中国农业科学 ›› 2019, Vol. 52 ›› Issue (23): 4350-4363.doi: 10.3864/j.issn.0578-1752.2019.23.015

• 专题:苹果分子生物学 • 上一篇    下一篇

柱状苹果Co基因的筛选与候选基因分析

白团辉(),李莉,郑先波,王苗苗,宋尚伟,焦健,宋春晖()

  1. 河南农业大学园艺学院/河南省果树瓜类生物学重点实验室,郑州 450002
  • 收稿日期:2019-07-17 接受日期:2019-09-06 出版日期:2019-12-01 发布日期:2019-12-01
  • 通讯作者: 白团辉,宋春晖
  • 基金资助:
    国家重点研发计划(2018YFD1000300);河南省高等学校青年骨干教师培养计划(2018GGJS029);河南省自然科学基金(162300410132);河南省教育厅科学技术研究重点项目(13A210475)

Screening and Expression Analysis of Co Candidate Genes in Columnar Apple

BAI TuanHui(),LI Li,ZHENG XianBo,WANG MiaoMiao,SONG ShangWei,JIAO Jian,SONG ChunHui()

  1. College of Horticulture, Henan Agricultural University/Henan Key Laboratory of Fruit and Cucurbit Biology, Zhengzhou 450002
  • Received:2019-07-17 Accepted:2019-09-06 Online:2019-12-01 Published:2019-12-01
  • Contact: TuanHui BAI,ChunHui SONG

摘要:

【目的】柱状苹果是一种特殊的矮生突变类型,其节间短、短枝多、侧生分枝少、主干粗壮直立,是苹果实行矮化密植栽培的重要资源。本研究在前期Co精细定位的基础上,对定位区间的基因进行筛选,为阐明柱状苹果形成的分子机制和选育柱状苹果新品种奠定基础。【方法】以柱状苹果‘舞佳’和‘润太一号’,普通型苹果‘富士’和‘华硕’的芽、茎尖和叶片为试材,根据最新的苹果基因组以及与柱状相关的转录组信息,对Co精细定位区间27.66—29.05 Mb的基因进行注释分类,选择目标基因,查找其CDS序列,使用RT-PCR技术检测引物特异性,利用实时荧光定量PCR分析预测基因在不同组织器官中的表达特征,筛选出差异基因并将其作为候选基因。【结果】在苹果第10号染色体27.66—29.05 Mb区域内包含67个基因,其中12个为非编码RNA(ncRNA),其余为编码蛋白质的基因。根据RNA-seq分析,柱状和普通型苹果基因相对表达差异倍数在1倍以上的有25个基因,其中13个基因在柱状苹果中上调表达,12个基因在柱状苹果中下调表达。在预测的14个基因中,发现4个基因MD10G1184100、MD10G1185400、MD10G1185600和MD10G1190500在柱状和普通型苹果的主枝茎尖或侧枝茎尖中相对表达存在显著差异。其中,MD10G1184100和MD10G1185600在两个柱状苹果主枝茎尖中的相对表达量均显著高于两个普通型苹果。MD10G1185400和MD10G1190500在两个柱状苹果侧枝茎尖的表达量显著高于两个普通型苹果,而MD10G1184100在两个柱状苹果中的表达量显著低于普通型苹果。进一步对这4个候选基因进行不同组织或器官的基因表达特征进行分析,发现基因MD10G1184100在柱状苹果根部的表达显著高于其他部位,MD10G1185400和MD10G1185600在柱状苹果的侧枝茎尖中显著高表达,而MD10G1190500在柱状苹果的顶芽中显著高表达。【结论】在柱状和普通型苹果茎尖中筛选到4个表达显著差异的基因,可作为Co候选基因,为该基因的克隆和功能验证及苹果树树型定向遗传改良奠定了基础。

关键词: 苹果, 柱状树型, 基因定位, 基因表达, 候选基因

Abstract:

【Objective】Columnar growth in apple (Malus × domestica Borkh.) is a special type of dwarf mutation. Due to short internodes and lateral branches, a limited canopy and minimal pruning, columnar apple trees are well adapted to high density plantings. Based on the fine mapping of Co, the genes in the localization interval were screened, which laid a foundation for elucidating the molecular mechanism of columnar apple formation and breeding new varieties of columnar apples.【Method】Based on the latest apple genome data and transcriptome information, the buds, stem tips and leaves of columnar apple Wujia, Runtai No.1 and standard apple Fuji and Huashuo were used as test materials, and the genes between the fine mapping Co gene in interval from 27.66 Mb to 29.05 Mb were annotated and predicted. The coding sequence of the target gene was selected to detect primer specificity by RT-PCR, the real-time quantitative PCR was used to analyze the expression characteristics of target genes in different tissues and organs, and differential genes were screened out as candidate genes.【Result】The results showed that there were 67 genes between 27.66 Mb and 29.05 Mb in chromosome 10, 12 of which were non-coding RNAs (ncRNA), and the rest were genes with encoding proteins. According to the columnar and standard apple RNA-seq, there were 25 genes with more than 1 fold difference, 13 of which were up-regulated, and 12 genes were down-regulated in columnar apples. Among the 14 predicted genes, there were significant differences in the relative expression of the four genes MD10G1184100, MD10G1185400, MD10G1185600 and MD10G1190500 between shoot tips and lateral shoot tips in columnar and standard apples. The relative expression levels of MD10G1184100 and MD10G1185600 in the tip of terminal bud of two columnar apples were significantly higher than those of both standard apples. The relative expression of MD10G1185400 and MD10G1190500 genes in the tip of lateral bud of two columnar apples was significantly higher than that of two standard apples, while the expression of MD10G1184100 gene in two columnar apples was significantly lower than that of standard apples. The gene expression patterns of different tissues or organs of four candidate genes were analyzed. The result showed that the expression of MD10G1184100 gene in the roots of columnar apples was significantly higher than that in other tissues. The MD10G1185400 and D10G1185600 genes were significantly expressed in lateral tips in columnar apples, while MD10G1190500 gene was prominently expressed in the terminal bud of columnar apples.【Conclusion】4 genes with significant differences in columnar and standard apple could be regarded as Co candidate genes, which laid a foundation for gene cloning and functional verification and apple tree-oriented genetic improvement.

Key words: apple, columnar trait, gene mapping, gene expression, candidate gene analysis
