生姜NHX基因家族成员鉴定及其在硅缓解盐胁迫中的表达特征

doi:10.3864/j.issn.0578-1752.2024.19.011

中国农业科学 ›› 2024, Vol. 57 ›› Issue (19): 3848-3869.doi: 10.3864/j.issn.0578-1752.2024.19.011

生姜NHX基因家族成员鉴定及其在硅缓解盐胁迫中的表达特征

尹军良¹^,²(), 李婧怡¹, 韩硕¹, 杨培华², 马佳伟², 刘奕清², 胡海骏², 朱永兴¹^,²()

¹ 长江大学农学院，湖北荆州 434025
² 长江大学园艺园林学院/香辛园艺植物种质创新与利用湖北省重点实验室/湿地生态与农业利用教育部工程研究中心，湖北荆州 434025

收稿日期:2024-06-09 接受日期:2024-07-22 出版日期:2024-10-01 发布日期:2024-10-09
通信作者:
朱永兴，E-mail：xbnlzyx@163.com
联系方式: 尹军良，E-mail：yinjunliang@yangtzeu.edu.cn。
基金资助:
湖北省重点研发项目(2022BBA0061); 重庆英才优秀科学家项目(CQYC20220101514); 湿地生态与农业利用教育部工程研究中心开放基金(KFT202305); 重庆市自然科学基金项目-面上项目(CSTB2022NSCQ-MSX1588)

Identification of Ginger (Zingiber officinale Roscoe) NHX Gene Family Members and Characterization of Their Expression Patterns in Silicon Alleviating Salt Stress

YIN JunLiang¹^,²(), LI JingYi¹, HAN Shuo¹, YANG PeiHua², MA JiaWei², LIU YiQing², HU HaiJun², ZHU YongXing¹^,²()

¹ College of Agriculture, Yangtze University, Jingzhou 434025, Hubei
² College of Horticulture and Gardening, Yangtze University/ Hubei Key Laboratory of Spices & Horticultural Plant Germplasm Innovation & Utilization/Engineering Research Center of Wetland Ecology and Agricultural Use, Ministry of Education, Jingzhou 434025, Hubei

Received:2024-06-09 Accepted:2024-07-22 Published:2024-10-01 Online:2024-10-09

摘要/Abstract

摘要：

【目的】系统分析生姜NHX基因家族成员的基本特征，探究其在生姜不同组织、处理下的表达模式，为进一步研究ZoNHXs功能提供理论基础。【方法】以拟南芥NHX蛋白序列为参考序列，与生姜基因组进行BLAST比对，筛选出包含Na⁺/H⁺ exchange保守结构域的蛋白序列，得到生姜ZoNHX家族成员。使用MEGA 7.0构建拟南芥和生姜NHX家族成员的系统发育树，利用ExPASy ProtParam、GSDS、MEME、PHYRE2、SOPMA和TBtools对ZoNHXs的理化性质、基因结构、保守基序、二级结构和三级结构、染色体定位、基因共线性及表达模式进行分析。借助RT-qPCR分析ZoNHXs在对照（CK）、盐胁迫（NaCl）、盐胁迫+纳米硅（NaCl+SiNP）处理的生姜根系和叶片中的表达特征，并测定生姜各个组织内的Na⁺、K⁺离子含量。【结果】从生姜基因组中共鉴定出15个ZoNHX基因家族成员，根据其染色体位置分别命名为ZoNHX1—ZoNHX15。根据系统发育关系和亚细胞定位分析，将ZoNHXs归为液泡膜（vacuole，Vac）、核内体膜（endosome，Endo）和质膜（plasma membrane，PM）3个亚组。蛋白质特征分析结果表明，ZoNHXs的相对分子量介于26.01—163.59 kDa，氨基酸序列长度介于231—1 459 aa。亚细胞定位分析发现，11个ZoNHXs定位在液泡，ZoNHX14定位于细胞膜和细胞核，ZoNHX1、ZoNHX7和ZoNHX9分别定位于细胞质、细胞膜和叶绿体。信号肽预测发现，只有ZoNHX1为含有信号肽的分泌蛋白，其余均为非分泌蛋白。顺式作用元件分析显示，ZoNHXs启动子区域包含生长发育响应元件、激素响应元件和胁迫响应元件。转录组数据分析表明，15个ZoNHXs在生姜叶片和根系中均有表达；其中，ZoNHX12在生姜各组织和各非生物胁迫下表达水平相对较高，ZoNHX14在生姜各生长时期及低温下表达量显著上调。RT-qPCR结果显示，与CK相比，除ZoNHX8、ZoNHX11外，其余基因在盐胁迫后的根系和叶片中表达量均显著上调。同单独盐胁迫相比，NaCl+SiNP100处理后，除根系和叶片ZoNHX8、ZoNHX11的表达水平显著上调外，其余基因的表达水平均下调，表明ZoNHXs参与生姜对盐胁迫的响应过程，且ZoNHXs的表达受外源SiNP的调控。Na⁺、K⁺离子含量、K⁺/Na⁺比值及运输选择系数S_K⁺_/Na⁺结果表明，盐胁迫处理下生姜根茎、茎、叶中的Na⁺含量较CK上升，K⁺/Na⁺比值及运输选择系数下降，NaCl+SiNP100处理的根、根茎、茎、叶中的Na⁺含量显著下降，K⁺/Na⁺比值及运输选择系数上升。表明ZoNHXs可能参与生姜各组织的Na⁺、K⁺转运调控，缓解盐胁迫损伤。【结论】生姜基因组中15个ZoNHXs可分为3个亚组，分布在6条染色体上；ZoNHX1—ZoNHX15的表达均受盐胁迫诱导；SiNP100预处理可调控ZoNHXs的表达，降低植株体内Na⁺含量，提高生姜根、根茎、茎和叶片中的K⁺/Na⁺比值和K⁺、Na⁺运输选择性系数，从而缓解植株盐胁迫。

关键词: 生姜, NHX基因家族, 盐胁迫, 表达分析, 转录组

Abstract:

【Objective】 Systematic analysis of the basic features of the ZoNHX family members in ginger and exploration of their expression patterns in different tissues and treatments of ginger can provide a theoretical foundation for further research on the function of ZoNHXs. 【Method】The Arabidopsis thaliana NHX protein sequences were used as reference sequences to compare with the ginger genome to obtain the ginger ZoNHXs. The phylogenetic tree containing Arabidopsis and ginger NHX family members were constructed based on the neighbor-joining method by MEGA 7.0. Physicochemical properties, gene structure, conserved motifs, secondary structure and tertiary structure of ZoNHXs were analyzed by using ExPASy ProtParam software, GSDS, MEME online website, PHYRE 2 and SOPMA, while chromosomal localization, intragenomic covariance and expression patterns of ZoNHXs were analyzed by using TBtools software. The gene expression levels of ZoNHXs in different treatments including CK, NaCl, and NaCl+SiNP100, and different ginger tissues were analyzed using RT-qPCR. The Na⁺ and K⁺ contents of ginger tissues was determined. 【Result】A total of 15 NHX gene family members were identified from the ginger genome, and were named as ZoNHX1-ZoNHX15 based on their chromosomal locations. The ZoNHXs were classified into three subgroups according to phylogenetic relationship and subcellular localization, including vesicular membranes (Vac, vacuole), endosomal membranes in the nucleus (Endo, endosome) and plasma membranes (PM, plasma). Protein characterization analysis showed that the relative molecular weights of ZoNHXs ranged from 26.01 kDa to 163.59 kDa, and the protein lengths ranged from 231 to 1 459 aa. The results of subcellular localization prediction showed that 11 ZoNHXs were distributed on the vacuole, ZoNHX14 were distributed both on the cell membrane and nucleus, ZoNHX1, ZoNHX7 and ZoNHX9 were respectively distributed on cytoplasm, cell membrane, and chloroplast. Signal peptide prediction showed that only ZoNHX1 contained a signal peptide and was a secreted protein, while other ZoNHX family members were non-secretory proteins. Cis-acting element analysis showed that the promoter regions of the ZoNHXs contain growth and development response elements, hormone response elements, and stress response elements. Transcriptome analysis showed that all ZoNHXs were detected to be expressed in ginger leaf and root, among which, ZoNHX12 was highly expressed in all tissues of ginger and under different abiotic stresses, and ZoNHX14 was significantly up-regulated in all growth periods of ginger and at low temperatures. RT-qPCR results showed that, compared with the CK, all genes were significantly up-regulated in roots and leaves after salt stress except for ZoNHX8 and ZoNHX11. Compared with the NaCl treatment alone, NaCl+SiNP100 decreased the expression levels of all genes except for ZoNHX8 and ZoNHX11, the expression levels of which were significantly up-regulated. These indicated that ZoNHXs were involved in the response process of ginger to salt stress and the expression of ZoNHXs were also regulated by exogenous SiNP100. The results of Na⁺, K⁺ion content, K⁺/Na⁺ratio and transport selection coefficient S_K⁺_/Na⁺ showed that the Na⁺ content in ginger rhizomes, stems, and leaves under salt treatment was increased compared with CK, and the K⁺/Na⁺ ratio and transport selection coefficient were decreased. NaCl+SiNP100 treatment significantly decreased Na⁺content in roots, rhizomes, stems and leaves, whereases increased K⁺/Na⁺ ratio and transport selection coefficient. 【Conclusion】 The ginger genome contains 15 ZoNHXs and divides into three subgroups. RT-qPCR results showed that the expression of ZoNHX1-ZoNHX15 were all induced by salt stress. SiNP100 pretreatment could alleviate plant salt stress through reducing the Na⁺ content and increase the K⁺/Na⁺ ratio and K⁺ and Na⁺ content of the ginger roots, rhizomes, stems, and leaves by regulating the expression of ZoNHXs.

Key words: ginger, NHX gene family, salt stress, expression analysis, transcriptome

尹军良, 李婧怡, 韩硕, 杨培华, 马佳伟, 刘奕清, 胡海骏, 朱永兴. 生姜NHX基因家族成员鉴定及其在硅缓解盐胁迫中的表达特征[J]. 中国农业科学, 2024, 57(19): 3848-3869.

YIN JunLiang, LI JingYi, HAN Shuo, YANG PeiHua, MA JiaWei, LIU YiQing, HU HaiJun, ZHU YongXing. Identification of Ginger (Zingiber officinale Roscoe) NHX Gene Family Members and Characterization of Their Expression Patterns in Silicon Alleviating Salt Stress[J]. Scientia Agricultura Sinica, 2024, 57(19): 3848-3869.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2024.19.011

https://www.chinaagrisci.com/CN/Y2024/V57/I19/3848

图/表 17

表1

图1

表2

图2

图3

图4

图5

图6

图7

表3

图8

图9

图10

图11

图12

表4

表5

参考文献 67

[1]	ISAYENKOV S V, DABRAVOLSKI S A, PAN T, SHABALA S. Phylogenetic diversity and physiological roles of plant monovalent cation/H⁺ antiporters. Frontiers in Plant Science, 2020, 11: 573564.
[2]	罗达, 吴正保, 史彦江, 宋锋惠. 盐胁迫对3种平欧杂种榛幼苗叶片解剖结构及离子吸收、运输与分配的影响. 生态学报, 2022, 42(5): 1876-1888.
	LUO D, WU Z B, SHI Y J, SONG F H. Effects of salt stress on leaf anatomical structure and ion absorption, transportation and distribution of three Ping’ou hybrid hazelnut seedlings. Acta Ecologica Sinica, 2022, 42(5): 1876-1888. (in Chinese)
[3]	CHEN Z H, POTTOSIN I I, CUIN T A, FUGLSANG A T, TESTER M, JHA D, ZEPEDA-JAZO I, ZHOU M X, PALMGREN M G, NEWMAN I A, SHABALA S. Root plasma membrane transporters controlling K⁺/Na⁺ homeostasis in salt-stressed barley. Plant Physiology, 2007, 145(4): 1714-1725.
[4]	康红霞, 伍国强, 魏明, 李善家. Na⁺/H⁺逆向转运蛋白在植物应答非生物逆境胁迫中的作用. 植物生理学报, 2022, 58(3): 511-523.
	KANG H X, WU G Q, WEI M, LI S J. The role of Na⁺/H⁺ antiporter in response of plant to abiotic stress. Plant Physiology Journal, 2022, 58(3): 511-523. (in Chinese)
[5]	BASSIL E, BLUMWALD E. The ins and outs of intracellular ion homeostasis: NHX-type cation/H⁺ transporters. Current Opinion in Plant Biology, 2014, 22: 1-6.
[6]	CAO B N, XIA Z Q, LIU C Y, FAN W, ZHANG S, LIU Q, XIANG Z H, ZHAO A C. New insights into the structure-function relationship of the endosomal-type Na⁺, K⁺/H⁺ antiporter NHX6 from mulberry (Morus notabilis). International Journal of Molecular Sciences, 2020, 21(2): 428.
[7]	BASSIL E, COKU A, BLUMWALD E. Cellular ion homeostasis: Emerging roles of intracellular NHX Na⁺/H⁺ antiporters in plant growth and development. Journal of Experimental Botany, 2012, 63(16): 5727-5740.
[8]	PARDO J M, CUBERO B, LEIDI E O, QUINTERO F J. Alkali cation exchangers: Roles in cellular homeostasis and stress tolerance. Journal of Experimental Botany, 2006, 57(5): 1181-1199. doi: 10.1093/jxb/erj114 pmid: 16513813
[9]	WANG L G, FENG X Y, ZHAO H, WANG L D, AN L Z, QIU Q S. Functional analysis of the Na⁺, K⁺/H⁺ antiporter PeNHX3 from the tree halophyte Populus euphratica in yeast by model-guided mutagenesis. PLoS ONE, 2014, 9(8): e104147.
[10]	WANG L G, WU X X, LIU Y F, QIU Q S. AtNHX5 and AtNHX6 control cellular K⁺ and pH homeostasis in Arabidopsis: Three conserved acidic residues are essential for K⁺ transport. PLoS ONE, 2015, 10(12): e0144716.
[11]	吴金平, 周洁, 符家平, 肖颖, 郭凤领. 来凤生姜栽培现状及优势品种推荐. 长江蔬菜, 2020(23): 8-10.
	WU J P, ZHOU J, FU J P, XIAO Y, GUO F L. Production status and recommended cultivars of Zingiber officinaie roscoe in Laifeng County of Hubei. Journal of Changjiang Vegetables, 2020(23): 8-10. (in Chinese)
[12]	唐宁, 吕健飞, 谢奇玕, 胡静, 高娜, 黄晓磊, 陈德, 叶雪珠. 不同种植年限生姜土壤质量变化规律. 浙江农业科学, 2023, 64(10): 2413-2417. doi: 10.16178/j.issn.0528-9017.20221090
	TANG N, LÜ J F, XIE Q X, HU J, GAO N, HUANG X L, CHEN D, YE X Z. Changes of soil quality of ginger with different planting years. Journal of Zhejiang Agricultural Sciences, 2023, 64(10): 2413-2417. (in Chinese)
[13]	高伟, 席克勇, 尹军良, 刘奕清, 朱永兴, 贾切. 外源SiNPs对盐胁迫下生姜幼苗生长和生理特性的影响. 西北农林科技大学学报(自然科学版), 2023, 51(9): 109-118.
	GAO W, XI K Y, YIN J L, LIU Y Q, ZHU Y X, JIA Q. Effects of exogenous SiNPs on growth and physiological characteristics of ginger seedlings under salt stress. Journal of Northwest A & F University (Natural Science Edition), 2023, 51(9): 109-118. (in Chinese)
[14]	徐悦, 曹逼力, 陈子敬, 徐坤. 盐碱交互胁迫对生姜产量和品质的影响及其数学模型的建立. 中国蔬菜, 2019(12): 41-45.
	XU Y, CAO B L, CHEN Z J, XU K. Effect of salt-alkali interaction stress on yield and quality of ginger and establishment of its mathematical model. China Vegetables, 2019(12): 41-45. (in Chinese)
[15]	RATNER A, JACOBY B. Effect of K⁺, its counter anion, and pH on sodium efflux from barley root tips. Journal of Experimental Botany, 1976, 27(5): 843-852.
[16]	周梦岩, 王涛涛, 陈冉红, 金松松, 李明, 马留银. 互花米草NHX2基因的克隆与功能鉴定. 西北植物学报, 2019, 39(12): 2093-2099.
	ZHOU M Y, WANG T T, CHEN R H, JIN S S, LI M, MA L Y. Cloning and function identification of NHX2 gene from Spartina alterniflora. Acta Botanica Boreali-Occidentalia Sinica, 2019, 39(12): 2093-2099. (in Chinese)
[17]	WANG G, YANG D, WANG W T, PENG D L, JI J, JIN C, GUAN C F. Regulation effects of Na⁺/H⁺ Antiporter (NHX1) on Nicotiana tabacum stressed with metals of different valences. Journal of Plant Growth Regulation, 2023, 42(3): 1846-1864.
[18]	JIN T, AN J, XU H D, CHEN J, PAN L, ZHAO R R, WANG N, GAI J Y, LI Y. A soybean sodium/hydrogen exchanger GmNHX6 confers plant alkaline salt tolerance by regulating Na⁺/K⁺ homeostasis. Frontiers in Plant Science, 2022, 13: 938635.
[19]	缑天韵, 苏艳, 陈馨航, 朱永兴, 宫海军. 硅促进盐胁迫下黄瓜NHX1基因表达及Na⁺在液泡中的区隔化效应. 植物营养与肥料学报, 2020, 26(11): 1923-1934.
	GOU T Y, SU Y, CHEN X H, ZHU Y X, GONG H J. Silicon upregulates NHX1 expression to enhance Na⁺ partitioning into vacuoles in leaf mesophyll cells of cucumber under salt stress. Journal of Plant Nutrition and Fertilizers, 2020, 26(11): 1923-1934. (in Chinese)
[20]	GHORBANI A, PISHKAR L, SARAVI K V, CHEN M X. Melatonin-mediated endogenous nitric oxide coordinately boosts stability through proline and nitrogen metabolism, antioxidant capacity, and Na⁺/K⁺ transporters in tomato under NaCl stress. Frontiers in Plant Science, 2023, 14: 1135943.
[21]	马红萍. 超表达霸王ZxNHX1和拟南芥AtNHX1转基因紫花苜蓿耐盐性和抗旱性的比较研究[D]. 兰州: 兰州大学, 2020.
	MA H P. Comparative study on salt and drought resistance between transgenic alfalfa lines overexpressing ZxNHX1 from Zygophyllum xanthoxylum and AtNHXl from Arabidopsis[D]. Lanzhou: Lanzhou University, 2020. (in Chinese)
[22]	罗建, 许春苗, 张国斌, 郁继华. 辣椒NHX基因家族的鉴定和表达分析. 华北农学报, 2021, 36(3): 15-24. doi: 10.7668/hbnxb.20191999
	LUO J, XU C M, ZHANG G B, YU J H. Bioinformation analysis and expression analysis of NHX genes family in pepper. Acta Agriculturae Boreali-Sinica, 2021, 36(3): 15-24. (in Chinese) doi: 10.7668/hbnxb.20191999
[23]	许海霞. 小麦Na⁺/H⁺逆转蛋白的功能分析[D]. 郑州: 河南农业大学, 2009.
	XU H X. Functional characterization of Na⁺/H⁺antiporter in wheat (Triticum aestivum)[D]. Zhengzhou: Henan Agricultural University, 2009. (in Chinese)
[24]	杨杰, 陈蓉, 胡文娟, 吴巧玲, 佟晓楠, 李兴涛, 陈健美. 甜橙NHX基因家族的鉴定及功能分析. 江苏农业科学, 2022, 50(7): 35-42.
	YANG J, CHEN R, HU W J, WU Q L, TONG X L, LI X T, CHEN J M. Identification and functional analysis of the NHX gene family in Citrus sinensis. Jiangsu Agricultural Sciences, 2022, 50(7): 35-42. (in Chinese)
[25]	徐亚, 滕梦鑫, 何岳东, 乔飞, 李新国. 香蕉NHX基因家族的鉴定及表达分析. 植物生理学报, 2021, 57(3): 681-691.
	XU Y, TENG M X, HE Y D, QIAO F, LI X G. Identification and expression analysis of NHX genes family in banana. Plant Physiology Journal, 2021, 57(3): 681-691. (in Chinese)
[26]	王影, 李慧, 蔺经, 杨青松, 张绍铃, 常有宏. 杜梨NHX基因家族的鉴定及其在非生物胁迫下的表达分析. 果树学报, 2019, 36(7): 825-836.
	WANG Y, LI H, LIN J, YANG Q S, ZHANG S L, CHANG Y H. Identification of NHX gene family in Pyrus betulaefolia and its expression under abiotic stress. Journal of Fruit Science, 2019, 36(7): 825-836. (in Chinese)
[27]	张业猛, 朱丽丽, 陈志国. 藜麦NHX基因家族鉴定及盐胁迫下表达分析. 生物技术通报, 2022, 38(12): 184-193. doi: 10.13560/j.cnki.biotech.bull.1985.2022-0404
	ZHANG Y M, ZHU L L, CHEN Z G. Identification and expression analysis of NHX gene family in quinoa under salt stress. Biotechnology Bulletin, 2022, 38(12): 184-193. (in Chinese)
[28]	SAHOO D P, KUMAR S, MISHRA S, KOBAYASHI Y, PANDA S K, SAHOO L. Enhanced salinity tolerance in transgenic mungbean overexpressing Arabidopsis antiporter (NHX1) gene. Molecular Breeding, 2016, 36(10): 144.
[29]	LI H L, WU L, DONG Z M, JIANG Y S, JIANG S J, XING H T, LI Q, LIU G C, TIAN S M, WU Z Y, WU B, LI Z X, ZHAO P, ZHANG Y, TANG J M, XU J B, HUANG K, LIU X, ZHANG W L, LIAO Q H, REN Y, HUANG X Z, LI Q Z, LI C Y, WANG Y, XAVIER-RAVI B, LI H H, LIU Y, WAN T, LIU Q H, ZOU Y, JIAN J B, XIA Q Y, LIU Y Q. Haplotype-resolved genome of diploid ginger (Zingiber officinale) and its unique gingerol biosynthetic pathway. Horticulture Research, 2021, 8(1): 189.
[30]	王荣花, 王树彬, 刘栓桃, 张志刚, 李巧云, 王立华, 赵智中. 大白菜LACS家族基因鉴定与表达分析. 山东农业科学, 2022, 54(6): 1-9.
	WANG R H, WANG S B, LIU S T, ZHANG Z G, LI Q Y, WANG L H, ZHAO Z Z. Identification and expression analysis of LACS family genes in Chinese cabbage (Brassica rapa L. ssp. pekinensis). Shandong Agricultural Sciences, 2022, 54(6): 1-9. (in Chinese)
[31]	姜南, 石杨, 赵志慧, 李斌, 赵熠辉, 杨俊彪, 闫家铭, 靳雨瑶, 陈稷, 黄进. 镉胁迫下水稻OsPT1的表达及功能分析. 生物技术通报, 2023, 39(1): 166-174. doi: 10.13560/j.cnki.biotech.bull.1985.2022-0489
	JIANG N, SHI Y, ZHAO Z H, LI B, ZHAO Y H, YANG J B, YAN J M, JIN Y F, CHEN J, HUANG J. Expression and functional analysis of OsPT1 gene in rice under cadmium stress. Biotechnology Bulletin, 2023, 39(1): 166-174. (in Chinese) doi: 10.13560/j.cnki.biotech.bull.1985.2022-0489
[32]	马建荣, 余永红, 宋卉, 刘戈飞, 沈晓萌. 水稻白叶枯病菌FabG同源蛋白生物信息学分析. 西南农业学报, 2022, 35(5): 1117-1127.
	MA J R, YU Y H, SONG H, LIU G F, SHEN X M. Bioinformatics analysis of FabG homologous proteins of Xanthomonas oryzea pv. Oryzea. Southwest China Journal of Agricultural Sciences, 2022, 35(5): 1117-1127. (in Chinese)
[33]	LIVAK K J, SCHMITTGEN T D. Analysis of relative gene expression data using real-time quantitative PCR and the 2^-ΔΔCT method. Methods, 2001, 25(4): 402-408.
[34]	孟元发. 外源硅对苜蓿盐胁迫的缓解效应及调控机理[D]. 呼和浩特: 内蒙古大学, 2020.
	MENG Y F. Alleviation effects and mechanisms of exogenous silicon on salt stress-induced damage in alfalfa[D]. Huhhot: Inner Mongolia University, 2020. (in Chinese)
[35]	徐威, 袁庆华, 王瑜, 景艳霞. 盐胁迫下白三叶幼苗离子分布规律的初步研究. 中国草地学报, 2011, 33(5): 33-39.
	XU W, YUAN Q H, WANG Y, JING Y X. Studies on ion distribution in white clover seedling under salt stress. Chinese Journal of Grassland, 2011, 33(5): 33-39. (in Chinese)
[36]	LI G, MA J W, YIN J L, GUO F L, XI K Y, YANG P H, CAI X D, JIA Q, LI L, LIU Y Q, ZHU Y X. Identification of reference genes for reverse transcription-quantitative PCR analysis of ginger under abiotic stress and for postharvest biology studies. Frontiers in Plant Science, 2022, 13: 893495.
[37]	JIANG Y S, HUANG M J, ZHANG M X, LAN J B, WANG W X, TAO X, LIU Y Q. Transcriptome analysis provides novel insights into high-soil-moisture-elevated susceptibility to Ralstonia solanacearum infection in ginger (Zingiber officinale Roscoe cv. Southwest). Plant Physiology and Biochemistry, 2018, 132: 547-556.
[38]	HUANG M J, XING H T, LI Z X, LI H L, WU L, JIANG Y S. Identification and expression profile of the soil moisture and Ralstonia solanacearum response CYPome in ginger (Zingiber officinale). PeerJ, 2021, 9: e11755.
[39]	徐悦. pH与盐胁迫对生姜产量品质及相关生理代谢的影响[D]. 泰安: 山东农业大学, 2020.
	XU Y. Effects of pH and salt stress on yield, quality and related physiological metabolism of ginger[D]. Taian: Shandong Agricultural University, 2020. (in Chinese)
[40]	周喆, 张彩霞, 张利义, 王强, 李武兴, 田义, 丛佩华. 苹果LysM基因家族的生物信息学及表达分析. 中国农业科学, 2014, 47(13): 2602-2612. doi: 10.3864/j.issn.0578-1752.2014.13.012.
	ZHOU Z, ZHANG C X, ZHANG L Y, WANG Q, LI W X, TIAN Y, CONG P H. Bioinformatics and expression analysis of the LysM gene family in apple. Scientia Agricultura Sinica, 2014, 47(13): 2602-2612. doi: 10.3864/j.issn.0578-1752.2014.13.012. (in Chinese)
[41]	LIU H, WANG Q Q, YU M M, ZHANG Y Y, WU Y B, ZHANG H X. Transgenic salt-tolerant sugar beet (Beta vulgaris L.) constitutively expressing an Arabidopsis thaliana vacuolar Na⁺/H⁺ antiporter gene, AtNHX3, accumulates more soluble sugar but less salt in storage roots. Plant, Cell & Environment, 2008, 31(9): 1325-1334.
[42]	张梦茹. 桑树Na⁺/H⁺逆向转运蛋白基因的表达特征及Mul-NHX5基因的耐盐功能研究[D]. 泰安: 山东农业大学, 2022.
	ZHANG M R. Study on expression characteristics of Na⁺/H⁺ antiporter gene in mulberry (Morus multicaulis) and the salt-tolerance function of Mul-NHX5 gene[D]. Taian: Shandong Agricultural University, 2022. (in Chinese)
[43]	李茹霞, 顾寅钰, 李萌, 陈传杰, 梁晓艳, 李俊林, 邢延富, 张海洋, 付娆. 菠菜NHX家族基因鉴定及其响应盐胁迫的表达分析. 山东农业科学, 2021, 53(9): 1-7.
	LI R X, GU Y Y, LI M, CHEN C J, LIANG X Y, LI J L, XING Y F, ZHANG H Y, FU R. Identification of NHX family genes and its expression analysis of response to salt stress in spinach (Spinacia oleracea L.). Shandong Agricultural Sciences, 2021, 53(9): 1-7. (in Chinese)
[44]	卢世雄, 许春苗, 何红红, 梁国平, 王萍, 陈佰鸿, 毛娟. 葡萄NHX基因家族的鉴定和表达分析. 果树学报, 2019, 36(3): 266-276.
	LU S X, XU C M, HE H H, LIANG G P, WANG P, CHEN B H, MAO J. Identification and expression analysis of NHX genes family in grape. Journal of Fruit Science, 2019, 36(3): 266-276. (in Chinese)
[45]	王立光. 拟南芥内膜Na⁺, K⁺/H⁺反向转运体研究进展. 生物工程学报, 2019, 35(8): 1424-1432.
	WANG L G. Progress in endosomal Na⁺, K⁺/H⁺ antiporter in Arabidopsis thaliana. Chinese Journal of Biotechnology, 2019, 35(8): 1424-1432. (in Chinese)
[46]	李淼, 李桂祥, 刘伟, 高晓兰, 王孝友, 张安宁. 桃NHX基因家族的全基因组鉴定与表达分析. 山东农业科学, 2021, 53(12): 8-16.
	LI M, LI G X, LIU W, GAO X L, WANG X Y, ZHANG A N. Genome-wide identification and expression analysis of NHX gene family in peach. Shandong Agricultural Sciences, 2021, 53(12): 8-16. (in Chinese)
[47]	郭力. 小鼠耳芥KEA和NHX基因家族的鉴定、进化和表达特征分析[D]. 石河子: 石河子大学, 2022.
	GUO L. Identification, evolution and expression characteristics of KEA and NHX gene families in Arabidopsis pumila[D]. Shihezi: Shihezi University, 2022. (in Chinese)
[48]	王雪花, 韩佳, 马济中, 杨曦婷, 满华丽, 乔亚丽, 高雪琴, 胡琳莉. 大白菜NHX基因家族的鉴定与表达分析. 生物工程学报, 2023, 39(2): 552-565.
	WANG X H, HAN J, MA J Z, YANG X T, MAN H L, QIAO Y L, GAO X Q, HU L L. Identification and expression analysis of NHX gene family in Chinese cabbage. Chinese Journal of Biotechnology, 2023, 39(2): 552-565. (in Chinese)
[49]	DONG J M, LIU C Y, WANG Y Y, ZHAO Y J, GE D P, YUAN Z H. Genome-wide identification of the NHX gene family in Punica granatum L. and their expressional patterns under salt stress. Agronomy, 2021, 11(2): 264.
[50]	WU G Q, WANG J L, LI S J. Genome-wide identification of Na⁺/H⁺ antiporter (NHX) genes in sugar beet (Beta vulgaris L.) and their regulated expression under salt stress. Genes, 2019, 10(5): 401.
[51]	GASTEIGER E, HOOGLAND C, GATTIKER A, DUVAUD S, WILKINS M R, APPEL R D, BAIROCH A. Protein Identification and Analysis Tools on the ExPASy Server. Totowa, NJ: Humana Press, 2005: 571-607.
[52]	朱志刚, 胡洪涛, 石丽桥, 曹春霞, 姚经武, 黄大野, 龙同, 邱正明, 陈伟, 杨自文. 生姜青枯病防治药剂室内筛选及评价. 植物保护, 2017, 43(6): 202-206, 212.
	ZHU Z G, HU H T, SHI L Q, CAO C X, YAO J W, HUANG D Y, LONG T, QIU Z M, CHEN W, YANG Z W. Indoors screening and evaluation of bactericides controlling ginger bacterial wilt. Plant Protection, 2017, 43(6): 202-206, 212. (in Chinese)
[53]	李嘉文, 麻冬梅, 苏立娜, 张玲, 侯汶君, 杭嘉慧. 外源褪黑素对盐胁迫下燕麦幼苗生长及抗氧化系统的影响. 草地学报, 2023, 31(2): 396-403. doi: 10.11733/j.issn.1007-0435.2023.02.011
	LI J W, MA D M, SU L N, ZHANG L, HOU W J, HANG J H. Effects of exogenous melatonin on oat seedling growth and antioxidant system under salt stress. Acta Agrestia Sinica, 2023, 31(2): 396-403. (in Chinese)
[54]	秦曼丽, 朱永兴, 刘续立, 刘燃, 李姗蓉, 张中华, 袁继荣, 刘奕清. 外源壳聚糖对干旱胁迫下生姜幼苗光合特性及水分代谢的影响. 中国瓜菜, 2022, 35(9): 48-56.
	QIN M L, ZHU Y X, LIU X L, LIU R, LI S R, ZHANG Z H, YUAN J R, LIU Y Q. Exogenous chitosan affects photosynthetic characteristics and water metabolism of ginger seedling under drought stress. China Cucurbits and Vegetables, 2022, 35(9): 48-56. (in Chinese)
[55]	PADAN E, VENTURI M, GERCHMAN Y, DOVER N. Na⁺/H⁺ antiporters. Biochimica et Biophysica Acta (BBA)-Bioenergetics, 2001, 1505(1): 144-157.
[56]	齐琪, 马书荣, 徐维东. 盐胁迫对植物生长的影响及耐盐生理机制研究进展. 分子植物育种, 2020, 18(8): 2741-2746.
	QI Q, MA S R, XU W D. Advances in the effects of salt stress on plant growth and physiological mechanisms of salt tolerance. Molecular Plant Breeding, 2020, 18(8): 2741-2746. (in Chinese)
[57]	谢颖悦, 王琦, 王春平, 周冰玉, 周宇, 刘芬, 孙翔宇. 植物响应盐胁迫的机制研究进展. 激光生物学报, 2022, 31(5): 398-403.
	XIE Y Y, WANG Q, WANG C P, ZHOU B Y, ZHOU Y, LIU F, SUN X Y. Progress of studies on the mechanism of plant response to salt stress. Acta Laser Biology Sinica, 2022, 31(5): 398-403. (in Chinese)
[58]	曹岩坡, 代鹏, 戴素英, 贺超兴. 丛枝菌根真菌(AMF)对盐胁迫下芦笋幼苗生长及体内Na⁺、K⁺、Ca²⁺、Mg²⁺含量和分布的影响. 生态学杂志, 2015, 34(6):1699-1704.
	CAO Y P, DAI P, DAI S Y, HE C X. Effects of arbuscular mycorrhizal fungi (AMF) on seedling growth and Na⁺, K⁺, Ca²⁺, Mg²⁺ contents and distribution in asparagus under salt stress. Chinese Journal of Ecology, 2015, 34(6):1699-1704. (in Chinese)
[59]	张远兰, 胡鑫, 郁万文, 国靖, 蔡金峰, 曹福亮, 汪贵斌. Na₂SO₄和Na₂CO₃胁迫对苦楝幼苗渗透调节特性和离子分配的影响. 中南林业科技大学学报, 2021, 41(4): 76-85.
	ZHANG Y L, HU X, YU W W, GUO J, CAI J F, CAO F L, WANG G B. Effects of Na₂SO₄ or Na₂CO₃ on osmotic regulation characteristics and ion distribution in Melia azedarach seedlings. Journal of Central South University of Forestry & Technology, 2021, 41(4): 76-85. (in Chinese)
[60]	梁育勤. 盐胁迫对肯氏南洋杉幼苗生长及离子分布的影响. 厦门大学学报(自然科学版), 2023, 62(1): 144-150.
	LIANG Y Q. Effects of salt stress on growth and ion distribution of Araucaria cunninghamii seedlings. Journal of Xiamen University (Natural Science), 2023, 62(1): 144-150. (in Chinese)
[61]	闫国超, 樊小平, 谭礼, 尹昌, 梁永超. 盐胁迫下添加外源硅提高水稻抗氧化酶活性与钠钾平衡相关基因表达. 植物营养与肥料学报, 2020, 26(11): 1935-1943.
	YAN G C, FAN X P, TAN L, YIN C, LIANG Y C. Exogenous silicon effectively enhances salt stress resistance of rice by upregulating antioxidant enzymes activities and expression of genes related to Na/K homeostasis. Journal of Plant Nutrition and Fertilizers, 2020, 26(11): 1935-1943. (in Chinese)
[62]	BOSNIC P, BOSNIC D, JASNIC J, NIKOLIC M. Silicon mediates sodium transport and partitioning in maize under moderate salt stress. Environmental and Experimental Botany, 2018, 155: 681-687.
[63]	张茂明, 丁俊杰, 刘凯, 杨晓贺, 姚亮亮, 高雪冬, 邱磊, 来永才. 盐碱胁迫下外源硅对水稻绥粳306离子平衡调节的复式研究. 黑龙江农业科学, 2022(11): 22-26.
	ZHANG M M, DING J J, LIU K, YANG X H, YAO L L, GAO X D, QIU L, LAI Y C. Compound study on ion balance regulation of exogenous silicon on rice Suigeng 306 under salt alkali stress. Heilongjiang Agricultural Sciences, 2022(11): 22-26. (in Chinese)
[64]	刘雪华, 宋琎楠, 张玉喜, 侯丽霞, 于延冲, 赵方贵, 刘春英, 董春海, 杨洪兵. 苦荞麦FtNHX1基因的克隆及表达分析. 华北农学报, 2017, 32(4): 49-54. doi: 10.7668/hbnxb.2017.04.008
	LIU X H, SONG J N, ZHANG Y X, HOU L X, YU Y C, ZHAO F G, LIU C Y, DONG C H, YANG H B. Cloning and expression analysis of FtNHX1 in Tartary Buckwheat. Acta Agriculturae Boreali-Sinica, 2017, 32(4): 49-54. (in Chinese)
[65]	于学宁. 刺槐Na⁺/H⁺逆向转运蛋白基因克隆与序列分析及刺槐再生体系建立[D]. 泰安: 山东农业大学, 2008.
	DING X N. Cloning, sequence analysis of the Na⁺/H⁺ antipoter gene and establishment of regeneration system of black locust[D]. Taian: Shandong Agricultural University, 2008. (in Chinese)
[66]	陈瑶, 凌宇, 龙江宇, 范吉标. 外源柠檬酸缓解高羊茅盐胁迫的机制. 草业科学, 2023, 40(2): 511-520.
	CHEN Y, LING Y, LONG J Y, FAN J B. Mechanism of exogenous citric acid alleviating salt stress in Festuca arundinacea. Pratacultural Science, 2023, 40(2): 511-520. (in Chinese)
[67]	梁娟红, 李巧丽, 赖晶, 张小花, 张腾国. 外源ATP对盐胁迫下油菜种子萌发及幼苗生长的影响. 干旱地区农业研究, 2020, 38(3): 89-96.
	LIANG J H, LI Q L, LAI J, ZHANG X H, ZHANG T G. Effects of exogenous ATP on seed germination and seedling growth of Brassica campestris under salt stress. Agricultural Research in the Arid Areas, 2020, 38(3): 89-96. (in Chinese)

基因ID Gene ID	名称 Name	引物序列Primer sequence (5′-3′)		长度 Length (bp)
基因ID Gene ID	名称 Name	正向Forword	反向Reverse	长度 Length (bp)
Maker00056825	ZoNHX1	AATGCCTGGTTTGCTTCCTC	GCTTGTTGGGCTTGCTGTG	99
Maker00009627	ZoNHX2	AGATGGGAGGGTTCACGAG	GACAATGTACCCCCGATCC	116
Maker00078687	ZoNHX3	CAAACCCTTCCGCTTCTCC	GACGACGAGGCTCCGACTA	133
Maker00077763	ZoNHX4	TGCCCTGGCATTTAGTCAG	AGGTCGTCCGACTTCCATC	166
Maker00035912	ZoNHX5	GACAAGAGGTTACAGAGGGATATG	CACCGAAAGTGTAGAAGGAAAG	151
Maker00016804	ZoNHX6	TTGACTCGTCGGCTTTGATC	CTGACCCATGACTATTTGGTAGAA	131
Maker00016508	ZoNHX7	CGATGGTGGTTCACAGAGG	ACCGACGCTGAGCTACCTT	155
Maker00016634	ZoNHX8	ATCCTGTTGCTGTCGTTGC	ATTGCAGTCCCATCGTTCA	143
Maker00016696	ZoNHX9	AGCATGTCGGTTTGCTCAG	TTCTGCAATGGCTTCTTGG	162
Maker00029358	ZoNHX10	TTGTGCATCCCCACTGTTT	AATAGGGGGCAGCAAGAAC	177
Maker00028403	ZoNHX11	CTGGTCGCATGTTGGATTC	TGAAGGGCAAGTGCAAAAG	134
Maker00058140	ZoNHX12	GCTGGGGATCTCTCAGCTC	CAGGTGGCCAATAACGATG	154
Maker00022420	ZoNHX13	TGGAATGGATGCATTGGAC	CAAGCCATGTCCATTTTCG	119
Maker00061543	ZoNHX14	TTTCTCCCGACCATTCTCC	GACGTCGTCAACACCAACC	170
Maker00007292	ZoNHX15	GCTGCGTCTTCCACTCAAC	CCCTCCCCGAAGACAATAC	149
MTCONS_00009943	RBP	CCTATGAAGCGTAGAAACACAAG	GGAAGGACAACATCCCAAATC	123

基因名称 Gene name	基因ID Gene ID	蛋白长度 Protein length (aa)	分子量 Molecular weight (kDa)	等电点 pI	亲水指数 Gravy	不稳定系数 Instability index	亚细胞预测 Predicted location	信号肽 Signal
ZoNHX1	Maker00056825	231	26.01	5.96	0.238	39.92	细胞质 Cytoplasm	有 Yes
ZoNHX2	Maker00009627	1459	163.59	8.88	-0.036	42.16	液泡 Vacuole	无 No
ZoNHX3	Maker00078687	315	34.76	7.08	0.388	46.86	液泡 Vacuole	无 No
ZoNHX4	Maker00077763	425	47.62	8.96	0.394	44.93	液泡 Vacuole	无 No
ZoNHX5	Maker00035912	539	58.62	5.43	0.306	44.86	液泡 Vacuole	无 No
ZoNHX6	Maker00016804	543	60.23	8.99	-0.049	43.39	液泡 Vacuole	无 No
ZoNHX7	Maker00016508	990	111.68	9.08	-0.055	47.28	细胞膜 Cell membrane	无 No
ZoNHX8	Maker00016634	318	34.14	5.42	0.745	33.06	液泡 Vacuole	无 No
ZoNHX9	Maker00016696	833	93.58	6.13	-0.137	41.12	叶绿体 Chloroplast	无无 No
ZoNHX10	Maker00029358	257	28.72	5.27	0.854	46.73	液泡 Vacuole	无 No
ZoNHX11	Maker00028403	292	32.51	6.66	0.273	42.53	液泡 Vacuole	无 No
ZoNHX12	Maker00058140	617	68.4	6.64	0.521	36.21	液泡 Vacuole	无 No
ZoNHX13	Maker00022420	324	36.19	9.24	-0.008	53.85	细胞膜、细胞核 Cell membrane, Nucleus	无 No
ZoNHX14	Maker00061543	683	75.61	9.47	0.443	44.91	液泡 Vacuole	无 No
ZoNHX15	Maker00007292	450	49.88	8.48	0.420	34.1	液泡 Vacuole	无 No

蛋白Protein	α-螺旋 Alpha helix (%)	延伸链 Extended strand (%)	β-转角 Beta turn (%)	不规则卷曲 Random coil (%)
ZoNHX3	39.05	21.59	10.48	28.89
ZoNHX1	44.16	19.91	6.93	29.00
ZoNHX9	45.74	12.48	5.28	36.49
ZoNHX7	45.96	16.77	9.70	27.58
ZoNHX6	41.25	18.23	9.02	31.49
ZoNHX8	54.09	19.81	6.29	19.81
ZoNHX10	42.80	20.23	3.50	33.46
ZoNHX11	48.63	11.30	4.45	35.62
ZoNHX5	44.34	16.88	3.15	35.62
ZoNHX13	40.12	19.75	9.26	30.86
ZoNHX15	41.56	18.67	4.22	35.56
ZoNHX4	46.12	19.29	3.53	31.06
ZoNHX14	40.56	18.74	4.69	36.02
ZoNHX12	41.98	22.37	5.53	30.31
ZoNHX2	34.82	23.92	11.38	29.88

处理 Treatment	根Root	根茎Tuber	茎Stem	叶Leaf
CK	278.93±27.39a	64.59±2.77a	2779.50±17.65a	4040.83±1206.794a
NaCl	7.00±0.67b	4.87±0.21c	17.65±1.25b	16.84±3.20b
SiNP100+NaCl	14.10±0.43b	12.18±1.35b	46.74±4.75b	105.96±7.55b

处理 Treatment	根→根茎(S_K⁺_/Na⁺) Root→Tuber	根茎→茎(S_K⁺_/Na⁺) Tuber→Stem	茎→叶(S_K⁺_/Na⁺) Stem→Leaf
CK	0.23±0.02c	43.16±7.10a	1.44±0.33b
NaCl	0.70±0.06b	3.63±0.37b	0.97±0.24b
SiNP100+NaCl	0.86±0.08a	3.87±0.60b	2.28±0.19a

生姜NHX基因家族成员鉴定及其在硅缓解盐胁迫中的表达特征

Identification of Ginger (Zingiber officinale Roscoe) NHX Gene Family Members and Characterization of Their Expression Patterns in Silicon Alleviating Salt Stress

RichHTML

PDF

赞

可视化

摘要/Abstract

引用本文

使用本文

图/表 17

参考文献 67

相关文章 15

Metrics

本文评价

推荐阅读 0

[1]	戚仁洁, 宁宇, 刘静, 刘之洋, 徐海, 罗志丹, 陈龙正. 基于转录组测序的苦瓜皂苷合成相关基因的鉴定和分析[J]. 中国农业科学, 2024, 57(9): 1779-1793.
[2]	林蔚, 吴水金, 李跃森. 转录组和蛋白质组关联分析解析巴西蕉幼苗响应低温的分子机制[J]. 中国农业科学, 2024, 57(8): 1575-1591.
[3]	高晨曦, 郝陆洋, 胡悦, 李永祥, 张登峰, 李春辉, 宋燕春, 石云素, 王天宇, 黎裕, 刘旭洋. 干旱条件下玉米转座子插入关联的表观调控分析[J]. 中国农业科学, 2024, 57(6): 1034-1048.
[4]	裴书瑶, 曹红霞, 张泽宇, 赵方洋, 李志军. 盆栽番茄对NaCl和Na₂SO₄微咸水灌溉的生理响应[J]. 中国农业科学, 2024, 57(3): 570-583.
[5]	韩旭东, 杨传奇, 张擎, 李亚伟, 杨夏夏, 何佳甜, 薛吉全, 张兴华, 徐淑兔, 刘建超. 玉米氮效率QTL定位和候选基因筛选[J]. 中国农业科学, 2024, 57(21): 4175-4191.
[6]	邵嘉朱, 吕雯, 廖鑫琳, 袁歆瑜, 宋振, 蒋冬花. 大豆根际促生菌的分离、鉴定及其耐盐促生作用[J]. 中国农业科学, 2024, 57(21): 4248-4263.
[7]	马荆鄂, 熊信威, 周敏, 吴斯琪, 韩甜, 饶友生, 王樟凤, 许继国. 基于垂体全长转录组测序分析鸡睾丸性状相关基因[J]. 中国农业科学, 2024, 57(20): 4130-4144.
[8]	代瑛姿, 郭宏扬, 杨志峰, 王宪璞, 许丽丽. 葡萄转录因子VvERF2耐盐功能鉴定[J]. 中国农业科学, 2024, 57(2): 336-348.
[9]	陈菲儿, 张志鹏, 蒋庆雪, 马琳, 王学敏. 紫花苜蓿MsSPL17的克隆及生物学功能验证[J]. 中国农业科学, 2024, 57(17): 3335-3349.
[10]	刘桐, 王志荣, 李伟, 刘洋, 王祥儒, 赖弟利, 何毓琦, 张凯旋, 赵振军, 周美亮. 苦荞bHLH93转录因子响应铝胁迫的功能研究[J]. 中国农业科学, 2024, 57(16): 3127-3141.
[11]	陈文杰, 陈渊, 韦清源, 汤复跃, 郭小红, 陈淑芳, 覃夏燕, 韦荣昌, 梁江. 利用高世代转录组测序挖掘控制南方大豆皱叶症候选基因[J]. 中国农业科学, 2024, 57(15): 2914-2930.
[12]	蔚书涵, 秦小杰, 吴其超, 李玲, 臧德奎, 马燕. 芍药响应细极链格孢侵染的转录组分析[J]. 中国农业科学, 2024, 57(15): 3035-3052.
[13]	徐明睿, 王晓娟, 杨亚莉, 马越飞, 刘万茂, 孙颖. 基于转录组学分析辣椒对磷营养逆境的响应[J]. 中国农业科学, 2024, 57(14): 2827-2846.
[14]	徐梦雨, 王佳洋, 王江波, 唐雯, 陈一恒, 上官凌飞, 房经贵, 卢素文. 不同葡萄种质果皮中香气物质含量及基因表达的差异分析[J]. 中国农业科学, 2024, 57(13): 2635-2650.
[15]	张海青, 张恒涛, 高启明, 姚家龙, 王亚荣, 刘珍珍, 孟祥鹏, 周喆, 阎振立. 转录组分析筛选调控苹果分枝能力的关键基因[J]. 中国农业科学, 2024, 57(10): 1995-2009.
