基于感官评价及GC-MS结合OPLS-DA分析热杀菌对蟠桃汁呈香品质的影响

doi:10.3864/j.issn.0578-1752.2022.12.013

摘要/Abstract

摘要：

【目的】通过解析热杀菌对蟠桃汁呈香物质的影响,结合多元统计模型探究热杀菌过程中蟠桃汁风味品质劣变主要靶点因素,为高品质蟠桃汁风味品质的调控提供理论基础。【方法】以新疆4种主要的蟠桃品种（‘早露蟠’（ZLP）、‘早蟠’（ZP）、‘瑞蟠1号’（RP1）、‘瑞蟠18号’（RP18））为试材制备果汁样本,在85℃条件下加热处理30 min。利用电子鼻、描述性感官评价及GC-MS分析分别对其热杀菌前后样本的电子鼻响应值、感官特性及香气组成进行分析,在此基础上结合正交偏最小二乘法判别分析（OPLS-DA）模型中VIP值筛选蟠桃汁热杀菌前后标志性差异物。【结果】描述性感官评价及电子鼻结果表明,4个品种蟠桃鲜汁香气虽存在差异但均呈现较高的清香、桃香、花香及果香,而热杀菌对蟠桃汁香气品质的影响极大,主要表现为清香显著下降,同时甜香、异味及蒸煮味突显。蟠桃汁的香气组成主要为酯类、内酯类、醛类、醇类、酮类、烯烃类及呋喃类物质;热杀菌后醛类（己醛、(E)-2-己烯醛）、酯类（乙酸乙酯、乙酸己酯）及萜烯类物质（柠檬烯）含量显著下降,而具有不良气味属性的物质（戊醛、α-松油醇、β-大马士酮等）显著增加。由OPLS-DA模型中的S-Plot图及VIP值筛选到可区分鲜汁与热杀菌样本的10种标志性差异物,包括醛类、酯类、萜烯类3大种类物质及(E)-2-己烯醛、己醛、乙酸乙酯、苯甲醛、柠檬烯、乙酸己酯、乙酸叶醇酯7种挥发性物质,该结果验证了感官评价及GC-MS分析的准确性。【结论】热杀菌导致蟠桃汁清香感丧失严重且产生异味及蒸煮味;己醛、(E)-2-己烯醛、苯甲醛、乙酸乙酯、乙酸己酯、柠檬烯、乙酸叶醇酯7种挥发性物质含量的下降及不良属性物质如戊醛及β-大马士酮的生成是导致热杀菌蟠桃汁清香感丧失、异味及蒸煮味产生的关键因素;基于电子鼻分析、感官评价及GC-MS检测结合PCA/OPLS-DA多元统计分析方法可以准确评价热杀菌对蟠桃汁香气轮廓的影响并追踪热杀菌蟠桃汁风味品质劣变的关键靶点因子,研究结果为后续深入探究蟠桃汁风味品质劣变机制提供了参考。

关键词: 蟠桃汁, 热杀菌, 描述性感官评价, GC-MS, OPLS-DA

Abstract:

【Objective】In order to provide a theoretical basis for the quality control of flat peach juice products, the aroma quality changes and the main deterioration factors of flat peach juice after thermal sterilization were investigated.【Method】 Flat peach juice samples were prepared by using four flat peach varieties from Xinjiang province (Zaolupan, ZLP; Zaopan, ZP; Ruipan1, RP1; Ruipan18, RP18) as raw materials and treated at 85℃ for 30 min. Then, the changes of sensory characteristics and aroma composition were investigated by using E-nose, descriptive sensory evaluation (DSA), and GC-MS. Furthermore, OPLS-DA model was applied to screen the marker compounds which caused the quality changes in thermally sterilized juice.【Result】Descriptive sensory analysis and E-nose results indicated that differences existed among four fresh juices, but all of the fresh samples showed high scores in green, peach-like, floral, and fruity attributes. Whereas, the aroma quality of flat peach juice changed greatly after thermal sterilization, as reflected by the decrease of green attribute and the increase of sweet, off-flavor, and cooked flavor. Seven categories of volatile compounds were identified by GC-MS, including esters, lactones, aldehydes, alcohols, ketones, terpenes, and furan compounds. The concentration of aldehydes (hexanal, (E)-2-hexenal), esters (ethyl acetate, hexyl acetate) and terpenes (limonene) decreased significantly after thermal sterilization, while some compounds with off-flavor attribute (pentanal, α-terpineol, β-damascenone) increased significantly. Ten compounds, including three categories compounds (aldehydes, esters, and terpenes) and (E)-2-hexenal, hexanal, ethyl acetate, benzaldehyde, limonene, hexyl acetate and (Z)-3-hexenyl acetate were screened as markers that could distinguish the fresh juice and thermally sterilized juice according to S-Plot and VIP value of OPLS-DA model, so this result verified the accuracy of sensory evaluation and GC-MS analysis.【Conclusion】 The green attribute significantly decreased, meanwhile off-flavor and cooked flavor attributes emerged after thermal sterilization. The decrease of (E)-2-hexenal, hexanal, ethyl acetate, benzaldehyde, limonene, hexyl acetate and (Z)-3-hexenyl acetate and the formation of pentanal and β-damascenone were the main factors for leading to the loss of green attribute and formation of off-flavor and cooked flavor. GC-MS and sensory evaluation coupled with multivariate statistical analysis method (PCA/ OPLS-DA) could be used to accurately evaluate the effect of thermal sterilization on the aroma profile of flat peach juice, and further to trace the key factors of flavor quality deterioration of thermally sterilized juice, which provided a reference for further exploring the degeneration mechanism of thermally processed juice.

Key words: flat peach juice, thermal sterilization, descriptive sensory evaluation, GC-MS, OPLS-DA

谭凤玲,詹萍,王鹏,田洪磊. 基于感官评价及GC-MS结合OPLS-DA分析热杀菌对蟠桃汁呈香品质的影响[J]. 中国农业科学, 2022, 55(12): 2425-2435.

TAN FengLing,ZHAN Ping,WANG Peng,TIAN HongLei. Effects of Thermal Sterilization on Aroma Quality of Flat Peach Juice Based on Sensory Evaluation and GC-MS Combined with OPLS-DA[J]. Scientia Agricultura Sinica, 2022, 55(12): 2425-2435.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2022.12.013

https://www.chinaagrisci.com/CN/Y2022/V55/I12/2425

图/表 4

参考文献 33

[1]	MA R, YU M, DU P, GUO H, SONG H. Evaluation of germplasm resources and breeding of flat peach. Acta Horticulturae, 2003(620): 161-167.
[2]	刘春燕, 童婷, 陈宇昂, 陈冬立. 新疆兵团第十二师桃产业发展现状与解决对策. 天津农业科学, 2020, 26(4): 29-31, 48.
	LIU C Y, TONG T, CHEN Y A, CHEN D L. Development status and countermeasures of the peach industry in 12th division of production and construction corps of Xinjiang. Tianjin Agricultural Sciences, 2020, 26(4): 29-31, 48. (in Chinese)
[3]	宋方圆, 赵志永, 李冀新, 邓小蓉. 蟠桃采后保鲜果实品质的研究进展. 农产品加工, 2015(21): 58-60. doi: 10.16693/j.cnki.1671-9646(X).2015.11.018. doi: 10.16693/j.cnki.1671-9646(X).2015.11.018
	SONG F Y, ZHAO Z Y, LI J X, DENG X R. Research progress of fruit quality of peach postharvest. Farm Products Processing, 2015(21): 58-60. doi: 10.16693/j.cnki.1671-9646(X).2015.11.018. (in Chinese) doi: 10.16693/j.cnki.1671-9646(X).2015.11.018
[4]	EVRENDILEK G A, AVSAR Y K, EVRENDILEK F. Modelling stochastic variability and uncertainty in aroma active compounds of PEF-treated peach nectar as a function of physical and sensory properties, and treatment time. Food Chemistry, 2016, 190: 634-642. doi: 10.1016/j.foodchem.2015.06.010. doi: 10.1016/j.foodchem.2015.06.010
[5]	WANG Y J, YANG C X, LI S H, YANG L, WANG Y N, ZHAO J B, JIANG Q. Volatile characteristics of 50 peaches and nectarines evaluated by HP-SPME with GC-MS. Food Chemistry, 2009, 116(1): 356-364. doi: 10.1016/j.foodchem.2009.02.004
[6]	TIAN H L, WANG P, ZHAN P, YAN H Y, ZHOU W J, ZHANG F. Effects of β-glucosidase on the aroma characteristics of flat peach juice as assessed by descriptive sensory analysis and gas chromatography and compared by partial least squares regression. LWT-Food Science and Technology, 2017, 82: 113-120. doi: 10.1016/j.lwt.2017.04.029
[7]	WANG P, ZHAN P, TIAN H L, ZHANG F, XI J P. Characterization of the influence of thermal sterilization on the volatiles in flat peach juice. Analytical Letters, 2018, 51(15): 2340-2350. doi: 10.1080/00032719.2017.1423323. doi: 10.1080/00032719.2017.1423323
[8]	王鹏, 周文杰, 田洪磊, 张海轮, 詹萍, 张洪安, 梁霞, 张芳. 基于GC-MS结合PCA技术探究β-葡萄糖苷酶对蟠桃汁增香效果的研究. 现代食品科技, 2017, 33(2): 197-204. doi: 10.13982/j.mfst.1673-9078.2017.2.030. doi: 10.13982/j.mfst.1673-9078.2017.2.030
	WANG P, ZHOU W J, TIAN H L, ZHANG H L, ZHAN P, ZHANG H A, LIANG X, ZHANG F. Effects of β-glycosidase on the aroma enhancement of flat peach juice using GC-MS combined with PCA. Modern Food Science and Technology, 2017, 33(2): 197-204. doi: 10.13982/j.mfst.1673-9078.2017.2.030. (in Chinese) doi: 10.13982/j.mfst.1673-9078.2017.2.030
[9]	TAN F L, WANG P, ZHAN P, TIAN H L. Characterization of key aroma compounds in flat peach juice based on gas chromatography- mass spectrometry-olfactometry (GC-MS-O), odor activity value (OAV), aroma recombination, and omission experiments. Food Chemistry, 2022, 366: 130604. doi: 10.1016/j.foodchem.2021.130604. doi: 10.1016/j.foodchem.2021.130604
[10]	NIU Y W, WANG R L, XIAO Z B, ZHU J C, SUN X X, WANG P P. Characterization of ester odorants of apple juice by gas chromatography- olfactometry, quantitative measurements, odour threshold, aroma intensity and electronic nose. Food Research International, 2019, 120: 92-101. doi: 10.1016/j.foodres.2019.01.064
[11]	牛丽影, 郁萌, 吴继红, 刘夫国, 刘春泉. 固相微萃取条件对橙汁主要挥发性成分GC-FID测定的影响. 食品科学, 2013, 34(22): 224-233. doi: 10.7506/spkx1002-6630-201322045. doi: 10.7506/spkx1002-6630-201322045
	NIU L Y, YU M, WU J H, LIU F G, LIU C Q. Effect of SPME conditions on the determination of volatile compounds in orange juice using GC-FID method. Food Science, 2013, 34(22): 224-233. doi: 10.7506/spkx1002-6630-201322045. (in Chinese) doi: 10.7506/spkx1002-6630-201322045
[12]	张芳, 未志胜, 王鹏, 李凯旋, 詹萍, 田洪磊. 基于BP神经网络和遗传算法的库尔勒香梨挥发性物质萃取条件的优化. 中国农业科学, 2018, 51(23): 4535-4547. doi: 10.3864/j.issn.0578-1752.2018.23.012. doi: 10.3864/j.issn.0578-1752.2018.23.012
	ZHANG F, WEI Z S, WANG P, LI K X, ZHAN P, TIAN H L. Using neural network coupled genetic algorithm to optimize the SPME conditions of volatile compounds in Korla pear. Scientia Agricultura Sinica, 2018, 51(23): 4535-4547. doi: 10.3864/j.issn.0578-1752.2018.23.012. (in Chinese) doi: 10.3864/j.issn.0578-1752.2018.23.012
[13]	李国卫, 索彩仙, 吴文平, 潘礼业, 胡绮萍, 何嘉莹, 孙冬梅. 基于多元统计分析的不同诃子属药材多指标成分研究. 天然产物研究与开发, 2021, 33(1): 23-33. doi: 10.16333/j.1001-6880.2021.1.004. doi: 10.16333/j.1001-6880.2021.1.004
	LI G W, SUO C X, WU W P, PAN L Y, HU Q P, HE J Y, SUN D M. Multi-indicative component analysis of different species of Terminalia L. based on multivariate statistical analysis. Natural Product Research and Development, 2021, 33(1): 23-33. doi: 10.16333/j.1001-6880.2021.1.004. (in Chinese) doi: 10.16333/j.1001-6880.2021.1.004
[14]	JIA H J. Studies on peach quality affected by orchard practices[D]. Okayama: Okayama University, 2002.
[15]	ZHAO Y, WANG P, ZHAN P, TIAN H L, LU C, TIAN P. Aroma characteristics of cloudy kiwifruit juices treated with high hydrostatic pressure and representative thermal processes. Food Research International, 2021, 139: 109841. doi: 10.1016/j.foodres.2020.109841. doi: 10.1016/j.foodres.2020.109841
[16]	魏利军, 王菊侠, 侯丽芳, 李琴梅. 西瓜汁热变性的研究及其解决方法探讨. 食品工程, 2013(2): 40-42, 52. doi: 10.3969/j.issn.1673-6044.2013.02.014. doi: 10.3969/j.issn.1673-6044.2013.02.014
	WEI L J, WANG J X, HOU L F, LI Q M. Research on thermal denaturation of watermelon juice and the solution. Food Engineering, 2013(2): 40-42, 52. doi: 10.3969/j.issn.1673-6044.2013.02.014. (in Chinese) doi: 10.3969/j.issn.1673-6044.2013.02.014
[17]	李宝丽, 邓建玲, 蔡欣, 刘睿, 谭军, 王红. 顶空固相微萃取-气质联用结合主成分分析研究纯葡萄汁的香气成分. 中国食品学报, 2016, 16(4): 258-270. doi: 10.16429/j.1009-7848.2016.04.035. doi: 10.16429/j.1009-7848.2016.04.035
	LI B L, DENG J L, CAI X, LIU R, TAN J, WANG H. Studies on aroma components in pure grape juice by HS-SPME-GC-MS coupled with PCA. Journal of Chinese Institute of Food Science and Technology, 2016, 16(4): 258-270. doi: 10.16429/j.1009-7848.2016.04.035. (in Chinese) doi: 10.16429/j.1009-7848.2016.04.035
[18]	姬云云, 詹萍, 田洪磊. 炖煮时间对羊肉汤风味品质的影响. 中国食品学报, 2020, 20(12): 256-267. doi: 10.16429/j.1009-7848.2020.12.031. doi: 10.16429/j.1009-7848.2020.12.031
	JI Y Y, ZHAN P, TIAN H L. Effects of different stewed times on sensory quality of mutton soup. Journal of Chinese Institute of Food Science and Technology, 2020, 20(12): 256-267. doi: 10.16429/j.1009-7848.2020.12.031. (in Chinese) doi: 10.16429/j.1009-7848.2020.12.031
[19]	于爱梅, 徐岩, 王栋, 王立平, 刘扬岷, 费新伟. 发酵原料对苹果酒挥发性香气物质影响的分析. 中国农业科学, 2006, 39(4): 786-791. doi: 10.3321/j.issn:0578-1752.2006.04.020. doi: 10.3321/j.issn:0578-1752.2006.04.020
	YU A M, XU Y, WANG D, WANG L P, LIU Y M, FEI X W. Analysis of influence on different raw materials on volatile aroma compounds of ciders. Scientia Agricultura Sinica, 2006, 39(4): 786-791. doi: 10.3321/j.issn:0578-1752.2006.04.020. (in Chinese) doi: 10.3321/j.issn:0578-1752.2006.04.020
[20]	徐增慧, 贾建会, 吕晓莲, 彭义交, 田旭, 郭宏. 高静压和热杀菌对桃汁香气成分的影响. 食品科学, 2012, 33(5): 25-28. doi: 10.1111/j.1365-2621.1968.tb00877.x
	XU Z H, JIA J H, LÜ X L, PENG Y J, TIAN X, GUO H. Effect of high hydrostatic pressure and heat sterilization on volatile components in peach juice. Food Science, 2012, 33(5): 25-28. (in Chinese) doi: 10.1111/j.1365-2621.1968.tb00877.x
[21]	YANG F, LIU Y, WANG B, SONG H L, ZOU T T. Screening of the volatile compounds in fresh and thermally treated watermelon juice via headspace-gas chromatography-ion mobility spectrometry and comprehensive two-dimensional gas chromatography-olfactory-mass spectrometry analysis. LWT-Food Science and Technology, 2021, 137: 110478. doi: 10.1016/j.lwt.2020.110478
[22]	HASHIZUME M, GORDON M H, MOTTRAM D S. Light-induced off-flavor development in cloudy apple juice. Journal of Agricultural and Food Chemistry, 2007, 55(22): 9177-9182. doi: 10.1021/jf0715727. doi: 10.1021/jf0715727
[23]	BEZYSOV A, DUBOVA H, ROGOVA N. New methods of plant selection for food aroma recovery aided by oxidation processes. Acta Universitatis Cinbinesis Series E: Food Technology, 2015, 19(2): 15-26.
[24]	CLARK J B, CHANBLEE T S. Acid-catalyzed reactions of citrus oils and other terpene-containing flavors. Developments in Food Science, 1992, 28: 229-285.
[25]	PÉREZ-LÓPEZ A J, SAURA D, LORENTE J, CARBONELL- BARRACHINA Á A . Limonene, linalool, α-terpineol, and terpinen- 4-ol as quality control parameters in mandarin juice processing. European Food Research and Technology, 2006, 222(3/4): 281-285. doi: 10.1007/s00217-005-0055-5. doi: 10.1007/s00217-005-0055-5
[26]	WINTERHALTER P, ROUSEFF R L. Carotenoid-derived aroma compounds: An introduction. America: American Chemical Society, 2002: 89-101.
[27]	DERAIL C, HOFMANN T, SCHIEBERL P. Differences in key odorants of handmade juice of yellow-flesh peaches (Prunus persica L.) induced by the workup procedure. Journal of Agricultural and Food Chemistry, 1999, 47(11): 4742-4745. doi: 10.1021/jf990459g
[28]	BALDERMANN S, NAIM M, FLEISCHMANN P. Enzymatic carotenoid degradation and aroma formation in nectarines (Prunus persica). Food Research International, 2005, 38(8/9): 833-836. doi: 10.1016/j.foodres.2005.02.009
[29]	SUNTHONVIT N, SRZEDNICKI G, CRASKE J. Effects of drying treatments on the composition of volatile compounds in dried nectarines. Drying Technology, 2007, 25(5): 877-881. doi: 10.1080/07373930701370274. doi: 10.1080/07373930701370274
[30]	YUAN J P, CHEN F. Degradation of ascorbic acid in aqueous solution. Journal of Agricultural and Food Chemistry, 1998, 46(12): 5078-5082. doi: 10.1021/jf9805404. doi: 10.1021/jf9805404
[31]	SHINODA Y, KOMURA H, HOMMA S, MURATA M. Browning of model orange juice solution: factors affecting the formation of decomposition products. Bioscience, Biotechnology, and Biochemistry, 2005, 69(11): 2129-2137. doi: 10.1271/bbb.69.2129. doi: 10.1271/bbb.69.2129
[32]	李俊南, 侯艳, 孙凤宇, 李康. OPLS方法的原理及其在代谢组学数据判别分析中的应用. 中国卫生统计, 2014, 31(5): 765-769.
	LI J N, HOU Y, SUN F Y, LI K. The theoretical properties of orthogonal projection to latent structures (OPLS) and its application in metabolomics data analysis. Chinese Journal of Health Statistics, 2014, 31(5): 765-769. (in Chinese)
[33]	邓红, 雷佳蕾, 杨天歌, 刘旻昊, 孟永宏, 郭玉蓉, 薛佳. 超高压和高温短时杀菌对NFC苹果汁贮藏期品质的影响. 中国农业科学, 2019, 52(21): 3903-3923. doi: 10.3864/j.issn.0578-1752.2019.21.018. doi: 10.3864/j.issn.0578-1752.2019.21.018
	DENG H, LEI J L, YANG T G, LIU M H, MENG Y H, GUO Y R, XUE J. Effect of ultra-high pressure and high temperature short-time sterilization on the quality of NFC apple juice during storage. Scientia Agricultura Sinica, 2019, 52(21): 3903-3923. doi: 10.3864/j.issn.0578-1752.2019.21.018. (in Chinese) doi: 10.3864/j.issn.0578-1752.2019.21.018
