棉花纤维优势表达基因GhSLD1启动子的克隆和功能分析

doi:10.3864/j.issn.0578-1752.2023.19.002

摘要/Abstract

摘要：

【目的】棉花纤维是棉花的主要经济产品，是由胚珠外珠被表皮细胞经极性伸长和次生壁加厚而成的单细胞。棉花纤维细胞是最长的植物细胞之一，是研究植物细胞生长发育的理想材料。鉴定纤维细胞特异或优势表达启动子可为纤维发育的基础研究提供控制目标基因表达的调控序列，为改良纤维性状的分子育种提供依据。【方法】克隆纤维细胞优势表达基因GhSLD1的启动子，通过启动子序列分析网站PlantCARE分析克隆序列中包含的重要顺式调控元件。根据部分重要顺式调控元件的分布，对克隆启动子片段进行5′-端删除，共获得4个启动子片段，并构建了相应的植物表达载体。利用构建的植物表达载体进行烟草和棉花的遗传转化，通过转基因烟草和棉花的分子鉴定明确转基因植株。并检测转基因植株不同组织器官、纤维细胞不同发育时期的GUS活性。【结果】克隆获得最长启动子片段为2 900 bp，除了包含多个启动子必备转录调控元件外，还包含多个脱落酸响应元件、厌氧诱导元件、茉莉酸甲酯响应元件、油菜素内酯响应元件、种子特异调控元件、胁迫响应元件和MYB转录因子结合位点。通过5′-端删除获得长度分别为2 900（GhSLD-P1）、2 178（GhSLD1-P2）、1 657（GhSLD1-P3）和1 232 bp（GhSLD-P4）4个启动子片段，经分子鉴定，获得4个片段的转基因烟草，在转基因烟草中，GhSLD-P1、GhSLD1-P2和GhSLD1-P3不表达，而GhSLD-P4广泛表达，表达强度与CaMV 35S启动子相似。GhSLD1-P3和GhSLD-P4差异序列中包含4个脱落酸响应元件、2个油菜素内酯响应元件和3个MYB结合位点，这些顺式调控元件可能与GhSLD1-P1、GhSLD1-P2和GhSLD1-P3在转基因烟草中不表达有一定关系。经分子鉴定，获得GhSLD1-P2转基因棉花。GhSLD1-P2在转基因棉花纤维中优势表达，在转基因花粉中有较低的表达，在其他组织器官中几乎不表达。在纤维细胞的生长发育过程中，GhSLD1-P2在纤维细胞早期生长阶段（5 DPA）表达较低，在纤维细胞伸长期（10—15 DPA）表达水平相对较高，在纤维细胞次生壁合成期（20—30 DPA）表达水平有所降低。【结论】GhSLD1-P4启动子是一个广泛表达启动子，GhSLD1-P2启动子是一个纤维细胞优势表达启动子，在纤维细胞伸长期表达量相对较高。可应用于棉花纤维发育相关基因的功能研究和改良纤维性状的分子育种。

关键词: 棉花, 启动子, 功能分析, GhSLD1, 鞘脂delta8-去饱和酶

Abstract:

【Objective】Cotton fiber is the main economic product of cotton. It is the epidermal cells of the ovule outer integument through polar elongation and secondary wall thickening. As one of the longest plant cells, the cotton fiber cells are regarded as an ideal material in the study of plant cell growth and development. Identification of promoters specifically or preferentially expressed in fiber cells is of great significance for basic research on fiber development and molecular breeding for improving fiber traits. 【Method】In this study, we cloned the promoter of GhSLD1 gene, which is predominantly expressed in fiber cells. Through the PlantCARE website for promoter sequence analysis, we identified the important cis-regulatory elements contained in the cloned sequence. According to the distribution of some important cis-regulatory elements, the cloned promoter fragments were deleted at 5′- end. A total of 4 promoter fragments were obtained and the corresponding plant expression vector was constructed. The constructed plant expression vectors were used for genetic transformation of tobacco and cotton. The transgenic plants were identified through molecular identification of transgenic tobacco and cotton. GUS activity in different tissues, organs and fiber cells of transgenic plants at different development stages was also investigated. 【Result】The longest promoter cloned was 2 900 bp in length. In addition to a lot of transcription regulatory elements in the promoter, the sequence also contained multiple abscisic acid response elements, the elements essential for the anaerobic induction, methyl jasmonate response elements, brassinolide response elements, the elements involved in seed-specific regulation, the elements involved in defense and stress responsiveness, and MYB transcription factor binding sites. Four promoter fragments with a length of 2 900 bp (GhSLD-P1), 2 178 bp (GhSLD1-P2), 1 657 bp (GhSLD1-P3) and 1 232 bp (GhSLD-P4) were obtained by the 5′-terminal deletion, respectively. The transgenic tobacco plants were generated after confirmed by molecular identification. GhSLD-P1, GhSLD1-P2 and GhSLD1-P3 did not express in transgenic tobacco, while GhSLD-P4 is widely expressed, and the expression level of GhSLD-P4 was similar to that of CaMV 35S promoter. The different sequence between GhSLD1-P3 and GhSLD-P4 contained four abscisic acid response elements, two brassinolide response elements, and three MYB binding sites. These cis-regulatory elements may be associated with the non-expression of GhSLD1-P1, GhSLD1-P2, and GhSLD1-P3 promoters in transgenic tobacco. The transgenic cotton plants of GhSLD1-P2 were obtained after confirmed by molecular identification. GhSLD1-P2 predominantly expressed in transgenic cotton fibers, and its expression level was higher at the elongation stage (10-15 DPA) of fiber cells while lower in the early developmental stage (5 DPA) of fiber cells and the stage of secondary cell wall deposition (20-30 DPA). 【Conclusion】The GhSLD1-P4 promoter was a widely expressed promoter, and the GhSLD1-P2 promoter was a fiber predominant expression promoter, which was highly expressed during the elongation of fibers. It could be applied to the study on the gene function involved in cotton fiber development and molecular breeding for improving fiber traits.

Key words: cotton, promoter, functional characterization, GhSLD1, sphingolipid delta8-desaturase

刘芳, 徐梦贝, 王巧玲, 孟倩, 李桂名, 张宏菊, 田惠丹, 徐凡, 罗明. 棉花纤维优势表达基因GhSLD1启动子的克隆和功能分析[J]. 中国农业科学, 2023, 56(19): 3712-3722.

LIU Fang, XU MengBei, WANG QiaoLing, MENG Qian, LI GuiMing, ZHANG HongJu, TIAN HuiDan, XU Fan, LUO Ming. Cloning and Functional Characterization of the Promoter of GhSLD1 Gene That Predominantly Expressed in Cotton Fiber[J]. Scientia Agricultura Sinica, 2023, 56(19): 3712-3722.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2023.19.002

https://www.chinaagrisci.com/CN/Y2023/V56/I19/3712

图/表 10

图1

图2

表1

图3

图4

图5

图6

图7

图8

图9

参考文献 32

[1]	JOHN M E, CROW L J. Gene expression in cotton (Gossypium hirsutum L.) fiber: Cloning of the mRNAs. Proceedings of the National Academy of Sciences of the United States of America, 1992, 89(13): 5769-5773.
[2]	JOHN M E, KELLER G. Metabolic pathway engineering in cotton: Biosynthesis of polyhydroxybutyrate in fiber cells. Proceedings of the National Academy of Sciences of the United States of America, 1996, 93(23): 12768-12773.
[3]	于晓红, 朱勇清, 林芝萍, 陈晓亚, 许智宏. 亚洲棉GAE6-3A上游序列的分离及其在烟草中的表达. 植物生理学报, 2000, 26(2): 143-147, 180.
	YU X H, ZHU Y Q, LIN Z P, CHEN X Y, XU Z H. Isolation of GAE6-3A upstream fragment from Gossypium arboreum and its expression in tobacco. Acta Photophysiologica Sinica, 2000, 26(2): 143-147, 180. (in Chinese)
[4]	吴蔼民, 刘进元. 棉花半乳糖苷酶基因启动子的分离及其在转基因烟草中的表达. 中国科学C辑: 生命科学, 2005, 35(5): 389-397.
	WU A M, LIU J Y. Isolation of cotton galactosidase gene promoter and its expression in transgenic tobacco. Science in China Ser.C Life Sciences, 2005, 35(5): 389-397. (in Chinese)
[5]	RINEHART J A, PETERSEN M W, JOHN M E. Tissue-specific and developmental regulation of cotton gene FbL2A (demonstration of promoter activity in transgenic plants). Plant Physiology, 1996, 112(3): 1331-1341. doi: 10.1104/pp.112.3.1331
[6]	DELANEY S K, ORFORD S J, MARTIN-HARRIS M, TIMMIS J N. The fiber specificity of the cotton FSltp4 gene promoter is regulated by an AT-Rich promoter region and the AT-Hook transcription factor GhAT1. Plant and Cell Physiology, 2007, 48(10): 1426-1437. doi: 10.1093/pcp/pcm111
[7]	MA D P, TAN H, SI Y, CREECH R G, JENKINS J N. Differential expression of a lipid transfer protein gene in cotton fiber. Biochimica et Biophysica Acta (BBA) - Lipids and Lipid Metabolism, 1995, 1257(1): 81-84. doi: 10.1016/0005-2760(95)00077-P
[8]	MA D P, LIU H C, TAN H, CREECH R G, JENKINS J N, CHANG Y F. Cloning and characterization of a cotton lipid transfer protein gene specifically expressed in fiber cells. Biochimica et Biophysica Acta(BBA)-Lipids and Lipid Metabolism, 1997, 1344(2): 111-114.
[9]	LIU H C, CREECH R G, JENKINS J N, MA D P. Cloning and promoter analysis of the cotton lipid transfer protein gene Ltp3(1). Biochimica Et Biophysica Acta(BBA)-Lipids and Lipid Metabolism, 2000, 1487(1): 106-111.
[10]	HSU C Y, CREECH R G, JENKINS J N, MA D P. Analysis of promoter activity of cotton lipid transfer protein gene LTP6 in transgenic tobacco plants. Plant Science, 1999, 143(1): 63-70. doi: 10.1016/S0168-9452(99)00026-6
[11]	WU A M, HU J S, LIU J Y. Functional analysis of a cotton cellulose synthase A4 gene promoter in transgenic tobacco plants. Plant Cell Reports, 2009, 28(10): 1539-1548. doi: 10.1007/s00299-009-0753-8
[12]	KIM H J, MURAI N, FANG D D, TRIPLETT B A. Functional analysis of Gossypium hirsutum cellulose synthase catalytic subunit 4 promoter in transgenic Arabidopsis and cotton tissues. Plant Science, 2011, 180(2): 323-332. doi: 10.1016/j.plantsci.2010.10.003
[13]	LI X B, FAN X P, WANG X L, CAI L, YANG W C. The cotton ACTIN1 gene is functionally expressed in fibers and participates in fiber elongation. The Plant Cell, 2005, 17(3): 859-875. doi: 10.1105/tpc.104.029629
[14]	DENG F L, TU L L, TAN J F, LI Y, NIE Y C, ZHANG X L. GbPDF1 is involved in cotton fiber initiation via the core cis-element HDZIP2ATATHB2. Plant Physiology, 2011, 158(2): 890-904. doi: 10.1104/pp.111.186742
[15]	HO M H, SAHA S, JENKINS J N, MA D P. Characterization and promoter analysis of a cotton RING-type ubiquitin ligase (E3) gene. Molecular Biotechnology, 2010, 46(2): 140-148. doi: 10.1007/s12033-010-9280-7
[16]	HOU L, LIU H, LI J B, YANG X, XIAO Y H, LUO M, SONG S Q, YANG G W, PEI Y. SCFP, a novel fiber-specific promoter in cotton. Chinese Science Bulletin, 2008, 53(17): 2639-2645.
[17]	LI Y, TU L L, YE Z Z, WANG M J, GAO W H, ZHANG X L. A cotton fiber-preferential promoter, PGbEXPA2, is regulated by GA and ABA in Arabidopsis. Plant Cell Reports, 2015, 34(9): 1539-1549. doi: 10.1007/s00299-015-1805-x
[18]	胡海燕, 刘迪秋, 李允静, 李阳, 涂礼莉. 一个棉花纤维伸长期优势表达启动子pGhFLA1的克隆与鉴定. 作物学报, 2017, 43(6): 849-854.
	HU H Y, LIU D Q, LI Y J, LI Y, TU L L. Identification of promoter GhFLA1 preferentially expressed during cotton fiber elongation. Acta Agronomica Sinica, 2017, 43(6): 849-854. (in Chinese) doi: 10.3724/SP.J.1006.2017.00849
[19]	WANG L, LIU C, LIU Y J, LUO M. Fumonisin B1-induced changes in cotton fiber elongation revealed by sphingolipidomics and proteomics. Biomolecules, 2020, 10(9): 1258. doi: 10.3390/biom10091258
[20]	WANG Q L, MENG Q, XU F, CHEN Q, MA C X, HUANG L, LI G M, LUO M. Comparative metabolomics analysis reveals sterols and sphingolipids play a role in cotton fiber cell initiation. International Journal of Molecular Sciences, 2021, 22(21): 11438. doi: 10.3390/ijms222111438
[21]	CHEN Q, XU F, WANG L, SUO X D, WANG Q L, MENG Q, HUANG L, MA C X, LI G M, LUO M. Sphingolipid profile during cotton fiber growth revealed that a phytoceramide containing hydroxylated and saturated VLCFA is important for fiber cell elongation. Biomolecules, 2021, 11(9): 1352. doi: 10.3390/biom11091352
[22]	LUO M, XIAO Y, LI X, LU X, DENG W, LI D, HOU L, HU M, LI Y, PEI Y. GhDET2, a steroid 5α-reductase, plays an important role in cotton fiber cell initiation and elongation. The Plant Journal, 2007, 51(3): 419-430. doi: 10.1111/j.1365-313X.2007.03144.x
[23]	WANG M J, TU L L, LIN M, LIN Z X, WANG P C, YANG Q Y, YE Z X, SHEN C, LI J Y, ZHANG L, ZHOU X L, NIE X H, LI Z H, GUO K, MA Y Z, HUANG C, JIN S X, ZHU L F, YANG X Y, MIN L, YUAN D J, ZHANG Q H, LINDSEY K, ZHANG X. Asymmetric subgenome selection and cis-regulatory divergence during cotton domestication. Nature Genetics, 2017, 49(4): 579-587. doi: 10.1038/ng.3807 pmid: 28263319
[24]	ZHANG J X, WANG F R, ZHANG C Y, ZHANG J H, CHEN Y, LIU G D, ZHAO Y X, HAO F S, ZHANG J. A novel VIGS method by agroinoculation of cotton seeds and application for elucidating functions of GhBI-1 in salt-stress response. Plant Cell Reports, 2018, 37(8): 1091-1100. doi: 10.1007/s00299-018-2294-5 pmid: 29868984
[25]	ZHANG J, HUANG G Q, ZOU D, YAN J Q, LI Y, HU S, LI X B. The cotton (Gossypium hirsutum) NAC transcription factor (FSN1) as a positive regulator participates in controlling secondary cell wall biosynthesis and modification of fibers. The New Phytologist, 2018, 217(2): 625-640. doi: 10.1111/nph.2018.217.issue-2
[26]	JIANG Y J, GUO W Z, ZHU H Y, RUAN Y L, ZHANG T Z. Overexpression of GhSusA1 increases plant biomass and improves cotton fiber yield and quality. Plant Biotechnology Journal, 2012, 10(3): 301-312. doi: 10.1111/j.1467-7652.2011.00662.x pmid: 22044435
[27]	ZHANG M, ZHENG X L, SONG S Q, ZENG Q W, HOU L, LI D M, ZHAO J, WEI Y, LI X B, LUO M, XIAO Y H, LUO X Y, ZHANG J F, XIANG C B, PEI Y. Spatiotemporal manipulation of auxin biosynthesis in cotton ovule epidermal cells enhances fiber yield and quality. Natture Biotechnology, 2011, 29(5): 453-458.
[28]	GUAN X Y, YU N, SHANGGUAN X X, WANG S, LU S, WANG L J, CHEN X Y. Arabidopsis trichome research sheds light on cotton fiber development mechanisms. Chinese Science Bulletin, 2007, 52(13): 1734-1741. doi: 10.1007/s11434-007-0273-2
[29]	WANG Z, YANG Z R, LI F G. Updates on molecular mechanisms in the development of branched trichome in Arabidopsis and nonbranched in cotton. Plant Biotechnology Journal, 2019, 17(9): 1706-1722. doi: 10.1111/pbi.v17.9
[30]	WU A M, LING C, LIU J Y. Isolation of a cotton reversibly glycosylated polypeptide (GhRGP1) promoter and its expression activity in transgenic tobacco. Journal of Plant Physiology, 2006, 163(4): 426-435. doi: 10.1016/j.jplph.2005.06.014
[31]	WU A M, LV S Y, LIU J Y. Functional analysis of a cotton glucuronosyltransferase promoter in transgenic tobaccos. Cell Research, 2007, 17(2): 174-183. doi: 10.1038/sj.cr.7310119
[32]	SHANGGUAN X X, XU B, YU Z X, WANG L J, CHEN X Y. Promoter of a cotton fibre MYB gene functional in trichomes of Arabidopsis and glandular trichomes of tobacco. Journal of Experimental Botany, 2008, 59(13): 3533-3542. doi: 10.1093/jxb/ern204

序号No.	功能Function	序列Sequence	正链Strand+	反链Strand-
Ⅰ	脱落酸响应元件 Abscisic acid responsiveness	CACGTG/ACGTG	4
Ⅱ	厌氧诱导元件 Anaerobic induction	AAACCA	4
Ⅲ	茉莉酸甲酯响应元件 MeJA-responsiveness	CGTCA	1
Ⅳ	油菜素内酯响应元件 Brassinolide responsiveness	CANNTG	7	3
V	MYB结合位点 MYB binding site	AACCTAA/TAACCA/ CAACCA/ TAACTG	5	2
VI	种子特异调控元件 Seed-specific regulation	CATGCATG	1
VII	胁迫响应元件 Defense and stress responsiveness	ATTCTCTAAC		1
