4株鸭坦布苏病毒的毒力、E基因序列和抗原差异性

doi:10.3864/j.issn.0578-1752.2019.23.021

摘要/Abstract

摘要：

【目的】比较鸭坦布苏病毒（duck tembusu virus, DTMUV）分离株的毒力、分析E蛋白基因序列、研究抗原差异性,为鸭坦布苏病防控提供依据。【方法】将DTMUV-HB(2011)、DTMUV-AH(2014)、DTMUV-GX1(2012)、DTMUV-GX2(2015) 4株病毒接种10日龄易感鸭胚进行增殖,并利用6日龄SPF鸡胚测定ELD₅₀。根据测定的病毒含量,将分离毒株稀释为100ELD₅₀/0.5mL,人工感染40只180日龄健康北京鸭,进行临床症状观察、病毒分离、大体剖检,分析分离毒株的毒力有无差异。提取8株DTMUV分离病毒株的RNA,通过RT-PCR扩增E基因,分析比较不同地区的DTMUV的E基因核苷酸和氨基酸序列相似性,构建进化树。利用实验室建立的鸭坦布苏病毒血凝抑制试验分别测定4株病毒阳性血清对4株病毒的HI效价。同时采用固定病毒稀释血清法,利用C6/36细胞测定4株病毒阳性血清对4株DTMUV的血清中和效价。通过交叉血凝抑制试验和血清交叉中和试验比较4株病毒的抗原差异性（R值）。【结果】 (1)各毒株的病毒含量范围在10 ^4.7—10 ^5.3 ELD₅₀/0.1mL。人工感染鸭试验,攻毒后3 d鸭采食量和产蛋量均显著下降,各组病毒分离阳性率均在85%以上,剖检病变主要表现为卵泡变形、出血。(2)分离株序列分析结果表明,核苷酸序列相似性为95.7%—100%,推导氨基酸序列相似性在98.2%以上。遗传进化分析表明共同构成了一个进化分支。(3)4株病毒及其阳性血清进行血凝抑制交叉试验,计算的抗原性差异R值在0.79—1.12之间;进行细胞中和交叉试验,计算的R值在0.79—1.20之间。【结论】分离的4株DTMUV在毒力、E蛋白基因和抗原性上未见显著差异。

关键词: 鸭坦布苏病毒, 毒力, E基因, 抗原性

Abstract:

【Objective】The research aimed to compare the virulence of Duck Tembusu Virus (DTMUV), and to analysis its envelope protein gene sequence analysis and antigenic difference. 【Method】Susceptible 10-day-old duck embryos were inoculated with four different DTMUV strains, including DTMUV-HB isolated in 2011, DTMUV-AH isolated in 2014, DTMUV-GX1 isolated in 2012 and DTMUV-GX2 isolated in 2015. The median embryo lethal dose (ELD₅₀) of the four strains was measured with 6-day-old SPF chicken embryos. According to that, forty 180-day-old healthy Peking duck were challenged respectively with four strains which were diluted into 100 ELD₅₀/0.5 mL. The clinical, virological, pathological features of different DTMUV strains infection in ducks were characterized. The viral RNA of eight DTMUV strains were extracted from the allantoic fluid, and then the E gene were amplified by RT-PCR and sequenced. Then the similarity analysis of nucleotide and amino acid sequence and phylogenetic analysis were carried out. The HI titers of 4 antisera against 4 DTMUV strains were determined with duck Tembusu virus hemagglutination inhibition test. The neutralization titers of 4 antisera against 4 DTMUV strains were determined by neutralization assay using C6/36 cell lines. We analyzed the antigenic difference of 4 DTMUV strains by R value, which contained cross hemagglutination inhibition test and cell cross neutralization test. 【Result】(1) The median embryo lethal dose (ELD₅₀) were 10 ^-4.7-10 ^-5.3/0.1ml. The artificial infection test suggested that, feed intake and egg production of the challenged group decreased significantly on 3 days post inoculation (dpi), and the virus positive isolation rate were more than 85% on 2 dpi. The gross lesions of the reproductive system were mainly deformed and hemorrhaged follicular by necropsying on 8 dpi. (2) The results of sequence analysis showed that nucleotide sequence similarity was 95.7% - 100%, and the similarity of amino acid sequence was 98.2%. Genetic evolutionary analysis illustrated that all the DTMUV isolates in this study gathered into the same clade. (3) The R value showed antigenic difference of cross hemagglutination inhibition test were 0.79-1.12, and that of cell cross neutralization test were 0.79-1.20. 【Conclusion】There were no significant difference in virulence, E gene sequence and antigenicity of four DTMUV strains isolated in this study.

Key words: Duck Tembusu virus, virulence, envelope protein gene, antigenicity

杨志远,段会娟,王小蕾,刘立新,赵际成,潘洁,刘月焕,林健. 4株鸭坦布苏病毒的毒力、E基因序列和抗原差异性[J]. 中国农业科学, 2019, 52(23): 4406-4414.

YANG ZhiYuan,DUAN HuiJuan,WANG XiaoLei,LIU LiXin,ZHAO JiCheng,PAN Jie,LIU YueHuan,LIN Jian. Virulence, E Gene Sequence and Antigenic Difference of 4 Duck Tembusu Virus Isolations[J]. Scientia Agricultura Sinica, 2019, 52(23): 4406-4414.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2019.23.021

https://www.chinaagrisci.com/CN/Y2019/V52/I23/4406

图/表 7

表1

图1

图2

表2

表3

表4

图3

参考文献 40

[1]	CAO Z, ZHANG C, LIU Y, LIU Y, YE W, HAN J, MA G, ZHANG D, XU F, GAO X, TANG Y, SHI S, WAN C, ZHANG C, HE B, YANG M, LU X, HUANG Y, DIAO Y, MA X, ZHANG D . Tembusu virus in ducks, China. Emerging Infectious Diseases, 2011,17(10):1873-1875. doi: 10.3201/eid1710.101890
[2]	SU J, LI S, HU X, YU X, WANG Y, LIU P, LU X, ZHANG G, HU X, LIU D, LI X, SU W, LU H, MOK N S, WANG P, WANG M, TIAN K, GAO G F . Duck egg-drop syndrome caused by BYD virus, a new Tembusu-related flavivirus. PLoS ONE, 2011,6(3):e18106. doi: 10.1371/journal.pone.0018106 pmid: 21455312
[3]	YAN P, ZHAO Y, ZHANG X, XU D, DAI X, TENG Q, YAN L, ZHOU J, JI X, ZHANG S, LIU G, ZHOU Y, KAWAOKA Y, TONG G, LI Z . An infectious disease of ducks caused by a newly emerged Tembusu virus strain in mainland China. Virology, 2011,417(1):1-8. doi: 10.1016/j.virol.2011.06.003
[4]	曹贞贞, 张存, 黄瑜, 刁有祥, 叶伟成, 刘月焕, 韩婧文, 马国明, 张冬冬, 许丰, 王丹, 姜甜甜, 袁媛, 谢小雨, 高绪慧, 唐熠, 施少华, 万春和, 张晨, 何玢, 杨梦婕, 陆新浩, 张冰, 张国中, 马学军, 张大丙 . 鸭出血性卵巢炎的初步研究. 中国兽医杂志, 2010,46(12):3-6.
	CAO Z Z, ZHANG C, HUANG Y, DIAO Y X, YE W C, LIU Y H, HAN J W, MA G M, ZHANG D D, XU F, WANG D, JIANG T T, YUAN Y, XIE X Y, GAO X H, TANG Y, SHI S H, WAN C H, ZHANG C, HE B, YANG M J, LU X H, ZHANG B, ZHANG G Z, MA X J, ZHANG D B . Preliminary studies on duck hemorrhagic ovaritis. Chinese Journal of Veterinary Medicine, 2010,46(12):3-6.(in Chinese)
[5]	廖敏, 牟小东, 耿阳, 边葶苈, 陆新浩, 陈秋英, 任祖伊, 丁铲, 周继勇 . 鸭传染性产蛋减少症(暂定名)的病原分离初报. 中国动物传染病学报, 2011,19(1):22-26.
	LIAO M, MOU X D, GENG Y, BIAN T L, LU X H, CHEN Q Y, REN Z Y, DING C, ZHOU J Y . The primary study on virus isolation of duck infectious egg fallings. Chinese Journal of veterinary Parasitology, 2011,19(1):22-26.(in Chinese)
[6]	李玉峰, 马秀丽, 于可响, 王友令, 高巍, 黄兵, 徐怀英, 吴静, 王生雨, 王莉莉, 秦卓明 . 一种从鸭新分离的黄病毒研究初报. 畜牧兽医学报, 2011(6):885-891.
	LI Y F, MA X L, YU K X, WANG Y L, GAO W, HUANG B, XU H Y, WU J, WANG S Y, WANG L L, QIN Z M . A brief report of flaviviruses newly isolated from duck. Chinese Journal of Animal and Veterinary Sciences, 2011(6):885-891.(in Chinese)
[7]	朱丽萍, 颜世敢 . 鸭坦布苏病毒研究进展. 中国预防兽医学报, 2012,34(1):79-82.
	ZHU L P, YAN S G . Progress of duck Tembusu Virus. Chinese Journal of Preventive Veterinary Medicine, 2012,34(1):79-82.(in Chinese)
[8]	张大丙 . 鸭出血性卵巢炎的研究进展. 中国家禽, 2011,33(14):37-38.
	ZHANG D B . Research progress of Duck hemorrhagic ovaritis. China Poultry, 2011,33(14):37-38.(in Chinese)
[9]	PLATT G S, WAY H J, BOWEN E T, SIMPSON D I, HILL M N, KAMATH S, BENDELL P J, HEATHCOTE O H . Arbovirus infections in Sarawak, October 1968-February 1970 Tembusu and Sindbis virus isolations from mosquitoes. Annals of Tropical Medicine and Parasitology, 1975,69(1):65-71. doi: 10.1080/00034983.1975.11686984 pmid: 235907
[10]	LEAKE C J, USSERY M A, NISALAK A, HOKE C H, ANDRE R G, BURKE D S . Virus isolations from mosquitoes collected during the 1982 Japanese encephalitis epidemic in northern Thailand. Transactions of the Royal Society of Tropical Medicine and Hygiene, 1986,80(5):831-837. doi: 10.1016/0035-9203(86)90397-4 pmid: 2885948
[11]	PANDEY B D, KARABATSOS N, CROPP B, TAGAKI M, TSUDA Y, ICHINOSE A, IGARASHI A . Identification of a flavivirus isolated from mosquitos in Chiang Mai Thailand. The Southeast Asian Journal of Tropical Medicine and Public Health, 1999,30(1):161-165. pmid: 10695806
[12]	KONO Y, TSUKAMOTO K, ABD H M, DARUS A, LIAN T C, SAM L S, YOK C N, Di KB, LIM K T, YAMAGUCHI S, NARITA M . Encephalitis and retarded growth of chicks caused by Sitiawan virus, a new isolate belonging to the genus Flavivirus. The American Journal of Tropical Medicine and Hygiene, 2000,63(1/2):94-101. doi: 10.4269/ajtmh.2000.63.94 pmid: 11358004
[13]	YUN T, ZHANG D, MA X, CAO Z, CHEN L, NI Z, YE W, YU B, HUA J, ZHANG Y, ZHANG C . Complete genome sequence of a novel flavivirus, duck tembusu virus, isolated from ducks and geese in China. Journal of Virology, 2012,86(6):3406-3407. doi: 10.1128/JVI.07132-11
[14]	万春和, 施少华, 傅光华, 梁昭平, 王斌, 程龙飞, 李敏, 陈红梅, 林芳, 林建生, 王鑫, 许芬芬, 黄瑜 . 鸭黄病毒油乳剂灭活疫苗研制及免疫效果测定. 养禽与禽病防治, 2011(10):20-22.
	WAN C H, SHI S H, FU G H, LIANG Z P, WANG B, CHENG L F, LI M, CHEN H M, LIN F, LIN J S, WANG X, XU F F, HUANG Y . Immune effectiveness of the oil-emulsion inactivated vaccine against duck Tembusu virus. Poultry Husbandry and Disease Control, 2011(10):20-22.(in Chinese)
[15]	李振华, 李小康, 郭香玲, 张春杰, 刘凤军, 王臣 . 鸭坦布苏病毒灭活油乳苗的制备及免疫效力测定. 中国预防兽医学报, 2013,35(5):388-391.
	LI Z H, LI X K, GUO X L, ZHANG C J, LIU F J, WANG C . Immune effectiveness of the oil-emulsion inactivated vaccine against duck Tembusu virus. Chinese Journal of Preventive Veterinary Medicine, 2013,35(5):388-391.(in Chinese)
[16]	CHEN P, LIU J, JIANG Y, ZHAO Y, LI Q, WU L, HE X, CHEN H . The vaccine efficacy of recombinant duck enteritis virus expressing secreted E with or without PrM proteins of duck tembusu virus. Vaccine, 2014,32(41):5271-5277. doi: 10.1016/j.vaccine.2014.07.082
[17]	LI G, GAO X, XIAO Y, LIU S, SHAN P, LI X, YING S, ZHANG Y, LEI Y, WU X , Development of a live attenuated vaccine candidate against duck Tembusu viral disease. Virology, 2014, 450-451(1):233-242. doi: 10.1016/j.vetmic.2019.03.022 pmid: 30955813
[18]	SUN L, LI Y, YUE Z, HAN Z, YANG X, KONG X, LIU S . Adaptation and attenuation of duck Tembusu virus strain Du/CH/ LSD/110128 following serial passage in chicken embryos. Clinical & Vaccine Immunology, 2014,21(8):1046-1053. doi: 10.1055/a-1059-9739 pmid: 31841290
[19]	ZOU Z, LIU Z, JIN M . Efficient strategy to generate a vectored duck enteritis virus delivering envelope of duck Tembusu virus. Viruses, 2014,6(6):2428-2443. doi: 10.3390/v6062428 pmid: 24956180
[20]	LIN J, LIU Y, WANG X, YANG B, HE P, YANG Z, DUAN H, XIE J, ZOU L, ZHAO J . Efficacy evaluation of an inactivated duck Tembusu virus vaccine. Avian Diseases, 2015,59(2):244-248. doi: 10.1637/10960-101514-Reg pmid: 26473674
[21]	MA T, LIU Y, CHENG J, LIU Y, FAN W, CHENG Z, NIU X, LIU J . Liposomes containing recombinant E protein vaccine against duck Tembusu virus in ducks. Vaccine, 2016,34(19):2157-2163. doi: 10.1016/j.vaccine.2016.03.030 pmid: 27016654
[22]	刘友生, 彭春香, 傅光华, 侯东军, 施少华, 万春和, 程龙飞, 陈红梅, 林建生, 林芳, 黄瑜 . 2010~2011年中国部分地区禽坦布苏病毒感染调查及分子变异分析. 中国动物传染病学报, 2012(1):47-53.
	LIU Y S, PENG C X, FU G H, HOU D J, SHI S H, WAN C H, CHENG L F, CHEN H M, LIN J S, LIN F, HUANG Y . Detection and molecular analysis of avian Tembusu virus partial areas of China from 2010 to 2011. Chinese Journal of Animal Infectious Diseases, 2012(1):47-53.(in Chinese)
[23]	傅光华, 黄瑜, 程龙飞, 万春和, 施少华, 傅秋玲, 陈红梅, 林建生, 林芳 . 坦布苏病毒鸡源分离株全基因组及遗传变异分析. 中国兽医学报, 2014(9):1418-1422.
	FU G H, HUANG Y, CHENG L F, WAN C H, SHI S H, FU Q L, CHEN H M, LIN J S, LIN F . Genome sequence and phylogenetic analysis of Tembusu viruses isolated from chicken. Chinese Journal of Veterinary Science, 2014(9):1418-1422.(in Chinese)
[24]	王钰, 王经满, 曹瑞兵 . 鸭坦布苏病毒XZ-2012株的分离鉴定与基因变异分析. 南京农业大学学报, 2015(3):446-452.
	WANG Y, WANG J M, CAO R B . Isolation and gene variation character of duck Tembusu virus strain XZ-2012. Journal of Nanjing Agricultural University, 2015(3):446-452.(in Chinese)
[25]	韦天超, 农海连, 潘超, 李秀凤, 蒋桂林, 程二财, 苑亚东, 磨美兰, 韦平 . 鸭坦布苏病毒GX150829株的分离鉴定与E基因的序列分析. 中国家禽, 2016(7):19-22.
	WEI T C, NONG H L, PAN C, LI X F, JIANG G L, CHENG E C, YUAN Y D, MO M L, WEI P . Isolation and identification of Duck Tembusu virus GX150829 strain and sequence analysis of E Gene. China Poultry, 2016(7):19-22.(in Chinese)
[26]	王楠楠, 姜安安, 王蓓, 王晓旭, 毕庄莉, 唐井玉, 刘光清, 王桂军 . 鸭坦布苏病毒AH-F10株全基因组的分子克隆与序列分析. 中国兽医科学, 2014(1):50-54.
	WANG N N, JIANG A A, WANG B, WANG X X, BI Z L, TANG J Y, LIU G Q, WANG G J . Molecular cloning and sequence analysis of the complete genome of duck Tembusu virus AH-F10 strain. Chinese Veterinary Science, 2014(1):50-54.(in Chinese)
[27]	GOULD E A, MOSS S R, TURNER S L . Evolution and dispersal of encephalitic flaviviruses. Archives of virology. Supplementum, 2004(18):65-84. doi: 10.1007/978-3-7091-0572-6_6 pmid: 15119763
[28]	YU K, SHENG Z Z, HUANG B, MA X, LI Y, YUAN X, QIN Z, WANG D, CHAKRAVARTY S, LI F, SONG M, SUN H . Structural, antigenic, and evolutionary characterizations of the envelope protein of newly emerging Duck Tembusu Virus. PLoS ONE, 2013,8(8):e71319. doi: 10.1371/journal.pone.0071319 pmid: 23990944
[29]	谢佳, 韩春华, 林健, 段会娟, 杨志远, 赵际成, 潘洁, 刘月焕 . 鸭出血性卵巢炎病毒血症研究. 中国农业科学, 2014(23):4763-4768. doi: 10.3864/j.issn.0578-1752.2014.23.021
	XIE J, HAN C H, LIN J, DUAN H J, YANG Z Y, ZHAO J C, PAN J, LIU Y H . Study on viremia of the ducks infected with DHOV-HB strain. Scientia Agricultura Sinica, 2014(23):4763-4768.(in Chinese) doi: 10.3864/j.issn.0578-1752.2014.23.021
[30]	CLARKE D H, CASALS J . Techniques for hemagglutination and hemagglutination-inhibition with arthropod-borne viruses. American Journal of Tropical Medicine and Hygiene, 1958,7(5):561-573. doi: 10.4269/ajtmh.1958.7.561 pmid: 13571577
[31]	ARCHETTI I, HORSFALL F J . Persistent antigenic variation of influenza A viruses after incomplete neutralization in ovo with heterologous immune serum. Journal of Experimental Medicine, 1950,92(5):441-462. doi: 10.1084/jem.92.5.441 pmid: 14778924
[32]	林健, 杨志远, 何平有, 段会娟, 邹立宏, 杨保收, 赵际成, 潘洁, 王小蕾, 刘立新, 刘月焕 . 鸭坦布苏病毒病卵巢病变标准的判定. 中国农业科学, 2016(14):2830-2836. doi: 10.3864/j.issn.0578-1752.2016.14.017
	LIN J, YANG Z Y, HE P Y, DUAN H J, ZOU L H, YANG B S, ZHAO J C, PAN J, WANG X L, LIU L X, LIU Y H . Criterion of ovarian lesions of duck Tembusu virus disease. Scientia Agricultura Sinica, 2016(14):2830-2836.(in Chinese) doi: 10.3864/j.issn.0578-1752.2016.14.017
[33]	林健, 韩春华, 陈华林, 蒋桃珍, 梁武, 何平有, 杨保收, 王英, 韩婧雯, 刘东艳, 潘洁, 段会娟, 丁佩佩, 胡胜强, 刘月焕 . 鸭出血性卵巢炎实验感染模型的建立. 中国农业科学, 2011(10):2161-2167. doi: 10.3864/j.issn.0578-1752.2011.10.022
	LIN J, HAN C H, CHEN H L, JIANG T Z, LIANG W, HE P Y, YANG B S, WANG Y, HAN J W, LIU D Y, PAN J, DUAN H J, DING P P, HU S Q, LIU Y H . Establishment of experimental infection model of duck hemorrhagic ovaritis. Scientia Agricultura Sinica, 2011(10):2161-2167.(in Chinese) doi: 10.3864/j.issn.0578-1752.2011.10.022
[34]	于可响 . 鸭坦布苏病毒生物学特性、基因组特征、诊断方法以及感染性克隆的研究[D]. 扬州: 扬州大学, 2013.
	YU K X . Study on biological characteristics, genome analysis, diagnosis methods and infectious clone for newly emerged duck Tembusu virus[D]. Yangzhou: Yangzhou University, 2013. (in Chinese)
[35]	范萍萍 . 鸭坦布苏病毒铜陵株的分离与鉴定[D]. 合肥: 安徽农业大学, 2016.
	FAN P P . Isolation and identification of duck Tembusu virus TongLing strain[D]. Hefei: Anhui Agricultural University, 2016.(in Chinese)
[36]	万春和, 施少华, 黄瑜 . 禽坦布苏病毒包膜蛋白E的基因特征. 福建农业学报, 2014(8):715-719.
	WAN C H, SHI S H, HUANG Y . Genetic feature of the envelop protein of avian Tembusu virus. Fujian Journal of Agricultural Sciences, 2014(8):715-719.(in Chinese)
[37]	张帅 . 鸭坦布苏病毒的分子生物学快速诊断与E蛋白基因变异性分析[D]. 泰安: 山东农业大学, 2012.
	ZHANG S . Rapid diagnosis of DTMUV based on molecular techniques and the variability analysis of DTMUV E gene[D]. Taian: Shandong Agricultural University, 2012. (in Chinese)
[38]	姬希文, 闫丽萍, 颜丕熙, 李国新, 张七斤, 李泽君 . 鸭坦布苏病毒抗体间接ELISA检测方法的建立. 中国预防兽医学报, 2011,33(8):630-634.
	JI X W, YAN L P, YAN P X, LI G X, ZHANG Q J, LI Z J . Establishment of an indirect ELISA for detection of antibody against duck Tembusu virus. Chinese Journal of Preventive Veterinary Medicine, 2011,33(8):630-634.(in Chinese)
[39]	LI X, LI G, TENG Q, YU L, WU X, LI Z . Development of a blocking ELISA for detection of serum neutralizing antibodies against newly emerged duck Tembusu virus. PLoS ONE, 2012,7(12):83. doi: 10.1371/journal.pone.0053026 pmid: 23300851
[40]	WANG Q, WEN Y, YIFAN H, WU Y, CAI Y, XU L, WANG C, LI A, WU B, CHEN J . Isolation and identification of duck Tembusu virus strain lH and development of latex-agglutination diagnostic method for rapid detection of antibodies. Avian Diseases, 2014,58(4):616-622.

动物数量（只） Animal	攻毒用毒株 Virus	攻毒途径及剂量 Routes and dose	病毒分离阳性率 Positive rate of virus isolation
8	DTMUV-HB	肌肉注射 Intramuscular injection 0.5mL (100ELD₅₀)	100%(8^A/8^B)
8	DTMUV-AH		87.5%(7/8)
8	DTMUV-GX1		87.5%(7/8)
8	DTMUV-GX2		100%(8/8)
8	/	/	0%(0/8)

毒株 Virus	4株DTMUV阳性血清HI效价 Positive sera HI titer of 4 DTMUV isolates
毒株 Virus	DTMUV-HB	DTMUV-AH	DTMUV-GX1	DTMUV-GX2
DTMUV-HB	1:806.3	1:806.3	1:806.3	1:640.0
DTMUV-AH	1:160.0	1:201.6	1:201.6	1:100.8
DTMUV-GX1	1:127.0	1:127.0	1:100.8	1:100.8
DTMUV-GX2	1:201.6	1:254.0	1:254.0	1:201.6

R值 R value	DTMUV-HB	DTMUV-AH	DTMUV-GX-1	DTMUV-GX-2
DTMUV-HB	**	0.79	0.91	1.20
DTMUV-AH	0.89	**	0.82	0.91
DTMUV-GX-1	1.12	1.12	**	0.93
DTMUV-GX-2	0.89	0.79	1.12	**

毒株 Virus	4株DTMUV阳性血清中和效价 Positive sera neutralization titer of 4 DTMUV isolates
毒株 Virus	DTMUV-HB	DTMUV-AH	DTMUV-GX1	DTMUV-GX2
DTMUV-HB	1:54.6	1:29.3	1:34.9	1:55.4
DTMUV-AH	1:44.3	1:38.3	1:34.9	1:48.9
DTMUV-GX1	1:59.3	1:33.4	1:45.3	1:45.4
DTMUV-GX2	1:62.0	1:28.4	1:37.7	1:44.0
