农杆菌介导大麦无筛选标记转基因植株的获得

doi:10.3864/j.issn.0578-1752.2020.18.002

摘要/Abstract

摘要：

【目的】目前,国内外大麦遗传转化主要利用Golden Promise品种,基因依赖性严重,尤其是大麦的转化效率较低,并且获得安全型转基因大麦植株对其进一步产业化非常重要。建立高效、无筛选标记大麦遗传转化体系,拓展大麦遗传转化的受体基因型,为大麦基因功能解析和大麦转基因育种及商业化种植提供技术保障。【方法】以优良大麦品种Vlamingh为受体,取开花授粉后14 d左右的幼胚为转化材料,通过对培养基成分及培养步骤优化,建立农杆菌介导的高效遗传转化体系,并利用该体系将Bar和GUS在不同T-DNA区段的双T-DNA表达载体pWMB123转化大麦,获得候选转基因植株,然后利用PCR、Bar试纸条、组织化学染色和Southern blot等检测方法,在T₁代转基因植株中成功获得无筛选标记大麦转基因植株。【结果】在愈伤组织分化阶段,发现培养基中添加1.0 mg·L^-1 KT、0.5 mg·L^-1 6-BA和0.05 mg·L^-1 NAA明显促进愈伤组织分化。在转基因植株生根阶段,发现采用添加1.0 mg·L^-1的IBA的SM1（无其他生长素）的生根效果最佳,培养基中添加2.5 mg·L^-1 CuSO₄显著降低了大麦转基因植株白化现象。共转化了138个幼胚,最终获得14株大麦转基因植株,转化效率10.14%。PCR、Bar试纸条、GUS染色等检测证实,T₀代转基因植株中均含有Bar,而仅有10株含有GUS,2个T-DNA的共转化效率为71.43%。选取4个同时含有Bar和GUS的转基因植株,对其自交后代进行检测,在BL8株系中筛选到2株只含GUS而不含Bar的转基因植株,无筛选标记效率为6.9%。在T₁代转基因植株中对Bar和GUS进行了Southern blot鉴定,发现在多数转基因植株中Bar和GUS均为多拷贝整合,进一步证实BL8-15和BL8-19为无筛选标记的转基因植株。【结论】利用大麦品种Vlamingh为转化材料可以较高效率获得转基因植株,提高愈伤组织分化效率和转基因植株生根效率,降低转基因植株白化现象。利用农杆菌介导双T-DNA表达载体转化大麦,成功获得了无筛选标记转基因植株。

关键词: 大麦, 遗传转化, 无筛选标记, 农杆菌介导法

Abstract:

【Objective】Genotype dependence is a very serious problem in barley genetic transformation in which Golden Promise has been mainly used. In addition, the transformation efficiency of barley is still very low in China. Moreover, the generation of marker-free transgenic barley plants is very important to the future commercialization of genetically modified barley due to the considerably increased public concerns. It is necessary to establish an efficient genetic transformation system for generating marker-free transgenic barley plants, expand available barley genotypes for genetic transformation, and provide technical support for functional genomics study and breeding and potential commercialization of genetically modified varieties of barley. 【Method】The composition and auxin adding ratio in the medium used for barley transformation as well as culture regime was optimized to establish an efficient Agrobacterium-mediated genetic transformation system for barley using the immature embryos approximately 14 days post anthesis of a good agronomic trait variety Vlamingh. A double T-DNA vector pWMB123 containing the Bar gene and the GUS gene cassette was introduced into barley by Agrobacterium-mediated transformation to obtain marker-free transgenic barley plants in T₁ generation. 【Result】 It is indicated that the shoot induction medium supplemented with 1.0 mg·L^-1 KT, 0.5 mg·L^-1 6-BA and 0.05 mg·L^-1 NAA significantly promoted the differentiation ability of barley transformed calli. The adding of 2.5 mg·L^-1 copper sulfate in shoot induction medium lightened the albinism of transgenic barley plantlets. Through the exploration of different hormone ratios and medium components, it was found that the SM1 supplemented with 1.0 mg·L^-1 IBA without other auxin had the best rooting effect. A total of 138 immature embryos were transformed with Agrobacterium containing pWMB123 vector, and fourteen transgenic barley plants were obtained with a transformation efficiency of 10.14%. Detection by PCR, Quick Stix strips and histochemical staining assays confirmed that all T₀ plants contained Bar gene, among which four plants did not contain GUS gene. The co-transformation efficiency of the two T-DNAs is 71.43%. In the T₁ populations derived from the four T₀ transgenic lines containing Bar and GUS genes, two transgenic plants with GUS gene and without Bar gene were screened out in line BL8, and the efficiency for marker-free transgenic plants was 6.9%. The two foreign genes of Bar and GUS were identified to be integrated in most T₁transgenic barley plants be multiple copies using Southern blot. It was further confirmed that BL8-15 and BL8-19 were marker-free transgenic plants. 【Conclusion】An efficient genetic transformation system mediated by Agrobacterium-mediated for generating marker-free transgenic plants with healthy roots and less albinism were successfully established in barley.

Key words: barley, transformation, marker-free transgenic, agrobacterium-mediated

龚强,王轲,叶兴国,杜丽璞,徐延浩. 农杆菌介导大麦无筛选标记转基因植株的获得[J]. 中国农业科学, 2020, 53(18): 3638-3649.

GONG Qiang,WANG Ke,YE XingGuo,DU LiPu,XU YanHao. Generation of Marker-Free Transgenic Barley Plants by Agrobacterium-Mediated Transformation[J]. Scientia Agricultura Sinica, 2020, 53(18): 3638-3649.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2020.18.002

https://www.chinaagrisci.com/CN/Y2020/V53/I18/3638

图/表 11

图1

表1

表2

图2

图3

图4

图5

图6

图7

表3

图8

参考文献 35

[1]	国家大麦青稞产业技术体系. 中国现代农业产业可持续发展战略研究·大麦青稞分册, 北京: 中国农业出版社, 2018.
	China Agriculture Research System Of Barley. China's Modern Agricultural Industry Sustainable Development Strategy Research · Barley Volume. Beijing: China Agriculture Press, 2018: 2-8. (in Chinese)
[2]	MASCHER M, GUNDLACH H, HIMMELBACH A, BEIER S, TWARDZIOK S O, WICKER T, RADCHUK V, DOCKTER C, HEDLEY P E, RUSSELL J, BAYER M, RAMSAY L, LIU H, HABERER G, ZHANG X Q, ZHANG Q, BARRERO R A, LI L, TAUDIEN S, GROTH M, FELDER M, HASTIE A, SIMKOVA H, STANKOVA H, VRANA J, CHAN S, MUNOZ-AMATRIAIN M, OUNIT R, WANAMAKER S, BOLSER D, COLMSEE C, SCHMUTZER T, ALIYEVA-SCHNORR L, GRASSO S, TANSKANEN J, CHAILYAN A, SAMPATH D, HEAVENS D, CLISSOLD L, CAO S, CHAPMAN B, DAI F, HAN Y, LI H, LI X, LIN C, MCCOOKE J K, TAN C, WANG P, WANG S, YIN S, ZHOU G, POLAND J A, BELLGARD M I, BORISJUK L, HOUBEN A, DOLEZEL J, AYLING S, LONARDI S, KERSEY P, LANGRIDGE P, MUEHLBAUER G J, CLARK M D, CACCAMO M, SCHULMAN A H, MAYER KF X, PLATZER M, CLOSE T J, SCHOLZ U, HANSSON M, ZHANG G, BRAUMANN I, SPANNAGL M, LI C, WAUGH R, STEIN N. A chromosome conformation capture ordered sequence of the barley genome. Nature, 2017,544(7651):427-433. doi: 10.1038/nature22043 pmid: 28447635
[3]	WAN Y, LEMAUX P G. Generation of large numbers of independently transformed fertile barley plants. Plant Physiology, 1994,104(1):37-48. doi: 10.1104/pp.104.1.37 pmid: 12232059
[4]	TINGAY S, MCELROY D, KALLA R, FIEG S, WANG M, THORNTON S, BRETTELL R. Agrobacterium tumefaciens-mediated barley transformation. The Plant Journal, 1997,11(6):1369-1376. doi: 10.1046/j.1365-313X.1997.11061369.x
[5]	TRIFONOVA A, MADSEN S, OLESEN A. Agrobacterium -mediated transgene delivery and integration into barley under a range of in vitro culture conditions. Plant Science, 2001,161(5):871-880. doi: 10.1016/S0168-9452(01)00479-4
[6]	FANG Y D, AKULA C, ALTPETER F. Agrobacterium -mediated barley (Hordeum vulgare L.) transformation using green fluorescent protein as a visual marker and sequence analysis of the T-DNA: barley genomic DNA junctions. Journal of Plant Physiology, 2002,159(10):1131-1138. doi: 10.1078/0176-1617-00707
[7]	TRAVELLA S, ROSS S M, HARDEN J, EVERETT C, SNAPE J W, HARWOOD W A. A comparison of transgenic barley lines produced by particle bombardment and Agrobacterium-mediated techniques. Plant Cell Reports, 2005,23(12):780-789. doi: 10.1007/s00299-004-0892-x
[8]	BARTLETT J G, ALVES S C, SMEDLEY M, SNAPE J W, HARWOOD W A. High-throughput Agrobacterium -mediated barley transformation. Plant Methods, 2008,4(1):22. doi: 10.1186/1746-4811-4-22
[9]	HENSEL G, VALKOV V, MIDDLEFELL-WILLIAMS J, KUMLEHN J. Efficient generation of transgenic barley: The way forward to modulate plant-microbe interactions. Journal of Plant Physiology, 2008,165(1):71-82. doi: 10.1016/j.jplph.2007.06.015 pmid: 17905476
[10]	马春业. 农杆菌介导miR396基因对大麦愈伤组织的遗传转化[D]. 武汉: 华中农业大学, 2016.
	MA C Y. Genetic transformation of miR396 gene into barley callus by Agrobacterium tumefaciens infection[D]. Wuhan: Huazhong Agricultural University, 2016. (in Chinese)
[11]	马玲珑, 任盼荣, 汪军成, 孟亚雄, 马小乐, 李葆春, 王化俊. 啤酒大麦品种甘啤4号成熟胚再生体系的建立. 分子植物育种, 2015,13(3):663-669.
	MA L L, REN P R, WANG J C, MENG Y X, MA X L, LI B C, WANG H J. Establishing regeneration system from mature embryos of beer barley variety Ganpi 4. Molecular Plant Breeding, 2015, 2015,13(3):663-669. (in Chinese)
[12]	余桂红, 张旭, 孙晓波, 马鸿翔. 大麦苏啤4号幼胚愈伤组织的诱导及植株的高频再生. 江苏农业学报, 2013,29(5):953-956.
	YU G H, ZHANG X, ZHANG X B, MA H X. Calli induction from immature embryos and plantlet high frequency regeneration of Hordeum vulgare L. cv.Supi 4. Jiangsu Journal of Agricultural Science, 2013,29(5):953-956. (in Chinese)
[13]	王兴珍, 林国梁, 赖勇, 杨轲, 孟亚雄, 李葆春, 马小乐, 尚勋武, 王化俊. 西北地区特色大麦品种成熟胚离体培养的初步研究. 麦类作物学报, 2013,33(2):286-289. doi: 10.7606/j.issn.1009-1041.2013.02.013
	WANG X Z, LIN G L, LAI Y, YANG K, MENG Y X, LI B C, MA X L, SHANG X W, WANG H J. Preliminary study of tissue culture for mature embryo from local feature barley. Journal of Triticeae Crops, 2013,33(2):286-289. (in Chinese) doi: 10.7606/j.issn.1009-1041.2013.02.013
[14]	黎冬华, 廖玉才, 李和平. 根癌农杆菌介导的大麦茎尖转化研究. 麦类作物学报, 2012,32(1):44-47. doi: 10.7606/j.issn.1009-1041.2012.01.008
	LI D H, LIAO Y C, LI H P. Transformation of shoot apical meristems of elit barley cultivars via agribacterium-mediated transformation. Journal of Triticeae Crops, 2012,32(1):44-47. (in Chinese) doi: 10.7606/j.issn.1009-1041.2012.01.008
[15]	高润红, 杜志钊, 郭桂梅, 邹磊, 何婷, 陈志伟, 李梁, 陆瑞菊, 黄剑华. 优良大麦品种花30幼胚遗传转化体系的优化. 植物遗传资源学报, 2012,13(5):901-906.
	GAO R H, DU Z Z, GUO G M, ZOU L, HE T, CHEN Z W, LI L, LU R J, HUANG J H. Optimization of genetic transformation system for immature embryos of improved barley( Hordeum vulgare L.) variety Hua 30. Journal of Plant Genetic Resources, 2012,13(5):901-906. (in Chinese)
[16]	闫永荣, 张正英, 李静雯, 李淑洁. 甘啤4号大麦幼胚愈伤组织诱导及植株再生的研究. 分子植物育种, 2010,8(1):89-93.
	YAN Y R, ZHANG Z Y, LI J W, LI S J. Studies on callus induction and plant regeneration from immature embryos of Ganpi4 hao. Molecular Plant Breeding, 2010,8(1):89-93. (in Chinese)
[17]	李静雯, 张正英. 根癌农杆菌介导的大麦幼胚遗传转化影响因素研究. 大麦与谷类科学, 2010(2):1-6.
	LI J W, ZHANG Z Y. Study on factors influencing the genetic transformation of immature barley embryos mediated byAgrobacterium tumefaciens. Barley and Cereal Science, 2010(2):1-6. (in Chinese)
[18]	郭晓琳, 张红伟, 刘欣洁, 刘亚娟, 张锋, 孙东发, 谭振波. 大麦成熟胚愈伤组织的诱导和植株再生的研究. 植物遗传资源学报, 2005,6(4):418-422.
	GUO X L, ZHANG H W, LIU X J, LIU Y J, ZHANG F, SUN D F, TAN Z B. Study on callus induction and plant regeneration from mature embryos of barley elite cultivars. Journal of Plant Genetic Resources, 2005,6(4):418-422. (in Chinese)
[19]	李会勇, 尹钧, 刘雷, 任江萍, 郭向云, 李志远. Cu²⁺浓度对啤酒大麦幼胚组织培养与植株再生的影响 . 麦类作物学报, 2003,23(2):27-29. doi: 10.7606/j.issn.1009-1041.2003.02.047
	LI H Y, YIN J, LIU L, REN J P, GUO X Y, LI Z Y. Effect of Cu²⁺concentration on tissue culture and plant regeneration of beer barley . Journal of Triticeae Crops, 2003,23(2):27-29. (in Chinese) doi: 10.7606/j.issn.1009-1041.2003.02.047
[20]	严华军, 王君晖. 大麦成熟胚胚性愈伤组织的高频诱导和植株再生. 作物学报, 1996,22(1):58-65.
	YAN H J, WANG J H. Efficeient induction of embryogenic callus and regeneration from barley mature embryos. Acta Agronomoca Sinica, 1996,22(1):58-65. (in Chinese)
[21]	REN J, LIU L, YIN J, WANG X, LI L. Optimization of transgenic system of barley and transformation of TrxS gene by means of particle bombardment. Acta Botanica Boreali-Occidentalia Sinica, 2004,24(9):1662-1668.
[22]	孔维威. TrxS的表达及其对啤酒大麦发芽种子水解酶和贮藏物质降解的影响[D]. 郑州: 河南农业大学, 2006.
	KONG W W. The expression and the effects of TrxS gene on hydrolytic enzyme and degration of storage substances during malting barley seed germination[D]. Zhengzhou: Henan Agricultural University, 2006. (in Chinese)
[23]	吕维涛, 刘芳, 崔德才, 赵檀方. 农杆菌介导法获得转反义磷脂酶Dγ基因大麦. 生物技术, 2005,15(5):11-13.
	LÜ W T, LIU F, CUI D C, LIU T F. Production of transgenic barley with Anti -PLDγ gene via Agrobacterium tumefaciens. Biotechnology, 2005,15(5):11-13. (in Chinese)
[24]	李静雯, 张正英, 令利军, 李淑洁. 利用RNAi抑制B-hordein合成降低大麦籽粒蛋白质含量. 中国农业科学, 2014,47(19):3746-3756. doi: 10.3864/j.issn.0578-1752.2014.19.003
	LI J W, ZHANG Z Y, LING L J, LI S J. Creating low grain protein content barley by suppressing b-hordein synthesis through RNA interference. Scientia Agricultura Sinica, 2014,47(19):3746-3756. (in Chinese) doi: 10.3864/j.issn.0578-1752.2014.19.003
[25]	叶兴国, 陈明, 杜丽璞, 徐惠君. 小麦转基因方法及其评述. 遗传, 2011,33(5):422-430.
	YE X G, CHEN M, DU L P, XU H J. Description and evaluation of transformation approaches used in wheat. Hereditas, 2011,33(5):422-430. (in Chinese)
[26]	WANG K, LIU H, DU L, YE X G. Generation of marker-free transgenic hexaploid wheat via an Agrobacterium-mediated co- transformation strategy in commercial Chinese wheat varieties. Plant Biotechnology Journal, 2016,15(5):614-623. doi: 10.1111/pbi.12660 pmid: 27862820
[27]	MCCORMAC A C, FOWLER M R, CHEN D F, ELLIOTT M C. Efficient Co-transformation of Nicotiana tabacum by two independent T-DNAs, the effect of T-DNA size and implications for genetic separation. Transgenic Research, 2001,10(2):143-155. doi: 10.1023/A:1008909203852
[28]	XING A, ZHANG Z, SATO S, STASWICK P, CLEMENTE T. The use of the two T-DNA binary system to derive marker-free transgenic soybeans. Vitro Cellular & Developmental Biology Plant, 2000,36(6):456-463.
[29]	MILLER M, TAGLIANI L, WANG N, BERKA B, BIDNEY D, ZHAO Z Y. High efficiency transgene segregation in Co-transformed maize plants using an Agrobacterium tumefaciens 2 T-DNA binary system. Transgenic Research, 2002,11(4):381-396. doi: 10.1023/A:1016390621482
[30]	LU L, WU X, YIN X, MORRAND J, CHEN X, FOLK W R, ZHANG Z J. evelopment of marker-free transgenic sorghum [Sorghum bicolor (L.) Moench] using standard binary vectors with bar as a selectable marker. Plant Cell Tissue & Organ Culture, 2009,99(1):97-108.
[31]	MANGU V R R, CHIDAMBARAM P, RAJASEKARAN S, KARUPPANNAN V. Transgene stacking and marker elimination in transgenic rice by sequential Agrobacterium-mediated co-transformation with the same selectable marker gene. Plant Cell Reports, 2011,30(7):1241-1252. doi: 10.1007/s00299-011-1033-y
[32]	ISHIDA Y, TSUNASHIMA M, HIEI Y, KOMARI T. Wheat (Triticum aestivum L.). Methods in Molecular Biology, Agrobacterium Protocols, 3rd edn. New York: Springer, 2014: 189-198.
[33]	MATTHEWS P R, WANG M B, WATERHOUSE P M, THORNTON S, FIEG S J, GUBLER F, JACOBSEN J V. Marker gene elimination from transgenic barley, using co-transformation with adjacent `twin T-DNAs' on a standard Agrobacterium transformation vector. Molecular Breeding, 2001,7(3):195-202. doi: 10.1023/A:1011333321893
[34]	YAO Q, CONG L, CHANG J L, LI K X, YANG G X, HE G Y. Low copy number gene transfer and stable expression in a commercial wheat cultivar via particle bombardment. Journal of Experimental Botany, 2006,57(14):3737-3746. doi: 10.1093/jxb/erl145 pmid: 17032730
[35]	YAO Q, CONG L, HE G, CHANG J, LI K, YANG G. Optimization of wheat co-transformation procedure with gene cassettes resulted in an improvement in transformation frequency. Molecular Biology Reports, 2007,34(1):61-67. doi: 10.1007/s11033-006-9016-8

组分 Composition	侵染液 IM	共培养培养基 CM	第一次筛选培养基 SM1	第二次筛选培养基 SM2	过渡培养基 TM	分化培养基 DM
MS	0.434	0.434	4.340	4.340	2.700	2.170
麦芽糖 Maltose			30	30	20	20
葡萄糖 Glucose	10	10
乙酰丁香酮Acetosyringone	0.02745	0.03924
谷氨酰胺 Glutamine					0.75
酪蛋白水解物Casein hydrolysate			1	1
肌醇 Myoinositol			0.35	0.35
脯氨酸 Proline			0.69	0.69
盐酸硫胺Thiamine HCl			0.001	0.001	0.004
麦草畏Dicamba			0.0025	0.0025
二氯苯氧乙酸2, 4-D					0.0025
硫酸铜CuSO₄			0.00125	0.00125	0.00125	0.00125
6-苄氨基嘌呤6-BA					0.0001
琼脂糖Agarose		8
植物凝胶Phytagel			3.5	3.5	3.5	3.0
草铵膦Phosphinothricin^a			0.005	0.010	0.010	0.005
羧苄青霉素Carbenicillin^a			0.25	0.25	0.25	0.25
头孢噻肟Cefotaxime^a			0.25

培养基编号 Medium ID	IAA	IBA	NAA
SR1	1	1	1
SR2	1	1	2
SR3	1	2	1
SR4	2	1	1
SR5	1	1	0
SR6	1	0	1
SR7	0	1	1
SR8	1	0	0
SR9	2	0	0
SR10	0	0	1
SR11	0	0	1.5
SR12	0	0	2
SR13	0	1	0
SR14	0	1.5	0
SR15	0	2	0

株系 Lines	Bar⁺GUS⁺	Bar⁺GUS^—	Bar^—GUS⁺
BL1	19	1	0
BL6	23	0	0
BL-7	24	2	0
BL-8	27	0	2
