低温胁迫下链霉菌TOR3209对番茄叶绿素荧光特性和叶黄素循环的影响

doi:10.3864/j.issn.0578-1752.2024.22.011

摘要/Abstract

摘要：

【目的】研究链霉菌TOR3209提高番茄低温耐受能力的生物学机制，从叶绿素荧光特性和叶黄素循环两方面入手揭示TOR3209对光系统II（PSII）的保护机制。【方法】以番茄为试验材料，将4叶期番茄幼苗于移栽时施加TOR3209菌剂，并于移栽30 d后进行低温（5 ℃）处理，设置常温TOR3209（TOR3209）、常温NI（NI）、低温TOR3209（TOR3209+C）和低温NI（NI+C）4个处理。比较低温胁迫下接菌和未接菌植株PSII性能、非光化学淬灭（NPQ）相关的叶绿素荧光参数、叶黄素循环组分、紫黄质脱环氧化酶（VDE）活性和抗坏血酸-谷胱甘肽（AsA-GSH）循环的差异。【结果】链霉菌TOR3209可缓解低温诱导的PSII实际光化学效率Y（II）的下降，避免了PSII光抑制。低温胁迫下番茄叶片快速叶绿素荧光诱导动力学（OJIP）曲线的J点明显上升同时出现K点，快速叶绿素荧光诱导动力学分析（JIP-test）发现，相对荧光曲线的初始斜率（M_o）增加，用于初级醌受体（Q_A）下游电子传递的能量比例（Ψ_o）降低，以吸收光能为基础的光化学性能指数（PI_ABS）减小；施加TOR3209菌剂的植株J点未上升且能够抑制K点的出现，M_o、Ψ_o和PI_ABS均能回归到常温水平，即TOR3209对PSII受体侧电子传递体和供体侧放氧复合体（OEC）均起到保护作用。TOR3209抑制低温胁迫下番茄叶片PI_ABS和以单位面积为基础的性能指数（PI_CS）的显著降低，结合荧光参数NPQ和保护性热耗散（Ф_NPQ）显著增加且非调节性能量耗散（Ф_NO）显著降低，证实促进保护性热耗散是TOR3209保护PSII的作用机制。低温胁迫导致番茄叶片叶黄素总库含量和VDE活性的降低，且AsA-GSH循环中的抗氧化酶（抗坏血酸过氧化物酶APX、谷胱甘肽还原酶GR、单脱氢抗坏血酸还原酶MDHAR）活性和抗氧化剂（抗坏血酸AsA、还原型谷胱甘肽GSH）含量降低，叶黄素循环启动减慢，叶片光合能力受到抑制。TOR3209不仅能提高低温胁迫下叶黄素脱环氧化状态（DEPS），而且增加叶黄素总库含量和VDE活性，进一步提高非光化学淬灭水平，及时转化过剩光能，保护光合机构的稳定性；TOR3209也能提高低温胁迫下番茄叶片上述抗氧化酶活性和抗氧化剂AsA的含量，优化AsA-GSH循环系统以清除活性氧（ROS）的同时还能促进叶黄素循环。【结论】TOR3209提高低温胁迫下番茄叶片光合电子传递活性维持PSII稳定性，促进叶黄素循环介导的热耗散缓解PSII光抑制，优化AsA-GSH循环减轻PSII氧化胁迫，增强番茄耐低温能力。

关键词: 番茄, 链霉菌, 低温胁迫, PSII光抑制, 叶绿素荧光, 叶黄素循环

Abstract:

【Objective】In order to explore the biological mechanism of Streptomyces sp. TOR3209 in improving the low temperature tolerance of tomato, and to reveal the protective mechanism of TOR3209 on photosystem II (PSII) from two aspects (chlorophyll fluorescence characteristics and xanthophyll cycle).【Method】As the experimental material, tomato seedlings of quadrifoil stage were applied with TOR3209 when transplanted into the pots, cold stress (5 ℃) was imposed on the 30th day after transplanting. The experiment was divided into four parts, which were inoculated plants (TOR3209), non-inoculated plants (NI), inoculated plants exposed to cold stress (TOR3209+C) and non-inoculated plants exposed to cold stress (NI+C). The differences in PSII performance, chlorophyll fluorescence parameters related to NPQ, xanthophyll cycle component, violaxanthin de-epoxidase (VDE) activity, and ascorbate-glutathione (AsA-GSH) cycle in plants of different treatments were compared.【Result】Streptomyces sp. TOR3209 could alleviate the decrease of actual photochemical efficiency of PSII Y (II) by cold stress and avoid PSII photoinhibition. Defensing to the cold stress, the shape of chlorophyll a fluorescence transient (OJIP) curve was significantly changed with increased in J step and an emergence of K step; while the approximated initial slope of the fluorescence transient (M_o) increased, and the rate at which trapped excitons transfer electrons to other electron receptors downstream of primary quinone receptor (Q_A) in the electron transport chain (Ψ_o) decreased, and the performance index on absorption basis (PI_ABS) decreased in JIP-test of tomato leaves. The inoculation of TOR3209 under cold stress prevented a significant increase in variable fluorescence intensity at J step and an emergence of K step, while the M_o, Ψ_oand PI_ABSreturned to the levels in plants of NI, indicating that TOR3209 protected the electron transporters at PSII acceptor side and oxygen-evolving complex (OEC) at PSII donor side. The inoculation of TOR3209 also prevented a significant decrease in PI_ABS and the performance index on cross section basis (PI_CS) in tomato leaves as revealed by JIP-test, which in combination with the significantly increased NPQ and protective heat dissipation (Ф_NPQ), as well as the significantly decreased non-regulatory energy dissipation (Ф_NO), evidenced that the main mechanism of TOR3209 to protect PSII was the protective heat dissipation. Cold stress apparently decreased the de-epoxidation state (DEPS) of xanthophyll cycle, at the same time, reduced the levels of xanthophyll cycle components, the activities of VDE and antioxidases in AsA-GSH pathway (ascorbate peroxidase APX, glutathione reductase GR, monodehydroascorbate reductase MDHAR), and contents of antioxidants (ascorbate AsA, glutathione GSH), slowed down the xanthophyll cycle, and depressed the photosynthetic capacity of tomato leaves. However, TOR3209 inoculation could increase the DEPS of xanthophyll cycle, enhance the levels of xanthophyll cycle components and VDE activity under cold stress, which further raised the level of PSII non-photochemical fluorescence quenching coefficient, prevented excess excitation energy, and protected the photosynthetic apparatus. Meanwhile, TOR3209 inoculation improved the activities of the above-mentioned antioxidases and AsA content under cold stress, optimized the AsA-GSH cycle to confront the accumulation of reactive oxygen species (ROS) and facilitate xanthophyll cycle.【Conclusion】The improvement of cold tolerant capacity in tomato plants by TOR3209 inoculation was reflected in maintaining PSII stability by increasing the photosynthetic electron transfer activity, alleviating the damage of PSII photoinhibition via enhancing the xanthophyll cycle, and reducing oxidative stress on PSII by optimizing AsA-GSH cycle.

Key words: tomato (Solanum lycopersicum), Streptomyces, cold stress, PSII photoinhibition, chlorophyll fluorescence, xanthophyll cycle

马佳, 彭杰丽, 贾楠, 王旭, 王占武, 胡栋. 低温胁迫下链霉菌TOR3209对番茄叶绿素荧光特性和叶黄素循环的影响[J]. 中国农业科学, 2024, 57(22): 4522-4540.

MA Jia, PENG JieLi, JIA Nan, WANG Xu, WANG ZhanWu, HU Dong. Effects of Streptomyces sp. TOR3209 on Chlorophyll Fluorescence Characteristics and Xanthophyll Cycle in Tomato Plants Under Cold Stress[J]. Scientia Agricultura Sinica, 2024, 57(22): 4522-4540.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2024.22.011

https://www.chinaagrisci.com/CN/Y2024/V57/I22/4522

图/表 13

表1

JIP-test荧光参数的计算公式及注释[9]"

参数及公式Parameter and formula	注释Definition
F_o	最小荧光强度Minimal recorded fluorescence intensity
F_m	最大荧光强度Maximal recorded fluorescence intensity
V_J=(F_J-F_o)/(F_m-F_o)	J点的相对可变荧光强度Relative variable fluorescence intensity at the J-step
M_o=4×(F_{300 μs}-F_o)/(F_m-F_o)	相对荧光曲线的初始斜率Approximated initial slope of the fluorescence transient
ABS/RC=M_o×(1/V_J)×(1/φ_Po)	单位反应中心吸收的光能Absorption flux per reaction center
TR_o/RC=M_o×(1/V_J)	单位反应中心捕获的光能Trapped energy flux per reaction center
ET_o/RC=M_o×(1/V_J)×ψ_o	单位反应中心捕获的用于电子传递的能量（在t=0时）Electron transport flux per reaction center (at t=0)
DI_o/RC=(ABS/RC)-(TR_o/RC)	单位反应中心耗散的能量（在t=0时）Dissipated energy flux per reaction center (at t=0)
φ_Po=TR_o/ABS	最大光化学效率（在t=0时）Maximum quantum yield for primary photochemistry (at t=0)
Ψ_o=ET_o/TR_o	捕获的激子将电子传递到电子传递链中超过Q_A的其他电子受体的概率（在t=0时） Probability that a trapped exciton moves an electron into the electron transport chain beyond Q_A (at t=0)
φ_Eo=ET_o/ABS	电子传递的量子产额（在t=0时）Quantum yield for electron transport (at t=0)
φ_Do=1-φ_Po	用于热耗散的量子比率（在t=0时）Quantum ratio for dissipated energy (at t=0)
ABS/CS_o≈F_o	单位横截面积吸收的光能（在t=0时）Absorption flux per cross-sectional area (at t=0)
TR_o/CS_o=φ_Po×(ABS/CS_o)	单位横截面积捕获的光能（在t=0时）Trapped energy flux per cross-sectional area (at t=0)
ET_o/CS_o=φ_Eo×(ABS/CS_o)	单位横截面积电子传递的量子产额（在t=0时） Quantum yield for electron transport flux per cross-sectional area (at t=0)
DI_o/CS_o=(ABS/CS_o)-(TR_o/CS_o)	单位横截面积的热耗散能量（在t=0时）Dissipated energy flux per cross-sectional area (at t=0)
RC/CS_o=φ_Po×(V_J/M_o)×(ABS/CS_o)	单位面积有活性反应中心的数量Number of reaction centers per unit area
PI_ABS=(RC/ABS)×[φ_Po/(1-φ_Po)]×[Ψ_o/(1-Ψ_o)]	以吸收光能为基础的性能指数Performance index on absorption basis
PI_CS=(RC/CS_o)×[φ_Po/(1-φ_Po)]×[Ψ_o/(1-Ψ_o)]	以单位面积为基础的性能指数（在t=0时）Performance index on cross section basis (at t=0)

表1

图1

图2

图3

图4

图5

图6

图7

图8

表2

表3

表4

表5

参考文献 61

[1]	LI H Z, JIANG X C, LV X Z, AHAMMED G J, GUO Z X, QI Z Y, YU J Q, ZHOU Y H. Tomato GLR3.3 and GLR3.5 mediate cold acclimation-induced chilling tolerance by regulating apoplastic H₂O₂ production and redox homeostasis. Plant, Cell and Environment, 2019, 42(12): 3326-3339.
[2]	DONGSANSUK A, LUTZ C, NEUNER G. Effects of temperature and irradiance on quantum yield of PSII photochemistry and xanthophyll cycle in a tropical and a temperate species. Photosynthetica, 2013, 51(1): 13-21.
[3]	SAVITCH L V, IVANOV A G, GUDYNAITE-SAVITCH L, HUNER N P A, SIMMONDS J. Effects of low temperature stress on excitation energy partitioning and photoprotection in Zea mays. Functional Plant Biology, 2009, 36: 37-49.
[4]	LACOUR T, BABIN M, LAVAUD J. Diversity in xanthophyll cycle pigments content and related nonphotochemical quenching (NPQ) among microalgae: Implications for growth strategy and ecology. Journal of Phycology, 2020, 56(2): 245-263. doi: 10.1111/jpy.12944 pmid: 31674660
[5]	董雷, 韩嘉瑞, 李帅, 岳凌翔, 李文均. 链霉菌最新研究进展. 微生物学报, 2023, 63(5): 1815-1832.
	DONG L, HAN J R, LI S, YUE L X, LI W J. The latest research progress of Streptomycetes. Acta Microbiologica Sinica, 2023, 63(5): 1815-1832. (in Chinese)
[6]	GUO Y J, LU Y P, GOLTSEV V, STRASSER R J, KALAJI H M, WANG H, WANG X X, CHEN S G, QIANG S. Comparative effect of tenuazonic acid, diuron, bentazone, dibromothymoquinone and methyl viologen on the kinetics of Chl a fluorescence rise OJIP and the MR820 signal. Plant Physiology and Biochemistry, 2020, 156: 39-48.
[7]	ZHAO L, ZHANG Y Q. Effects of phosphate solubilization and phytohormone production of Trichoderma asperellum Q1 on promoting cucumber growth under salt stress. Journal of Integrative Agriculture, 2015, 14(8): 1588-1597. doi: 10.1016/S2095-3119(14)60966-7
[8]	KALAJI H M, JAJOO A, OUKARROUM A, BRESTIC M, ŽIVCAK M, SAMBORSKA I A, CETNER M D, ŁUKASIK I, GOLTSEV V, LADLE R J. Chlorophyll a fluorescence as a tool to monitor physiological status of plants under abiotic stress conditions. Acta Physiologiae Plantarum, 2016, 38(4): 102.
[9]	STRASSER R J, SRIVASTAVA A, TSIMILLI-MICHAEL M. The fluorescence transient as a tool to characterize and screen photosynthetic samples//Probing Photosynthesis: Mechanisms, Regulation and Adaptation. 2000: 445-483.
[10]	李书鑫, 徐婷, 李慧, 杨文莹, 蔺吉祥, 朱先灿. 低温胁迫对玉米幼苗叶绿素荧光诱导动力学的影响. 土壤与作物, 2020, 9(3): 221-230.
	LI S X, XU T, LI H, YANG W Y, LIN J X, ZHU X C. Effects of low temperature on chlorophyll fluorescence kinetics of maize seedlings. Soils and Crops, 2020, 9(3): 221-230. (in Chinese)
[11]	杜思梦, 方保停, 李向东, 张德奇, 岳俊芹, 邵运辉, 王汉芳, 杨程, 秦峰. 外源水杨酸对低温胁迫下小麦幼苗叶绿素荧光特性及抗氧化酶活性的影响. 江苏农业科学, 2022, 50(19): 68-73.
	DU S M, FANG B T, LI X D, ZHANG D Q, YUE J Q, SHAO Y H, WANG H F, YANG C, QIN F. Effects of exogenous salicylic acid on chlorophyll fluorescence characteristics and antioxidant enzyme activity of wheat seedlings under low temperature stress. Jiangsu Agricultural Sciences, 2022, 50(19): 68-73. (in Chinese)
[12]	ZHANG G X, LIU Y F, NI Y, MENG Z J, LU T, LI T L. Exogenous calcium alleviates low night temperature stress on the photosynthetic apparatus of tomato leaves. PLoS ONE, 2014, 9(5): e97322.
[13]	BIRHANE E, STERCK F J, FETENE M, BONGERS F, KUYPER T W. Arbuscular mycorrhizal fungi enhance photosynthesis, water use efficiency, and growth of frankincense seedlings under pulsed water availability conditions. Oecologia, 2012, 169(4): 895-904. doi: 10.1007/s00442-012-2258-3 pmid: 22286084
[14]	BERNARDO S, RODRIGO M J, VIVES-PERIS V, GOMEZ-CADENAS A, ZACARIAS L, MACHADO N, MOUTINHO-PEREIRA J, DINIS L T. Fine-tuning of grapevine xanthophyll-cycle and energy dissipation under Mediterranean conditions by kaolin particle-film. Scientia Horticulturae, 2022, 291: 110584.
[15]	袁凌云, 汪承刚, 黄兴学, 汤玲, 侯金锋, 刘凡, 汪龙, 朱世东. 油菜素内酯对Ca(NO₃)₂胁迫下黄瓜叶绿体AsA-GSH循环及叶黄素稳态的影响. 园艺学报, 2017, 44(5): 881-890. doi: 10.16420/j.issn.0513-353x.2016-0877
	YUAN L Y, WANG C G, HUANG X X, TANG L, HOU J F, LIU F, WANG L, ZHU S D. The regulation of 24-epibrassinolide on AsA-GSH cycle and xanthophylls homeostasis in chloroplast of cucumber under Ca(NO₃)₂ stress. Acta Horticulturae Sinica, 2017, 44(5): 881-890. (in Chinese)
[16]	马超, 张均, 王学平, 贾琦石, 原佳乐, 张苏, 冯雅岚. 外源MeJA对花后干旱胁迫下小麦光合特性的影响. 麦类作物学报, 2018, 38(5): 563-571.
	MA C, ZHANG J, WANG X P, JIA Q S, YUAN J L, ZHANG S, FENG Y L. Effect of exogenous methyl jasmonate on photosynthetic characteristics in wheat under drought stress after anthesis. Journal of Triticeae Crops, 2018, 38(5): 563-571. (in Chinese)
[17]	HAJIBOLAND R, JOUDMAND A, ALIASGHARZAD N, TOLRÁ R, POSCHENRIEDER C. Arbuscular mycorrhizal fungi alleviate low-temperature stress and increase freezing resistance as a substitute for acclimation treatment in barley. Crop and Pasture Science, 2019, 70(3): 218-233.
[18]	ZHU X C, SONG F B, XU H W. Arbuscular mycorrhizae improves low temperature stress in maize via alterations in host water status and photosynthesis. Plant and Soil, 2010, 331: 129-137.
[19]	SU F, JACQUARD C, VILLAUME S, MICHEL J, RABENOELINA F, CLEMENT C, BARKA E A, DHONDT-CORDELIER S, VAILLANT-GAVEAU N. Burkholderia phytofirmans PsJN reduces impact of freezing temperatures on photosynthesis in Arabidopsis thaliana. Frontiers in Plant Science, 2015, 6: 810.
[20]	CAO S M, YANG F, ZHANG H H, WANG Q M, XU G G, ZHU B S, WU C X. Physiological and transcriptome profiling analyses reveal important roles of Streptomyces rochei D74 in improving drought tolerance of Puccinellia distans (Jacq.) Parl. Environmental and Experimental Botany, 2023, 207: 105204.
[21]	NIU S Q, GAO Y, ZI H X, LIU Y, LIU X M, XIONG X Q, YAO Q Q, QIN Z W, CHEN N, GUO L, YANG Y Z, QIN P, LIN J Z, ZHU Y H. The osmolyte-producing endophyte Streptomyces albidoflavus OsiLf-2 induces drought and salt tolerance in rice via a multi-level mechanism. The Crop Journal, 2022, 10(2): 375-386.
[22]	MATHUR S, JAJOO A. Arbuscular mycorrhizal fungi protects maize plants from high temperature stress by regulating photosystem II heterogeneity. Industrial Crops and Products, 2020, 143: 111934.
[23]	MA J, PENG J L, TIAN S, HE Y X, ZHANG C M, JIA N, WANG E T, WANG Z W, HU D. Streptomyces sp. TOR3209 alleviates cold stress in tomato plants. New Zealand Journal of Crop and Horticultural Science, 2023, 51(4): 662-682.
[24]	HU D, LI S H, LI Y, PENG J L, WEI X Y, MA J, ZHANG C M, JIA N, WANG E T, WANG Z W. Streptomyces sp. strain TOR3209: A rhizosphere bacterium promoting growth of tomato by affecting the rhizosphere microbial community. Scientific Reports, 2020, 10: 20132.
[25]	LI Q, CHEN L S, JIANG H X, TANG N, YANG L T, LIN Z H, LI Y, YANG G H. Effects of manganese-excess on CO₂ assimilation, ribulose-1, 5-bisphosphate carboxylase/oxygenase, carbohydrates and photosynthetic electron transport of leaves, and antioxidant systems of leaves and roots in Citrus grandis seedlings. BMC Plant Biology, 2010, 10(1): 42.
[26]	STRASSER R J, TSIMILLI-MICHAEL M, SRIVASTAVA A. Analysis of the chlorophyll a fluorescence transient//Chlorophyll a Fluorescence. Advances in Photosynthesis and Respiration. Dordrecht: Springer Netherlands, 2004: 321-362.
[27]	张忠学, 郑恩楠, 王长明, 贠宁晗. 不同水氮处理对水稻荧光参数和光合特性的影响. 农业机械学报, 2017, 48(6): 176-183.
	ZHANG Z X, ZHENG E N, WANG C M, YUN N H. Effect of different water and nitrogen levels on chlorophyll fluorescence parameters and photosynthetic characteristics of rice. Transactions of the Chinese Society for Agricultural Machinery, 2017, 48(6): 176-183. (in Chinese)
[28]	BETHMANN S, MELZER M, SCHWARZ N, JAHNS P. The zeaxanthin epoxidase is degraded along with the D1 protein during photoinhibition of photosystem II. Plant Direct, 2019, 3(11): e00185.
[29]	陈华新, 陈玮, 姜闯道, 高辉远, 邹琦. 光温交叉处理对小麦紫黄质脱环氧化酶活性及其热耗散能力的影响. 植物生态学报, 2008, 32(5): 1015-1022. doi: 10.3773/j.issn.1005-264x.2008.05.006
	CHEN H X, CHEN W, JIANG C D, GAO H Y, ZOU Q. Effects of temperature and light treatment on violaxanthin de-epoxidase activity and xanthophyll cycle-dependent energy dissipation in wheat leaves. Journal of Plant Ecology, 2008, 32(5): 1015-1022. (in Chinese)
[30]	COSTA H, GALLEGO S M, TOMARO M L. Effect of UV-B radiation on antioxidant defense system in sunflower cotyledons. Plant Science, 2002, 162: 939-945.
[31]	苏晓琼, 王美月, 束胜, 孙锦, 郭世荣. 外源亚精胺对高温胁迫下番茄幼苗快速叶绿素荧光诱导动力学特性的影响. 园艺学报, 2013, 40(12): 2409-2418.
	SU X Q, WANG M Y, SHU S, SUN J, GUO S R. Effects of exogenous Spd on the fast chlorophyll fluorescence induction dynamics in tomato seedlings under high temperature stress. Acta Horticulturae Sinica, 2013, 40(12): 2409-2418. (in Chinese)
[32]	石嘉琦, 刘宇庆, 王艳玲, 杨再强. 施氮对高温胁迫下黄瓜果期荧光特性的影响. 华北农学报, 2022, 37(2): 84-95. doi: 10.7668/hbnxb.20192694
	SHI J Q, LIU Y Q, WANG Y L, YANG Z Q. Effects of nitrogen application on fluorescence characteristics of cucumber in fruit growth stage under high temperature stress. Acta Agriculturae Boreali-Sinica, 2022, 37(2): 84-95. (in Chinese) doi: 10.7668/hbnxb.20192694
[33]	顾博文, 杨劲峰, 鲁晓玲, 吴怡慧, 李娜, 刘宁, 安宁, 韩晓日. 连续施用生物炭对花生不同生育时期叶绿素荧光特性的影响. 中国农业科学, 2021, 54(21): 4552-4561. doi: 10.3864/j.issn.0578-1752.2021.21.006.
	GU B W, YANG J F, LU X L, WU Y H, LI N, LIU N, AN N, HAN X R. Effects of continuous application of biochar on chlorophyll fluorescence characteristics of peanut at different growth stages. Scientia Agricultura Sinica, 2021, 54(21): 4552-4561. doi: 10.3864/j.issn.0578-1752.2021.21.006. (in Chinese)
[34]	FENG Y, CAO K. Photosynthesis and photoinhibition after night chilling in seedlings of two tropical tree species grown under three irradiances. Photosynthetica, 2005, 43(4): 567-574.
[35]	刘欣悦, 刘轶飞, 易伯涛, 孙志宇, 张思威, 马明珠, 韩晓日. 外源钙缓解花生低温光合障碍的调控机制. 植物营养与肥料学报, 2022, 28(2): 291-301.
	LIU X Y, LIU Y F, YI B T, SUN Z Y, ZHANG S W, MA M Z, HAN X R. Foliar calcium application alleviates cold stress-induced photosynthetic inhibition in peanut. Journal of Plant Nutrition and Fertilizers, 2022, 28(2): 291-301. (in Chinese)
[36]	ZHANG Z S, LI G, GAO H Y, ZHANG L T, YANG C, LIU P, MENG Q. Characterization of photosynthetic performance during senescence in stay-green and quick-leaf-senescence Zea mays L. inbred lines. PLoS ONE, 2012, 7(8): e42936.
[37]	YAN K, HE W J, BIAN L X, ZHANG Z S, TANG X L, AN M X, LI L X, HAN G X. Salt adaptability in a halophytic soybean (Glycine soja) involves photosystems coordination. BMC Plant Biology, 2020, 20: 155. doi: 10.1186/s12870-020-02371-x pmid: 32276592
[38]	WU Y X, WANG X, PENG X Y, GE J K, CAI J, HUANG M, ZHOU Q, ZHONG Y X, JIANG D. Cold priming improves chilling resistance in wheat seedlings: Changing of photosystem II imprints during recovery from priming. Environmental and Experimental Botany, 2023, 207: 105220.
[39]	DASTOGEER K M G, ZAHAN M I, RHAMAN M S, SARKER M S A, CHAKRABORTY A. Microbe-mediated thermotolerance in plants and pertinent mechanisms - A meta-analysis and review. Frontiers in Microbiology, 2022, 13: 833566.
[40]	JIANG Y, FENG X, WANG H, CHEN Y Q, SUN Y J. Heat-induced down-regulation of photosystem II protects photosystem I in honeysuckle (Lonicera japonica). Journal of Plant Research, 2021, 134: 1311-1321. doi: 10.1007/s10265-021-01336-x pmid: 34351552
[41]	李鹏民, 高辉远, STRASSER R J. 快速叶绿素荧光诱导动力学分析在光合作用研究中的应用. 植物生理与分子生物学学报, 2005, 31(6): 559-566.
	LI P M, GAO H Y, STRASSER R J. Application of the fast chlorophyll fluorescence induction dynamics analysis in photosynthesis study. Acta Photophysiologica Sinica, 2005, 31(6): 559-566. (in Chinese)
[42]	CHEN K, ZHANG M, ZHU H, HUANG M Y, ZHU Q, TANG D Y, HAN X L, LI J L, SUN J, FU J M. Ascorbic acid alleviates damage from heat stress in the photosystem II of tall fescue in both the photochemical and thermal phases. Frontiers in Plant Science, 2017, 8: 1373. doi: 10.3389/fpls.2017.01373 pmid: 28848577
[43]	吴思佳, 李仁英, 谢晓金, 张婍, 陈佳林, 徐向华, 胡宗荟, 卢炳浩, 张娜. 抽穗期高温对水稻叶片光合特性、叶绿素荧光特性和产量构成因素的影响. 南方农业学报, 2021, 52(1): 20-27.
	WU S J, LI R Y, XIE X J, ZHANG Q, CHEN J L, XU X H, HU Z H, LU B H, ZHANG N. Effects of high temperature on characteristics of photosynthesis and chlorophyll fluorescence and yield components of rice at heading stage. Journal of Southern Agriculture, 2021, 52(1): 20-27. (in Chinese)
[44]	ZHANG H H, LI X, CHE Y H, WANG Y, LI M B, YANG R Y, XU N, SUN G Y. A study on the effects of salinity and pH on PSII function in mulberry seedling leaves under saline-alkali mixed stress. Trees, 2020, 34(3): 693-706.
[45]	徐超, 王明田, 杨再强, 韩玮, 郑盛华. 高温对温室草莓光合生理特性的影响及胁迫等级构建. 应用生态学报, 2021, 32(1): 231-240. doi: 10.13287/j.1001-9332.202101.028
	XU C, WANG M T, YANG Z Q, HAN W, ZHENG S H. Effects of high temperature on photosynthetic physiological characteristics of strawberry seedlings in greenhouse and construction of stress level. Chinese Journal of Applied Ecology, 2021, 32(1): 231-240. (in Chinese) doi: 10.13287/j.1001-9332.202101.028
[46]	ÇIÇEK N, PEKCAN V, ARSLAN O, ERDAL S C, NALCAIYI A S B, CIL A N, ŞAHIN V, KAYA Y, EKMEKCI Y. Assessing drought tolerance in field-grown sunflower hybrids by chlorophyll fluorescence kinetics. Brazilian Journal of Botany, 2019, 42(2): 249-260.
[47]	刘倩倩, 马寿宾, 冯希环, 孙艳, 衣艳君, 刘维信. 嫁接对高温和低温胁迫下辣椒幼苗快速叶绿素荧光诱导动力学特性的影响. 园艺学报, 2016, 43(5): 885-896. doi: 10.16420/j.issn.0513-353x.2015-0970
	LIU Q Q, MA S B, FENG X H, SUN Y, YI Y J, LIU W X. Effects of grafting on the fast chlorophyll fluorescence induction dynamics of pepper seedlings under temperature stress. Acta Horticulturae Sinica, 2016, 43(5): 885-896. (in Chinese)
[48]	孙德智, 韩晓日, 彭靖, 范富, 张庆国. 外源NO对Ca(NO₃)₂胁迫下番茄幼苗PSII功能及光能分配利用的影响. 核农学报, 2016, 30(12): 2451-2459. doi: 10.11869/j.issn.100-8551.2016.12.2451
	SUN D Z, HAN X R, PENG J, FAN F, ZHANG Q G. Effect of exogenous nitric oxide on PSII function and distribution and utilization of luminous energy in tomato seedlings under stress of Ca(NO₃)₂. Journal of Nuclear Agricultural Sciences, 2016, 30(12): 2451-2459. (in Chinese)
[49]	ZUSHI K, KAJIWARA S, MATSUZOE N. Chlorophyll a fluorescence OJIP transient as a tool to characterize and evaluate response to heat and chilling stress in tomato leaf and fruit. Scientia Horticulturae, 2012, 148: 39-46.
[50]	吴含玉, 肖飞, 张亚黎, 姜闯道, 张旺锋. 强闪光抑制棉花叶片光系统II活性和热耗散. 作物学报, 2019, 45(5): 792-797. doi: 10.3724/SP.J.1006.2019.84104
	WU H Y, XIAO F, ZHANG Y L, JIANG C D, ZHANG W F. Repetitive intense flashes inhibit photosystem II activity and thermal dissipation in cotton leaves. Acta Agronomica Sinica, 2019, 45(5): 792-797. (in Chinese)
[51]	刘建新, 王金成, 王瑞娟, 刘秀丽. 混合盐碱胁迫对燕麦幼苗矿质离子吸收和光合特性的影响. 干旱地区农业研究, 2017, 35(1): 178-184, 239.
	LIU J X, WANG J C, WANG R J, LIU X L. Effect of complex saline-alkali stress on the mineral ions absorption and photosynthetic characteristics of oat seedlings. Agricultural Research in the Arid Areas, 2017, 35(1): 178-184, 239. (in Chinese)
[52]	刘文娟, 常丽娟, 岳丽杰, 宋君, 张富丽, 王东, 吴佳蔚, 郭灵安, 雷绍荣. 两个玉米品种维管束鞘叶绿体的非光化学淬灭对干旱胁迫的响应. 中国农业科学, 2020, 53(8): 1532-1544. doi: 10.3864/j.issn.0578-1752.2020.08.004.
	LIU W J, CHANG L J, YUE L J, SONG J, ZHANG F L, WANG D, WU J W, GUO L A, LEI S R. Response of non-photochemical quenching in bundle sheath chloroplasts of two maize hybrids to drought stress. Scientia Agricultura Sinica, 2020, 53(8): 1532-1544. doi: 10.3864/j.issn.0578-1752.2020.08.004. (in Chinese)
[53]	胡雪华, 刘宁宁, 陶慧敏, 彭可佳, 夏晓剑, 胡文海. 低温胁迫对番茄幼苗不同叶龄叶片叶绿素荧光成像特性的影响. 中国农业科学, 2022, 55(24): 4969-4980. doi: 10.3864/j.issn.0578-1752.2022.24.014.
	HU X H, LIU N N, TAO H M, PENG K J, XIA X J, HU W H. Effects of chilling on chlorophyll fluorescence imaging characteristics of leaves with different leaf ages in tomato seedlings. Scientia Agricultura Sinica, 2022, 55(24): 4969-4980. doi: 10.3864/j.issn.0578-1752.2022.24.014. (in Chinese)
[54]	WEI D D, ZHANG T P, WANG B Q, ZHANG H L, MA M Y, LI S F, CHEN T H H, BRESTIC M, LIU Y, YANG X H. Glycinebetaine mitigates tomato chilling stress by maintaining high-cyclic electron flow rate of photosystem I and stability of photosystem II. Plant Cell Reports, 2022, 41(4): 1087-1101. doi: 10.1007/s00299-022-02839-0 pmid: 35150305
[55]	JAHNS P, HOLZWARTH A R. The role of the xanthophyll cycle and of lutein in photoprotection of photosystem II. Biochimica et Biophysica Acta (BBA)-Bioenergetics, 2012, 1817(1): 182-193.
[56]	HALLIN E I, GUO K, AKERLUND H E. Violaxanthin de-epoxidase disulphides and their role in activity and thermal stability. Photosynthesis Research, 2015, 124(2): 191-198. doi: 10.1007/s11120-015-0118-9 pmid: 25764016
[57]	WANG P, YIN L, LIANG D, LI C, MA F W, YUE Z Y. Delayed senescence of apple leaves by exogenous melatonin treatment: Toward regulating the ascorbate-glutathione cycle. Journal of Pineal Research, 2012, 53(1): 11-20. doi: 10.1111/j.1600-079X.2011.00966.x pmid: 21988707
[58]	SUBRAMANIAN P, KIM K, KRISHNAMOORTHY R, MAGESWARI A, SELVAKUMAR G, SA T. Cold stress tolerance in psychrotolerant soil bacteria and their conferred chilling resistance in tomato (Solanum lycopersicum Mill.) under low temperatures. PLoS ONE, 2016, 11(8): e0161592.
[59]	LI J H, ARKORFUL E, CHENG S Y, ZHOU Q Q, LI H, CHEN X, SUN K, LI X H. Alleviation of cold damage by exogenous application of melatonin in vegetatively propagated tea plant (Camellia sinensis (L.) O. Kuntze). Scientia Horticulturae, 2018, 238: 356-362.
[60]	LI L J, LU X C, MA H Y, LYU D G. Jasmonic acid regulates the ascorbate-glutathione cycle in Malus baccata Borkh. roots under low root-zone temperature. Acta Physiologiae Plantarum, 2017, 39: 174.
[61]	ZHAO H L, YE L, WANG Y P, ZHOU X T, YANG J W, WANG J W, CAO K, ZOU Z R. Melatonin increases the chilling tolerance of chloroplast in cucumber seedlings by regulating photosynthetic electron flux and the ascorbate-glutathione cycle. Frontiers in Plant Science, 2016, 7: 1814. doi: 10.3389/fpls.2016.01814 pmid: 27999581

叶黄素循环 Xanthophyll cycle	处理 Treatment	0 d	1 d	3 d	6 d	10 d
总叶黄素 Total xanthophyll (mmol·mol^-1 Chl)	TOR3209+C	111.77±4.15a	81.41±2.64ab	109.82±4.46a	79.66±5.30ab	76.05±10.87ab
	NI+C	86.36±19.24a	67.64±5.15b	69.91±10.00b	63.52±7.64b	62.81±4.93b
	TOR3209	111.77±4.15a	92.65±12.30a	109.43±17.44a	98.33±5.46a	89.84±2.18a
	NI	86.36±19.24a	79.11±10.14ab	77.46±13.24b	73.04±22.03b	83.84±7.44a
叶黄素脱环氧化状态DEPS	TOR3209+C	70.96±7.05a	74.94±2.49a	80.32±3.72a	89.13±1.48a	91.26±0.40a
	NI+C	63.79±8.78a	70.15±3.11ab	77.11±4.04ab	82.31±1.78a	85.86±2.37b
	TOR3209	70.96±7.05a	74.56±4.04a	73.85±1.95bc	71.30±4.65b	70.08±2.22c
	NI	63.79±8.78a	66.30±4.49b	70.75±2.54c	68.29±7.46b	65.50±2.26d

处理 Treatment	VDE活性VDE activity (μmol·min^-1·g^-1)
处理 Treatment	0 d	1 d	3 d	6 d	10 d
TOR3209+C	3.00±0.07a	3.58±0.03a	3.11±0.09a	3.60±0.03a	3.28±0.09a
NI+C	2.90±0.10a	2.10±0.10d	1.56±0.07d	1.68±0.05d	1.69±0.09d
TOR3209	3.00±0.07a	2.96±0.08b	2.72±0.14b	2.75±0.01b	3.08±0.05b
NI	2.90±0.10a	2.40±0.07c	2.21±0.10c	1.83±0.08c	2.56±0.03c

抗氧化剂 Antioxidant	处理 Treatment	0 d	1 d	3 d	6 d	10 d
抗坏血酸 AsA	含量Content (μg·g^-1)
	TOR3209+C	391.26±127.99a	443.84±64.03c	572.45±101.04b	461.70±55.45ab	293.58±90.89c
	NI+C	362.86±90.38a	363.85±30.57c	395.99±47.24c	388.44±33.12b	283.26±94.51c
	TOR3209	391.26±127.99a	827.13±42.62a	819.71±35.95a	520.25±82.13a	602.01±42.44a
	NI	362.86±90.38a	687.80±28.62b	628.16±64.83b	485.52±36.93ab	461.76±56.24b
	F值F value
	T	ns	18.119**	22.651**	ns	ns
	C	ns	196.438***	38.447***	5.939*	32.101***
	T×C	ns	ns	ns	ns	ns
还原型谷胱甘肽 GSH	含量Content (μmol·g^-1)
	TOR3209+C	0.48±0.10a	0.49±0.09b	0.61±0.08ab	0.83±0.03b	0.60±0.09c
	NI+C	0.44±0.09a	0.47±0.12b	0.55±0.04b	0.82±0.17b	0.53±0.06c
	TOR3209	0.48±0.10a	0.88±0.09a	0.75±0.10a	1.77±0.08a	1.72±0.12a
	NI	0.44±0.09a	0.54±0.10b	0.69±0.09ab	1.08±0.22b	1.02±0.08b
	F值F value
	T	ns	9.542*	ns	16.968**	53.589***
	C	ns	14.994**	8.396*	49.793***	232.974***
	T×C	ns	7.099*	ns	16.350**	35.053***

抗氧化酶 Antioxidase	处理 Treatment	0 d	1 d	3 d	6 d	10 d
抗坏血酸过氧化物酶 APX	酶活性Enzyme activity (nmol·min^-1·g^-1)
	TOR3209+C	664.38±8.71a	386.95±9.57b	227.79±6.31c	517.68±42.28c	248.32±43.18c
	NI+C	422.43±35.46b	227.15±20.83c	127.61±19.59d	219.01±13.23d	252.45±27.61c
	TOR3209	664.38±8.71a	542.77±33.78a	947.39±54.25a	969.51±24.93a	519.76±27.57a
	NI	422.43±35.46b	507.89±12.78a	402.39±13.43b	611.92±23.67b	331.44±20.41b
	F值F value
	T	263.408***	62.140***	352.071***	410.892***	26.757**
	C	ns	312.452***	836.310***	680.805***	96.849***
	T×C	ns	25.586**	167.349***	ns	29.211**
谷胱甘肽还原酶 GR	酶活性Enzyme activity (U·g^-1)
	TOR3209+C	638.41±78.70a	508.06±32.07ab	418.70±20.40b	291.26±22.55b	491.78±47.88a
	NI+C	404.28±48.16b	466.47±62.81b	176.15±35.84c	258.16±55.02b	342.97±59.97b
	TOR3209	638.41±78.70a	595.77±51.74a	614.98±52.69a	590.94±89.21a	563.92±95.40a
	NI	404.28±48.16b	584.72±51.32a	548.91±88.40a	533.82±92.16a	505.00±6.97a
	F值F value
	T	38.632***	ns	23.248**	ns	8.608*
	C	ns	12.373**	79.035***	49.680***	10.940*
	T×C	ns	ns	7.602*	ns	ns
单脱氢抗坏血酸还原酶 MDHAR	酶活性Enzyme activity (nmol·min^-1·g^-1)
	TOR3209+C	108.54±24.98a	101.16±46.02ab	81.88±11.51a	119.43±18.93a	104.10±18.42a
	NI+C	56.38±16.37b	44.77±2.42b	45.43±10.95b	73.52±8.65ab	63.63±10.29ab
	TOR3209	108.54±24.98a	116.62±40.55a	63.69±8.57ab	79.40±37.78ab	107.44±44.15a
	NI	56.38±16.37b	70.41±16.08ab	48.74±9.62b	60.62±21.43b	44.43±5.93b
	F值F value
	T	18.297**	7.841*	18.949**	5.411*	13.221**
	C	ns	ns	ns	ns	ns
	T×C	ns	ns	ns	ns	ns
