弱光涝渍复合胁迫对夏玉米产量及光合特性的影响

doi:10.3864/j.issn.0578-1752.2021.18.004

摘要/Abstract

摘要：

【目的】旨在探讨不同生育时期弱光涝渍复合胁迫影响夏玉米产量和光合特性的生理机制。【方法】选用DH605为试验材料,通过在大田条件下设置不同生育时期遮阴、淹水以及遮阴+淹水处理,即分别为三叶期淹水（V3-W）、拔节期淹水（V6-W）、开花期淹水（VT-W）;三叶期遮阴（V3-S）、拔节期遮阴（V6-S）、开花期遮阴（VT-S）;三叶期遮阴淹水（V3-S-W）、拔节期遮阴淹水（V6-S-W）、开花期遮阴淹水（VT-S-W）,并以自然光和常规水分处理为对照（CK）,以模拟不同生育时期的寡照、涝渍及其复合胁迫,研究不同生育时期遮阴淹水复合处理对夏玉米产量、光合特性以及干物质的积累与分配的影响。【结果】遮阴淹水后,夏玉米叶面积指数（LAI）下降,叶片叶绿素相对含量（SPAD值）显著降低,净光合速率（Pn）、蒸腾速率（Tr）、气孔导度（Gs）显著下降,胞间二氧化碳浓度（Ci）小幅上升,其中V3-S-W、V6-S-W和VT-S-W处理的Pn较CK分别下降43.7%、41.1%和35.1%,且遮阴淹水复合处理后夏玉米净光合速率的下降幅度大于遮阴、淹水等单一胁迫。遮阴淹水复合处理引发夏玉米光合性能降低,导致夏玉米干物质积累能力及向籽粒分配比例的下降并最终导致产量降低。从2018年和2019年的产量平均值来看,V3-S-W、V6-S-W和VT-S-W处理的产量较CK分别降低32.5%、28.3%和24.7%。与单一遮阴和淹水处理相比,V3-S-W处理的产量较V3-S和V3-W处理分别降低26.3%和13.1%;V6-S-W处理的产量较V6-S和V6-W处理分别下降14.9%和6.2%;VT-S-W处理的产量较VT-S和VT-W处理分别降低2.9%和15.0%。【结论】遮阴淹水复合处理导致夏玉米群体叶面积指数显著降低,叶绿素相对含量下降,光合性能受到抑制,进而导致夏玉米光合同化物的积累与分配受阻,最终导致产量显著下降。三叶期遮阴淹水对夏玉米光合特性和产量的下降幅度的影响最大,拔节期次之,花期的影响较小。同时,遮阴淹水复合处理造成的光合特性及产量下降程度高于任一单处理。

关键词: 夏玉米, 遮阴, 淹水, 弱光涝渍复合胁迫, 产量, 光合特性

Abstract:

【Objective】 The purpose of this study was to investigate the physiological mechanism of shade and waterlogging combined treatment on photosynthetic characteristics of summer maize during different growth stages. 【Method】 DH605 was selected as the test variety. Shading treatment, waterlogging treatment and shading + waterlogging treatment were set in different growth periods under field conditions, including waterlogging at the third leaf stage (V3-W), the sixth leaf stage (V6-W), and flowering stage (VT-W); shading at V3 (V3-S), V6 (V6-S), and VT (VT-S); waterlogging and shading combined treatment at V3 (V3-S-W), V6 (V6-S-W), and VT stage (VT-S-W). The effects of shading and waterlogging compound treatment on yield, photosynthetic characteristics and dry matter accumulation and distribution of summer maize were studied, and the differences of photosynthetic characteristics and yield between single treatment and compound treatment were compared. 【Result】 After shading and waterlogging, the LAI, relative chlorophyll content, net photosynthetic rate (Pn), Transpiration rate (Tr), and stomatal conductance (Gs) of summer maize were significantly decreased. Compared with CK, the Pn under V3-S-W, V6-S-W and VT-S-W was significantly decreased by 43.7%, 41.1% and 35.1%, respectively. Moreover, the net photosynthetic rate of the combined treatment of shading and waterlogging was decreased more than that of shading or waterlogging treatment. The combined treatment of shading and waterlogging resulted in the decrease of photosynthetic performance of summer maize, leading to the decrease of dry matter accumulation ability and grain distribution ratio of summer maize, and thus resulting in a significant decrease of maize yield. Compared with CK, the yield under V3-S-W, V6-S-W and VT-S-W were reduced by 32.5%, 28.3% and 24.7%, respectively. Compared with single shading or flooding treatment, the yield under V3-S-W was 26.3% and 13.1% lower than that under V3-S and V3-W, respectively. Compared with V6-S and V6-W, the grain yield under V6-S-W was decreased by 14.9% and 6.2%, respectively. Compared with VT-S and VT-W, the yield of VT-S-W was reduced by 2.9% and 15.0%, respectively. 【Conclusion】 Combined treatment with shading and waterlogging resulted in significantly reduced LAI, decreased relative chlorophyll content and inhibited photosynthetic performance of summer maize, which led to hindered accumulation and distribution of photosynthetic compounds in summer maize, and thus resulting in the decrease of maize yield. Combined treatment with shading and waterlogging at V3 stage had the greatest effect on photosynthetic characteristics and yield of summer maize, followed by V6 and VT stage. At the same time, the photosynthetic characteristics and yield decreased by combined treatment with shading and waterlogging were higher than either single treatment.

Key words: summer maize, shade, waterlogging, combined stress of shade and waterlogging, yield, photosynthetic characteristics

于维祯,张晓驰,胡娟,邵靖宜,刘鹏,赵斌,任佰朝. 弱光涝渍复合胁迫对夏玉米产量及光合特性的影响[J]. 中国农业科学, 2021, 54(18): 3834-3846.

YU WeiZhen,ZHANG XiaoChi,HU Juan,SHAO JingYi,LIU Peng,ZHAO Bin,REN BaiZhao. Combined Effects of Shade and Waterlogging on Yield and Photosynthetic Characteristics of Summer Maize[J]. Scientia Agricultura Sinica, 2021, 54(18): 3834-3846.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2021.18.004

https://www.chinaagrisci.com/CN/Y2021/V54/I18/3834

图/表 8

图1

图2

表1

表2

图3

图4

图5

表3

参考文献 31

[1]	MENG Q F, LIU B H, YANG H S, CHEN X P. Solar dimming decreased maize yield potential on the North China Plain. Food and Energy Security, 2020, 9(4): 125-137.
[2]	任佰朝, 张吉旺, 董树亭, 赵斌, 刘鹏. 生育前期淹水对夏玉米冠层结构和光合特性的影响. 中国农业科学, 2017, 50(11): 2093-2103.
	REN B Z, ZHANG J W, DONG S T, ZHAO B, LIU P. Effect of waterlogging at early period on structure and photosynthetic characteristics of summer maize. Scientia Agricultura Sinica, 2017, 50(11): 2093-2103. (in Chinese)
[3]	高文华, 李开封, 靳豪豪. 1960-2014年河南极端降水特征分析. 河南大学学报(自然科学版), 2020, 50(3): 253-261.
	GAO W H, LI K F, JIN H H. Characteristics of extreme precipitation in Henan province during 1960-2014. Journal of Henan University (Natural Science), 2020, 50(3): 253-261. (in Chinese)
[4]	邱美娟, 刘布春, 刘园, 张玥滢, 王珂依, 庞静漪. 中国北方苹果主产省降水分布特征分析. 中国农业气象, 2020, 41(5): 263-274.
	QIU M J, LIU B C, LIU Y, ZHANG Y Y, WANG K Y, PANG J Y. Analysis on distribution characteristics of precipitation in major production provinces of apple in Northern China. Chinese Journal of Agrometeorology, 2020, 41(5): 263-274. (in Chinese)
[5]	王群, 赵向阳, 陈启, 李鸿萍, 董朋飞, 李潮海. 夏玉米阴雨寡照致灾机理及减灾稳产技术研究. 中国作物学会, 2019: 82.
	WANG Q, ZHAO X Y, LI H P, DONG P F, LI C H. Study on disaster mechanism and disaster reduction and stable production technology of summer maize with poor rain and light. The Crop Science Society of China, 2019: 82. (in Chinese)
[6]	REN B Z, ZHANG J W, DONG S T, LIU P, ZHAO B. Effects of waterlogging on leaf mesophyll cell ultrastructure and photosynthetic characteristics of summer maize. PLoS One, 2016, 11(9): e0161424. doi: 10.1371/journal.pone.0161424
[7]	GAO J, LIU Z, ZHAO B, DONG S, LIU P, ZHANG J W. Shade stress decreased maize grain yield, dry matter, and nitrogen accumulation. Agronomy Journal, 2020, 112(4): 2768-2776. doi: 10.1002/agj2.v112.4
[8]	余卫东, 冯利平, 刘荣花. 玉米涝渍灾害研究进展与展望. 玉米科学, 2013, 21(4): 143-147.
	YU W D, FENG L P, LIU R H. Research progress and prospect of waterlogging disaster in maize. Journal of Maize Sciences, 2013, 21(4): 143-147. (in Chinese)
[9]	僧珊珊, 王群, 李潮海, 刘天学, 赵龙飞, 刘怀攀. 淹水胁迫下不同玉米品种根结构及呼吸代谢差异. 中国农业科学, 2012, 45(20): 4141-4148.
	SENG S S, WANG Q, LI C H, LIU T X, ZHAO L F, LIU H P. Difference in root structure and respiration metabolism between two maize cultivars under waterlogging stress. Scientia Agricultura Sinica, 2012, 45(20): 4141-4148. (in Chinese)
[10]	李从锋, 贾春兰, 陶志强, 杨今胜, 柳京国, 赵明. 拔节期淹水对不同株高夏玉米产量、形态特征及物质生产的影响. 玉米科学, 2019, 27(6): 62-67.
	LI C F, JIA C L, TAO Z Q, YANG J S, LIU J G, ZHAO M. Effects of waterlogging at jointing stage on grain yield, plant morphology and dry matter production in different plant height of summer maize. Journal of Maize Sciences, 2019, 27(6): 62-67. (in Chinese)
[11]	崔海岩, 靳立斌, 李波, 赵斌, 董树亭, 刘鹏, 张吉旺. 大田遮阴对夏玉米光合特性和叶黄素循环的影响. 作物学报, 2013, 39(3): 478-485. doi: 10.3724/SP.J.1006.2013.00478
	CUI H Y, JIN L B, LI B, ZHAO B, DONG S T, LIU P, ZHANG J W. Effects of shading on photosynthetic characteristics and xanthophyll cycle of summer maize in the field. Acta Agronomica Sinica, 2013, 39(3): 478-485. (in Chinese) doi: 10.3724/SP.J.1006.2013.00478
[12]	任佰朝, 张吉旺, 李霞, 范霞, 董树亭, 刘鹏, 赵斌. 大田淹水对夏玉米养分吸收与转运的影响. 植物营养与肥料学报, 2014, 20(2): 298-308.
	REN B Z, ZHANG J W, LI X, FAN X, DONG S T, LIU P, ZHAO B. Effect of waterlogging on nutrient uptake and transport of summer maize. Journal of Plant Nutrition and Fertilizers, 2014, 20(2): 298-308. (in Chinese)
[13]	胡旭光, 杨兵兵, 石磊, 盛绍学, 李文阳. 小麦拔节期淹水对叶片光合特性的影响. 生态科学, 2018, 37(5): 72-76.
	HU X G, YANG B B, SHI L, SHENG S X, LI W Y. Effects of waterlogging at jointing stage on photosynthetic characteristics of wheat leaves. Ecological Science, 2018, 37(5): 72-76. (in Chinese)
[14]	任佰朝, 张吉旺, 李霞, 范霞, 董树亭, 赵斌, 刘鹏. 大田淹水对夏玉米叶片衰老特性的影响. 应用生态学报, 2014, 25(4): 1022-1028.
	REN B Z, ZHANG J W, LI X, FAN X, DONG S T, ZHAO B, LIU P. Effect of waterlogging on leaf senescence characteristics of summer maize in the field. Chinese Journal of Applied Ecology, 2014, 25(4): 1022-1028. (in Chinese)
[15]	任佰朝, 朱玉玲, 李霞, 范霞, 董树亭, 赵斌, 刘鹏, 张吉旺. 大田淹水对夏玉米光合特性的影响. 作物学报, 2015, 41(2): 329-338. doi: 10.3724/SP.J.1006.2015.00329
	REN B Z, ZHU Y L, LI X, FAN X, DONG S T, ZHAO B, LIU P, ZHANG J W. Effects of waterlogging on photosynthetic characteristics of summer maize under field conditions. Acta Agronomica Sinica, 2015, 41(2): 329-338. (in Chinese) doi: 10.3724/SP.J.1006.2015.00329
[16]	张昆, 万勇善, 刘凤珍. 苗期弱光对花生光合特性的影响. 中国农业科学, 2010, 43(1): 65-67.
	ZHANG K, WAN Y S, LIU F Z. Effects of weak light on photosynthetic characteristics of peanut seedlings. Scientia Agricultura Sinica, 2010, 43(1): 65-67. (in Chinese)
[17]	高佳, 崔海岩, 史建国, 董树亭, 刘鹏, 赵斌, 张吉旺. 花粒期光照对夏玉米光合特性和叶绿体超微结构的影响. 应用生态学报, 2018, 29(3): 883-890.
	GAO J, CUI H Y, SHI J G, DONG S T, LIU P, ZHAO B, ZHANG J W. Effects of light intensities after anthesis on the photosynthetic characteristics and chloroplast ultrastructure in mesophyll cell of summer maize (Zea mays L.). Chinese Journal of Applied Ecology, 2018, 29(3): 883-890. (in Chinese)
[18]	贾士芳, 董树亭, 王空军, 张吉旺, 刘鹏. 弱光胁迫对玉米产量及光合特性的影响. 应用生态学报, 2007, 18(11): 2456-2461.
	JIA S F, DONG S T, WANG K J, ZHANG J W, LIU P. Effects of weak light stress on grain yield and photosynthetic traits of maize. Chinese Journal of Applied Ecology, 2007, 18(11): 2456-2461. (in Chinese)
[19]	黄鑫慧, 高佳, 任佰朝, 赵斌, 刘鹏, 张吉旺. 植酶Q9对大田弱光夏玉米产量形成的影响. 中国农业科学, 2019, 52(19): 3309-3322.
	HUANG X H, GAO J, REN B Z, ZHAO B, LIU P, ZHANG J W. Effects of phytase Q9 on yield formation of summer maize shading in the field. Scientia Agricultura Sinica, 2019, 52(19): 3309-3322. (in Chinese)
[20]	LI H, CAI J, JIANG D, LIU F, DAIL T, CAO W. Carbohydrates accumulation and remobilization in wheat plants as influenced by combined waterlogging and shading stress during grain filling. Journal of Agronomy and Crop Science, 2013, 199(1): 38-48. doi: 10.1111/jac.2013.199.issue-1
[21]	郑仁娜, 阚正荣, 苏盛楠, 江孟孟, 丁锦峰, 李春燕, 朱新开, 郭文善. 遮光和渍水对小麦幼苗形态和生长的影响. 麦类作物学报, 2017, 37(2): 238-245.
	ZHENG R N, KAN Z R, SU S N, JIANG M M, DING J F, LI C Y, ZHU X K, GUO W S. Effects of shading and waterlogging on morphology and growth on wheat seeding. Journal of Triticeae Crops, 2017, 37(2): 238-245. (in Chinese)
[22]	NAJEEB U, BANGE M P, ATWELL B J, TAN D K Y. Low incident light combined with partial waterlogging impairs photosynthesis and imposes a yield penalty in cotton. Journal of Agronomy and Crop Science, 2016, 202(4): 331-341. doi: 10.1111/jac.12164
[23]	张银杰, 王磊, 白由路, 卢艳丽, 张静静, 李格. 玉米不同层位叶片生理生化指标与SPAD值的关系. 植物营养与肥料学报, 2020, 26(7): 1-13.
	ZHANG Y J, WANG L, BAI Y L, LU Y L, ZHANG J J, LI G. Relationship of physiological and biochemical indicators with SPAD values in maize leaves at different layers. Journal of Plant Nutrition and Fertilizers, 2020, 26(7): 1-13. (in Chinese)
[24]	吕晋慧, 李艳锋, 王玄, 任磊, 冯雁梦, 赵夏陆, 张春来. 遮阴处理对金莲花生长发育和生理响应的影响. 中国农业科学, 2013, 46(9): 1772-1780.
	LÜ J H, LI Y F, WANG X, REN L, FENG Y M, ZHAO X L, ZHANG C L. Impact of shading on growth, development and physiological characteristics of trollius chinensis bunge. Scientia Agricultura Sinica, 2013, 46(9): 1772-1780. (in Chinese)
[25]	贾士芳, 李从锋, 董树亭, 张吉旺. 花后不同时期遮光对玉米粒重及品质影响的细胞学研究. 中国农业科学, 2010, 43(5): 911-921.
	JIA S F, LI C F, DONG S T, ZHANG J W. Effects of shading at different stages after anthesis on maize grain weight and quality at cytology level. Scientia Agricultura Sinica, 2010, 43(5): 911-921. (in Chinese)
[26]	张吉旺, 董树亭, 王空军, 胡昌浩, 刘鹏. 大田遮荫对夏玉米光合特性的影响. 作物学报, 2007, 33(2): 216-222.
	ZHANG J W, DONG S T, WANG K J, HU C H, LIU P. Effects of shading in field on photosynthetic characteristics in summer corn. Acta Agronomica Sinica, 2007, 33(2): 216-222. (in Chinese)
[27]	王群, 赵向阳, 刘东尧, 闫振华, 李鸿萍, 董朋飞, 李潮海. 淹水弱光复合胁迫对夏玉米根形态结构、生理特性和产量的影响. 中国农业科学, 2020, 53(17): 3479-3495.
	WANG Q, ZHAO X Y, LIU D Y, YAN Z H, LI H P, DONG P F, LI C H. Root morphological, physiological traits and yield of maize under waterlogging and low light stress. Scientia Agricultura Sinica, 2020, 53(17): 3479-3495. (in Chinese)
[28]	周卫霞, 董朋飞, 王秀萍, 李潮海. 弱光胁迫对不同基因型玉米籽粒发育和碳氮代谢的影响. 作物学报, 2013, 39(10): 1826-1834. doi: 10.3724/SP.J.1006.2013.01826
	ZHOU W X, DONG P F, WANG X P, LI C H. Effects of low-light stress on kernel setting and metabolism of carbon and nitrogen in different maize (Zea mays L.) genotypes. Acta Agronomica Sinica, 2013, 39(10): 1826-1834. (in Chinese) doi: 10.3724/SP.J.1006.2013.01826
[29]	LENSSEN J P M, MENTING F B J, VANDER PUTTEN W H. Plant responses to simultaneous stress of waterlogging and shade: Amplified or hierarchical effects. New Phytologist, 2003, 157(2): 281-290. doi: 10.1046/j.1469-8137.2003.00666.x
[30]	牟会荣, 姜东, 戴廷波, 张传辉, 荆奇, 曹卫星. 遮光对小麦籽粒淀粉品质和花前贮存非结构碳水化合物转运的影响. 应用生态学报, 2009, 20(4): 805-810.
	MU H R, JIANG D, DAI T B, ZHANG C H, JING Q, CAO W X. Effects of shading on wheat grain starch quality and redistribution of pre-anthesis stored nonstructural carbohydrates. Chinese Journal of Applied Ecology, 2009, 20(4): 805-810. (in Chinese)
[31]	顾蕴倩, 刘雪, 张巍, 亓春杰, 汤开磊, 赵杨, 张岩, 李刚, 王斌, 赵春江, 罗卫红. 灌浆期弱光逆境对小麦生长和产量影响的模拟模型. 中国农业科学, 2013, 46(5): 898-908.
	GU Y Q, LIU X, ZHANG W, QI C J, TANG K L, ZHAO Y, ZHANG Y, LI G, WANG B, ZHAO C J, LUO W H. The simulation model of the effects of low level of radiation at milk filling stage on wheat growth and yield. Scientia Agricultura Sinica, 2013, 46(5): 898-908. (in Chinese)

年份处理 Treatment		2018				2019
年份处理 Treatment		千粒重 1000-grain weight (g)	穗粒数 kernels per spike	公顷穗数 Ear number (ear)	产量 Yield (kg·hm^-2)	千粒重 1000-grain weight (g)	穗粒数 kernels per spike	公顷穗数 Ear number (ear)	产量 Yield (kg·hm^-2)
CK		375ab	544a	67496	13770a	348a	496a	67496	13563a
V3-W		377a	477e	65962	11897cd	308de	364g	62304	8114f
V3-S		373abc	544a	65962	13386a	330b	480b	65850	12130b
V3-S-W		381a	450f	64561	11094e	304e	325h	64122	7378g
V6-W		365c	487d	64823	11528de	314d	375ef	62304	8538e
V6-S		378a	528b	63063	12590b	326bc	474c	64121	11542c
V6-S-W		373abc	464e	64741	11225e	314d	369fg	62292	8409ef
VT-W		366bc	518c	64684	12267bc	321c	462d	65850	11397c
VT-S		364c	518c	67496	12754b	326bc	372ef	64121	9051d
VT-S-W		373abc	480de	64624	11587de	321c	376e	64121	9025d
显著性 Significant	S	ns	**	-	**	**	**	-	**
	W	ns	**	-	**	**	**	-	**
	G	**	**	-	*	**	**	-	**
	S×W	ns	**	-	ns	**	*	-	**
	S×G	ns	**	-	ns	ns	**	-	**
	W×G	ns	**	-	*	**	**	-	**
	S×W×G	ns	**	-	ns	ns	**	-	**

处理 Treatment		净光合速率 Pn (μmol·m^-2·s^-1)	蒸腾速率 Tr (μmol·m^-2·s^-1)	气孔导度 Gs ((μmol·m^-2·s^-1)	胞间二氧化碳浓度 Ci (μmol·m^-2·s^-1)
CK		37.7a	6.75a	357a	172c
V3-W		21.5e	4.63d	190e	248a
V3-S		35.9ab	5.76b	330bc	185bc
V3-S-W		21.2e	4.11d	181e	260a
V6-W		22.7de	4.71cd	197de	238a
V6-S		35.9ab	5.69b	346ab	201b
V6-S-W		22.2e	3.99e	189e	239a
VT-W		35.3b	5.66b	316c	189bc
VT-S		25.4c	5.30bc	212d	182bc
VT-S-W		24.5cd	5.30bc	194de	179bc
显著性 Significant	S	**	**	**	**
	W	**	**	**	*
	G	**	**	ns	**
	S×W	**	*	*	ns
	S×G	**	ns	ns	**
	W×G	**	**	ns	**
	S×W×G	ns	ns	ns	ns

年份 Year	处理 Treatment	茎 Stem		叶 Leaf		粒 Grain		轴 Spike axis		单株 Total dry matter (g/plant)
年份 Year	处理 Treatment	干重 Dry matter (g/plant)	比例 Proportion (%)	干重 Dry matter (g/plant)	比例 Proportion (%)	干重 Dry matter (g/plant)	比例 Proportion (%)	干重 Dry matter (g/plant)	比例 Proportion (%)	单株 Total dry matter (g/plant)
2018	CK	71.0ab	21.8%	37.0bc	11.4%	199.0a	61.1%	18.0b	5.5%	325.5a
	V3-W	73.0ab	26.7%	44.7ab	16.4%	135.0d	49.3%	21.0ab	7.7%	273.7d
	V3-S	68.0b	21.9%	39.6bc	12.7%	186.0ab	59.8%	17.5b	5.6%	311.1a
	V3-S-W	75.0a	27.5%	42.2b	15.5%	132.0d	48.5%	23.0a	8.4%	272.2d
	V6-W	66.8b	23.8%	45.4ab	16.5%	150.4c	53.0%	19.0b	6.7%	283.6cd
	V6-S	65.0b	21.3%	41.6bc	13.7%	180.3b	59.2%	17.7b	5.8%	304.6bc
	V6-S-W	66.2b	23.7%	52.7a	18.9%	141.0d	50.5%	19.5b	7.0%	279.3d
	VT-W	70.5b	23.6%	32.2c	10.8%	175.0b	58.7%	20.5ab	6.9%	298.2c
	VT-S	69.5b	24.0%	39.4bc	13.6%	161.0c	55.6%	19.8b	6.8%	289.7c
	VT-S-W	69.9b	24.4%	36.6bc	12.8%	159.0c	55.5%	20.8ab	7.3%	286.3cd
2019	CK	76.7a	21.4%	36.9a	10.3%	202.4a	59.8%	22.6a	6.7%	338.6a
	V3-W	46.5f	24.9%	25.3de	13.6%	97.5de	52.3%	17.6c	9.4%	186.5f
	V3-S	62.0c	21.2%	32.9ab	11.2%	174.8b	59.8%	22.7a	7.8%	292.5c
	V3-S-W	54.2e	30.9%	21.6e	12.3%	96.2e	49.1%	13.5d	7.7%	185.4g
	V6-W	64.2c	29.9%	28.1cd	13.1%	105.7d	49.2%	16.7bc	9.6%	214.7e
	V6-S	71.2b	24.5%	31.8bc	10.9%	167.7b	57.7%	20.1bc	6.9%	290.8c
	V6-S-W	58.2d	27.5%	27.4cd	13.0%	105.9d	50.9%	10.2d	7.2%	211.4e
	VT-W	72.2b	23.9%	37.9a	12.5%	167.9b	55.5%	24.7a	8.2%	302.7b
	VT-S	76.5a	28.5%	37.0a	13.8%	132.8c	49.5%	22.1ab	8.2%	268.4d
	VT-S-W	74.1ab	28.0%	37.4a	14.1%	132.4c	50.1%	20.5bc	7.8%	264.4d
