葡萄转录因子VvERF2耐盐功能鉴定

doi:10.3864/j.issn.0578-1752.2024.02.009

摘要/Abstract

摘要：

【目的】对葡萄转录因子VvERF2进行蛋白质生物信息学分析，利用基因克隆、同源遗传转化技术，探索该转录因子在葡萄愈伤组织盐胁迫下的功能，为进一步研究AP2/ERF超家族对葡萄的作用机理提供参考。【方法】借助NCBI-Blast（https://blast.ncbi.nlm.nih.gov/Blast.cgi）等在线数据库工具对VvERF2蛋白进行生物信息学分析；以‘无核白’葡萄（Vitis. vinifera L.）愈伤组织为材料，构建葡萄VvERF2同源遗传转化体系，结合生长量、总糖、总酸等理化指标鉴定转基因愈伤组织表型；设定不同盐浓度梯度，通过游离脯氨酸、抗氧化酶活性等生理指标鉴定转基因愈伤组织耐盐功能。【结果】对VvERF2及一致性最高的7个直系同源蛋白序列进行生物信息学分析，发现VvERF2编码240个氨基酸，与番茄、无花果氨基酸序列高度相似，蛋白同源性分别为78%和67%。8种不同物种的氨基酸残基数为240—348个，分子量为26.43—38.60 kDa，理论等电点在5.54—8.68，脂肪氨基酸指数均大于66%，均属于不稳定性蛋白；不同物种氨基酸序列理化性质存在差异较大。此外，VvERF2启动子存在多种与脱落酸等激素及MYB等转录因子相关的顺式作用元件。VvERF2具有组织表达特异性，在愈伤组织中表达水平最低，且受外源盐胁迫诱导显著上调（为对照组的3倍）。转基因结果表明，VvERF2在葡萄愈伤组织中过量表达后，生长量、总酸、总酚含量及DPPH（1,1-二苯基-2-三硝基苯肼，1,1-Diphenyl-2- trinitrophenylhydrazine）等抗氧化活性均显著升高，不同浓度外源NaCl处理后，转基因愈伤组织总蛋白、游离脯氨酸等含量均高于野生型愈伤组织。【结论】 VvERF2过量表达促进葡萄愈伤组织生长量和次生代谢产物相关物如酚类物质的含量积累，从而提高葡萄耐盐性。

关键词: 葡萄, VvERF2, 盐胁迫, 功能鉴定

Abstract:

【Objective】 In order to give references for future study on the mechanism of the AP2/ERF superfamily on grapes, the protein bioinformatics analysis of grape transcription factor VvERF2 was performed. Additionally, the procedures of gene cloning and homologous genetic transformation were employed for exploring the function of VvERF2 under salt stress in grape callus. 【Method】 For the bioinformatics analysis of the VvERF2 protein, the NCBI Blast database (https://blast.ncbi.nlm.nih.gov/Blast.cgi) and additional online resources were utilized. The Thompson seedless (Vitis vinifera L.) callus was used as the material, and the grape homologous genetic transformation system of VvERF2 were constructed. The transgenic callus phenotype was determined by growth volume, total sugar, total acid, and other factors. Free proline, antioxidant enzyme activity, and other indices were used to assess the salt tolerance of transgenic callus. 【Result】 Based on the bioinformatical analysis of VvERF2 and the 7 most homologous orthologous protein sequences, the VvERF2 gene encoded 240 amino acids, which were quite similar to those of tomatoes and figs, with protein homology percentages of 78% and 67%, respectively. The amino acid residues in eight species varied from 240 to 348, their molecular weights from 26.43 to 38.60 kDa, their theoretical isoelectric points from 5.54 to 8.68, and their index of fatty amino acids were all belonged to unstable proteins, which was higher than 66%. The physicochemical properties of amino acid sequences in different species were quite different. In addition, the promoter of VvERF2 gene had a variety of cis-acting element related to abscisic acid and other transcription factors, such as MYB. Particularly, VvERF2 expressed specificity in different tissues, with callus exhibiting the lowest level of expression. Following salt stress, however, VvERF2 gene expression increased to three times that of the control group. Transgenic results showed that after overexpression of VvERF2 gene in grape callus, growth amount, total acid, total phenol content and antioxidant activity of DPPH (1, 1-diphenyl-2-trinitrophenylhydrazine) were significantly increased. The content of total protein and free proline in transgenic callus were almost higher than those in wild-type callus treated with different concentrations of NaCl. 【Conclusion】 The overexpression of VvERF2 promoted callus growth and accumulation of secondary metabolites, such as phenolic substances, and improved salt tolerance of grape.

Key words: grape, VvERF2, salt stress, functional identification

代瑛姿, 郭宏扬, 杨志峰, 王宪璞, 许丽丽. 葡萄转录因子VvERF2耐盐功能鉴定[J]. 中国农业科学, 2024, 57(2): 336-348.

DAI YingZi, GUO HongYang, YANG ZhiFeng, WANG XianPu, XU LiLi. Identification of Salt Resistance Functional of Grape Transcription Factor VvERF2[J]. Scientia Agricultura Sinica, 2024, 57(2): 336-348.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2024.02.009

https://www.chinaagrisci.com/CN/Y2024/V57/I2/336

图/表 10

表1

图1

图2

表2

图3

表3

图4

图5

表4

图6

参考文献 60

[1]	LICAUSI F, GIORGI F M, ZENONI S, OSTI F, PEZZOTTI M, PERATA P. Genomic and transcriptomic analysis of the AP2/ERF superfamily in Vitis vinifera. BMC Genomics, 2010, 11(1): 1-16. doi: 10.1186/1471-2164-11-1
[2]	NAKANO T, SUZUKI K, FUJIMURA T, SHINSHI H. Genome-wide analysis of the ERF gene family in Arabidopsis and rice. Plant Physiology, 2006, 140(2): 411-432. doi: 10.1104/pp.105.073783
[3]	JOFUKU K D, DEN BOER B G, VAN MONTAGU M, OKAMURO J K. Control of Arabidopsis flower and seed development by the homeotic gene APETALA2. The Plant Cell, 1994, 6(9): 1211-1225.
[4]	FENG K, HOU X L, XING G M, LIU J X, DUAN A Q, XU Z S, LI M Y, ZHUANG J, XIONG A S. Advances in AP2/ERF super-family transcription factors in plant. Critical Reviews in Biotechnology, 2020, 40(6): 750-776. doi: 10.1080/07388551.2020.1768509 pmid: 32522044
[5]	OH S J, SONG S I, KIM Y S, JANG H J, KIM S Y, KIM M, KIM Y K, NAHM B H, KIM J K. Arabidopsis CBF₃/DREB1A and ABF₃ in transgenic rice increased tolerance to abiotic stress without stunting growth. Plant Physiology, 2005, 138(1): 341-351. doi: 10.1104/pp.104.059147
[6]	MAGHSOUDI K, EMAM Y, NIAZI A, PESSARAKLI M, ARVIN M J. P5CS expression level and proline accumulation in the sensitive and tolerant wheat cultivars under control and drought stress conditions in the presence/absence of silicon and salicylic acid. Journal of Plant Interactions, 2018, 13(1): 461-471. doi: 10.1080/17429145.2018.1506516
[7]	BANDURSKA H, BREŚ W, ZIELEZIŃSKA M, MIELOSZYK E. Does potassium modify the response of Zinnia (Zinnia elegans jacq.) to long-term salinity? Plants, 2023, 12(7): 1439. doi: 10.3390/plants12071439
[8]	吕笑言, 王宇光, 金英. 甜菜BvM14-CMO、BvM14-BADH基因的克隆、盐胁迫表达及生物信息学分析. 黑龙江大学自然科学学报, 2018, 35(1): 79-84.
	LÜ X Y, WANG Y G, JIN Y. Cloning, salt stress expression and bioinformatics analysis of BvM14-CMO and BvM14-BADH genes in sugarbeet. Journal of Natural Science of Heilongjiang University, 2018, 35(1): 79-84. (in Chinese)
[9]	SEKULA B, DAUTER Z. Spermidine synthase (SPDS) undergoes concerted structural rearrangements upon ligand binding - A case study of the two SPDS isoforms from Arabidopsis thaliana. Frontiers in Plant Science, 2019, 10: 555. doi: 10.3389/fpls.2019.00555
[10]	CHITNIS M V, MUNRO C A, BROWN A J P, GOODAY G W, GOW N A R, DESHPANDE M V. The zygomycetous fungus, Benjaminiella poitrasii contains a large family of differentially regulated chitin synthase genes. Fungal Genetics and Biology, 2002, 36(3): 215-223. doi: 10.1016/S1087-1845(02)00015-4
[11]	MILLER E N, INGRAM L O. Sucrose and overexpression of trehalose biosynthetic genes (otsBA) increase desiccation tolerance of recombinant Escherichia coli. Biotechnology Letters, 2008, 30(3): 503-508. doi: 10.1007/s10529-007-9573-5
[12]	王镭, 才华, 柏锡, 李丽文, 李勇, 朱延明. 转OsCDPK7基因水稻的培育与耐盐性分析. 遗传, 2008, 30(8): 1051-1055.
	WANG L, CAI H, BAI X, LI L W, LI Y, ZHU Y M. Cultivation of transgenic rice plants with OsCDPK7 gene and its salt tolerance. Hereditas, 2008, 30(8): 1051-1055. (in Chinese)
[13]	FU S F, CHOU W C, HUANG D D, HUANG H J. Transcriptional regulation of a rice mitogen-activated protein kinase gene, OsMAPK4, in response to environmental stresses. Plant and Cell Physiology, 2002, 43(8): 958-963. doi: 10.1093/pcp/pcf111
[14]	PIAO H L, LIM J H, KIM S J, CHEONG G W, HWANG I. Constitutive over-expression of AtGSK1 induces NaCl stress responses in the absence of NaCl stress and results in enhanced NaCl tolerance in Arabidopsis. The Plant Journal, 2001, 27(4): 305-314. doi: 10.1046/j.1365-313x.2001.01099.x
[15]	SHOU H X, BORDALLO P, WANG K. Expression of the Nicotiana protein kinase (NPK₁) enhanced drought tolerance in transgenic maize. Journal of Experimental Botany, 2004, 55(399): 1013-1019. doi: 10.1093/jxb/erh129
[16]	ZHOU Y B, LIU C, TANG D Y, YAN L, WANG D, YANG Y Z, GUI J S, ZHAO X Y, LI L G, TANG X D, YU F, LI J L, LIU L L, ZHU Y H, LIN J Z, LIU X M. The receptor-like cytoplasmic kinase STRK1 phosphorylates and activates CatC, thereby regulating H₂O₂ homeostasis and improving salt tolerance in rice. The Plant Cell, 2018, 30(5): 1100-1118. doi: 10.1105/tpc.17.01000
[17]	UMEZAWA T, YOSHIDA R, MARUYAMA K, YAMAGUCHI- SHINOZAKI K, SHINOZAKI K. SRK2C, a SNF₁-related protein kinase 2, improves drought tolerance by controlling stress-responsive gene expression in Arabidopsis thaliana. Proceedings of the National Academy of Sciences of the United States of America, 2004, 101(49): 17306-17311.
[18]	ZHU J Q, ZHANG J T, TANG R J, LV Q D, WANG Q Q, YANG L, ZHANG H X. Molecular characterization of ThIPK2, an inositol polyphosphate kinase gene homolog from Thellungiella halophila, and its heterologous expression to improve abiotic stress tolerance in Brassica napus. Physiologia Plantarum, 2009, 136(4): 407-425. doi: 10.1111/ppl.2009.136.issue-4
[19]	苏倩, 杜文宣, 马琳, 夏亚迎, 李雪, 祁智, 庞永珍. 紫花苜蓿MsCIPK2的克隆及功能分析. 中国农业科学, 2022, 55(19): 3697-3709. doi: 10.3864/j.issn.0578-1752.2022.19.002.
	SU Q, DU W X, MA L, XIA Y Y, LI X, QI Z, PANG Y Z. Cloning and functional analyses of MsCIPK2 in Medicago sativa. Scientia Agricultura Sinica, 2022, 55(19): 3697-3709. doi: 10.3864/j.issn.0578-1752.2022.19.002. (in Chinese)
[20]	LATZ A, MEHLMER N, ZAPF S, MUELLER T D, WURZINGER B, PFISTER B, CSASZAR E, HEDRICH R, TEIGE M, BECKER D. Salt stress triggers phosphorylation of the Arabidopsis vacuolar K⁺ channel TPK1 by calcium-dependent protein kinases (CDPKs). Molecular Plant, 2013, 6(4): 1274-1289. doi: 10.1093/mp/sss158
[21]	DUTILLEUL C, RIBEIRO I, BLANC N, NEZAMES C D, DENG X W, ZGLOBICKI P, PALACIO BARRERA A M, ATEHORTÙA L, COURTOIS M, LABAS V, GIGLIOLI-GUIVARC'H N, DUCOS E. ASG2 is a farnesylated DWD protein that acts as ABA negative regulator in Arabidopsis. Plant, Cell & Environment, 2016, 39(1): 185-198.
[22]	ZHOU X Y, LI J F, WANG Y Q, LIANG X Y, ZHANG M, LU M H, GUO Y, QIN F, JIANG C F. The classical SOS pathway confers natural variation of salt tolerance in maize. The New Phytologist, 2022, 236(2): 479-494. doi: 10.1111/nph.v236.2
[23]	潘晓雪, 胡明瑜, 蒋晓英, 白文钦, 官玲, 吴红, 雷开荣. 过量表达盐芥TsIPK2基因增强转基因水稻耐盐性. 植物营养与肥料学报, 2019, 25(5): 741-747.
	PAN X X, HU M Y, JIANG X Y, BAI W Q, GUAN L, WU H, LEI K R. Overexpression of the Thellungiella salsuginea TsIPK2 gene enhances salt tolerance of transgenic rice. Plant Nutrition and Fertilizer Science, 2019, 25(5): 741-747. (in Chinese)
[24]	SHI H Z, KIM Y, GUO Y, STEVENSON B, ZHU J K. The Arabidopsis SOS₅ locus encodes a putative cell surface adhesion protein and is required for normal cell expansion. The Plant Cell, 2003, 15(1): 19-32. doi: 10.1105/tpc.007872
[25]	DOU M Z, CHENG S, ZHAO B T, XUAN Y H, SHAO M L. The indeterminate domain protein ROC1 regulates chilling tolerance via activation of DREB1B/CBF₁ in rice. International Journal of Molecular Sciences, 2016, 17(3): 233. doi: 10.3390/ijms17030233
[26]	MARUYAMA K, TAKEDA M, KIDOKORO S, YAMADA K, SAKUMA Y, URANO K, FUJITA M, YOSHIWARA K, MATSUKURA S, MORISHITA Y, SASAKI R, SUZUKI H, SAITO K, SHIBATA D, SHINOZAKI K, YAMAGUCHI-SHINOZAKI K. Metabolic pathways involved in cold acclimation identified by integrated analysis of metabolites and transcripts regulated by DREB1A and DREB2A. Plant Physiology, 2009, 150(4): 1972-1980. doi: 10.1104/pp.109.135327 pmid: 19502356
[27]	KIM S, KANG J Y, CHO D I, PARK J H, KIM S Y. ABF2, an ABRE-binding bZIP factor, is an essential component of glucose signaling and its overexpression affects multiple stress tolerance. The Plant Journal, 2004, 40(1): 75-87. doi: 10.1111/tpj.2004.40.issue-1
[28]	HWANG K, SUSILA H, NASIM Z, JUNG J Y, AHN J H. Arabidopsis ABF₃ and ABF₄ transcription factors act with the NF-YC complex to regulate SOC1 expression and mediate drought-accelerated flowering. Molecular Plant, 2019, 12(4): 489-505. doi: 10.1016/j.molp.2019.01.002
[29]	YOSHIDA T, FUJITA Y, SAYAMA H, KIDOKORO S, MARUYAMA K, MIZOI J, SHINOZAKI K, YAMAGUCHI-SHINOZAKI K. AREB1, AREB2, and ABF₃ are master transcription factors that cooperatively regulate ABRE-dependent ABA signaling involved in drought stress tolerance and require ABA for full activation. The Plant Journal, 2010, 61(4): 672-685. doi: 10.1111/tpj.2010.61.issue-4
[30]	WANG C L, LU G Q, HAO Y Q, GUO H M, GUO Y, ZHAO J, CHENG H M. ABP9, a maize bZIP transcription factor, enhances tolerance to salt and drought in transgenic cotton. Planta, 2017, 246(3): 453-469. doi: 10.1007/s00425-017-2704-x pmid: 28474114
[31]	VERMA D, JALMI S K, BHAGAT P K, VERMA N, SINHA A K. A bHLH transcription factor, MYC₂, imparts salt intolerance by regulating proline biosynthesis in Arabidopsis. The FEBS Journal, 2020, 287(12): 2560-2576. doi: 10.1111/febs.v287.12
[32]	YOO J H, PARK C Y, KIM J C, DO HEO W, CHEONG M S, PARK H C, KIM M C, MOON B C, CHOI M S, KANG Y H, LEE J H, KIM H S, LEE S M, YOON H W, LIM C O, YUN D J, LEE S Y, CHUNG W S, CHO M J. Direct interaction of a divergent CaM isoform and the transcription factor, MYB2, enhances salt tolerance in Arabidopsis. Journal of Biological Chemistry, 2005, 280(5): 3697-3706. doi: 10.1074/jbc.M408237200
[33]	OH J E, KWON Y, KIM J H, NOH H, HONG S W, LEE H. A dual role for MYB60 in stomatal regulation and root growth of Arabidopsis thaliana under drought stress. Plant Molecular Biology, 2011, 77(1/2): 91-103. doi: 10.1007/s11103-011-9796-7
[34]	SUGANO S, KAMINAKA H, RYBKA Z, CATALA R, SALINAS J, MATSUI K, OHME-TAKAGI M, TAKATSUJI H. Stress-responsive zinc finger geneZPT2-3 plays a role in drought tolerance in petunia. The Plant Journal, 2003, 36(6): 830-841. doi: 10.1046/j.1365-313X.2003.01924.x
[35]	KIM S H, HONG J K, LEE S C, SOHN K H, JUNG H W, HWANG B K. CAZFP1, Cys2/His2-type zinc-finger transcription factor gene functions as a pathogen-induced early-defense gene in Capsicum annuum. Plant Molecular Biology, 2004, 55(6): 883-904. doi: 10.1007/s11103-005-2151-0
[36]	GAMBINO G, RUFFA P, VALLANIA R, GRIBAUDO I. Somatic embryogenesis from whole flowers, anthers and ovaries of grapevine (Vitis spp.). Plant Cell, Tissue and Organ Culture, 2007, 90(1): 79-83. doi: 10.1007/s11240-007-9256-x
[37]	LIVAK K J, SCHMITTGEN T D. Analysis of relative gene expression data using real-time quantitative PCR and the 2^-ΔΔCT method. Methods, 2001, 25(4): 402-408. doi: 10.1006/meth.2001.1262
[38]	LI X L, WANG C R, LI X Y, YAO Y X, HAO Y J. Modifications of Kyoho grape berry quality under long-term NaCl treatment. Food Chemistry, 2013, 139: 931-937. doi: 10.1016/j.foodchem.2013.02.038
[39]	XU L L, YUE Q Y, BIAN F E, SUN H, ZHAI H, YAO Y X. Melatonin enhances phenolics accumulation partially via ethylene signaling and resulted in high antioxidant capacity in grape berries. Frontiers in Plant Science, 2017, 8: 1426. doi: 10.3389/fpls.2017.01426 pmid: 28868058
[40]	KATALINIĆ V, MOŽINA S S, SKROZA D, GENERALIĆ I, ABRAMOVIČ H, MILOŠ M, LJUBENKOV I, PISKERNIK S, PEZO I, TERPINC P, BOBAN M. Polyphenolic profile, antioxidant properties and antimicrobial activity of grape skin extracts of 14 Vitis vinifera varieties grown in Dalmatia (Croatia). Food Chemistry, 2010, 119(2): 715-723. doi: 10.1016/j.foodchem.2009.07.019
[41]	RE R, PELLEGRINI N, PROTEGGENTE A, PANNALA A, YANG M, RICE-EVANS C. Antioxidant activity applying an improved ABTS radical cation decolorization assay. Free Radical Biology and Medicine, 1999, 26(9/10): 1231-1237. doi: 10.1016/S0891-5849(98)00315-3
[42]	SUN B S, NEVES A C, FERNANDES T A, FERNANDES A L, MATEUS N, DE FREITAS V, LEANDRO C, SPRANGER M I. Evolution of phenolic composition of red wine during vinification and storage and its contribution to wine sensory properties and antioxidant activity. Journal of Agricultural and Food Chemistry, 2011, 59(12): 6550-6557. doi: 10.1021/jf201383e pmid: 21561162
[43]	LI Z J, TIAN Y S, XU J, FU X Y, GAO J J, WANG B, HAN H J, WANG L J, PENG R H, YAO Q H. A tomato ERF transcription factor, SlERF84, confers enhanced tolerance to drought and salt stress but negatively regulates immunity against Pseudomonas syringae pv. tomato DC3000. Plant Physiology and Biochemistry, 2018, 132: 683-695. doi: 10.1016/j.plaphy.2018.08.022
[44]	YOU S J, WU Y, LI W, LIU X F, TANG Q L, HUANG F K, LI Y, WANG H, LIU M C, ZHANG Y. SlERF. G3-Like mediates a hierarchical transcriptional cascade to regulate ripening and metabolic changes in tomato fruit. Plant Biotechnology Journal, 2023: 10.1111/pbi.14177.
[45]	ZHANG Y T, GUO C H, DENG M Y, LI S L, CHEN Y Y, GU X J, TANG G H, LIN Y X, WANG Y, HE W, LI M Y, ZHANG Y, LUO Y, WANG X R, CHEN Q, TANG H R. Genome-wide analysis of the ERF family and identification of potential genes involved in fruit ripening in octoploid strawberry. International Journal of Molecular Sciences, 2022, 23(18): 10550. doi: 10.3390/ijms231810550
[46]	RUI L, ZHU Z Q, YANG Y Y, WANG D R, LIU H F, ZHENG P F, LI H L, LIU G D, LIU R X, WANG X F, ZHANG S, YOU C X. Functional characterization of MdERF113 in apple. Physiologia Plantarum, 2023, 175(1): e13853. doi: 10.1111/ppl.v175.1
[47]	ZHANG X M, JIANG J W, MA Z W, YANG Y P, MENG L D, XIE F C, CUI G W, YIN X J. Cloning of TaeRF1 gene from Caucasian clover and its functional analysis responding to low-temperature stress. Frontiers in Plant Science, 2022, 13: 968965. doi: 10.3389/fpls.2022.968965
[48]	ZHANG G Y, CHEN M, LI L C, XU Z S, CHEN X P, GUO J M, MA Y Z. Overexpression of the soybean GmERF₃ gene, an AP2/ERF type transcription factor for increased tolerances to salt, drought, and diseases in transgenic tobacco. Journal of Experimental Botany, 2009, 60(13): 3781-3796. doi: 10.1093/jxb/erp214
[49]	ZHANG G Y, CHEN M, CHEN X P, XU Z S, LI L C, GUO J M, MA Y Z. Isolation and characterization of a novel EAR-motif-containing gene GmERF₄ from soybean (Glycine max L.). Molecular Biology Reports, 2010, 37(2): 809-818. doi: 10.1007/s11033-009-9616-1
[50]	YANG Z, TIAN L N, LATOSZEK-GREEN M, BROWN D, WU K Q. Arabidopsis ERF4 is a transcriptional repressor capable of modulating ethylene and abscisic acid responses. Plant Molecular Biology, 2005, 58(4): 585-596. doi: 10.1007/s11103-005-7294-5
[51]	LIU D F, CHEN X J, LIU J Q, YE J C, GUO Z J. The rice ERF transcription factor OsERF922 negatively regulates resistance to Magnaporthe oryzae and salt tolerance. Journal of Experimental Botany, 2012, 63(10): 3899-3911. doi: 10.1093/jxb/ers079
[52]	ZHUANG J, JIANG H H, WANG F, PENG R H, YAO Q H, XIONG A S. A rice OsAP23, functioning as an AP2/ERF transcription factor, reduces salt tolerance in transgenic Arabidopsis. Plant Molecular Biology Reporter, 2013, 31(6): 1336-1345. doi: 10.1007/s11105-013-0610-3
[53]	TIAN Z D, HE Q, WANG H X, LIU Y, ZHANG Y, SHAO F, XIE C H. The potato ERF transcription factor StERF₃ negatively regulates resistance to Phytophthora infestans and salt tolerance in potato. Plant and Cell Physiology, 2015, 56(5): 992-1005. doi: 10.1093/pcp/pcv025
[54]	李慧, 韩占品, 贺丽霞, 杨亚苓, 尤书燕, 邓琳, 王春国. 花椰菜BraERF023a的克隆及在响应盐和干旱胁迫中的功能. 中国农业科学, 2021, 54(1): 152-163. doi: 10.3864/j.issn.0578-1752.2021.01.011.
	LI H, HAN Z P, HE L X, YANG Y L, YOU S Y, DENG L, WANG C G. Cloning and functional analysis of BraERF023a under salt and drought stresses in cauliflower (Brassica oleracea L. var. botrytis). Scientia Agricultura Sinica, 2021, 54(1): 152-163. doi: 10.3864/j.issn.0578-1752.2021.01.011. (in Chinese)
[55]	GUTTERSON N, REUBER T L. Regulation of disease resistance pathways by AP2/ERF transcription factors. Current Opinion in Plant Biology, 2004, 7(4): 465-471. doi: 10.1016/j.pbi.2004.04.007 pmid: 15231271
[56]	SUN X M, ZHANG L L, WONG D C J, WANG Y, ZHU Z F, XU G Z, WANG Q F, LI S H, LIANG Z C, XIN H P. The ethylene response factor VaERF092 from Amur grape regulates the transcription factor VaWRKY33, improving cold tolerance. The Plant Journal, 2019, 99(5): 988-1002. doi: 10.1111/tpj.14378 pmid: 31063661
[57]	TRAN L S P, NAKASHIMA K, SAKUMA Y, OSAKABE Y, QIN F, SIMPSON S D, MARUYAMA K, FUJITA Y, SHINOZAKI K, YAMAGUCHI-SHINOZAKI K. Co-expression of the stress-inducible zinc finger homeodomain ZFHD1 and NAC transcription factors enhances expression of the ERD1 gene in Arabidopsis. The Plant Journal, 2007, 49(1): 46-63. doi: 10.1111/tpj.2007.49.issue-1
[58]	XUE G P, LOVERIDGE C W. HvDRF1 is involved in abscisic acid-mediated gene regulation in barley and produces two forms of AP2 transcriptional activators, interacting preferably with a CT-rich element. The Plant Journal, 2004, 37(3): 326-339. doi: 10.1046/j.1365-313X.2003.01963.x
[59]	SALEH A, LUMBRERAS V, LOPEZ C, KIZIS E D P D, PAGÈS M. Maize DBF1-interactor protein 1 containing an R3H domain is a potential regulator of DBF₁ activity in stress responses. The Plant Journal, 2006, 46(5): 747-757. doi: 10.1111/tpj.2006.46.issue-5
[60]	宁蕾, 王曙光, 琚鹏举, 柏星轩, 葛林豪, 齐欣, 姜奇彦, 孙现军, 陈明, 孙黛珍. 过表达谷子SiANT1对水稻耐盐性的影响. 中国农业科学, 2018, 51(10): 1830-1841. doi: 10.3864/j.issn.0578-1752.2018.10.002.
	NING L, WANG S G, JU P J, BAI X X, GE L H, QI X, JIANG Q Y, SUN X J, CHEN M, SUN D Z. Rice overexpression of millet SiANT1 gene increases salt tolerance. Scientia Agricultura Sinica, 2018, 51(10): 1830-1841. doi: 10.3864/j.issn.0578-1752.2018.10.002. (in Chinese)

名称 Name	上游引物 Forward primer (5′-3′)	下游引物 Reverse primer (5′-3′)
VvERF2	AACATCCTCATCACCCCTCCAT	AACGGTGTCCATCCGACATCA
β-Actin	CTTGCATCCCTCAGCACCTT	TCCTGTGGACAATGGATGGA

物种 Species	ID号 ID number	氨基酸残基数 Number of amino acid residue	分子量 Molecular weight (kDa)	理论等电点 Theoretical isoelectric point	不稳定系数 Instability index (%)	脂肪指数Aliphatic index	平均亲水性 Average hydrophilicity
葡萄 Vitis vinifera	XP_002279585.2	240	26.43	6.94	62.32	68.67	-0.555
苹果 Malus domestica	XP_008352414	276	29.62	8.45	57.23	70.98	-0.457
草莓 Fragaria ananassa	AZL19475	295	31.60	6.76	56.57	71.80	-0.363
中国白梨 Pyrus bretschneideri	XP_009369170.2	269	28.82	8.47	52.47	68.85	-0.455
桃 Prunus persica	XP_007209449	281	30.16	9.09	59.26	76.65	-0.411
无花果 Ficus carica	QID57935.1	348	38.60	5.54	55.88	66.75	-0.570
拟南芥 Arabidopsis thaliana	AB008103.1	266	28.97	8.68	56.72	67.86	-0.499
番茄 Solanum lycopersicum	NP_001316388.2	242	26.76	7.68	71.59	69.34	-0.433

元件 Motifs	ABRE	ARE	MYB	MYC	Box4	CGTCA-motif	MRE
数量 Quantity	2	2	4	6	7	4	2
功能 Function	参与脱落酸信号响应 Participate in abscisic acid signal response	厌氧诱导调控元件 Anaerobic induction regulatory element			参与光信号响应 Participate in optical signal response	茉莉酸甲酯响应信号调控元件 Methyl jasmonate responsive signal regulatory element	参与光信号响应的MYB结合位点 MYB binding sites involved in optical signal response

愈伤组织 Callus	生长量 Growth (g·dish^-1 FW)	总糖 Total sugar (mg·g^-1 FW)	总酸 Total acid (mg·g^-1 FW)	总酚 Total phenol (mg·g^-1 FW)	DPPH抗氧化活性 DPPH antioxidant activity (mg·g^-1 FW)	FRAP抗氧化活性 FRAP antioxidant activity (mg·g^-1 FW)	ABTS抗氧化活性 ABTS antioxidant activity (mg·g^-1 FW)
wt	0.33±0.017	26.04±1.02	0.14±0.0088	0.13±0.0012	0.86±0.010	1.60±0.45	1.38±0.32
erf2-1	0.41±0.065*	27.48±1.98	0.11±0.0069**	0.17±0.0032**	1.22±0.012*	2.88±0.27*	1.75±0.12*
erf2-2	0.40±0.027*	26.99±1.34	0.08±0.0060*	0.18±0.0021*	1.33±0.021*	3.51±0.073**	2.38±0.23*
erf2-3	0.39±0.051*	28.02±2.18	0.10±0.0021*	0.18±0.0032**	1.40±0.030*	3.51±0.10**	2.45±0.10*
