, LI X L, WU J X, WANG H L. Quantitative analysis of ecdysteroid in adults and the pre-diapause, diapause and post-diapause larvae of wheat blossom midge, Sitodiplosis mosellana Gehin. Acta Phytophylacica Sinica, 2009, 36(2): 163-167. (in Chinese)
[37]	史学凯, 寇利花, 张育平, 马恩波, 张建珍, 吴海花. 温度对中华稻蝗小分子热休克蛋白基因表达的影响. 应用昆虫学报, 2016, 53(6): 1267-1273.
	SHI X K, KOU L H, ZHANG Y P, MA E B, ZHANG J Z, WU H H. Effects of temperature on the expression patterns of OcsHSP genes in Oxya chinensis. Chinese Journal of Applied Entomology, 2016, 53(6): 1267-1273. (in Chinese)
[38]	GARCIA-REINA A, RODRIGUEZ-GARCIA M J, RAMIS G, GALIAN J. Real-time cell analysis and heat shock protein gene expression in the TcA Tribolium castaneum cell line in response to environmental stress conditions. Insect Science, 2017, 24(3): 358-370. doi: 10.1111/1744-7917.12306
[39]	刘魏魏, 杨璞, 陈晓鸣. 白蜡虫热激蛋白基因在低温胁迫下的表达分析. 林业科学研究, 2013, 26(6): 681-685.
	LIU W W, YANG P, CHEN X M. Expression analysis of heat shock protein genes in Ericerus pela under cold stress. Forest Research, 2013, 26(6): 681-685. (in Chinese)

引物Primer	序列Sequence (5′ to 3′)	用途Purpose
Hsp21.9-3′-outer	TACCGTCGTTCCACTAGTGATTT	3′ RACE
Hsp21.9-3′-inner	CGCGGATCCTCCACTAGTGATTTCACTATAGG	3′ RACE
Hsp21.9-5′-outer	CATGGCTACATGCTGACAGCCTA	5′ RACE
Hsp21.9-5′-inner	CGCGGATCCACAGCCTACTGATGATCAGTCGATG	5′ RACE
Hsp21.9-all-F	GCTATTTACGAGCAATCAC	cDNA全长验证 Full-length cDNA validation
Hsp21.9-all-R	GCGCAATAATCTGCCAATA	cDNA全长验证 Full-length cDNA validation
Hsp21.9-q-F	GATTCAAGCCAGAGCAAGT	实时定量PCR Real-time quantitative PCR
Hsp21.9-q-R	GGTTTCAGGTTTCGGACAT
GADPH-q-F	CCATCAAAGCAAGCAAGA
GADPH-q-R	CAGCACGGAGCACAAGAC
Hsp21.9-F	GGAATTCAAATTAAAGTGTGAACAATGTCGCT (EcoR Ⅰ)	原核表达 Prokaryotic expression
Hsp21.9-R	CCCAAGCTTCATTATTTCTTCTCATCTGTTTTCT (Hind Ⅲ)	原核表达 Prokaryotic expression
