2种架式对3个鲜食葡萄品种栽培性状及果实品质的影响

doi:10.3864/j.issn.0578-1752.2019.07.003

摘要/Abstract

摘要：

【目的】比较研究2种不同架式对鲜食葡萄多年生大树在栽培性状、果实品质、病害发生情况等的影响,为华北冲积平原埋土区推广适宜的葡萄栽培架式提供参考。【方法】以鲜食葡萄‘瑞都脆霞’‘瑞都无核怡’和‘瑞都香玉’为试材,分别采用T型架和V型架栽培,系统分析2种架式对葡萄物候期、生长结果习性、光合作用、树体结构、果实基本理化指标,多酚化合物含量和栽培用工等方面的影响。【结果】2种架式的物候期和结果习性差异不显著。T型架葡萄副梢管理次数、摘心次数、结果枝绑缚次数和冬季修剪工时均小于V型架,二者冬季下架埋土和春季出土上架所用工时无显著差异。‘瑞都脆霞’T型架在2017年的净光合速率小于V型架,‘瑞都无核怡’T型架在2016年的净光合速率小于V型架,其他情况均表现为T型架的光合性能更强。2017年3个品种在2种架式下的新梢粗度无显著差异。新梢粗度标准差的结果表明,当葡萄树体的树势由强旺调控至中庸水平后,3个品种在T型架的新梢粗度标准差分别为2.3、2.6和2.3,低于V型架的2.7、2.75和3.0,表现出更强的新梢一致性。3个品种在叶幕高度和叶幕长度的表现有所差异,但是V型架的叶幕厚度和叶幕体积均大于T型架,其中‘瑞都脆霞’和‘瑞都香玉’达到显著水平;‘瑞都脆霞’和‘瑞都香玉’在V型架下的叶面积指数高于T型,‘瑞都无核怡’结果相反;2种架式下的叶片叶绿素含量并无显著差异。V型架的叶片霜霉病发病率和病情指数均显著高于T型,白粉病差异不显著。在产量调控至同一水平时,2种架式的穗重、单粒重、纵横径和可溶性固形物之间无显著差异,但是2016年和2017年T型架下葡萄果实的固酸比显著优于V型架。‘瑞都脆霞’和‘瑞都无核怡’在T型架下的总花色苷含量高于V型,其中‘瑞都无核怡’达到显著水平,比V型架高0.018 mg·g ^-1;3个品种在T型架下的类黄酮含量均高于V型架,其中‘瑞都香玉’达到显著水平,比V型架高0.70 mg·g ^-1;‘瑞都无核怡’在T型架下的原花色素含量显著高于V型架,另外2个品种架式间差异不显著。【结论】对位于华北冲积平原且须埋土防寒的葡萄产区,相较于V型架,T型架叶片光合利用效率更高,叶部病害发生更少,新梢生长一致性更好,果实品质更优,口感更佳,管理更省工,具有推广应用价值。

关键词: 葡萄, 架式, 树势, 品质

Abstract:

【Objective】The effects of two different trellis systems on viticultural characteristics, fruit quality and disease incidence of three table grape cultivars were studied deeply to provide theoretical basis for the selection of appropriate trellis system for Northern China alluvial plain.【Method】Vitis vinifera L. were used as plant materials, including Ruiducuixia, Ruiduwuheyi and Ruiduhongyu, which were planted with “T” shaped and “V” shaped trellis systems, respectively. Phenological stages, fruiting habits, photosynthetic characteristics, vine structure, labor intensity, fruit quality indexes including cluster weight, berry weight, berry width, berry length, total soluble solids (TSS), titratable acidity (TA), total anthocyanins, flavonoid and proanthocyanidin of three cultivars in both trellis systems were measured.【Result】There was no significant difference in phenological stages or fruiting habits. In most cases, percentage of germination showed higher value with T-trellis, while other fruiting habits showed no significant differences. T-trellis showed considerable advantages in management operations of the vineyard, in terms of the lateral shoot management, topping of primary shoot, fruit branch binding and winter pruning. Both Soil-bury and untying hours in the fall and out-of-soil and tying hours in the spring showed no statistically difference between the two trellis systems. Ruiducuixia showed higher net photosynthetic rate (Pn) with V-trellis in 2017, Ruiduwuheyi showed higher Pn with V-trellis in 2016, in other cases, T-trellis showed significantly higher Pn. Ruiduwuheyi showed higher stomatal conductance with T-trellis for the three years but the other two cultivars showed inconsistent results. Ruiducuixia had a higher transpiration rate with V-trellis; Ruiduxiangyu had the same trend in 2016. In most cases, there was no difference in intercellular CO₂ concentration between the two trellis systems. The shoot width of three cultivars showed trivial difference between the two trellis systems in 2017. However, after the vigor of the vine had been trained to a moderate level, the standard deviation of shoot width of T-trellis had decreased to 2.3, 2.6 and 2.3 for the three cultivars, lower than that of V-trellis (2.7, 2.75 and 3.0), showing higher shoot consistency. Three cultivars showed different results of canopy height and canopy length, while the grapevines grown with V-trellis had larger canopy volume. Leaf area index of Ruiducuixia and Ruiduxiangyu were much higher with V-trellis than T-trellis, while Ruiduwuheyi showed the opposite. The leaf chlorophyll between the two trellis systems showed no statistical difference. As for leaf disease, V-trellis showed much higher disease index and incidence of downy mildew than T-trellis, while no difference was found on powdery mildew. There was no significant difference in cluster weight, single berry weight, vertical diameter, horizontal diameter or total soluble solids. With T-trellis, TSS/TA was in a better range which made the berries taste more balanced and desirable. Ruiducuixia and Ruiduwuheyi showed higher total anthocyanins with T-trellis; all three cultivars had higher level of flavonoid with T-trellis; besides, Ruiduwuheyi showed higher value of proanthocyanidin with T-trellis system, while the other two cultivars showed no significant difference. 【Conclusion】 Based on the three-year study, for soil-bury grape growing areas in Northern China alluvial plain, T-trellis system showed higher photosynthetic use efficiency, less disease incidence, better shoot consistency, higher fruit quality and less labor intensity for vineyard management, manifesting an favorable trellis system to be promoted and practiced in commercial vineyards.

Key words: grape, trellis system, vine vigor, fruit quality

王晓玥,张国军,孙磊,赵印,闫爱玲,王慧玲,任建成,徐海英. 2种架式对3个鲜食葡萄品种栽培性状及果实品质的影响[J]. 中国农业科学, 2019, 52(7): 1150-1163.

WANG XiaoYue,ZHANG GuoJun,SUN Lei,ZHAO Yin,YAN AiLing,WANG HuiLing,REN JianCheng,XU HaiYing. Effects of Two Trellis Systems on Viticultural Characteristics and Fruit Quality of Three Table Grape Cultivars[J]. Scientia Agricultura Sinica, 2019, 52(7): 1150-1163.

图/表 11

表1

图1

表2

表3

表4

图2

图3

表5

表6

表7

图4

参考文献 49

[1]	张国军, 王晓玥, 孙磊, 闫爱玲, 王慧玲, 任建成, 徐海英 . 大陆季风气候区葡萄树势调控理念与应对策略分析. 中外葡萄与葡萄酒, 2016(3):30-33. doi: 10.13414/j.cnki.zwpp.2016.03.006
	ZHANG G J, WANG X Y, SUN L, YAN A L, WANG H L, REN J C, XU H Y . Grapevine vigor control theory and coping strategy for grape growing under mainland monsoon type climate. Sino-Overseas Grapevine and Wine, 2016(3):30-33. (in Chinese) doi: 10.13414/j.cnki.zwpp.2016.03.006
[2]	KELLER M, TARARA J M, MILLS L J . Spring temperatures alter reproductive development in grapevines. Australian Journal of Grape and Wine Research, 2010,16:445-454. doi: 10.1111/j.1755-0238.2010.00105.x
[3]	李华, 王华 . 中国葡萄酒. 杨凌: 西北农林科技大学出版社, 2010: 26-29.
	LI H, WANG H . Chinese Wine. Yangling: Northwest Agriculture and Forestry University Press, 2010: 26-29. (in Chinese)
[4]	WOLF T K, DRY P R, ILAND P G, BOTTING D, DICK J, KENNEDY U, RISTIC R . Response of Shiraz grapevines to five different training systems in the Barossa Valley, Australia. Australian Journal of Grape and Wine Research, 2003,9:82-95. doi: 10.1111/j.1755-0238.2003.tb00257.x
[5]	张大鹏 . 叶幕PAR光能截留和分配对葡萄群体光合同化物库源关系的调控. 植物生态学报, 1995,19(4):302-310.
	ZHANG D P . Regulating effects of canopy light (PAR) interception and distribution on photosynthate ‘sink-source’ relation in grapevine population with different canopy structures. Chinese Journal of Plant Ecology, 1995,19(4):302-310. (in Chinese)
[6]	单守明, 平吉成, 王振平, 冯美, 王文举, 张亚红 . 不同架式对设施葡萄光合作用和果实品质的影响. 安徽农业科学, 2009,37(35):17801-17803. doi: 10.3969/j.issn.0517-6611.2009.35.071
	SHAN S M, PING J C, WANG Z P, FENG M, WANG W J, ZHANG Y H . Effect of different shaping modes on photosynthesis and quality of grape in greenhouse. Journal of Anhui Agricultural Science, 2009,37(35):17801-17803. (in Chinese) doi: 10.3969/j.issn.0517-6611.2009.35.071
[7]	杨晓盆, 翟秋喜, 张国强, 王跃进 . 不同架式温室葡萄冠位叶片及叶绿体结构的变化. 中国农学通报, 2007,27(3):332-335. doi: 10.3969/j.issn.1000-6850.2007.03.073
	YANG X P, ZHAI Q X, ZHANG G Q, WANG Y J . Studies on leaf microstructure and chloroplast ultrastructure of grapes in greenhouse for various trellis system and position. Chinese Agricultural Science Bulletin, 2007,27(3):332-335. (in Chinese) doi: 10.3969/j.issn.1000-6850.2007.03.073
[8]	高美英, 李换桃, 秦国新, 温鹏飞 . 架式和整枝方式对日光温室葡萄新梢生长的影响. 山西农业大学学报(自然科学版), 2010,30(6):533-535. doi: 10.3969/j.issn.1671-8151.2010.06.012
	GAO M Y, LI H T, QIN G X, WEN P F . Studies of frame structures and pruning system on the spindling of grape in the greenhouse. Journal of Shanxi Agricultural University (Natural Science Edition), 2010,30(6):533-535. (in Chinese) doi: 10.3969/j.issn.1671-8151.2010.06.012
[9]	JACKSON D I, LOMBARD P B . Environmental and management practices affecting grape composition and wine quality-A review. American Journal of Enology and Viticulture, 1993,44:409-430.
[10]	KLIEWER W M, DOKOOZLIAN N K . Leaf area/crop weight ratios of grapevines: Influence of fruit composition and wine quality. American Journal of Enology and Viticulture, 2005,52:170-181. doi: 10.1016/j.scienta.2004.06.014
[11]	赵文东, 满丽婷, 孙凌俊, 高圣华, 赵海亮, 马丽, 郭修武 . 架式与负载量对晚红葡萄果实品质的影响. 中国农学通报, 2010,26(11):241-244.
	ZHAO W D, MAN L T, SUN L J, GAO S H, ZHAO H L, MA L, GUO X W . Effect of different trellis and fruit load on the fruit quality of red globe grape. Chinese Agricultural Science Bulletin, 2010,26(11):241-244. (in Chinese)
[12]	TROUGHT M C T, NAYLOR A P, FRAMPTON C . Effect of row orientation, trellis type, shoot and bunch position on the variability of Sauvignon Blanc (Vitis vinifera L.) juice composition. Australian Journal of Grape and Wine Research, 2017,23:240-250. doi: 10.1111/ajgw.12275
[13]	廉国武 . 不同架式对红地球葡萄生长结果特性的影响. 山西果树, 2012(5):8-10. doi: 10.3969/j.issn.1005-345X.2012.05.004
	LIAN G W . Effect of different trellis system on the growth and fruiting characteristics of Red Globe grape. Shanxi Fruits, 2012(5):8-10. (in Chinese) doi: 10.3969/j.issn.1005-345X.2012.05.004
[14]	单守明, 杨恕玲, 王振平, 平吉成 . 不同架式对设施葡萄生长发育和主芽坏死的影响. 北方园艺, 2011(2):51-53.
	SHAN S M, YANG S L, WANG Z P, PING J C . Effects of different shaping modes on grapevine growth, development and primary buds in greenhouse. Northern Horticulture, 2011(2):51-53. (in Chinese)
[15]	文旭, 边凤霞, 王富霞, 容新民 . 不同架式对四师67团酿酒葡萄生长发育和果实品质的影响. 安徽农业科学, 2015(33):60-61.
	WEN X, BIAN F X, WANG F X, RONG X M . Effects of different tree form on the growth and fruit quality of wine grape at the four division 67 regiment. Journal of Anhui Agricultural Science, 2015(33):60-61. (in Chinese)
[16]	周咏梅, 韩佳宇, 张劲, 成果, 谢太理 . 不同架式对桂葡6号葡萄树体生长及果实品质的影响. 中国南方果树, 2018,47(1):101-103.
	ZHOU Y M, HAN J Y, ZHANG J, CHENG G, XIE T L . Effects of different trellis systems on grapevine growth and fruit quality of Vitis vinifera L. cv. Guipu No.6. South China Fruits, 2018,47(1):101-103. (in Chinese)
[17]	张军贤, 张振文 . 架式与新梢留量对赤霞珠葡萄酒中单体酚的影响. 中国农业科学, 2010,43(18):3784-3790. doi: 10.3864/j.issn.0578-1752.2010.18.012
	ZHANG J X, ZHANG Z W . Effects of trellis systems and shoot density on free phenol of wine from Vitis vinifera L. cv. Cabernet sauvignon. Scientia Agricultura Sinica, 2010,43(18):3784-3790. (in Chinese) doi: 10.3864/j.issn.0578-1752.2010.18.012
[18]	李建华, 粟周群, 潘玉英 . 不同架式对紫秋等葡萄品种栽培性状的影响. 中国南方果树, 2017,46(1):107-110. doi: 10.13938/j.issn.1007-1431.20160348
	LI J H, SU Z Q, PAN Y Y . Effects of trellis systems on viticultural practices of two grapvine cultivars. South China Fruits, 2017,46(1):107-110. (in Chinese) doi: 10.13938/j.issn.1007-1431.20160348
[19]	陆贵峰, 黄凤珠, 廖慧茜, 彭宏祥, 秦献泉, 林玲, 李冬波, 李鸿莉, 徐宁, 朱建华 . 两种架形对酿酒葡萄凌丰生长及产量的影响. 南方农业学报, 2017,48(5):866-869. doi: 10.3969/j.issn.2095-1191.2017.05.018
	LU G F, HUANG F Z, LIAO H Q, PENG H X, QIN X Q, LIN L, LI D B, LI H L, XU N, ZHU J H . Effects of V and T trellis on growth and yield of wine grape variety Lingfeng. Journal of Southern Agriculture, 2017,48(5):866-869. (in Chinese) doi: 10.3969/j.issn.2095-1191.2017.05.018
[20]	李道德, 杨会芳 . 葡萄电杆式“T”形架效果好. 科学种养, 2008(7):20.
	LI D D, YANG H F . A good trellis system for grapevine growing: T-trellis. Kexuezhongyang, 2008(7):20. (in Chinese)
[21]	贺普超, 程国利 . 酿酒葡萄不同整形方式的研究. 果树科学, 1994,11(1):14-18.
	HE P C, CHENG G L . Studies of different training systems on wine grapes. Journal of Fruit Science, 1994,11(1):14-18. (in Chinese)
[22]	李玉鼎, 张光弟, 马金萍 . 埋土防寒区篱架酿酒葡萄斜干水平式新树形. 中外葡萄与葡萄酒, 2006(6):25-27. doi: 10.3969/j.issn.1004-7360.2006.06.007
	LI Y D, ZHANG G D, MA J P . A new training system for wine grapes in soil-bury areas: inclined trunk with horizontal cordons. Sino-Overseas Grapevine and Wine, 2006(6):25-27. (in Chinese) doi: 10.3969/j.issn.1004-7360.2006.06.007
[23]	何娟, 王平, 段长青, 管雪强, 雷玉娟, 吴敏 . 顺架龙干形整形方式对“红地球”葡萄结果性状和树体营养的影响. 北方园艺, 2014(21):16-19.
	HE J, WANG P, DUAN C Q, GUAN X Q, LEI Y J, WU M . Effects of inclined trunk with horizontal cordons on fruiting characteristics and vine nutrition reserve of red globe grape. Northern Horticulture, 2014(21):16-19. (in Chinese)
[24]	LAMBERT R J, SKANDAMIS P N, COOTE P J, NYCHAS G J . A study of the minimum inhibitory concentration and mode of action of oregano essential oil, thymol and carvacrol. Journal of Applied Microbiology, 2001,91(3):453-462. doi: 10.1046/j.1365-2672.2001.01428.x pmid: 11556910
[25]	杨夫臣, 吴江, 程建徽, 徐凯, 陈俊伟 . 葡萄果皮花色素的提取及其理化性质. 果树学报, 2007,24(3):287-292. doi: 10.3969/j.issn.1009-9980.2007.03.006
	YANG F C, WU J, CHENG J H, XU K, CHEN J W . Studies on extraction and physical-chemical properties of anthocyanin from red globe grape peel. Journal of Fruit Science, 2007,24(3):287-292. (in Chinese) doi: 10.3969/j.issn.1009-9980.2007.03.006
[26]	RAMCHANDANI A G, CHETTIYAR R S, PAKHALE S S . Evaluation of antioxidant and anti-initiating activities of crude polyphenolic extracts from seedless and seeded Indian grapes. Food Chemistry, 2010,119(1):298-305. doi: 10.1016/j.foodchem.2009.06.032
[27]	代红军, 秦晨亮, 丁玲 . 水杨酸对‘赤霞珠’葡萄总类黄酮、白藜芦醇含量及相关酶活性的影响. 中国农业大学学报, 2016,21(7):37-42.
	DAI H J, QIN C L, DING L . Effects of salicylic acid on the contents of total flavonoids and resveratrol and related enzyme activities in ‘Cabernet Sauvignon’. Journal of China Agricultural University, 2016,21(7):37-42. (in Chinese)
[28]	JAYASENA V, CAMERON I . Brix/acid ratio as a predictor of consumer acceptability of Crimson Seedless table grapes. Journal of Food Quality, 2008,31:736-750. doi: 10.1111/j.1745-4557.2008.00231.x
[29]	CRISOSTO C H, CRISOSTO G M . Understanding American and Chinese consumer acceptance of ‘Red Globe’ table grapes. Postharvest Biological Technology, 2002,24(2):155-162. doi: 10.1016/S0925-5214(01)00189-2
[30]	PERCIVAL D C, FISHER K H, SULLIVAN J A . Use of fruit zone leaf removal with Vitis vinifera L. cv. Riesling grapevines. I. Effect on canopy structure, microclimate, bud survival, shoot density, and vine vigor. American Journal of Enology and Viticulture, 1994,45:123-132. doi: 10.0000/PMID313
[31]	黄海华 . 高干“T”型架和简易避雨栽培巨峰葡萄技术. 现代园艺, 2006(5):16-17. doi: 10.3969/j.issn.1009-0584.2006.02.022
	HUANG H H . Application of T-trellis system and rain-shelter cultivation on ‘Kyoho’. Modern Horticulture, 2006(5):16-17. (in Chinese) doi: 10.3969/j.issn.1009-0584.2006.02.022
[32]	李晓梅, 唐晓萍, 董志刚, 谭伟, 于静, 王新平 . 葡萄生产上几种常见架式及其应用. 山西果树, 2015(2):36-38.
	LI X M, TANG X P, DONG Z G, TAN W, YU J, WANG X P . Popular grapevine trellis systems and their application in commercial vineyards. Shanxi Fruits, 2015(2):36-38. (in Chinese)
[33]	GARDEA A A, NORIEGA J R, OROZCO J A, GARCÍA- BANUELOS M, CARVAJAL-MILLÁN E, VALENZUELA-SOTO E M, VALENZUELA A A . Advanced maturity of ‘Perlette’ table grapes by training systems which increase foliage exposure to sunlight. Revista Fitotecnia Mexicana, 2008,31(1):27-33.
[34]	王莉娜, 袁维祥, 杨敦敦 . 葡萄省工栽培新架式—高“Y”型平棚架. 中外葡萄与葡萄酒, 2010(7):56-57.
	WANG L N, YUAN W X, YANG D D . A new labor saving trellis system: Y shaped pergola. Sino-Overseas Grapevine and Wine, 2010(7):56-57. (in Chinese)
[35]	熊其仁, 蔡伟 . 栽培新设施—小棚简易避雨T型架. 农技服务, 2004(5):20. doi: 10.3969/j.issn.1004-8421.2004.05.014
	XIONG Q R, CAI W . A new viticultural facility: T trellis with rain-shelter cultivation. Nongjifuwu, 2004(5):20. (in Chinese) doi: 10.3969/j.issn.1004-8421.2004.05.014
[36]	赵海亮, 赵文东, 孙凌俊, 高圣华, 马丽, 刘晓菊 . 不同架式巨峰葡萄光合特性与叶绿素荧光参数研究. 西南农业学报, 2015,28(6):2691-2695. doi: 10.16213/j.cnki.scjas.2015.06.063
	ZHAO H L, ZHAO W D, SUN L J, GAO S H, MA L, LIU X J . Study on photosynthetic characteristics and chlorophyll fluorescence parameters of Kyoho grape in different trellis. Southwest China Journal of Agricultural Sciences, 2015,28(6):2691-2695. (in Chinese) doi: 10.16213/j.cnki.scjas.2015.06.063
[37]	SCHUBERT A, RESTAGNO M, NOVELLO V, PETERLUNGER E . Effects of shoot orientation on growth, net photosynthesis, and hydraulic conductivity of Vitis vinifera L. cv. Cortese. American Journal of Enology and Viticulture, 1995,46:324-328. doi: 10.1016/0304-4238(94)00735-X
[38]	晁无疾, 张伟, 姚林启 . 不同修剪方式对红地球葡萄成花效应的影响. 中外葡萄与葡萄酒, 2009(1):31-33. doi: 10.3969/j.issn.1004-7360.2009.01.008
	CHAO W J, ZHANG W, YAO L Q . Effects of different pruning methods on flower initiation of red globe grape. Sino-Overseas Grapevine and Wine, 2009(1):31-33. (in Chinese) doi: 10.3969/j.issn.1004-7360.2009.01.008
[39]	NELSON K E, SCHUTZ H G, AHMEDULLAH M, MCPHERSON J . Flavour preferences of supermarket customers for ‘Thompson Seedless’ grapes. American Journal of Enology and Viticulture, 1973,24(1):31-40.
[40]	张磊, 张晓煜, 亢艳莉, 马国飞, 袁海燕 . 土壤肥力对酿酒葡萄品质的影响. 江西农业大学学报, 2008(2):226-229, 234.
	ZHANG L, ZHANG X Y, KANG Y L, MA G F, YUAN H Y . The effect of soil fertility on wine grape quality. Acta Agriculturae Univeristatis Jiangxiensis, 2008(2):226-229, 234. (in Chinese)
[41]	白世践, 李超, 蔡军社, 赵荣华, 陈光 . 吐鲁番地区新征集葡萄资源果实主要品质性状的因子分析和聚类分析. 西北农业学报, 2016,25(7):1006-1016. doi: 10.7606/j.issn.1004-1389.2016.07.008
	BAI S J, LI C, CAI J S, ZHAO R H, CHEN G . Principal factor analysis and Euclidean cluster diagram of new grape cultivars’ quality traits in Turpan area. Acta Agriculturae Boreali-occidentalis Sinica, 2016,25(7):1006-1016. (in Chinese) doi: 10.7606/j.issn.1004-1389.2016.07.008
[42]	NELSON K E, BAKER G A, WINKLER A J, AMERINE M A, RICHARDSON H B, JONES F R . Chemical and sensory variability in table grapes. Hilgardia, 1963,34:1-42. doi: 10.3733/hilg.v34n01p001
[43]	ELTOM M, TROUGHT M C T, AGNEW R, PARKER A, WINEFIELD C S . Pre-budburst temperature influences the inner and outer arm structure, phenology, flower number, fruit set, TSS accumulation and variability of Vitis vinifera L. Sauvignon Blanc bunches. Australian Journal of Grape and Wine Research, 2017,23:280-286.
[44]	DOKOOZLIAN N K . Grape berry growth and development. //Christensen L P. ed. Raisin Production Manual. Oakland: University of California, Agriculture and Natural Resources Communication Services, 2002: 30-37.
[45]	BERGQVIST J, DOKOOZLIAN N K, EBISUDA N . Sunlight exposure and temperature effects on berry growth and composition of Cabernet Sauvignon and Grenache in the central san joaquin valley in California. American Journal of Enology and Viticulture, 2001,52(1):1-7. doi: 10.1016/S0065-2911(01)45006-5
[46]	左玉 . 多酚类化合物研究进展. 粮食与油脂, 2013,26(4):6-10.
	ZUO Y . Research progress on polyphenols. Cereals and Oils, 2013,26(4):6-10. (in Chinese)
[47]	XIA L L, XU C M, HUANG K L, LU J, ZHANG Y L . Evaluation of phenolic compounds, antioxidant and antiproliferative activities of 31 grape cultivars with different genotypes. Journal of Food Biochemistry, 2018. doi: org/10.1111/jfbc.12626. doi: 10.1111/jfbc.12626
[48]	PALLIOTTI A . A new closing Y-shaped training system for grapevines. Australian Journal of Grape and Wine Research, 2012,18:57-63. doi: 10.1111/j.1755-0238.2011.00171.x
[49]	沈甜, 单守明, 孙晔, 李映龙, 张军翔 . “厂字”架式对“赤霞珠”葡萄光合效率和果实品质的影响. 北方园艺, 2015(1):27-30. doi: 10.11937/bfyy.201501007
	SHEN T, SHAN S M, SUN Y, LI Y L, ZHANG J X . The effect of Chang trellis system on photosynthetic efficiency and fruit quality of Cabernet Sauvignon. Northern Horticulture, 2015(1):27-30. (in Chinese) doi: 10.11937/bfyy.201501007

生长季 Growing period	平均温度 Mean temperature (℃)	相对湿度 Relative humidity (%)	风速 Wind speed (km?h^-1)	降雨量 Precipitation (mm)	有效积温 Growing degree days
2015
4月April	14.7	45.7	11.3	34.29	134.0
5月May	20.8	44.3	11.3	24.89	290.0
6月June	24.4	57.9	9.3	34.80	407.5
7月July	26.5	65.7	7.6	83.07	481.0
8月August	26.1	68.6	7.3	71.10	501.0
9月September	20.6	71.2	8.1	50.54	302.5
10月October	13.8	59.2	9.3	14.22	130.5
11月November	2.9	78.9	7.5	17.28	0.5
均值/总合Average/Total	18.7	61.4	9.0	330.20	2247
2016
4月April	15.5	38.8	11.4	5.59	159.5
5月May	20.2	45.0	10.9	17.77	297.0
6月June	24.9	57.7	8.5	61.47	421.5
7月July	27.1	69.4	7.9	181.61	501.0
8月August	27.0	66.3	8.1	71.37	500.0
9月September	21.3	66.2	7.7	56.13	335.5
10月October	12.9	72.4	8.0	50.30	113.0
11月November	3.52	62.1	8.6	7.87	1.5
均值/总合Average/Total	19.1	59.7	8.9	452.11	2329
2017
4月April	15.5	36.4	10.6	0	124.5
5月May	22.0	40.9	10.5	28.95	293.5
6月June	24.7	50.5	9.0	80.78	357.5
7月July	27.3	75.0	7.7	63.51	443.5
8月August	25.9	73.3	7.5	199.9	423
9月September	21.7	64.5	7.4	3.05	318
10月October	12.3	72.5	7.1	32.77	80.5
11月November	3.1	46.0	10.3	0	4.0
均值/总合Average/Total	19.1	57.4	8.8	408.96	2044.5

年份 Year	品种 Cultivar	架式 Trellis system	萌芽期 Bud break (M-D)	初花期 First bloom (M-D)	始熟期 Veraison (M-D)	新梢始熟期 Cane maturation (M-D)
2015	CX	T	4-18	5-26	7-6	9-6
		V	4-19	5-27	7-9	9-1
	WHY	T	4-22	5-27	7-19	8-25
		V	4-22	5-26	7-22	8-2
	XY	T	4-21	5-24	7-13	8-14
		V	4-19	5-24	7-13	8-5
2016	CX	T	4-18	5-23	7-2	9-9
		V	4-18	5-22	7-2	9-1
	WHY	T	4-21	5-28	7-24	8-28
		V	4-22	5-26	7-24	8-26
	XY	T	4-17	5-20	7-25	8-25
		V	4-18	5-19	7-24	8-27
2017	CX	T	4-18	5-19	7-5	8-28
		V	4-18	5-19	7-4	8-25
	WHY	T	4-21	5-20	7-16	8-18
		V	4-22	5-20	7-16	8-18
	XY	T	4-17	5-16	7-6	8-26
		V	4-18	5-16	7-9	8-28

年份 Year	品种 Cultivar	架式 Trellis system	萌芽率 Percentage of germination (%)	结果枝率 Percentage of bearing shoots (%)	结果系数 Cluster number per bearing shoot
2015	CX	T	95.3±2.2*	83.8±4.7	1.73±0.1
		V	48.3±4.8	94.2±1.7	1.80±0.1
	WHY	T	71.0±3.1	66.2±2.0	1.21±0.0
		V	39.2±4.0	69.4±6.5	1.09±0.0
	XY	T	86.7±3.3*	54.7±17.6	1.63±0.1
		V	47.6±3.3	80.0±2.0	1.88±0.1
2016	CX	T	67.8±3.9	90.0±1.1	1.83±0.1
		V	63.8±3.3	93.3±4.1	1.57±0.0
	WHY	T	72.0±1.5	87.4±3.6	1.45±0.1
		V	70.5±2.0	75.8±10.5	1.17±0.0
	XY	T	72.0±2.9	59.0±8.2	1.11±0.1
		V	61.1±3.6	71.5±4.4	1.56±0.1
2017	CX	T	73.1±5.0	77.8±6.1	1.52±0.1
		V	64.6±8.1	71.6±6.1	1.49±0.0
	WHY	T	67.4±7.6	76.6±7.4	1.35±0.1
		V	67.9±3.7	54.1±21.5	1.30±0.1
	XY	T	60.5±3.7	71.6±7.7	1.41±0.2
		V	67.7±8.0	61.9±3.8	1.71±0.1

项目 Parameter	V型 V-trellis	T型 T-trellis
长势Vigor	较旺 Vigorous	中庸 Moderate
顶端优势 Apical dominance	较明显 Obvious	不明显 Not obvious
结果带距地面高度Fruit setting height (cm)	40	170
出土上架工时（时／人·亩）Out-of-soil and tying hours per person per 1/6 acre	24	24
副梢管理次数（／年）Lateral shoot management times (/year)	10	5
摘心次数（／年）Topping times (/year)	1—2	1
结果枝绑缚次数（／年）Fruit branch binding times (/year)	2	1
冬季修剪工时（时／人·亩）Winter pruning hours per person per 1/6 acre	2	1.33
下架埋土工时（时／人·亩） Soil-bury and untying hours per person per 1/6 acre	3.2	3.2

品种 Cultivar	架式 Trellis system	叶幕高度 Canopy height (cm)	叶幕长度 Canopy length (cm)	叶幕厚度 Canopy thickness (cm)	叶幕体积 Canopy volume (cm³)	叶面积指数 Leaf area index	叶片叶绿素 Leaf chlorophyll contents (SPAD)
CX	T	127.3±2.7	162.7±3.0	39.3±2.0	0.86±0.0	1.33±0.22	42.4±1.6
	V	111.7±6.1	303.0±28.8	60.0±5.8*	2.0±0.3*	1.71±0.15	31.4±3.9
WHY	T	111.0±8.5	177.7±29.0	52.0±4.0	1.0±0.2	2.05±0.23	44.9±0.6
	V	114.7±2.4	202.7±30.0	58.7±7.2	1.4±0.3	1.78±0.03	49.1±1.8
XY	T	94.3±1.9	328.0±17.4*	51.0±4.0	1.6±0.1	1.00±0.07	44.6±1.7
	V	116.7±3.2*	234.7±25.9	73.0±10.4	1.9±0.1*	1.57±0.14*	44.0±0.9
