耐草甘膦转EPSPS/GAT大豆多重PCR检测体系的建立及应用

doi:10.3864/j.issn.0578-1752.2020.20.003

摘要/Abstract

摘要：

【目的】建立一种精准、高效的草甘膦抗性基因G2-EPSPS和GAT的检测方法,为转基因大豆新品系ZH10-6的广泛应用提供技术支持。【方法】根据抗草甘膦大豆ZH10-6和受体中黄10的分子特征,设计大豆内源参考基因（Actin）、外源基因（G2-EPSPS和GAT）以及侧翼序列（G2EPSPS-2/ZH10P2和ZH10P1/GAT-2）的特异性引物,通过PCR扩增测试引物的特异性和适用性。调整引物配比、DNA模板量、dNTP含量、退火温度和延伸温度等,筛选该多重PCR体系的最适扩增条件。将转基因大豆ZH10-6和受体中黄10的基因组DNA按质量比混合,制备成100%、50%、10%、5%、1%、0.5%、0.1%和0的DNA样品,进行灵敏度检测。运用建立的多重PCR体系检测转基因大豆ZH10-6不同地理来源的11份衍生品系,并根据鉴定结果对该体系的应用性进行评价。【结果】建立的多重PCR方法中引物GmActin11 F/R、G2-EPSPS F/R、GAT F/R、ZH10P1/GAT和G2/ZH10P2可分别扩增出转基因大豆ZH10-6大小为126、430、338、810和1 626 bp的特异性目标条带。用该方法扩增受体中黄10时,除了GmActin11 F/R可以扩增出126 bp目标条带,侧翼序列上游引物ZH10P1和下游引物ZH10P2也可以扩增出632 bp目标条带。多重PCR最适扩增体系为DNA模板量100 ng、5 U·μL^-1 Ex Taq 0.2 μL、10×ExTaq Buffer 2.5 μL、2.5 mmol·L^-1 dNTP 2 μL、10 μmol·L^-1引物（GmActin11 F/R 0.4 μL、G2-EPSPS F/R 0.6 μL、GAT F/R 0.4 μL、ZH10P1/GAT 0.6 μL和G2/ZH10P2 0.6 μL）,ddH₂O补足25 μL。多重PCR扩增最适程序为95℃ 5 min;95℃ 30 s,60℃ 30 s,68℃ 1 min 20 s,35个循环;72℃ 12 min。该多重PCR体系灵敏度为0.5%,符合欧盟有关转基因产品标识的要求。该多重PCR方法特异性很强,可以成功检测受体中黄10、转基因大豆ZH10-6及ZH10-6不同地理来源的11个衍生品系。【结论】建立的转EPSPS/GAT大豆多重PCR检测体系具有高通量、特异性强、操作简便和应用广泛的优点,并且能够快速、准确地检测转基因大豆ZH10-6及其衍生品系。

关键词: 转基因大豆, 抗除草剂, 外源基因, 侧翼序列, 多重PCR

Abstract:

【Objective】This study aims to establish an accurate and efficient high-throughput detection method for herbicide-resistant genes of G2-EPSPS and GAT, providing technical support for the application of transgenic soybean ZH10-6.【Method】Based on the molecular characteristics of glyphosate-resistant soybean ZH10-6 and ZH10, specific primers for endogenous reference genes (Actin), exogenous genes (G2-EPSPS and GAT) and flank sequences (G2EPSPS-2/ZH10P2 and ZH10P1/GAT-2) were designed for testing their specificity and applicability by PCR amplification. The optimal PCR amplified condition of the multiplex PCR system were screened by adjusting primer ratio, DNA template amount, dNTP content, annealing temperature and elongation temperature. The different mix of transgenic soybean ZH10-6 and ZH10 were prepared according to the mass ratio and formed DNA samples of 100%, 50%, 10%, 5%, 1%, 0.5%, 0.1% and 0 for sensitivity detection. Eleven derived lines of transgenic soybean ZH10-6 from different geographical sources were detected for evaluation of its application potential.【Result】Primers of GmActin11 F/R, G2-EPSPS F/R, GAT F/R, ZH10P1/GAT and G2/ZH10P2 were amplified the specific target fragments of 126, 430, 338, 810 and 1 626 bp in the multiple PCR method in transgenic soybean ZH10-6. In addition to the 126 bp target fragment amplified by ZH10 with GmActin11 F/R, the 632 bp target fragments were amplified by ZH10P1/ ZH10P2. The optimal system for multiple PCR amplification included 100 ng DNA template, 5 U·μL^-1 Ex Taq 0.2 μL, 10×ExTaq Buffer 2.5 μL, 2.5 mmol·L^-1 dNTP 2 μL, 10 μmol·L^-1 primers(GmActin11 F/R 0.4 μL, G2-EPSPS F/R 0.6 μL, GAT F/R 0.4 μL, ZH10P1/GAT 0.6 μL and G2/ZH10P2 0.6 μL), ddH₂O supplemented 25 μL. The optimal multiplex PCR amplification procedure: 95℃ for 5 min; 95℃ 30 s, 60℃ 30 s, 68℃ 1 min20 s, 35 cycles; 72℃ 12 min. The sensitivity of the multiplex PCR system is 0.5%, which meets the requirements of the European Union for the labeling of transgenic products. The multiplex PCR method is high specificity and detected ZH10, ZH10-6 and eleven ZH10-6 derived lines successfully. 【Conclusion】The multiple PCR system of EPSPS/GAT were established, which had advantage of high throughput, strong specificity, simple operation and wide application. It can detect transgenic soybean ZH10-6 and its derived lines quickly and accurately.

Key words: transgenic soybean, herbicide resistance, foreign genes, flanking sequence, multiplex PCR

文静,郭勇,邱丽娟. 耐草甘膦转EPSPS/GAT大豆多重PCR检测体系的建立及应用[J]. 中国农业科学, 2020, 53(20): 4127-4136.

WEN Jing,GUO Yong,QIU LiJuan. Establishment and Application of Multiple PCR Detection System for Glyphosate-Tolerant Gene EPSPS/GAT in Soybean[J]. Scientia Agricultura Sinica, 2020, 53(20): 4127-4136.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2020.20.003

https://www.chinaagrisci.com/CN/Y2020/V53/I20/4127

图/表 8

表1

图1

图2

图3

图4

图5

图6

表2

参考文献 34

[1]	REDENBAUGH K, HIATT W, MARTINEAU B, EMLAY D. Regulatory assessment of the FLAVR SAVR tomato. Trends in Food Science & Technology, 1994,5(4):105-110. doi: 10.1016/0924-2244(94)90197-X
[2]	JAMES C. 2018年全球生物技术/转基因作物商业化发展态势. 中国生物工程杂志, 2019,39(8):1-6.
	JAMES C. Global status of commercialized biotech/GM crops in 2018. China Biotechnology, 2019,39(8):1-6. (in Chinese)
[3]	DLUGOSCH K M, WHITTON J. Can we stop transgenes from taking a walk on the wild side? Molecular Ecology, 2008,17(5):1167-1169. doi: 10.1111/j.1365-294X.2008.03663.x pmid: 18302682
[4]	YASSEEN Y M, BARRINGER S A, SPLITTSTOESSER W E, COSTANZA S. The role of seed coats in seed viability. The Botanical Review, 1994,60(4):426-439. doi: 10.1007/BF02857926
[5]	KOSIR A B, SPILSBERQ B, HOLST J A, ZEI J, DOBNIK. Development and inter-laboratory assessment of droplet digital PCR assays for multiplex quantification of 15 genetically modified soybean lines. Scientific Reports, 2017,7(1):8601-8611. doi: 10.1038/s41598-017-09377-w pmid: 28819142
[6]	JENSEN A H. Testing for genetically modified organisms (GMOs): Past, present and future perspectives. Biotechnology Advances, 2009,27(6):1071-1082. doi: 10.1016/j.biotechadv.2009.05.025
[7]	瞿勇, 武玉花, 吴刚, 曹应龙, 卢长明. 转基因玉米MON88017转化事件特异性定性PCR检测方法及其标准化. 农业生物技术学报, 2010,18(6):1208-1214.
	QU Y, WU Y H, WU G, CAO Y L, LU C M. Event-specific PCR detection method of transgenic maize line MON88017 and its standardization. Journal of Agricultural Biotechnology, 2010,18(6):1208-1214. (in Chinese)
[8]	GERMINI A, ZANETTI A, SALATI C, ROSSI S, FORRE C, SCHMID S, MARCHELLI R. Development of a seven-target multiplex PCR for the simultaneous detection of transgenic soybean and maize in feeds and foods. Journal of Agricultural and Food Chemistry, 2004,52(11):3275-3280. doi: 10.1021/jf035052x pmid: 15161182
[9]	MARKOULATOS P, SIAFAKAS N, MONCANY M. Multiplex polymerase chain reaction: A practical approach. Journal of Clinical Laboratory Analysis, 2002,16(1):47-51. pmid: 11835531
[10]	吕山花, 常汝镇, 陶波, 李向华, 栾凤侠, 郭珊花, 邱丽娟. 抗草甘膦转基因大豆PCR检测方法的建立与应用. 中国农业科学, 2003,36(8):883-887.
	LÜ S H, CHANG R Z, TAO B, Li X H, LUAN F X, GUO S H, QIU L J. Methodological research on PCR based detection of genetically modified soybean resistant to glyphosate. Scientia Agricultura Sinica, 2003,36(8):883-887. (in Chinese)
[11]	沈苏南. 一种多重PCR技术在转基因大豆检测中的应用研究[D]. 苏州: 苏州大学, 2016.
	SHEN S N. A novel multiplex-PCR assay to identify genetically modified soybean events[D]. Suzhou: Soochoow University, 2016. (in Chinese)
[12]	鲁军, 李刚, 赵建宁, 杨殿林, 修伟明. 多重PCR技术在转基因成分检测中的最新研究进展. 生物学杂志, 2018,35(5):87-90.
	LU J, LI G, ZHAO J N, YANG D L, XIU W M. Review on multiplex polymerase chain reaction for the detection of genetically modified components. Journal of Biology, 2018,35(5):87-90. (in Chinese)
[13]	TIAN F, WANG X, TENG D, YANG Y, GUAN Q, AO C, WANG J. Optimization of a multiplex PCR assay for detecting transgenic soybean components in feed products. Applied Biochemistry & Biotechnology, 2011,165(6):1225-1234.
[14]	LEE, HUN S. Screening DNA chip and event-specific multiplex PCR detection methods for biotech crops. Journal of the Science of Food and Agriculture, 2014,94(14):2856-2862. doi: 10.1002/jsfa.6625
[15]	GUO J C, CHEN L L, LIU X, GAO Y, ZHANG D B, YANG L T. A multiplex degenerate PCR analytical approach targeting to eight genes for screening GMOs. Food Chemistry, 2012,132(3):1566-1573. doi: 10.1016/j.foodchem.2011.11.096
[16]	JAMES D, SCHMIDT A M, WALL E, GREEN M, MASRI S. Reliable detection and identification of genetically modified maize, soybean, and canola by multiplex PCR analysis. Journal of Agricultural and Food Chemistry, 2003,51(20):5829-5834. doi: 10.1021/jf0341159 pmid: 13129280
[17]	尹全, 李忆, 宋君, 王东, 张富丽, 刘文娟, 常丽娟, 刘勇. 多重PCR检测抗草甘膦大豆GTS40-3-2. 大豆科学, 2016,35(4):666-671.
	YIN Q, LI Y, SONG J, WANG D, ZHANG F L, LIU W J, CHANG L J, LIU Y. Multiplex PCR for detection of roundup-ready soybean GTS40-3-2. Soybean Science, 2016,35(4):666-671. (in Chinese)
[18]	AO J, LI Q, GAO X, YU Y, LI L, ZHANG M. A multiplex nested PCR assay for the simultaneous detection of genetically modified soybean, maize and rice in highly processed products. Food Control, 2011,22(10):1617-1623. doi: 10.1016/j.foodcont.2011.03.018
[19]	KIM J H, JEONG D, KIM Y R, KWON Y K, RHEE G S, ZHANG D B, KIM H Y. Development of a multiplex PCR method for testing six GM soybean events. Food Control, 2013,31(2):366-371. doi: 10.1016/j.foodcont.2012.10.015
[20]	付伟, 任娇, 魏霜, 袁俊杰, 周广彪, 吴希阳, 朱水芳, 刘中勇. 转基因大豆DAS44406-6多重荧光定量PCR检测方法的建立. 食品工业科技, 2017,38(4):63-67.
	FU W, REN J, WEI S, YUAN J J, ZHOU G B, WU X Y, ZHU S F, LIU Z Y. Multiplex real-time PCR for the detection of genetically modified soybean DAS44406-6. Science and Technology of Food Industry, 2017,38(4):63-67. (in Chinese)
[21]	鲁军, 李刚, 赵建宁, 杨殿林, 修伟明. 5种转基因油菜转化体特异性多重PCR检测方法. 生物安全学报, 2017,26(3):244-250.
	LU J, LI G, ZHAO J N, YANG D L, XIU W M. Event-specific multiplex PCR detection method for five genetically modified canola lines. Entomological Journal of East China, 2017,26(3):244-250. (in Chinese)
[22]	JENSEN A H. Testing for genetically modified organisms (GMOs): Past, present and future perspectives. Biotechnology Advances, 2009,27(6):1071-1082. doi: 10.1016/j.biotechadv.2009.05.025
[23]	YANG L T, GUO J C, PAN A H, ZHANG H B, ZHANG K W, WANG Z M, ZHANG D. Event-specific quantitative detection of nine genetically modified maizes using one novel standard reference molecule. Journal of Agricultural and Food Chemistry, 2007,55(1):15-24. pmid: 17199308
[24]	LI Y J, LI J, WU Y H, CAO Y L, LI J, ZHU L, LI X F, HUANG S M, WU G. Successful detection of foreign inserts in transgenic rice TT51-1 (BT63) by RNA-sequencing combined with PCR. Journal of the Science of Food and Agriculture, 2016,97(5):1634-1639. doi: 10.1002/jsfa.7913 pmid: 27436567
[25]	RANDHAWA G J, CHHABRA R, SINGH M. Decaplex and real-time PCR based detection of MON531 and MON15985 Bt cotton events. Journal of Agricultural & Food Chemistry, 2010,58(18):9875-9881. doi: 10.1021/jf100466n pmid: 20687600
[26]	ROY A, FAYAD A, BARTHE G, BRLANSKY R H. A multiplex polymerase chain reaction method for reliable, sensitive and simultaneous detection of multiple viruses in citrus trees. Journal of Virological Methods, 2005,129(1):47-55. pmid: 15951030
[27]	YAN W. Multiplex PCR primer design for simultaneous detection of multiple pathogens. Methods in Molecular Biology, 2015,1275:91-101. pmid: 25697653
[28]	赵红庆, 苑锡铜, 黄留玉. 多重PCR技术在病原检测中的应用. 生物技术通讯, 2007,18(5):863-865.
	ZHAO H Q, YUAN X T, HUANG L Y. Application of multiplex PCR in detection of pathogens. Letters in Biotechnology, 2007,18(5):863-865. (in Chinese)
[29]	曹洪志, 颜其贵, 郭万柱, 樊汶樵, 肖雪, 李成贤. 多重PCR技术在动物疫病诊断中的应用. 中国动物检疫, 2007,24(1):45-47.
	CAO H Z, YAN Q G, GUO W Z, FAN W Q, XIAO X, LI C X. Application of multiplex PCR in the diagnosis of animal diseases. China Journal of Animal Quarantine, 2007,24(1):45-47. (in Chinese)
[30]	刘志杰, 李如举, 曾智勇, 周莉, 汤德元, 李谦, 肖超能. 多重PCR反应的影响因素及其优化. 黑龙江畜牧兽医, 2011,13(7):26-28.
	LIU Z J, LI R J, ZENG Z Y, ZHOU L, TANG D Y, LI Q, XIAO C N. Factors influencing multiple PCR reactions and their optimization. Heilongjiang Animal Science and Veterinary Medicine, 2011,13(7):26-28. (in Chinese)
[31]	LIU Z B, GAO Q R, WANG R X, QIAO X L, QIU X M. Application of multiplex PCR to studies on plant biology. Molecular Plant Breeding, 2005,2(3):261-268.
[32]	HENEGARIU O, HEEREMA N A, DLOUHY S R, VOGT P H. Multiplex PCR: Critical parameters and step-by-step protocol. Bio Techniques, 1997,23(3):504-511.
[33]	陈贞, 芦春斌, 杨梦婕, 马骏, 白卫斌, 吴希阳. 多重PCR检测转基因菜籽粕中的转基因成分. 植物检疫, 2011,25(3):35-38.
	CHEN Z, LU C B, YANG M J, MA J, BAI W B, WU X Y. Multiplex PCR for detection of genetically modified components of rapeseed meal. Plant Quarantine, 2011,25(3):35-38. (in Chinese)
[34]	董立明, 李葱葱, 邢珍娟, 邵改革, 夏蔚, 闫伟, 李飞武. 利用多重PCR技术快速检测五个转基因大豆品系. 大豆科学, 2016,35(6):1002-1007.
	DONG L M, LI C C, XING Z J, SHAO G G, XIA W, YAN W, LI F W. Rapid detection of five genetically modified soybean lines by multiplex PCR method. Soybean Science, 2016,35(6):1002-1007. (in Chinese)

基因/标记名称 Gene/Marker name	引物名称 Primer name	引物序列 Primer sequence (5′-3′)	产物大小 Fragment size (bp)
内源参考基因Actin Endogenous gene Actin	GmActin11F	ATCTTGACTGAGCGTGGTTATTCC	126
内源参考基因Actin Endogenous gene Actin	GmActin11R	GCTGGTCCTGGCTGTCTCC	126
侧翼序列ZH10P1/GAT-2 Flanking sequence ZH10P1/GAT-2	ZH10P1	TAATAGTAGAATGGGACTGGTGGAT	810
侧翼序列ZH10P1/GAT-2 Flanking sequence ZH10P1/GAT-2	GAT	GCGGACTTGCTTTGGTGTAAT	810
侧翼序列G2EPSPS-2/ZH10P2 Flanking sequence G2EPSPS-2/ZH10P2	G2	CCCGAATCATCAGGCAAACA	1626
侧翼序列G2EPSPS-2/ZH10P2 Flanking sequence G2EPSPS-2/ZH10P2	ZH10P2	AACACATCATAGTATTCTAAAACGCTT	1626
外源基因G2-EPSPS Exogenous gene G2-EPSPS	G2-EPSPS F	CAAATCCATTACCAACCGTGC	430
外源基因G2-EPSPS Exogenous gene G2-EPSPS	G2-EPSPS R	ACCACCATCAATCTCGAAACG	430
外源基因GAT Exogenous gene GAT	GAT F	CTCAGACCAAACCAGCCGATAG	338
外源基因GAT Exogenous gene GAT	GAT R	GTGTCGAATACCTCTCCCTGCTC	338

衍生品系类型 Derived strain type	引物名称 The name of the primers						衍生品系名称 The name of the derivative lines
衍生品系类型 Derived strain type	GmActin11	G2-EPSPS	GAT	ZH10P1/GAT	G2/ZH10P2	ZH10P1/ZH0P2	衍生品系名称 The name of the derivative lines
类型1 Type 1	√					√	NZG700、ZH10
类型2 Type 2	√	√	√	√	√		NZK100、NZK180、NZJ77、NZJ110、SUN100、ZH10-6
类型3 Type 3	√	√	√			√	NZC400
类型4 Type 4	√	√	√				NZK001
类型5 Type 5	√	√	√	√	√	√	NZC100、NZK150、NZM150
