返青后补灌与氮肥用量对旱地小麦产量及水氮利用效率的影响

doi:10.3864/j.issn.0578-1752.2023.17.012

摘要/Abstract

摘要： 【目的】 基于高标准农田建设改善了旱地麦田灌溉条件，但小麦季通常仅能进行一次灌溉的生产实际，探索返青后补灌与氮肥互作对旱地小麦生产力、水氮利用以及土壤硝态氮残留的影响，为旱地小麦高产高效和环境友好生产提供理论依据和技术支撑。【方法】 于2019—2022年，在黄土高原与黄淮海平原交汇处的典型旱地小麦种植区，设置两因素裂区试验，灌溉水平为主处理，分别为全生育期不灌溉（I0）和返青后补灌（I1，小麦返青后0—40 cm土层首次出现土壤含水量低于田间持水量的60%时，补灌至田间持水量的85%，全生育期仅灌溉一次）。施氮量为副处理，分别为0（N0）、120（N120）、180（N180）和240 kg N·hm^-2（N240）。分析小麦产量及其构成因素、水分利用效率、氮素吸收利用特征以及0—200 cm土层硝态氮残留量。【结果】 与I0相比，I1优化了小麦产量构成要素，增加了氮素吸收能力，籽粒产量和水分利用效率3年平均分别显著提高55.8%和34.7%，0—200 cm土层硝态氮残留显著降低11.6%。随着施氮量增加，I0水平下小麦产量、穗数、穗粒数和水分利用效率均呈现先升高后下降的趋势，以N180处理最高；而I1水平下表现为先增加后保持稳定，N180和N240处理均保持较高水平。两种灌溉水平下，增加施氮量均显著降低了氮素利用效率、氮肥吸收效率和氮肥偏生产力，但N180处理下氮肥农学效率和氮肥表观利用率与N120相比无显著降低（2021—2022年度I1除外）。无论灌溉与否，增加施氮量均提高了成熟期麦田土壤硝态氮残留量，I0水平下各施氮处理硝态氮主要富集在0—60 cm土层，且N180和N240处理在0—200 cm土层出现逐年累积效应；而I1较I0显著降低了0—60 cm土层硝态氮残留量，0—200 cm土层仅在N240处理下出现硝态氮累积。从互作效应看，3年试验中，I1N180和I1N240组合均具有较高的籽粒产量和水分利用效率，但I1N180较I1N240降低了生育期耗水量和土壤硝态氮残留量，并提高了氮效率。【结论】 小麦返青后补灌配施氮肥180 kg N·hm^-2可以优化产量构成要素，提高植株氮素积累量及积累强度，不仅在提高小麦产量的同时获得最优氮效率，还能降低0—200 cm土层硝态氮残留量，是旱地小麦在灌溉条件改善后兼顾小麦高产高效和环境友好生产的水肥组合。

关键词: 返青后补灌, 氮肥用量, 旱地, 小麦, 产量, 水分利用效率, 硝态氮残留

Abstract:

【Objective】 The project of high standard farmland construction in China has improved the irrigation conditions in dryland, however, there is usually only once limited irrigation that could be carried out in wheat growing season. In this study, the effects of supplemental irrigation after regreening and nitrogen (N) fertilizer rates on productivity, water and N utilization in dryland wheat and nitrate residue in soil were investigated, so as to provide the theoretical basis and technical support for high-yield, high-efficiency and environment-friendly production in dryland wheat. 【Method】 The two-factor split-plot field experiment was conducted in the typical dryland of the intersection between Loess Plateau and Huang-Huai-Hai Plain from 2019 to 2022, where the irrigation conditions of no-irrigation during whole growth period (I0) and supplemental irrigation after regreening (I1, supplemental irrigation to 85% of field capacity when the soil water content in the 0-40 cm soil layer after wheat regreening was lower than 60% of field capacity at the first time) were assigned to the main plots, and the nitrogen application rates of 0 (N0), 120 kg N·hm^-2(N120), 180 kg N·hm^-2(N180) and 240 kg N·hm^-2(N240) were assigned to the subplots. The grain yield and yield components, water use efficiency, N absorption and utilization in wheat were tested, as well as the nitrate residue in the 0-200 cm soil layer in dryland. 【Result】 Compared with I0, I1 could optimize wheat yield components and increase N absorption capacity, for the 3-year average grain yield and water use efficiency significantly increased by 55.8% and 34.7%, respectively, however, it decreased soil nitrate residue by 11.6% in the 0-200 cm soil layer. With the increase of N application rate, the grain yield, spike number, kernels per spike and water use efficiency initially increased and then decreased, and reached the maximum under the N180 treatment with I0 level, but there were initially increased and then remained stable, and reached the higher level both in the N180 and N240 treatments under I1 level. With the increase of N application rate, the N use efficiency, N uptake efficiency and N partial factor productivity were significantly decreased under the both two irrigation conditions, but the N agronomy efficiency and N apparent efficiency under N180 treatment was not significantly decreased compared with N120 treatment (except I1 level in 2021-2022). Regardless of irrigation, with the increase of N application rate, the soil nitrate residue at harvest were significantly increased. Soil nitrate accumulated largely in the 0-60 cm soil layer under each N application rates with I0 level, and the obvious accumulated effects of soil nitrate residue in the 0-200 cm soil layer were found under N180 and N240 treatments; meanwhile, the soil nitrate residue under I1 level in the 0-60 cm soil layer was significantly lower than that under I0, and there were only accumulated effects of soil nitrate residue was found in the 0-200 cm soil layer under N240 treatment. In general, both the I1N180 and I1N240 could obtain the higher grain yield and water use efficiency. I1N180 treatment reduced water consumption during growth period and soil nitrate residue in the 0-200 cm soil layer, and improved the N efficiency, compared with I1N240 treatment. 【Conclusion】 Supplemental irrigation after regreening combined with 180 kg N·hm^-2N fertilizer could optimize the yield components, shoot N accumulation and N accumulative rate, thus it could not only improve the grain yield and N absorption and utilization efficiency in wheat, but also reduce the soil nitrate residue in 0-200 cm soil layer. Therefore, I1N180 treatment was an optimal model for realizing the collaborative target of high-yield, high-efficiency and environment-friendly in dryland wheat production system.

Key words: supplemental irrigation after regreening, N fertilizer application rate, dryland, wheat, yield, water use efficiency, nitrate residue

赵凯男, 吴金芝, 黄明, 李友军, 汪洪涛, 黄修利, 吴姗薇, 张军, 赵志明, 赵雯馨, 李淑靖, 李爽, 李文娜. 返青后补灌与氮肥用量对旱地小麦产量及水氮利用效率的影响[J]. 中国农业科学, 2023, 56(17): 3383-3398.

ZHAO KaiNan, WU JinZhi, HUANG Ming, LI YouJun, WANG HongTao, HUANG XiuLi, WU ShanWei, ZHANG Jun, ZHAO ZhiMing, ZHAO WenXin, LI ShuJing, LI Shuang, LI WenNa. Effects of Supplemental Irrigation After Regreening and Nitrogen Fertilizer Application Rates on Wheat Yield, Water and Nitrogen Use Efficiency in Dryland[J]. Scientia Agricultura Sinica, 2023, 56(17): 3383-3398.

图/表 9

图1

图2

表1

表2

表3

图3

图4

表4

不同处理对小麦氮素吸收和利用的影响"

年度 Year	处理 Treatment	氮素利用效率 N use efficiency (kg·kg^-1)	氮肥吸收效率 N uptake efficiency (kg·kg^-1)	氮肥农学效率 N agronomy efficiency (kg·kg^-1)	氮肥偏生产力 N partial factor productivity (kg·kg^-1)	氮肥表观利用率 N apparent efficiency (%)
2019‒2020	I0N0	28.8±0.7d	—	—	—	—
	I0N120	28.1±0.4d	1.10±0.01c	4.46±0.35abc	30.8±0.7c	18.0±1.1c
	I0N180	27.5±0.4de	0.85±0.01e	5.92±0.66a	23.5±0.4d	24.3±0.8b
	I0N240	26.2±0.6e	0.63±0.01f	3.29±0.30c	16.5±0.2e	17.1±1.6c
	I1N0	37.0±0.5a	—	—	—	—
	I1N120	35.5±0.3b	1.52±0.02a	4.02±0.58bc	54.1±0.7a	17.0±2.8c
	I1N180	31.4±0.4c	1.22±0.02b	5.01±0.48ab	38.4±0.5b	31.9±0.7a
	I1N240	31.2±0.1c	0.93±0.01d	4.14±0.25bc	29.2±0.2c	25.8±1.7b
2020‒2021	I0N0	37.6±1.0b	—	—	—	—
	I0N120	33.8±0.9c	1.09±0.02c	8.01±0.12ab	36.9±0.5c	32.4±4.5b
	I0N180	31.4±1.2d	0.86±0.02e	7.58±0.31ab	26.8±0.4e	34.4±2.5b
	I0N240	30.3±1.0d	0.63±0.01f	4.56±0.27c	19.0±0.2f	24.3±1.9c
	I1N0	47.4±0.2a	—	—	—	—
	I1N120	37.6±0.3b	1.67±0.02a	8.02±0.48ab	62.9±0.4a	51.7±1.5a
	I1N180	35.5±0.4bc	1.27±0.01b	8.36±0.91a	44.9±0.3b	49.4±1.7a
	I1N240	33.6±0.5c	1.03±0.01d	7.00±0.58b	34.4±0.2d	44.7±1.1a
2021‒2022	I0N0	48.3±1.6a	—	—	—	—
	I0N120	37.1±0.7bc	1.18±0.02c	3.98±1.96d	43.6±1.1b	35.5±3.2cd
	I0N180	36.1±0.3bcd	0.95±0.01e	7.85±0.81c	34.3±0.3d	40.1±1.3c
	I0N240	34.1±0.2cde	0.72±0.01f	4.83±0.38d	24.7±0.2f	31.2±1.4d
	I1N0	49.6±2.2a	—	—	—	—
	I1N120	37.9±0.4b	1.59±0.01a	14.65±1.42a	60.3±0.5a	66.7±2.2a
	I1N180	33.2±0.3de	1.26±0.02b	11.42±0.70b	41.9±0.4c	64.5±3.0a
	I1N240	31.6±0.3e	1.01±0.01d	9.06±0.29bc	31.9±0.3e	54.9±1.2b
变异来源 Source of variance (F-value)	年度 Year (Y)	198.8**	40.9**	49.2**	391.7**	231.8**
	灌溉 Irrigation (I)	116.8**	3337.4**	45.6**	4970.2**	265.8**
	氮肥N rate (N)	197.8**	2099.2**	14.7**	3316.0**	19.6**
	灌溉×氮肥 I×N	11.3**	42.4**	3.6*	197.4**	0.29

表4

图5

参考文献 44

[1]	雒文鹤, 师祖姣, 王旭敏, 李军, 王瑞. 节水减氮对土壤硝态氮分布和冬小麦水氮利用效率的影响. 作物学报, 2020, 46(6): 924-936. doi: 10.3724/SP.J.1006.2020.91060
	LUO W H, SHI Z J, WANG X M, LI J, WANG R. Effects of water saving and nitrogen reduction on soil nitrate nitrogen distribution, water and nitrogen use efficiencies of winter wheat. Acta Agronomica Sinica, 2020, 46(6): 924-936. (in Chinese) doi: 10.3724/SP.J.1006.2020.91060
[2]	张嫚, 周苏玫, 杨习文, 周燕, 杨蕊, 张珂珂, 贺德先, 尹钧. 减氮适墒对冬小麦土壤硝态氮分布和氮素吸收利用的影响. 中国农业科学, 2017, 50(20): 3885-3897. doi: 10.3864/j.issn.0578-1752.2017.20.005. doi: 10.3864/j.issn.0578-1752.2017.20.005
	ZHANG M, ZHOU S M, YANG X W, ZHOU Y, YANG R, ZHANG K K, HE D X, YIN J. Effects of nitrogen-reducing and suitable soil moisture on nitrate nitrogen distribution in soil, nitrogen absorption and utilization of winter wheat. Scientia Agricultura Sinica, 2017, 50(20): 3885-3897. doi: 10.3864/j.issn.0578-1752.2017.20.005. (in Chinese) doi: 10.3864/j.issn.0578-1752.2017.20.005
[3]	赵财, 王巧梅, 郭瑶, 殷文, 樊志龙, 胡发龙, 于爱忠, 柴强. 水氮耦合对地膜玉米免耕轮作小麦干物质积累及产量的影响. 作物学报, 2018, 44(11): 1694-1703. doi: 10.3724/SP.J.1006.2018.01694
	ZHAO C, WANG Q M, GUO Y, YIN W, FAN Z L, HU F L, YU A Z, CHAI Q. Effects of water-nitrogen coupling patterns on dry matter accumulation and yield of wheat under no-tillage with previous plastic mulched maize. Acta Agronomica Sinica, 2018, 44(11): 1694-1703. (in Chinese) doi: 10.3724/SP.J.1006.2018.01694
[4]	杨传邦, 于振文, 张永丽, 石玉. 测墒补灌深度对济麦22冠层光截获和荧光特性及籽粒产量的影响. 作物学报, 2017, 43(2): 253-262.
	YANG C B, YU Z W, ZHANG Y L, SHI Y. Effect of soil depth with supplemental irrigation on canopy photosynthetically active radiation interception and chlorophyll fluorescence parameters in Jimai 22. Acta Agronomica Sinica, 2017, 43(2): 253-262. (in Chinese) doi: 10.3724/SP.J.1006.2017.00253
[5]	李萍, 尚云秋, 林祥, 刘帅康, 王森, 胡鑫慧, 王东. 拔节期阶段性干旱对小麦茎蘖成穗与结实的影响. 中国农业科学, 2020, 53(20): 4137-4151. doi: 10.3864/j.issn.0578-1752.2020.20.004. doi: 10.3864/j.issn.0578-1752.2020.20.004
	LI P, SHANG Y Q, LIN X, LIU S K, WANG S, HU X H, WANG D. Effects of drought stress during jointing stage on spike formation and seed setting of main stem and tillers of winter wheat. Scientia Agricultura Sinica, 2020, 53(20): 4137-4151. doi: 10.3864/j.issn.0578-1752.2020.20.004. (in Chinese) doi: 10.3864/j.issn.0578-1752.2020.20.004
[6]	巨晓棠, 谷保静. 氮素管理的指标. 土壤学报, 2017, 54(2): 281-296.
	JU X T, GU B J. Indexes of nitrogen management. Acta Pedologica Sinica, 2017, 54(2): 281-296. (in Chinese)
[7]	同延安, Ove Emteryd, 张树兰, 梁东丽. 陕西省氮肥过量施用现状评价. 中国农业科学, 2004, 37(8): 1239-1244. doi: 10.3864/j.issn.0578-1752.040828. doi: 10.3864/j.issn.0578-1752.040828
	TONG Y N, EMTERYD O, ZHANG S L, LIANG D L. Evalution of over-application of nitrogen fertilizer in China’s Shaanxi Province. Scientia Agricultura Sinica, 2004, 37(8): 1239-1244. doi: 10.3864/j.issn.0578-1752.040828. (in Chinese) doi: 10.3864/j.issn.0578-1752.040828
[8]	张艳, 张洋, 陈冲, 李东, 翟丙年. 水分胁迫条件下施氮对不同水氮效率基因型冬小麦苗期生长发育的影响. 麦类作物学报, 2009, 29(5): 844-848.
	ZHANG Y, ZHANG Y, CHEN C, LI D, ZHAI B N. Effect of water stress and nitrogen application on growth and development of winter wheat genotypes with different water and nitrogen use efficiency at seedling stage. Journal of Triticeae Crops, 2009, 29(5): 844-848. (in Chinese)
[9]	张馨月, 王寅, 陈健, 陈安吉, 王莉颖, 郭晓颖, 牛雅郦, 张星宇, 陈利东, 高强. 水分和氮素对玉米苗期生长、根系形态及分布的影响. 中国农业科学, 2019, 52(1): 34-44. doi: 10.3864/j.issn.0578-1752.2019.01.004. doi: 10.3864/j.issn.0578-1752.2019.01.004
	ZHANG X Y, WANG Y, CHEN J, CHEN A J, WANG L Y, GUO X Y, NIU Y L, ZHANG X Y, CHEN L D, GAO Q. Effects of soil water and nitrogen on plant growth, root morphology and spatial distribution of maize at the seedling stage. Scientia Agricultura Sinica, 2019, 52(1): 34-44. doi: 10.3864/j.issn.0578-1752.2019.01.004. (in Chinese) doi: 10.3864/j.issn.0578-1752.2019.01.004
[10]	CLAY D E, ENGEL R E, LONG D S, LIU Z. Nitrogen and water stress interact to influence carbon-13 discrimination in wheat. Soil Science Society of America Journal, 2001, 65(6): 1823-1828. doi: 10.2136/sssaj2001.1823
[11]	张经廷, 吕丽华, 董志强, 张丽华, 姚艳荣, 申海平, 姚海坡, 贾秀领. 华北冬小麦开花期补灌的增产效应及其影响因素. 作物学报, 2019, 45(11): 1746-1755. doi: 10.3724/SP.J.1006.2019.81060
	ZHANG J T, LÜ L H, DONG Z Q, ZHANG L H, YAO Y R, SHEN H P, YAO H P, JIA X L. Yield-increasing effect of supplementary irrigation at winter wheat flowering and its influencing factors based on water and nitrogen coupling in North China. Acta Agronomica Sinica, 2019, 45(11): 1746-1755. (in Chinese)
[12]	马兴华, 王东, 于振文, 王西芝, 许振柱. 不同施氮量下灌水量对小麦耗水特性和氮素分配的影响. 生态学报, 2010, 30(8): 1955-1965.
	MA X H, WANG D, YU Z W, WANG X Z, XU Z Z. Effect of irrigation regimes on water consumption characteristics and nitrogen distribution in wheat at different nitrogen applications. Acta Ecologica Sinica, 2010, 30(8): 1955-1965. (in Chinese)
[13]	马耕, 张盼盼, 王晨阳, 刘卫星, 张美微, 马冬云, 谢迎新, 朱云集, 郭天财. 高产小麦花后植株氮素累积、转运和产量的水氮调控效应. 麦类作物学报, 2015, 35(6): 798-805.
	MA G, ZHANG P P, WANG C Y, LIU W X, ZHANG M W, MA D Y, XIE Y X, ZHU Y J, GUO T C. Regulation effect of irrigation and nitrogen on post-anthesis nitrogen accumulation, translocation and grain yield of high-yield wheat. Journal of Triticeae Crops, 2015, 35(6): 798-805. (in Chinese)
[14]	满建国, 于振文, 石玉, 张永丽. 不同土层测墒补灌对冬小麦耗水特性与光合速率和产量的影响. 应用生态学报, 2015, 26(8): 2353-2361.
	MAN J G, YU Z W, SHI Y, ZHANG Y L. Effects of supplemental irrigation by measuring moisture content in different soil layers on water consumption characteristics, photosynthesis and grain yield of winter wheat. Chinese Journal of Applied Ecology, 2015, 26(8): 2353-2361. (in Chinese)
[15]	LI H Y, ZHANG Y H, ZHANG Q, AHMAD N, LIU P Z, WANG R, LI J, WANG X L. Converting continuous cropping to rotation including subsoiling improves crop yield and prevents soil water deficit: A 12-yr in situ study in the Loess Plateau, China. Agricultural Water Management, 2021, 256: 107062. doi: 10.1016/j.agwat.2021.107062
[16]	李强, 王朝辉, 李富翠, 戴健, 李孟华, 何刚, 曹群虎, 段长林, 鱼昌为. 氮肥管理与地膜覆盖对旱地冬小麦产量和氮素利用效率的影响. 作物学报, 2014, 40(1): 93-100.
	LI Q, WANG Z H, LI F C, DAI J, LI M H, HE G, CAO Q H, DUAN C L, YU C W. Effects of nitrogen fertilizer management on yield and nitrogen use efficiency in winter wheat growing on dryland with plastic film mulching. Acta Agronomica Sinica, 2014, 40(1): 93-100. (in Chinese) doi: 10.3724/SP.J.1006.2014.00093
[17]	黄明, 吴金芝, 李友军, 付国占, 赵凯男, 张振旺, 杨中帅, 侯园泉. 耕作方式和氮肥用量对旱地小麦产量、蛋白质含量和土壤硝态氮残留的影响. 中国农业科学, 2021, 54(24): 5206-5219. doi: 10.3864/j.issn.0578-1752.2021.24.004. doi: 10.3864/j.issn.0578-1752.2021.24.004
	HUANG M, WU J Z, LI Y J, FU G Z, ZHAO K N, ZHANG Z W, YANG Z S, HOU Y Q. Effects of tillage practices and nitrogen fertilizer application rates on grain yield, protein content in winter wheat and soil nitrate residue in dryland. Scientia Agricultura Sinica, 2021, 54(24): 5206-5219. doi: 10.3864/j.issn.0578-1752.2021.24.004. (in Chinese) doi: 10.3864/j.issn.0578-1752.2021.24.004
[18]	DAI J, WANG Z H, LI F C, HE G, WANG S, LI Q, CAO H B, LUO L C, ZAN Y L, MENG X Y, ZHANG W W, WANG R H, MALHI S S. Optimizing nitrogen input by balancing winter wheat yield and residual nitrate-N in soil in a long-term dryland field experiment in the Loess Plateau of China. Field Crops Research, 2015, 181: 32-41. doi: 10.1016/j.fcr.2015.06.014
[19]	史桂清, 白倩倩, 郭程瑾, 肖凯. 节水条件下供氮水平对冬小麦氮素吸收利用特性的影响. 麦类作物学报, 2018, 38(5): 608-614.
	SHI G Q, BAI Q Q, GUO C J, XIAO K. Effect of nitrogen application level on acquisition and utilization of N under the water-saving cultivation conditions in winter wheat. Journal of Triticeae Crops, 2018, 38(5): 608-614. (in Chinese)
[20]	杨慧敏, 王涛, 窦瑛霞, 赵护兵, 毛安然, 王朝辉. 不同降水年型地膜覆盖及秸秆覆盖提高小麦产量和氮素利用的效应. 植物营养与肥料学报, 2021, 27(11): 1905-1914.
	YANG H M, WANG T, DOU Y X, ZHAO H B, MAO A R, WANG Z H. Effects of plastic film mulching and straw mulching on wheat yield and nitrogen utilization during different precipitation years. Journal of Plant Nutrition and Fertilizers, 2021, 27(11): 1905-1914. (in Chinese)
[21]	张丽霞, 杨永辉, 尹钧, 武继承, 潘晓莹. 水肥一体化对小麦干物质和氮素积累转运及产量的影响. 农业机械学报, 2021, 52(2): 275-282, 319.
	ZHANG L X, YANG Y H, YIN J, WU J C, PAN X Y. Effects of drip fertigation on accumulation and translocation of dry matter and nitrogen together with yield in wheat. Transactions of the Chinese Society for Agricultural Machinery, 2021, 52(2): 275-282, 319. (in Chinese)
[22]	栗丽, 洪坚平, 王宏庭, 谢英荷. 水氮互作对冬小麦氮素吸收分配及土壤硝态氮积累的影响. 水土保持学报, 2013, 27(3): 138-142, 149.
	LI L, HONG J P, WANG H T, XIE Y H. Effects of nitrogen and irrigation interaction on nitrogen uptake and distribution in winter wheat and nitrate accumulation in soil. Journal of Soil and Water Conservation, 2013, 27(3): 138-142, 149. (in Chinese)
[23]	褚鹏飞, 王东, 张永丽, 王小燕, 王西芝, 于振文. 灌水时期和灌水量对小麦耗水特性、籽粒产量及蛋白质组分含量的影响. 中国农业科学, 2009, 42(4): 1306-1315. doi: 10.3864/j.issn.0578-1752.2009.04.022. doi: 10.3864/j.issn.0578-1752.2009.04.022
	CHU P F, WANG D, ZHANG Y L, WANG X Y, WANG X Z, YU Z W. Effects of irrigation stage and amount on water consumption characteristics, grain yield and content of protein components of wheat. Scientia Agricultura Sinica, 2009, 42(4): 1306-1315. doi: 10.3864/j.issn.0578-1752.2009.04.022. (in Chinese) doi: 10.3864/j.issn.0578-1752.2009.04.022
[24]	张经廷, 吕丽华, 张丽华, 董志强, 姚艳荣, 姚海坡, 申海平, 贾秀领. 作物水肥耦合类型量化方法在华北冬小麦水氮配置中的应用. 中国农业科学, 2019, 52(17): 2997-3007. doi: 10.3864/j.issn.0578-1752.2019.17.008. doi: 10.3864/j.issn.0578-1752.2019.17.008
	ZHANG J T, LÜ L H, ZHANG L H, DONG Z Q, YAO Y R, YAO H P, SHEN H P, JIA X L. A novel method for quantitating water and fertilizer coupling types and its application in optimizing water and nitrogen combination in winter wheat in the North China plain. Scientia Agricultura Sinica, 2019, 52(17): 2997-3007. doi: 10.3864/j.issn.0578-1752.2019.17.008. (in Chinese) doi: 10.3864/j.issn.0578-1752.2019.17.008
[25]	张振旺, 吴金芝, 黄明, 李友军, 赵凯男, 侯园泉, 赵志明, 杨中帅. 干旱胁迫对不同抗旱性冬小麦灌浆期下午旗叶光合特性和籽粒产量的影响. 华北农学报, 2022, 37(2): 67-77. doi: 10.7668/hbnxb.20192526
	ZHANG Z W, WU J Z, HUANG M, LI Y J, ZHAO K N, HOU Y Q, ZHAO Z M, YANG Z S. Effects of drought stress on the photosynthetic characteristics in flag leaf in the afternoon during the grain filling stage and grain yield of winter wheat with different drought resistance. Acta Agriculturae Boreali-Sinica, 2022, 37(2): 67-77. (in Chinese) doi: 10.7668/hbnxb.20192526
[26]	孙乾, 顾晓鹤, 孙林, 王淼, 周龙飞, 杨贵军, 李卫国, 束美艳. 不同灌溉条件下冬小麦冠层含水量的光谱响应. 中国农业科学, 2019, 52(14): 2425-2435. doi: 10.3864/j.issn.0578-1752.2019.14.004. doi: 10.3864/j.issn.0578-1752.2019.14.004
	SUN Q, GU X H, SUN L, WANG M, ZHOU L F, YANG G J, LI W G, SHU M Y. Spectral response analysis of canopy water content of winter wheat under different irrigation conditions. Scientia Agricultura Sinica, 2019, 52(14): 2425-2435. doi: 10.3864/j.issn.0578-1752.2019.14.004. (in Chinese) doi: 10.3864/j.issn.0578-1752.2019.14.004
[27]	王秀波, 上官周平. 干旱胁迫下氮素对不同基因型小麦根系活力和生长的调控. 麦类作物学报, 2017, 37(6): 820-827.
	WANG X B, SHANGGUAN Z P. Effect of nitrogen on root vigor and growth in different genotypes of wheat under drought stress. Journal of Triticeae Crops, 2017, 37(6): 820-827. (in Chinese)
[28]	张艳艳, 张永丽, 石玉, 于振文. 测墒补灌深度对小麦旗叶光合作用和产量的影响. 麦类作物学报, 2014, 34(9): 1233-1238.
	ZHANG Y Y, ZHANG Y L, SHI Y, YU Z W. Effects of supplemental irrigation based on measurement of soil moisture content on the photosynthesis and grain yield of winter wheat. Journal of Triticeae Crops, 2014, 34(9): 1233-1238. (in Chinese)
[29]	范雪梅, 戴廷波, 姜东, 荆奇, 曹卫星. 花后干旱与渍水下氮素供应对小麦碳氮运转的影响. 水土保持学报, 2004, 18(6): 63-67.
	FAN X M, DAI T B, JIANG D, JING Q, CAO W X. Effects of nitrogen rates on carbon and nitrogen assimilate translocation in wheat grown under drought and waterlogging from anthesis to maturity. Journal of Soil Water Conservation, 2004, 18(6): 63-67. (in Chinese)
[30]	韩占江, 于振文, 王东, 张永丽, 许振柱. 测墒补灌对冬小麦氮素积累与转运及籽粒产量的影响. 生态学报, 2011, 31(6): 1631-1640.
	HAN Z J, YU Z W, WANG D, ZHANG Y L, XU Z Z. Effects of supplemental irrigation based on measured soil moisture on nitrogen accumulation, distribution and grain yield in winter wheat. Acta Ecologica Sinica, 2011, 31(6): 1631-1640. (in Chinese)
[31]	张江伟, 李慧, 柴晓甜, 赵帅, 李莉威, 张斯佳, 贾丽娟, 张建恒, 王贵彦. 玉米深松分层施肥和小麦限水灌溉对土壤微生物量碳、氮及酶活性的影响. 水土保持学报, 2022, 36(6): 346-355.
	ZHANG J W, LI H, CHAI X T, ZHAO S, LI L W, ZHANG S J, JIA L J, ZHANG J H, WANG G Y. Effects of fertilization with subsoiling of maize and limited irrigation of wheat on soil microbial biomass carbon, nitrogen and enzymes activities. Journal of Soil and Water Conservation, 2022, 36(6): 346-355. (in Chinese)
[32]	曹翠玲, 李生秀. 水分胁迫和氮素有限亏缺对小麦拔节期某些生理特性的影响. 土壤通报, 2003, 34(6): 505-509.
	CAO C L, LI S X. Effect of water stress and nitrogen deficiency on some physiological characteristics and wheat yield at the jointing stage. Chinese Journal of Soil Science, 2003, 34(6): 505-509. (in Chinese)
[33]	孙婷, 张迪, 王冀川, 张建芳, 石元强, 比拉力·艾力, 朱娟. 滴灌水氮运筹对南疆春小麦根系生长及产量的影响. 干旱地区农业研究, 2020, 38(2): 10-20.
	SUN T, ZHANG D, WANG J C, ZHANG J F, SHI Y Q, BILALI AILI, ZHU J. Effects of drip irrigation and nitrogen application on root growth and yield of spring wheat in Southern Xinjiang. Agricultural Research in the Arid Areas, 2020, 38(2): 10-20. (in Chinese)
[34]	陈娟, 马忠明, 吕晓东, 刘婷婷. 水氮互作对固定道垄作栽培春小麦根系生长及产量的影响. 应用生态学报, 2016, 27(5): 1511-1520. doi: 10.13287/j.1001-9332.201605.033
	CHEN J, MA Z M, LÜ X D, LIU T T. Influence of different levels of irrigation and nitrogen application on the root growth and yield of spring wheat under permanent raised bed. Chinese Journal of Applied Ecology, 2016, 27(5): 1511-1520. (in Chinese)
[35]	王朝辉, 王兵, 李生秀. 缺水与补水对小麦氮素吸收及土壤残留氮的影响. 应用生态学报, 2004, 15(8): 1339-1343.
	WANG Z H, WANG B, LI S X. Influence of water deficit and supplemental irrigation on nitrogen uptake by winter wheat and nitrogen residual in soil. Chinese Journal of Applied Ecology, 2004, 15(8): 1339-1343. (in Chinese)
[36]	张雨新, 张富仓, 邹海洋, 陈东峰, 范军亮. 生育期水分调控对甘肃河西地区滴灌春小麦氮素吸收和利用的影响. 植物营养与肥料学报, 2017, 23(3): 597-605.
	ZHANG Y X, ZHANG F C, ZOU H Y, CHEN D F, FAN J L. Effects of soil water regulation at different growing stages on nitrogen uptake and utilization of spring wheat in the Hexi Region, Gansu Province. Journal of Plant Nutrition and Fertilizer, 2017, 23(3): 597-605. (in Chinese)
[37]	郭曾辉, 刘朋召, 雒文鹤, 王瑞, 李军. 限水减氮对关中平原冬小麦氮素利用和氮素表观平衡的影响. 应用生态学报, 2021, 32(12): 4359-4369. doi: 10.13287/j.1001-9332.202112.022
	GUO Z H, LIU P Z, LUO W H, WANG R, LI J. Effects of water limiting and nitrogen reduction on nitrogen use and apparent balance of winter wheat in the Guanzhong Plain, Northwest China. Chinese Journal of Applied Ecology, 2021, 32(12): 4359-4369. (in Chinese)
[38]	LIU W X, WANG J R, WANG C Y, MA G, WEI Q R, LU H F, XIE Y X, MA D Y, KANG G Z. Root growth, water and nitrogen use efficiencies in winter wheat under different irrigation and nitrogen regimes in North China plain. Frontiers in Plant Science, 2018, 9: 1798. doi: 10.3389/fpls.2018.01798 pmid: 30568670
[39]	CHUAN L M, HE P, ZHAO T K, ZHENG H G, XU X P. Agronomic characteristics related to grain yield and nutrient use efficiency for wheat production in China. PLoS ONE, 2016, 11(9): e0162802. doi: 10.1371/journal.pone.0162802
[40]	任科宇, 段英华, 徐明岗, 张旭博. 施用有机肥对我国作物氮肥利用率影响的整合分析. 中国农业科学, 2019, 52(17): 2983-2996. doi: 10.3864/j.issn.0578-1752.2019.17.007. doi: 10.3864/j.issn.0578-1752.2019.17.007
	REN K Y, DUAN Y H, XU M G, ZHANG X B. Effect of manure application on nitrogen use efficiency of crops in China: A meta-analysis. Scientia Agricultura Sinica, 2019, 52(17): 2983-2996. doi: 10.3864/j.issn.0578-1752.2019.17.007. (in Chinese) doi: 10.3864/j.issn.0578-1752.2019.17.007
[41]	WANG C Y, LIU W X, LI Q X, MA D Y, LU H F, FENG W, XIE Y X, ZHU Y J, GUO T C. Effects of different irrigation and nitrogen regimes on root growth and its correlation with above-ground plant parts in high-yielding wheat under field conditions. Field Crops Research, 2014, 165: 138-149. doi: 10.1016/j.fcr.2014.04.011
[42]	张丽娟, 巨晓棠, 张福锁, 彭正萍. 土壤剖面不同层次标记硝态氮的运移及其后效. 中国农业科学, 2007, 40(9): 1964-1972.
	ZHANG L J, JU X T, ZHANG F S, PENG Z P. Movement and residual effect of labeled nitrate-N in different soil layers. Scientia Agricultura Sinica, 2007, 40(9): 1964-1972. (in Chinese)
[43]	王雪, 谷淑波, 林祥, 王威雁, 张保军, 朱俊科, 王东. 微喷补灌水肥一体化对冬小麦产量及水分和氮素利用效率的影响. 作物学报, 2023, 49(3): 784-794. doi: 10.3724/SP.J.1006.2023.21009
	WANG X, GU S B, LIN X, WANG W Y, ZHANG B J, ZHU J K, WANG D. Effects of supplemental irrigation with micro-sprinkling hoses and water and fertilizer integration on yield and water and nitrogen use efficiency in winter wheat. Acta Agronomica Sinica, 2023, 49(3): 784-794. (in Chinese) doi: 10.3724/SP.J.1006.2023.21009
[44]	DONG Q, DANG T H, GUO S L, HAO M D. Effect of different mulching measures on nitrate nitrogen leaching in spring maize planting system in south of Loess Plateau. Agricultural Water Management, 2019, 213: 654-658. doi: 10.1016/j.agwat.2018.09.044

生长季 Growth season	补灌前土壤含水量 Soil water content before supplemental irrigation (%)	目标土壤含水量 Target soil water content (%)	灌水量 Irrigation amount (mm)
2019-2020	15.8	23.3	40.4
2020-2021	14.7	23.3	46.3
2021-2022	15.6	23.3	41.4

年度 Year	处理 Treatment	穗数 Spike number (×10⁴·hm^-2)	穗粒数 Kernels per spike	千粒重 1000-grain weight (g)	产量 Yield (kg·hm^-2)
2019‒2020	I0N0	371.1±9.3f	20.7±1.2d	42.6±1.5a	3159±72g
	I0N120	421.8±13.0e	22.6±1.4cd	42.4±2.6ab	3694±142f
	I0N180	441.8±3.8d	24.2±1.0c	41.1±0.8ab	4224±134d
	I0N240	443.8±5.1d	23.0±1.6cd	40.0±1.2bc	3949±65e
	I1N0	480.2±5.6c	22.5±0.3cd	38.5±0.8cd	6006±77c
	I1N120	537.3±7.0b	28.9±1.4b	36.9±2.5de	6488±152b
	I1N180	573.8±7.2a	29.5±1.7ab	36.4±0.7de	6907±161a
	I1N240	575.7±13.1a	31.3±2.1a	35.3±1.4e	6999±108a
2020‒2021	I0N0	344.2±24.3e	23.9±0.8f	50.0±0.6a	3468±86f
	I0N120	372.5±40.5de	27.9±0.9e	49.1±0.7ab	4430±111e
	I0N180	389.2±5.3d	31.2±1.1d	49.0±0.6ab	4833±141d
	I0N240	373.5±11.6de	30.7±0.1d	48.3±0.6b	4561±95e
	I1N0	461.2±7.9c	35.9±1.0c	46.9±1.1c	6581±178c
	I1N120	526.6±19.4b	38.1±0.1b	44.1±0.2d	7543±88b
	I1N180	576.6±14.5a	41.2±1.4a	40.8±1.3e	8087±108a
	I1N240	590.3±10.0a	41.6±1.0a	40.1±0.3e	8262±96a
2021‒2022	I0N0	386.9±42.6d	32.2±2.9e	44.0±2.5ab	4759±202e
	I0N120	477.7±46.0bc	33.8±1.0de	40.0±1.3c	5237±238d
	I0N180	491.1±55.1bc	41.7±1.2c	42.1±1.2bc	6172±100c
	I0N240	478.6±10.4bc	40.3±0.7c	41.7±2.8bc	5919±75c
	I1N0	446.1±33.0cd	35.2±2.2d	45.6±1.1a	5478±194d
	I1N120	536.1±39.0ab	46.6±0.9b	40.6±1.6c	7236±104b
	I1N180	583.6±13.8a	51.0±1.6a	41.0±0.4c	7533±140a
	I1N240	574.5±25.3a	52.6±1.4a	41.7±1.1bc	7653±102a
变异来源 Source of variance (F-value)	年度 Year (Y)	19.2**	932.7**	863.7**	431.7**
	灌溉 Irrigation (I)	468.5**	730.2**	702.0**	6722.6**
	氮肥N rate (N)	59.8**	150.6**	145.2**	426.1**
	灌溉×氮肥 I×N	4.7**	10.9**	11.3**	17.7**

处理 Treatment	耗水量 ET (mm)			水分利用效率 WUE (kg·hm^-2·mm^-1)
处理 Treatment	2019‒2020	2020‒2021	2021‒2022	2019‒2020	2020‒2021	2021‒2022
I0N0	337.5±7.9e	311.1±7.7c	313.6±13.2d	9.4±0.3f	11.2±0.4e	15.2±0.4d
I0N120	333.1±9.4e	319.5±5.4c	332.8±7.6cd	11.1±0.5d	13.9±0.4d	15.7±0.3cd
I0N180	362.3±5.2d	323.2±3.7c	336.7±6.1bc	11.7±0.3d	15.0±0.2d	18.3±0.2b
I0N240	385.0±14.0c	319.6±3.1c	359.3±4.3b	10.3±0.4e	14.3±0.2d	16.5±0.3c
I1N0	405.7±4.7b	357.9±6.4b	351.2±8.9bc	14.8±0.2c	18.4±0.6c	15.6±0.5cd
I1N120	406.1±6.4b	373.2±12.3ab	388.4±6.1a	16.0±0.4b	20.3±0.7b	18.6±0.2ab
I1N180	403.3±3.7b	380.2±9.4a	385.7±6.4a	17.1±0.1a	21.3±0.4ab	19.5±0.5a
I1N240	425.2±7.1a	382.0±4.8a	401.8±10.8a	16.5±0.4ab	21.6±0.4a	19.1±0.5ab
均值 Average	382.3±7.1A	345.8±6.3C	358.7±6.5B	13.4±0.6B	16.9±0.8A	17.3±0.4A
F值 F Value
年度 Year (Y)	47.0**			288.8**
灌溉 Irrigation (I)	281.6**			982.9**
氮肥N rate (N)	19.1**			75.8**
灌溉×氮肥I×N	0.86			2.9*
