相对饲养水平对绵羊肌肉组织结构及肌纤维组成相关基因的影响

doi:10.3864/j.issn.0578-1752.2022.21.016

摘要/Abstract

摘要：

【目的】提高肉品质是现代肉羊生产的主要目标之一，研究不同饲养水平对阿勒泰羊背最长肌肌肉组织结构及肌纤维组成相关基因的影响，为通过饲养水平调控肉脂型绵羊肉品质，提高生产效益提供参考。【方法】选择出生日龄接近（（3.0±0.5）月龄）、体况良好、体重相近（（19.16±0.54）kg）、臀型一致的阿勒泰羊30只，随机分为3组，自由采食60 d后，分别按照50%（0.25 MJ/W^0.75×d^-1）（NL组）、100%（0.5 MJ/W^0.75×d^-1）（NM组）、150%（0.75 MJ/W^0.75×d^-1）（NH组）的维持代谢能饲喂30 d后屠宰，取背最长肌分别进行苏木精—伊红(H.E.)染色和2%醋酸铀-枸橼酸铅双染色法染色，光学显微镜和透射电镜观察肌肉组织结构，并通过免疫组化法测定肌球蛋白重链I (myosin heavy chain，MyHC I)和过氧化物酶体增殖物激活受体-γ（preoxisome proliferator-activated receptor gamma，PPARγ）蛋白表达量。【结果】(1) 阿勒泰羊摄入50%、100%和150%的维持代谢能时，三组试验羊的平均日增重分别为-90.67 kg、13.33 kg和203.00 kg，差异显著(P<0.05);背最长肌肌纤维直径NH组、NM组显著大于NL组（P<0.05）;肌内膜厚度NH组显著小于NL组（P<0.05）;肌束肌纤维数量、肌束纤维面积、肌束膜厚度以及肌纤维面积、肌纤维密度差异不显著（P>0.05）。(2) 饲养水平对肌质网终池面积、脂滴面积以及肌质网终池、肌原纤维、肌质的面积比都有影响，肌质网终池面积和面积比NH组显著大于NM和NL组（P<0.05），脂滴面积NH组显著大于NL组（P<0.05）;肌质面积比NM组显著大于NH和NL组（P<0.05）;线粒体、糖原三组之间无显著差异（P<0.05）。(3) 饲养水平对肌纤维组成相关基因蛋白的表达有影响，PPARγ的蛋白表达强度、阳性面积和阳性率NL和NM组显著低于NH组（P<0.05）;MyHCⅠ蛋白表达强度随能量摄入水平的增加而增大，但是三组间差异不显著（P>0.05）。【结论】不同饲养水平对阿勒泰羊背最长肌肌肉组织结构和肌纤维类型相关基因蛋白的表达具有显著的影响，在育肥期可通过饲养水平控制肌肉组织结构和肌纤维类型组成，从而按照生产需要调控肉品质。

关键词: 相对饲养水平, 肉品质, 肌肉组织结构, 肌纤维, PPARγ, MyHC I, 阿勒泰羊

Abstract:

【Objective】Improving meat quality is one of the main goals of the modern mutton sheep production. The objective of this study was to compare the muscle tissue structure and the genes expression related muscle development of longissimus dorsi muscle in Altay sheep, so as to provide the reference for regulating meat quality and improving production efficiency of meat-fat type sheep by feeding level. 【Method】 Thirty Altay female lambs with a similar month ((3.0±0.5) months), similar body weight ((19. 16±0.54) kg), uniform tail size were randomly divided into 3 groups with 10 lambs per group. After 60 days of ad libitum feeding, three test sheep groups were fed with 50% (0.25 MJ/W^0.75 ×d^-1, NL group), 100% (0.5 MJ/W^0.75 ×d^-1, NM group), and 150% (0.75 MJ/W^0.75 ×d^-1, NH group) maintenance metabolizable for 30 days, respectively, and then slaughtered. The longissimus dorsi muscle was stained with Hematoxylin Eosin (HE staining) and 2% uranyl acetate-lead citrate double staining, respectively, and then the expression of myosin heavy chain I (MyHC I) and peroxisome receptor activator-activated gamma (PPARγ) was determined by immunohistochemistry. 【Result】(1) When Altay sheep were fed 50%, 100% and 150% metabolizable energy, respectively, the difference of average daily gain was significant (P<0.05), and the difference of three groups were -90.67 kg, 13.33 kg and 203.00 kg, respectively. The diameter of longissimus dorsi muscle fibers from NL group and NH group was significantly larger than that from NL group (P<0.05), while the thickness of muscular intima from NH group was significantly smaller than that in NL group (P<0.05), but there were no significant differences in the amount of muscle fiber, the area of muscle fiber, the thickness of muscle fascicle, the area of muscle fiber and the density of muscle fiber (P>0.05). (2) The feeding levels affected the area of terminal cisterna, lipid droplets and the area ratio of terminal cisterna, myofibril and sarcoplasm. The area and area ratio of terminal cisterna from NH were significantly larger than those from NM group and NL group (P<0.05), while the area of lipid droplets from NH group was significantly larger than that from NL group (P<0.05). The area ratio of sarcoplasm from NM group was significantly larger than that from NH and NL Group (P<0.05), and mitochondria and glycogen had no significant difference among the three groups (P<0.05). (3) The feeding levels affected the expression of gene related muscle fiber, PPARγ expression intensity, positive area and positive rate from NL, and NM groups were significantly lower than those from NH group (P<0.05). The expression intensity of MyHC Ⅰ protein increased with the increase of feeding level, but there was no significant difference among three groups (P>0.05).【Conclusion】The feeding level had a significant effect on the muscle tissue structure and the expression of gene protein related to muscle fiber type of the Longissimus dorsi muscle in Altay sheep, and it could be used to control the muscle tissue structure and muscle fiber type composition during fattening period, in order to regulate the quality of meat according to production needs.

Key words: feeding level, meat quality, muscle tissue structure, muscle fiber, PPARγ, MyHC I, Altay sheep

宋淑珍, 高良霜, 李宏, 宫旭胤, 刘立山, 魏玉兵. 相对饲养水平对绵羊肌肉组织结构及肌纤维组成相关基因的影响[J]. 中国农业科学, 2022, 55(21): 4304-4314.

SONG ShuZhen, GAO LiangShuang, LI Hong, GONG XuYin, LIU LiShan, WEI YuBing. Effects of Feeding Levels on Muscle Tissue Structure and Muscle Fiber Composition Related Genes in Sheep[J]. Scientia Agricultura Sinica, 2022, 55(21): 4304-4314.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2022.21.016

https://www.chinaagrisci.com/CN/Y2022/V55/I21/4304

图/表 9

表1

表2

表3

图1

图2

表4

图3

图4

表5

参考文献 41

[1]	薛宝玲, 曹志军, 蔡永敏, 格日勒图. 不同月龄乌珠穆沁羊肌纤维类型与肉品质的变化分析. 食品研究与开发, 2019, 40(18): 193-197.
	XUE B L, CAO Z J, CAI Y M, GERILRTU. Relationship between muscle fibers type and meat quality changes during the growth of ujumqin sheep. Food Research and Development, 2019, 40(18): 193-197. (in Chinese)
[2]	束婧婷, 宋迟, 徐文娟, 章明, 单艳菊, 陈文峰, 宋卫涛, 陶志云, 李慧芳. IGF-I-CaN-NFATc3信号通路相关基因在鸭发育早期骨骼肌中的同步表达及其与肌纤维性状相关性. 中国农业科学, 2015, 48(6): 1195-1204.
	SHU J T, SONG C, XU W J, ZHANG M, SHAN Y J, CHEN W F, SONG W T, TAO Z Y, LI H F. Expression profile of IGF-I- calcineurin-NFATc3-dependent pathway genes in skeletal muscles and their associations with myofiber traits during embryonic and early post-hatching development in ducks. Scientia Agricultura Sinica, 2015, 48(6): 1195-1204. (in Chinese)
[3]	CHOI Y M, RYU Y C, KIM B C. Influence of myosin heavy- and light chain isoforms on early postmortem glycolytic rate and pork quality. Meat Science, 2007, 76(2): 281-288. doi:10.1016/j.meatsci.2006.11.009.
[4]	LEE S H, JOO S T, RYU Y C. Skeletal muscle fiber type and myofibrillar proteins in relation to meat quality. Meat Science, 2010, 86(1): 166-170. doi:10.1016/j.meatsci.2010.04.040.
[5]	ESSÉN-GUSTAVSSON B, KARLSSON A, LUNDSTRÖM K, ENFÄLT A C. Intramuscular fat and muscle fibre lipid contents in halothane-gene-free pigs fed high or low protein diets and its relation to meat quality. Meat Science, 1994, 38(2): 269-277. doi:10.1016/0309-1740(94)90116-3.
[6]	STEFANO S, CARLO R. Fiber types in mammalia skeletal museles. Physiological Reviews, 2011, 91 (4): 1447-1531.
[7]	LEE S H, CHOE J H, CHOI Y M, JUNG K C, RHEE M S, HONG K C, LEE S K, RYU Y C, KIM B C. The influence of pork quality traits and muscle fiber characteristics on the eating quality of pork from various breeds. Meat Science, 2012, 90(2): 284-291. doi:10.1016/j.meatsci.2011.07.012.
[8]	KIM G D, JEONG J Y, HUR S J, YANG H S, JEON J T, JOO S T. The relationship between meat color (CIE L* and a*), myoglobin content, and their influence on muscle fiber characteristics and pork quality. Korean Journal for Food Science of Animal Resources, 2010, 30(4): 626-633.
[9]	MASHIMA D, OKA Y, GOTOH T, TOMONAGA S, SAWANO S, NAKAMURA M, TATSUMI R, MIZUNOYA W. Correlation between skeletal muscle fiber type and free amino acid levels in Japanese Black steers. Animal Science Journal, 2019, 90(4): 604-609. doi:10.1111/asj.13185.
[10]	李银, 孙红梅, 张春晖, 白跃宇, 王振宇. 牛肉解冻过程中蛋白质氧化效应分析. 中国农业科学, 2013, 46(7): 1426-1433.
	LI Y, SUN H M, ZHANG C H, BAI Y Y, WANG Z Y. Analysis of frozen beef protein oxidation effect during thawing. Scientia Agricultura Sinica, 2013, 46(7): 1426-1433. (in Chinese)
[11]	BEE G, CALDERINI M, BIOLLEY C, GUEX G, HERZOG W, LINDEMANN M D. Changes in the histochemical properties and meat quality traits of porcine muscles during the growing-finishing period as affected by feed restriction, slaughter age, or slaughter weight. Journal of Animal Science, 2007, 85(4): 1030-1045. doi:10.2527/jas.2006-496.
[12]	SOLOMON M B, CAMPBELL R G, STEELE N C, CAPERNA T J, MCMURTRY J P. Effect of feed intake and exogenous porcine somatotropin on longissimus muscle fiber characteristics of pigs weighing 55 kilograms live weight. Journal of Animal Science, 1988, 66(12): 3279-3284. doi:10.2527/jas1988.66123279x.
[13]	JEONG J Y, KIM G D, HA D M, PARK M J, PARK B C, JOO S T, LEE C Y. Relationships of muscle fiber characteristics to dietary energy density, slaughter weight, and muscle quality traits in finishing pigs. Journal of Animal Science and Technology, 2012, 54(3) 175-183.
[14]	PARK S K, GUNAWAN A M, SCHEFFLER T L, GRANT A L, GERRARD D E. Myosin heavy chain isoform content and energy metabolism can be uncoupled in pig skeletal muscle. Journal of Animal Science, 2009, 87(2): 522-531. doi:10.2527/jas.2008-1269.
[15]	FERNANDES M H M R, RESENDE K T, TEDESCHI L O, FERNANDES J S, SILVA H M, CARSTENS G E, BERCHIELLI T T, TEIXEIRA I A M A, AKINAGA L. Energy and protein requirements for maintenance and growth of Boer crossbred kids. Journal of Animal Science, 2007, 85(4): 1014-1023. doi:10.2527/jas.2006-110.
[16]	高良霜, 吴建平, 宋淑珍, 李宏, 郎侠, 魏玉斌, 宫旭胤, 刘立山. 不同能量水平对阿勒泰羊血清脂质指标及脂肪沉积的影响. 饲料工业, 2020, 41(9): 14-23. doi:10.13302/j.cnki.fi.2020.09.003.
	GAO L S, WU J P, SONG S Z, LI H, LANG X, WEI Y B, GONG X Y, LIU L S. Effect of different energy levels on serum lipid index and lipid deposition of Altay sheep. Feed Industry, 2020, 41(9): 14-23. doi:10.13302/j.cnki.fi.2020.09.003. (in Chinese)
[17]	庞之洪, 罗清尧, 熊本海. 中国饲料成分及营养价值表(2007年第18版)制订说明. 中国饲料, 2007(21): 33.
	PANG Z H, LUO Q Y, XIONG B H. Introduction of tables of feed composition and nutritive values in China (2007 eighteenth edition). China Feed, 2007(21): 33. (in Chinese)
[18]	陈圆, 胡惠军, 廖淑芬, 林培平, 钟淡龙, 李红伟. 惠阳胡须鸡肌纤维直径、密度生长发育规律的研究. 惠州学院学报, 2017, 37(3): 65-68, 75. doi:10.16778/j.cnki.1671-5934.2017.03.012.
	CHEN Y, HU H J, LIAO S F, LIN P P, ZHONG D L, LI H W. Study on muscle fiber density and diameter in Huiyang bearded chicken at different age. Journal of Huizhou University, 2017, 37(3): 65-68, 75. doi:10.16778/j.cnki.1671-5934.2017.03.012. (in Chinese)
[19]	殷亚杰, 聂春雨, 刘伟石, 邹琦, 李和平. 马鹿肌肉组织学特征与肉质关系的研究. 中国农学通报, 2012, 28(35): 51-54.
	YIN Y J, NIE C Y, LIU W S, ZOU Q, LI H P. The study on relationship of muscle histological characteristics to meat quality of red deer. Chinese Agricultural Science Bulletin, 2012, 28(35): 51-54. (in Chinese)
[20]	谢恺舟, 徐东, 李洋静, 李拥军, 谢星, 周卫东, 姚宜林, 陈书琴, 吴力力. 海门山羊肌肉组织学特性的研究. 安徽农业科学, 2010, 38(23): 12341-12343. doi:10.13989/j.cnki.0517-6611.2010.23.242.
	XIE K Z, XU D, LI Y J, LI Y J, XIE X, ZHOU W D, YAO Y L, CHEN S Q, WU L L. Study on the muscle histological characteristics of Haimen goats. Journal of Anhui Agricultural Sciences, 2010, 38(23): 12341-12343. doi:10.13989/j.cnki.0517-6611.2010.23.242. (in Chinese)
[21]	尹靖东. 动物肌肉生物学与肉品科学. 北京: 中国农业大学出版社, 2011.
	YIN J D. Animal Muscle Biology and Meat Quality. Beijing: China Agricultural University Press, 2011. (in Chinese)
[22]	ASHMORE C R, DOERR L. Comparative aspects of muscle fiber types in different species. Experimental Neurology, 1971, 31(3): 408-418. doi:10.1016/0014-4886(71)90243-3.
[23]	BOWKER B C, GRANT A L, SWARTZ D R, GERRARD D E. Myosin heavy chain isoforms influence myofibrillar ATPase activity under simulated postmortem pH, calcium, and temperature conditions. Meat Science, 2004, 67(1): 139-147. doi:10.1016/j.meatsci.2003.09.016.
[24]	LISTRAT A, LEBRET B, LOUVEAU I, ASTRUC T, BONNET M, LEFAUCHEUR L, PICARD B, BUGEON J. How muscle structure and composition influence meat and flesh quality. The Scientific World Journal, 2016, 2016: 3182746. doi:10.1155/2016/3182746.
[25]	ASGHAR A, YEATES M F. Muscle Characteristics and meat quality of lambs, grown on different nutritional planes. III. Effect on muscle ultrastructure. Agricultural and Biological Chemistry, 1979, 43(3): 445-453.
[26]	王震, 马铁伟, 邓凯平, 冯旭, 李奉哲, 王锋, 陶晓强, 樊懿萱. 能量限饲和补偿对湖羊生长性能及相关激素和肉品质的影响. 南京农业大学学报, 2018, 41(4): 722-729.
	WANG Z, MA T W, DENG K P, FENG X, LI F Z, WANG F, TAO X Q, FAN Y X. Effects of energy restriction and compensation on growth performance, and related hormones and meat quality of Hu sheep. Journal of Nanjing Agricultural University, 2018, 41(4): 722-729. (in Chinese)
[27]	张崇志, 高爱武, 侯先志, 考桂兰, 刘小刚, 张园. 不同营养水平对羔羊肌肉组织学性状的影响. 动物营养学报, 2011, 23(2): 336-342.
	ZHANG C Z, GAO A W, HOU X Z, KAO G L, LIU X G, ZHANG Y. Effects of different nutritional levels on muscle histological characteristics of lambs. Chinese Journal of Animal Nutrition, 2011, 23(2): 336-342. (in Chinese)
[28]	MUCKTA K. Investigations on the effect of nicotinic acid supplementation on muscle fiber distribution and muscle metabolic phenotype in pig and sheep[D]. Giessen: Justus Liebig University Giessen, 2014.
[29]	万磊, 周明芳, 熊婷, 刘秋红, 席苏望, 胡晓龙, 刘三凤. 宁都黄鸡胸肌不同部位肌纤维组织学特性分析. 黑龙江畜牧兽医, 2021(19): 60-63, 147. doi:10.13881/j.cnki.hljxmsy.2021.01.0342.
	WAN L, ZHOU M F, XIONG T, LIU Q H, XI S W, HU X L, LIU S F. Histological characteristics analysis of muscle fiber in different parts of breast muscle of Ningdu yellow chicken. Heilongjiang Animal Science and Veterinary Medicine, 2021(19): 60-63, 147. doi:10.13881/j.cnki.hljxmsy.2021.01.0342. (in Chinese)
[30]	OLZMANN J A, CARVALHO P. Dynamics and functions of lipid droplets. Nature Reviews Molecular Cell Biology, 2019, 20(3): 137-155. doi:10.1038/s41580-018-0085-z.
[31]	王丽莎, 王航, 李侠, 张春晖, 梁红, 李敏. 不同部位猪肉肌纤维类型组成与品质特性比较研究. 肉类研究, 2020, 34(6): 1-7.
	WANG L S, WANG H, LI X, ZHANG C H, LIANG H, LI M. Comparison of muscle fiber traits and meat quality of different porcine skeletal muscles. Meat Research, 2020, 34(6): 1-7. (in Chinese)
[32]	HENCKEL P, OKSBJERG N, ERLANDSEN E, BARTON-GADE P, BEJERHOLM C. Histo- and biochemical characteristics of the Longissimus dorsi muscle in pigs and their relationships to performance and meat quality. Meat Science, 1997, 47(3/4): 311-321. doi:10.1016/S0309-1740(97)00063-6.
[33]	WANG Q Y, WANG Y C, HUSSAIN T, DAI C P, LI J Z, HUANG P F, LI Y L, DING X Q, HUANG J, JI F J, ZHOU H L, YANG H S. Effects of dietary energy level on growth performance, blood parameters and meat quality in fattening male Hu lambs. Journal of Animal Physiology and Animal Nutrition, 2020, 104(2): 418-430. doi:10.1111/jpn.13278.
[34]	ALMURSHED K, GRUNEWALD K. The effects of dietary energy restriction on overloaded skeletal muscle in rats. The British Journal of Nutrition, 2000, 84(5): 697-704.
[35]	MACIEJEWSKA-SKRENDO A, PAWLIK A, SAWCZUK M, RAC M, DZIEDZIEJKO V. PPAR alpha, PPAR delta and PPAR gamma gene polymorphisms in patients with unstable angina. Gene, 2019(1): 143947.
[36]	FU M G, ZHANG J F, ZHU X J, MYLES D E, WILLSON T M, LIU X D, CHEN Y E. Peroxisome proliferator-activated receptor γ inhibits transforming growth factor β-induced connective tissue growth factor expression in human aortic smooth muscle cells by interfering with Smad3. Journal of Biological Chemistry, 2001, 276(49): 45888-45894. doi:10.1074/jbc.m105490200.
[37]	GU H, ZHOU Y, YANG J Z, LI J N, PENG Y X, ZHANG X, MIAO Y L, JIANG W, BU G W, HOU L M, LI T, ZHANG L, XIA X L, MA Z Y, XIONG Y Z, ZUO B. Targeted over-expression of PPARγ in pig skeletal muscle improves oxidative fiber formation and intramuscular fat deposition[EB/OL]. 10.1101/2020.06.24.168641, 2020.
[38]	CHEN W, XUE N N, CUI L K, XU C, ZHENG Z B, LI S, WANG L L. Novel dual PPARα/δ agonist F₃SM increased oxidative muscle fiber and ameliorated metabolic disorders in non-trained mice. The FASEB Journal, 2019, 33(S1): 670.7. doi:10.1096/fasebj.2019.33.1_supplement.
[39]	LUQUET S, LOPEZ-SORIANO J, HOLST D, FREDENRICH A, GRIMALDI P A. Peroxisome proliferator-activated receptor δ controls muscle development and oxidative capability. Faseb Journal Official Publication of the Federation of American Societies for Experimental Biology, 2003, 17(15): 2299-2301.
[40]	王小芳, 曾洁, 田崇奇, 王小龙, 杨雨鑫, 陈玉林, 张恩平. 日粮能量和蛋白水平对滩羊脂肪组织PPARγ和FABP4mRNA表达的影响. 畜牧兽医学报, 2016, 47(11): 2266-2273.
	WANG X F, ZENG J, TIAN C Q, WANG X L, YANG Y X, CHEN Y L, ZHANG E P. Effects of diet energy and protein levels on the mRNA expression of PPARγ and FABP₄ in adipose tissues of Tan sheep. Chinese Journal of Animal and Veterinary Sciences, 2016, 47(11): 2266-2273. (in Chinese)
[41]	宋洪新, 任战军, 杨雪娇, 贺国瑞, 韩营, 常万波, 颉宏兵. 日粮能量水平对幼龄獭兔血液生化指标及肝脏PPARγ、INSIG-2基因表达的影响. 西北农林科技大学学报(自然科学版), 2014, 42(5): 11-16, 21. doi:10.13207/j.cnki.jnwafu.2014.05.029.
	SONG H X, REN Z J, YANG X J, HE G R, HAN Y, CHANG W B, XIE H B. Effect of diet energy level on blood parameters and expression of PPARγand INSIG-2 genes in liver of juvenile rabbits. Journal of Northwest A ＆ F University (Natural Science Edition), 2014, 42(5): 11-16, 21. doi:10.13207/j.cnki.jnwafu.2014.05.029. (in Chinese)

成分Ingredient	含量Content	营养水平Nutrient level ²⁾	含量Content
苜蓿干草Alfalfa hay	25.40	消化能DE（MJ·kg^-1）	10.66
玉米秆Corn straw	19.40	代谢能ME（MJ·kg^-1）	8.67
小麦秆Wheat straw	5.00	粗蛋白质CP	12.51
玉米Corn	30.00	粗脂肪EE	2.13
大豆粕Soybean meal	10.00	钙Ca	0.65
麸皮Wheat bran	5.00	总磷TP	0.45
菜籽粕Rapeseed meal	4.00	中性洗涤纤维NDF	55.30
磷酸氢钙Calcium hydrogen phosphate	0.20	酸性洗涤纤维ADF	32.22
碳酸钙Calcium carbonate	0.35
氯化钠NaCI	0.50
预混料Premixture¹⁾	0.15
合计Total	100.00

组别 Treatment	初重 Initial weight (kg)	末重 Final weight (kg)	平均日增重 Average daily gain (g)	代谢体重平均日采食量 Average daily intake of metabolic weight (g/W^0.75)
NL组 NL group	30.17±1.17	27.45±2.36c	-90.67±0.04c	0.04±0.00c
NM组 NM group	30.75±1.72	31.15±1.49b	13.33±0.07b	0.08±0.00b
NH组 NH group	30.83±1.16	36.93±2.73a	203.00±0.05a	0.12±0.00a

组别 Treatment	肌束纤维数量 Muscular bundle number (number/bundle)	肌束纤维面积 Muscular bundle area (μm²)	肌纤维面积 Muscle fiber area (μm²)	肌纤维密度 Muscle fiber density (number/mm²)	肌纤维最长直径 Muscle fiber maximum density (μm)	肌纤维最短直径 Muscle fiber minimum density (μm)	肌纤维平均直径 Muscle fiber diameter (μm)	肌内膜厚度 Endomysium thickness (μm)	肌束膜厚度 Perimysium thickness (μm)
NL组 NL group	114.17±10.16	105509.52±2132.25	942.28±105.95	1134.44±132.01	36.27±1.90b	20.07±1.56b	28.17±.46b	4.98±0.45a	13.00±1.49
NM组 NM group	113.83±7.25	89244.27±7337.58	795.90±83.48	1319.73±123.19	42.65±3.28ab	27.48±3.97ab	35.07±.45a	3.94±0.52ab	12.39±2.54
NH组 NH group	105.83±6.80	98028.30±9200.17	959.81±135.47	1143.12±146.89	44.48±2.76a	33.80±3.60a	39.14±.49a	3.69±0.19b	13.63±1.71

组别 Treatment	肌质网终池 Terminal cisternae		肌原纤维 Myofibril		肌质 Sarcoplasm		线粒体 Chondriosome		肌糖原 Glucogen		脂滴 Lipid
组别 Treatment	面积 Area (μm²)	面积比 Area ratio	面积 Area (μm²)	面积比 Area ratio	面积 Area (μm²)	面积比 Area ratio	面积 Area (μm²)	面积比 Area ratio	面积 Area (μm²)	面积比 Area ratio	面积 Area (μm²)	面积比 Area ratio
NL组 NL group	0.069±0.006b	0.033±0.003b	1.020±0.004	0.480±0.015a	1.045±0.096	0.487±0.016b	0.414±0.056	0.647±0.038	0.173±0.027	0.293±0.040	0.037±0.008b	0.061±0.012
NM组 NM group	0.084±0.006b	0.042±0.004b	0.870±0.080	0.040±0.019b	1.239±0.119	0.557±0.020a	0.488±0.062	0.606±0.045	0.309±0.073	0.308±0.047	0.051±0.005ab	0.067±0.009
NH组 NH group	0.136±0.018a	0.066±0.008a	0.993±0.090	0.468±0.021a	1.008±0.106	0.467±0.022b	0.591±0.086	0.711±0.042	0.227±0.066	0.225±0.046	0.056±0.003a	0.078±0.012

组别 Treatment	MyHCⅠ				PPARγ
组别 Treatment	积分光密度值 Integral optical density (IOD)	阳性面积 Positive area (μm²)	蛋白表达强度 Protein expression intensity (%)	阳性率 Positive rate (%)	积分光密度值 Integral optical density (IOD)	阳性面积 Positive area (μm²)	蛋白表达强度 Protein expression intensity (%)	阳性率 Positive rate (%)
NL组 NL group	58987.44±9756.69	12141.92±987.74	0.0047±0.0008	0.17±0.01	66415.77±19885.47	24112.09±7846.90b	0.005±0.0016 b	0.33±0.11b
NM组 NM group	75598.94±15209.87	14334.56±1587.26	0.0060±0.0012	0.20±0.02	93424.27±32592.84	25226.34±4038.18b	0.007±0.0026 b	0.34±0.05b
NH组 NH group	86479.87±9013.80	15042.09±2166.93	0.0069±0.0007	0.20±0.00	125531.67±28874.92	49822.16±9579.31a	0.010±0.0023 a	0.68±0.13a
