基于图像特征识别的马铃薯薯皮粗糙度分级研究

doi:10.3864/j.issn.0578-1752.2023.22.006

摘要/Abstract

摘要：

【目的】马铃薯薯皮粗糙度分级研究可以提供块茎外观品质性状无损检测方法，为客观评价品质质量和高通量筛选品种提供理论和实践基础。【方法】以79份马铃薯品种（系）为供试材料，利用相机采集有/无芽眼的薯皮图像。基于MATLAB R2016a软件对薯皮图像预处理，随机选择8份材料用相关函数指标比较图像灰度化、增强及去噪效果。利用灰度共生矩阵（gray level co-occurrence matrix，GLCM）提取图像特征参数角二阶矩（angular second moment，ASM）、熵（entropy，ENT）、对比度（contrast，CON）和相关度（correlation，COR），并确定矩阵最适像素距离（d）。比较两类薯皮图像特征参数间的差异，选择差异较小的薯皮图像特征集进行统计分析和分类识别。构建支持向量机（support vector machines，SVM）和BP神经网络（backpropagation neural network，BPNN）模型对薯皮粗糙度分级分类，模型分级精度评价指标为准确率、精准率、召回率及调和平均数。【结果】加权平均值法进行灰度处理后的薯皮图像纹理结构清晰，图像清晰度评价值为2.5698±0.5959，显著高于平均值法（1.8035±0.4856）和最大值法（1.0535±0.4088）；直方图均衡化增强后的薯皮图像灰度级范围由100—200扩大为0—200，灰度分布更加广泛；中值滤波对3×3窗口下的薯皮图像椒盐噪声去噪效果明显，峰值信噪比（peak signal-to-noise ratio,PSNR）最大（（28.6250±3.9784）Bp），显著高于3×3和5×5窗口下对高斯噪声去噪后的PSNR。通过GLCM（d=4）提取的两类薯皮图像特征参数间差异显著，选择其中差异较小的无芽眼薯皮图像特征集进行统计分析和分类识别，结果表明该特征集变异系数差异明显，对比度变异系数最大（0.40），其次是角二阶矩（0.24）和相关度（0.23）,熵变异系数最小（0.18）。将该特征集作为分类模型输入变量用于薯皮分类，相较于BP神经网络，SVM对马铃薯薯皮粗糙度的整体分类性能较高，准确率为87.5%。其中，对光滑皮和重麻皮的预测准确度和识别能力最高，精准率均为100%，召回率分别为85.7%和100%，调和平均数分别为92.3%和100%。【结论】综合利用本研究提出的图像处理技术及GLCM提取的纹理特征参数能有效表征马铃薯块茎薯皮粗糙度差异；通过构建SVM分类模型可实现基于机器视觉的马铃薯薯皮粗糙度分级，且准确率达87.5%。

关键词: 马铃薯, 薯皮粗糙度, 图像特征, 机器视觉, 支持向量机

Abstract:

【Objective】The classification analysis of potato tuber skin roughness could provide the non-destructive testing methods for tuber appearance quality traits, which would establish the theoretical and practical base for the objective evaluation of tuber quality and high-throughput screening varieties.【Method】Seventy-nine potato varieties (lines) were selected as materials, and the images of tuber skin with and without bud-eyes were taken by camera. The tuber skin images were preprocessed using MATLAB R2016a software. Eight materials were randomly selected to compare the effect of image graying, enhancement and denoising using the correlation function indicators. The image characteristic parameters, angular second moment (ASM), entropy (ENT), contrast (CON) and correlation (COR) were extracted using the gray level co-occurrence matrix (GLCM), and the suitable distance (d) of GLCM were determined. The differences in two types of tuber skin image feature parameters were compared, and the set of tuber skin image features with less difference was selected for statistical analysis and classification recognition. The support vector machine (SVM) and backpropagation neural network (BPNN) models were constructed for tuber skin roughness classification, and the evaluation indexes of model grading accuracy were accuracy, precision, recall and harmonic mean, respectively. 【Result】The texture structure of tuber skin image after grayscale processing using the weighted average method was clear, and the evaluation value of image clarity was 2.5698±0.5959, which was significantly higher than that of the mean method (1.8035±0.4856) and the maximum method (1.0535±0.4088). The gray scale range of tuber skin image after histogram equalization enhancement was expanded from 100-200 to 0-200, which made the gray distribution wider. The salt noise denoising effect of tuber skin images using the median filter under 3×3 sliding windows was obvious, and the peak signal-to-noise ratio (PSNR) was maximum (28.6250±3.9784 Bp), which was significantly higher than that under 3×3 and 5×5 windows. Two types of tuber skin image feature parameters extracted by GLCM (d=4) were significantly different, and the set of tuber skin image features (without bud-eyes) with less difference was selected for statistical analysis and classification recognition. The results indicated that the variation coefficient of these parameters was varied significantly. The variation coefficient of contrast was the largest (0.40), followed by the angular second moment (0.24) and correlation (0.23), and the variation coefficient of entropy was the smallest (0.18). Using the feature set as the input variable of tuber skin classification model, the overall classification performance of SVM was higher than BP neural network, and the accuracy reached 87.5%. Especially, the prediction accuracy and recognizability of SVM for smooth and heavy hemp skins was the highest. The accuracy reached 100%, the recall reached 85.7% and 100%, and the harmonic mean reached 100% and 92.3%, respectively. 【Conclusion】The combination of the image processing techniques presented in this study and the GLCM extracted texture feature parameters could effectively characterize potato tuber skin roughness variations. The tuber skin roughness grading based on machine vision could be achieved by constructing SVM classification model, and the accuracy reached 87.5%.

Key words: Solanum tuberosum, tuber skin roughness, image characteristic, machine vision, support vector machine

唐振三, 袁剑龙, 康亮河, 程李香, 吕汰, 杨晨, 张峰. 基于图像特征识别的马铃薯薯皮粗糙度分级研究[J]. 中国农业科学, 2023, 56(22): 4428-4440.

TANG ZhenSan, YUAN JianLong, KANG LiangHe, CHENG LiXiang, LÜ Tai, YANG Chen, ZHANG Feng. Potato Tuber Skin Roughness Classification Analysis Based on Image Characteristics Recognition[J]. Scientia Agricultura Sinica, 2023, 56(22): 4428-4440.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2023.22.006

https://www.chinaagrisci.com/CN/Y2023/V56/I22/4428

图/表 12

表1

图1

表2

表3

表4

表5

表6

表7

图2

图3

表8

表9

参考文献 44

[1]	国家市场监督管理总局, 中国国家标准化管理委员会. 植物品种特异性、一致性和稳定性测试指南马铃薯:GB/T 19557.28—2018. 北京: 中国标准出版社, 2018.
	State Administration for Market Regulation; Standardization Administration of the People's Republic of China. Guidelines for the conduct of tests for distinctness, uniformity and stability-Potato (Solanum tuberosum L.): GB/T 19557.28-2018. Beijing: Standard Press of China, 2018. (in Chinese)
[2]	韩仲志, 赵友刚. 利用花生荚果图像特征识别品种与检验种子. 作物学报, 2012, 38(3): 535-540.
	HAN Z Z, ZHAO Y G. Variety identification and seed test by peanut pod image characteristics. Acta Agronomica Sinica, 2012, 38(3): 535-540. (in Chinese) doi: 10.3724/SP.J.1006.2012.00535
[3]	王红军, 熊俊涛, 黎邹邹, 邓建猛, 邹湘军. 基于机器视觉图像特征参数的马铃薯质量和形状分级方法. 农业工程学报, 2016, 32(8): 272-277.
	WANG H J, XIONG J T, LI Z Z, DENG J M, ZOU X J. Potato grading method of weight and shape based on imaging characteristics parameters in machine vision system. Transactions of the Chinese Society of Agricultural Engineering, 2016, 32(8): 272-277. (in Chinese)
[4]	姜宏, 于永波, 章翔峰, 陈宇彤. 马铃薯外部品质分级方法综述. 科学技术与工程, 2022, 22(14): 5519-5527.
	JIANG H, YU Y B, ZHANG X F, CHEN Y T. Potato external quality grading methods: a review. Science Technology and Engineering, 2022, 22(14): 5519-5527. (in Chinese)
[5]	周竹, 黄懿, 李小昱, 文东东, 汪成龙, 陶海龙. 基于机器视觉的马铃薯自动分级方法. 农业工程学报, 2012, 28(7): 178-183.
	ZHOU Z, HUANG Y, LI X Y, WEN D D, WANG C L, TAO H L. Automatic detecting and grading method of potatoes based on machine vision. Transactions of the Chinese Society of Agricultural Engineering, 2012, 28(7): 178-183. (in Chinese)
[6]	刘丽, 匡纲要. 图像纹理特征提取方法综述. 中国图象图形学报, 2009, 14(4): 622-635.
	LIU L, KUANG G Y. Overview of image textural feature extraction methods. Journal of Image and Graphics, 2009, 14(4): 622-635. (in Chinese)
[7]	展慧, 李小昱, 王为, 汪成龙, 周竹, 黄懿. 基于机器视觉的板栗分级检测方法. 农业工程学报, 2010, 26(4): 327-331.
	ZHAN H, LI X Y, WANG W, WANG C L, ZHOU Z, HUANG Y. Determination of chestnuts grading based on machine vision. Transactions of the Chinese Society of Agricultural Engineering, 2010, 26(4): 327-331. (in Chinese)
[8]	薄华, 马缚龙, 焦李成. 图像纹理的灰度共生矩阵计算问题的分析. 电子学报, 2006, 34(1): 155-158, 134.
	BO H, MA F L, JIAO L C. Research on computation of GLCM of image texture. Acta Electronica Sinica, 2006, 34(1): 155-158, 134. (in Chinese)
[9]	SINGH K R, CHAUDHURY S. Comparative analysis of texture feature extraction techniques for rice grain classification. IET Image Processing, 2020, 14(11): 2532-2540. doi: 10.1049/ipr2.v14.11
[10]	LADDI A, SHARMA S, KUMAR A, KAPUR P. Classification of tea grains based upon image texture feature analysis under different illumination conditions. Journal of Food Engineering, 2013, 115(2): 226-231. doi: 10.1016/j.jfoodeng.2012.10.018
[11]	SHAFI U, MUMTAZ R, HAQ I U, HAFEEZ M, IQBAL N, SHAUKAT A, ZAIDI S M H, MAHMOOD Z. Wheat yellow rust disease infection type classification using texture features. Sensors, 2021, 22(1): 146. doi: 10.3390/s22010146
[12]	张超, 乔敏, 刘哲, 金虹杉, 宁明宇, 孙海艳. 基于无人机和卫星遥感影像的制种玉米田识别纹理特征尺度优选. 农业工程学报, 2017, 33(17): 98-104.
	ZHANG C, QIAO M, LIU Z, JIN H S, NING M Y, SUN H Y. Texture scale analysis and identification of seed maize fields based on UAV and satellite remote sensing images. Transactions of the Chinese Society of Agricultural Engineering, 2017, 33(17): 98-104. (in Chinese)
[13]	谢元澄, 徐焕良, 谢庄. 基于牛肉大理石花纹标准(BMS)图像的纹理特征分析. 中国农业科学, 2010, 43(24): 5121-5128. doi: 10.3864/j.issn.0578-1752.2010.24.016.
	XIE Y C, XU H L, XIE Z. Analysis of texture features based on beef marbling standards (BMS) images. Scientia Agricultura Sinica, 2010, 43(24): 5121-5128. doi: 10.3864/j.issn.0578-1752.2010.24.016. (in Chinese)
[14]	高程程, 惠晓威. 基于灰度共生矩阵的纹理特征提取. 计算机系统应用, 2010, 19(6): 195-198.
	GAO C C, HUI X W. GLCM-based texture feature extraction. Computer Systems & Applications, 2010, 19(6): 195-198. (in Chinese)
[15]	刘涛, 仲晓春, 孙成明, 郭文善, 陈瑛瑛, 孙娟. 基于计算机视觉的水稻叶部病害识别研究. 中国农业科学, 2014, 47(4): 664-674. doi: 10.3864/j.issn.0578-1752.2014.04.006.
	LIU T, ZHONG X C, SUN C M, GUO W S, CHEN Y Y, SUN J. Recognition of rice leaf diseases based on computer vision. Scientia Agricultura Sinica, 2014, 47(4): 664-674. doi: 10.3864/j.issn.0578-1752.2014.04.006. (in Chinese)
[16]	党满意, 孟庆魁, 谷芳, 顾彪, 胡耀华. 基于机器视觉的马铃薯晚疫病快速识别. 农业工程学报, 2020, 36(2): 193-200.
	DANG M Y, MENG Q K, GU F, GU B, HU Y H. Rapid recognition of potato late blight based on machine vision. Transactions of the Chinese Society of Agricultural Engineering, 2020, 36(2): 193-200. (in Chinese)
[17]	GOMES J F S, LETA F R. Applications of computer vision techniques in the agriculture and food industry: A review. European Food Research and Technology, 2012, 235(6): 989-1000. doi: 10.1007/s00217-012-1844-2
[18]	GUZMÁN E, BAETEN V, PIERNA J A F, GARCÍA-MESA J A. Determination of the olive maturity index of intact fruits using image analysis. Journal of Food Science and Technology, 2015, 52(3): 1462-1470. doi: 10.1007/s13197-013-1123-7 pmid: 25745214
[19]	WANG A C, ZHANG W, WEI X H. A review on weed detection using ground-based machine vision and image processing techniques. Computers and Electronics in Agriculture, 2019, 158(2019): 226-240. doi: 10.1016/j.compag.2019.02.005
[20]	LI B, XU X M, ZHANG L, HAN J W, BIAN C S, LI G C, LIU J G, JIN L P. Above-ground biomass estimation and yield prediction in potato by using UAV-based RGB and hyperspectral imaging. ISPRS Journal of Photogrammetry and Remote Sensing, 2020, 162: 161-172. doi: 10.1016/j.isprsjprs.2020.02.013
[21]	RAZMJOOY N, MOUSAVI B S, SOLEYMANI F. A real-time mathematical computer method for potato inspection using machine vision. Computers & Mathematics with Applications, 2012, 63(1): 268-279. doi: 10.1016/j.camwa.2011.11.019
[22]	纪娜, 何国荣. 基于灰度识别的猕猴桃形状疤痕图像纹理特征提取方法. 自动化与仪器仪表, 2019(1): 159-162.
	JI N, HE G R. Texture feature extraction method of kiwifruit shape scar image based on gray level recognition. Automation & Instrumentation, 2019(1): 159-162. (in Chinese)
[23]	李祚林, 李晓辉, 马灵玲, 胡玥, 唐伶俐. 面向无参考图像的清晰度评价方法研究. 遥感技术与应用, 2011, 26(2): 239-246.
	LI Z L, LI X H, MA L L, HU Y, TANG L L. Research of definition assessment based on no-reference digital image quality. Remote Sensing Technology and Application, 2011, 26(2): 239-246. (in Chinese)
[24]	宋凤菲. 彩色图像灰度化及其效果的客观评价方法研究[D]. 泉州: 华侨大学, 2014.
	SONG F F. Research on objective evaluation method of color image graying and its effect[D]. Quanzhou: Huaqiao University, 2014. (in Chinese)
[25]	杨卫中, 徐银丽, 乔曦, 饶伟, 李道亮, 李振波. 基于对比度受限直方图均衡化的水下海参图像增强方法. 农业工程学报, 2016, 32(6): 197-203.
	YANG W Z, XU Y L, QIAO X, RAO W, LI D L, LI Z B. Method for image intensification of underwater sea cucumber based on contrast-limited adaptive histogram equalization. Transactions of the Chinese Society of Agricultural Engineering, 2016, 32(6): 197-203. (in Chinese)
[26]	孙宏琦, 施维颖, 巨永锋. 利用中值滤波进行图像处理. 长安大学学报(自然科学版), 2003, 23(2): 104-106.
	SUN H Q, SHI W Y, JU Y F. Image processing with medium value filter. Journal of Chang’an University (Natural Science Edition), 2003, 23(2): 104-106. (in Chinese)
[27]	刘祝华. 图像去噪方法的研究[D]. 南昌: 江西师范大学, 2005.
	LIU Z H. Research on image denoising method[D]. Nanchang: Jiangxi Normal University, 2005. (in Chinese)
[28]	DASS A K. Improvising MSN and PSNR for finger-print image noised by GAUSSIAN and SALT & PEPPER. The International Journal of Multimedia & Its Applications, 2012, 4(4): 59-72.
[29]	HARALICK R M, SHANMUGAM K, DINSTEIN I. Textural features for image classification. IEEE Transactions on Systems, Man, and Cybernetics, 1973, SMC-3(6): 610-621. doi: 10.1109/TSMC.1973.4309314
[30]	侯群群, 王飞, 严丽. 基于灰度共生矩阵的彩色遥感图像纹理特征提取. 自然资源遥感, 2013, 25(4): 26-32.
	HOU Q Q, WANG F, YAN L. Extraction of color image texture feature based on gray-level co-occurrence matrix. Remote Sensing for Natural Resources, 2013, 25(4): 26-32. (in Chinese)
[31]	蔡苇荻, 张羽, 刘海燕, 郑恒彪, 程涛, 田永超, 朱艳, 曹卫星, 姚霞. 基于成像高光谱的小麦冠层白粉病早期监测方法. 中国农业科学, 2022, 55(6): 1110-1126. doi: 10.3864/j.issn.0578-1752.2022.06.005.
	CAI W D, ZHANG Y, LIU H Y, ZHENG H B, CHENG T, TIAN Y C, ZHU Y, CAO W X, YAO X. Early detection on wheat canopy powdery mildew with hyperspectral imaging. Scientia Agricultura Sinica, 2022, 55(6): 1110-1126. doi: 10.3864/j.issn.0578-1752.2022.06.005. (in Chinese)
[32]	李智峰, 朱谷昌, 董泰锋. 基于灰度共生矩阵的图像纹理特征地物分类应用. 地质与勘探, 2011, 47(3): 456-461.
	LI Z F, ZHU G C, DONG T F. Application of GLCM-based texture features to remote sensing image classification. Geology and Exploration, 2011, 47(3): 456-461. (in Chinese)
[33]	郑冠楠, 谭豫之, 张俊雄, 李伟. 基于计算机视觉的马铃薯自动检测分级. 农业机械学报, 2009, 40(4): 166-168, 156.
	ZHENG G N, TAN Y Z, ZHANG J X, LI W. Automatic detecting and grading method of potatoes with computer vision. Transactions of the Chinese Society for Agricultural Machinery, 2009, 40(4): 166-168, 156. (in Chinese)
[34]	黄辰, 费继友. 基于图像特征融合的苹果在线分级方法. 农业工程学报, 2017, 33(1): 285-291.
	HUANG C, FEI J Y. Online apple grading based on decision fusion of image features. Transactions of the Chinese Society of Agricultural Engineering, 2017, 33(1): 285-291. (in Chinese)
[35]	魏永康, 杨天聪, 臧少龙, 贺利, 段剑钊, 谢迎新, 王晨阳, 冯伟. 基于无人机多光谱影像特征融合的小麦倒伏监测. 中国农业科学, 2023, 56(9): 1670-1685. doi: 10.3864/j.issn.0578-1752.2023.09.005.
	WEI Y K, YANG T C, ZANG S L, HE L, DUAN J Z, XIE Y X, WANG C Y, FENG W. Monitoring wheat lodging based on UAV multi-spectral image feature fusion. Scientia Agricultura Sinica, 2023, 56(9): 1670-1685. doi: 10.3864/j.issn.0578-1752.2023.09.005. (in Chinese)
[36]	高传新, 殷勇. 数码相机ISO感光度的调整对刑事案件中痕迹检验照相质量的影响. 影像技术, 2008, 21(3): 33-35.
	GAO C X, YIN Y. Influence of digital camera ISO speed setting on the quality of criminological photography for traces detection. Image Technology, 2008, 21(3): 33-35. (in Chinese)
[37]	PHAM L H, TRAN D N N, RHIE C H, JEON J W. Analysis of the smartphone camera exposure effect on laser extraction//2021 International Conference on Electronics, Information, and Communication (ICEIC), 2021.
[38]	唐俊, 邓立苗, 陈辉, 栾涛, 马文杰. 基于机器视觉的玉米叶片透射图像特征识别研究. 中国农业科学, 2014, 47(3): 431-440. doi: 10.3864/j.issn.0578-1752.2014.03.003.
	TANG J, DENG L M, CHEN H, LUAN T, MA W J. Research on maize leaf recognition of characteristics from transmission image based on machine vision. Scientia Agricultura Sinica, 2014, 47(3): 431-440. doi: 10.3864/j.issn.0578-1752.2014.03.003. (in Chinese)
[39]	杨嘉能. 基于直方图均衡的图像增强算法优化研究[D]. 乌鲁木齐: 新疆大学, 2021.
	YANG J N. Optimization of image enhancement algorithm based on histogram equalization[D]. Urumqi: Xinjiang University, 2021. (in Chinese)
[40]	陈永亮. 灰度图像的直方图均衡化处理研究[D]. 合肥: 安徽大学, 2014.
	CHEN Y L. Research on histogram equalization processing of gray image[D]. Hefei: Anhui University, 2014. (in Chinese)
[41]	宁媛, 李皖. 图像去噪的几种方法分析比较. 贵州工业大学学报(自然科学版), 2005, 34(4): 63-66.
	NING Y, LI W. Analysis and comparison of some techniques on image denoising. Journal of Guizhou University of Technology (Natural Science Edition), 2005, 34(4): 63-66. (in Chinese)
[42]	杨光义. 图像质量评价及其在图像去噪中的应用研究[D]. 武汉: 武汉大学, 2018.
	YANG G Y. Image quality evaluation and its application in image denoising[D]. Wuhan: Wuhan University, 2018. (in Chinese)
[43]	苑丽红, 付丽, 杨勇, 苗静. 灰度共生矩阵提取纹理特征的实验结果分析. 计算机应用, 2009, 29(4): 1018-1021.
	YUAN L H, FU L, YANG Y, MIAO J. Analysis of texture feature extracted by gray level co-occurrence matrix. Journal of Computer Applications, 2009, 29(4): 1018-1021. (in Chinese) doi: 10.3724/SP.J.1087.2009.01018
[44]	王璨, 李志伟. 利用融合高度与单目图像特征的支持向量机模型识别杂草. 农业工程学报, 2016, 32(15): 165-174.
	WANG C, LI Z W. Weed recognition using SVM model with fusion height and monocular image features. Transactions of the Chinese Society of Agricultural Engineering, 2016, 32(15): 165-174. (in Chinese)

品系编号 Variety code	CIP编号 CIP entry	品系编号 Variety code	CIP编号 CIP entry	品系编号 Variety code
G4	CIP 392617.54	G72	CIP 395436.8	Innovator
G8	CIP 393227.66	G74	CIP 396311.1	1412-1
G9	CIP 393228.67	G82	CIP 397044.25	1428-1-35
G12	CIP 392657.171	G84	CIP 397065.2	2137
G13	CIP 393280.64	G89	CIP 397079.26	1867
G14	CIP 391047.34	G96	CIP 397197.9	215
G16	CIP 393085.5	G97	CIP 398014.2	Lucinda
G17	CIP 398192.213	G99	CIP 388615.22	0933-5
G18	CIP 398098.119	G101	CIP 390637.1	0933-1
G19	CIP 398098.203	G102	CIP 391180.6	1416-5
G27	CIP 398208.33	G104	CIP 391724.1	0730-185
G31	CIP 301029.18	G106	CIP 392740.4	1425-1-13
G32	CIP 301040.63	G108	CIP 392759.1	0938-2-7
G33	CIP 300046.22	G113	CIP 397035.26	0730-180
G35	CIP 300054.29	G115	CIP 302476.108	0730-156
G36	CIP 300056.33	G118	CIP 304350.100	1425-1-27
G42	CIP 300101.11	G121	CIP 304371.67	0730-211
G44	CIP 385499.11	G122	CIP 304383.41	0916-1
G47	CIP 388972.22	G133	CIP 394904.20	0902-1-9
G51	CIP 392781.1	希森6号Xisen no.6		0938-2-18
G52	CIP 392797.22	大西洋Atlantic		0941-1-17
G57	CIP 394034.7	早大白 Zaodabai		0941-1-1
G62	CIP 394613.32	Memphis		0902-4
G63	CIP 394614.117	费乌瑞它Favorita
G65	CIP 395186.6	布尔班克 Burbank
G67	CIP 395195.7	陇薯10号 Longshu no.10
G68	CIP 395196.4	荷兰15号 Helan no.15
G70	CIP 395432.51	夏波蒂Shepody

类别Category	A	B	C	D
重麻皮 Heavy hemp skin
麻皮 Hemp skin
略麻皮 Slightly hemp skin
光滑皮 Smooth skin

类别 Category	样本数 Number of samples	类平均标准差 Class mean standard deviation
A	8	1.8035±0.4856c	C-A	0.7663
B	8	1.0535±0.4088b	C-B	1.5163
C	8	2.5698±0.5959a	C-C	0

类别 Category	A	B	C	D
重麻皮 Heavy hemp skin
麻皮 Hemp skin
略麻皮 Slightly hemp skin
光滑皮 Smooth skin

类别 Category	原始图像 Original images	3×3窗口 3×3 Window		5×5窗口 5×5 Window
类别 Category	原始图像 Original images	高斯噪声 Gaussian noise	椒盐噪声 Salt and pepper noise	高斯噪声 Gaussian noise	椒盐噪声 Salt and pepper noise
A
B
C
D
