中国农业科学 ›› 2022, Vol. 55 ›› Issue (20): 4011-4019.doi: 10.3864/j.issn.0578-1752.2022.20.012
收稿日期:
2022-01-10
接受日期:
2022-04-11
出版日期:
2022-10-16
发布日期:
2022-10-24
通讯作者:
仝宇欣
作者简介:
李扬眉,Tel:17683058646;E-mail: 基金资助:
LI YangMei(),LIU Xin,JIA MengHan,TONG YuXin()
Received:
2022-01-10
Accepted:
2022-04-11
Online:
2022-10-16
Published:
2022-10-24
Contact:
YuXin TONG
摘要:
【背景】 近年来,植物工厂因具有可在垂直立体空间进行周年计划性、省力化和无农药、洁净安全生产等传统农业无可比拟的优势,在全球得到蓬勃发展。然而,由于植物工厂内叶菜生长速度较快,而新叶部位的蒸腾较弱等原因,较易发生干烧心,大幅降低叶菜外观和内在品质。【目的】 研究光期不同湿度对水培生菜干烧心、生长及其营养品质的影响,优化预防或减缓生菜干烧心发生的植物工厂湿度环境参数,为防控生菜干烧心发生,提高植物工厂生菜品质和运行效益提供技术和理论支撑。【方法】 选用在植物工厂环境下较易发生干烧心的‘Tiberius’生菜作为研究对象,在光环境、温度、二氧化碳等环境条件保持一致的情况下,使光期(16 h)各处理空气相对湿度分别维持在50%(RH50)、70%(RH70)和90%(RH90),暗期(8 h)各处理空气相对湿度保持一致为70%,湿度控制正负误差在5%以内。调查各处理组生菜干烧心发生情况、叶片光合参数、产量及营养品质的差异。【结果】 与RH70和RH90相比:(1)RH50处理显著提高了生菜新叶中钙离子含量,降低了采收时干烧心发生率,并且随着相对湿度水平降低,干烧心的初次发生时间得到显著推迟;(2)RH50处理未对试验光强下生菜的净光合速率产生影响,但却显著增加了生菜气孔导度、蒸腾速率和胞间CO2浓度,促进了茎叶的钙离子运输;(3)RH50处理未显著降低生菜的总叶面积及茎叶鲜重,但却明显改善了生菜营养品质,使淀粉、抗坏血酸和可溶性蛋白的含量得到显著提高。【结论】 植物工厂高湿环境是生菜干烧心频发的原因之一,通过合理降低湿度水平能够在不显著影响生菜光合能力及产量的情况下,有效减缓生菜干烧心的发生,提高生菜的外观和营养品质,增加其商品价值,保障植物工厂优质高效生产。
李扬眉,刘鑫,贾梦晗,仝宇欣. 光期湿度对植物工厂生菜干烧心及其营养品质的影响[J]. 中国农业科学, 2022, 55(20): 4011-4019.
LI YangMei,LIU Xin,JIA MengHan,TONG YuXin. Tipburn Injury and Nutritional Quality of Lettuce Plants as Affected by Humidity Control During the Light Period in A Plant Factory[J]. Scientia Agricultura Sinica, 2022, 55(20): 4011-4019.
表2
不同湿度水平处理对生菜光合参数的影响"
处理 Treatment | 气孔导度 Stomatal conductance (mol·m-2·s-1) | 蒸腾速率 Transpiration rate (mmol·m-2·s-1) | 胞间二氧化碳浓度 Intercellular carbon dioxide concentration (μmol·mol-1) | 净光合速率 Net photosynthetic rate (μmol·m-2·s-1) | 暗呼吸速率 Dark respiration rate (μmol·m-2·s-1) |
---|---|---|---|---|---|
RH50 | 0.41±0.03a | 4.8±0.3a | 519.5±5.1a | 14.8±0.1a | 1.8±0.1b |
RH70 | 0.27±0.02b | 2.0±0.1b | 492.6±7.0b | 14.7±0.2a | 2.1±0.1a |
RH90 | 0.20±0.02b | 1.1±0.1c | 464.2±11.4c | 14.1±0.4a | 2.0±0.1ab |
表3
不同湿度水平处理对生菜生长发育及其产量的影响"
处理 Treatment | 总叶片数 Total leaf number | 总叶面积 Total leaf area (cm2) | 茎叶鲜重 Shoot fresh weight (g) | 茎叶干重 Shoot dry weight (g) | 根系鲜重 Root fresh weight (g) | 根系干重 Root dry weight (g) | 比叶重 Leaf mass per area (g·m-2) |
---|---|---|---|---|---|---|---|
RH50 | 23.7±0.4b | 1608.2±53.2a | 123.1±4.2a | 6.6±0.2a | 10.1±0.4b | 0.77±0.04a | 22.1±0.5a |
RH70 | 26.2±0.5a | 1525.5±40.5a | 127.2±2. 9a | 6.0±0.2b | 12.6±0. 6a | 0.69±0.04ab | 20.8±0.5a |
RH90 | 27.1±0.5a | 1511.0±36.5a | 121.0±3.3a | 5.8±0.1b | 11.4±0.5ab | 0.63±0.02b | 18.8±0.3b |
[1] | 仝宇欣, 方炜, 王敏娟, 马承伟, 徐丹, 王柔心, 钟兴颖. 数字化植物工厂理论与实践. 北京: 中国农业科学技术出版社, 2020. |
TONG Y X, FANG W. WANG M J, MA C W, XU D, WANG R X, ZHONG X Y. The theory and practice of digital plant factory. The first edition. Beijing: China Agricultural Science and Technology Press, 2020. (in Chinese) | |
[2] |
XU W S, NGUYEN D T P, SAKAGUCHI S, AKIYAMA T, TSUKAGOSHI S, FELDMAN A, LU N. Relation between relative growth rate and tipburn occurrence of romaine lettuce under different light regulations in a plant factory with LED lighting. European Journal of Horticultural Science, 2020, 85(5): 354-361. doi: 10.17660/eJHS.2020/85.5.7.
doi: 10.17660/eJHS.2020/85.5.7 |
[3] |
SAGO Y. Effects of light intensity and growth rate on tipburn development and leaf calcium concentration in butterhead lettuce. HortScience, 2016, 51(9): 1087-1091. doi: 10.21273/HORTSCI10668-16.
doi: 10.21273/HORTSCI10668- 16 |
[4] |
HAGASSOU D, FRANCIA E, RONGA D, BUTI M. Blossom end-rot in tomato (Solanum lycopersicum L.): A multi-disciplinary overview of inducing factors and control strategies. Scientia Horticulturae, 2019, 249: 49-58. doi: 10.1093/jxb/erq128.
doi: 10.1093/jxb/erq128 |
[5] |
YU X M, WANG J Z, NIE P X, XUE X M, WANG G P, AN M. Control efficacy of Ca-containing foliar fertilizers on bitter pit in bagged ‘Fuji’ apple and effects on the Ca and N contents of apple fruits and leaves. Journal of the Science of Food and Agriculture, 2018, 98(14): 5435-5443. doi: 10.1002/jsfa.9087.
doi: 10.1002/jsfa.9087 |
[6] |
KOYAMA R, SANADA M, ITOH H, KANECHI M, INAGAKI N, UNO Y. In vitro evaluation of tipburn resistance in lettuce (Lactuca sativa L). Plant Cell, Tissue and Organ Culture, 2012, 108(2): 221-227. doi: 10.1007/s11240-011-0033-5.
doi: 10.1007/s11240-011-0033-5 |
[7] |
JENNI S, TRUCO M J, MICHELMORE R W. Quantitative trait loci associated with tipburn, heat stress-induced physiological disorders, and maturity traits in crisphead lettuce. Theoretical and Applied Genetics, 2013, 126(12): 3065-3079. doi: 10.1007/s00122-013-2193-7.
doi: 10.1007/s00122-013- 2193-7 |
[8] |
MACIAS-GONZÁLEZ M, TRUCO M J, BERTIER L D, JENNI S, SIMKO I, HAYES R J, MICHELMORE R W. Genetic architecture of tipburn resistance in lettuce. Theoretical and Applied Genetics, 2019, 132(8): 2209-2222. doi: 10.1007/s00122-019-03349-6.
doi: 10.1007/s00122-019-03349-6 |
[9] |
KURONUMA T, ANDO M, WATANABE H. Tipburn incidence and Ca acquisition and distribution in lisianthus (Eustoma grandiflorum (raf.) shinn.) cultivars under different Ca concentrations in nutrient solution. Agronomy, 2020, 10(2): 216. doi: 10.3390/agronomy10020216.
doi: 10.3390/agronomy10020216 |
[10] |
DE BANG T C, HUSTED S, LAURSEN K H, PERSSON D P, SCHJOERRING J K. The molecular-physiological functions of mineral macronutrients and their consequences for deficiency symptoms in plants. The New Phytologist, 2021, 229(5): 2446-2469. doi: 10.1111/nph.17074.
doi: 10.1111/nph.17074 |
[11] |
LEE R J, BHANDARI S R, LEE G, LEE J G. Optimization of temperature and light, and cultivar selection for the production of high-quality head lettuce in a closed-type plant factory. Horticulture, Environment, and Biotechnology, 2019, 60(2): 207-216. doi: 10.1007/s13580-018-0118-8.
doi: 10.1007/ s13580-018-0118-8 |
[12] |
CHOI K Y, LEE Y B. Effect of air temperature on tipburn incidence of butterhead and leaf lettuce in a plant factory. Journal of the Korean Society for Horticultural Science, 2003, 44(6): 805-808. doi: 10.1007/978-94-015-9371-727.
doi: 10.1007/ 978-94-015-9371-727 |
[13] |
SAMARAKOON U, PALMER J, LING P, ALTLAND J. Effects of electrical conductivity, pH, and foliar application of calcium chloride on yield and tipburn of lactuca sativa grown using the nutrient-film technique. HortScience, 2020, 55(8): 1265-1271. doi: 10.21273/HORTSCI15070-20.
doi: 10.21273/ HORTSCI15070-20 |
[14] |
INTHICHACK P, NISHIMURA Y, FUKUMOTO Y. Effect of potassium sources and rates on plant growth, mineral absorption, and the incidence of tip burn in cabbage, celery, and lettuce. Horticulture, Environment, and Biotechnology, 2012, 53(2): 135-142. doi: 10.1007/s13580-012-0126-z.
doi: 10.1007/s13580-012-0126-z |
[15] |
NUKAYA A, GOTO K, JANG H, KANO A, OHKAWA K. Effect of NH4-N level in the nutrient solution on the incidence of blossom-end rot and gold specks on tomato fruit grown in rockwool. Acta Horticulturae, 1995, 401: 381-388. doi: 10.17660/actahortic.1995.401.46.
doi: 10.17660/actahortic.1995.401. 46 |
[16] |
XU J, GUO Z X, JIANG X C, AHAMMED G J, ZHOU Y H. Light regulation of horticultural crop nutrient uptake and utilization. Horticultural Plant Journal, 2021, 7(5): 367-379. doi: 10.1016/j.hpj.2021.01.005.
doi: 10.1016/j.hpj. 2021.01.005 |
[17] | 李列, 仝宇欣, 李锦, 杨其长. 不同光质组合对生菜生长和能量利用效率的影响. 西北农林科技大学学报(自然科学版), 2020, 48(9): 114-120. |
LI L, TONG Y X, LI J, YANG Q C. Effect of different combinations of light wavelengths on growth and energy use efficiency of lettuce. Journal of Northwest A & F University (Natural Science Edition), 2020, 48(9): 114-120. (in Chinese) | |
[18] |
AHMED H A, TONG Y X, YANG Q C. Lettuce plant growth and tipburn occurrence as affected by airflow using a multi-fan system in a plant factory with artificial light. Journal of Thermal Biology, 2020, 88: 102496. doi: 10.1016/j.jtherbio.2019.102496.
doi: 10.1016/j.jtherbio.2019.102496 |
[19] |
GOTO E, TAKAKURA T. Prevention of lettuce tipburn by supplying air to inner leaves. Transactions of the American Society of Agricultural Engineers, 1992, 35(2): 641-645. doi: 10.13031/2013.28644.
doi: 10.13031/2013. 28644 |
[20] |
BORKOWSKI J, DYKI B, OSKIERA M, MACHLANSKA A, FELCZYNSKA A. The prevention of tipburn on Chinese cabbage (Brassica rapa L. var. pekinensis (Lour.) Olson) with foliar fertilizers and biostimulators. Journal of Horticultural Research, 2016, 24(1): 47-56. doi: 10.1515/johr-2016-0006.
doi: 10.1515/johr-2016-0006 |
[21] | 泰兹, 奇格尔, 宋纯鹏, 王学路, 周云. 植物生理学. 第五版. 北京: 科学出版社, 2015: 80-81. |
TAIZ L, ZEIGER E, SONG C P, WANG X L, ZHOU Y. Plant Physiology. 5th edition. Beijing: Science Press, 2015: 80-81. (in Chinese). | |
[22] |
GILLIHAM M, DAYOD M, HOCKING B J, XU B, CONN S J, KAISER B N, LEIGH R A, TYERMAN S D. Calcium delivery and storage in plant leaves: Exploring the link with water flow. Journal of Experimental Botany, 2011, 62(7): 2233-2250. doi: 10.1093/jxb/err111.
doi: 10.1093/jxb/err111 pmid: 21511913 |
[23] | 高丽红, 别之龙. 无土栽培学. 北京: 中国农业大学出版社, 2017. |
GAO L H, BIE Z L. Soilless Culture. Beijing: China Agricultural University Press, 2017. (in Chinese) | |
[24] |
叶子飘. 光合作用对光和CO2响应模型的研究进展. 植物生态学报, 2010, 34(6): 727-740.
doi: 10.3773/j.issn.1005-264x.2010.06.012 |
YE Z P. A review on modeling of responses of photosynthesis to light and CO2. Chinese Journal of Plant Ecology, 2010, 34(6): 727-740. (in Chinese)
doi: 10.3773/j.issn.1005-264x.2010.06.012 |
|
[25] | 王三根. 植物生理学实验教程. 北京: 科学出版社, 2017. |
WANG S G. Experiment Course of Plant Physiology. Beijing: Science Press, 2017. (in Chinese) | |
[26] | 陈德伟, 汤寓涵, 石文波, 张夏燕, 陶俊, 赵大球. 钙调控植物生长发育的进展分析. 分子植物育种, 2019, 17(11): 3593-3601. |
CHEN D W, TANG Y H, SHI W B, ZHANG X Y, TAO J, ZHAO D Q. Progress in the regulation of calcium growth and development. Molecular Plant Breeding, 2019, 17(11): 3593-3601. (in Chinese) | |
[27] | 李贺, 刘世琦, 刘中良, 冯磊, 刘景凯, 陈祥伟, 王越. 钙对大蒜生理特性及主要矿质元素吸收的影响. 中国农业科学, 2013, 46(17): 3626-3634. |
LI H, LIU S Q, LIU Z L, FENG L, LIU J K, CHEN X W, WANG Y. Effects of calcium on physiological characteristics and main mineral elements absorption of garlic. Scientia Agricultura Sinica, 2013, 46(17): 3626-3634. (in Chinese) | |
[28] | CHOI K Y, LEE Y B. Effects of relative humidity on the apparent variability in the incidence of tipburn symptom and distribution of mineral nutrients between morphologically different lettuce (Lactuca sativa L.) cultivars. Horticulture Environment and Biotechnology, 2008, 49: 20-24. |
[29] | 程涣. 大白菜干烧心病发生与钙运输基因和CAS基因表达分析[D]. 南京: 南京农业大学, 2015. |
CHENG H. The expression analysis on Ca2+ transport and response genes under calcium deficiency condition in different resistance plants[D]. Nanjing: Nanjing Agricultural University, 2015. (in Chinese) | |
[30] |
MONTANARO G, DICHIO B, XILOYANNIS C. Significance of fruit transpiration on calcium nutrition in developing apricot fruit. Journal of Plant Nutrition and Soil Science, 2010, 173(4): 618-622. doi: 10.1002/jpln.200900376.
doi: 10.1002/jpln.200900376 |
[31] | 韩路, 王海珍, 徐雅丽, 牛建龙. 灰胡杨蒸腾速率对气孔导度和水汽压差的响应. 干旱区资源与环境, 2016, 30(8): 193-197. |
HAN L, WANG H Z, XU Y L, NIU J L. Responses of transpiration rate of Populus pruinosa to stomatal conductance and vapor pressure deficient. Journal of Arid Land Resources and Environment, 2016, 30(8): 193-197. (in Chinese) | |
[32] |
GRANTZ D A. Plant response to atmospheric humidity. Plant, Cell and Environment, 1990, 13(7): 667-679. doi: 10.1111/j.1365-3040.1990.tb01082.x.
doi: 10.1111/j.1365-3040. 1990.tb01082.x |
[33] |
CARINS MURPHY M R, JORDAN G J, BRODRIBB T J. Acclimation to humidity modifies the link between leaf size and the density of veins and stomata. Plant, Cell & Environment, 2014, 37(1): 124-131. doi: 10.1111/pce.12136.
doi: 10.1111/pce.12136 |
[34] |
HASSIOTOU F, RENTON M, LUDWIG M, EVANS J R, VENEKLAAS E J. Photosynthesis at an extreme end of the leaf trait spectrum: how does it relate to high leaf dry mass per area and associated structural parameters? Journal of Experimental Botany, 2010, 61(11): 3015-3028. doi: 10.1093/jxb/erq128.
doi: 10.1093/jxb/erq128 pmid: 20484320 |
[35] | 陈晓丽, 杨其长, 张馨, 马太光, 郭文忠, 薛绪掌. LED绿光补光模式对生菜生长及品质的影响. 中国农业科学, 2017, 50(21): 4170-4177. |
CHEN X L, YANG Q C, ZHANG X, MA T G, GUO W Z, XUE X Z. Effects of green LED light on the growth and quality of lettuce. Scientia Agricultura Sinica, 2017, 50(21): 4170-4177. (in Chinese) | |
[36] |
LEE S K, KADER A A. Preharvest and postharvest factors influencing vitamin C content of horticultural crops. Postharvest Biology and Technology, 2000, 20(3): 207-220.
doi: 10.1016/S0925-5214(00)00133-2 |
[37] |
AHNEN R T, JONNALAGADDA S S, SLAVIN J L. Role of plant protein in nutrition, wellness, and health. Nutrition Reviews, 2019, 77(11): 735-747. doi: 10.1093/nutrit/nuz028.
doi: 10.1093/nutrit/nuz028 pmid: 31322670 |
[38] |
PONGPRAYOON W, ROYTRAKUL S, PICHAYANGKURA R, CHADCHAWAN S. The role of hydrogen peroxide in chitosan- induced resistance to osmotic stress in rice (Oryza sativa L.). Plant Growth Regulation, 2013, 70(2): 159-173. doi: 10.1007/s10725-013-9789-4.
doi: 10.1007/s10725-013- 9789-4 |
[39] | 程智慧, 高芸, 孟焕文. 盐胁迫对番茄幼苗转化酶表达及糖代谢的影响. 西北农林科技大学学报(自然科学版), 2007, 35(1): 184-188. |
CHENG Z H, GAO Y, MENG H W. Effects of salinity stress on invertase expression and carbohydrate metabolism in tomato seedling. Journal of Northwest A & F University (Natural Science Edition), 2007, 35(1): 184-188. (in Chinese) |
