土壤侵蚀对紫色土坡耕地耕层物理及力学特性的影响

doi:10.3864/j.issn.0578-1752.2020.09.012

摘要/Abstract

摘要：

【目的】紫色土坡耕地是南方丘陵区农业生产重要的耕地资源,其耕层土壤退化主要为物理退化。为了探讨土壤侵蚀对紫色土坡耕地耕层物理特性及力学特性退化的影响,在耕层土壤退化分级的基础上,定量分析了不同侵蚀程度下紫色土坡耕地耕层物理、力学特性及土壤退化指数的变化特征。【方法】采用铲土侵蚀模拟试验方法,以未侵蚀地块为对照组（CK）,对比分析了侵蚀5 cm（S_-5）、10 cm（S_-10）、15 cm（S_-15）、20 cm（S_-20）条件下紫色土坡耕地耕层土壤渗透性、土壤力学特性及土壤退化指数变化特征,对坡耕地耕层物理、力学特性的退化程度进行了定量分析。【结果】（1）紫色土坡耕地不同侵蚀程度下耕层土壤渗透性为CK>S_-5>S_-10>S_-15>S_-20,土壤初始入渗率、稳定入渗率、平均入渗率、饱和导水率随着侵蚀程度加剧而降低,S_-20土壤渗透性能最差;不同侵蚀程度下紫色土坡耕地均表现为0—20 cm土层的土壤渗透性指标高于20—40 cm土层的。（2）紫色土坡耕地不同侵蚀程度耕层土壤力学性质为CK-5-10-15-20,土壤抗剪强度、土壤紧实度随侵蚀程度加剧而增加。不同侵蚀程度下紫色土坡耕地各层土壤力学指标均表现为0—20 cm土层的高于20—40 cm土层的。（3）土壤抗剪强度对第一轴贡献率最大,土壤抗剪强度是影响不同侵蚀程度下紫色土坡耕地土壤物理性质及力学特性变化的主要因素。紫色土坡耕地土壤物理性质及力学特性与第一轴相关性排序表现为稳定入渗率>土壤紧实度>饱和导水率>平均入渗率>初始入渗率>抗剪强度。（4）不同侵蚀程度下紫色土坡耕地土壤退化指数大小为S_-5（-8.71%）>S_-10（-10.95%）>S_-20（-12.17%）>S_-15（-15.37%）,S_-15处理对耕层物理性质影响最大,S_-15土壤退化指数最小,土壤退化程度为重度退化。不同侵蚀条件下,紫色土坡耕地土壤退化指数10—20 cm土层的最大,土壤退化对10—20 cm土层影响最小。【结论】紫色土坡耕地土壤退化现象严重,不同侵蚀程度土壤的退化等级分为4级,分别为未退化、轻度退化、中度退化、重度退化。研究结果可为坡耕地耕层质量退化过程辨识及恢复调控提供技术参数。

关键词: 紫色土, 土壤侵蚀, 坡耕地, 耕层, 土壤退化作用, 土壤物理特性

Abstract:

【Objective】Purple soil slope farmland is an important cultivated land resource for agricultural production in southern hilly area. In order to study the effects of soil erosion on the physical properties and mechanical properties degradation of purple soil slope arable land, based on the classification of soil degradation, the change characteristics of physical and mechanical properties and soil degradation index under different erosion degrees were quantitatively analyzed. 【Method】With non-eroded plots as control group, the soil permeability, soil mechanical properties and soil degradation index of cultivated-layer were compared and analyzed under 5 cm (S_-5), 10 cm (S_-10), 15 cm (S_-15) and 20 cm (S_-20) erosion conditions by shovel soil erosion simulation test method, and the degradation degree of physical and mechanical properties of sloping farmland was quantitatively analyzed. 【Result】Soil permeability of cultivated-layer under different erosion degrees was CK>S_-5>S_-10>S_-15>S_-20. The initial infiltration rate, stable infiltration rate, average infiltration rate and saturated water conductivity of soil decreased with the increase of erosion degree. Soil permeability index of each layer under different erosion degrees was 0-20 cm soil layer>20-40 cm soil layer. Soil mechanical properties of different erosion degrees were CK-5-10-15-20. Soil shear strength and soil compacted degree increased with erosion degree. Soil mechanical indexes of all layers under different erosion degrees were 0-20 cm soil layer<20-40 cm soil layer. The contribution rate of soil shear strength to the first axis was the largest, and soil shear strength was the main factor affecting the change of soil physical properties and mechanical properties under different erosion degrees. Soil physical properties and mechanical properties were ranked as stable infiltration rate>soil compaction>saturated water conductivity>average infiltration rate>initial infiltration rate>shear strength. Soil degradation index of under different erosion degrees was S_-5 (-8.71%)>S_-10 (-10.95%)>S_-20 (-12.17%)>S_-15 (-15.37%). S_-15 had the greatest influence on the topsoil physical properties, and the S_-15 soil degradation index was the smallest, with the degree of soil degradation being severe. 【Conclusion】Soil compaction was serious in slope farmland of purple soil. According to soil infiltration and mechanical properties, the soil degradation grade with different erosion degree could be classified into four grades: undegraded, mild degradation, moderate degradation and severe degradation. The results could provide the technical parameters for the identification and restoration control of the quality degradation process of sloping farmland.

Key words: purple soil, soil erosion, slope farmland, top layer, soil degradation, physical characteristics of soil

江娜,史东梅,蒋光毅,宋鸽,司承静,叶青. 土壤侵蚀对紫色土坡耕地耕层物理及力学特性的影响[J]. 中国农业科学, 2020, 53(9): 1845-1859.

Na JIANG,DongMei SHI,GuangYi JIANG,Ge SONG,ChengJing SI,Qing YE. Effects of Soil Erosion on Physical and Mechanical Properties of Cultivated Layer of Purple Soil Slope Farmland[J]. Scientia Agricultura Sinica, 2020, 53(9): 1845-1859.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2020.09.012

https://www.chinaagrisci.com/CN/Y2020/V53/I9/1845

图/表 14

表1

图1

图2

表2

表3

图3

表4

图4

表5

表6

图5

图6

表7

表8

参考文献 32

[1]	中国科学院成都分院土壤研究室. 中国紫色土(Ⅰ). 北京: 科学出版社, 1991.
	Department of Soil Research, Chengdu Branch, Chinese Academy of Sciences. Purple Soil of China(I). Beijing: Science Press, 1991. (in Chinese)
[2]	WANG S S, SUN B X, LI C D, LI Z B, MA B . Runoff and soil erosion on slope cropland: A review. Journal of Resources and Ecology, 2018,9(5):461-470. doi: 10.5814/j.issn.1674-764x.2018.05.002
[3]	韩晓增, 邹文秀, 陆欣春, 段景海 . 旱作土壤耕层及其肥力培育途径. 土壤与作物, 2015,4(4):145-150.
	HAN X Z, ZOU X W, LU X C, DUANG J H . The soil cultivated layer in dryland and technical patterns in cultivating soil fertility. Soil and Crop, 2015,4(4):145-150. (in Chinese)
[4]	苏正安, 张建辉, 聂小军 . 紫色土坡耕地土壤物理性质空间变异对土壤侵蚀的响应. 农业工程学报, 2009,25(5):54-60.
	SU Z A, ZHANG J H, NIE X J . Response of spatial variability of soil physical properties to soil erosion in purple soil slope farmland. Transactions of the Chinese Society of Agricultural Engineering, 2009,25(5):54-60. (in Chinese)
[5]	黄少燕, 查轩 . 坡耕地侵蚀过程与土壤理化特性演变. 山地学报, 2002,20(3):290-295.
	HUANG S Y, CHA X . Study on soil erosion process and evolution of soil physicochemisty characteristics on sloping farmland. Journal of Mountain Research, 2002,20(3):290-295. (in Chinese)
[6]	葛方龙, 张建辉, 苏正安, 聂小军 . 坡耕地紫色土养分空间变异对土壤侵蚀的响应. 生态学报, 2007(2):459-464.
	GE F L, ZHANG J H, SU Z A, NIE X J . Response of changes in soil nutrients to soil erosion on a purple soil of cultivated sloping land. Acta Ecologica Sinica, 2007(2):459-464. (in Chinese)
[7]	史德明, 韦启潘 . 中国南方侵蚀土壤退化指标体系研究. 水土保持学报, 2000,14(3):1-9.
	SHI D M, WEI Q P . Research on index system of eroded soil degradation in southern China. Journal of Soil and Water Conservation, 2000,14(3):1-9. (in Chinese)
[8]	史东梅, 蒋光毅, 蒋平, 娄义宝, 丁文斌, 金慧芳 . 土壤侵蚀因素对紫色丘陵区坡耕地耕层质量影响. 农业工程学报, 2017,33(13):270-279.
	SHI D M, JIANG G Y, JIANG P, LOU Y B, DING W B, JIN H F . Effects of soil erosion factors cultivated-layer quality of slope farmland in purple hilly area. Transactions of the Chinese Society of Agricultural Engineering, 2017,33(13):270-279. (in Chinese)
[9]	LARNEY F J, JANZEN H H, OLSON B M, WAYNE L C . Soil quality and productivity responses to simulated erosion and restorative amendments. Canadian Journal of Soil Science, 2000,80(3):515-522.
[10]	OYEDELE D J, AINA P O . Response of soil properties and maize yield to simulated erosion by artificial topsoil removal. Plant & Soil, 2006,284(1/2):375-384.
[11]	刘慧, 魏永霞 . 黑土区土壤侵蚀厚度对土地生产力的影响及其评价. 农业工程学报, 2014,30(20):288-296.
	LIU H, WEI Y X . Influence of soil erosion thickness on soil productivity of black soil and its evaluation. Transactions of the Chinese Society of Agricultural Engineering, 2014,30(20):288-296. (in Chinese)
[12]	张瑞, 苟晓敏, 赵玉珍, 王志强 . 东北黑土区土壤侵蚀对土壤持水性的影响. 水土保持学报, 2015,29(1):62-65.
	ZHANG R, GOU X M, ZHAO Y Z, WANG Z Q . Effects of soil erosion on soil water retention in black soil region of Northeast China. Journal of Soil and Water Conservation, 2015,29(1):62-65. (in Chinese)
[13]	陈奇伯, 王克勤, 李金洪, 朱国进, 李跃 . 元谋干热河谷坡耕地土壤侵蚀造成的土地退化. 山地学报, 2004,22(5):528-532.
	CHEN Q B, WANG K Q, LI J H, ZHU G J, LI Y . Land degradation caused by soil erosion in slope farmland in dry-hot of Yuanmou county. Journal of Mountain Science, 2004,22(5):528-532. (in Chinese)
[14]	成婧, 吴发启, 王健, 云峰, 吴光艳, 于晓玲 . 渭北旱塬不同程度土壤侵蚀及生产力恢复试验. 中国水土保持科学, 2013,11(2):19-24.
	CHENG J, WU F Q, WANG J, YUN F, WU G Y, YU X L . Effects of soil erosion of different degrees on soil productivity and recovery in Weibei Dryland. Science of Soil and Water Conservation, 2013,11(2):19-24. (in Chinese)
[15]	LIU J X, TU S H, GUO Y Z, JIA Q H . Effect of soil erosion on productivity of sloping field in Mico-plot experiment. Agricultural Science & Technology, 2013,14(1):127-130. doi: 10.13227/j.hjkx.201703025 pmid: 29965201
[16]	ZHENG S U, ZHANG J H, NIE X J . Effect of soil erosion on soil properties and crop yields on slopes in the Sichuan Basin, China. Pedosphere, 2010,20(6):740-746. doi: 10.1002/(sici)1097-4598(199706)20:6&lt;740::aid-mus12&gt;3.0.co;2-y pmid: 9149082
[17]	王志强, 刘宝元, 王旭艳, 高晓飞, 刘刚 . 东北黑土区土壤侵蚀对土地生产力影响试验研究. 中国科学: 地球科学, 2009(10):1397-1412.
	WANG Z Q, LIU B Y, WANG X Y, GAO X F, LIU G . Experimental study on the effect of soil erosion on land productivity in black soil region of Northeast China. Science in China: Earth Science, 2009(10):1397-1412. (in Chinese)
[18]	中国科学院南京土壤研究所土壤物理研究室. 土壤物理性质测定方法. 北京: 科学出版社, 1978: 140-148.
	Department of Soil Physics, Institute of Soil Science, Chinese Academy of Sciences. Method for Determination of Soil Physical Properties. Beijing: Science Press, 1978:140-148. (in Chinese)
[19]	ADEJUWON J O, EKANADE O . A comparison of soil properties under different land use types in a part of the Nigerian cocoa belt. Catena, 1988,15(3):319-331. doi: 10.1016/0341-8162(88)90054-9
[20]	SHIRAZI M A, HART J W, BOERSMA L . A unifying quantitative analysis of soil texture: improvement of precision and extension of scale. Soil Science Society of America Journal, 1988,52(1):181. doi: 10.2136/sssaj1988.03615995005200010032x
[21]	金慧芳, 史东梅, 陈正发, 刘益军, 娄义宝, 杨旭 . 基于聚类及PCA分析的红壤坡耕地耕层土壤质量评价指标. 农业工程学报, 2018,34(7):155-164.
	JIN H F, SHI D M, CHEN Z F, LIU Y J, LOU Y B, YANG X . Evaluation indicators of cultivated layer soil quality for red soil slope farmland based on cluster and PCA analysis. Transactions of the Chinese Society of Agricultural Engineering, 2018,34(7):155-164. (in Chinese)
[22]	许明祥, 刘国彬, 赵允格 . 黄土丘陵区土壤质量评价指标研究. 应用生态学报, 2005,16(10):1843-1848. pmid: 16425459
	XU M X, LIU G B, ZHAO Y G . Assessment indicators of soil quality in hilly Loess Plateau. Chinese Journal of Applied Ecology, 2005,16(10):1843-1848. (in Chinese) pmid: 16425459
[23]	XU M, LI Q, WILSON G . Degradation of soil physicochemical quality by ephemeral gully erosion on sloping cropland of the hilly Loess Plateau, China. Soil & Tillage Research, 2016,155:9-18.
[24]	MA W M, ZHANG X C . Effect of Pisha sandstone on water infiltration of different soils on the Chinese Loess Plateau. Journal of Arid Land, 2016,8(3):331-340. doi: 10.1007/s40333-016-0122-8
[25]	林芳, 朱兆龙, 曾全超, 安韶山 . 延河流域三种土壤可蚀性K值估算方法比较. 土壤学报, 2017,54(5):1136-1146.
	LIN F, ZHU Z L, ZENG Q C, AN S S . Comparative study of three different methods for estimation of soil erodibility K in Yanhe Watershed of China. Acta Pedologica Sinica, 2017,54(5):1136-1146. (in Chinese)
[26]	周宁, 李超, 琚存勇, 马亚怀 . 黑龙江省土壤可蚀性K值特征分析. 农业工程学报, 2015,31(10):182-189.
	ZHOU N, LI C, QU C Y, MA Y H . Analysis of K-value characteristics of soil erodibility in Heilongjiang Province. Transactions of the Chinese Society of Agricultural Engineering, 2015,31(10):182-189. (in Chinese)
[27]	ZHANG K, LI L, ZHANG Z . Reliability of soil erodibility estimation in areas outside the US: A comparison of erodibility for main agricultural soils in the US and China. Environmental Earth Sciences, 2016,75(3):252. doi: 10.1007/s12665-015-4980-8
[28]	张慧利, 蔡洁, 夏显力 . 水土流失治理效益与生态农业发展的耦合协调性分析. 农业工程学报, 2018,34(8):162-169.
	ZHANG H L, CAI J, XIA X L . Coupling coordinative degree analysis on benefit of water and soil erosion control and development of ecological agriculture. Transactions of the Chinese Society of Agricultural Engineering, 2018,34(8):162-169. (in Chinese)
[29]	潘剑君, Ir. E. Bergsma. . 利用土壤入渗速率和土壤抗剪力确定土壤侵蚀等级. 水土保持学报, 1995(2):93-96.
	PAN J. Bergsma E . Determination of soil erosion grade using soil infiltration rate and soil shear resistance. Journal of Soil and Water Conservation, 1995(2):93-96. (in Chinese)
[30]	李卓, 吴普特, 冯浩, 赵西宁, 黄俊, 庄文化 . 容重对土壤水分入渗能力影响模拟试验. 农业工程学报, 2009,25(6):40-45.
	LI Z, WU P T, FENG H, ZHAO X N, HUANG J, ZHUANG W H . Simulated experiment on effect of soil bulk density on soil infiltration capacity. Transactions of the Chinese Society of Agricultural Engineering, 2009,25(6):40-45. (in Chinese)
[31]	李卓, 吴普特, 冯浩, 赵西宁, 黄俊, 庄文化 . 容重对土壤水分蓄持能力影响模拟试验研究. 土壤学报, 2010,47(4):611-620.
	LI Z, WU P T, FENG H, ZHAO X N, HUANG J, ZHUANG W H . Simulated experiment on effects of soil bulk density on soil water holding capacity. Acta Pedologica Sinica, 2010,47(4):611-620. (in Chinese)
[32]	WANG G Q, WU B, ZHANG L, JIANG H, XU Z X . Role of soil erodibility in affecting available nitrogen and phosphorus losses under simulated rainfall. Journal of Hydrology, 2014,514:180-191.

原始不同土层(h_i) Original different soil layers (cm)	模拟侵蚀深度/模拟侵蚀年限Simulated erosion depth (cm)/Simulated erosion age (a)
	0/0	5/20	10/40	15/60	20/80
	S_-0	S_-5	S_-10	S_-15	S_-20
0-20	20	15.55	12.09	9.40	5.50
20-25	-	4.45	3.46	2.69	3.90
25-30	-	-	4.45	3.46	2.69
30-35	-	-	-	4.45	3.46
35-40	-	-	-	-	4.45

	主成分 Principal component		Norm值 Norm value
	F₁	F₂	Norm值 Norm value
X₁饱和导水率Saturated hydraulic conductivity	0.021	0.997	1.02
X₂初始入渗率Initial soil infiltration	0.978	0.125	1.64
X₃稳定入渗率Stable infiltration rate	0.939	-0.161	1.58
X₄平均入渗率Average infiltration ratio	0.982	0.008	1.64
主成分特征值Principal component eigenvalue	2.802	1.036	-
主要方差贡献率Contribution rate of major variance	70.06	25.91	-
主要成分累积贡献率Cumulative contribution rate of major components	70.06	95.97	-

处理 Manage	0-10 cm		10-20 cm		20-30 cm		30-40 cm		平均得分 The average score	排序 The sorting	退化程度 Degradation
处理 Manage	得分 Score	排序 The sorting	得分 Score	排序 The sorting	得分 Score	排序 The sorting	得分 Score	排序 The sorting	平均得分 The average score	排序 The sorting	退化程度 Degradation
CK	3.06	1.00	1.23	1.00	0.50	2.00	0.25	2.00	1.26	1	未退化 Non degradation
S_-5	1.53	1.00	0.90	2.00	-0.07	3.00	-0.78	3.00	0.40	2	轻度退化 Mild degradation
S_-10	0.72	2.00	0.38	2.00	0.05	2.00	-0.74	3.00	0.10	2	轻度退化 Mild degradation
S_-15	0.19	2.00	-0.13	3.00	-1.25	4.00	-1.64	4.00	-0.71	3	中度退化 Moderate degradation
S_-20	0.06	2.00	-0.41	3.00	-1.59	4.00	-2.08	4.00	-1.01	4	重度退化 Severe degradation

	土壤容重 Soil bulk density	土壤总孔隙度 Soil total porosity	毛管孔隙度 Soil capillary porosity	砂粒Sand	粉粒 Silt	黏粒 Clay	饱和导水率 Saturated hydraulic conductivity	初始入渗率 Initial soil infiltration	平均入渗率 Average infiltration rate	稳定入渗率 Stable infiltration rate	抗剪强度 Soil shear strength	土壤紧实度 Soil compactibility
Z₁	1
Z₂	-1.000**	1
Z₃	-0.696**	0.698**	1
Z₄	0.655**	-0.655**	-0.517*	1
Z₅	-0.770**	0.770**	0.549*	-0.978**	1
Z₆	0.880**	-0.881**	-0.741**	0.429	-0.561*	1
X₁	-0.859**	0.858**	0.697**	-0.774**	0.841**	-0.824**	1
X₂	-0.924**	0.923**	0.763**	-0.709**	0.789**	-0.873**	0.947**	1
X₃	-0.750**	0.749**	0.595**	-0.814**	0.843**	-0.614**	0.853**	0.857**	1
X₄	-0.935**	0.934**	0.788**	-0.684**	0.766**	-0.865**	0.909**	0.973**	0.872**	1
Y₅	0.889**	-0.890**	-0.696**	0.435	-0.572**	0.991**	-0.840**	-0.889**	-0.644**	-0.876**	1
Y₆	0.769**	-0.770**	-0.968**	0.547*	-0.606**	0.840**	-0.758**	-0.825**	-0.668**	-0.841**	0.807**	1

	Axis 1	Axis 2	Axis 3	Axis 4
特征值Eigenvalue	0.0023	0.0004	0.0003	0
解释变异（累计）Explained variation (cumulative)	73.50	86.03	94.57	94.85
Pseudo-canonical相关性Pseudo-canonical correlation	0.9950	0.9847	0.8347	0.7174
解释拟合变异（累积）Explained fitted variation (cumulative)	77.48	90.70	99.70	100.00
