柑橘黄化花叶病毒的实时定量PCR检测及其在寄主植株中的时空分布规律

doi:10.3864/j.issn.0578-1752.2023.18.007

摘要/Abstract

摘要：

【背景】柑橘黄化花叶病毒（citrus yellow mosaic virus，CYMV）是首先发现于印度并对其柑橘产业造成严重危害的一种杆状DNA病毒。目前，CYMV已被美国、日本、新西兰、欧洲和地中海地区列入检疫性有害生物名单，具有传入我国的潜在风险。【目的】建立CYMV的实时荧光定量PCR（real-time quantitative PCR，qPCR）检测体系；筛选CYMV敏感柑橘品种；明确CYMV在寄主植株中的时空分布规律，为该病毒的监控提供技术支持。【方法】根据NCBI中CYMV外壳蛋白（coat protein，CP）基因保守序列，利用软件Primer Premier 5设计qPCR检测引物8对，通过常规PCR筛选扩增效果好、特异性强的引物。通过对引物浓度、退火温度等反应条件优化，建立CYMV的qPCR检测体系，并进一步通过对不同柑橘病原的检测评价所建体系的特异性；以梯度稀释的1.98×10⁹—1.98 copies/μL的质粒标准品平行进行常规PCR及qPCR检测，评价所建方法的灵敏度；随机采集田间柑橘样品，平行进行常规PCR及qPCR检测，评价所建方法的适用性。将CYMV接种到玉环柚（Citrus grandis）、强德勒柚（C. grandis）、22号枳（Poncirus trifoliata）等15个柑橘品种，进行症状观察和分子检测以筛选敏感指示植物。在接种后不同时间，分别自MV甜橙（C. sinensis）植株不同组织部位取样，以柑橘生长因子1α基因为内参基因，利用所建体系进行qPCR检测，从而明确CYMV在寄主植株中的时空分布规律。【结果】建立了CYMV的qPCR检测体系，其最佳引物为CYMV-qF7/R7，最佳引物浓度为200 nmol·L^-1，最佳退火温度为63 ℃。该检测体系的特异性强，检测灵敏度是常规PCR的1 000倍。对来自不同地区的660个田间柑橘样品的检测结果表明，qPCR检测与常规PCR检测结果一致，除阳性对照外均未检测到CYMV阳性植株。不同柑橘品种接种试验结果表明，15个柑橘品种中，玉环柚和强德勒柚最早表现出强烈的黄化花叶典型侵染症状，可以作为敏感指示植物。qPCR检测结果表明，老叶中的CYMV滴度最高，老皮和根病毒滴度较高，嫩皮中的滴度较低。CYMV在植株中的相对含量，7—9月最高，此后逐月下降，并在次年1月达到最低值，从次年2月开始，CYMV的相对含量开始上升，与环境温度变化趋势一致。【结论】建立了特异性强、灵敏度高的CYMV实时荧光定量PCR检测方法，利用该方法明确了CYMV在寄主植株中的时空分布规律。此外，玉环柚和强德勒柚可作为CYMV敏感指示植物。

关键词: 柑橘黄化花叶病毒, 实时荧光定量PCR, 时空分布

Abstract:

【Background】Citrus yellow mosaic virus (CYMV) is a member of badnaviruses that was first discovered in India and caused serious damage to its citrus industry. At present, CYMV has been listed as a quarantine pest in the United States, Japan, New Zealand, Europe and the Mediterranean region, which has the potential risk of being introduced into China.【Objective】The objective of this study is to establish a real-time quantitative PCR (qPCR) detection system for CYMV, screen sensitive citrus varieties to CYMV, elucidate the spatial and temporal distribution of CYMV in host plant, and to provide technical support for monitoring of the virus.【Method】According to the conserved sequences of CYMV coat protein (CP) gene in NCBI, eight pairs of qPCR primers were designed using software Primer Premier 5, and were screened by conventional PCR for primer pairs with good amplification effect and high specificity. The concentration and annealing temperature of the primers were optimized to establish the CYMV qPCR detection system. The specificity of the system was evaluated by detecting different citrus pathogens. Conventional PCR and qPCR were performed in parallel with 1.98×10⁹-1.98 copies/μL of plasmid standards diluted in a gradient as template to evaluate the sensitivity of the established system. The field citrus samples were collected randomly and detected using conventional PCR and qPCR in parallel to evaluate the applicability of the method. Fifteen citrus varieties including Yuhuanyou (Citrus grandis), Chandler pomelo (C. grandis), No.22 karatachi (Poncirus trifoliata), etc., were inoculated with CYMV for symptom observation and molecular detection to screen sensitive indicator plants. Samples from different tissues of Madam Vinous orange (C. sinensis) plants were collected at different times post inoculation, and qPCR assays were performed with C. sinensis elongation factor 1 alpha as an internal reference gene to clarify the spatial and temporal distribution patterns of CYMV in the host plants.【Result】The qPCR detection system for CYMV was established with the optimal primer of CYMV-qF7/R7, the optimal concentration 200 nmol·L^-1 and the optimal annealing temperature 63 ℃. The results of the evaluation experiments showed that the specificity of the established qPCR system is strong, and the detection sensitivity is 1 000 times that of the conventional PCR. The detection results of 660 field citrus samples from different regions showed that the qPCR assay was consistent with the conventional PCR assay, and no CYMV-positive plants were detected except for the positive control. Among the 15 citrus varieties in the inoculation experiment, Yuhuanyou and Chandler pomelo showed strong and typical yellowing mosaic symptoms of CYMV infection at the earliest, suggesting that both could be used as sensitive indicator plants. The detection results of qPCR showed that the titer of CYMV in old leaves was the highest, the titer of virus in old cortex and root was higher, and the titer in tender cortex was lower. The relative content of CYMV in plants was highest from July to September, then decreased month by month, and reached the lowest value in January of the next year. From February of the next year, the relative content of CYMV began to rise, which was consistent with the change trend of the environmental temperature.【Conclusion】A qPCR assay for CYMV detection with high specificity and sensitivity was established, and the spatial and temporal distribution pattern of CYMV in the host plants was determined. In addition, Yuhuanyou and Chandler pomelo can be used as CYMV-sensitive indicator plants.

Key words: citrus yellow mosaic virus (CYMV), real-time quantitative PCR (qPCR), spatial and temporal distribution

曹鹏, 许建建, 李楚欣, 王新亮, 王春庆, 宋晨虎, 宋震. 柑橘黄化花叶病毒的实时定量PCR检测及其在寄主植株中的时空分布规律[J]. 中国农业科学, 2023, 56(18): 3574-3584.

CAO Peng, XU JianJian, LI ChuXin, WANG XinLiang, WANG ChunQing, SONG ChenHu, SONG Zhen. Real-Time Quantitative PCR Detection of Citrus Yellow Mosaic Virus and Its Spatial and Temporal Distribution in Host Plants[J]. Scientia Agricultura Sinica, 2023, 56(18): 3574-3584.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2023.18.007

https://www.chinaagrisci.com/CN/Y2023/V56/I18/3574

图/表 6

表1

图1

表2

图2

图3

图4

参考文献 32

[1]	DAKSHINAMURTI V, REDDY G S. Mosaic: A transmissible disorder of sweet oranges. Indian Phytopathology, 1975, 28: 398-399.
[2]	PRINGLE C R. The universal system of virus taxonomy of the International Committee on Virus Taxonomy ICTV, including new proposals ratified since publication of the sixth ICTV report in 1995. Archives of Virology, 1998, 143(1): 203-210.
[3]	HUANG Q, HARTUNG J S. Cloning and sequence analysis of an infectious clone of citrus yellow mosaic virus that can infect sweet orange via Agrobacterium-mediated inoculation. The Journal of General Virology, 2001, 82(10): 2549-2558. doi: 10.1099/0022-1317-82-10-2549
[4]	MASON W S, TAYLOR J M, HULL R. Retroid virus genome replication//Advances in Virus Research. Amsterdam: Elsevier, 1987: 35-96.
[5]	AHLAWAT Y S. Citrus decline: Problems and prevention. Indian Phytopathology, 2007, 60: 1-12.
[6]	JOHNSON A M, GOPAL D V R, SUDHAKAR C, DASGUPTA I. Citrus yellow mosaic badnavirus infecting Citrus sp.:A threat to the citrus industry and a quarantine issue. Journal of General Plant Pathology, 2017, 83(2): 57-65. doi: 10.1007/s10327-017-0702-2
[7]	European Food Safety Authority. Pest risk assessment made by France on citrus yellow mosaic virus or citrus mosaic badnavirus considered by France as harmful in the French overseas departments of French Guiana, Guadeloupe, Martinique and Réunion - Scientific opinion of the panel on plant health. The EFSA Journal, 2008, 6(5): 686. doi: 10.2903/j.efsa.2008.686
[8]	DAKSHINAMURTI V. Investigations on mosaic virus disease of Sathgudi (Citrus sinensis (L) Osb) in Andhra Pradesh[D]. Tirupati, India: Sri Venkateswara University, 1981.
[9]	AHLAWAT Y S, PANT R P, LOCKHART B E L, SRIVASTAVA M, CHAKRABORTY N K, VARMA A. Association of a badnavirus with citrus mosaic disease in India. Plant Disease, 1996, 80(5): 590-592. doi: 10.1094/PD-80-0590
[10]	BHAT A I, HOHN T, SELVARAJAN R. Badnaviruses: The current global scenario. Viruses, 2016, 8(6): 177. doi: 10.3390/v8060177
[11]	BARANWAL V K, SHARMA S K. Emergence and diversity of badnaviruses in India//A Century of Plant Virology in India. Singapore: Springer, 2017: 49-73.
[12]	蒋琪琪, 许建建, 苏越, 张琦, 曹鹏, 宋晨虎, 李中安, 宋震. 柑橘黄化花叶病毒侵染性克隆构建及应用. 中国农业科学, 2022, 55(24): 4840-4850. doi: 10.3864/j.issn.0578-1752.2022.24.005. doi: 10.3864/j.issn.0578-1752.2022.24.005
	JIANG Q Q, XU J J, SU Y, ZHANG Q, CAO P, SONG C H, LI Z A, SONG Z. Construction and application of infectious clone of citrus yellow mosaic virus. Scientia Agricultura Sinica, 2022, 55(24): 4840-4850. doi: 10.3864/j.issn.0578-1752.2022.24.005. (in Chinese) doi: 10.3864/j.issn.0578-1752.2022.24.005
[13]	GADDAM S A, KOTAKAD V S, REDDY M N, SAIGOPAL D. Survey and indexing of citrus yellow mosaic virus infecting citrus species in rayalaseema region of Andhra Pradesh. Archives of Applied Science Research, 2012, 4(4): 1821-1824.
[14]	MOTGHARE M, DHAR A K, KOKANE A, WARGHANE A, KOKANE S, SHARMA A K, REDDY M K, GHOSH D K. Quantitative distribution of citrus yellow mosaic badnavirus in sweet orange (Citrus sinensis) and its implication in developing disease diagnostics. Journal of Virological Methods, 2018, 259: 25-31. doi: S0166-0934(18)30208-8 pmid: 29859966
[15]	SINGH R P, DILWORTH A D, BARANWAL V K, GUPTA K N. Detection of citrus exocortis viroid, iresine viroid, and tomato chlorotic dwarf viroid in new ornamental host plants in India. Plant Disease, 2006, 90(11): 1457. doi: 10.1094/PD-90-1457A pmid: 30780914
[16]	BORAH B K, JOHNSON A M, GOPAL D V R, DASGUPTA I. A comparison of four DNA extraction methods for the detection of citrus yellow mosaic badna virus from two species of Citrus using PCR and dot-blot hybridization. Journal of Virological Methods, 2008, 151(2): 321-324. doi: 10.1016/j.jviromet.2008.05.022
[17]	BARANWAL V K, MAJUMDER S, AHLAWAT Y S, SINGH R P. Sodium sulphite yields improved DNA of higher stability for PCR detection of citrus yellow mosaic virus from citrus leaves. Journal of Virological Methods, 2003, 112(1/2): 153-156. doi: 10.1016/S0166-0934(03)00188-5
[18]	GOPI V, SANKAR T, KURUBA G, LAKSHMI M. Molecular detection of citrus yellow mosaic virus (CYMV) and citrus greening bacterium (CGB) in Sathgudi sweet orange by duplex polymerase chain reaction (dPCR). International Journal of Current Microbiology and Applied Sciences, 2016, 5(12): 726-732. doi: 10.20546/ijcmas
[19]	GOPI V, GOPAL K, SANKAR T G, PALANIVEL S. Detection of citrus yellow mosaic virus by PCR and nucleic acid spot hybridisation using non-radioactive probes in commercial citrus species. Archives of Phytopathology and Plant Protection, 2010, 43(9): 892-899. doi: 10.1080/03235400802075740
[20]	KUMAR P V, SHARMA S K, RISHI N, GHOSH D K, BARANWAL V K. An isothermal based recombinase polymerase amplification assay for rapid, sensitive and robust indexing of citrus yellow mosaic virus. Acta Virologica, 2018, 62(1): 104-108. doi: 10.4149/av_2018_113 pmid: 29521109
[21]	JOHNSON A M, DASGUPTA I, GOPAL D V R. Development of loop-mediated isothermal amplification and SYBR green real-time PCR methods for the detection of citrus yellow mosaic badnavirus in citrus species. Journal of Virological Methods, 2014, 203: 9-14. doi: 10.1016/j.jviromet.2014.03.013 pmid: 24675064
[22]	GHOSH D K, AGLAVE B, BARANWAL V K. Simultaneous detection of one RNA and one DNA virus from naturally infected citrus plants using duplex PCR technique. Current Science, 2008, 94(10): 1314-1318.
[23]	JOHNSON A M. Genomics development of diagnostics of citrus yellow mosaic badnavirus (CMBV) infecting citrus species and partial characterization of zucchini yellow mosaic virus (ZYMV) isolates infecting Cucurbits in Andhra Pradesh[D]. India: Sri Venkateswara University, 2011.
[24]	王艳娇, 崔甜甜, 黄爱军, 陈洪明, 李中安, 周常勇, 宋震. 柑橘脉突病毒实时荧光定量RT-PCR检测体系的建立与应用. 园艺学报, 2016, 43(8): 1613-1620. doi: 10.16420/j.issn.0513-353x.2016-0150
	WANG Y J, CUI T T, HUANG A J, CHEN H M, LI Z A, ZHOU C Y, SONG Z. Development and application of a quantitative RT-PCR approach for quantification of citrus vein enation virus. Acta Horticulturae Sinica, 2016, 43(8): 1613-1620. (in Chinese)
[25]	李楠, 王亚迪, 杨军玉, 丁丽, 王亚南, 曹克强. 苹果褪绿叶斑病毒在苹果植株体内的分布. 北方园艺, 2018(13): 47-52.
	LI N, WANG Y D, YANG J Y, DING L, WANG Y N, CAO K Q. Spatial and temporal distribution of apple chlorotic leaf spot virus in apple plant. Northern Horticulture, 2018(13): 47-52. (in Chinese)
[26]	刘科宏, 周常勇, 宋震, 周彦, 李中安, 唐科志. 运用实时荧光RT-PCR技术检测柑橘碎叶病毒. 果树学报, 2009, 26(5): 748-751.
	LIU K H, ZHOU C Y, SONG Z, ZHOU Y, LI Z A, TANG K Z. Detection of citrus tatter leaf virus (CTLV) by real-time RT-PCR. Journal of Fruit Science, 2009, 26(5): 748-751. (in Chinese)
[27]	王莹. 高温抑制柠檬黄脉病症状表现的机理初探[D]. 重庆: 西南大学, 2022.
	WANG Y. Preliminary study on the mechanism of high temperature inhibiting the symptoms of lemon yellow vein clearing disease[D]. Chongqing: Southwest University, 2022. (in Chinese)
[28]	ZHANG X, ZHANG X, SINGH J, LI D W, QU F. Temperature- dependent survival of turnip crinkle virus-infected Arabidopsis plants relies on an RNA silencing-based defense that requires dcl2, AGO2, and HEN1. Journal of Virology, 2012, 86(12): 6847-6854. doi: 10.1128/JVI.00497-12
[29]	DING X S, FLASINSKI S, NELSON R S. Infection of barley by brome mosaic virus is restricted predominantly to cells in and associated with veins through a temperature-dependent mechanism. Molecular Plant-Microbe Interactions, 1999, 12(7): 615-623. doi: 10.1094/MPMI.1999.12.7.615
[30]	陶宁颖. ‘阳光玫瑰’葡萄病毒病原鉴定与脱毒技术研究[D]. 杭州: 浙江大学, 2019.
	TAO N Y. The research of the virus identification and elimination techniques on ‘Shine Muscat’ grape[D]. Hangzhou: Zhejiang University, 2019. (in Chinese)
[31]	徐振鹏, 邱隆, 杨婷, 林宏辉, 席德慧. 高温对本氏烟抗病毒机制影响的研究. 四川大学学报(自然科学版), 2019, 56(4): 749-757.
	XU Z P, QIU L, YANG T, LIN H H, XI D H. The research on the interaction between high temperature and viral defense mechanism in Nicotiana benthamiana. Journal of Sichuan University (Natural Science Edition), 2019, 56(4): 749-757. (in Chinese)
[32]	弟豆豆. 苹果坏死花叶病毒烟台分离物的鉴定与表达特性分析[D]. 烟台: 烟台大学, 2020.
	DI D D. Identification and analysis of expression characteristics of apple necrosis mosaic virus Yantai isolate[D]. Yantai: Yantai University, 2020. (in Chinese)

引物名称 Primer name	引物序列 Primer sequence (5′-3′)	扩增产物长度 Product length (bp)	用途 Usage
CYMV-CP-F	GATGAATATGAGAACCTTGTTACAACT	642	CP序列扩增 CP sequence amplification
CYMV-CP-R	TCGTTTCACATTTCGCCG	642	CP序列扩增 CP sequence amplification
CYMV-JC-F	ACACCGGAAACGGTGAAGTT	342	CYMV检测 CYMV detection
CYMV-JC-R	ACCCTTCGAACATGGGCATT	342	CYMV检测 CYMV detection
EF-1α F	CTCAAGCCTGGTATGGTGGT	185	内参基因 Reference gene
EF-1α R	GGATCATCCTTCGAGTTGGA	185	内参基因 Reference gene
CYMV-qF1	TTGGTGTTTGCCCTCGGATT	119	qPCR检测 qPCR detection
CYMV-qR1	GCCTGGGATAGGGATTGAGC	119
CYMV-qF2	TGGGCATAGTTCAGGTTCGG	93
CYMV-qR2	CTCCTTGCCACCGATTGTCT	93
CYMV-qF3	CCAGTCGTGCTCGTACAGTT	119
CYMV-qR3	CCGCTGCCACTGCCTATAAT	119
CYMV-qF4	CAGGAGTACATCGCCTGGTG	149
CYMV-qR4	TTTCGCCTGCGAGAGTCTAC	149
CYMV-qF5	CAAAGACTGGGCGCATGTTC	142
CYMV-qR5	AGAATCCGAGGGCAAACACC	142
CYMV-qF6	AACAGTTAAGCAGGAGCGGT	128
CYMV-qR6	TCCTTGCCACCGATTGTCTC	128
CYMV-qF7	GCTCAATCCCTATCCCAGGC	208
CYMV-qR7	ACATTTCGCCGGTCATTTGG	208
CYMV-qF8	TGCAAAGATGCAGCGTTCA	59
CYMV-qR8	GGGATTGAGCTGCAAAAGGA	59

地区 <BOLD>R</BOLD>egion	采集品种 Variety	常规PCR（阳性数/总数） Conventional PCR (Positive/Total)	qPCR（阳性数/总数） qPCR (Positive/Total)
广西Guangxi	砂糖橘C. reticulata	0/60	0/60
湖南Hunan	宫川温州蜜柑C. unshiu	0/150	0/150
湖南Hunan	纽荷尔脐橙C. sinensis	0/150	0/150
重庆Chongqing	柠檬C. limon	0/200	0/200
重庆Chongqing	沙田柚C. maxima ‘Shatian Yu’	0/100	0/100
阳性对照Positive control	MV甜橙C. sinensis	25/30	30/30
