白背飞虱酚氧化酶原PPO基因特性及其免疫应答

doi:10.3864/j.issn.0578-1752.2020.15.011

摘要/Abstract

摘要：

【目的】酚氧化酶（phenoloxidase,PO）是昆虫体内的免疫蛋白,在昆虫体内起重要的调节作用,主要以无活性的酚氧化酶原（prophenoloxidase,PPO）形式存在。本研究在转录组测序获得白背飞虱（Sogatella furcifera）3条PPO序列的基础上,通过分析白背飞虱体内不同SfPPO的发育和组织表达模式,并进一步抑制SfPPO的表达以及病原菌诱导,探讨SfPPO在白背飞虱体内的生物学功能。【方法】以白背飞虱3条SfPPO序列为研究对象,利用生物信息学方法分析其蛋白结构以及与其他昆虫之间的同源性。并以注射绿色荧光蛋白（green fluorescent protein,GFP）的dsRNA作为对照组,通过注射合成的dsSfPPO后采用实时荧光定量PCR（qRT-PCR）检测基因表达抑制效果;此外,为了探究SfPPO在白背飞虱生长发育和免疫应答方面的作用,利用qRT-PCR检测SfPPO在不同发育阶段及组织中的表达情况,以及注射大肠杆菌（Escherichia coli）和枯草芽孢杆菌（Bacillus subtilis）后3个SfPPO的诱导表达情况。【结果】SfPPO1、SfPPO2-1、SfPPO2-2的开放阅读框长度分别为2 079、999、2 070 bp,分别编码692、332、689个氨基酸,预测蛋白分子量分别为79.84、37.67、79.53 kD,等电点分别为6.43、9.56、6.20。生物信息学分析表明,白背飞虱的3个PPO蛋白具有较高的同源性,且与褐飞虱（Nilaparvata lugens）的亲缘关系最近;SfPPO1、SfPPO2-1、SfPPO2-2均在成虫第3天表达量最高,其中SfPPO2-1和SfPPO2-2的发育表达模式相似;SfPPO1和SfPPO2-1在表皮和脂肪体内表达量较高,而SfPPO2-2在翅和脂肪体内表达量较高,在头、足、中肠、马氏管中表达量相对较低;与注射dsGFP组相比,注射靶标基因的dsRNA后都能够显著沉默目的基因的表达,而且当SfPPO2-1表达被沉默后,SfPPO1出现显著高表达,说明不同的PPO之间可能具有补偿功能;大肠杆菌诱导后12 h,SfPPO2-1和SfPPO2-2表达量显著升高,SfPPO1表达量则在诱导24 h后显著升高;枯草芽胞杆菌诱导24 h后,SfPPO1、SfPPO2-1和SfPPO2-2表达量均显著升高。【结论】SfPPO1、SfPPO2-1、SfPPO2-2的表达存在组织和龄期特异性,且在不同菌诱导情况下存在免疫应答差异性。研究结果有助于更加全面、深入地探索白背飞虱酚氧化酶在调控昆虫发育及免疫中的潜在分子机理。

关键词: 白背飞虱, 酚氧化酶原, RNA干扰, 实时荧光定量PCR, 诱导表达, 免疫应答

Abstract:

【Objective】Phenoloxidase (PO) is an immune protein and plays an important regulatory role in insects. It exists as the form of inactive prophenoloxidase (PPO). In this study, based on the three PPO sequences of Sogatella furcifera by transcriptome sequencing, the biological functions of SfPPOs were further explored by analyzing the developmental and tissue expression patterns of different SfPPOs, suppressing the expression of SfPPOs and inducing by pathogenic bacteria.【Method】Taking three SfPPO sequences as research objects, the protein structure and homology with other insects were analyzed by bioinformatics method. In addition, dsRNA injected with green fluorescent protein (GFP) was used as a control group, and the inhibitory effect of target gene was detected by quantitative real-time PCR (qRT-PCR) after injecting with dsSfPPO. In order to investigate the role of SfPPO in the growth and immune response of S. furcifera, qRT-PCR was used to detect the expression of SfPPO at different developmental stages and in different tissues, as well as the induced expression of three SfPPOs after injecting with Escherichia coli and Bacillus subtilis.【Result】The open reading frames (ORF) of SfPPO1, SfPPO2-1, and SfPPO2-2 are 2 079, 999, and 2 070 bp in length, respectively, which encoding 692, 332, and 689 amino acids, respectively. The predicted protein molecular weights are 79.84, 37.67, and 79.53 kD, and the isoelectric points are 6.43, 9.56, and 6.20, respectively. Bioinformatics analysis showed that the three PPO proteins of S. furcifera had high homology and were closely related to Nilaparvata lugens. SfPPO1, SfPPO2-1 and SfPPO2-2 were all highly expressed on the 3rd day of adult, and the developmental expression patterns of SfPPO2-1 and SfPPO2-2 were similar. The tissue expression results showed that SfPPO1 and SfPPO2-1 were highly expressed in the epidermis and fat body, while SfPPO2-2 was highly expressed in the wing and fat body, and the expressions of all the three genes were relatively low in head, foot, midgut and Malpighian tubule. Compared with the dsGFP group, injecting with the dsRNA of target gene could significantly silence the expression of target gene, and when the SfPPO2-1 expression was silenced, SfPPO1 appeared to be significantly overexpressed, indicating that there might be compensatory function among different PPOs. The expression levels of SfPPO2-1 and SfPPO2-2 were significantly increased after 12 h of induction with E. coli, while the expression of SfPPO1 was significantly increased after 24 h of induction. In addition, the expression levels of SfPPO1, SfPPO2-1 and SfPPO2-2 were all significantly increased after 24 h of induction with B. subtilis.【Conclusion】The expression of SfPPO1, SfPPO2-1 and SfPPO2-2 has tissue and development specificity, and there are differences in immune response under the induction of different pathogenic bacteria. The results are helpful to explore the potential molecular mechanism of phenoloxidase in insect development and immunity.

Key words: Sogatella furcifera, prophenoloxidase (PPO), RNA interference (RNAi), quantitative real-time PCR (qRT-PCR), inducible expression, immune response

张道伟,康奎,余亚娅,匡富萍,潘碧莹,陈静,唐斌. 白背飞虱酚氧化酶原PPO基因特性及其免疫应答[J]. 中国农业科学, 2020, 53(15): 3108-3119.

ZHANG DaoWei,KANG Kui,YU YaYa,KUANG FuPing,PAN BiYing,CHEN Jing,TANG Bin. Characteristics and Immune Response of Prophenoloxidase Genes in Sogatella furcifera[J]. Scientia Agricultura Sinica, 2020, 53(15): 3108-3119.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2020.15.011

https://www.chinaagrisci.com/CN/Y2020/V53/I15/3108

图/表 7

表1

图1

图2

图3

图4

图5

图6

参考文献 36

[1]	徐安隆, 陈曙, 贺文爱, 张木清, 邱永福. 水稻抗褐飞虱与白背飞虱研究进展. 南方农业学报, 2015,46(9):1628-1635.
	XU A L, CHEN S, HE W A, ZHANG M Q, QIU Y F. Progress on rice resistance to brown planthopper and white-backed planthopper. Journal of Southern Agriculture, 2015,46(9):1628-1635. (in Chinese)
[2]	KANOST M R, JIANG H, YU X Q. Innate immune responses of a lepidopteran insect,Manduca sexta. Immunological Reviews, 2004,198(1):97-105.
[3]	GILLESPIE J P, KANOST M R, TRENCZEK T. Biological mediators of insect immunity. Annual Review of Entomology, 1997,42:611-643. doi: 10.1146/annurev.ento.42.1.611 pmid: 9017902
[4]	STRAND M R. The insect cellular immune response. Insect Science, 2008,15(1):1-14.
[5]	ASHIDA M, BREY P. Recent advances in research on insect prophenoloxidase cascade//BREY P, HULTMARK D. Molecular Mechanisms of Immune Responses in Insects. London: Chapman and Hall, 1997: 135-172.
[6]	CERENIUS L, LEE B L, SÖDERHÄLL K. The proPO-system: pros and cons for its role in invertebrate immunity. Trends in Immunology, 2008,29(6):263-271. doi: 10.1016/j.it.2008.02.009 pmid: 18457993
[7]	KANOST M R, GORMAN M J. Phenoloxidases in insect immunity//BECKAGE N E. Insect Immunology. Elsevier Inc., 2008: 69-96.
[8]	LEMAITRE B, HOFFMANN J. The host defense of Drosophila melanogaster. Annual Review of Immunology, 2007,25:697-743. pmid: 17201680
[9]	LAI S C, CHEN C C, HOU R F. Immunolocalization of prophenoloxidase in the process of wound healing in the mosquito Armigeres subalbatus (Diptera: Culicidae). Journal of Medical Entomology, 2002,39(2):266-274. pmid: 11931025
[10]	NAM H J, JANG I H, YOU H, LEE K A, LEE W J. Genetic evidence of a redox-dependent systemic wound response via Hayan protease-phenoloxidase system in Drosophila. The EMBO Journal, 2012,31(5):1253-1265. pmid: 22227521
[11]	陈晓宇, 时敏, 陈学新. 昆虫酚氧化酶原激活酶研究. 应用昆虫学报, 2015,52(2):281-288.
	CHEN X Y, SHI M, CHEN X X. The prophenoloxidase activating proteinase in insects. Chinese Journal of Applied Entomology, 2015,52(2):281-288. (in Chinese)
[12]	吕鸿声. 昆虫免疫学原理. 上海: 上海科学技术出版社, 2008.
	LÜ H S. Principles of Insect Immunology. Shanghai: Shanghai Scientific and Technical Publishers, 2008. (in Chinese)
[13]	张道伟, 陈静. 酚氧化酶参与德国小蠊对大肠杆菌的免疫应答. 昆虫学报, 2014,57(10):1123-1132.
	ZHANG D W, CHEN J. Phenoloxidase is involved in regulating immune response to Escherichia coli in Blattella germanica (Blattodea: Blattellidae). Acta Entomologica Sinica, 2014,57(10):1123-1132. (in Chinese)
[14]	陈静, 张道伟, 钱正敏. 褐飞虱两个酚氧化酶原基因的特性及细菌诱导后的表达分析. 中国生物防治学报, 2018,34(1):44-51.
	CHEN J, ZHANG D W, QIAN Z M. Characteristics and bacterial-induced expression analysis of two prophenoloxidase genes in the brown planthopper, Nilaparvata lugens (Hemiptera Delphacidae). Chinese Journal of Biological Control, 2018,34(1):44-51. (in Chinese)
[15]	MAQBOOL M, MOBASHIR M, HODA N. Pivotal role of glycogen synthase kinase-3: A therapeutic target for Alzheimer's disease. European Journal of Medicinal Chemistry, 2016,107:63-81. pmid: 26562543
[16]	ZHAO L N, YANG M M, SHEN Q D, LIU X J, SHI Z K, WANG S G, TANG B. Functional characterization of three trehalase genes regulating the chitin metabolism pathway in rice brown planthopper using RNA interference. Scientific Reports, 2016,6:27841. pmid: 27328657
[17]	CHEN Q W, JIN S, ZHANG L, SHEN Q D, WEI P, WEI C M, WANG S G, TANG B. Regulatory functions of trehalose-6-phosphate synthase in the chitin biosynthesis pathway in Tribolium castaneum (Coleoptera: Tenebrionidae) revealed by RNA interference. Bulletin of Entomological Research, 2018,108(3):388-399. doi: 10.1017/S000748531700089X pmid: 28920565
[18]	LU A, ZHANG Q, ZHANG J, YANG B, WU K, XIE W, LUAN Y X, LING E. Insect prophenoloxidase: The view beyond immunity. Frontiers in Physiology, 2014,5:252. doi: 10.3389/fphys.2014.00252 pmid: 25071597
[19]	WERTHEIM B, KRAAIJEVELD A R, SCHUSTER E, BLANC E, HOPKINS M, PLETCHER S D, STRAND M R, PARTRIDGE L, GODFRAY H C. Genome-wide gene expression in response to parasitoid attack in Drosophila. Genome Biology, 2005,6(11):R94. pmid: 16277749
[20]	HERNÁNDEZ-LÓPEZ J, GOLLAS-GALVÁN T, GÓMEZ-JIMÉNEZ S, PORTILLO-CLARK G, VARGAS-ALBORES F. In the spiny lobster (Panulirus interruptus) the prophenoloxidase is located in plasma not in haemocytes. Fish and Shellfish Immunology, 2003,14(2):105-114. pmid: 12526875
[21]	张小玉, 汪贞, 黄泽夫, 王国秀, 刘绪生. 棉铃虫不同虫态及虫龄血淋巴中酚氧化酶活力的比较. 应用昆虫学报, 2006,43(3):330-332.
	ZHANG X Y, WANG Z, HUANG Z F, WANG G X, LIU X S. Dynamics of phenoloxidase activity in haemolymph of Helicoverpa armigera at different stages and instars. Chinese Journal of Applied Entomology, 2006,43(3):330-332. (in Chinese)
[22]	冯从经, 杜予州, 陆自强, 符文俊. 亚洲玉米螟幼虫血清中酚氧化酶原的性质. 昆虫学报, 2005,48(5):649-654.
	FENG C J, DU Y Z, LU Z Q, FU W J. Characterization of prophenoloxidase from the hemolymph of Ostrinia furnacalis (Guenée). Acta Entomologica Sinica, 2005,48(5):649-654. (in Chinese)
[23]	张永亮, 朱勇. 家蚕和野桑蚕酚氧化酶原基因的组织表达差异比较. 蚕业科学, 2009,35(3):630-633.
	ZHANG Y L, ZHU Y. A comparison on tissue-specific expressions of prophenoloxidase gene in Bombyx mori and Bombyx mandarina. Science of Sericulture, 2009,35(3):630-633. (in Chinese)
[24]	LOU Y H, PAN P L, YE Y X, CHENG C, XU H J, ZHANG C X. Identification and functional analysis of a novel chorion protein essential for egg maturation in the brown planthopper. Insect Molecular Biology, 2018,27(3):393-403. pmid: 29465791
[25]	韩艳华, 刘梦姚, 张洪志, 王曼姿, 高飞, 王孟卿, 刘晨曦, 陈红印, 张礼生. RNA干扰技术在昆虫滞育机制研究中的应用. 环境昆虫学报, 2018,40(6):1248-1254.
	HAN Y H, LIU M Y, ZHANG H Z, WANG M Z, GAO F, WANG M Q, LIU C X, CHEN H Y, ZHANG L S. Application of RNA interference on researches of diapause mechanism in insects. Journal of Environmental Entomology, 2018,40(6):1248-1254. (in Chinese)
[26]	XI Y, PAN P L, ZHANG C X. The β-N-acetylhexosaminidase gene family in the brown planthopper, Nilaparvata lugens. Insect Molecular Biology, 2015,24(6):601-610. pmid: 26304035
[27]	FIRE A, XU S, MONTGOMERY M K, KOSTAS S A, DRIVER S E, MELLO C C. Potent and specific genetic interference by double- stranded RNA in Caenorhabditis elegans. Nature, 1998,391(6669):806-811. doi: 10.1038/35888 pmid: 9486653
[28]	ZHU Q S, ARAKANE Y, BEEMAN R W, KRAMER K J, MUTHUKRISHNAN S. Functional specialization among insect chitinase family genes revealed by RNA interference. Proceedings of the National Academy of Sciences of the United States of America, 2008,105(18):6650-6655. pmid: 18436642
[29]	FU K Y, LI Q, ZHOU L T, MENG Q W, LÜ F G, GUO W C, LI G Q. Knockdown of juvenile hormone acid methyl transferase severely affects the performance of Leptinotarsa decemlineata (Say) larvae and adults. Pest Management Science, 2016,72(6):1231-1241. doi: 10.1002/ps.4103 pmid: 26299648
[30]	CHEN J, TANG B, CHEN H, YAO Q, HUANG X F, CHEN J, ZHANG D W, ZHANG W Q. Different functions of the insect soluble and membrane-bound trehalase genes in chitin biosynthesis revealed by RNA interference. PLoS ONE, 2010,5(4):e10133. doi: 10.1371/journal.pone.0010133 pmid: 20405036
[31]	徐亚玲, 李文楚. 昆虫酚氧化酶作用机制的研究进展. 安徽农业科学, 2010,38(27):14844-14846.
	XU Y L, LI W C. Research progress in activation mechanisms of phenoloxidse in insects. Journal of Anhui Agricultural Sciences, 2010,38(27):14844-14846. (in Chinese)
[32]	刘守柱, 薛超彬, 罗万春. 黄粉虫幼虫体壁硬化过程中酚氧化酶活性的变化. 昆虫学报, 2009,52(9):941-945.
	LIU S Z, XUE C B, LUO W C. Phenoloxidase activity during cuticle sclerotization in larvae of Tenebrio molitor (Coleoptera: Tenebrionidae). Acta Entomologica Sinica, 2009,52(9):941-945. (in Chinese)
[33]	王荫长. 昆虫生物化学. 北京: 中国农业出版社, 2001: 245-270.
	WANG Y C. Insect Biochemistry Beijing: China Agriculture Press, 2001: 245-270. (in Chinese)
[34]	LI Y, WANG Y, JIANG H, DENG J. Crystal structure of Manduca sexta prophenoloxidase provides insights into the mechanism of type 3 copper enzymes. Proceedings of the National Academy of Sciences of the United States of America, 2009,106(40):17002-17006. doi: 10.1073/pnas.0906095106 pmid: 19805072
[35]	李国荣, 张士璀, 李红岩, 王昌留. 酚氧化酶研究概况Ⅰ: 特性、功能、分布和在胚胎发育中的变化. 海洋科学, 2003,27(4):4-8.
	LI G R, ZHANG S C, LI H Y, WANG C L. Advance on the study of phenoloxidase Ⅰ: Properties, functions, distribution and change during embryonic stage. Marine Sciences, 2003,27(4):4-8. (in Chinese)
[36]	杨伟克, 刘增虎, 钟健, 董占鹏. 家蚕眠期血淋巴酚氧化酶活性变化及其基因表达分析. 南方农业学报, 2019,50(2):391-396.
	YANG W K, LIU Z H, ZHONG J, DONG Z P. Variation of activity of phenoloxidase and its gene expression in hemolymph of Bombyx mori larvae during molting stage. Journal of Southern Agriculture, 2019,50(2):391-396. (in Chinese)

引物名称 Primer name	正向引物 Forward primer (5′-3′)	反向引物 Reverse primer (5′-3′)	产物长度 Length (bp)
qSf18s	CGCTACTACCGATTGAA	GGAAACCTTGTTACGACTT	165
qSfPPO1	GACTCTGCCTCCCTACACC	AGCGAGCGAACACGTTGC	176
dsSfPPO1	TGGGCATCAACCTACATCA	TGCTAACAGCCTCGTACAAAC	360
dsSfPPO1-T7	T7-TGGGCATCAACCTACATCA	T7-TGCTAACAGCCTCGTACAAAC	410
qSfPPO2-1	AGAACTCACCTCGCAACCA	CTGAAGATGCTGCACCCTAG	116
dsSfPPO2-1	AGCATCTTCAGCATCAGCCTTTC	T7-GGCATTCCCTCGGCGTTT	361
dsSfPPO2-1-T7	T7-AGCATCTTCAGCATCAGCCTTTC	GGCATTCCCTCGGCGTTT	411
qSfPPO2-2	TGCTCGCATCACTCATCT	ACAAATCTGTCCACCTCAA	177
dsSfPPO2-2	GGCATCAACCTACACCAT	CCCTGCGTATTTATCACC	383
dsSfPPO2-2-T7	T7-GGCATCAACCTACACCAT	T7-CCCTGCGTATTTATCACC	433
dsSfGFP	AAGGGCGAGGAGCTGTTCACCG	CAGCAGGACCATGTGATCGCGC
dsSfGFP-T7	T7-AAGGGCGAGGAGCTGTTCACCG	T7-CAGCAGGACCATGTGATCGCGC
