低压静电场辅助短期冻藏对猪肉品质的影响

doi:10.3864/j.issn.0578-1752.2021.09.015

摘要/Abstract

摘要：

【目的】研究低压静电场（low voltage electrostatic field,LVEF）辅助短期冻藏（28 d）对猪肉品质的影响,为肉品新型贮藏保鲜技术开发提供理论依据。【方法】以猪背最长肌（Longissimus thoracis et lumborum）为试验材料,对比分析在-18、-12和-6℃的静电场（设备输出电压2 500 V,电流0.2 mA）和非静电场环境（对照）下冻藏0、7、14、21和28 d的菌落总数、TVB-N含量、色泽、贮藏损失、蒸煮损失、剪切力、TBARS、巯基含量、冰晶形态及水分分布等指标的变化。【结果】贮藏期间,静电场组肉样的菌落总数、TVB-N含量和TBARS值比对照显著下降（P<.05）,且肉样持水力较高,色泽更鲜亮,肌肉中形成冰晶小且均匀,对肌肉微观结构破坏程度低。贮藏28 d时,静电场下-12℃冻藏肉样的菌落总数、TVB-N含量及TBARS值分别为4.50 lg（CFU/g）、8.73 mg/100 g和0.1691 mg MDA?kg^-1,与-18℃对照组的4.48 lg（CFU/g）、8.91 mg/100g及0.1754 mg MDA?kg^-1结果相比均无显著差异（P>0.05）,两组肉样间的贮藏损失、剪切力及色泽差异也不显著（P>0.05）。【结论】低压静电场辅助冻藏可有效延缓猪肉在贮藏期间的品质劣变,且静电场辅助-12℃冻藏28 d内的肉品品质可达到-18℃常规冻藏的效果,低压静电场下-6℃冻藏肉样品质与-12℃非静电场冻藏效果也趋于一致。

关键词: 低压静电场, 短期冻藏, 猪肉品质, 保鲜

Abstract:

【Objective】The current study was aimed to explore the effects of low voltage electrostatic field (LVEF) on pork quality traits during short-term frozen storage (28 d), and the results might provide a theoretical basis for the development of novel technology in meat preservation. 【Method】In the current study, pork longissimus thoracis et lumborum muscles were used as experimental material. Quality indices of the meat samples frozen at -18, -12 and -6℃ under LVEF (to output a voltage of 2 500 V and a current of 0.2 mA) or in the absence of LVEF (control group) were determined during frozen storage periods (0, 7, 14, 21 and 28 d), which included total bacterial count, total volatile basic nitrogen (TVB-N) content, color, purge loss, cooking loss, shear force, TBARS value and sulfhydryl content. Moreover, the morphology of ice crystals was observed, and the myowater distribution of meat samples was determined by using low-field nuclear magnetic resonance. 【Result】Throughout storage period of samples, there were significantly lower (P<.05) total bacterial counts, TVB-N contents and TBARS values observed in LVEF samples than that of control group. Compared with control group, the meat samples subjected to LVEF groups exhibited higher water holding capacity and fresher color. During freezing, the meat samples under LVEF formed smaller and more uniform ice crystals in muscle, which resulted in less damage to the muscle microstructure. It was noteworthy that at 28 d, no significant differences (P>0.05) were observed among the total bacterial counts (4.50 lg (CFU/g)), TVB-N content (8.73 mg/100g) and TBARS value (0.1691 mg MDA?kg^-1) in meat samples subjected to LVEF group at -12℃, and those of control group at -18℃ (4.48 lg (CFU/g), 8.91 mg/100 g and 0.1754 mg MDA?kg^-1, respectively). Additionally, the purge loss, shear force and color between two groups showed no significant difference (P>0.05). 【Conclusion】In general, LVEF could effectively alleviate the quality deterioration of pork during frozen storage. However, there were no significant differences observed (P>0.05) in the meat quality traits between LVEF group at -12℃ and control group at -18℃ throughout the short-term storage (28 d), and the similar trend was found between LVEF group at -6℃ and control group at -12℃.

Key words: low voltage electrostatic field, short-term frozen storage, pork quality, retain freshness

胡斐斐,钱书意,黄峰,姜薇,强宇,江峰,胡海梅,李侠,张春晖. 低压静电场辅助短期冻藏对猪肉品质的影响[J]. 中国农业科学, 2021, 54(9): 1993-2005.

HU FeiFei,QIAN ShuYi,HUANG Feng,JIANG Wei,QIANG Yu,JIANG Feng,HU HaiMei,LI Xia,ZHANG ChunHui. Effect of Low Voltage Electrostatic Field-Assisted Short-Term Frozen Storage on Quality of Pork[J]. Scientia Agricultura Sinica, 2021, 54(9): 1993-2005.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2021.09.015

https://www.chinaagrisci.com/CN/Y2021/V54/I9/1993

图/表 12

表1

图1

图2

表2

图3

图4

图5

图6

图7

图8

图9

图10

参考文献 49

[1]	白京, 田寒友, 邹昊, 李文采, 王辉, 贾仕杰, 乔晓玲. 不同冻结方式对冻结猪肉保水性的影响机制. 食品科学, 2020,41(11):83-89.
	BAI J, TIAN H Y, ZOU H, LI W C, WANG H, JIA S J, QIAO X L. Effects of different freezing methods on water-holding capacity of frozen pork. Food Science, 2020,41(11):83-89. (in Chinese)
[2]	李瑶琪. 不同包装材料对冷、冻藏猪肉在贮藏期间品质的影响[D]. 大连: 大连工业大学, 2018.
	LI Y Q. Effect of different packaging materials on quality of chilling and frozen pork during storage[D]. Dalian: Dalian Polytechnic University, 2018. (in Chinese)
[3]	COOMBS C E O, HOLMAN B W B, FRIEND M A, HOPKINS D L. Long-term red meat preservation using chilled and frozen storage combinations: A review. Meat Science, 2017,125:84-94.
[4]	余小领, 李学斌, 赵良, 田孟超, 马汉军, 徐幸莲, 周光宏. 常规冷冻冻藏对猪肉保水性和组织结构的影响. 农业工程学报, 2008,24(12):264-268.
	YU X L, LI X B, ZHAO L, TIAN M C, MA H J, XU X L, ZHOU G H. Effects of conventional freezing processing and frozen storage on pork water-holding capacity and structure. Transactions of the Chinese Society of Agricultural Engineering, 2008,24(12):264-268. (in Chinese)
[5]	CHOI M J, TOLIBOVICH A, KIM E J, HONG G P. Effects of deep freezing temperature for long-term storage on quality characteristics and freshness of lamb meat. Korean Journal for Food Science of Animal Resources, 2018,38(5):959-969.
[6]	LU X, ZHANG Y M, ZHU L X, LUO X, HOPKINS D L. Effect of superchilled storage on shelf life and quality characteristics of M. longissimus lumborum from Chinese Yellow cattle. Meat Science, 2019,149:79-84.
[7]	QIAN S Y, LI X, WANG H, SUN Z, GUAN W Q, ZHANG C H, GUAN W Q, BLECKER C. Effect of sub-freezing storage (-6, -9 and -12℃) on quality and shelf life of beef. International Journal of Food Science & Technology, 2018,53(9):2129-2140.
[8]	孙圳. 牛肉亚冻结保藏品质变化与水分迁移机制[D]. 北京: 中国农业科学院, 2017.
	SUN Z. Study on the quality changing and water migration mechanism of beef in sub-freezing preservation[D]. Beijing: Chinese Academy of Agricultural Sciences, 2017. (in Chinese)
[9]	李里特, 方胜. 对静电场下果蔬保鲜机理的初步分析. 中国农业大学学报, 1996,1(2):62-65.
	LI L T, FANG S. Preliminary analysis on mechanism of fruit and vegetable preservation using electrostatic field. Journal of China Agricultural University, 1996,1(2):62-65. (in Chinese)
[10]	景德礼, 方胜, 李里特. 高压静电场在食品保鲜中的应用研究. 食品与机械, 1998(6):12-13.
	JING D L, FANG S, LI L T. Study on the effect of foodstuff preservation induced by high voltage electrostatic field. Food and Machinery, 1998(6):12-13. (in Chinese)
[11]	QIAN S Y, LI X, WANG H, MEHMOOD W, ZHONG M, ZHANG C H, BLECKER C. Effects of low voltage electrostatic field thawing on the changes in physicochemical properties of myofibrillar proteins of bovine Longissimus dorsi muscle. Journal of Food Engineering, 2019,261:140-149.
[12]	尚柯, 杨方威, 李侠, 张春晖, 钱书意, 孙圳. 静电场辅助冻结-解冻对肌肉保水性及蛋白理化特性的影响. 食品科学, 2018,39(3):157-162.
	SHANG K, YANG F W, LI X, ZHANG C H, QIAN S Y, SUN Z. Effect of electrostatic field-assisted freezing-thawing on water-holding capacity and physicochemical characteristics of beef muscle proteins. Food Science, 2018,39(3):157-162. (in Chinese)
[13]	李侠, 钱书意, 杨方威, 孙圳, 尚柯, 张春晖. 低压静电场下不同隔距冻结-解冻对牛肉品质的影响. 农业工程学报, 2017,33(8):278-285.
	LI X, QIAN S Y, YANG F W, SUN Z, SHANG K, ZHANG C H. Effects of different gauges under low voltage electrostatic field assisting thawing-freezing on beef quality. Transactions of the Chinese Society of Agricultural Engineering, 2017,33(8):278-285. (in Chinese)
[14]	段伟文, 全沁果, 高静, 毛伟杰, 郝记明, 刘书成, 吉宏武. 低压静电场结合气调包装对凡纳滨对虾冰温贮藏期品质的影响. 食品科学, 2019,40(13):252-259.
	DUAN W W, QUAN Q G, GAO J, MAO W J, HAO J M, LIU S C, JI H W. Effect of low-voltage electrostatic field combined with modified atmosphere packaging on the quality of Litopenaeus vannamei during controlled freezing-point storage. Food Science, 2019,40(13):252-259. (in Chinese)
[15]	王杏娣, 谢超, 梁瑞萍, 张家玮, 余铭, 张海玲. 低压静电场处理对竹节虾(Penaeus japonicus)微冻贮藏过程中品质的影响. 食品工业科技, 2020,41(7):1-6, 12.
	WANG X D, XIE C, LIANG R P, ZHANG J W, YU M, ZHANG H L. Effect of low voltage electrostatic field treatment on the quality of Penaeus japonicus during microfreezing storage. Science and Technology of Food Industry, 2020,41(7):1-6, 12. (in Chinese)
[16]	李银, 孙红梅, 张春晖, 白跃宇, 王振宇. 牛肉解冻过程中蛋白质氧化效应分析. 中国农业科学, 2013,46(7):1426-1433.
	LI Y, SUN H M, ZHANG C H, BAI Y Y, WANG Z Y. Analysis of frozen beef protein oxidation effect during thawing. Scientia Agricultura Sinica, 2013,46(7):1426-1433. (in Chinese)
[17]	HONIKEL K. Reference methods for the assessment of physical characteristic of meat. Meat Science, 1998,49(4):447-457.
[18]	谢小雷, 李侠, 张春晖, 王金枝, 王春青, 王兆进, 穆国锋. 中红外-热风组合干燥牛肉干降低能耗提高品质. 农业工程学报, 2013,29(23):217-226.
	XIE X L, LI X, ZHANG C H, WANG J Z, WANG C Q, WANG Z J, MU G F. Moisture mobility mechanism of beef jerky during combined mid-infrared and hot air drying. Transactions of the Chinese Society of Agricultural Engineering, 2013,29(23):217-226. (in Chinese)
[19]	XIA X F, KONG B H, LIU Q, LIU J. Physicochemical change and protein oxidation in porcine longissimus dorsi as influenced by different freeze-thaw cycles. Meat Science, 2009,83(2):239-245.
[20]	BAO Y L, ERTBJERG P. Relationship between oxygen concentration, shear force and protein oxidation in modified atmosphere packaged pork. Meat Science, 2015,110:174-179.
[21]	黄鸿兵, 徐幸莲, 周光宏. 冷冻贮藏过程中温度波动对猪肉肌间冰晶, 颜色和新鲜度的影响. 食品科学, 2006,27(8):49-53.
	HUANG H B, XU X L, ZHOU G H. Effects of temperature fluctuation on ice crystal, color and quality of pork muscle during frozen storage. Food Science, 2006,27(8):49-53. (in Chinese)
[22]	LI Y, LI X, WANG J Z, ZHANG C H, SUN H M, WANG C Q, XIE X L. Effects of oxidation on water distribution and physicochemical properties of porcine myofibrillar protein gel. Food Biophysics, 2014,9(2):169-178.
[23]	王正荣, 康壮丽, 朱明明, 赵圣明, 何鸿举, 马汉军. 食品鲜度保持卡对冰温贮藏鸡胸肉品质特性的影响. 食品工业科技, 2019,40(19):273-279, 290.
	WANG Z R, KANG Z L, ZHU M M, ZHAO S M, HE H J, MA H J. Influence of food antistaling agents on quality of fresh chicken breast during controlled freezing-point storage. Science and Technology of Food Industry, 2019,40(19):273-279, 290. (in Chinese)
[24]	RUIZ-CAPILLAS C, MORAL A. Changes in free amino acids during chilled storage of hake (Merluccius merluccius L.) in controlled atmospheres and their use as a quality control index. European Food Research and Technology, 2001,212(3):302-307.
[25]	SUMAN S P, HUNT M C, NAIR M N, RENTFROW G. Improving beef color stability: Practical strategies and underlying mechanisms. Meat Science, 2014,98(3):490-504.
[26]	EGELANDSDAL B, ABIE S M, BJARNADOTTIR S, ZHU H, KOLSTAD H, BJERKE F, MARTINSEN G, MASON A, MÜNCH D. Detectability of the degree of freeze damage in meat depends on analytic-tool selection. Meat Science, 2019,152:8-19.
[27]	HOLMAN W B, COOMBS E O, MORRIS S, KERR M J, HOPKINS D L. Effect of long term chilled (up to 5 weeks) then frozen (up to 12 months) storage at two different sub-zero holding temperatures on beef: 1. Meat quality and microbial loads. Meat Science, 2017,133:133-142.
[28]	WANG C, WANG H, LI X, ZHANG C H. Effects of oxygen concentration in modified atmosphere packaging on water holding capacity of pork steaks. Meat Science, 2019,148:189-197.
[29]	BENJAKUL S, VISESSANGUAN W, THONGKAEW C, TANAKA M. Comparative study on physicochemical changes of muscle proteins from some tropical fish during frozen storage. Food Research International, 2003,36(8):787-795.
[30]	LI F F, ZHONG Q, KONG B H, WANG B, PAN N, XIA X F. Deterioration in quality of quick-frozen pork patties induced by changes in protein structure and lipid and protein oxidation during frozen storage. Food Research International, 2020,133:109142.
[31]	闫利国, 唐善虎, 王柳, 李思宁, 白菊红, 卢付青, 水旭亭. 冷冻贮藏过程中氧化诱导牦牛肉肌原纤维蛋白结构的变化. 食品科学, 2015,36(24):337-342.
	YAN L G, TANG S H, WANG L, LI S N, BAI J H, LU F Q, SHUI X T. Oxidation-induced changes of myofibrillar protein structure of yak muscles during frozen storage. Food Science, 2015,36(24):337-342. (in Chinese)
[32]	KAALE L, EIKEVIK T. A study of the ice crystal sizes of red muscle of pre-rigor Atlantic salmon (Salmo salar) fillets during superchilled storage. Journal of Food Engineering, 2013,119(3):544-551.
[33]	程天赋, 蒋奕, 张翼飞, 赵茉楠, 俞龙浩. 基于低场核磁共振研究不同解冻方式对冻猪肉食用品质的影响. 食品科学, 2019,40(7):20-26.
	CHENG T F, JIANG Y, ZHANG Y F, ZHAO M N, YU L H. Effects of different thawing methods on quality of frozen pork as investigated using low field-nuclear magnetic resonance. Food Science, 2019,40(7):20-26. (in Chinese)
[34]	周光宏. 肉品加工学. 北京: 中国农业出版社, 2008.
	ZHOU G H. Meat Science and Technology. Beijing: China Agriculture Press, 2008. (in Chinese)
[35]	ALIZADEH E, CHAPLEAU N, DE LAMBALLERIE M, LE-BAIL A. Effect of different freezing processes on the microstructure of Atlantic salmon (Salmo salar) fillets. Innovative Food Science & Emerging Technologies, 2007,8(4):493-499.
[36]	李苑, 王丽平, 余海霞, 杨水兵, 胡亚芹. 电场对三疣梭子蟹微冻贮藏过程中品质的影响. 食品研究与开发, 2018,39(5):192-197.
	LI Y, WANG L P, YU H X, YANG S B, HU Y Q. Effect of electric field on the quality of Portunus trituberculatus during superchilling. Food Research and Development, 2018,39(5):192-197. (in Chinese)
[37]	何向丽. 猪里脊肉冻结解冻特性及高压静电场(HVEF)解冻机理研究[D]. 北京: 中国农业大学, 2016.
	HE X L. Freezing and thawing characteristics of pork tenderloin meat and the mechanism of high voltage electrostatic field (HVEF) thawing[D]. Beijing: China Agricultural University, 2016. (in Chinese)
[38]	HUANG H, SUN W Q, XIONG G Q, SHI L, JIAO C H, WU W J, LI X, QIAO Y, LIAO L, DING A Z, WANG L. Effects of HVEF treatment on microbial communities and physicochemical properties of catfish fillets during chilled storage. LWT-Food Science and Technology, 2020,131:109667.
[39]	HSIEH C W, LAI C H, LEE C H, KO W C. Effects of high-voltage electrostatic fields on the quality of Tilapia meat during refrigeration. Journal of Food Science, 2011,76(6):312-317.
[40]	DALVI-ISFAHAN M, HAMDAMI N, LE-BAIL A. Effect of freezing under electrostatic field on the quality of lamb meat. Innovative Food Science and Emerging Technologies, 2016,37:68-73.
[41]	GROSS D. Electromobile surface charge alters membrane potential changes induced by applied electric fields. Biophysical Journal, 1988,54(5):879-884.
[42]	叶青. 高压静电场保鲜装置改进及对几种呼吸跃变型果实的影响[D]. 北京: 中国农业大学, 2004.
	YE Q. The improvement to equipment of HVEF and the effect of HVEF on some climacteric fruits[D]. Beijing: China Agricultural University, 2004. (in Chinese)
[43]	JIANG Q Q, NAKAZAWA N, HU Y Q, OSAKO K, OKAZAKI E. Changes in quality properties and tissue histology of lightly salted tuna meat subjected to multiple freeze-thaw cycles. Food Chemistry, 2019,293:178-186.
[44]	KO W Q, YANG S Y, CHANG C K, HSIEH C W. Effects of adjustable parallel high voltage electrostatic field on the freshness of tilapia (Orechromis niloticus) during refrigeration. LWT-Food Science and Technology, 2016,66:151-157.
[45]	岑剑伟. 冰温气调结合高压静电场对罗非鱼片保鲜及其机理研究[D]. 广州: 华南农业大学, 2016.
	CEN J W. Effect of high voltage electrostatic field combined with modified atmosphere packaging and controlled freezing-point storage on the quality of tilapia fillet and its mechanism research[D]. Guangzhou: South China Agricultural University, 2016. (in Chinese)
[46]	JIA G L, NIRASAWA S, JI X H, LUO Y K, LIU H J. Physicochemical changes in myofibrillar proteins extracted from pork tenderloin thawed by a high-voltage electrostatic field. Food Chemistry, 2018,240:910-916.
[47]	XANTHAKIS E, HAVET M, CHEVALLIER S, ABADIE J, LE-BAIL A. Effect of static electric field on ice crystal size reduction during freezing of pork meat. Innovative Food Science and Emerging Technologies, 2013,20:115-120.
[48]	DALVI-ISFAHAN M, HAMDAMI N, LE-BAIL A. Effect of combined high voltage electrostatic with air blast freezing on quality attributes of lamb meat. Journal of Food Process Engineering, 2018,41:e12811.
[49]	ORLOWSKA M, HAVET M, LE-BAIL A. Controlled ice nucleation under high voltage DC electrostatic field conditions. Food Research International, 2009,42(7):879-884.

组别 Group	温度 Temperature (℃)	条件 Treatment
-18L	-18	低压静电场 LVEF
-18	-18	对照 Control
-12L	-12	低压静电场 LVEF
-12	-12	对照 Control
-6L	-6	低压静电场 LVEF
-6	-6	对照 Control

贮藏时间 Storage time (d)		组别 Group
贮藏时间 Storage time (d)		-18L	-18	-12L	-12	-6L	-6
0	L*	54.11±0.81	54.11±0.81	54.11±0.81	54.11±0.81	54.11±0.81	54.11±0.81
	a*	7.55±0.21	7.55±0.21	7.55±0.21	7.55±0.21	7.55±0.21	7.55±0.21
	b*	4.96±0.38	4.96±0.38	4.96±0.38	4.96±0.38	4.96±0.38	4.96±0.38
7	L*	53.25±0.61a	52.7±0.44a	52.65±0.67a	52.53±0.54a	52.48±0.78a	52.45±0.63a
	a*	7.66±0.39a	7.51±0.54a	7.63±0.39a	7.33±0.60a	7.46±0.62a	7.10±0.72a
	b*	5.48±1.03a	5.56±0.83a	5.62±1.05a	5.21±0.87ab	5.85±0.65a	4.25±0.36b
14	L*	52.46±0.69a	51.71±0.72a	52.01±0.76a	51.66±0.80a	51.40±0.71a	51.14±0.59a
	a*	7.67±0.69a	7.20±0.64a	7.55±0.64a	7.07±0.45a	6.94±0.64a	6.85±0.77a
	b*	5.08±0.46ab	5.98±0.56a	4.80±0.83ab	5.63±0.76ab	4.65±1.01b	5.72±0.94ab
21	L*	52.22±0.49a	51.61±0.76ab	51.83±0.47a	51.49±1.66ab	51.09±0.54ab	50.26±0.85b
	a*	7.42±0.57a	6.56±0.31bc	6.74±0.67ab	6.71±0.48ab	6.12±0.46cd	5.73±0.38d
	b*	4.89±0.66b	6.12±0.49a	3.67±0.30c	5.96±0.99a	4.39±0.65bc	4.65±0.55b
28	L*	51.32±0.45a	50.87±0.83ab	50.76±0.77ab	50.27±0.72abc	50.05±0.78bc	49.40±0.60c
	a*	6.71±0.33a	6.36±0.24a	6.46±0.37a	6.42±0.90a	5.82±0.59a	5.65±0.49a
	b*	4.94±0.58b	5.15±0.42b	3.49±0.57c	4.62±0.45b	4.55±0.57b	6.22±0.76a
