侵染萝卜的油菜花叶病毒广东分离物分子特征及其致病性分析

doi:10.3864/j.issn.0578-1752.2022.14.006

摘要/Abstract

摘要：

【目的】病毒病是萝卜（Raphanus sativus）生产上的主要病害之一,严重危害萝卜生产安全及产业发展。本研究旨在鉴定侵染广东萝卜的病毒种类,探究侵染萝卜的油菜花叶病毒（youcai mosaic virus,YoMV）分子特征及致病性,为萝卜病毒病的防控提供科学依据。【方法】从广东省惠州市萝卜种植基地采集了3个疑似病毒病侵染的萝卜病样及1个无症状样品,提取样品总RNA,利用小RNA深度测序初步探明病毒种类,然后根据测序结果设计病毒特异引物进行RT-PCR验证。应用分段克隆方法扩增病原病毒YoMV基因组1—3 405 nt片段和3 194—6 304 nt片段,然后通过同源重组克隆到pCB301双元载体上,得到YoMV-GD分离物基因组全长序列,同时构建该病毒分离物的侵染性克隆。利用MEGA7软件对YoMV-GD及其他分离物全长核苷酸序列进行系统进化分析。通过侵染性克隆人工注射接种本生烟和普通烟,检验pCB301-YoMV-GD的侵染性,然后再注射接种萝卜和菜心,测定YoMV-GD分离物的致病性。【结果】侵染广东萝卜的病毒包含萝卜隐状病毒3（Raphanus sativus cryptic virus 3,RsCV3）、萝卜黄病毒1（Raphanus sativus chrysovirus 1,RasCV1）、芜菁花叶病毒（turnip mosaic virus,TuMV）、YoMV 4种;YoMV-GD分离物全长序列为6 304 nt,编码4个蛋白,分别为124.7 kD复制相关蛋白、183 kD复制酶、30 kD运动蛋白MP、17.7 kD外壳蛋白CP,与YoMV英国分离物（GenBank登录号：AY318866）核苷酸相似性最高,为99.18%;YoMV-GD分离物与英国、德国及我国上海、重庆分离物的亲缘关系较近;构建的侵染性克隆pCB301-YoMV-GD可以系统侵染本生烟和普通烟,引起严重的坏死、枯斑等症状,具有较强的侵染性;YoMV-GD可以系统侵染萝卜和菜心,引起轻微的黄化和花叶等症状,致病力较弱。【结论】侵染广东萝卜的病毒包含RsCV3、RasCV1、TuMV和YoMV,且以复合侵染形式存在;YoMV遗传进化并没有明显的地域性;YoMV-GD对烟草致病力较强,而对萝卜和菜心致病力较弱。

关键词: 萝卜病毒病, 油菜花叶病毒, 分子特征, 侵染性克隆, 致病性

Abstract:

【Objective】Viral disease is one of the major factors threatening the production safety and radish farming industry. The objective of this study is to identify the viruses that infect radish in Guangdong Province, and to analyze the molecular characteristics and pathogenicity of youcai mosaic virus (YoMV), so as to provide theoretical basis for the prevention of viral disease in radish. 【Method】Three symptomatic and one asymptomatic samples were collected from a radish-planting base in Guangdong and were subjected to total RNA extraction. Small RNA sequencing and assembly (sRSA) was used to identify the virus species, followed by RT-PCR verification with specific primer pairs designed according to the sRSA results. To construct the infectious cDNA clones of YoMV-GD isolate, two primer pairs were designed, and the PCR products were introduced into pCB301 vector by seamless cloning and assembly. Then the full-length genomic sequences of YoMV-GD and other YoMV isolates were used to construct phylogenetic tree by MEGA7 software. Agrobacterium containing pCB301-YoMV-GD was infiltrated into Nicotiana benthamiana and Nicotiana tabacum to verify the infectivity of YoMV-GD infectious cDNA clones. Subsequently, the pathogenicity of YoMV-GD was tested in radish and Chinese flowering cabbage by agroinfiltration. 【Result】sRSA result showed that the viruses that infecting radish in Guangdong include Raphanus sativus cryptic virus 3 (RsCV3), Raphanus sativus chrysovirus 1 (RasCV1), turnip mosaic virus (TuMV), and YoMV. Sanger sequencing reveals that YoMV-GD isolate contains 6 304 nt and encodes four proteins, replication-associated protein, replicase, movement protein, and coat protein. YoMV-GD shares the highest similarity (99.18%) with YoMV British isolate (GenBank accession number: AY318866). Phylogenetic analysis shows that YoMV-GD has a closer relationship with isolates from British, Germany, Shanghai, and Chongqing. In addition, the YoMV-GD infectious cDNA clones could successfully infect N. benthamiana and N. tabacum, causing crinkle, mosaic, and necrosis symptoms in the upper leaves. Moreover, though YoMV-GD isolate could systemically infect radish and Chinese flowering cabbage, the symptoms were very weak. 【Conclusion】Viruses infecting radish in Guangdong include RsCV3, RasCV1, TuMV, and YoMV, and mixed infection is the main type. There was no clear regional difference among YoMV isolates. YoMV-GD is highly pathogenic in tobacco, but weak in radish and Chinese flowering cabbage.

Key words: viral disease in radish, youcai mosaic virus (YoMV), molecular characteristics, infectious clone, pathogenicity

李正刚,汤亚飞,佘小漫,于琳,蓝国兵,何自福. 侵染萝卜的油菜花叶病毒广东分离物分子特征及其致病性分析[J]. 中国农业科学, 2022, 55(14): 2752-2761.

LI ZhengGang,TANG YaFei,SHE XiaoMan,YU Lin,LAN GuoBing,HE ZiFu. Molecular Characteristics and Pathogenicity Analysis of Youcai Mosaic Virus Guangdong Isolate Infecting Radish[J]. Scientia Agricultura Sinica, 2022, 55(14): 2752-2761.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2022.14.006

https://www.chinaagrisci.com/CN/Y2022/V55/I14/2752

图/表 7

表1

图1

表2

图2

图3

图4

图5

参考文献 29

[1]	袁伟玲, 袁尚勇, 甘彩霞, 崔磊, 邓晓辉. 湖北广水萝卜病毒病的分子鉴定与防治. 长江蔬菜, 2015(8): 61-62.
	YUAN W L, YUAN S Y, GAN C X, CUI L, DENG X H. Molecular identification and prevention of radish virus disease in Guangshui of Hubei Province. Journal of Changjiang Vegetables, 2015(8): 61-62. (in Chinese)
[2]	JU H K, KIM I H, HU W X, KIM B, CHOI G W, KIM J, LIM Y P, DOMIER L L, HAMMOND J, LIM H S. A single nucleotide change in the overlapping MP and CP reading frames results in differences in symptoms caused by two isolates of youcai mosaic virus. Archives of Virology, 2019, 164(6): 1553-1565. doi: 10.1007/s00705-019-04222-z
[3]	王莉爽, 陈小均, 陈文, 谭清群, 杨学辉. 贵州蔬菜病毒病主要病毒种类检测. 广东农业科学, 2015, 42(20): 63-67.
	WANG L S, CHEN X J, CHEN W, TAN Q Q, YANG X H. Detection of main viral species of vegetable virus deseases in Guizhou. Guangdong Agricultural Science, 2015, 42(20): 63-67. (in Chinese)
[4]	CHUNG J, HAN J Y, KIM J, JU H, GONG J, SEO E Y, HAMMOND J, LIM H S. Survey of viruses present in radish fields in 2014. Research in Plant Disease, 2015, 21(3): 235-242. doi: 10.5423/RPD.2015.21.3.235
[5]	CHOI S K, PARK S H, JEON B W, JANG S W, YOON J Y. First report of youcai mosaic virus in Raphanus raphanistrum subsp. sativus in Korea. Plant Disease, 2017, 101(11): 1959.
[6]	CHEN X R, WANG Y, ZHAO H H, ZHANG X Y, WANG X B, LI D W, YU J L, HAN C G. Brassica yellows virus’ movement protein upregulates anthocyanin accumulation, leading to the development of purple leaf symptoms on Arabidopsis thaliana. Scientific Reports, 2018, 8: 16273.
[7]	邱孝军, 谭群运, 肖清明, 梅时勇, 张冀芳. 长沙地区萝卜病毒病病原鉴定与萝卜种质抗病性评价. 园艺学报, 2020, 47(10): 1947-1955.
	QIU X J, TAN Q Y, XIAO Q M, MEI S Y, ZHANG J F. Pathogen identification of virus disease and evaluation for germplasm disease resistance in radish. Acta Horticulturae Sinica, 2020, 47(10): 1947-1955. (in Chinese)
[8]	刘勇, 李凡, 李月月, 张松柏, 高希武, 谢艳, 燕飞, 张安盛, 戴良英, 程兆榜, 等. 侵染我国主要蔬菜作物的病毒种类、分布与发生趋势. 中国农业科学, 2019, 52(2): 239-261.
	LIU Y, LI F, LI Y Y, ZHANG S B, GAO X W, XIE Y, YAN F, ZHANG A S, DAI L Y, CHENG Z B, et al. Identification, distribution and occurrence of viruses in the main vegetables of China. Scientia Agricultura Sinica, 2019, 52(2): 239-261. (in Chinese)
[9]	LARTEY R T, VOSS T C, MELCHER U. Tobamovirus evolution: Gene overlaps, recombination, and taxonomic implications. Molecular Biology and Evolution, 1996, 13(10): 1327-1338. doi: 10.1093/oxfordjournals.molbev.a025579
[10]	魏景超, 沈淑琳, 王俊林, 张成琬, 朱有釭. 华东地区油菜和十字花科蔬菜花叶病的初步研究. 植物病理学报, 1958, 4(2): 94-111, 149-150.
	WEI J C, SHEN S L, WANG J L, ZHANG C W, ZHU Y G. Mosaic disease of Chinese rape and other crucifers in eastern China. Acta Phytopathologica Sinica, 1958, 4(2): 94-111, 149-150. (in Chinese)
[11]	FUJI S I, MOCHIZUKI N, FUJINAGA M, IKEDA M, SHINODA K, UEMATSU S, FURUYA H, NAITO H, FUKUMOTO F. Incidence of viruses in Alstroemeria plants cultivated in Japan and characterization of broad bean wilt virus-2, cucumber mosaic virus and youcai mosaic virus. Journal of General Plant Pathology, 2007, 73(3): 216-221. doi: 10.1007/s10327-007-0009-9
[12]	ZHU H, HONG J, YE R, CHEN J, YU S, ADAMS M J. Sequence analysis shows that ribgrass mosaic virus Shanghai isolate (RMV-Sh) is closely related to youcai mosaic virus. Archives of Virology, 2001, 146(6): 1231-1238. doi: 10.1007/s007050170118
[13]	KWON S J, KIM Y B, BACK C K, CHUNG B N. First report of a mixed infection of youcai mosaic virus and rehmannia mosaic virus in Rehmannia glutinosa in Korea. Plant Disease, 2018, 102(2): 462.
[14]	KREUZE J F, PEREZ A, UNTIVEROS M, QUISPE D, FUENTES S, BARKER I, SIMON R. Complete viral genome sequence and discovery of novel viruses by deep sequencing of small RNAs: A generic method for diagnosis, discovery and sequencing of viruses. Virology, 2009, 388(1): 1-7. doi: 10.1016/j.virol.2009.03.024
[15]	ZHENG Y, GAO S, PADMANABHAN C, LI R, GALVEZ M, GUTIERREZ D, FUENTES S, LING K S, KREUZE J, FEI Z. VirusDetect: An automated pipeline for efficient virus discovery using deep sequencing of small RNAs. Virology, 2017, 500: 130-138. doi: 10.1016/j.virol.2016.10.017
[16]	姚敏, 张天奇, 田志超, 王源超, 陶小荣. 农杆菌介导的CMV侵染性克隆及2b缺失突变体构建. 中国农业科学, 2011, 44(14): 3060-3068.
	YAO M, ZHANG T Q, TIAN Z C, WANG Y C, TAO X R. Construction of Agrobacterium-mediated cucumber mosaic virus infectious cDNA clones and 2b deletion viral vector. Scientia Agricultura Sinica, 2011, 44(14): 3060-3068. (in Chinese)
[17]	KUMAR S, STECHER G, TAMURA K. MEGA7: Molecular evolutionary genetics analysis version 7.0 for bigger datasets. Molecular Biology and Evolution, 2016, 33(7): 1870-1874. doi: 10.1093/molbev/msw054
[18]	李正刚, 农媛, 汤亚飞, 佘小漫, 于琳, 蓝国兵, 邓铭光, 何自福. 侵染广东连州葫芦的黄瓜绿斑驳花叶病毒的分子特征及致病性分析. 中国农业科学, 2020, 53(5): 955-964.
	LI Z G, NONG Y, TANG Y F, SHE X M, YU L, LAN G B, DENG M G, HE Z F. Molecular characteristic and pathogenicity analyses of cucumber green mottle mosaic virus (CGMMV) infecting bottle gourd in Lianzhou, Guangdong. Scientia Agricultura Sinica, 2020, 53(5): 955-964. (in Chinese)
[19]	甘彩霞, 张兴中, 崔磊, 於校青, 王飞, 戴照义, 严承欢, 邓晓辉, 姚明华, 邱正明, 焦春海. 萝卜病毒病小RNA分析及资源抗性表现. 中国蔬菜, 2020(12): 28-34.
	GAN C X, ZHANG X Z, CUI L, YU X Q, WANG F, DAI Z Y, YAN C H, DENG X H, YAO M H, QIU Z M, JIAO C H. Small RNA analysis and resource resistance expression of radish virus disease. China Vegetables, 2020(12): 28-34. (in Chinese)
[20]	MANSOOR S, MUKHTAR S, HUSSAIN M, AMIN I, ZAFAR Y, MALIK K A, MARKHAM P G. Widespread occurrence of cotton leaf curl virus on radish in Pakistan. Plant Disease, 2000, 84(7): 809.
[21]	ISMAIL H, HASSAN I, ZUBAIR M, KHAN M Z, SERFRAZ S, JAMIL N, MANSOOR S, ASAD S, AMIN I. First report of pedilanthus leaf curl virus, tobacco leaf curl betasatellite, and guar leaf curl alphasatellite infecting radish (Raphanus sativus) in Pakistan. Plant Disease, 2017, 101(5): 845.
[22]	SVANELLA-DUMAS L, THEIL S, BARRET M, CANDRESSE T. Complete genomic sequence of Raphanus sativus cryptic virus 4 (RsCV4), a novel alphapartitivirus from radish. Archives of Virology, 2018, 163(4): 1097-1100. doi: 10.1007/s00705-017-3693-6
[23]	BOITEUX L S, FONSECA M E N, REIS A, COSTA A F, FONTES M G, GONZÁLEZ-ARCOS M. Wild radish (Raphanus spp.) and garden rocket (Eruca sativa) as new brassicaceae hosts of tomato chlorosis virus in South America. Plant Disease, 2016, 100(5): 1027.
[24]	VAINIO E J, CHIBA S, GHABRIAL S A, MAISS E, ROOSSINCK M, SABANADZOVIC S, SUZUKI N, XIE J, NIBERT M, ICTV Report Consortium. ICTV virus taxonomy profile: Partitiviridae. Journal of General Virology, 2018, 99(1): 17-18. doi: 10.1099/jgv.0.000985
[25]	GHABRIAL S A, CASTON J R, COUTTS R H A, HILLMAN B I, JIANG D, KIM D H, MORIYAMA H, ICTV Report Consortium. ICTV virus taxonomy profile: Chrysoviridae. Journal of General Virology, 2018, 99(1): 19-20. doi: 10.1099/jgv.0.000994
[26]	LI L, LIU J, XU A, WANG T, CHEN J, ZHU X. Molecular characterization of a trisegmented chrysovirus isolated from the radish Raphanus sativus. Virus Research, 2013, 176(1/2): 169-178. doi: 10.1016/j.virusres.2013.06.004
[27]	RYU S Y, HONG J S, RHEE S J, LEE G P. Brief report: Genome sequence and construction of an infectious cDNA clone of ribgrass mosaic virus from Chinese cabbage in Korea. Virus Genes, 2012, 44(2): 345-348.
[28]	AGUILAR I, SANCHEZ F, MARTIN A M, MARTINEZ-HERRERA D, PONZ F. Nucleotide sequence of Chinese rape mosaic virus (oilseed rape mosaic virus), a crucifer tobamovirus infectious on Arabidopsis thaliana. Plant Molecular Biology, 1996, 30(1): 191-197. doi: 10.1007/BF00017814
[29]	蔡丽, 许泽永, 陈坤荣, 晏立英, 侯明生. 油菜花叶病毒Wh株系的鉴定. 植物保护学报, 2005, 32(4): 367-372.
	CAI L, XU Z Y, CHEN K R, YAN L Y, HOU M S. Identification and characterization of oilseed rape mosaic virus (ORMV) Wh strain. Acta Phytophylacica Sinica, 2005, 32(4): 367-372. (in Chinese)

引物名称 Primer name	引物序列 Primer sequence	对应位置 Localization (nt)	产物长度 Product length (bp)	退火温度 Annealing temperature (℃)
RsCV3-F	ACAGGATTCATCTCGGATCTT	140-160	1042	55
RsCV3-R	ACTAGTGAATCGTCTCCTAATGT	1182-1160	1042	55
RasCV1-F	AATGTGATTGTCACACATGAACTAG	498-522	1030	55
RasCV1-R	CTAATAGCCCCATCCTTCAGG	1528-1508	1030	55
YoMV-F	AATATCAGAGAGCGGCATTCTAT	550-572	1104	55
YoMV-R	CTGTCGGTAAAAGTGCAATATAACT	1654-1630	1104	55
TuMV-F	GTCGCCGTTCTGTTGGTCGTTTTGA	1509-1533	1371	55
TuMV-R	TGCCTGCGATAACTGCTTGTGTACG	2879-2855	1371	55
301-YoMV-F1	AAGTTCATTTCATTTGGAGAGGGTT TTATTTTTATTGCAACAACAACAA	1-27	3405	66
301-YoMV-R1	TGAACACTGTGTCGATCTGTAATT GCTATTGGGTCCCCGA	3405-3366	3405	66
301-YoMV-F2	AACAGCGACTCCCTTGGAGATCAT ATCAAGAGCGTCACCTCATG	3194-3237	3111	70
301-YoMV-R2	GGTGGAGATGCCATGCCGACCCTT GGGCCCCTACCCGGGGTTA	6304-6284	3111	70

基因登录号 GenBank number	长度 Length (bp)	覆盖度 Coverage (%)	拼接序列条数 Contig	测序深度 Depth	平均测序深度 Depth (Norm)	同源性 Identity (%)	最高同源性 Iden. Max (%)	最低同源性 Iden. Min (%)	科 Family	属 Genus	种 Species
FJ461349	1609	1544 (96.0)	1	82.0	6.8	99.42	99.42	99.42	Partitiviridae	maybe Alphapartitivirus	RsCV3 segment 1
FJ461350	1581	1404 (88.8)	12	19.9	1.7	99.50	100.00	95.56	Partitiviridae	maybe Alphapartitivirus	RsCV3 segment 2
JQ045335	3638	3411 (93.8)	12	28.7	2.4	98.83	100.00	97.62	Chrysoviridae	Alphachrysovirus	RasCV1 segment 1
JQ045336	3517	3419 (97.2)	6	21.5	1.8	98.86	99.38	97.73	Chrysoviridae	Alphachrysovirus	RasCV1 segment 2
JQ045337	3299	3218 (97.5)	9	31.6	2.6	99.25	100.00	97.91	Chrysoviridae	Alphachrysovirus	RasCV1 segment 3
EU734433	9833	9833 (100)	127	2343.0	194.7	95.33	100.00	89.17	Potyviridae	Potyvirus	TuMV isolate TANX2
AY318866	6304	6302 (100)	1	980.2	81.4	99.21	99.21	99.21	Virgaviridae	Tobamovirus	YoMV
