苹果幼树根际和根内细菌丰度及根际酶活性对土壤紧实胁迫的响应特征

doi:10.3864/j.issn.0578-1752.2023.13.010

摘要/Abstract

摘要：

【目的】明确引起紧实胁迫下苹果根系微域环境中细菌丰度变化的主要因子，揭示土壤胁迫下苹果根际生物学特征，为果园土壤管理提供参考。【方法】以砧木分别为平邑甜茶（Malus hupehensis Rehd.）和八棱海棠（Malus robusta Rehd.）的2年生‘红富士’苹果（Malus domestica Borkh.cv. Red Fuji）盆栽幼树为试材，通过镇压土壤设置紧实胁迫，检测根际矿质养分含量和土壤酶活性以及根际细菌和根系内生细菌丰度。【结果】无论是红富士/平邑甜茶还是红富士/八棱海棠，土壤紧实胁迫均明显提高苹果根际速效磷和有效钾含量，提高根际过氧化氢酶活性；显著降低根际碱解氮含量和根际蔗糖酶、脲酶、酸性磷酸酶活性，以及根系内生细菌的丰度，并改变根际微生物组成结构。土壤紧实胁迫下，根际细菌数量和丰度、根际荧光素二乙酸酯（fluorescein diacetate，FDA）水解酶活性的变化因砧木而不同，它们在红富士/平邑甜茶中显著降低，降低幅度分别为46.88%、50.50%和29.13%；在红富士/八棱海棠中则显著升高，升高幅度分别为51.41%、20.22%和13.76%。土壤紧实胁迫下，红富士/平邑甜茶根际碱解氮含量、水解酶（蔗糖酶、脲酶、酸性磷酸酶）活性以及根内细菌丰度的下降幅度大于红富士/八棱海棠；红富士/八棱海棠根际比红富士/平邑甜茶具有更强的FDA水解酶活性。冗余分析显示，土壤紧实胁迫下，根际有效钾、碱解氮和FDA水解酶活性对苹果根际和根内细菌丰度变异的解释率最高。【结论】土壤紧实胁迫显著影响苹果根际微生物组成，进而改变根际土壤酶活性和根际有效性矿质养分的含量。根际细菌和FDA水解酶活性的变化因砧木而不同，其在红富士/平邑甜茶中受到土壤紧实胁迫的抑制程度较高。土壤紧实胁迫下，苹果根际有效钾和碱解氮磷含量以及FAD水解酶酶活性的改变与根际和根内细菌丰度的变化存在更密切的关系。

关键词: 土壤紧实, 苹果砧木, 根际, 土壤酶, 根内生细菌

Abstract:

【Objective】The aim of this study was to identify the main factors causing bacterial abundance changed in the apple roots microenvironment under compaction stress, so as to provide a reference for further revealing the biological characteristics of apple rhizosphere and orchard soil management under soil stress.【Method】The experimental materials were potted young apple (Malus domestica Borkh.cv. Red Fuji) tree with the rootstocks of Malus hupehensis Rehd. and Malus robusta Rehd., respectively. After pressing the potted soil to form compaction stress, the rhizosphere mineral nutrient content, soil enzyme activity and the bacterial abundance of rhizosphere and root endosphere were measured.【Result】In both M. huphensis and M. robusta, the soil compaction stress significantly increased rhizosphere available phosphorus content, available potassium content and catalase activity, however, significantly decreased rhizosphere alkaline-hydrolyzed nitrogen content, sucrase activity, urease activity, acid phosphatase activity and root endosphere bacterial abundance. Furthermore, the soil compaction stress also changed the composition and structure of rhizosphere microorganisms. Under soil compaction stress, the amount and abundance of rhizosphere bacterial and the activity of fluorescein diacetate (FDA) hydrolase changed with different rootstocks; however, which were significantly decreased in Red Fuji/M. hupehensis, with the reduction rates were 46.88%, 50.50% and 29.13%, respectively, and significantly increased in Red Fuji/M. robusta, with the increases were 51.41%, 20.22% and 13.76%, respectively. In compacted soil, rhizosphere alkali- hydrolyzed nitrogen content, hydrolase (sucrase, urease, acid phosphatase) activities and the bacterial abundance of root endosphere in Red Fuji/M. hupehensis decreased more than that in Red Fuji/M. robusta. Compared with Red Fuji/M. hupehensis, Red Fuji/M. robusta had stronger FDA hydrolase activity and recruited more rhizosphere bacteria. Redundancy analysis showed that rhizosphere available potassium, alkali-hydrolyzed nitrogen, and FDA hydrolase activities had the highest explanatory rate for variation of bacterial abundance in rhizosphere and root endosphere of apple under soil compaction stress.【Conclusion】The soil compaction stress significantly affected rhizosphere microbial composition, then changed soil enzyme activity and mineral nutrient content in apple rhizosphere. Rhizosphere bacteria and FDA hydrolase activity were different with rootstock, and highly inhibited by soil compaction stress in Red Fuji/M. hupehensis. Under soil compaction stress, the content of rhizosphere available potassium and alkali-hydrolyzed nitrogen, and the activity of rhizosphere FDA hydrolase were more closely related to the abundance of rhizosphere and root endosphere bacteria.

Key words: soil compaction, apple rootstock, rhizosphere, soil enzymes, root endosphere bacteria

李佳琦, 荀咪, 石钧元, 宋建飞, 石宇佳, 张玮玮, 杨洪强. 苹果幼树根际和根内细菌丰度及根际酶活性对土壤紧实胁迫的响应特征[J]. 中国农业科学, 2023, 56(13): 2563-2573.

LI JiaQi, XUN Mi, SHI JunYuan, SONG JianFei, SHI YuJia, ZHANG WeiWei, YANG HongQiang. Response Characteristics of Rhizosphere and Root Endosphere Bacteria and Rhizosphere Enzyme Activities to Soil Compaction Stress in Young Apple Tree[J]. Scientia Agricultura Sinica, 2023, 56(13): 2563-2573.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2023.13.010

https://www.chinaagrisci.com/CN/Y2023/V56/I13/2563

图/表 8

表1

图1

图2

表2

图3

表3

表4

图4

参考文献 39

[1]	LIU H W, BRETTELL L E, QIU Z G, SINGH B K. Microbiome- mediated stress resistance in plants. Trends in Plant Science, 2020, 25(8): 733-743. doi: 10.1016/j.tplants.2020.03.014
[2]	NAWAZ M F, BOURRIÉ G, TROLARD F. Soil compaction impact and modelling. A review. Agronomy for Sustainable Development, 2013, 33(2): 291-309. doi: 10.1007/s13593-011-0071-8
[3]	HERMANS S M, BUCKLEY H L, CASE B S, CURRAN- COURNANE F, TAYLOR M, LEAR G. Using soil bacterial communities to predict physico-chemical variables and soil quality. Microbiome, 2020, 8(1): 79. doi: 10.1186/s40168-020-00858-1 pmid: 32487269
[4]	HUANG G Q, KILIC A, KARADY M, ZHANG J, MEHRA P, SONG X Y, STURROCK C J, ZHU W W, QIN H, HARTMAN S, SCHNEIDER H M, BHOSALE R, DODD I C, SHARP R E, HUANG R F, MOONEY S J, LIANG W Q, BENNETT M J, ZHANG D B, PANDEY B K. Ethylene inhibits rice root elongation in compacted soil via ABA- and auxin-mediated mechanisms. Proceedings of the National Academy of Sciences of the United States of America, 2022, 119(30): e2201072119.
[5]	魏彬萌, 李忠徽, 王益权. 渭北旱塬苹果园土壤紧实化现状及成因. 应用生态学报, 2021, 32(3): 976-982. doi: 10.13287/j.1001-9332.202103.025
	WEI B M, LI Z H, WANG Y Q. Status and causes of soil compaction at apple orchards in the Weibei Dry Highland, North west China. Chinese Journal of Applied Ecology, 2021, 32(3): 976-982. (in Chinese)
[6]	田孝志, 徐龙晓, 宋建飞, 荀咪, 张玮玮, 杨洪强. 土壤紧实度对不同砧木苹果幼树根系H₂S及硫代谢酶的影响. 植物生理学报, 2020, 56(9): 1845-1853.
	TIAN X Z, XU L X, SONG J F, XUN M, ZHANG W W, YANG H Q. Effects of soil compactness on H₂S and sulfur metabolizing enzymes in root system of young apple trees with different rootstocks. Plant Physiology Journal, 2020, 56(9): 1845-1853. (in Chinese)
[7]	王群, 李潮海, 李全忠, 薛帅. 紧实胁迫对不同类型土壤玉米根系时空分布及活力的影响. 中国农业科学, 2011, 44(10): 2039-2050. doi: 10.3864/j.issn.0578-1752.2011.10.009
	WANG Q, LI C H, LI Q Z, XUE S. Effect of soil compaction on spatio-temporal distribution and activities in maize under different soil types. Scientia Agricultura Sinica, 2011, 44(10): 2039-2050. (in Chinese) doi: 10.3864/j.issn.0578-1752.2011.10.009
[8]	张方博, 侯玉雪, 敖园园, 申建波, 金可默. 土壤紧实胁迫下根系-土壤的相互作用. 植物营养与肥料学报, 2021, 27(3): 531-543.
	ZHANG F B, HOU Y X, AO Y Y, SHEN J B, JIN K M. Root-soil interaction under soil compaction. Journal of Plant Nutrition and Fertilizers, 2021, 27(3): 531-543. (in Chinese)
[9]	CORREA J, POSTMA J A, WATT M, WOJCIECHOWSKI T. Soil compaction and the architectural plasticity of root systems. Journal of Experimental Botany, 2019, 70(21): 6019-6034. doi: 10.1093/jxb/erz383 pmid: 31504740
[10]	PANDEY B K, HUANG G Q, BHOSALE R, HARTMAN S, STURROCK C J, JOSE L, MARTIN O C, KARADY M, VOESENEK L A C J, LJUNG K, LYNCH J P, BROWN K M, WHALLEY W R, MOONEY S J, ZHANG D B, BENNETT M J. Plant roots sense soil compaction through restricted ethylene diffusion. Science, 2021, 371(6526): 276-280. doi: 10.1126/science.abf3013 pmid: 33446554
[11]	QU Q, ZHANG Z Y, PEIJNENBURG W J G M, LIU W Y, LU T, HU B L, CHEN J M, CHEN J, LIN Z F, QIAN H F. Rhizosphere microbiome assembly and its impact on plant growth. Journal of Agricultural and Food Chemistry, 2020, 68(18): 5024-5038. doi: 10.1021/acs.jafc.0c00073 pmid: 32255613
[12]	朱永官, 彭静静, 韦中, 沈其荣, 张福锁. 土壤微生物组与土壤健康. 中国科学(生命科学), 2021, 51(1): 1-11.
	ZHU Y G, PENG J J, WEI Z, SHEN Q R, ZHANG F S. Soil microflora and soil health. Scientia Sinica (Vitae), 2021, 51(1): 1-11. (in Chinese)
[13]	徐龙晓, 荀咪, 宋建飞, 田孝志, 殷方鹏, 黄伟男, 张玮玮, 杨洪强. 土壤质地和砧木对苹果根际微生物功能多样性及其碳源利用的影响. 园艺学报, 2020, 47(8): 1530-1540. doi: 10.16420/j.issn.0513-353x.2020-0046
	XU L X, XUN M, SONG J F, TIAN X Z, YIN F P, HUANG W N, ZHANG W W, YANG H Q. Effect of soil textures and rootstock on rhizosphere microorganism and carbon source utilization of apple roots. Acta Horticulturae Sinica, 2020, 47(8): 1530-1540. (in Chinese) doi: 10.16420/j.issn.0513-353x.2020-0046
[14]	CAO H, JIA M F, XUN M, WANG X S, CHEN K, YANG H Q. Nitrogen transformation and microbial community structure varied in apple rhizosphere and rhizoplane soils under biochar amendment. Journal of Soils and Sediments, 2021, 21(2): 853-868. doi: 10.1007/s11368-020-02868-w
[15]	BALDRIAN P, KOLAŘÍK M, STURSOVÁ M, KOPECKÝ J, VALÁŠKOVÁ V, VĚTROVSKÝ T, ZIFČÁKOVÁ L, SNAJDR J, RÍDL J, VLČEK C, VOŘÍŠKOVÁ J. Active and total microbial communities in forest soil are largely different and highly stratified during decomposition. The ISME Journal, 2012, 6(2): 248-258. doi: 10.1038/ismej.2011.95
[16]	申建波, 白洋, 韦中, 储成才, 袁力行, 张林, 崔振岭, 丛汶峰, 张福锁. 根际生命共同体: 协调资源、环境和粮食安全的学术思路与交叉创新. 土壤学报, 2021, 58(4): 805-813.
	SHEN J B, BAI Y, WEI Z, CHU C C, YUAN L X, ZHANG L, CUI Z L, CONG W F, ZHANG F S. Rhizobiont: An interdisciplinary innovation and perspective for harmonizing resources, environment, and food security. Acta Pedologica Sinica, 2021, 58(4): 805-813. (in Chinese)
[17]	CALDWELL B A. Enzyme activities as a component of soil biodiversity: A review. Pedobiologia, 2005, 49(6): 637-644. doi: 10.1016/j.pedobi.2005.06.003
[18]	林娜, 刘勇, 李国雷, 于海群. 森林土壤酶研究进展. 世界林业研究, 2010, 23(4): 21-25.
	LIN N, LIU Y, LI G L, YU H Q. Research progress on forest soil enzyme. World Forestry Research, 2010, 23(4): 21-25. (in Chinese)
[19]	MARASCO R, ROLLI E, FUSI M, MICHOUD G, DAFFONCHIO D. Grapevine rootstocks shape underground bacterial microbiome and networking but not potential functionality. Microbiome, 2018, 6(1): 3. doi: 10.1186/s40168-017-0391-2 pmid: 29298729
[20]	CHERIF H, MARASCO R, ROLLI E, FERJANI R, FUSI M, SOUSSI A, MAPELLI F, BLILOU I, BORIN S, BOUDABOUS A, CHERIF A, DAFFONCHIO D, OUZARI H. Oasis Desert farming selects environment-specific date palm root endophytic communities and cultivable bacteria that promote resistance to drought. Environmental Microbiology Reports, 2015, 7(4): 668-678. doi: 10.1111/1758-2229.12304 pmid: 26033617
[21]	关松荫. 土壤酶及其研究法. 北京: 农业出版社, 1986.
	GUAN S Y. Soil Enzyme and Its Research Method. Beijing: Agricultural Press, 1986. (in Chinese)
[22]	李振高, 骆永明, 滕应. 土壤与环境微生物研究法. 北京: 科学出版社, 2008.
	LI Z G, LUO Y M, TENG Y. Soil and Environmental Microbiology Research Method. Beijing: Science Press, 2008. (in Chinese)
[23]	LU T, KE M J, LAVOIE M, JIN Y J, FAN X J, ZHANG Z Y, FU Z W, SUN L W, GILLINGS M, PEÑUELAS J, QIAN H F, ZHU Y G. Rhizosphere microorganisms can influence the timing of plant flowering. Microbiome, 2018, 6(1): 231. doi: 10.1186/s40168-018-0615-0 pmid: 30587246
[24]	ZENG Q C, AN S S. Identifying the biogeographic patterns of rare and abundant bacterial communities using different primer sets on the loess plateau. Microorganisms, 2021, 9(1): 139. doi: 10.3390/microorganisms9010139
[25]	CHEN L Y, ZHANG M T, LIU D, SUN H B, WU J X, HUO Y, CHEN X Y, FANG R X, ZHANG L L. Designing specific bacterial 16S primers to sequence and quantitate plant endo-bacteriome. Science China Life Sciences, 2022, 65(5): 1000-1013. doi: 10.1007/s11427-021-1953-5
[26]	CHAKRABORTY A, ISLAM E. Temporal dynamics of total and free-living nitrogen-fixing bacterial community abundance and structure in soil with and without history of arsenic contamination during a rice growing season. Environmental Science and Pollution Research, 2018, 25(5): 4951-4962. doi: 10.1007/s11356-017-0858-5
[27]	SHAH A N, TANVEER M, SHAHZAD B, YANG G Z, FAHAD S, ALI S, BUKHARI M A, TUNG S A, HAFEEZ A, SOULIYANONH B. Soil compaction effects on soil health and cropproductivity: An overview. Environmental Science and Pollution Research, 2017, 24(11): 10056-10067. doi: 10.1007/s11356-017-8421-y
[28]	VIEIRA S, SIKORSKI J, DIETZ S, HERZ K, SCHRUMPF M, BRUELHEIDE H, SCHEEL D, FRIEDRICH M W, OVERMANN J. Drivers of the composition of active rhizosphere bacterial communities in temperate grasslands. The ISME Journal, 2020, 14(2): 463-475. doi: 10.1038/s41396-019-0543-4
[29]	YU T B, CHENG L, LIU Q, WANG S S, ZHOU Y, ZHONG H B, TANG M F, NIAN H, LIAN T X. Effects of waterlogging on soybean rhizosphere bacterial community using V4, LoopSeq, and PacBio 16S rRNA sequence. Microbiology Spectrum, 2022, 10(1): e0201121. doi: 10.1128/spectrum.02011-21
[30]	臧明, 雷宏军, 刘鑫, 潘红卫, 徐建新. 增氧灌溉对氧气扩散速率和冬小麦养分利用的改善研究. 核农学报, 2020, 34(5): 1070-1078. doi: 10.11869/j.issn.100-8551.2020.05.1070
	ZANG M, LEI H J, LIU X, PAN H W, XU J X. Oxygation promotes soil oxygen diffusion rate and nutrient utilization of winter wheat. Journal of Nuclear Agricultural Sciences, 2020, 34(5): 1070-1078. (in Chinese) doi: 10.11869/j.issn.100-8551.2020.05.1070
[31]	杨晓娟, 李春俭. 机械压实对土壤质量、作物生长、土壤生物及环境的影响. 中国农业科学, 2008, 41(7): 2008-2015.
	YANG X J, LI C J. Impacts of mechanical compaction on soil properties, growth of crops, soil-borne organisms and environment. Scientia Agricultura Sinica, 2008, 41(7): 2008-2015. (in Chinese)
[32]	ZHOU W J, QIN X, LYU D G, QIN S J. Effect of glucose on the soil bacterial diversity and function in the rhizosphere of Cerasus sachalinensis. Horticultural Plant Journal, 2021, 7(4): 307-317. doi: 10.1016/j.hpj.2021.02.002
[33]	郑俊騫, 孙艳, 韩寿坤, 张浩, 王益权. 土壤紧实胁迫对黄瓜抗坏血酸—谷胱甘肽循环的影响. 中国农业科学, 2013, 46(2): 433-440. doi: 10.3864/j.issn.0578-1752.2013.02.023
	ZHENG J Q, SUN Y, HAN S K, ZHANG H, WANG Y Q. Effect of soil compaction stress on ascorbate-gluthione cycle in cucumber plants. Scientia Agricultura Sinica, 2013, 46(2): 433-440. (in Chinese)
[34]	LI C H, MA B L, ZHANG T Q. Soil bulk density effects on soil microbial populations and enzyme activities during the growth of maize (Zea mays L.) planted in large pots under field exposure. Canadian Journal of Soil Science, 2002, 82(2): 147-154. doi: 10.4141/S01-026
[35]	马星竹. 长期施肥土壤的FDA水解酶活性. 浙江大学学报(农业与生命科学版), 2010, 36(4): 451-455.
	MA X Z. Activity of soil fluorescein diacetate (FDA) hydrolase under long-term fertilization. Journal of Zhejiang University (Agriculture & Life Sciences), 2010, 36(4): 451-455. (in Chinese)
[36]	RAVANBAKHSH M, SASIDHARAN R, VOESENEK L A C J, KOWALCHUK G A, JOUSSET A. Microbial modulation of plant ethylene signaling: ecological and evolutionary consequences. Microbiome, 2018, 6(1): 52. doi: 10.1186/s40168-018-0436-1 pmid: 29562933
[37]	DE CAMPOS S B, YOUN J W, FARINA R, JAENICKE S, JÜNEMANN S, SZCZEPANOWSKI R, BENEDUZI A, VARGAS L K, GOESMANN A, WENDISCH V F, PASSAGLIA L M P. Changes in root bacterial communities associated to two different development stages of canola (Brassica napus L.var oleifera) evaluated through next-generation sequencing technology. Microbial Ecology, 2013, 65(3): 593-601. doi: 10.1007/s00248-012-0132-9
[38]	EL ZAHAR HAICHAR F, MAROL C, BERGE O, RANGEL- CASTRO J I, PROSSER J I, BALESDENT J, HEULIN T, ACHOUAK W. Plant host habitat and root exudates shape soil bacterial community structure. The ISME Journal, 2008, 2(12): 1221-1230. doi: 10.1038/ismej.2008.80
[39]	EDWARDS J, JOHNSON C, SANTOS-MEDELLÍN C, LURIE E, PODISHETTY N K, BHATNAGAR S, EISEN J A, SUNDARESAN V. Structure, variation, and assembly of the root-associated microbiomes of rice. Proceedings of the National Academy of Sciences of the United States of America, 2015, 112(8): E911-E920.

土壤物理性状 Soil physical property	红富士/平邑甜茶 Red Fuji/Malus hupehensis		红富士/八棱海棠 Red Fuji/Malus robusta
土壤物理性状 Soil physical property	正常土壤 Normal soil	紧实土壤 Compacted soil	正常土壤 Normal soil	紧实土壤 Compacted soil
土壤容重 Soil bulk density (g∙cm^-3)	1.18±0.02b	1.67±0.06a	1.16±0.08b	1.64±0.03a
土壤孔隙度SP Soil porosity (%)	55.18±0.01a	36.75±0.02b	56.06±0.03a	37.98±0.01b
氧气浓度O₂Oxygen concentration (%)	19.50±0.30a	13.86±0.20c	19.28±0.22a	15.16±0.15b

微生物群落组成结构 Microbial community composition structure	红富士/平邑甜茶 Red Fuji/Malus hupehensis		红富士/八棱海棠 Red Fuji/Malus robusta
微生物群落组成结构 Microbial community composition structure	正常土壤 Normal soil	紧实土壤 Compacted soil	正常土壤 Normal soil	紧实土壤 Compacted soil
细菌数Bacteria amount (×10⁵CFU/g)	32.00±2.65a	17.00±1.73b	11.67±0.58c	17.67±2.00b
真菌数Fungi amount (×10³CFU/g)	13.33±1.53b	6.33±1.15d	15.33±0.58a	8.33±0.58c
放线菌数Actinomyces amount (×10⁴CFU/g)	29.00±3.61c	38.00±2.00b	31.67±1.53c	52.00±2.65a
细菌数/真菌数（B/F）Ratio of bacteria to fungi	240.60±8.54b	271.43±14.74a	74.03±5.66d	212.96±14.30c
放线菌数/真菌数（A/F）Ratio of actinomyces to fungi	22.13±5.07b	61.52±12.85a	20.69±1.72b	62.64±6.04a

细菌丰度 Bacterial abundance	土壤物理性状 Soil physical property			根际矿质养分含量 Rhizosphere nutrient content						根际酶活性 Rhizosphere enzyme activity
细菌丰度 Bacterial abundance	SBD	SP	O₂	TN	TP	TK	AN	AP	AK	CAT	SAC	URE	ACP	FDA
根际细菌Rh_16s	-0.940**	0.941**	0.936**	0.195	0.206	0.754	0.925**	-0.953**	-0.880*	-0.834*	0.908*	0.953**	0.947**	0.946**
根内细菌En_16s	-0.973**	0.978**	0.985**	0.399	0.055	0.886*	0.962**	-0.986**	-0.953**	-0.811	0.972**	0.994**	0.991**	0.976**

细菌丰度 Bacterial abundance	土壤物理性状 Soil physical properties			根际矿质养分含量 Rhizosphere nutrient content						根际酶活 Rhizosphere enzyme activity
细菌丰度 Bacterial abundance	SBD	SP	O₂	TN	TP	TK	AN	AP	AK	CAT	SAC	URE	ACP	FDA
根际细菌Rh_16s	0.925**	-0.928**	-0.947**	-0.305	0.006	0.532	-0.884*	0.951**	0.952**	0.896*	-0.979**	-0.918**	-0.878*	0.979**
根内细菌En_16s	-0.953**	0.960**	0.983**	0.145	0.158	-0.554	0.933**	-0.991**	-0.991**	-0.950**	0.956**	0.992**	0.973**	-0.949**
