根灌乙酸及葡萄酒对海水胁迫下葡萄光抑制的影响

doi:10.3864/j.issn.0578-1752.2018.21.019

摘要/Abstract

摘要：

【目的】为了扩大盐渍化土壤的高效利用方式,提高葡萄在盐渍化土壤上的生长发育质量,探讨乙酸与葡萄酒对15%海水胁迫下葡萄叶片光抑制的影响,为盐渍化土壤葡萄栽培技术改良提供理论依据和技术参考。【方法】以一年生‘摩尔多瓦’葡萄(‘Moldova’)盆栽苗为试材,定植于直径为20 cm、高度为18 cm的塑料盆内,每盆土和基质的比例为1﹕1,置于日光温室内。培养条件为日均温在25℃左右,温室内透光率不低于自然光照强度的50%,其中最高光强在800 μmol·m ^-2·s ^-1,相对湿度在40%—60%,正常肥水管理至8—10片完全展开叶时,进行海水和外源乙酸处理。进行15%海水浇灌的同时,分别浇灌30 mmol·L ^-1乙酸、2%葡萄酒,以浇灌清水为对照,每个处理重复5盆,各处理均浇灌3次,每隔2 d浇灌一次,浇灌量为基质持水量的2倍,约1/3的溶液流出, 每次浇灌后第2天测定叶绿素荧光指标,处理到第10天后,解析植株取样分析二者对海水胁迫下丙二醛(MDA)含量、叶绿素含量以及根系活力的影响。【结果】15%海水灌溉显著增加了葡萄各器官的MDA含量,显著降低了葡萄叶片叶绿素含量和根系活力,其中,与清水对照相比,根、茎、叶中MDA含量分别提高了1.10、0.27、0.41倍,叶绿素含量降低了18.5%,根系活力降低了41.9%,而浇灌30 mmol·L ^-1乙酸及2%葡萄酒处理显著降低了葡萄各器官中的MDA含量,其中,浇灌乙酸处理的根、茎、叶中MDA含量比海水胁迫分别降低了29.3%、20.6%、15.8%;浇灌葡萄酒处理的根、茎、叶中MDA含量分别比海水胁迫的降低了29.4%、20.2%、25.2%。浇灌乙酸及葡萄酒处理显著提高了葡萄叶片的叶绿素含量和根系活力,其中,根系活力分别比海水胁迫处理的显著提高了68.4%和56.9%,叶绿素含量则分别提高了18.8%和20.3%。叶绿素荧光分析表明,15%海水灌溉导致叶片光系统II（PSII）最大光化学效率(F_v/F_m)及最大光氧化P700 (P_m)明显下降,其中第3、6、9天的P_m分别比对照下降了5.0%、9.6%、13.0%,光化学淬灭系数(qP)和PSII实际光化学效率Y(II)逐渐下降,而PSII处可调节性能量耗散的量子产额Y(NPQ)及非调节性能量耗散的量子产额Y(NO)均逐渐升高,PSI供体端侧抑制程度Y(ND)未发生明显变化,但是PSI受体侧抑制程度Y(NA)逐渐升高,导致PSI的实际光化学效率Y(I)降低。根灌乙酸及葡萄酒可以显著缓解15%海水胁迫,PSII及PSI实际光化学效率显著升高,而用于热耗散的能量分配明显降低,从而提高了葡萄叶片的光合性能,其中以2%葡萄酒处理缓解效果较明显。【结论】根灌乙酸及葡萄酒显著提高15%海水胁迫下葡萄根系活力及叶绿素含量,缓解叶片光抑制程度,从而提高了葡萄对海水胁迫环境下的适应性,研究结果为残次果加工果酒、果渣及醋等的综合利用改良盐渍化土壤提供了理论依据。

关键词: 葡萄, 海水, 光抑制, 乙酸, 葡萄酒, 叶绿素荧光

Abstract:

【Objective】In order to expand the effective utilization of salinized soil and improve the quality of grape growth and development in salinized soil, the effects of acetic acid and wine on leaf photoinhibition under 15% seawater stress were studied. The result will provide a theoretical basis and technical reference for the improvement of grape cultivation techniques in salinized soil. 【Method】One-year old potted ‘Moldova’ seedlings were grown in plastic pots (with a diameter of 20 cm, and a height of 18 cm). The ratio of soil to substrate in each pot was 1﹕1 and the pots were placed in greenhouse. The culture conditions of the greenhouse were as follows: the average daily temperature was about 25℃, the light transmittance was more than 50% of natural light intensity, the maximum light intensity was 800 μmol·m ^-2·s ^-1, the relative humidity was 40%-60%, and the normal fertilizer and water was managed until 8-10 pieces of fully expanded leaves, then the seawater and exogenous acetic acid were used. The plants were irrigated with 15% seawater, 30 mmol·L ^-1 exogenous acetic acid and 2% wine at the same time, each treatment repeated 5 times, the controls were treated with clear water. Each treatment was irrigated every 2 days and 3 times, the irrigation amount was 2 times of water holding capacity, and about 1/3 of the solution leaked out, chlorophyll fluorescence indicators were determined on the 2nd day of irrigation, after 10 days treatment, the effects of the two methods on malondialdehyde (MDA) content, chlorophyll content, and root activity under seawater stress were analyzed.【Result】15% seawater treatment significantly decreased the chlorophyll content of leaf and root activity, but increased MDA content of root, stem and leaf. Compared with clear water control, the chlorophyll content decreased by 18.5% and root activity decreased by 41.9%. MDA content of root, stem and leaf increased by 1.10, 0.27 and 0.41 times, respectively. However, 30 mmol·L ^-1 acetic acid and 2% wine treatments significantly decreased the MDA content in grape. The MDA content in root, stem and leaf of grape treated with acetic acid decreased by 29.3%, 20.6% and 15.8%, respectively, compared with that of seawater stress, and the MDA content in root, stem and leaf of grape treated with wine decreased by 29.4%, 20.2% and 25.2%, respectively, compared with that of seawater stress. Irrigated with acetic acid and wine significantly increased the leaf chlorophyll content and root activity. Compared with seawater stress treatment, the root activity increased by 68.4% and 56.9%, and the chlorophyll content increased by 18.8% and 20.3%, respectively. The analysis of chlorophyll fluorescence showed that 15% seawater treatment decreased the levels of photosystem II (PSII) maximum photochemical efficiency (F_v/F_m) and the maximum photo-oxidizable P700 (P_m). The Pm on the 3rd, 6th, and 9th day decreased by 5.0%, 9.6% and 13.0% compared with the control, the levels of photochemical quenching coefficient (qP) and PSII actual photochemical efficiency (YII) decreased gradually, but the quantum yield of regulated energy dissipation Y (NPQ) and the quantum yield of non-regulated energy dissipation Y (NO) increased gradually. The nonphotochemical quantum yield due to PSI donor side limitation Y (ND) changed little, but the nonphotochemical quantum yield due to PSI acceptor side limitation Y (NA) increased gradually, resulting in the decrease of PSI actual photochemical efficiency Y (I). The irrigation of 30 mmol·L ^-1 acetic acid and 2% wine significantly relieved the stress of 15% seawater. The actual photochemical efficiency of PSI and PSII increased significantly, meanwhile the energy dissipated through heat decreased, then enhanced the efficiency of light energy utilization of grape leaves, in which 2% wine treatment showed a more obvious alleviated effect.【Conclusion】Irrigation of acetic acid and wine significantly improved root activity and chlorophyll content, which alleviated the photoinhibition level and improved the adaptability of grape to saline environment. The results provided a theoretical basis for the use of extract of wine lees to improvement of coastal saline soil.

Key words: grape, seawater, photoinhibition, acetic acid, wine, chlorophyll fluorescence

王辉,高玉录,于梦,杜远鹏,孙永江,翟衡. 根灌乙酸及葡萄酒对海水胁迫下葡萄光抑制的影响[J]. 中国农业科学, 2018, 51(21): 4210-4218.

Hui WANG,YuLu GAO,Meng YU,YuanPeng DU,YongJiang SUN,Heng ZHAI. Effect of Root Irrigation of Acetic Acid and Wine on Photoinhibition of Grape Under Seawater Stress[J]. Scientia Agricultura Sinica, 2018, 51(21): 4210-4218.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2018.21.019

https://www.chinaagrisci.com/CN/Y2018/V51/I21/4210

图/表 6

表1

表2

图1

图2

图3

图4

参考文献 36

[1]	王佳丽, 黄贤金, 钟太洋, 陈志刚 . 盐碱地可持续利用研究综述. 地理学报, 2011,66(5):673-684.
	WANG J L, HUANG X J, ZHONG T Y, CHEN Z G . Review on sustainable utilization of salt-affected land. Acta Geographica Sinica, 2011,66(5):673-684. (in Chinese)
[2]	刘建新, 王金成, 王瑞娟, 贾海燕 . 盐、碱胁迫对燕麦幼苗光合作用的影响. 干旱地区农业研究, 2015,33(6):155-160. doi: 10.7606/j.issn.1000-7601.2015.06.26
	LIU J X, WANG J C, WANG R J, JIA H Y . Effects of salt and alkali stress on photosynthesis in Avena nuda seedlings. Agricultural Research in the Arid Areas, 2015,33(6):155-160. (in Chinese) doi: 10.7606/j.issn.1000-7601.2015.06.26
[3]	吴运荣, 林宏伟, 莫肖蓉 . 植物抗盐分子机制及作物遗传改良耐盐性的研究进展. 植物生理学报, 2014,50(11):1621-1629.
	WU Y R, LIN H W, MO X R . Research progress in the mechanism of plant salt tolerance and genetic engineering of salt resistant crops. Plant Physiology Journal, 2014,50(11):1621-1629. (in Chinese)
[4]	牛东玲, 王启基 . 盐碱地治理研究进展. 土壤通报, 2002,33(6):449-455.
	NIU D L, WANG Q J . Research progress on saline-alkali field control. Chinese Journal of Soil Science, 2002,33(6):449-455. (in Chinese)
[5]	AHMAD P, SHARMA S . Physio-biochemical attributes in two cultivars of mulberry (Morus alba L.) under NaHCO₃ stress. International Journal of Plant Product, 2010,4(2):79-86. doi: 10.1111/j.1757-1707.2010.01043.x
[6]	刘卫国, 丁俊祥, 邹杰, 林喆, 唐立松 . NaCl对齿肋赤藓叶肉细胞超微结构的影响. 生态学报, 2016,36(12):3556-3563. doi: 10.5846/stxb201410122011
	LIU W G, DING J X, ZOU J, LIN Z, TANG L S . Ultrastructural responses of Syntrichia caninervis to a gradient of NaCl stress. Acta Ecologica Sinica, 2016,36(12):3556-3563. (in Chinese) doi: 10.5846/stxb201410122011
[7]	KALAJI H M, JAJOO A, OUKARROUM A, BRESTIC M, ZIVCAK M, SAMBORSKA I A, CETNER M D, ŁUKASIK I, GOLTSEV V, LADLE R J . Chlorophyll a fluorescence as a tool to monitor physiological status of plants under abiotic stress conditions. Acta Physiologiae Plantarum, 2016,38:102. doi: 10.1007/s11738-016-2113-y
[8]	CHENG T, CHEN J, ZHANG J, SHI S, ZHOU Y, LU L, WANG P, JIANG Z, YANG J, ZHANG S, SHI J . Physiological and proteomic analyses of leaves from the halophyte Tangut nitraria reveals diverse response pathways critical for high salinity tolerance. Frontiers in Plant Science, 2015,6:30. doi: 10.3389/fpls.2015.00030 pmid: 25713577
[9]	郭艳超, 王文成, 李克晔, 吴新海, 董文琦, 吴菲 . NaCl胁迫对八棱海棠幼苗生长及其生理指标的影响. 中国农学通报, 2011,27(28):130-134.
	GUO Y C, WANG W C, LI K Y, WU X H, DONG W Q, WU F . Effects of NaCl stress on the growth and some physiological indexes of Malus robusta Rehd. Chinese Agricultural Science Bulletin, 2011,27(28):130-134. (in Chinese)
[10]	DING H, LAI J, WU Q, ZHANG S, CHEN L, DAI Y S, WANG C, DU J, XIAO S, YANG C . Jasmonate complements the function of Arabidopsis lipoxygenase3 in salinity stress response. Plant Science, 2016,244:1-7. doi: 10.1016/j.plantsci.2015.11.009 pmid: 26810448
[11]	JIANG C Q, CUI Q R, FENG K, XU D F, LI C F, ZHENG Q S . Melatonin improves antioxidant capacity and ion homeostasis and enhances salt tolerance in maize seedlings. Acta Physiologiae Plantarum, 2016,38:82. doi: 10.1007/s11738-016-2101-2
[12]	KIM J M, TO T K, MATSUI A, TANOI K, KOBAYASHI N I, MATSUDA F, HABU Y, OGAWA D, SAKAMOTO T, MATSUNAGA S, BASHIR K, RASHEED S, ANDO M, TAKEDA H, KAWAURA K, KUSANO M, FUKUSHIMA A, ENDO T A, KUROMORI T, ISHIDA J, MOROSAWA T, TANAKA M, TORII C, TAKEBAYASHI Y, SAKAKIBARA H, OGIHARA Y, SAITO K, SHINOZAKI K, DEVOTO A, SEKI M . Acetate-mediated novel survival strategy against drought in plants. Nature Plants, 2017, 3: Article number 17097. doi: 10.1038/nplants.2017.97 pmid: 28650429
[13]	赵世杰, 史国安, 董新纯 . 植物生理学实验指导. 北京: 中国农业科学技术出版社, 2015: 55-57, 142-143.
	ZHAO S J, SHI G A, DONG X C. Experimental Instruct of Plant Physiology. Beijing: China Agricultural Science and Technology Press, 2015: 55-57, 142-143. (in Chinese)
[14]	PFÜNDEL E, KLUGHAMMER C, SCHREIBER U . Monitoring the effects of reduced PS II antenna size on quantum yields of photosystems I and II using the Dual-PAM-100 measuring system. PAM Application Notes, 2008,1:21-24.
[15]	蒋金豹, 陈云浩, 黄文江 . 用高光谱微分指数估测条锈病胁迫下小麦冠层叶绿素密度. 光谱学与光谱分析, 2010,30(8):2243-2247.
	JIANG J B, CHEN Y H, HUANG W J . Using hyperspectral remote sensing to estimate canopy chlorophyll density of wheat under yellow rust stress. Spectroscopy and Spectral Analysis, 2010,30(8):2243-2247. (in Chinese)
[16]	HUANG W, FU P L, JIANG Y J, ZHANG J L, ZHANG S B, HU H, CAO K F . Differences in the responses of photosystem I and photosystem II of three tree species Cleistanthus sumatranus, Celtis philippensis and Pistacia weinmannifolia exposed to a prolonged drought in a tropical limestone forest. Tree Physiology, 2013,33(2):211-220.
[17]	赵鹏志, 陈祥伟, 杨小燕, 齐思明, 王恩姮 . 低分子有机酸对东北黑土酶活性与养分关系的影响. 南京林业大学学报(自然科学版), 2018,42(1):105-112.
	ZHAO P Z, CHEN X W, YANG X Y, QI S M, WANG E H . Relationship between enzyme activities and nutrients of black soil subjected to low molecular organic acid. Journal of Nanjing Forestry University (Natural Sciences Edition), 2018,42(1):105-112. (in Chinese)
[18]	丁永祯, 李志安, 邹碧 . 土壤低分子量有机酸及其生态功能. 土壤, 2005,37(3):243-250. doi: 10.3321/j.issn:0253-9829.2005.03.004
	DING Y Z, LI Z A, ZOU B . Low-molecular-weight organic acids and their ecological roles in soil. Soils, 2005,37(3):243-250. (in Chinese) doi: 10.3321/j.issn:0253-9829.2005.03.004
[19]	吴雪, 杨晓婷, 王冰, 王林, 疏伟慧, 张丽丽, 韩玉林 . 外源乙酸和EDTA对铜尾矿矿砂中芦苇幼苗生长及部分金属元素积累的影响. 植物资源与环境学报, 2011,20(4):29-34.
	WU X, YANG X T, WANG B, WANG L, SHU W H, ZHANG L L, HAN Y L . Effects of exogenous acetic acid and EDTA on growth and accumulation of some metal elements of Phragmites australis seedling in copper tailing ore. Journal of Plant Resources and Environment, 2011,20(4):29-34. (in Chinese)
[20]	刘建新, 王鑫, 王瑞娟, 李东波 . 碱胁迫对黑麦草幼苗根系活性氧代谢和渗透溶质积累的影响. 植物研究, 2011,31(6):674-679.
	LIU J X, WANG X, WANG R J, LI D B . Effects of alkaline stress on the metabolism of reactive oxygen species and osmotic accumulation in ryegrass seedling roots. Bulletin of Botanical Research, 2011,31(6):674-679. (in Chinese)
[21]	王振兴, 吕海燕, 秦红艳, 赵滢, 刘迎雪, 艾军, 曹建冉, 杨义明, 沈育杰 . 盐碱胁迫对山葡萄光合特性及生长发育的影响. 西北植物学报, 2017,37(2):339-345. doi: 10.7606/j.issn.1000-4025.2017.02.0339
	WANG Z X, LÜ H Y, QIN H Y, ZHAO Y, LIU Y X, AI J, CAO J R, YANG Y M, SHEN Y J . Photosynthetic characteristics and growth development of Amur grape (Vitis amurensis Rupr.) under saline- alkali stress. Acta Botanica Boreali-Occidentalia Sinica, 2017,37(2):339-345. (in Chinese) doi: 10.7606/j.issn.1000-4025.2017.02.0339
[22]	王伟华, 张希明, 闫海龙, 梁少民, 杨小林 . 盐处理对多枝怪柳光合作用和渗调物质的影响. 干旱区研究, 2009,26(4):561-568.
	WANG W H, ZHANG X M, YAN H L, LIANG S M, YANG X L . Effects of salt stress on photosynthesis and osmoregulation substance of Tamarix ramisissma Ledeb. Arid Zone Research, 2009,26(4):561-568. (in Chinese)
[23]	王斌 . NaCl和Na₂SO₄胁迫下沼泽小叶桦的生理响应. 南京林业大学学报 (自然科学版), 2013,37(1):132-136. doi: 10.3969/j.issn.1000-2006.2013.01.024
	WANG B . Effects of NaCl and Na₂SO₄ stress on physiological characteristics in Betula microphylla. Journal of Nanjing Forestry University (Natural Science Edition), 2013,37(1):132-136. (in Chinese) doi: 10.3969/j.issn.1000-2006.2013.01.024
[24]	范希峰, 侯新村, 朱毅, 武菊英 . 盐胁迫对柳枝稷苗期生长和生理特性的影响. 应用生态学报, 2012,23(6):1476-1480.
	FAN X F, HOU X C, ZHU Y, WU J Y . Impacts of salt stress on the growth and physiological characteristics of Panicum virgatum seedlings. Chinese Journal of Applied Ecology, 2012,23(6):1476-1480. (in Chinese)
[25]	李宏, 邓江宇, 张振春, 杨森, 曹林 . 盐胁迫对盐桦幼树光合特性的影响. 新疆农业科学, 2010,47(2):213-217.
	LI H, DENG J Y, ZHANG Z C, YANG S, CAO L . Influence of salt stress on physiological adaptability of young Betula halophila trees. Xinjiang Agricultural Sciences, 2010,47(2):213-217. (in Chinese)
[26]	徐静, 董宽虎, 高文俊, 谢开云 . NaCl和Na₂SO₄胁迫下冰草幼苗的生长及生理响应. 中国草地学报, 2011,33(1):36-41.
	XU J, DONG K H, GAO W J, XIE K Y . Growth and physiological responses of Agropyron cristatum seedlings under NaCl and Na₂SO₄ stress. Chinese Journal of Grassland, 2011,33(1):36-41. (in Chinese)
[27]	SANTOS C V . Regulation of chlorophyll biosynthesis and degradation by salt stress in sunflower leaves. Scientia Horticulturae, 2004,103(1):93-99. doi: 10.1016/j.scienta.2004.04.009
[28]	王斌, 巨波, 赵慧娟, 张群, 朱义, 崔心红 . 不同盐梯度处理下沼泽小叶桦的生理特征及叶片结构研究. 林业科学, 2011,47(10):29-36. doi: 10.11707/j.1001-7488.20111005
	WANG B, JU B, ZHAO H J, ZHANG Q, ZHU Y, CUI X H . Photosynthetic performance and variation in leaf anatomic structure of Betula microphylla var. paludosa under different saline conditions. Scientia Silvae Sinicae, 2011,47(10):29-36. (in Chinese) doi: 10.11707/j.1001-7488.20111005
[29]	REINBOTHE S, REINBOTHE C . The regulating of enzymes involved in chlorophyll biosynthesis. European Journal of Biochemistry, 1996,237(2):323-343. doi: 10.1111/j.1432-1033.1996.00323.x pmid: 8647070
[30]	HUANG W, YANG Y J, ZHANG J L, HU H, ZHANG S B . Superoxide generated in the chloroplast stroma causes photoinhibition of photosystem I in the shade-establishing tree species Psychotria henryi. Photosynthesis Research, 2017,132(3):293-303. doi: 10.1007/s11120-017-0389-4 pmid: 28432538
[31]	GIIMORE A M . Mechanistic aspects of xanthophyll cycle-dependent photoprotection in higher plant chloroplasts and leaves. Physiologia Plantarum, 1997,99:197-209. doi: 10.1111/j.1399-3054.1997.tb03449.x
[32]	NIYOGI K K, GROSSMAN A R, BJöRKMAN O . Arabidopsis mutants define a central role for the xanthophyll cycle in the regulation of photosynthetic energy conversion. The Plant Cell, 1998,10(7):1121-1134.
[33]	YAMAMOTO H Y, BUGOS R C, HIEBER A D . Biochemistry and molecular biology of the xanthophyll cycle//The Photochemistry of Carotenoids. Springer. Dordrecht, 1999: 293-303. doi: 10.1007/0-306-48209-6_16
[34]	HORTON P, HAGUE A . Studies on the induction of chlorophyll fluorescence in isolated barley protoplasts. IV. Resolution of non-photochemical quenching. Biochimica et Biophysica Acta (BBA)- Bioenergetics, 1988,932:107-115. doi: 10.1016/0005-2728(88)90144-2
[35]	寇伟锋, 刘兆普, 郑宏伟 . 海水胁迫对向日葵苗期生长及矿质营养吸收特性的影响. 生态学杂志, 2006,25(5):521-525.
	KOU W F, LIU Z P, ZHENG H W . Effects of sea water stress on Helianthus annuus L. seedlings growth and mineral nutrition. Chinese Journal of Ecology, 2006,25(5):521-525. (in Chinese)
[36]	王杨 . 长期海水灌溉对赤霞珠果实品质及土壤性质的影响[D]. 泰安: 山东农业大学, 2016.
	WANG Y . The effect of long term seawater irrigation on the quality of Cabernet Sauvignon fruit and soil properties[D]. Taian: Shandong Agricultural University, 2016. ( in Chinese)

处理 Treatment	土壤pH Soil pH	土壤容重 Soil bulk density (g·cm^-2)	土壤含水量 Soil moisture content (%)
清水对照Clear water control	7.48±0.06a	0.89±0.04a	21.6±1.6a
海水Seawater	7.53±0.08a	0.94±0.03a	24.6±3.4a
乙酸+海水Acetic acid + seawater	7.42±0.06a	0.86±0.09a	23.0±1.1a
葡萄酒+海水Wine + seawater	7.44±0.06a	0.83±0.04a	22.5±3.4a

处理 Treatment	丙二醛含量Malondialdehyde content (μmol·g^-1FW )
处理 Treatment	根Root	茎Stem	叶Leaf
清水对照Clear water control	6.76±0.06c	8.34±0.04b	12.44±0.04d
海水Seawater	14.20±0.03a	10.58±0.09a	17.52±0.09a
乙酸+海水Acetic acid + seawater	10.04±0.03b	8.40±0.03b	14.76±0.07b
葡萄酒+海水Wine + seawater	10.02±0.03b	8.44±0.06b	13.10±0.09c
