甘薯褪绿矮化病毒西非株系RT-RPA-LFD检测方法的建立与应用

doi:10.3864/j.issn.0578-1752.2024.14.007

摘要/Abstract

摘要：

【目的】利用逆转录酶重组酶聚合酶扩增（reverse transcriptase recombinase polymerase amplification，RT-RPA）结合侧向流层析（lateral flow dipstick，LFD）试纸条技术，建立甘薯褪绿矮化病毒（sweet potato chlorotic stunt virus，SPCSV）西非株系（west African strain，WA）的RT-RPA-LFD检测方法。【方法】根据SPCSV-WA外壳蛋白基因和热激蛋白基因的保守序列设计并筛选扩增效果好、特异性强的引物和探针。然后对引物和探针的浓度、扩增体系、温度、反应时间等条件进行优化，建立SPCSV-WA的RT-RPA-LFD检测方法。利用该方法对SPCSV-EA、甘薯羽状斑驳病毒（sweet potato feathery mottle virus，SPFMV）、甘薯潜隐病毒（sweet potato latent virus，SPLV）、甘薯G病毒（sweet potato virus G，SPVG）等常见的甘薯病毒进行检测，验证方法的特异性；将感染SPCSV-WA甘薯叶片样品总RNA进行10倍梯度稀释，分别采用RT-PCR和RT-RPA-LFD进行检测，比较RT-PCR和RT-RPA-LFD方法的灵敏度；对采自田间的甘薯样品和试管苗样品进行RT-RPA、RT-RPA-LFD和RT-PCR检测，验证该方法的实用性。【结果】建立了SPCSV-WA的RT-RPA-LFD检测方法，最适引物为CSV357F/R，探针CSV-CP-Probe（47 bp），引物和探针工作浓度分别为0.2和0.06 μmol·L^-1，温度为42 ℃，时间5 min。该方法可对SPCSV-WA进行特异性检测，与甘薯上其他常见病毒无交叉反应。RT-RPA-LFD最低可检测到总RNA稀释至10^-4溶液，而RT-PCR最低检测到总RNA稀释至10^-3溶液，RT-RPA-LFD灵敏度是RT-PCR的10倍。田间采集的22份甘薯样品经RT-PCR、RT-RPA和RT-RPA-LFD检测，均检出11份阳性样品，3种方法检测结果一致。28份试管苗样品的检测结果表明，RT-PCR和RT-RPA-LFD检测结果一致，均检出5份阳性样品。【结论】建立了SPCSV-WA的RT-RPA-LFD检测方法，该方法具有快速、简便、特异、灵敏、可视的特点，既可用于甘薯脱毒试管苗样品的病毒检测，也适用于基层单位田间甘薯病毒样品的现场快速检测。

关键词: 甘薯褪绿矮化病毒西非株系, 逆转录酶重组酶聚合酶扩增, 侧向流层析, 快速检测, 甘薯

Abstract:

【Objective】 This study aims to establish a novel technique for detecting the west African strain of sweet potato chlorotic stunt virus (SPCSV-WA) by combining reverse transcriptase recombinase polymerase amplification and lateral flow dipstick (RT-RPA-LFD).【Method】 Primers and probes with good amplification results and strong specificity were designed and screened on the basis of the conserved sequences of the SPCSV-WA coat protein gene and heat shock protein gene. Then, the conditions such as primer and probe concentrations, amplification system, temperature, and reaction time were optimized to detect SPCSV-WA using RT-RPA-LFD. This method was used to detect common viruses on sweet potato such as the east African strain of sweet potato chlorotic stunt virus (SPCSV-EA), sweet potato feathery mottle virus (SPFMV), sweet potato latent virus (SPLV) and sweet potato virus G (SPVG) to verify the specificity. Total RNA from SPCSV-infected sweet potato leaves was diluted in a 10-fold gradient, and RT-PCR and RT-RPA-LFD were performed to compare the sensitivity of the two methods. Field sweet potato samples and test tube seedling samples were subjected to RT-RPA, RT-RPA-LFD, and RT-PCR detection to validate the practicality of the method.【Result】 The RT-RPA-LFD detection method for SPCSV-WA was established using the optimal primer CSV357F/R and the CSV-CP-Probe (47 bp). The working concentrations of the primer and probe were 0.2 and 0.06 μmol·L^-1, respectively. The reaction conditions were set to 42 ℃ for 5 min. This method could specifically detect SPCSV-WA and had no cross-reaction with other common viruses on sweet potato. The RT-RPA-LFD could detect viruses up to 10^-4dilution, whereas RT-PCR could only detect up to 10^-3 dilution, making the sensitivity of RT-RPA-LFD 10 times higher than that of RT-PCR. Of the 22 field-gathered sweet potato samples tested by RT-PCR, RT-RPA, and RT-RPA-LFD, 11 positive samples were consistently found across the three methods. The testing results of 28 test tube seedling samples showed that RT-PCR and RT-RPA-LFD consistently detected five positive samples.【Conclusion】 The RT-RPA-LFD detection method for SPCSV-WA has been established and it is characterized by its speed, simplicity, specificity, sensitivity, and visibility. This method can be used for testing virus-free test tube seedling samples of sweet potato as well as for on-site rapid detection of field sweet potato samples in basic level units.

Key words: west African strain of sweet potato chlorotic stunt virus (SPCSV-WA), reverse transcriptase recombinase polymerase amplification (RT-RPA), lateral flow dipstick (LFD), rapid detection, sweet potato

王永江, 乔奇, 王爽, 赵付枚, 田雨婷, 张德胜, 张振臣. 甘薯褪绿矮化病毒西非株系RT-RPA-LFD检测方法的建立与应用[J]. 中国农业科学, 2024, 57(14): 2781-2790.

WANG YongJiang, QIAO Qi, WANG Shuang, ZHAO FuMei, TIAN YuTing, ZHANG DeSheng, ZHANG ZhenChen. Establishment and Application of RT-RPA-LFD Detection Method for Sweet Potato Chlorotic Stunt Virus WA Strain[J]. Scientia Agricultura Sinica, 2024, 57(14): 2781-2790.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2024.14.007

https://www.chinaagrisci.com/CN/Y2024/V57/I14/2781

图/表 9

表1

表2

图1

图2

图3

图4

图5

图6

图7

参考文献 33

[1]	李强, 赵海, 靳艳玲, 朱金城, 马代夫. 中国甘薯产业助力国家粮食安全的分析与展望. 江苏农业学报, 2022, 38(6): 1484-1491.
	LI Q, ZHAO H, JIN Y L, ZHU J C, MA D F. Analysis and perspectives of sweet potato industry contributing to national food security in China. Jiangsu Journal of Agricultural Sciences, 2022, 38(6): 1484-1491. (in Chinese)
[2]	王欣, 李强, 曹清河, 马代夫. 中国甘薯产业和种业发展现状与未来展望. 中国农业科学, 2021, 54(3): 483-492. doi: 10.3864/j.issn.0578-1752.2021.03.003.
	WANG X, LI Q, CAO Q H, MA D F. Current status and future prospective of sweet potato production and seed industry in China. Scientia Agricultura Sinica, 2021, 54(3): 483-492. doi: 10.3864/j.issn.0578-1752.2021.03.003. (in Chinese)
[3]	CLARK C A, DAVIS J A, ABAD J A, CUELLAR W J, FUENTES S, KREUZE J F, GIBSON R W, MUKASA S B, TUGUME A K, TAIRO F D, VALKONEN J P T. Sweet potato viruses: 15 years of progress on understanding and managing complex diseases. Plant Disease, 2012, 96(2): 168-185.
[4]	罗勤川, 唐伟, 孙厚俊, 马居奎, 杨冬静, 陈晶伟, 王芳, 谢逸萍, 张成玲. 江苏甘薯上常见病毒种类鉴定及多样性分析. 江西农业学报, 2022, 34(7): 70-75.
	LUO Q C, TANG W, SUN H J, MA J K, YANG D J, CHEN J W, WANG F, XIE Y P, ZHANG C L. Pathogen identification and diversity analysis of sweet potato viruses in Jiangsu Province. Acta Agriculturae Jiangxi, 2022, 34(7): 70-75. (in Chinese)
[5]	WANG Y J, QIN Y H, WANG S, ZHANG D S, TIAN Y T, ZHAO F M, WANG Y Z, LV H, QIAO Q, ZHANG Z C. Species and genetic variability of sweet potato viruses in China. Phytopathology Research, 2021, 3: 20.
[6]	赵付枚, 王爽, 田雨婷, 乔奇, 王永江, 张德胜, 张振臣. 甘薯病毒病发生关键因素研究. 中国农业科学, 2021, 54(15): 3232-3240. doi: 10.3864/j.issn.0578-1752.2021.15.008.
	ZHAO F M, WANG S, TIAN Y T, QIAO Q, WANG Y J, ZHANG D S, ZHANG Z C. An investigation into key factors influencing the occurrence of virus disease in sweet potato. Scientia Agricultura Sinica, 2021, 54(15): 3232-3240. doi: 10.3864/j.issn.0578-1752.2021.15.008. (in Chinese)
[7]	QIN Y H, WANG L, ZHANG Z C, QIAO Q, ZHANG D S, TIAN Y T, WANG S, WANG Y J, YAN Z L. Complete genomic sequence and comparative analysis of the genome segments of sweet potato chlorotic stunt virus in China. PLoS ONE, 2014, 9(8): e106323.
[8]	HOYER U, MAISS E, JELKMANN W, LESEMANN D E, VETTEN H J. Identification of the coat protein gene of a sweet potato sunken vein closterovirus isolate from Kenya and evidence for a serological relationship among geographically diverse closterovirus isolates from sweet potato. Phytopathology, 1996, 86(7): 744-750.
[9]	ARITUA V, BARG E, ADIPALA E, GIBSON R W, VETTEN H J. Further evidence for limited genetic diversity among east African isolates of sweet potato chlorotic stunt virus. Journal of Phytopathology, 2008, 156: 181-189.
[10]	QIAO Q, ZHANG Z C, QIN Y H, ZHANG D S, TIAN Y T, WANG Y J. First report of sweet potato chlorotic stunt virus infecting sweet potato in China. Plant Disease, 2011, 95(3): 356.
[11]	张振臣, 乔奇, 秦艳红, 张德胜, 田雨婷. 我国发现由甘薯褪绿矮化病毒和甘薯羽状斑驳病毒协生共侵染引起的甘薯病毒病害. 植物病理学报, 2012, 42(3): 328-333.
	ZHANG Z C, QIAO Q, QIN Y H, ZHANG D S, TIAN Y T. First evidence for occurrence of sweet potato virus disease (SPVD) caused by dual infection of sweet potato feathery mottle virus and sweet potato chlorotic stunt virus in China. Acta Phytopathologica Sinica, 2012, 42(3): 328-333. (in Chinese)
[12]	BEDNAREK R, DAVID M, FUENTES S, KREUZE J, FEI Z J. Transcriptome analysis provides insights into the responses of sweet potato to sweet potato virus disease (SPVD). Virus Research, 2021, 295: 198293.
[13]	MUKASA S B, RUBAIHAYO P R, VALKONEN J P T. Incidence of viruses and virus like diseases of sweetpotato in Uganda. Plant Disease, 2003, 87: 329-335. doi: 10.1094/PDIS.2003.87.4.329 pmid: 30831824
[14]	肖海峻, 孟利前, 陈梦然, 杨春林. 甘薯褪绿矮化病毒的RT-PCR检测技术构建. 分子植物育种, 2017, 15(7): 2896-2900.
	XIAO H J, MENG L Q, CHEN M R, YANG C L. Application of RT-PCR detection method for sweet potato chlorotic stunt virus. Molecular Plant Breeding, 2017, 15(7): 2896-2900. (in Chinese)
[15]	王丽, 王振东, 乔奇, 秦艳红, 张德胜, 田雨婷, 王爽, 张立军, 张振臣. 甘薯褪绿矮化病毒西非株系实时荧光定量PCR检测方法的建立及应用. 植物病理学报, 2014, 44(5): 461-468.
	WANG L, WANG Z D, QIAO Q, QIN Y H, ZHANG D S, TIAN Y T, WANG S, ZHANG L J, ZHANG Z C. Development and application of a real-time PCR method for detection of west African strain of sweet potato chlorotic stunt virus. Acta Phytopathologica Sinica, 2014, 44(5): 461-468. (in Chinese)
[16]	王爽, 田雨婷, 乔奇, 秦艳红, 张德胜, 张振臣. 侵染甘薯的菜豆金色花叶病毒属病毒和甘薯褪绿矮化病毒多重PCR检测方法的建立与应用. 植物保护学报, 2018, 45(6): 1427-1428.
	WANG S, TIAN Y T, QIAO Q, QIN Y H, ZHANG D S, ZHANG Z C. Development and application of multiplex PCR method for detection of sweepoviruses and sweet potato chlorotic stunt virus in sweet potato. Journal of Plant Protection, 2018, 45(6): 1427-1428. (in Chinese)
[17]	乔奇, 张振臣, 秦艳红, 张德胜, 田雨婷, 王爽, 王永江. 甘薯褪绿矮化病毒西非株系RT-LAMP检测方法的建立. 中国农业科学, 2013, 46(18): 3939-3945. doi: 10.3864/j.issn.0578-1752.2013.18.025.
	QIAO Q, ZHANG Z C, QIN Y H, ZHANG D S, TIAN Y T, WANG S, WANG Y J. Detection of sweet potato chlorotic stunt virus strain WA by reverse transcription loop-mediated isothermal amplification reaction. Scientia Agricultura Sinica, 2013, 46(18): 3939-3945. doi: 10.3864/j.issn.0578-1752.2013.18.025. (in Chinese)
[18]	TANG W, YANG D J, MA J K, CHEN J W, XIE Y P, SUN H J, ZHANG C L. Development of a dual RT-RPA detection for sweet potato feathery mottle virus and sweet potato chlorotic stunt virus. Molecular and Cellular Probes, 2022, 65: 101846.
[19]	PIEPENBURG O, WILLIAMS C H, STEMPLE D L, ARMES N A. DNA detection using recombination proteins. PLoS Biology, 2006, 4(7): e204.
[20]	王帅, 杨艳歌, 吴占文, 李红娜, 李涛, 孙冬梅, 袁飞. 重组酶聚合酶扩增、重组酶介导等温扩增及酶促重组等温扩增技术在食源性致病菌快速检测中的研究进展. 食品科学, 2023, 44(9): 297-305.
	WANG S, YANG Y G, WU Z W, LI H N, LI T, SUN D M, YUAN F. A review of the application of recombinase polymerase amplification, recombinase-aided amplification and enzymatic recombinase amplification in rapid detection of foodborne pathogens. Food Science, 2023, 44(9): 297-305. (in Chinese) doi: 10.7506/spkx1002-6630-20220526-322
[21]	马志敏, 许建建, 段玉, 王春庆, 苏越, 张琦, 宾羽, 周常勇, 宋震. 柑橘黄化脉明病毒 RT-RPA 检测方法的建立. 中国农业科学, 2021, 54(15): 3241-3249. doi: 10.3864/j.issn.0578-1752.2021.15.009.
	MA Z M, XU J J, DUAN Y, WANG C Q, SU Y, ZHANG Q, BIN Y, ZHOU C Y, SONG Z. Establishment of RT-RPA for citrus yellow vein clearing virus (CYVCV) detection. Scientia Agricultura Sinica, 2021, 54(15): 3241-3249. doi: 10.3864/j.issn.0578-1752.2021.15.009. (in Chinese)
[22]	黄涛, 李丹丹, 高慎阳, 贾宁. 猪瘟病毒核酸RT-RPA-LFD快速检测方法的建立. 兽医导刊, 2021(3): 115-118.
	HUANG T, LI D D, GAO S Y, JIA N. Rapid detection of classical swine fever virus nucleic acid by RT-RPA-LFD. Veterinary Orientation, 2021(3): 115-118. (in Chinese)
[23]	张阳, 徐聪灵, 孙涛. 基于RPA-LFD的寨卡病毒检测方法的建立与评价. 中国口岸科学技术, 2022, 4(2): 14-18.
	ZHANG Y, XU C L, SUN T. Establishment and evaluation of detection method for zika virus based on RPA-LFD. China Port Science and Technology, 2022, 4(2): 14-18. (in Chinese)
[24]	张阳, 孙涛, 徐聪林, 周冲. 登革病毒逆转录重组酶聚合酶扩增-测流层析试纸条检测方法的建立与评价. 口岸卫生控制, 2019, 24(3): 30-34.
	ZHANG Y, SUN T, XU C L, ZHOU C. Establish and evaluation of a method for detection of dengue virus reverse transcriptase polymerase amplification and flow chromatography strip. Port Health Control, 2019, 24(3): 30-34. (in Chinese)
[25]	梁辉. 流行性乙型脑炎RT-RPA-LFD检测方法的建立与评价[D]. 广州: 华南农业大学, 2016.
	LIANG H. Establishment and evaluation of RT-RPA-LFD method for rapid and simple detection of JEV[D]. Guangzhou: South China Agricultural University, 2016. (in Chinese)
[26]	张淼源, 卢佩珊, 李佳宁, 李佳乐, 郑炜欣, 欧阳岁东. 重组酶聚合酶侧流层析技术检测新冠病毒核酸快速诊断方法的初步建立. 中国人兽共患病学报, 2022, 38(7): 577-581.
	ZHANG M Y, LU P S, LI J N, LI J L, ZHENG W X, OUYANG S D. Preliminary establishment of a rapid diagnosis method for detecting SARS-CoV-2 nucleic acid through recombinase polymerase amplification combined with a lateral flow dipstick. Chinese Journal of Zoonoses, 2022, 38(7): 577-581. (in Chinese)
[27]	申世凯, 曾婷, 乔兴华, 陈力, 任杰群, 周彦. 柑橘衰退病毒RT-RPA-LFD可视化检测方法的建立及应用. 果树学报, 2023, 40(12): 2652-2660.
	SHEN S K, ZENG T, QIAO X H, CHEN L, REN J Q, ZHOU Y. Establishment and development of RT-RPA-LFD visualization assay for rapid detection of citrus tristeza virus. Journal of Fruit Science, 2023, 40(12): 2652-2660. (in Chinese)
[28]	付振艳, 张振臣. 甘薯病毒G(SPVG)外壳蛋白基因的克隆、表达及其抗血清的制备. 中国农学通报, 2007, 23(1): 38-41.
	FU Z Y, ZHANG Z C. Cloning, expression in E. coli of coat protein gene of sweet potato virus G and preparation of its antiserum. Chinese Agricultural Science Bulletin, 2007, 23(1): 38-41. (in Chinese)
[29]	黄玉娜, 张振臣. 甘薯潜隐病毒外壳蛋白基因的克隆、表达及其抗血清的制备. 植物病理学报, 2007, 37(3): 255-259.
	HUANG Y N, ZHANG Z C. Cloning, expression of coat protein gene of sweet potato latent virus in E. coli and preparation of antiserum. Acta Phytopathologica Sinica, 2007, 37(3): 255-259. (in Chinese)
[30]	谢锦. 基于重组酶聚合酶扩增的马铃薯病毒等温检测体系的建立和应用[D]. 武汉: 华中农业大学, 2023.
	XIE J. Establishment and application of an isothermal detection system for potato virus based on recombinase polymerase amplification[D]. Wuhan: Huazhong Agricultural University, 2023. (in Chinese)
[31]	LILLIS L, LEHMAN D, SINGHAL M C, CANTERA J, SINGLETON J, LABARRE P, TOYAMA A, PIEPENBURG O, PARKER M, WOOD R, OVERBAUGH J, BOYLE D S. Non-instrumented incubation of a recombinase polymerase amplification assay for the rapid and sensitive detection of proviral HIV-1 DNA. PLoS ONE, 2014, 9(9): e108189.
[32]	ROHRMAN B A, RICHARDS-KORTUM R R. A paper and plastic device for performing recombinase polymerase amplification of HIV DNA. Lab on a Chip, 2012, 12(17): 3082-3088. doi: 10.1039/c2lc40423k pmid: 22733333
[33]	LUTZ S, WEBER P, FOCKE M, FALTIN B, HOFFMANN J, MÜLLER C, MARK D, ROTH G, MUNDAY P, ARMES N, PIEPENBURG O, ZENGERLE R, VON STETTEN F. Microfluidic lab-on-a-foil for nucleic acid analysis based on isothermal recombinase polymerase amplification (RPA). Lab on a Chip, 2010, 10(7): 887-893. doi: 10.1039/b921140c pmid: 20300675

体系 System	编号 Number	引物名称 Primer name	引物和探针序列 Primer and probe sequence (5′-3′)	大小 Size (bp)	来源 <BOLD>S</BOLD>ource
RT-RPA	C1	CSV170F	ATGGCTGATAGCACTAAAGTCGAAGAGAAGAAC	170	本试验This study
	C1	CSV170R	GTAAGAATACCACTRGTTARCTCCATATCTC	170	本试验This study
	C2	CSV216F	GRCTTCCAACTATACTCTTTCCCGT	216	本试验This study
	C2	CSV216R	GATATTATGTCAAAGAGTCAAGAGGATG	216	本试验This study
	C3	CSV237F	GGCRTGGGCAAATCAGAGTACGTCCGAAAAGAAT	237	本试验This study
	C3	CSV237R	TTTCGCCTGYAAATGGTAATCGGGTTTAACAATAC	237	本试验This study
	C4	CSV253F	TTTGGGAAGACGAGATATGGAGYTAACTAGTGGT	253	本试验This study
	C4	CSV253R	TTTCGGACGTACTCTGATTTGCCCATGCCTGW	253	本试验This study
	C5	SCV259F	YGGCTAGTTTGGGAAGACGAGATATGGAGYTAA	259	本试验This study
	C5	CSV259R	TCGGACGTACTCTGATTTGCCCAYGCCTGW	259	本试验This study
	C6	CSV357F	[6-Fam]-TTTGGGAAGACGAGATATGGAGYTAACYAGTG	357	本试验This study
		CSV357R	Biotin-GGCATGTTAGRTTGAATATGGTTTATGAAGTTGT
		CSV-CP-Probe	[6-Fam]-CAGATATTATGTCAAAGAGTCAAGAGGAT[THF] AGTTTAAGCGTCATATG-C3Spacer
	C7	CSV405F	CGGRTCGGARTTTACYCCMACGTGTYGTCYRTYA	405	本试验This study
	C7	CSV405R	CCKAACGATTCACATACAGACTTCATAAACATYC	405	本试验This study
	C8	CSV313F	WCAGGCRTGGGCAAATCAGAGTACGTCCGAAAA	313	本试验This study
	C8	CSV313R	CTGCGGTTGTCGCCAAATCATTACCTCTCATG	313	本试验This study
RT-PCR		CP-F	ATGGCTGATAGCACTAAAGTCGA	774	文献[7] Reference [7]
		CP-R	TCAACAGTGAAGACCTGTTCCAG	774	文献[7] Reference [7]
		SPCSV-EA-SPSP1-T7	TAATACGACTCACTATAATGRMTACTGRCAAAGTAAACGATG	791	文献[10] Reference [10]
		SPCSV-EA-SPSP4	TCAACAGTGAAGACCRGYACCRGTCAA
		SPVG-P5-T7	TAATACGACTCACTATAACTGAATTCTCYRCTGAAGARAYATAYGATGC	1017	文献[28] Reference [28]
		SPVG-P3	ACTAAGCTTTTACTGCACACCCCTCATACC	1017	文献[28] Reference [28]
		SPLV-P5-T7	TAATACGACTCACTATAGCCGAY GAAACCATCMTCGAT	1093	文献[29] Reference [29]
		SPLV-P3	GTCTC Y GGTATAAGACG	1093	文献[29] Reference [29]

编号 Number	引物和探针反应浓度 Concentration of primer and probe (μmol·L^-1)	镁离子浓度 Concentration of Mg²⁺(μmol·L^-1)
A	CSV357F (2×10^-1)/CSV357R (2×10^-1)+CSV-CP-Probe (6×10^-2)	2.10×10⁴
B	CSV357F-fam (2×10^-1)/CSV357R (2×10^-1)	2.10×10⁴
C	CSV357F (4×10^-1)/CSV357R (4×10^-1)+CSV-CP-Probe (8×10^-2)	1.68×10⁴
D	CSV357F-fam (2×10^-1)/CSV357R (2×10^-1)	1.68×10⁴
E	CSV357F (2×10^-1)/CSV357R (2×10^-1)+CSV-CP-Probe (6×10^-2)	1.68×10⁴
F	CSV357F (1.6×10^-1)/CSV357R (1.6×10^-1)+CSV-CP-Probe (6×10^-2)	1.68×10⁴
