基于叶片反射光谱估测水稻氮营养指数

doi:10.3864/j.issn.0578-1752.2021.21.004

摘要/Abstract

摘要：

【目的】基于叶片反射光谱建立快速、无损监测水稻氮营养指数（nitrogen nutrition index,NNI）的估算模型。【方法】2018—2019年开展2个水稻品种（徽两优898和Y两优900）及5个氮肥梯度（施氮量为0、75、150、225和300 kg·hm^-2,分别记为N₀、N₁、N₂、N₃、N₄）的田间小区试验,测定关键生育期不同叶位叶片反射光谱和植株NNI,构建多种光谱指数的水稻NNI监测模型。【结果】单叶及叶位组合的敏感波段均分布在540 nm的绿光波长处,其与近红外波段构成的窄波段比值指数SR（R₉₀₀,R₅₄₀）可较好反演水稻NNI。但不同叶位叶片窄波段比值指数与水稻NNI的预测精度表现不同,顶3叶（L₃）预测精度最好（R²=0.731,RMSE =0.130,RE=11.6%）,顶2叶（L₂）次之（R²=0.707,RMSE =0.136,RE =12.2%）,顶1叶（L₁）最差（R²=0.443,RMSE =0.187,RE =14.7%）;顶2叶和顶3叶组合平均光谱（L₂₃）的预测精度优于单叶水平和其他叶位组合（R²=0.740,RMSE =0.128,RE =11.5%）。再将窄波段比值指数SR（R₉₀₀,R₅₄₀）近红外与绿光区域分别重采样50 nm和10 nm,所构建的宽波段比值指数SR[AR_{（900±50）},AR_{（540±10）}]模型精度较SR（R₉₀₀,R₅₄₀）未明显降低,且在L₂₃水平下2个模型的模型精度和预测精度基本一致（R²=0.740,RMSE =0.128,RE =11.5%）。水稻NNI小于1时与产量呈线性的正相关关系（P<0.05）,大于1时产量趋于平稳。【结论】L₂和L₃叶片反射光谱为监测水稻NNI的敏感叶位,其中叶位组合L₂₃可提高模型预测精度。基于叶片反射光谱构建的多种波段比值指数（SR（R₉₀₀,R₅₄₀）和SR[AR_{（900±50）},AR_{（540±10）}]）可快速估测水稻NNI,从而为不同传感器对水稻氮营养指数估测监测研究提供了理论依据。

关键词: 叶片, 水稻, 氮营养指数, 比值指数, 模型, 波段宽度

Abstract:

【Objective】The research aimed to analyze the relationship between rice (Oryza sativa L.) nitrogen nutrition index (NNI) and leaf spectral reflectance characteristics of leaf on different positions, so as to provide an effective method for nondestructive and timely evaluation of NNI in rice.【Method】Field experiments were conducted with different N application rates and rice cultivars across two growing seasons during 2018-2019, and the leaf hyperspectral reflectance of 350-2 500 nm of leaf on different positions and the plant NNI were measured during key fertility growth stages to construct a variety of spectral index model for rice NNI monitoring.【Result】The results indicated that green band (540 nm) at leaf level was the sensitive band for estimating NNI, and narrow band ratio index SR (R₉₀₀, R₅₄₀) composed of near infrared band and green band could be used to retrieve NNI of rice. However, the prediction accuracy of narrow band ratio index and rice NNI of leaf on different positions were different. In terms of prediction accuracy, the best single leaf position was the third leaf (L₃) from the top (R²=0.731, RMSE=0.130, RE=11.6%), the second leaf (L₂) from the top followed (R ²=0.707, RMSE=0.136, RE=12.2%), and the top one (L₁) was the worst (R ²=0.443, RMSE=0.187, RE=14.7%). The averaged spectra of L₂ and L₃ (L₂₃) was the optimum leaf spectra combination, which contributed to improving the predictability to NNI(R ²=0.740, RMSE=0.128, RE=11.5%). The samples were resampled at 50 nm and 10 nm in the near infrared region (900 nm) and green region (540 nm) respectively, and the accuracy of the wide band ratio index SR (AR_(900±50), AR_(540±10)) was not significantly lower than that of SR (R₉₀₀, R₅₄₀). The model accuracy and prediction accuracy of the two models were basically the same at L₂₃. When the NNI of rice was less than 1, there was a significant positive linear correlation with the yield, and then it tended to be stable. 【Conclusion】The results showed that the reflectance spectra of L₂ and L₃ leaves were sensitive for monitoring NNI for rice, and L₂₃ could improve the prediction accuracy of the model. Multiple band ratio indices SR (R₉₀₀, R₅₄₀) and SR (AR_(900±50), AR_(540±10)) based on leaf reflectance spectra could be used to rapidly estimate rice NNI, which provided a theoretical basis for monitoring rice NNI with various sensors.

Key words: leaf, rice(Oryza sativa L.), nitrogen nutrition index, ratio index, model, band width

徐浩聪, 姚波, 王权, 陈婷婷, 朱铁忠, 何海兵, 柯健, 尤翠翠, 吴小文, 郭爽爽, 武立权. 基于叶片反射光谱估测水稻氮营养指数[J]. 中国农业科学, 2021, 54(21): 4525-4538.

XU HaoCong, YAO Bo, WANG Quan, CHEN TingTing, ZHU TieZhong, HE HaiBing, KE Jian, YOU CuiCui, WU XiaoWen, GUO ShuangShuang, WU LiQuan. Determination of Suitable Band Width for Estimating Rice Nitrogen Nutrition Index Based on Leaf Reflectance Spectra[J]. Scientia Agricultura Sinica, 2021, 54(21): 4525-4538.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2021.21.004

https://www.chinaagrisci.com/CN/Y2021/V54/I21/4525

图/表 13

表1

图1

表2

表3

图2

图3

图4

表4

表5

图5

图6

表6

图7

参考文献 38

[1]	ZHAO D, REDDY K R, KAKANI V G, REDDY V R. Nitrogen deficiency effects on plant growth, leaf photosynthesis, and hyperspectral reflectance properties of sorghum. European Journal of Agronomy, 2005, 22(4):391-403. doi: 10.1016/j.eja.2004.06.005
[2]	GASTAL F, BLANGER G. The effects of nitrogen fertilization and the growing season on photosynthesis of field-grown tall fescue (Festuca arundinacea Schreb.) canopies. Annals of Botany, 1993, 72(5):401-408. doi: 10.1006/anbo.1993.1125
[3]	PENG S B, BURESH R J, HUANG J L, YANG J C, ZOU Y B, ZHONG X H, WANG G H, ZHANG F S. Strategies for overcoming low agronomic nitrogen use efficiency in irrigated rice systems in China. Field Crops Research, 2006, 96(1):37-47. doi: 10.1016/j.fcr.2005.05.004
[4]	BENTJE B, BJERG P L, SONG X F, JAKOBSEN R. Field scale interaction and nutrient exchange between surface water and shallow groundwater in the Baiyang Lake region, North China Plain. Journal of Environmental Sciences, 2016, 45(7):60-75. doi: 10.1016/j.jes.2015.11.021
[5]	ZHAO B, ATA-UL-KARIM S T, LIU Z D, NING D F, XIAO J F, LIU Z G, QIN A Z, NAN J Q, DUAN A W. Development of a critical nitrogen dilution curve based on leaf dry matter for summer maize. Field Crops Research, 2017, 208:60-68. doi: 10.1016/j.fcr.2017.03.010
[6]	贺志远, 朱艳, 李艳大, 刘小军, 曹强, 曹卫星, 汤亮. 中国南方双季稻氮营养指数及产量估算模型研究. 南京农业大学学报, 2017, 40(1):11-19.
	HE Z Y, ZHU Y, LI Y D, LIU X J, CAO Q, CAO W X, TANG L. Study on estimation model for nitrogen nutrition index and yield on double cropping rice in southern China. Journal of Nanjing Agricultural University, 2017, 40(1):11-19. (in Chinese)
[7]	杜宇笑, 李鑫格, 张羽, 程涛, 刘小军, 田永超, 朱艳, 曹卫星, 曹强. 不同产量水平下稻茬小麦的氮素营养指标特征. 植物营养与肥料学报, 2020, 26(8):1420-1429.
	DU Y X, LI X G, ZHANG Y, CHENG T, LIU X J, TIAN Y C, ZHU Y, CAO W X, CAO Q. Variation in nitrogen status indicators with grain yield level for winter wheat after rice. Journal of Plant Nutrition and Fertilizers, 2020, 26(8):1420-1429. (in Chinese)
[8]	贾彪, 付江鹏. 基于叶面积指数构建滴灌玉米营养生长期临界氮稀释曲线. 农业工程学报, 2020, 36(6):66-73.
	JIA B, FU J P. Critical nitrogen dilution curve of drip-irrigated maize at vegetative growth stage based on leaf area index. Transactions of the Chinese Society of Agricultural Engineering, 2020, 36(6):66-73. (in Chinese)
[9]	马露露, 吕新, 张泽, 马革新, 海兴岩. 基于临界氮浓度的滴灌棉花氮素营养诊断模型研究. 农业机械学报, 2018, 49(2):277-283.
	MA L L, LÜ X, ZHANG Z, MA G X, HAI X Y. Establishment of nitrogen nutrition diagnosis model for drip-irrigation cotton based on critical nitrogen concentration. Transactions of the Chinese Society for Agricultural Machinery, 2018, 49(2):277-283. (in Chinese)
[10]	ZHAO B, LIU Z D, ATA-UL-KARIM S T, XIAO J F, LIU Z G, QIN A Z, NING D F, NAN J Q, DUAN A W. Rapid and nondestructive estimation of the nitrogen nutrition index in winter barley using chlorophy Ⅱ measurements. Field Crops Research, 2016, 185:59-68. doi: 10.1016/j.fcr.2015.10.021
[11]	AKRAM M. Effects of nitrogen application on chlorophyll content, water relations, and yield of maize hybrids under saline conditions. Communications in Soil Science and Plant Analysis, 2014, 45(10):1336-1356. doi: 10.1080/00103624.2013.875199
[12]	SIMS D A, GAMON J A. Relationships between leaf pigment content and spectral reflectance across a wide range of species, leaf structures and developmental stages. Remote Sensing of Environment, 2002, 81(2/3):337-354. doi: 10.1016/S0034-4257(02)00010-X
[13]	GITELSON A, MERZLYAK M N. Spectral reflectance changes associated with autumn senescence of Aesculus hippocastanum L. and Acer platanoides L. leaves spectral features and relation to chlorophyll estimation. Journal of Plant Physiology, 1994, 143(3):286-292. doi: 10.1016/S0176-1617(11)81633-0
[14]	GUPTA R K, VIJAYAN D, PRASAD T S. Comparative analysis of red-edge hyperspectral indices. Advances in Space Research, 2003, 32(11):2217-2222. doi: 10.1016/S0273-1177(03)90545-X
[15]	VOGELMANN J E, ROCK B N, MOSS D M. Red edge spectral measurements from sugar maple leaves. International Journal of Remote Sensing, 1993, 14(8):1563-1575. doi: 10.1080/01431169308953986
[16]	CHEN P F, HABOUDANE D, TREMBLAY N, WANG J H, VIGNEAULT P, LI B G. New spectral indicator assessing the efficiency of crop nitrogen treatment in corn and wheat. Remote Sensing of Environment, 2010, 114(9):1987-1997. doi: 10.1016/j.rse.2010.04.006
[17]	CHO M A, SKIDMORE A K. A new technique for extracting the red edge position from hyperspectral data: The linear extrapolation method. Remote Sensing of Environment, 2006, 101(2):181-193. doi: 10.1016/j.rse.2005.12.011
[18]	XUE L H, CAO W X, LUO W H, DAI T B, ZHU Y. Monitoring leaf nitrogen status in rice with canopy spectral reflectance. Agronomy Journal, 2004, 96(1):135-142. doi: 10.2134/agronj2004.0135
[19]	曾水生, 李艳大, 舒时富, 陈立才, 叶春, 贺志远, 张晨, 曾一凡. 光谱技术在水稻生长监测中的应用研究进展. 农学学报, 2015, 5(2):100-104.
	ZENG S S, LI Y D, SHU S F, CHEN L C, YE C, HE Z Y, ZHANG C, ZENG Y F. Application of spectrum technique in monitoring rice growth. Journal of Agriculture, 2015, 5(2):100-104. (in Chinese)
[20]	梁惠平, 刘湘南. 玉米氮营养指数的高光谱计算模型. 农业工程学报, 2010, 26(1):264-269.
	LIANG H P, LIU X N. Model for calculating corn nitrogen nutrition index using hyper-spectral data. Transactions of the Chinese Society of Agricultural Engineering, 2010, 26(1):264-269. (in Chinese)
[21]	王仁红, 宋晓宇, 李振海, 杨贵军, 郭文善, 谭昌伟, 陈立平. 基于高光谱的冬小麦氮素营养指数估测. 农业工程学报, 2014, 30(19):191-198.
	WANG R H, SONG X Y, LI Z H, YANG G J, GUO W S, TAN C W, CHEN L P. Estimation of winter wheat nitrogen nutrition index using hyperspectral remote sensing. Transactions of the Chinese Society of Agricultural Engineering, 2014, 30(19):191-198. (in Chinese)
[22]	姚霞. 小麦冠层和单叶氮素营养指标的高光谱监测研究[D]. 南京:南京农业大学, 2009.
	YAO X. Monitoring nitrogen stayus at canopy and leaf scales with hyperspectral sensing in wheat[D]. Nanjing: Nanjing Agricultuarl University, 2009. (in Chinese)
[23]	田永超, 杨杰, 姚霞, 曹卫星, 朱艳. 利用叶片高光谱指数预测水稻群体叶层全氮含量. 作物学报, 2010, 36(9):1529-1537.
	TIAN Y C, YANG J, YAO X, CAO W X, ZHU Y. Monitoring canopy leaf nitrogen concentration based on leaf hyperspectral indices in rice. Acta Agronomica Sinica, 2010, 36(9):1529-1537. (in Chinese)
[24]	李刚华, 薛利红, 尤娟, 王绍华, 丁艳锋, 吴昊, 杨文祥. 水稻氮素和叶绿素SPAD叶位分布特点及氮素诊断的叶位选择. 中国农业科学, 2007, 40(6):1127-1134.
	LI G H, XUE L H, YOU J, WANG S H, DING Y F, WU H, YANG W X. Spatial distribution of leaf N content and SPAD value and determination of the suitable leaf for N diagnosis in rice. Scientia Agricultura Sinica, 2007, 40(6):1127-1134. (in Chinese)
[25]	赵犇, 姚霞, 田永超, 刘小军, 曹卫星, 朱艳. 基于上部叶片SPAD值估算小麦氮营养指数. 生态学报, 2013, 33(3):916-924. doi: 10.5846/stxb
	ZHAO B, YAO X, TIAN Y C, LIU X J, CAO W X, ZHU Y. Estimation of nitrogen nutrient index on SPAD value of top leaves in wheat. Acta Ecologica Sinica, 2013, 33(3):916-924. (in Chinese) doi: 10.5846/stxb
[26]	INOUE Y, SAKAIYA E, ZHU Y, TAKAHASHI W. Diagnostic mapping of canopy nitrogen content in rice based on hyperspectral measurements. Remote Sensing of Environment, 2012, 126:210-221. doi: 10.1016/j.rse.2012.08.026
[27]	TIAN Y C, GU K J, CHU X, YAO X, CAO W X, ZHU Y. Comparison of different hyperspectral vegetation indices for canopy leaf nitrogen concentration estimation in rice. Plant and Soil, 2014, 376(1/2):193-209. doi: 10.1007/s11104-013-1937-0
[28]	宋红燕, 胡克林, 彭希. 基于高光谱技术的覆膜旱作水稻植株氮含量及籽粒产量估算. 中国农业大学学报, 2016, 21(8):27-34.
	SONG H Y, HU K L, PENG X. Crop nitrogen content diagnosis and yield estimation in ground cover rice production system based on hyperspectral data. Journal of China Agricultural University, 2016, 21(8):27-34. (in Chinese)
[29]	LEMAIRE G, GASTAL F, SALETTE J. N Uptake and Distribution in Plant Canopies. Springer: Berlin, 1997, 25:3-45.
[30]	姚霞, 朱艳, 冯伟, 田永超, 曹卫星. 监测小麦叶片氮积累量的新高光谱特征波段及比值植被指数. 光谱学与光谱分析, 2009, 29(8):2191-2195.
	YAO X, ZHU Y, FENG W, TIAN Y C, CAO W X. Exploring novel hyperspectral band and key index for leaf nitrogen accumulation in wheat. Spectroscopy and Spectral Analysis, 2009, 29(8):2191-2195. (in Chinese)
[31]	STROPPIANA D, MBOSCHETTI M, BRIVIO P A, BOCCHI S. Plant nitrogen concentration in paddy rice from field canopy hyperspectral radiometry. Field Crops Research, 2009, 111(1/2):119-129. doi: 10.1016/j.fcr.2008.11.004
[32]	杜宇笑, 李鑫格, 王雪, 刘小军, 田永超, 朱艳, 曹卫星, 曹强. 不同产量水平稻茬小麦氮素需求特征研究. 作物学报, 2020, 46(11):1780-1789. doi: 10.3724/SP.J.1006.2020.01027
	DU Y X, LI X G, WANG X, LIU X J, TIAN Y C, ZHU Y, CAO W X, CAO Q. Nitrogen demand characteristics with different grain yield levels for wheat after rice. Acta Agronomica Sinica, 2020, 46(11):1780-1789. (in Chinese) doi: 10.3724/SP.J.1006.2020.01027
[33]	ATA-UL-KARIM S T, LIU X J, LU Z Z, ZHENG H B, CAO W X, ZHU Y. Estimation of nitrogen fertilizer requirement for rice crop using critical nitrogen dilution curve. Field Crops Research, 2017, 201:32-40. doi: 10.1016/j.fcr.2016.10.009
[34]	陈志强, 王磊, 白由路, 杨俐苹, 卢艳丽, 王贺, 王志勇. 玉米叶片的光谱响应及其氮素含量预测研究. 光谱学与光谱分析, 2013, 33(4):1066-1070.
	CHEN Z Q, WANG L, BAI Y L, YANG L P, LU Y L, WANG H, WANG Z Y. Spectral response of maize leaves and prediction of their nitrogen content. Spectroscopy and Spectral Analysis, 2013, 33(4):1066-1070. (in Chinese)
[35]	张银杰, 王磊, 白由路, 杨俐苹, 卢艳丽, 张静静, 李格. 基于高光谱分析的玉米叶片氮含量分层诊断研究. 光谱学与光谱分析, 2019, 39(9):2829-2835.
	ZHANG Y J, WANG L, BAI Y L, YANG L P, LU Y L, ZHANG J J, LI G. Nitrogen nutrition diagnostic based on hyperspectral analysis about different layers leaves in maize. Spectroscopy and Spectral Analysis, 2019, 39(9):2829-2835. (in Chinese)
[36]	刘忠, 万炜, 黄晋宇, 韩已文, 王佳莹. 基于无人机遥感的农作物长势关键参数反演研究进展. 农业工程学报, 2018, 34(24):60-71.
	LIU Z, WAN W, HUANG J Y, HAN Y W, WANG J Y. Progress on key parameters inversion of crop growth based on unmanned aerial vehicle remote sensing. Transactions of the Chinese Society of Agricultural Engineering, 2018, 34(24):60-71. (in Chinese)
[37]	李振. 基于高光谱玉米氮素营养与生长指标的监测[D]. 泰安: 山东农业大学, 2012.
	LI Z. Monitoring nitrogen status and growth characters with hyper-spectral in maize[D]. Taian:Shandong Agricutural University, 2012. (in Chinese)
[38]	ZHAO B, DUAN A W, ATA-UL-KARIM S T, LIU Z D, CHEN Z F, GONG Z H, ZHANG J Y, XIAO J F, LIU Z G, QIN A Z, NING D F. Exploring new spectral bands and vegetation indices for estimating nitrogen nutrition index of summer maize. European Journal of Agronomy, 2018, 93:113-125. doi: 10.1016/j.eja.2017.12.006

年份 Year	有机质 Organic matter (g·kg^-1)	全氮 Total N (g·kg^-1)	有效磷 Available P (mg·kg^-1)	速效钾 Available K (mg·kg^-1)	pH
2018	32.36	2.03	24.80	211.42	5.11
2019	30.89	1.77	25.97	245.52	5.54

光谱指数 Spectral index	计算公式 Algorithm	参考文献 Reference
比值光谱指数 Simple ratio spectral index (SR)	R₁ / R₂	本研究 This study
归一化差值光谱指数 Normalized difference spectral index (ND)	(R₁ - R₂)/(R₁ + R₂)	本研究This study
修正红边归一化指数 Modified red edge normalized difference vegetation index (MSR 705)	(R₇₅₀-R₇₀₅)/(R₇₅₀+2×R₄₄₅)	[12]
红边归一化指数 Red edge normalized difference vegetation index (ND 705)	(R₇₅₀- R₇₀₅)/(R₇₅₀+ R₇₀₅)	[13]
比值指数-ldB Ratio index-1dB (RI-ldB)	R₇₃₅/R₇₂₀	[14]
Vogelmann 红边指数 Vogelman red edge index (VOG)	R₇₄₀/ R₇₂₀	[15]
双峰冠层氮指数 Double-peak canopy nitrogen index (DCNI)	(R₇₂₀-R₇₀₀)/(R₇₀₀-R₆₇₀)/(R₇₂₀-R₆₇₀+0.03)	[16]
线性内插法红边位置 Red edge position: linear interpolation method (REP_LI)	700+40×[(R₆₇₀+R₇₈₀)/2-R₇₀₀] /(R₇₄₀-R₇₀₀)	[17]
比值植被指数II Ratio Vegetation Index Ⅱ(RVI Ⅱ)	R₈₁₀/ R₅₆₀	[18]

分组因子 Grouping factor	变异来源 Variation source	平方和 Sum of squares	自由度 df	均方 Mean square	F值 F-value	P值 P-value
氮肥处理 Nitrogen rate	组间 Between groups	2.643	4	0.661	31.745	0
	组内 Within groups	1.561	75	0.021
	总计 Total	4.203	79
品种 Variety	组间 Between groups	0.231	3	0.077	1.475	0.228
	组内 Within groups	3.972	76	0.052
	总计 Total	4.203	79
生育期 Growth stage	组间 Between groups	0.094	1	0.094	1.782	0.186
	组内 Within groups	4.109	78	0.053
	总计 Total	4.203	79

时期 Stage	叶位 Leaf position	MSR705	ND705	RI-1dB	VOG	DCNI	REP_LI	RVI Ⅱ
分蘖期 Tillering stage	顶1叶（L₁）	0.483**	0.534**	0.561**	0.564**	0.607**	0.478**	0.553**
	顶2叶（L₂）	0.555**	0.479**	0.444**	0.443**	0.367**	0.436**	0.563**
	顶3叶（L₃）	0.311**	0.394**	0.406**	0.409**	0.718**	0.488**	0.398**
	顶1、2叶平均（L₂₃）	0.441**	0.456**	0.446**	0.448**	0.555**	0.488**	0.499**
拔节期 Jointing stage	顶1叶（L₁）	0.568**	0.541**	0.538**	0.536**	0.253**	0.465**	0.657**
	顶2叶（L₂）	0.717**	0.665**	0.648**	0.649**	0.770**	0.538**	0.792**
	顶3叶（L₃）	0.765**	0.742**	0.718**	0.717**	0.652**	0.669**	0.810**
	顶2、3叶平均（L₂₃）	0.791**	0.748**	0.721**	0.721**	0.721**	0.655**	0.835**
孕穗期 Booting stage	顶1叶（L₁）	0.620**	0.635**	0.711**	0.712**	0.278**	0.629**	0.686**
	顶2叶（L₂）	0.781**	0.812**	0.833**	0.835**	0.476**	0.772**	0.859**
	顶3叶（L₃）	0.730**	0.755**	0.758**	0.758**	0.485**	0.714**	0.783**
	顶2、3叶平均（L₂₃）	0.763**	0.790**	0.807**	0.808**	0.490**	0.749**	0.837**
抽穗期 Heading stage	顶1叶（L₁）	0.462**	0.511**	0.510**	0.516**	0.519**	0.557**	0.521**
	顶2叶（L₂）	0.586**	0.652**	0.684**	0.690**	0.714**	0.592**	0.730**
	顶3叶（L₃）	0.546**	0.589**	0.635**	0.643**	0.600**	0.432**	0.706**
	顶2、3叶平均（L₂₃）	0.593**	0.649**	0.696**	0.703**	0.646**	0.538**	0.734**

叶位 Leaf position	MSR705	ND705	RI-1dB	VOG	DCNI	REP_LI	RVI Ⅱ
顶1叶（L₁）	0.571**	0.576**	0.570**	0.572**	0.477**	0.584**	0.621**
顶2叶（L₂）	0.708**	0.726**	0.741**	0.745**	0.575**	0.710**	0.798**
顶3叶（L₃）	0.629**	0.660**	0.698**	0.703**	0.577**	0.543**	0.739**
顶2、3叶平均（L₂₃）	0.676**	0.702**	0.733**	0.738**	0.587**	0.642**	0.781**
样本量 160 个 Sample volume is 160
