苹果LIM基因家族生物信息学及表达分析

doi:10.3864/j.issn.0578-1752.2019.23.013

摘要/Abstract

摘要：

【目的】在苹果全基因组中鉴定LIM,通过分析启动子作用元件、保守结构域、基因聚类、基因结构、染色体定位以及组织表达模式,为研究和利用苹果LIM奠定基础。【方法】利用苹果基因组数据库GDR和PLAZA,获得苹果LIM家族成员并进行编号。苹果LIM蛋白氨基酸序列的基本信息通过ExPASy Proteomics Server进行预测,利用Cell-PLoc进行亚细胞定位预测,利用CD-Search Tool进行LIM结构域分析,采用MEGA 7软件构建进化树,采用GSDS绘制基因结构,并利用TBtools软件对鉴定得到的MdLIM进行染色体定位,通过实时荧光定量RT-PCR对MdLIM的组织表达进行分析,并利用SPSS 18.0软件分析差异显著性。【结果】共鉴定得到11个苹果LIM家族成员,这些MdLIM蛋白包含96—222个不等的氨基酸残基,等电点分布在6.14—9.01。亚细胞定位结果显示,MdLIM蛋白在细胞核中均有分布。启动子作用元件分析表明,11个MdLIM启动子上分布有响应激素、环境适应性和逆境诱导的元件。蛋白保守结构域分析表明,11个MdLIM蛋白中除MdLIM8具有单LIM结构域外,其余10个均具有双LIM结构域。根据聚类分析结果可将MdLIM分为4组。染色体定位结果显示,MdLIM分布在苹果17条染色体中的7条,且MdLIM在7条染色体上的分布不均匀。花、叶、果皮和茎中的实时荧光定量RT-PCR结果显示,4个组织中均能检测到MdLIM的表达,且表达量具有一定差异。【结论】苹果LIM基因家族包括11个成员,进化上可分为4组,11个基因分布于7条染色体上,在不同组织中的表达具有多样性和特异性。

关键词: 苹果, 全基因组, LIM家族, 生物信息学, 表达分析

Abstract:

【Objective】 In order to lay a basis for the further functional research and application of MdLIM genes, this study were carried out to analyze the bioinformatics (e.g promoter action element, conserved domain, gene clustering, gene structure, chromosome localization) and expression of the LIM gene family in apple. 【Method】Based on the apple genome database GDR and PLAZA, the members of LIM gene were identified. The MdLIM amino acid sequence prediction, subcellular localization prediction, LIM domain analysis, and phylogenetic tree the gene structure were completed by ExPASy Proteomics Server, Cell-PLoc, CD-Search Tool, MEGA7, and GSDS, respectively. In addition, the expression pattern of MdLIM genes in different tissues and in peels with different degree of fruit russeting in samples was analyzed by real-time qRT-PCR.【Result】A total of eleven MdLIM genes were identified from apple genome. These MdLIM proteins contained 96-222 amino acid residues with isoelectric points ranging from 6.14 to 9.01. The results of subcellular localization showed that the apple LIM proteins were distributed in the nucleus. Analysis of promoter showed these 11 MdLIM genes contained cis-acting elements related to hormone responses, environmental adaptability and adversity induction. Conserved domains showed that ten MdLIM proteins had double LIM domains except MdLIM8. According to the phylogeny relationship, MdLIM genes were divided into four categories. The expression patterns of the 11 MdLIM genes in flowers, leaves, fruit peels and stems were determined by real-time RT-PCR, and the results showed that their diverse and specific expression could be detected in all of the four tissues, suggesting that they might play different roles in different tissues. 【Conclusion】Eleven MdLIM genes were identified from the whole genome of apple, and they could be divided into four groups, and distributed on 7 chromosomes with diverse and specific tissues expression patterns.

Key words: apple, genome-wide, LIM family, bioinformatics, expression analysis

袁高鹏, 韩晓蕾, 卞书迅, 张利义, 田义, 张彩霞, 丛佩华. 苹果LIM基因家族生物信息学及表达分析[J]. 中国农业科学, 2019, 52(23): 4322-4332.

YUAN GaoPeng, HAN XiaoLei, BIAN ShuXun, ZHANG LiYi, TIAN Yi, ZHANG CaiXia, CONG PeiHua. Bioinformatics and Expression Analysis of the LIM Gene Family in Apple[J]. Scientia Agricultura Sinica, 2019, 52(23): 4322-4332.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2019.23.013

https://www.chinaagrisci.com/CN/Y2019/V52/I23/4322

图/表 10

表1

表2

图1

图2

图3

图4

图5

图6

图7

图8

参考文献 41

[1]	WAY J C, CHALFIE M . mec-3, a homeobox-containing gene that specifies differentiation of the touch receptor neurons in C. elegans. Cell, 1988,54:5-16. doi: 10.1016/0092-8674(88)90174-2 pmid: 2898300
[2]	FREYD G, KIM S K, HORVITZ H R . Novel cysteine-rich motif and homeodomain in the product of the Caenorhabditis elegans cell lineage gene lin-11. Nature, 1990,344(6269):876-879. doi: 10.1038/344876a0 pmid: 1970421
[3]	KARLSSON O, THOR S, NORBERG T, OHLSSON H, EDLUND T . Insulin gene enhancer binding protein Isl-1 is a member of a novel class of proteins containing both a homeo-and a Cys-His domain. Nature, 1990,344(6269):879-882. doi: 10.1038/344879a0 pmid: 1691825
[4]	MÜLLER L, XU G, WELLS R, HOLLENBERG C P, PIEPERSBERG W . LRG1 is expressed during sporulation in Saccharomyces cerevisiae and contains motifs similar to LIM and rho/rac GAP domains. Nucleic Acids Research, 1994,22(15):3151-3154. doi: 10.1093/nar/22.15.3151 pmid: 8065929
[5]	MUNDEL C, BALTZ R, ELIASSON A, BRONNER R, GRASS N, KRÄUTER R, EVRARD J U, STEINMETZ A . A LIM-domain protein from sunflower is localized to the cytoplasm and/or nucleus in a wide variety of tissues and is associated with the phragmoplast in dividing cells. Plant Molecular Biology, 2000,42(2):291-302. doi: 10.1023/A:1006333611189
[6]	HICKE L, SCHUBERT H L, HILL C P . Ubiquitin-binding domains. Biochemical Journal, 2005,6(8):610-621. doi: 10.1042/BST20190869 pmid: 31829417
[7]	丁锡强, 宫国钦, 高峰, 杨金玲 . 2008年招远市苹果果锈病产生的气象条件分析. 山东气象, 2008(1):24-27.
	DING X Q, GONG G Q, GAO F, YANG J L . Weather conditions of apple rust disease occurring in 2008 in Zhaoyuan County. Journal of Shandong Meteorology, 2008(1):24-27. (in Chinese)
[8]	LASHBROOKE J, COHEN H, SAMOCHA D L, TZFADIA O, PANIZEL I I, ZEISLER V, MASSALHA H, STERN A, TRAINOTTI L, SCHREIBER L, COSTA F, AHARONIA A . MYB107 and MYB9 homologs regulate suberin deposition in angiosperms. The Plant Cell, 2016,28:2097-2116. doi: 10.1105/tpc.16.00490 pmid: 27604696
[9]	KAWAOKA A, EBINUMA H . Transcriptional control of lignin biosynthesis by tobacco LIM protein. Phytochemistry, 2001,57(7):1149-1157. doi: 10.1016/s0031-9422(01)00054-1 pmid: 11430987
[10]	李彤 . 高梁SbLIM1对木质素合成的转录调控及互作蛋白识别研究[D]. 济南: 山东大学, 2017.
	LI T . The transcriptional regulation of lignin biosynthesis and the interaction protein recognition by sorghum SbLIM1[D]. Jinan: Shandong University, 2017. (in Chinese)
[11]	SADLER I, CRAWFORD A W, MICHELSEN J W, BECKERLE M C . Zyxin and cCRP: Two interactive LIM domain proteins associated with the cytoskeleton. The Journal of Cell Biology, 1992,119(6):1573-1587. doi: 10.1083/jcb.119.6.1573 pmid: 1469049
[12]	杨洋, 李波, 胡文冉, 张经博, 范玲 . 棉花LIM蛋白基因家族的进化及表达特征分析. 植物生理学报, 2015,12:2133-2142.
	YANG Y, LI B, HU W R, ZHANG J B, FAN L . Evolution and expression analysis of the LIM protein gene family in cotton. Plant Physiology Journal, 2015,12:2133-2142. (in Chinese)
[13]	BALTZ R, DOMON C, PILLAY D T, STEINMETZ A . Characterization of a pollen-speciﬁc cDNA from sunﬂower encoding a zinc ﬁnger protein. Plant Journal, 1992,2(5):713-721. pmid: 1302629
[14]	BALTZ R, EVRARD J L, DOMON C, STEINMETZ A . A LIM motif is present in a pollen-specific protein. The Plant Cell, 1992,4(12):1465-1466. doi: 10.1105/tpc.4.12.1465 pmid: 1467648
[15]	THOMAS C, HOFFMANN C, DIETERLE M, VANTROYS M, AMPE C, STEINMETZ A . Tobacco WLIM1 is a novel F-actin binding proteininvolved in actin cytoskeleton remodeling. The Plant Cell, 2006,18(9):2194-2206. doi: 10.1105/tpc.106.040956 pmid: 16905656
[16]	PAPUGA J, HOFFMANN C, DIETERLE M, MOES D, MOREAU F, THOLL S, STEINMETZ A, THOMAS C . Arabidopsis LIM proteins: A family of actin bundlers with distinct expression patterns and modes of regulation. The Plant Cell, 2010,22(9):3034-3052. doi: 10.1105/tpc.110.075960 pmid: 20817848
[17]	罗明, 肖月华, 侯磊, 罗小英, 李德谋, 裴炎 . 棉花LIM结构域基因(GhLIM1)的克隆和表达分析. 遗传学报, 2003,30(2):175-182. pmid: 12776607
	LUO M, XIAO Y H, HOU L, LUO X Y, LI D M, PEI Y . Cloning and expression analysis of a LIM-Domain protein gene from cotton ( Gossypium hirsuturm L.). Acta Genetica Sintica, 2003,30(2):175-182. (in Chinese) pmid: 12776607
[18]	HAN L B, LI Y B, WANG H Y, WU X M, LI C L, LUO M, WU S J, KONG Z S, PEI Y, JIAO G L, XIA G X . The dual functions of WLIM1a in cell elongation and secondary wall formation in developing cotton ﬁbers. The Plant Cell, 2013,25(11):4421-4438. doi: 10.1105/tpc.113.116970 pmid: 24220634
[19]	LI Y, JIANG J, LI L, WANG X L, WANG N N, LI D D, LI X B . A cotton LIM, domain-containing protein (GhWLIM5) is involved in bundling actin ﬁlaments. Plant Physiology Biochemistry, 2013,66:34-40. doi: 10.1016/j.plaphy.2013.01.018 pmid: 23466745
[20]	ARNAUD D DÉJARDIN A, LEPLÉ J C, LESAGE-DESCAUSES M C, PILATE G . Genome-wide analysis of LIM gene family in Populus trichocarpa, Arabidopsis thaliana, and Oryza sativa. DNA Research, 2007,14(3):103-116. doi: 10.1093/dnares/dsm013 pmid: 17573466
[21]	WANG H J, WAN A R, JAUH G T . An actin-binding protein, LlLIM1, mediates calcium and hydrogen regulation of actin dynamics in pollen tubes. Plant Physiology Journal, 2008,147(4):1619-1636. doi: 10.1104/pp.108.118604 pmid: 18480376
[22]	吴瑞, 朱家红, 张全琪, 张治礼 . 巴西橡胶树LIM结构域基因克隆与生物信息学分析. 热带植物学报, 2010,1(1):62-65.
	WU R, ZHU J H, ZHANG Q Q, ZHANG Z L . Cloning and bioinformatics analysis of a LIM domain protein gene from Hevea brasiliensis. Journal of tropical organisms, 2010,1(1):62-65. (in Chinese)
[23]	蔡兴怀 . 玉米全基因组LIM基因分析及其进化研究[D]. 合肥: 安徽农业大学, 2011.
	CAI X H . Genome-wide analysis of LIM Genes and evolution pattens in Zea mays L[D]. Hefei: Shandong Agriculture University, 2011. (in Chinese)
[24]	张海燕, 李佐同, 赵长江, 杨克军, 王玉凤, 胡雪微, 赵莹 . 玉米LIM结构域蛋白基因家族分析. 玉米科学, 2013,21(3):40-47.
	ZHANG H Y, LI Z T, ZHAO C J, YANG K J, WANG Y F, HU X W, ZHAO Y . Genome-wide analysis of LIM domain-containing protein gene family in maize. Journal of Maize Sciences, 2013,21(3):40-47. (in Chinese)
[25]	李亚 . 稻瘟病菌四个蛋白编码基因及Gγ亚基编码基因的生物学功能研究[D]. 杭州: 浙江大学, 2013.
	LI Y . Functional analysis of four Lim protein encoding genes and Gγsubunit encoding gene in Magnaporthe oryzae[D]. Hangzhou: Zhejiang University, 2013. (in Chinese)
[26]	NIX D A, FRADELIZI J, BOCKHOLT S, MENICHI B, LOUVARD D, FRIEDERICH E, BECKERLE M C . Targeting of zyxin to sites of actin membrane interaction and to the nucleus. The Journal of Biological Chemistry, 2001,276:34759-34767. doi: 10.1074/jbc.M102820200 pmid: 11395501
[27]	MAUL R S, SONG Y, AMANN K J, GERBIN S C, POLLARD T D, CHANG D D . EPLIN regulates actin dynamics by cross-linking and stabilizing filaments. The Journal of Cell Biology, 2003,160(6):399-407. doi: 10.1083/jcb.200212057 pmid: 12566430
[28]	LEGAY S, GUERRIERO G, ANDRE C, GUIGNARD C, COCCO E, CHARTON S, BOUTRY M, ROWLAND O, HAUSMAN J F . MdMyb93 is a regulator of suberin deposition in russeted apple fruit skins. New Phytologist, 2016,212:977-991. doi: 10.1111/nph.14170 pmid: 27716944
[29]	聂继云, 董雅凤 . 果品质量安全标准与评价指标. 北京: 中国农业出版社, 2013.
	NIE J Y, DONG Y F. Standards and Evaluation Indices for Truit Quality and Safety. Beijing: China Agriculture Press, 2013. (in Chinese)
[30]	DACCORD N, CELTON J M, LINSMITH G, BECKER C, CHOISNE N, SCHIJLEN E, GEEST H, BIANCO L, MICHELETTI D, VELASCO R, PIERRO A D, GOUZY J, REES D J G, GUÉRIF P, MURANTY H, DUREL C E, LAURENS F, LESPINASSE Y, GAILLARD S, AUBOURG S, QUESNEVILLE H, WEIGEL D, WEG E, TROGGIO M, BUCHER E . High-quality de novo assembly of the apple genome and methylome dynamics of early fruit development. Nature Genetics, 2017,49(7):1099-1106. doi: 10.1038/ng.3886 pmid: 28581499
[31]	PROOST S, BEL M V, VANEECHOUTTE D, VANDEPEER Y, INZE D, MUELLER-ROEBER B, VANDEPOELE K . PLAZA 3.0: an access point for plant comparative genomics. Nucleic Acids Research, 2014,43(1):974-981. doi: 10.1093/nar/gku986 pmid: 25324309
[32]	POOLE R L . The TAIR database. Methods Molecular Biology, 2007,406(406):179-402. doi: 10.3390/biology8030063 pmid: 31470601
[33]	ARTIMO P, JONNALAGEDDA M, ARNOLD K, BARATIN D, CSARDI G, DECASTROE E, DUVAUD S, FLEGEL V, FORTIER A, GASTEIGER E . ExPASy: SIB bioinformatics resource portal. Nucleic Acids Research, 2012,40:597-603. doi: 10.1002/prca.201700069 pmid: 28975713
[34]	STOTHARD P . The sequence manipulation suite: JavaScript programs for analyzing and formatting protein and DNA sequences. Biotechniques, 2000,28:1102-1104. doi: 10.2144/00286ir01 pmid: 10868275
[35]	CHEN C J, XIA R, CHEN H, HE Y H . TBtools, a Toolkit for Biologists integrating various biological data handling tools with a user-friendly interface. BioRxiv, 2018: 289660.
[36]	TAMURA K, PETERSON D, PETERSON N, STECHER G, NEI M, KUMAR S . MEGAS: Molecular evolutionary genetics analysis using maximum likelihood, evolutionary distance, and maximum parsimony methods. Molecular Biology and Evolution, 2011,28(10):2731-2739. doi: 10.1093/molbev/msr121
[37]	LIVAK K J, SCHMITTGEN T D . Analysis of relative gene expression data using real-time quantitative PCR and the 2(-Delta Delta C(T)) method. Methods, 2001,25:402-408. doi: 10.1006/meth.2001.1262 pmid: 11846609
[38]	周喆, 张彩霞, 张利义, 王强, 李武兴, 田义, 丛佩华 . 苹果LysM基因家族的生物信息学及表达分析. 中国农业科学, 2013,47(13):2602-2612.
	ZHOU Z, ZHANG C X, ZHANG L Y, WANG Q, LI W X, TIAN Y, CONG P H . Bioinformatics and expression analysis of the LysM gene family in apple. Scientia Agricultura Sinica, 2013,47(13):2602-2612. (in Chinese)
[39]	HENG W, WANG Z T, JIANG X H, JIA B, LIU P, LIU L, YE Z F, ZHU L Y . The role of polyamines during exocarp formation in a russet mutant of ‘Dangshansuli’ pear (Pyrus bretschneideri Rehd.). Plant Cell Report, 2016,35:1841-1852. doi: 10.1007/s00299-016-1998-7 pmid: 27255339
[40]	WANG Y P, TAN X, PATERSON A H . Different patterns of gene structure divergence following gene duplication in Arabidopsis. Genomics, 2013,14:652. doi: 10.1186/1471-2164-14-652 pmid: 24063813
[41]	范贝, 刘明晓, 李慧杰, 张雪, 王晓梅, 崔喜艳 . 拟南芥AAP基因家族的生物信息学分析. 生命的化学, 2015,36(3):372-378.
	FAN B, LIU M X, LI H J, ZHANG X, WANG X M, CUI X Y . Bioinformatics analysis of AAP gene family in Arabidopsis thaliaha. Chemistry of Life, 2015,36(3):372-378. (in Chinese)

基因 Gene	上游引物Forward primer (5′-3′)	下游引物Reverse primer (5′-3′)
MdLIM1	ATGCAGCGCCTGTGATAAGA	GCTCGAAATGAGGTTTGCAGT
MdLIM2	GCTACTTGTGGTAAAACCGCT	CCAAAGCCGCGTAGTTTGAG
MdLIM3	ATGCCAAGTCAGTCTCAAACT	TGGTATGGAGTCCCGTTG
MdLIM4	GGGACCGTAGACAAATGTGC	AGTTGGGCAAAGTGGTGCTT
MdLIM5	AAAACTGTTCGAGAAAGATCCG	GAAGAGTTGGCTATGGTGATGC
MdLIM6	GACAGTCTATCCGCTGGAGA	ACGATGAATGTGTAAGGGCA
MdLIM7	GATGGGATTTCCTACCACAA	CAGTCTCCTTGAACAGTTGCT
MdLIM8	TCTCCTTTCTCAGGGACACC	GCACTTATCTCTGGTTCCACC
MdLIM9	TGCCTACCATAAGACCTGCT	TCTCCTTGAAGAGTTGCTCG
MdLIM10	ACTAGTTCCAGTACACAGACCAAC	CTCCATGAGTGCACCGGAAA
MdLIM11	TCTACCACAAAGCCTGCTTCC	CAAGACTGCCGGTTCTTTTGA
MdActin	TGACCGAATGAGCAAGGAAATTACT	TACTCAGCTTTGGCAATCCACATC

基因 Gene	基因登录号 Gene accession No.	染色体定位 Chromosome location	大小 Size (aa)	分子量 Molecular weight (D)	等电点 Isoelectric point	亚细胞定位 Subcellular Localization
MdLIM1	MD01G1054500	Chr01:15895562..15897359	219	23939.82	6.14	细胞核Nucleus
MdLIM2	MD01G1145700	Chr01:25554814..25556454	199	21649.78	9.01	细胞核Nucleus
						高尔基体Golgi apparatus
MdLIM3	MD05G1101500	Chr05:20964629..20966107	197	22242.34	8.73	细胞核Nucleus
MdLIM4	MD06G1078000	Chr06:19291196..19292843	213	23595.59	7.51	细胞核Nucleus
MdLIM5	MD06G1178800	Chr06:31881986..31883872	188	21297.27	8.86	细胞核Nucleus
MdLIM6	MD07G1140900	Chr07:20424546..20426430	221	24195.19	6.31	细胞核Nucleus
MdLIM7	MD07G1212800	Chr07:29070702..29074084	200	21720.86	9.01	细胞核Nucleus
MdLIM8	MD08G1081300	Chr08:6745950..6747349	96	10755.12	7.03	细胞核Nucleus
MdLIM9	MD14G1098800	Chr14:15093296..15094757	222	24598.9	8.49	细胞核Nucleus
MdLIM10	MD14G1185200	Chr14:27756572..27758485	188	21254.15	8.77	细胞核Nucleus
MdLIM11	MD15G1068200	Chr15:4725341..4726746	195	21931.05	8.87	细胞核Nucleus
						高尔基体Golgi apparatus
