1985—2015年福建省农牧系统磷素流动特征及影响因素

doi:10.3864/j.issn.0578-1752.2020.07.011

摘要/Abstract

摘要： 【目的】探明福建省农牧系统磷素流动时间变化特征及其影响因素,为实施农牧系统养分资源综合管理和推进农业绿色发展提供科学依据。【方法】 通过整理福建省1985—2015年统计年鉴中农牧业产品活动数据和补充文献中农牧业产品养分参数,结合实地调研,使用NUFER (nutrient flows in food chain, environment and resources use) 模型,定量估算1985—2015年福建省种植业和养殖业磷素流动账户平衡、利用率与损失变化特征,明确影响农牧生产系统磷素流动的主要因素。【结果】 1985—2015年,福建省农牧生产系统磷素输入总量由63.1 Gg升至196.2 Gg,主要输入项为化肥投入及饲料进口,其中种植业单位面积化肥磷投入量由27.8 kg·hm^-2逐渐上升并稳定于60.4 kg·hm^-2,受福建省种植业及养殖业规模和结构变化影响,本地饲料磷供应量由3.33 Gg降至1.65 Gg,饲料磷进口数量由20.7 Gg增至70.2 Gg;农牧系统输出端,磷素输出总量由45.0 Gg增至90.9 Gg,主要输出项为作物主产品和粪尿损失,其中作物主产品变化较小,由24.3 Gg增至26.7 Gg,粪尿损失磷增加较多,由1.44 Gg增至25.8 Gg;在农牧系统内部,磷素的主要去向为土壤累积,且逐年上升,由18.1 Gg升至106 Gg,种植业磷素利用率（PUE_c）由36.1%降至16.6%,农牧系统的磷素利用率（PUE_c+a）变化趋势与PUE_c相仿,逐渐下降并最终维持于15.0%,同时单位农牧产品磷损失由0.3 kg P·kg^-1逐渐上升并稳定于1.3 kg P·kg^-1。在经济发展和种植结构方面,当人均生产总值（GDP）<1.1万元时,GDP与化肥磷投入数量呈显著正相关,当GDP<1.5万元时,与单位农牧产品磷损失之间呈显著正相关,人均GDP<1.3万元时,与PUE_c呈显著负相关;经济作物播种面积占比与单位农牧产品磷损失、化肥磷投入之间呈极显著正相关,与PUE_c之间呈极显著负相关。【结论】 当前福建省种植业结构特征为经济作物播种面积占比较高,同时单位面积化肥磷投入量较大,养殖业畜禽粪尿循环不充分,导致单位农牧产品磷损失较多,同时磷素利用率偏低。因此,控制磷肥的施用量、增强农牧业废弃物资源化利用程度,将是提高福建省农牧系统磷素利用率,促进农牧业可持续绿色发展的保障。

关键词: 磷素, NUFER模型, 磷素利用率, 农牧系统, 经济作物占比

Abstract: 【Objective】The objective of this study is to determine the temporal changes and influencing factors of phosphorus (P) flows in the crop-livestock system of Fujian Province, and to provide a scientific reference for integrated nutrient management and green development of agriculture.【Method】Using a coupled NUFER (nutrient flows in food chain, environment and resources use) model, data were collected and sorted from statistical yearbooks, literatures, and field investigations from 1985 to 2015 to quantitatively estimate the balance, use efficiency and loss characteristics of P flow in the crop-livestock system of Fujian Province. 【Result】The total P input in crop-livestock production system increased from 63.1 to 196.2 Gg in Fujian Province from 1985 to 2015. The main P format inputs were fertilizer and feed import. The amount of per unit area of P fertilizer input in crop system increased gradually from 27.8 to 60.4 kg·hm^-2. Due to the influence of scale and structure change of crop-livestock system in Fujian Province, local feed supply decreased from 3.33 to 1.65 Gg, while the feed import increased from 20.7 to 70.2 Gg. From the output perspective, total P increased from 45.0 to 90.9 Gg, mainly including crop main product and animal manure loss. P uptake of crop main products changed slightly (only from 24.3 to 26.7 Gg), while the P loss in animal manure increased significantly from 1.44 to 25.8 Gg. Soil accumulation is the main loss pathway of P in crop-livestock system, which increased year by year from 18.1 to 106 Gg. P use efficiency in crop production system (PUE_c) decreased from 36.1% to 16.6%, and the change trend of P use efficiency in crop-livestock system (PUE_c+a) was similar to that of PUE_c, which gradually decreased and eventually remained at 15.0%. In the same time, the unit P loss of crop-livestock products increased gradually from 0.3 to 1.3 kg P·kg^-1. In terms of economic development and planting structure, there was a significant positive correlation between per capita GDP and fertilizer input when the per capita GDP was less than 11 000 yuan. When per capita GDP was less than 15 000 yuan, there was a significant positive correlation between per capita GDP and unit P loss of crop-livestock products, but there was a significantly negative correlation between per capita GDP and PUE_c when per capita GDP was less than 13 000 yuan. The proportion of cash crops planting area was significantly and positively correlated with the unit P loss of crop-livestock products and P input of fertilizer, and it was significantly negatively correlated with PUE_c.【Conclusion】At present, the cash crops planting area is relatively high, which is one of the structural characteristics of crop system in Fujian Province. At the same time, the unit area quantity of P input by fertilizer is large, circulation of animal manure is inadequate, which probably lead to more unit P loss in crop-livestock products, and low P use efficiency. Therefore, controlling the application amount of phosphate fertilizer and enhancing the utilization level in crop-livestock waste resources will be the guarantee in improving P use efficiency and promoting agriculture sustainable green development in Fujian Province.

Key words: phosphorus, NUFER model, phosphorus use efficiency, crop-livestock system, proportion of cash crops

刘东晖,张世昌,杨静,黄梦元,吴良泉. 1985—2015年福建省农牧系统磷素流动特征及影响因素[J]. 中国农业科学, 2020, 53(7): 1419-1431.

DongHui LIU,ShiChang ZHANG,Jing YANG,MengYuan HUANG,LiangQuan WU. Characteristics and Influencing Factors of Phosphorus Flows in the Crop-Livestock System of Fujian Province from 1985 to 2015[J]. Scientia Agricultura Sinica, 2020, 53(7): 1419-1431.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2020.07.011

https://www.chinaagrisci.com/CN/Y2020/V53/I7/1419

图/表 10

图1

表1

表2

表3

表4

图2

图3

图4

图5

图6

参考文献 44

[1]	SCHACHTMAN D P, REID R J, AYLING S M.Phosphorus uptake by plants: From soil to cell.Plant Physiology, 1998, 116(2): 447-453.
[2]	CORDELL D, NESET T S S. Phosphorus vulnerability: A qualitative
	framework for assessing the vulnerability of national and regional food systems to the multi-dimensional stressors of phosphorus scarcity.Global Environmental Change, 2014, 24(1): 108-122.
[3]	KOPPELAAR R H E M, WEIKARD H P. Assessing phosphate rock depletion and phosphorus recycling options.Global Environmental Change, 2013, 23(6): 1454-1466.
[4]	BOUWMAN L, GOLDEWIJK K K, VAN DER HOEK K W, BEUSEN A H W, VAN VUUREN D P, WILLEMS J, RUFINO M C, STEHFEST E. Exploring global changes in nitrogen and phosphorus cycles in agriculture induced by livestock production over the 1900-2050 period.Proceedings of the National Academy of Sciences of the United States of America, 2013, 110(52): 20882-20887.
[5]	SUH S, YEE S.Phosphorus use-efficiency of agriculture and food system in the US.Chemosphere, 2011, 84(6): 806-813.
[6]	OTT C, RECHBERGER H.The European phosphorus balance.Resources, Conservation and Recycling, 2012, 60(3): 159-172.
[7]	张晓萌. 东北地区食物链氮磷养分流动特征研究[D]. 长春: 吉林农业大学, 2017: 22-34.
	ZHANG X M.Study on characteristics of nitrogen and phosphorus nutrient flow in food chain in northeast China[D]. Changchun: Jilin Agricultural University, 2017: 22-34. (in Chinese)
[8]	张华芳. 河北省农牧生产体系氮磷养分流动特征及调控途径[D]. 保定: 河北农业大学, 2013: 15-30.
	ZHANG H F.Nitrogen and phosphorus flow in agro-livestock system and strategies of optimization in Hebei Province[D]. Baoding: Hebei Agricultural University, 2013: 15-30. (in Chinese)
[9]	张建杰, 郭彩霞, 张一弓, 张强. 山西省农牧生产体系磷流动空间变异特征. 中国生态农业学报, 2016, 24(5): 553-562.
	ZHANG J J, GUO C X, ZHANG Y G, ZHANG Q.Spatial characteristics of phosphorus flow in crop-livestock production systems in Shanxi, China.Chinese Journal of Eco-Agriculture, 2016, 24(5): 553-562. (in Chinese)
[10]	SMIL V.Phosphorus in the environment: Natural flows and human interferences.Annual Review of Energy and the Environment, 2000, 25: 53-88.
[11]	SENTHILKUMAR K, MOLLIER A, PELLERIN S.Regional-scale phosphorus flows and budgets within France: The importance of agricultural production systems.Nutrient Cycling in Agroecosystems, 2012, 92(2): 145-159.
[12]	MA L, MA W Q, VELTHOF G L, WANG F H, QIN W, ZHANG F S, OENEMA O.Modeling nutrient flows in the food chain of China.Journal of Environmental Quality, 2010, 39(4): 1279-1289.
[13]	魏莎, 柏兆海, 吴迪梅, 夏立江, 江荣风, 马林. 都市圈“土壤-饲料-动物”系统养分流动与环境效应——以北京市为例. 中国农业科学, 2018, 51(3): 430-441.
	WEI S, BAI Z H, WU D M, XIA L J, JIANG R F, MA L.Nutrient flow and environmental effects of “soil-feed-livestock” system in metropolis: A case study in Beijing.Scientia Agricultura Sinica, 2018, 51(3): 430-441. (in Chinese)
[14]	BAI Z H, MA L, MA W Q, QIN W, VELTHOF G L, OENEMA O, ZHANG F S.Changes in phosphorus use and losses in the food chain of China during 1950-2010 and forecasts for 2030.Nutrient Cycling in Agroecosystems, 2016, 104(3): 361-372.
[15]	龙军, 张黎明, 沈金泉, 周碧青, 毛艳玲, 邱龙霞, 邢世和. 复杂地貌类型区耕地土壤有机质空间插值方法研究. 土壤学报, 2014, 51(6): 1270-1281.
	LONG J, ZHANG L M, SHEN J Q, ZHOU B Q, MAO Y L, QIU L X, XING S H.Spatial interpolation of soil organic matter in farmlands in areas complex in landform.Acta Pedologica Sinica, 2014, 51(6): 1270-1281. (in Chinese)
[16]	福建省统计局. 福建统计年鉴. 北京: 中国统计出版社, 1986-2016.
	Statistical Bureau of Fujian Province. Fujian Statistical Yearbook. Beijing: China Statistics Press, 1986-2016. (in Chinese)
[17]	马怡斐, 柏兆海, 马林, 聂永强, 江荣风. 栾城城郊型农牧系统养分流动与环境排放时空特征. 中国农业科学, 2018, 51(3): 493-506.
	MA Y F, BAI Z H, MA L, NIE Y Q, JIANG R F.Temporal and spatial changes of nutrient flows and losses in the peri-urban crop-livestock system in Luancheng.Scientia Agricultura Sinica, 2018, 51(3): 493-506. (in Chinese)
[18]	BAI Z H, MA W Q, MA L, VELTHOF G L, WEI Z B, HAVLIK P, OENEMA O, LEE M R F, ZHANG F S. China’s livestock transition: Driving forces, impacts, consequences. Science Advances, 2018, 4 (7): eaar8534.
[19]	福建省统计局. 福建经济与社会统计年鉴. 福州: 福建人民出版社, 1986-2016.
	Statistical Bureau of Fujian Province. Fujian Economic and Social Statistical Yearbook. Fuzhou: Fujian People’s Publishing House, 1986-2016. (in Chinese)
[20]	国家统计局环境保护部. 中国环境统计年鉴. 北京: 中国统计出版社, 1986-2016.
	Ministry of Environmental Protection of the National Bureau of Statistics. China Environmental Statistics Yearbook. Beijing: China Statistics Press, 1986-2016. (in Chinese)
[21]	陈代文. 动物营养与饲料学. 2版. 北京: 中国农业出版社, 2015: 107-304.
	CHEN D W.Animal Nutrition and Feed Science. 2nd ed. Beijing: China Agriculture Press, 2015: 107-304. (in Chinese)
[22]	杨扎根. 主要农作物施肥技术. 北京: 中国农业出版社, 2012: 360-365.
	YANG Z G.Main Crop Fertilization Technology. Beijing: China Agriculture Press, 2012: 360-365. (in Chinese)
[23]	李书田, 金继运. 中国不同区域农田养分输入、输出与平衡. 中国农业科学, 2011, 44(20): 4207-4229.
	LI S T, JIN J Y.Characteristics of nutrient input/output and nutrient balance in different regions of China. Scientia Agricultura Sinica, 2011, 44(20): 4207-4229. (in Chinese)
[24]	全国农业技术推广服务中心. 中国有机肥料养分志. 北京: 中国农业出版社, 1999: 5-142
	National Agricultural Technology Extension Service Center. China Organic Fertilizer Nutrient. Beijing: China Agriculture Press, 1999: 5-142. (in Chinese)
[25]	林栤清, 陈亢川. 福建省食物营养成分表. 福州: 福建科学技术出版社, 1991: 4-40.
	LIN B Q, CHEN K C.Fujian Food Nutrition Composition Table. Fuzhou: Fujian Science and Technology Publishing House, 1991: 4-40. (in Chinese)
[26]	罗文华, 周勤飞, 杨金龙. 适度规模肉兔场高效生产技术. 北京: 中国农业科学技术出版社, 2015: 12-21.
	LUO W H, ZHOU Q F, YANG J L.Efficient Production Technology of Moderate-scale Meat Rabbit Farm. Beijing: China Agricultural Science and Technology Press, 2015: 12-21. (in Chinese)
[27]	黄炎坤, 姜东凤. 肉鸡场标准化示范技术. 郑州: 河南科学技术出版社, 2014: 88-112.
	HUANG Y K, JIANG D F.Broiler Farm Standardization Demonstration Technology. Zhengzhou: Henan Science and Technology Press, 2014: 88-112. (in Chinese)
[28]	贾佳. 鸭鹅最佳出栏时间. 农村养殖技术, 2011(19): 49.
	JIA J.Best time for ducks and geese out of the bar.Rural Breeding Technology, 2011(19): 49. (in Chinese)
[29]	中国农业大学. 家畜粪便学. 上海: 上海交通大学出版社, 1997: 265-272.
	China Agricultural University. Livestock Manure.Shanghai: Shanghai Jiaotong University Press, 1997: 265-272. (in Chinese)
[30]	朱金凤, 张丁华, 庞歌, 秦彩玲. 黄河湿地野鸭孵化期蛋壳钙、磷含量变化规律的研究. 中国家禽, 2008, 30(6): 24-26.
	ZHU J F, ZHANG D H, PANG G, QIN C L.Change of calcium, phosphorus and potassium contents inside the mallard eggshell in the marsh of the Yellow River during different periods of hatching.China Poultry, 2008, 30(6): 24-26. (in Chinese)
[31]	彭克美. 畜禽解剖学. 2版. 北京: 高等教育出版社, 2009: 11-277.
	PENG K M.Livestock and Poultry Anatomy. 2nd ed. Beijing: Higher Education Press, 2009: 11-277. (in Chinese)
[32]	MA L, VELTHOF G L, WANG F H, QIN W, ZHANG W F, LIU Z, ZHANG Y, WEI J, LESSCHEN J P, MA W Q, OENEMA O, ZHANG F S.Nitrogen and phosphorus use efficiencies and losses in the food chain in China at regional scales in 1980 and 2005.Science of the Total Environment, 2012, 434(18): 51-61.
[33]	林瑞坤, 许修柱, 郑朝元, 叶德练, 张世昌, 颜晓军, 刘东晖, 吴良泉. 福建省平和县蜜柚园磷肥使用现状及土壤磷素平衡研究. 福建热作科技, 2018, 43(3): 5-12.
	LIN R K, XU X Z, ZHENG C Y, YE D L, ZHANG S C, YAN X J, LIU D H, WU L Q.Present situation of phosphate fertilizer use and soil phosphorus balance in Pinhe County, Fujian Province.Fujian Science and Technology of Tropical Crops, 2018, 43(3): 5-12. (in Chinese)
[34]	林海柱. 永定县水稻施肥现状、问题与对策. 福建农业科技, 2006(3): 56-57.
	LIN H Z.Present situation, problems and countermeasures of rice fertilization in Yongding County.Fujian Agricultural Science and Technology, 2006(3): 56-57. (in Chinese)
[35]	LI H, HUANG G, MENG Q, MA L, YUAN L, WANG F, ZHANG W, CUI Z, SHEN J, CHEN X, JIANG R, ZHANG F.Integrated soil and plant phosphorus management for crop and environment in China. A review.Plant and Soil, 2011, 349(1/2): 157-167.
[36]	张晓萌, 王寅, 焉莉, 冯国忠, 高强. 东北地区农牧系统氮、磷养分流动特征. 中国农业科学, 2018, 51(3): 417-429.
	ZHANG X M, WANG Y, YAN L, FENG G Z, GAO Q.Characteristics of nitrogen and phosphorus nutrient flow in farming and animal husbandry system in northeast China.Scientia Agricultura Sinica, 2018, 51(3): 417-429. (in Chinese)
[37]	MA L, WANG F H, ZHANG W F, MA W Q, VELTHOF G, QIN W, OENEMA O, ZHANG F S.Environmental assessment of management options for nutrient flows in the food chain in China.Environmental Science and Technology, 2013, 47(13): 7260-7268.
[38]	ZHANG F S, CUI Z L, FAN M S, ZHANG W F, CHEN X P, JIANG R F.Integrated soil-crop system management: Reducing environmental risk while increasing crop productivity and improving nutrient use efficiency in China.Journal of Environmental Quality, 2011, 40(4): 1051-1057.
[39]	许修柱. 琯溪蜜柚生产中的碳排放及优化施肥的综合效应评价[D]. 福州: 福建农林大学, 2019: 32-46.
	XU X Z.Comprehensive evaluation of carbon emission and optimum fertilization in Guanxi pomelo production[D]. Fuzhou: Fujian Agriculture and Forestry University, 2019: 32-46. (in Chinese)
[40]	刘源. 东部沿海地区: 福建省福清市畜禽粪污资源化利用整县推进情况. 中国畜牧业, 2018(20): 24-26.
	LIU Y.Eastern coastal area: The promotion of the utilization of livestock and poultry manure resources in Fuqing City, Fujian Province.China Animal Industry, 2018(20): 24-26. (in Chinese)
[41]	张福锁. 最佳养分管理技术列单. 北京: 中国农业大学出版社, 2010: 92-102.
	ZHANG F S.List of Best Nutrient Management Technologies. Beijing: China Agricultural University Press, 2010: 92-102. (in Chinese)
[42]	BOSI P.Feeding strategies to produce high quality pork.Asian Australasian Journal of Animal Sciences, 1999, 12(2): 271-281.
[43]	贾伟. 我国粪肥养分资源现状及其合理利用分析[D]. 北京: 中国农业大学, 2014: 99-111.
	JIA W.Studies on the evaluation of nutrient resources derived from manure and optimized utilization in arable land of China[D]. Beijing: China Agricultural University, 2014: 99-111. (in Chinese)
[44]	王宝英, 邓同炜, 黄炎坤, 向瑞平, 王扬伟. 新编禽病诊疗手册. 郑州: 中原农民出版社, 2006: 21-58.
	WANG B Y, DENG T W, HUANG Y K, XIANG R P, WANG Y W.New Poultry Diseases Handbook. Zhengzhou: Zhongyuan Peasant Press, 2006: 21-58. (in Chinese)

作物种类<break/>Crop	收获可（食）用部分Harvest edible parts		收获不可（食）用部分Harvest non-edible parts
作物种类<break/>Crop	百分比Percent (%)	磷含量P content (%)	百分比Percent (%)	磷含量P content (%)
（干）稻谷Rice	53	0.300	47	0.130
（干）小麦Wheat	48	0.370	52	0.080
（干）油料Oil plant	56	0.305	44	0.163
（鲜）薯类Tuber crop	67	0.020	33	0.045
（鲜）甘蔗Sugarcane	77	0.014	23	0.046
（干）烟叶Tobacco	38	0.184	62	0.169
（干）茶Tea	100	0.222	—	—
（鲜）水果Fruit	100	0.020	—	—
（鲜）蔬菜Vegetable	100	0.039	—	—
（鲜）青饲料Forage	100	0.080	—	—
（鲜）绿肥Green manure	—	—	100	0.057

畜禽种类<break/>Livestock	饲养周期<break/>Feeding period (d)	粪便日排泄量及其磷含量Daily excrement and P content		尿液日排泄量及磷含量Daily urine and P content
畜禽种类<break/>Livestock	饲养周期<break/>Feeding period (d)	排泄量Excretion (kg·d^-1)	磷含量P content (%)	排泄量Excretion (kg·d^-1)	磷含量P content (%)
肉牛Beef	>365	18.00	0.095	9.0	0.017
奶牛Cattle	>365	18.00	0.095	9.0	0.017
羊Sheep	243	1.50	0.216	0.5	0.021
猪Pig	198	2.00	0.245	3.0	0.022
兔Rabbit	180	0.08	0.296	—	—
肉鸡Broiler	55	0.09	0.413	—	—
蛋鸡Layer	>365	0.15	0.413	—	—
鸭、鹅<break/>Duck, Goose	60	0.17	0.289	—	—

	鲜重<break/>Fresh weight<break/>(kg)	畜禽身体划分Partitioning of animal body (%)			磷含量P content (%)
	鲜重<break/>Fresh weight<break/>(kg)	可食用部分 Edible part	骨头<break/>Bone	其他部分<break/>Other parts	可食用部分<break/>Edible part	骨头<break/>Bone	其他部分<break/>Other parts
猪Pig	90.00	50	13	37	0.18	3.3	0.07
牛Cattle	477.30	45	20	35	0.17	4.2	0.01
羊Sheep	35.00	55	24	21	0.17	5.6	0.15
禽Poultry	2.04	65	20	15	0.16	2.0	0.01
兔Rabbit	1.75	50	7.5	42.5	0.17	4.0	0.21
蛋Egg	—	90	—	10	0.21	—	0.20
奶Milk	—	100	—	—	0.09	—	—

项目Item	参数Parameter (%)
淋洗参数Leaching parameter	0.6
径流参数Runoff parameter	1.5
侵蚀参数Erosion parameter	7.2
