基于品质指标预测北京烤鸭的中心温度

doi:10.3864/j.issn.0578-1752.2020.08.014

摘要/Abstract

摘要：

【目的】解决烤鸭传统挂炉烤制过程中中心温度难以在线精确监测的问题。【方法】通过测定烤鸭的品质指标,利用多元线性回归、偏最小二乘回归、支持向量回归、人工神经网络等方法对北京烤鸭中心温度进行在线客观预测。【结果】烤鸭胸肉的L*、a*、b*、脱氧肌红蛋白、氧合肌红蛋白、高铁肌红蛋白、水分含量、脂肪含量、蛋白二级结构等指标均可用于有效识别北京烤鸭的中心温度;线性模型多元线性回归和偏最小二乘回归的预测集决定系数R ²_C分别为0.9543和0.9384,均方根误差SEC分别为5.8205℃和6.7634℃,MLR模型预测效果优于偏最小二乘回归模型;非线性模型支持向量回归优于人工神经网络模型,其预测集决定系数R ²_C和交叉验证决定系数R ²_CV分别为0.9837和0.9496,均方根误差SEC和交叉验证均方根误差SECV分别为3.5215℃和6.1236℃,北京烤鸭中心温度预测模型构建以支持向量回归模型效果最好;支持向量回归验证集的决定系数R ²_V较高,达到0.9748,均方根误差SEV为5.5204℃,结合建模结果得出支持向量回归模型预测挂炉烤制北京烤鸭的中心温度效果最佳。【结论】北京烤鸭胸肉的色度、肌红蛋白、水分含量、脂肪含量、蛋白二级结构等可有效识别北京烤鸭的中心温度;基于品质指标的SVR模型可准确预测烤鸭的中心温度。

关键词: 北京烤鸭, 中心温度, 品质, 预测模型

Abstract:

【Objective】 The aim of this study was to solve the problem in detecting center temperature of Beijing roast duck during traditional Gua-lu roasting accurately and timely. 【Method】 The prediction models of center temperature were established by using multiple linear regression, partial least-squares regression, support vector regression and artificial neural network according to the quality indicators. 【Result】 The results showed that the models were effective to identify center temperature of Beijing roast duck by L*, a*, b*, deoxymyoglobin, oxymyoglobin, metmyoglobin, moisture and fat content, as well as protein secondary structure of duck breast. The R ²_C of multiple linear regression and partial least-squares regression were 0.9543 and 0.9384, and SEC of 5.8205℃ and 6.7634℃, respectively. The prediction effect of multiple linear regression was better than partial least-squares regression, while the prediction model of support vector regression was superior to artificial neural network. R ²_C and R ²_CVof support vector regression were 0.9837 and 0.9496, SEC and SECV were 3.5215℃ and 6.1236℃, respectively, so the support vector regression was the best prediction model of center temperature. The R ²_V of the verified models of support vector regression was 0.9748, and the SEV was 5.5204℃. The model obtained by support vector regression together with the modeling results could accurately predict the center temperature of Beijing roast duck. 【Conclusion】 The color, myoglobin, water content, fat content and protein secondary structure of the breast of Beijing roast duck could effectively identify the central temperature. The SVR model was the most accurate prediction model for the center temperature.

Key words: Beijing roast duck, center temperature, quality, prediction model

柳艳霞,王振宇,郑晓春,朱瑶迪,陈丽,张德权. 基于品质指标预测北京烤鸭的中心温度[J]. 中国农业科学, 2020, 53(8): 1655-1663.

LIU YanXia,WANG ZhenYu,ZHENG XiaoChun,ZHU YaoDi,CHEN Li,ZHANG DeQuan. Prediction of Center Temperature of Beijing Roast Duck Based on Quality Index[J]. Scientia Agricultura Sinica, 2020, 53(8): 1655-1663.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2020.08.014

https://www.chinaagrisci.com/CN/Y2020/V53/I8/1655

图/表 7

图1

图2

图3

图4

表1

图5

图6

参考文献 36

[1]	王雅琪, 饶伟丽, 田建文, 王振宇 . 烤鸭绿色制造技术研究进展. 食品工业科技, 2017,38(13):315-319.
	WANG Y Q, RAO W L, TIAN J W, WANG Z Z . Research progress in green manufacturing technology of roasted duck. Science and Technology of Food Industry, 2017,38(13):315-319. (in Chinese)
[2]	周小理, 王雨蔷, 唐文, 谢凡, 周一鸣 . 烤鸭水提物细胞抗氧化活性的研究. 食品工业, 2016,37(6):212-215.
	ZHOU X L, WANG Y Q, TANG W, XIE F, ZHOU Y M . Research of water-soluble extracts from roast duck on cell antioxidant activity. The Food Industry, 2016,37(6):212-215. (in Chinese)
[3]	HUANG J . The dining experience of Beijing Roast Duck: A comparative study of the Chinese and English online consumer reviews. International Journal of Hospitality Management, 2017,66:117-129.
[4]	刘登勇, 周光宏, 徐幸莲 . 西餐中肉类烹调程度的控制. 扬州大学烹饪学报, 2004(3):37-40.
	LIU D Y, ZHOU G H, XU X L . Control of meat cooking degree in western cuisine. Culinary Science Journal of Yangzhou University, 2004(3):37-40. (in Chinese)
[5]	万红兵, 祁兴磊, 李海鹏, 王欢, 雷元华, 张松山, 谢鹏, 刘璇, 孙宝忠 . 加热温度和时间对牛肉嫩度影响的主成分分析评价. 农业工程学报, 2018,34(13):303-310.
	WAN H B, QI X L, LI H P, WANG H, LEI Y H, ZHANG S H, XIE P, LIU X, SUN B Z . Evaluation of effects of heating temperature and time on tenderness of beef based on principal component analysis. Transactions of the Chinese Society of Agricultural Engineering, 2018,34(13):303-310. (in Chinese)
[6]	AASLYNG M D, BEJERHOLM C, ERTBJERG P, BERTRAM H C, ANDERSEN H J . Cooking loss and juiciness of pork in relation to raw meat quality and cooking procedure. Food Quality and Preference, 2003,14(4):277-288.
[7]	WATTANACHANT S, BENJAKUL S, LEDWARD D A . Effect of heat treatment on changes in texture, structure and properties of Thai indigenous chicken muscle. Food Chemistry, 2005,93(2):337-348.
[8]	秦刚 . 荣昌猪肉在不同烤制温度中挥发性风味物质的研究[D]. 重庆: 西南大学, 2011.
	QIN G . Study on the aroma compounds of Rong-chang pork at different core temperature in processing[D]. Chongqing: Southwest University, 2011. (in Chinese)
[9]	潘腾, 孟静, 崔建云, 郭慧媛, 罗海玲, 葛克山 . 商业化烤制羊排中心温度预测模型. 农业机械学报, 2015,46(6):233-238.
	PAN T, MENG J, CUI J Y, GUO H Y, LUO H L, GE K S . Mathematical model for predicting core temperature of commercial mutton chops during grilling. Transactions of the Chinese Society of Agricultural Machinery, 2015,46(6):233-238. (in Chinese)
[10]	LIU Y W, SUN D W, CHENG J H, HAN Z . Hyperspectral imaging sensing of changes in moisture content and color of beef during microwave heating process. Food Analytical Methods, 2018,11(9):2472-2484.
[11]	李宏燕, 何建国, 马莹, 王松磊, 吴龙国, 康宁波, 王芹志 . 自然对流红外辐射复合加热在羊肉烤制过程中的传热解析. 食品科学, 2017,38(21):61-66.
	LI H Y, HE J G, MA Y, WANG S L, WU L G, KANG N B, WANG Q Z . Heating transfer analysis during mutton roasting by natural convection combined with infrared radiation. Food Science, 2017,38(21):61-66. (in Chinese)
[12]	FELIX R, FEYISSA A H . Kinetic Modeling of Texture and Color Changes During Thermal Treatment of Chicken Breast Meat. Food and Bioprocess Technology, 2018,11(8):1495-1504.
[13]	刘晶晶 . 结缔组织热变化对牛肉嫩度影响的研究[D]. 北京: 中国农业科学院, 2018.
	LIU J J . The influence of heat change of connective tissue on beef tenderness[D]. Beijing: Chinese Academy of Agricultural Sciences, 2018. (in Chinese)
[14]	VIEIRA E S, MÁRSICO E T, CONTE-JUNIOR C A, DAMIANI C, CANTO A C V C S, MONTEIRO M L G, SILVA F A . Effects of different frying techniques on the color, fatty acid profile, and lipid oxidation of Arapaima gigas. Journal of Food Processing and Preservation, 2018,42(11):e13820.
[15]	叶树良 . 北京烤鸭加工工艺研究. 肉类工业, 2012(8):8-9.
	YE S L . Study on processing technology of Beijing roast duck. Meat Industry, 2012(8):8-9. (in Chinese)
[16]	LI X, ZHANG Y, LI Z, LI M, LIU Y F, ZHANG D Q . The effect of temperature in the range of -0.8 to 4℃ on lamb meat color stability. Meat Science, 2017,134:28-33.
[17]	ZHANG L L, ZHANG F X, WANG X . Changes of protein secondary structures of pollock surimi gels under high-temperature (100℃ and 120℃) treatment. Journal of Food Engineering, 2016,171:159-163.
[18]	艾虎 . 基于计算机视觉的人工神经网络和图像处理技术的牛肉大理石花纹自动分级研究[D]. 雅安: 四川农业大学, 2009.
	AI H . Study on the automatic grading for beef marbling based on computer vision ＆ artificial neural network ＆ image processing. Ya’an: Sichuan Agricultural University, 2009. (in Chinese)
[19]	田晓静 . 基于电子鼻和电子舌的羊肉品质检测[D]. 杭州: 浙江大学, 2014.
	TIAN X J . Detection of mutton quality based on electronic nose and lectronic tongue[D]. Hangzhou: Zhejiang University, 2014. (in Chinese)
[20]	KHAN M A, ALI S, YANG H J, KAMBOH A A, AHMAD Z, TUME R K, ZHOU G h . Improvement of color, texture and food safety of ready-to-eat high pressure-heat treated duck breast. Food Chemistry, 2019,277:646-654.
[21]	YU X Y, LLAVE Y, FUKUOKA M, SAKAI N . Estimation of color changes in fish surface at the beginning of grilling based on the degree of protein denaturation. Journal of Food Engineering, 2014,129:12-20.
[22]	FERRINI G, COMAPOSADA J, ARNAU J, GOU P . Colour modification in a cured meat model dried by Quick-Dry-Slice process® and high pressure processed as a function of NaCl, KCl, K-lactate and water contents. Innovative Food Science & Emerging Technologies, 2012,13:69-74.
[23]	GARCÍA-ROMERO J, GINÉS R, IZQUIERDO M S, HAROUN R, BADILLA R, ROBAINA L . Effect of dietary substitution of fish meal for marine crab and echinoderm meals on growth performance, ammonia excretion, skin colour, and flesh quality and oxidation of red porgy (Pagrus pagrus). Aquaculture, 2014,422/423:239-248.
[24]	CAI L Y, LI D M, DONG Z J, CAO A L, LIN H, LI J R . Change regularity of the characteristics of Maillard reaction products derived from xylose and Chinese shrimp waste hydrolysates. LWT-Food Science and Technology, 2016,65:908-916.
[25]	YARMAND M S, HOMAYOUNI A . Effect of microwave cooking on the microstructure and quality of meat in goat and lamb. Food Chemistry, 2009,112(4):782-785.
[26]	ADEDEJI A A, NGADI M O, RAGHAVAN G S V . Kinetics of mass transfer in microwave precooked and deep-fat fried chicken nuggets. Journal of Food Engineering, 2009,91(1):146-153.
[27]	YU T Y, MORTON J D, CLERENS S, DYER J M . Cooking-induced protein modifications in meat. Comprehensive Reviews in Food Science and Food Safety, 2017,16(1):141-159.
[28]	WEI L Q, CUI B W, JAMALI M A, HUI T, LIU S X, BAO Y J, PENG Z Q, ZHANG Y W . The mechanics of formation of heat- induced myofibrillar protein gel from rabbit psoas major. CyTA-Journal of Food, 2017,15(2):181-190.
[29]	BÖCKER U, OFSTAD R, BERTRAM H C, EGELANDSDAL B, KOHLER A . Salt-induced changes in pork myofibrillar tissue investigated by FT-IR microspectroscopy and light microscopy. Journal of Agricultural and Food Chemistry, 2006,54(18):6733-6740.
[30]	BERTRAM H C, KOHLER A, BÖCKER U, OFSTAD R, ANDERSEN H J . Heat-induced changes in myofibrillar protein structures and myowater of two pork qualities. A combined FT-IR spectroscopy and low-field NMR relaxometry study. Journal of Agricultural and Food Chemistry, 2006,54(5):1740-1746.
[31]	KIRSCHNER C, OFSTAD R, SKARPEID H J, HØST V, KOHLER A . Monitoring of denaturation processes in aged beef loin by fourier transform infrared microspectroscopy. Journal of Agricultural and Food Chemistry, 2004,52(12):3920-3929.
[32]	HASHIM D M, CHE MAN Y B, NORAKASHA R, SHUHAIMI M, SALMAH Y, SYAHARIZA Z A . Potential use of Fourier transform infrared spectroscopy for differentiation of bovine and porcine gelatins. Food Chemistry, 2010,118(3):856-860.
[33]	FARIFTEH J, VAN DER MEER F, ATZBERGER C, CARRANZA E J M . Quantitative analysis of salt-affected soil reflectance spectra: A comparison of two adaptive methods (PLSR and ANN). Remote Sensing of Environment, 2007,110(1):59-78.
[34]	HUGHES J M, OISETH S K, PURSLOW P P, WARNER R D . A structural approach to understanding the interactions between colour, water-holding capacity and tenderness. Meat Science, 2014,98(3):520-532.
[35]	MICKLANDERY E, PESHLOVY B, PURSLOW P P, ENGELSENY S B . NMR-cooking: monitoring the changes in meat during cooking by low-field ¹H-NMR . Trends in Food Science & Technology, 2002,13(9/10):341-346.
[36]	熊振杰 . 基于高光谱成像技术的鸡肉品质快速无损检测[D]. 广州: 华南理工大学, 2015.
	XIONG Z J . Rapid and non-destructive detection of chicken meat quality based onhyperspectral imaging technique[D]. Guangzhou: South China University of Technology, 2015. (in Chinese)

建模方法 Modeling methods	校正集决定系数R²_C R²_C for Calibration set	校正集均方根误差 SEC for Calibration set	交叉验证决定系数R²_CV R²_CV for Cross-validation set	交叉验证均方根误差 SECV for Cross-validation set	模型表征 Model characterization
MLR	0.9543	5.8205	0.9376	6.8249	Y=0.5138X₁-1.2166X₂+1.8129X₃+14.4454X₄+ 14.6893X₅+13.6934X₆-1.7653X₇+0.2512X₈- 13.2067X₉-12.7812X₁₀-12.6912X₁₁-12.6671X₁₂
PLSR	0.9384	6.7634	0.9221	7.6114	Y=0.5831X₁-0.5723X₂+0.9120X₃+1.7496X₄+ 1.0477X₅+0.4625X₆-1.7756X₇-0.0101X₈+ 0.2155X₉+0.4015X₁₀+1.2262X₁₁+0.8696X₁₂
SVR	0.9837	3.5215	0.9496	6.1236
ANN	0.9712	4.6260	0.9055	8.5726
