除臭菌的筛选及其在堆肥中的应用效果

doi:10.3864/j.issn.0578-1752.2024.13.010

摘要/Abstract

摘要：

【目的】筛选新型除臭菌，解决以鸡粪为主要原料的有机肥厂的臭气排放问题，为好氧堆肥生物除臭技术提供理论依据和支撑。【方法】以鸡粪为筛菌样品，利用定性初筛、驯化富集、分离纯化、定量复筛、拮抗试验以及耐药性试验筛选能够满足多重目标的除臭菌，并通过形态观察与16S rDNA测序鉴定菌株。将筛选获得的除臭菌株制成复合菌剂BH并应用于鸡粪堆肥，共设置3个处理，分别为对照CK（原料中不添加菌剂）、DT1（原料中添加1%除臭菌剂BH）、DT2（原料中添加1%的市售商品除臭菌剂）。在堆肥不同时期，分析测定堆体温度、pH、电导率（EC）、庆大霉素（GM）含量以及NH₃排放量等指标，探讨耐药性除臭菌剂BH对堆肥过程的影响。【结果】初步筛选分离获得15株细菌，命名为BH1—BH15，未筛选到真菌；经复筛发现，菌株BH2、BH5、BH9、BH11、BH12和BH15对NH₃的去除率较高，分别为48.8%、49.4%、45.8%、48.3%、51.0%和51.8%，且各菌株间无拮抗作用。对除臭菌株耐药性研究发现，菌株BH11和BH12对庆大霉素具有较强的耐受性；经形态学特征与分子生物学鉴定，菌株BH11为Bordetella sp.，BH12为Weeksella massiliensis。将菌株BH11和BH12制成复合菌剂BH，其除臭效果显著优于单一菌剂，NH₃去除率高达65.8%。堆肥试验中，各处理高温期均持续9 d以上，实现了鸡粪的无害化处理；堆肥结束时各处理的pH稳定在8.4左右，处于5.5—8.5之间，EC在2.73—3.43 mS·cm^-1之间，低于4 mS·cm^-1，表明物料可用作植物肥料且符合有机肥标准。研究发现，DT2处理的GM降解效率显著高于CK处理，表明商品菌剂能够促进庆大霉素降解。此外，堆肥过程中NH₃的排放主要发生在堆肥升温期与高温期，且高温期的排放量高于升温期；与CK处理相比，菌剂BH显著抑制升温期NH₃的排放，且除臭效果优于商品菌剂；而进入高温期后，商品菌剂除臭效果优于菌剂BH。【结论】筛选获得2株耐药性除臭菌，对NH₃的去除率分别为48.3%（BH11）和51.0%（BH12），制成的复合菌剂BH对NH₃的去除率高达65.8%。将菌剂BH应用于鸡粪堆肥，可以有效减少堆肥过程中NH₃的排放，且各指标均符合堆肥腐熟标准。

关键词: 除臭菌, 耐药性, 筛选, 复合菌剂, 鸡粪, 堆肥

Abstract:

【Objective】 The aim of this study was to screen new deodorizing bacteria for solving the problem of odor emission from organic fertilizer plants with chicken manure as the main raw material, and providing the theoretical basis and support for aerobic composting biological deodorization technology.【Method】 The chicken manure was used as the sample to screen deodorizing bacteria to meet multiple goals by qualitative preliminary screening, domestication and enrichment, separation and purification, quantitative re-screening, antagonism test and drug-resistance test. The strains were identified by morphological observation and 16S rDNA sequence, and the compound bacteria agent BH was prepared and applied to chicken manure composting. Three treatments were set up, including raw materials without biological agents (CK), raw materials mixed with 1% biological deodorizing agent BH (DT1), and raw materials mixed with 1% purchased biological deodorizing agent (DT2). Some indexes were detected, including temperature, pH, electroconductibility (EC), gentamicin (GM) content and NH₃ emission, to explore the effect of BH during composting.【Result】 15 strains of bacteria were screened and isolated, named as BH1-BH15, but no fungi were screened. After rescreening, it was found that strains BH2, BH5, BH9, BH11, BH12 and BH15 had higher removal rates of NH₃, which were 48.8%, 49.4%, 45.8%, 48.3%, 51.0% and 51.8%, respectively, and there was no antagonism among the strains. The study on the drug-resistance of deodorizing strains showed that strains BH11 and BH12 had strong resistance to gentamicin. BH11 was identified as Bordetella sp. and BH12 was identified as Weeksella massiliensis by morphology and molecular biology. Then strain BH11 and BH12 were made into compound bacterial agent BH, and its deodorizing effect was significantly better than that of single bacterial agent, with the removal rate of NH₃ was 65.8%. During composting, the thermophilic phase of each treatment lasted for more than 9 days, and the harmless treatment of chicken manure was achieved. At the end of composting, the pH value of each treatment was stable at 8.40, between 5.5 and 8.5, and the EC was between 2.73 and 3.43 mS·cm^-1, lower than 4 mS·cm^-1, indicated that the material could be used as plant fertilizer and met the organic fertilizer standards. It was found that the GM degradation efficiency of DT2 treatment was significantly higher than that of CK treatment, indicated the commercial bacterial agent could promote the degradation of gentamicin. In addition, the emission of NH₃ during composting mainly occurred in mesophilic phase and thermophilic phase, and the emission in thermophilic phase was higher than that in mesophilic phase. Compared with CK treatment, the bacterial agent BH significantly inhibited the emission of NH₃ in mesophilic phase, and the deodorization effect was better than that of the commercial bacterial agent. After entering thermophilic phase, the deodorization effect of commercial bacterial agent was better than that of bacterial agent BH.【Conclusion】 Two strains of drug-resistant deodorizing bacteria were screened and the removal rates of NH₃ were 48.3% (BH11) and 51.0% (BH12), respectively, and the removal rate of NH₃ by the compound bacterial agent BH was 65.8%. The application of bacterial agent BH to chicken manure composting could effectively reduce the emission of NH₃ during composting, and all indicators met the standards of composting maturity.

Key words: deodorizing bacteria, drug resistance, screening, compound bacterial agent, chicken manure, composting

魏启航, 冯瑶, 王晓醒, 朱宏岗, 方昭, 李兆君. 除臭菌的筛选及其在堆肥中的应用效果[J]. 中国农业科学, 2024, 57(13): 2623-2634.

WEI QiHang, FENG Yao, WANG XiaoXing, ZHU HongGang, FANG Zhao, LI ZhaoJun. Screening of Deodorizing Bacteria and Its Application in Composting[J]. Scientia Agricultura Sinica, 2024, 57(13): 2623-2634.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2024.13.010

https://www.chinaagrisci.com/CN/Y2024/V57/I13/2623

图/表 11

表1

图1

表2

图2

图3

图4

图5

图6

图7

表3

图8

参考文献 45

[1]	中华人民共和国生态环境部, 国家统计局, 中华人民共和国农业农村部. 第二次全国污染源普查公报. 环境保护, 2020, 48(18): 8-10.
	Ministry of Ecology and Environment of the People’s Republic of China, National Bureau of Statistics, Ministry of Agriculture and Rural Affairs of the People’s Republic of China. The second national pollution source census bulletin. Environmental Protection, 2020, 48(18): 8-10. (in Chinese)
[2]	再协. 《关于推进农业废弃物资源化利用试点的方案》解读. 中国资源综合利用, 2016, 34(10): 15-16.
	ZAI X. Interpretation of “scheme for promoting the pilot project of agricultural waste resource utilization”. China Resources Comprehensive Utilization, 2016, 34(10): 15-16. (in Chinese)
[3]	中华人民共和国国务院办公厅. 国务院办公厅关于促进畜牧业高质量发展的意见. 中华人民共和国国务院公报, 2020(29): 20-24.
	General Office of the State Council of the People’s Republic of China. Opinions of the General Office of the State Council on promoting high-quality development of animal husbandry. Gazette of the State Council of the People’s Republic of China, 2020(29): 20-24. (in Chinese)
[4]	CAO Y B, WANG X, LIU L, VELTHOF G L, MISSELBROOK T, BAI Z H, MA L. Acidification of manure reduces gaseous emissions and nutrient losses from subsequent composting process. Journal of Environmental Management, 2020, 264: 110454.
[5]	CHEN H Y, AWASTHI S K, LIU T, DUAN Y M, REN X N, ZHANG Z Q, PANDEY A, AWASTHI M K. Effects of microbial culture and chicken manure biochar on compost maturity and greenhouse gas emissions during chicken manure composting. Journal of Hazardous Materials, 2020, 389: 121908.
[6]	DOMINGO J L, ROVIRA J, VILAVERT L, NADAL M, FIGUERAS M J, SCHUHMACHER M. Health risks for the population living in the vicinity of an Integrated Waste Management Facility: Screening environmental pollutants. Science of the Total Environment, 2015, 518/519: 363-370.
[7]	PARK J, KANG T, HEO Y, LEE K, KIM K, LEE K, YOON C. Evaluation of short-term exposure levels on ammonia and hydrogen sulfide during manure-handling processes at livestock farms. Safety and Health at Work, 2020, 11(1): 109-117. doi: 10.1016/j.shaw.2019.12.007 pmid: 32206381
[8]	ZHOU S Z, LI Y J, LIAO X D, WANG W, MAO C F, MI J D, WU Y B, WANG Y. A low-cost deodorizing spray net device for the removal of ammonia emissions in livestock houses. Journal of Cleaner Production, 2021, 318: 128516.
[9]	吴伟霞, 席北斗, 黄彩红, 李艳红, 李伟, 马彩云, 郭威, 唐朱睿. 有机固废堆肥中产臭及除臭技术的微生物作用机制研究进展. 环境科学研究, 2021, 34(10): 2486-2496.
	WU W X, XI B D, HUANG C H, LI Y H, LI W, MA C Y, GUO W, TANG Z R. Review on microbial mechanism of odor generation and deodorization technology during organic solid waste composting. Research of Environmental Sciences, 2021, 34(10): 2486-2496. (in Chinese)
[10]	魏启航, 任艳芳, 何俊瑜, 李兆君. 畜禽养殖废弃物堆肥过程中微生物除臭研究进展. 中国农业科学, 2020, 53(15): 3134-3145. doi: 10.3864/j.issn.0578-1752.2020.15.013.
	WEI Q H, REN Y F, HE J Y, LI Z J. Research progress of microbial deodorization in livestock and poultry wastes composting. Scientia Agricultura Sinica, 2020, 53(15): 3134-3145. doi: 10.3864/j.issn.0578-1752.2020.15.013. (in Chinese)
[11]	李玥, 李成成, 李静, 张潇月, 张紫薇, 黄议漫, 刘浩, 罗鸿, 张小平, 赵珂. 鸡粪除臭菌的分离筛选及除臭效果分析. 农业环境科学学报, 2020, 39(5): 1103-1110.
	LI Y, LI C C, LI J, ZHANG X Y, ZHANG Z W, HUANG Y M, LIU H, LUO H, ZHANG X P, ZHAO K. Isolation and screening of deodorant bacterial strains from chicken manure and analysis of their deodorant effects. Journal of Agro-Environment Science, 2020, 39(5): 1103-1110. (in Chinese)
[12]	张宏才, 魏荷芬, 汪顺丽, 胡子全, 赵海泉. 鸡粪除臭菌的筛选、培养条件优化及其应用. 安全与环境学报, 2017, 17(1): 250-255.
	ZHANG H C, WEI H F, WANG S L, HU Z Q, ZHAO H Q. Optimized microorganism for deodorizing the chicken manure, and the related culture conditions. Journal of Safety and Environment, 2017, 17(1): 250-255. (in Chinese)
[13]	沈琦, 孙筱君, 吴逸飞, 姚晓红, 李园成, 孙宏, 王新, 汤江武. 畜禽粪污除臭微生物的筛选与鉴定. 浙江农业科学, 2019, 60(11): 2110-2113. doi: 10.16178/j.issn.0528-9017.20191156
	SHEN Q, SUN X J, WU Y F, YAO X H, LI Y C, SUN H, WANG X, TANG J W. Screening and identification of deodorant microorganism for livestock manure. Journal of Zhejiang Agricultural Sciences, 2019, 60(11): 2110-2113. (in Chinese)
[14]	赵党阳. 漯河垃圾填埋场除臭菌种筛选及培养条件优化. 河南化工, 2020, 37(10): 15-18, 55.
	ZHAO D Y. Screening of deodorizing bacteria and optimization of culture conditions in Luohe landfill. Henan Chemical Industry, 2020, 37(10): 15-18, 55. (in Chinese)
[15]	LI H Y, CHENG W M, LI B H, XU Y, ZHENG X Q. The fate of antibiotic resistance genes during co-composting of swine manure with cauliflower and corn straw. Bioresource Technology, 2020, 300: 122669.
[16]	尹红梅, 刘标, 郭照辉, 许丽娟, 杜东霞, 陈薇. 1株畜禽粪便堆肥脱氨除臭菌的筛选及特性. 江苏农业科学, 2020, 48(17): 261-265.
	YIN H M, LIU B, GUO Z H, XU L J, TU D X, CHEN W. Screening and characterization of a denitrifying and deodorizing strain from manure compost. Jiangsu Agricultural Sciences, 2020, 48(17): 261-265. (in Chinese)
[17]	曹慧, 强者. 兽用抗生素的分类及临床特点. 畜牧兽医科技信息, 2022(12): 239-241.
	CAO H, QIANG Z. Classification and clinical characteristics of veterinary antibiotics. Chinese Journal of Animal Husbandry and Veterinary Medicine, 2022(12): 239-241. (in Chinese)
[18]	RAI R, SUTHAR S. Composting of toxic weed Parthenium hysterophorus: Nutrient changes, the fate of faecal coliforms, and biopesticide property assessment. Bioresource Technology, 2020, 311: 123523.
[19]	刘元望. 庆大霉素菌渣堆肥化处理机制及风险评估[D]. 北京: 中国农业科学院, 2020.
	LIU Y W. Mechanism and risk assessment of composting using gentamicin fermentation residue[D]. Beijing: Chinese Academy of Agricultural Sciences, 2020. (in Chinese)
[20]	刘春青, 张勇. 猪舍氨气含量检测方法综述. 猪业科学, 2011, 28(11): 80-82.
	LIU C Q, ZHANG Y. Summary of detection methods of ammonia content in piggery. Swine Industry Science, 2011, 28(11): 80-82. (in Chinese)
[21]	李海龙, 胡峻, 吴小国, 马威, 刘美玲. 除臭微生物的筛选、鉴定及其应用效果. 环境科学与技术, 2016, 39(S2): 73-78.
	LI H L, HU J, WU X G, MA W, LIU M L. Screening, identification of deodorant microbial and its application effect. Environmental Science & Technology, 2016, 39(S2): 73-78. (in Chinese)
[22]	窦建军, 徐芯渝. 高效除臭菌的分离筛选及Biolog鉴定. 安徽农业科学, 2018, 46(32): 66-70.
	DOU J J, XU X Y. Isolation and screening of high-efficiency deodorizing bacteria and identification of biolog. Journal of Anhui Agricultural Sciences, 2018, 46(32): 66-70. (in Chinese)
[23]	张生伟, 姚拓, 黄旺洲, 杨巧丽, 滚双宝. 猪粪高效除臭微生物菌株筛选及发酵条件优化. 草业学报, 2015, 24(11): 38-47. doi: 10.11686/cyxb2014513
	ZHANG S W, YAO T, HUANG W Z, YANG Q L, GUN S B. Optimization of fermentation conditions of swine manure and screening for efficient microbial deodorant strains. Acta Prataculturae Sinica, 2015, 24(11): 38-47. (in Chinese)
[24]	杨井泉, 张云峰, 高磊, 沈敏. 2株兼具除臭功能的纤维素降解细菌的分离鉴定. 家畜生态学报, 2018, 39(9): 46-51.
	YANG J Q, ZHANG Y F, GAO L, SHEN M. Isolation and identification of two strains of cellulose-decomposing bacterium with the function of deodorization. Journal of Domestic Animal Ecology, 2018, 39(9): 46-51. (in Chinese)
[25]	刘标, 尹红梅, 刘惠知. 病死猪堆肥降氨除臭微生物的筛选与鉴定. 科学技术与工程, 2018, 18(34): 248-252.
	LIU B, YIN H M, LIU H Z. Screening and identification of deodorant microorganism for dead-pig composting. Science Technology and Engineering, 2018, 18(34): 248-252. (in Chinese)
[26]	王晓醒, 郭雪琦, 冯瑶, 冀拯宇, 刘聪, 李兆君. 堆肥过程中抗生素和耐药基因消减研究进展. 农业环境科学学报, 2021, 40(11): 2383-2394.
	WANG X X, GUO X Q, FENG Y, JI Z Y, LIU C, LI Z J. Progress of the degradation of antibiotics and the elimination of antibiotic resistance genes. Journal of Agro-Environment Science, 2021, 40(11): 2383-2394. (in Chinese)
[27]	黄玉杰, 陈贯虹, 张强, 张闻, 孔学, 傅晓文, 王加宁. 微生物除臭剂在畜禽粪便无害化处理中的应用进展. 当代畜牧, 2017(9): 53-57.
	HUANG Y J, CHEN G H, ZHANG Q, ZHANG W, KONG X, FU X W, WANG J N. Application of microbial deodorant in the harmless treatment of livestock manure. Contemporary Animal Husbandry, 2017(9): 53-57. (in Chinese)
[28]	屈艳芬, 叶锦韶, 尹华. 生物过滤法处理城市污水处理厂臭气. 生态科学, 2005, 24(1): 18-20.
	QU Y F, YE J S, YIN H. Removal on odor of municipal sewage by biofiltration. Ecologic Science, 2005, 24(1): 18-20. (in Chinese)
[29]	徐昌文, 刘宁, 文斌, 张凯, 余志菊, 简文素, 傅祥超, 刘汉中. 四川地区动物源支气管败血波氏杆菌多重耐药性调查研究. 草学, 2021(5): 67-72, 79.
	XU C W, LIU N, WEN B, ZHANG K, YU Z J, JIAN W S, FU X C, LIU H Z. Investigation on multi drug resistance of Bordetella bronchiseptica in Sichuan Province. Journal of Grassland and Forage Science, 2021(5): 67-72, 79. (in Chinese)
[30]	韩保安, 凌超, 李扬, 鲍大林, 赵鸿涛, 胡子全, 赵海泉. 猪粪除臭菌的筛选、复配以及培养条件的优化. 家畜生态学报, 2017, 38(12): 55-61, 72.
	HAN B A, LING C, LI Y, BAO D L, ZHAO H T, HU Z Q, ZHAO H Q. Selection of pig manure deodorant, compound and optimization of culture conditions. Journal of Domestic Animal Ecology, 2017, 38(12): 55-61, 72. (in Chinese)
[31]	JIANG J S, LIU X L, HUANG Y M, HUANG H. Inoculation with nitrogen turnover bacterial agent appropriately increasing nitrogen and promoting maturity in pig manure composting. Waste Management, 2015, 39: 78-85. doi: 10.1016/j.wasman.2015.02.025 pmid: 25769536
[32]	BARGOUGUI L, GUERGUEB Z, CHAIEB M, MEKKI A. Co-composting of olive industry wastes with poultry manure and evaluation of the obtained compost maturity. Waste and Biomass Valorization, 2020, 11(11): 6235-6247.
[33]	XU Y L, LI X Y, CONG C, GONG G L, XU Y P, CHE J, HOU F Q, CHEN H L, WANG L L. Use of resistant Rhizoctonia cerealis strains to control wheat sharp eyespot using organically developed pig manure fertilizer. The Science of the Total Environment, 2020, 726: 138568.
[34]	LI H H, ZHANG T, TSANG D C W, LI G X. Effects of external additives: Biochar, bentonite, phosphate, on co-composting for swine manure and corn straw. Chemosphere, 2020, 248: 125927.
[35]	AWASTHI M K, PANDEY A K, BUNDELA P S, WONG J W C, LI R H, ZHANG Z Q. Co-composting of gelatin industry sludge combined with organic fraction of municipal solid waste and poultry waste employing zeolite mixed with enriched nitrifying bacterial consortium. Bioresource Technology, 2016, 213: 181-189. doi: S0960-8524(16)30152-3 pmid: 26897474
[36]	中华人民共和国农业农村部. NY/T 525—2021: 有机肥料. 北京: 中国农业出版社, 2021.
	Ministry of Agriculture and Rural Affairs of the People's Republic of China. NY/T 525—2021: Organic fertilizer. Beijing: China Agriculture Press, 2021. (in Chinese)
[37]	WANG G Y, KONG Y L, LIU Y, LI D Y, ZHANG X H, YUAN J, LI G X. Evolution of phytotoxicity during the active phase of co-composting of chicken manure, tobacco powder and mushroom substrate. Waste Management, 2020, 114: 25-32. doi: S0956-053X(20)30344-5 pmid: 32645612
[38]	AWASTHI M K, DUAN Y M, AWASTHI S K, LIU T, ZHANG Z Q, KIM S H, PANDEY A. Effect of biochar on emission, maturity and bacterial dynamics during sheep manure compositing. Renewable Energy, 2020, 152: 421-429.
[39]	LIU T, KUMAR AWASTHI M, KUMAR AWASTHI S, REN X N, LIU X Y, ZHANG Z Q. Influence of fine coal gasification slag on greenhouse gases emission and volatile fatty acids during pig manure composting. Bioresource Technology, 2020, 316: 123915.
[40]	KAMEI-ISHIKAWA N, MAEDA T, SOMA M, YOSHIDA N, SAMESHIMA Y, SASAMOTO M, HIGASHIYAMA Y, TOUNO E, ITO A. Tylosin degradation during manure composting and the effect of the degradation byproducts on the growth of green algae. The Science of the Total Environment, 2020, 718: 137295.
[41]	ERICKSON B D, ELKINS C A, MULLIS L B, HEINZE T M, WAGNER R D, CERNIGLIA C E. A metallo-β-lactamase is responsible for the degradation of ceftiofur by the bovine intestinal bacterium Bacillus cereus P41. Veterinary Microbiology, 2014, 172(3/4): 499-504.
[42]	LIU Y W, FENG Y, CHENG D M, XUE J M, WAKELIN S A, HU H Y, LI Z J. Gentamicin degradation and changes in fungal diversity and physicochemical properties during composting of gentamicin production residue. Bioresource Technology, 2017, 244: 905-912. doi: S0960-8524(17)31362-7 pmid: 28847079
[43]	冯瑶. 鸡粪堆肥过程中诺氟沙星削减规律及微生物分子生态学机制[D]. 北京: 中国农业科学院, 2016.
	FENG Y. Microbial ecological mechanism for degradation of norfloxacin during chicken manure composting[D]. Beijing: Chinese Academy of Agricultural Sciences, 2016. (in Chinese)
[44]	ZHANG H D, MARCHANT-FORDE J N, ZHANG X Y, WANG Y. Effect of cornstalk biochar immobilized bacteria on ammonia reduction in laying hen manure composting. Molecules, 2020, 25(7): 1560.
[45]	HOANG H G, THUY B T P, LIN C, VO D V N, TRAN H T, BAHARI M B, LE V G, VU C T. The nitrogen cycle and mitigation strategies for nitrogen loss during organic waste composting: A review. Chemosphere, 2022, 300: 134514.

指标 Index	pH	EC (mS·cm^-1)	含水率 Moisture content (%)	有机碳 Organic carbon (%)	全氮 Total nitrogen (%)
鸡粪 Chicken manure	6.55	3.86	54.07	28.97	3.83
玉米秸秆 Corn straw	/	/	9.69	49.81	0.64

菌株Strain	BH2	BH5	BH9	BH11	BH12	BH15
BH2	-
BH5	-	-
BH9	-	-	-
BH11	-	-	-	-
BH12	-	-	-	-	-
BH15	-	-	-	-	-	-

处理Treatment	庆大霉素含量Gentamicin content		降解率 Degradation rate (%)
处理Treatment	1 d (mg·kg^-1)	40 d (mg·kg^-1)	降解率 Degradation rate (%)
CK	38.76±1.50	19.79±0.61	48.88±2.65a
DT1	38.57±1.62	19.51±0.49	49.40±0.86a
DT2	38.78±0.91	17.13±0.72	55.82±1.47b
