基于耕地承载力的十堰市畜禽养殖环境风险评价

doi:10.3864/j.issn.0578-1752.2023.05.009

摘要/Abstract

摘要：

【目的】十堰市是南水北调中线工程的核心水源区，全面认识畜禽养殖污染现状及其对耕地的潜在威胁，为加强畜禽粪便风险管控提供依据。【方法】运用畜禽粪便环境风险评价模型，对十堰市各县（区、市）2020年主要畜禽粪便来源结构进行定量分析，并从种养平衡视角对其环境风险进行综合评价。【结果】十堰市2020年主要畜禽养殖粪便猪粪当量达306.85×10⁴ t，且主要分布于郧阳区、丹江口市和房县，粪便中有机物的化学需氧量（COD）最大（57.00×10⁴ t），总氮（TN）（2.63×10⁴ t），总磷（TP）含量较少（0.65×10⁴ t）。十堰市畜禽养殖等标污染负荷总量为15.532×10¹⁰ m³，且在不同地区的来源结构差异明显，TP是畜禽养殖的首要污染物，其污染等标负荷占负荷总量的41.68%，其次为TN，污染负荷率为33.85%，COD的等标污染负荷率最小，为24.47%。养牛是十堰地区畜禽养殖面源污染的首要污染源，对等标污染负荷总量的贡献率达49.47%，其次为家禽（21.60%）。环境污染风险评价结果显示，全市单位耕地畜禽粪便负荷强度为10.15 t·hm^-2，警报值为0.338，分级指数为Ⅰ，对环境构成污染的威胁为“无”。TN、TP的负荷强度分别为0.09和0.02 t·hm^-2，环境风险指数为1.023和1.223，但区域间存在明显的空间分异特征。全市有超过1/2地区存在潜在的畜禽养殖污染风险，其中以茅箭区和郧阳区最为突出。以磷（P）为衡量标准，十堰市养殖总量须在现有基础上消减98.51万头猪当量。【结论】保持合理的畜禽养殖规模（≤441.00万头猪当量），同时做好污染物消减措施，对促进十堰市种养平衡和畜禽养殖业有序发展具有重要意义。

关键词: 十堰市, 耕地承载力, 畜禽粪便, 耕地负荷, 环境风险

Abstract:

【Objective】 Shiyan city was the core water source area of the middle route of the South-to-North Water Transfer Project, a comprehensive understanding of the current situation of livestock and poultry pollution and its potential threat to farmland would provide a basis for strengthening environmental risk control. 【Method】This paper used the livestock manure environmental risk assessment model to quantitatively analyze the source structure of livestock and poultry manure in different areas of Shiyan city in 2020, and the environmental risk from the perspective of the balance between planting and raising was comprehensively evaluated. 【Result】 The total amount of livestock and poultry manure reached 306.85×10⁴ t in 2020, and it was mainly distributed in Yunyang district, Danjiangkou city and Fangxian county. COD production was the highest (57.00×10⁴ t), followed by TN (2.63×10⁴ t), and TP production was less (0.65×10⁴ t). The total equivalent standard pollution load was 15.532×10¹⁰ m³, and the source structure was obviously inconsistent in different regions. TP was the primary pollutant in livestock and poultry breeding, and its equivalent standard pollution load accounts for 41.68% of the total load, followed by TN with the pollution load rate of 33.85%, and the lowest equivalent standard pollution load rate of COD was 24.47%. Cattle was the primary source of non-point source pollution in livestock and poultry production in Shiyan city, contributing 49.47% to the total pollution load of the equivalent standard, followed by poultry (21.60%). According to the result of environmental pollution risk assessment, the load of animal excretion per hectare of arable land in Shiyan city was 10.15 t·hm^-2, the alarm value was 0.338 and the risk level was Ⅰ, indicating the environmental pollution was “no risk”. The load intensity of TN and TP was 0.09 and 0.02 t·hm^-2, respectively, and the environmental risk index was 1.023 and 1.223, respectively, but there were obvious spatial differences among regions. More than half of the whole city had the potential pollution risk of livestock and poultry breeding, among which Maojian district and Yunyang District were the most serious. With phosphorus as the measurement standard, the total amount of breeding in Shiyan city was close to saturation, the total amount of livestock and poultry must be reduced by 98.51×10⁴ pigs equivalent on the existing basis.【Conclusion】It was of great significance to maintain a reasonable scale of poultry breeding (≤441.00×10⁴ pigs equivalent) and take measures of pollutant abatement, in order to promote the balance of planting and breeding and orderly development of livestock and poultry breeding in Shiyan city.

Key words: Shiyan city, arable land carrying capacity, livestock and poultry manure, cropland load, environmental risk

龚世飞, 肖能武, 丁武汉, 居学海, 吴平华, 余永松, 李虎. 基于耕地承载力的十堰市畜禽养殖环境风险评价[J]. 中国农业科学, 2023, 56(5): 920-934.

GONG ShiFei, XIAO NengWu, DING WuHan, JU XueHai, WU PingHua, YU YongSong, LI Hu. Environmental Risks Assessment of Livestock and Poultry Non- Point Source Pollution in Shiyan City Based on Arable Land Carrying Capacity[J]. Scientia Agricultura Sinica, 2023, 56(5): 920-934.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2023.05.009

https://www.chinaagrisci.com/CN/Y2023/V56/I5/920

图/表 11

表1

表2

表3

表4

图1

图2

图3

表5

表6

表7

表8

参考文献 43

[1]	刘晓永, 李书田. 中国畜禽粪尿养分资源及其还田的时空分布特征. 农业工程学报, 2018, 34(4): 1-14, 316.
	LIU X Y, LI S T. Temporal and spatial distribution of nutrient resource from livestock and poultry feces and its returning to cropland. Transactions of the Chinese Society of Agricultural Engineering, 2018, 34(4): 1-14, 316.(in Chinese)
[2]	国家环境保护总局自然生态保护司. 全国规模化畜禽养殖业污染情况调查及防治对策. 北京: 中国环境科学出版社, 2002.
	Department of Natural Ecology Protection, State Environmental Protection Administration. Investigation and Countermeasures on Pollution of Large-Scale Livestock and Poultry Industry in China. Beijing: China Environment Science Press, 2002.(in Chinese)
[3]	高定, 陈同斌, 刘斌, 郑袁明, 郑国砥, 李艳霞. 我国畜禽养殖业粪便污染风险与控制策略. 地理研究, 2006, 25(2): 311-319.
	GAO D, CHEN T B, LIU B, ZHENG Y M, ZHENG G D, LI Y X. Releases of pollutants from poultry manure in China and recommended strategies for the pollution prevention. Geographical Research, 2006, 25(2): 311-319.(in Chinese) doi: 10.11821/yj2006020015
[4]	胡静锋. 重庆市农业面源污染测算与空间特征解析. 中国农业资源与区划, 2017, 38(1): 135-144.
	HU J F. Measurement and spatial feature analysis of agricultural non-point source pollution in Chongqing. Chinese Journal of Agricultural Resources and Regional Planning, 2017, 38(1): 135-144.(in Chinese)
[5]	吴永胜, 孙越鸿, 杨雪, 许祯莹, 齐桂兰, 邱时秀, 李娟. 基于种养平衡的成都市畜禽养殖环境效应分析. 中国农业资源与区划, 2018, 39(1): 195-203.
	WU Y S, SUN Y H, YANG X, XU Z Y, QI G L, QIU S X, LI J. Analysis of environmental effect of livestock and poultry breeding based on planting-breeding balance in Chengdu. Chinese Journal of Agricultural Resources and Regional Planning, 2018, 39(1): 195-203.(in Chinese)
[6]	吴浩玮, 孙小淇, 梁博文, 陈家斌, 周雪飞. 我国畜禽粪便污染现状及处理与资源化利用分析. 农业环境科学学报, 2020, 39(6): 1168-1176.
	WU H W, SUN X Q, LIANG B W, CHEN J B, ZHOU X F. Analysis of livestock and poultry manure pollution in China and its treatment and resource utilization. Journal of Agro-Environment Science, 2020, 39(6): 1168-1176.(in Chinese)
[7]	杨旭, 黄艳艳, 刘海林, 茶正早, 罗微, 林清火. 海南省畜禽养殖环境承载力及有机肥替代化肥潜力分析. 农业环境科学学报, 2019, 38(11): 2609-2618.
	YANG X, HUANG Y Y, LIU H L, CHA Z Z, LUO W, LIN Q H. Potential for the environmental carrying capacity of livestock and poultry breeding to substitute organic fertil? izers in Hainan Province, China. Journal of Agro-Environment Science, 2019, 38(11): 2609- 2618.(in Chinese)
[8]	刘晓永, 王秀斌, 李书田. 中国农田畜禽粪尿磷负荷量及环境风险分析. 农业环境科学学报, 2019, 38(11): 2594-2608.
	LIU X Y, WANG X B, LI S T. Phosphorus loading rates from livestock and poultry faeces, and environmental evaluation in China. Journal of Agro-Environment Science, 2019, 38(11): 2594-2608.(in Chinese)
[9]	龚世飞, 丁武汉, 肖能武, 郭元平, 叶青松, 王巍, 李虎. 丹江口水库核心水源区典型流域农业面源污染特征. 农业环境科学学报, 2019, 38(12): 2816-2825.
	GONG S F, DING W H, XIAO N W, GUO Y P, YE Q S, WANG W, LI H. Characteristics of surface runoff and agricultural non-point source pollution in the core water source area of the Danjiangkou Reservoir. Journal of Agro-Environment Science, 2019, 38(12): 2816-2825.(in Chinese)
[10]	龚世飞, 丁武汉, 居学海, 肖能武, 叶青松, 黄进, 李虎. 典型农业小流域面源污染源解析与控制策略: 以丹江口水源涵养区为例. 中国农业科学, 2021, 54(18): 3919-3931. doi: 10.3864/j.issn.0578-1752.2021.18.011
	GONG S F, DING W H, JU X H, XIAO N W, YE Q S, HUANG J, LI H. Source analysis and control strategies of non-point source pollution in typical agricultural small watershed: A case study of Danjiangkou water conservation area. Scientia Agricultura Sinica, 2021, 54(18): 3919-3931.(in Chinese) doi: 10.3864/j.issn.0578-1752.2021.18.011
[11]	姜世英, 韩鹏, 贾振邦, 毛小玲, 司今, 叶芳芳. 南水北调中线丹江口库区农业面源污染PSR评价与基于GIS的空间特征分析. 农业环境科学学报, 2010, 29(11): 2153-2162.
	JIANG S Y, HAN P, JIA Z B, MAO X L, SI J, YE F F. Evaluation with PSR model and GIS analysis of agricultural non-point source pollution in Danjiangkou reservoir of the mid-route of the south-to-north water transfer project. Journal of Agro-Environment Science, 2010, 29(11): 2153-2162.(in Chinese)
[12]	王国重, 李中原, 左其亭, 屈建钢, 李晓宇. 丹江口水库水源区农业面源污染物流失量估算. 环境科学研究, 2017, 30(3): 415-422.
	WANG G Z, LI Z Y, ZUO Q T, QU J G, LI X Y. Estimation of agricultural non-point source pollutant loss in catchment areas of Danjiangkou reservoir. Research of Environmental Sciences, 2017, 30(3): 415-422.(in Chinese)
[13]	刘亚琼, 杨玉林, 李法虎. 基于输出系数模型的北京地区农业面源污染负荷估算. 农业工程学报, 2011, 27(7): 7-12.
	LIU Y Q, YANG Y L, LI F H. Estimation of pollution loads from agricultural nonpoint sources in Beijing region based on export coefficient modeling approach. Transactions of the Chinese Society of Agricultural Engineering, 2011, 27(7): 7-12.(in Chinese)
[14]	许策, 李晔, 束继年, 李松炳, 李明高. 汉江流域荆门段面源污染负荷时空分布与污染现状评价. 水土保持通报, 2017, 37(4): 63-68.
	XU C, LI Y, SHU J N, LI S B, LI M G. Spatial distribution and evaluation of non-point pollution source in Jingmen region of Hanjiang watershed. Bulletin of Soil and Water Conservation, 2017, 37(4): 63-68.(in Chinese)
[15]	谢经朝, 赵秀兰, 何丙辉, 李章安. 汉丰湖流域农业面源污染氮磷排放特征分析. 环境科学, 2019, 40(4): 1760-1769.
	XIE J C, ZHAO X L, HE B H, LI Z G. Analysis of the characteristics of nitrogen and phosphorus emissions from agricultural non-point sources on Hanfeng Lake Basin. Environmental Science, 2019, 40(4): 1760-1769.(in Chinese)
[16]	耿维, 胡林, 崔建宇, 卜美东, 张蓓蓓. 中国区域畜禽粪便能源潜力及总量控制研究. 农业工程学报, 2013, 29(1): 171-179, 295.
	GENG W, HU L, CUI J Y, BU M D, ZHANG B B. Biogas energy potential for livestock manure and gross control of animal feeding in region level of China. Transactions of the Chinese Society of Agricultural Engineering, 2013, 29(1): 171-179, 295.(in Chinese)
[17]	王方浩, 马文奇, 窦争霞, 马林, 刘小利, 许俊香, 张福锁. 中国畜禽粪便产生量估算及环境效应. 中国环境科学, 2006, 26(5): 614-617.
	WANG F H, MA W Q, DOU Z X, MA L, LIU X L, XU J X, ZHANG F S. The estimation of the production amount of animal manure and its environmental effect in China. China Environmental Science, 2006, 26(5): 614-617.(in Chinese)
[18]	朱建春, 张增强, 樊志民, 李荣华. 中国畜禽粪便的能源潜力与氮磷耕地负荷及总量控制. 农业环境科学学报, 2014, 33(3): 435-445.
	ZHU J C, ZHANG Z Q, FAN Z M, LI R H. Biogas potential, cropland load and total amount control of animal manure in China. Journal of Agro-Environment Science, 2014, 33(3): 435-445.(in Chinese)
[19]	郭珊珊, 张涵, 杨汝馨. 基于耕地承载力的畜禽养殖污染负荷及环境风险研究: 以四川省为例. 水土保持通报, 2019, 39(1): 226-232, 325.
	GUO S S, ZHANG H, YANG R X. Pollutant loads and environmental risks of livestock production based on arable land carrying capacity—A case study in Sichuan Province. Bulletin of Soil and Water Conservation, 2019, 39(1): 226-232, 325.(in Chinese)
[20]	张绪美, 董元华, 王辉, 沈旦. 中国畜禽养殖结构及其粪便N污染负荷特征分析. 环境科学, 2007, 28(6): 1311-1318.
	ZHANG X M, DONG Y H, WANG H, SHEN D. Structure of livestock and variation of fecal nitrogen pollution load in China. Environmental Science, 2007, 28(6): 1311-1318.(in Chinese)
[21]	张英, 武淑霞, 刘宏斌, 雷秋良, 王洪媛, 翟丽梅. 基于种养平衡的河南省畜禽养殖分析及其环境污染风险研究. 中国土壤与肥料, 2019(4): 24-30, 52.
	ZHANG Y, WU S X, LIU H B, LEI Q L, WANG H Y, ZHAI L M. Analysis on rationality and pollution of livestock industry in Henan Province based on balance between crop-planting and livestock- raising. Soils and Fertilizers Sciences in China, 2019(4): 24-30, 52.(in Chinese)
[22]	黄美玲, 夏颖, 范先鹏, 黄敏, 吴茂前, 刘冬碧, 张富林. 湖北省畜禽养殖污染现状及总量控制. 长江流域资源与环境, 2017, 26(2): 209-219.
	HUANG M L, XIA Y, FAN X P, HUANG M, WU M Q, LIU D B, ZHANG F L. Pollution status and total amount control of livestock and poultry breeding in Hubei Province. Resources and Environment in the Yangtze Basin, 2017, 26(2): 209-219.(in Chinese)
[23]	中国农业科学院农业环境与可持续发展研究所, 环境保护部南京环境科学研究所. 第一次全国污染源普查畜禽养殖业源产排污系数, 2009.
	Institute of Environment and Sustainable Development in Agriculture CAAS, Nanjing Institute of Environmental Sciences, MEP. The first national survey of pollution sources on pollution discharge coefficients of livestock and poultry industry, 2009.(in Chinese)
[24]	中华人民共和国生态环境部. 排放源统计调查产排污核算方法和系数手册. [2021-06-11]. https://www.mee.gov.cn/xxgk2018/xxgk/xxgk01/202106/t20210618_839512.html.
	Ministry of Ecology and Environment of the People’s Republic of China. Emission source statistics survey production and emission accounting method and coefficient manual. [2021-06-11]. https://www.mee.gov.cn/xxgk2018/xxgk/xxgk01/202106/t20210618_839512.Html. in Chinese)
[25]	卢少勇, 张萍, 潘成荣, 彭书传, 刘晓晖. 洞庭湖农业面源污染排放特征及控制对策研究. 中国环境科学, 2017, 37(6): 2278-2286.
	LU S Y, ZHANG P, PAN C R, PENG S C, LIU X H. Agricultural non-point source pollution discharge characteristic and its control measures of Dongtinghu Lake. China Environmental Science, 2017, 37(6): 2278-2286.(in Chinese)
[26]	黄美玲, 夏颖, 范先鹏, 黄敏, 吴茂前, 刘冬碧, 张富林. 湖北省三峡库区畜禽养殖污染现状评价. 生态学杂志, 2017, 36(3): 725-733.
	HUANG M L, XIA Y, FAN X P, HUANG M, WU M Q, LIU D B, ZHANG F L. Evaluation of livestock pollution status in the Three Gorges Reservoir Area of Hubei Province. Chinese Journal of Ecology, 2017, 36(3): 725-733.(in Chinese)
[27]	丁尚, 付阳, 郭浩浩, 宋晨阳, 李博玲, 赵洪伟. 海南岛1988—2018年畜禽粪尿氮磷负荷量及环境效应. 中国农业科学, 2020, 53(18): 3752-3763. doi: 10.3864/j.issn.0578-1752.2020.18.011
	DING S, FU Y, GUO H H, SONG C Y, LI B L, ZHAO H W. Nitrogen and phosphorus loads and their environmental effects of animal manure in Hainan Island from 1988 to 2018. Scientia Agricultura Sinica, 2020, 53(18): 3752-3763.(in Chinese) doi: 10.3864/j.issn.0578-1752.2020.18.011
[28]	郭利京, 黄振英. 淮河生态经济带农业面源污染空间分布及治理研究. 长江流域资源与环境, 2021, 30(7): 1746-1756.
	GUO L J, HUANG Z Y. Study on spatial distribution and control of agricultural non-point source pollution in Huaihe ecological economic belt. Resources and Environment in the Yangtze Basin, 2021, 30(7): 1746-1756.(in Chinese)
[29]	时晓瑞, 武升, 黄瑜, 欧三青, 王树仁, 马友华, 姜家生. 淮河流域奎濉河典型小流域农业面源污染调查与评价. 生态科学, 2021, 40(5): 109-115.
	SHI X R, WU S, HUANG Y, OU S Q, WANG S R, MA Y H, JIANG J S. Investigation and evaluation of agricultural non-point source pollution in typical small watershed of Kuisui River in Huaihe Basin in Suzhou City, Anhui Province. Ecological Science, 2021, 40(5): 109-115.(in Chinese)
[30]	唐肖阳, 唐德善, 鲁佳慧, 常文倩, 唐新玥. 汉江流域农业面源污染的源解析. 农业环境科学学报, 2018, 37(10): 2242-2251.
	TANG X Y, TANG D S, LU J H, CHANG W Q, TANG X Y. Source apportionment of agricultural nonpoint source pollution in the Hanjiang River Basin. Journal of Agro-Environment Science, 2018, 37(10): 2242-2251.(in Chinese)
[31]	HENKENS P L C M, KEULEN H V. Mineral policy in the Netherlands and nitrate policy within the European Community. NJAS - Wageningen Journal of Life Sciences, 2001, 49(2/3): 117-134. doi: 10.1016/S1573-5214(01)80002-6
[32]	OENEMA O, VAN LIERE L, PLETTE S, PRINS T, VAN ZEIJTS H, SCHOUMANS O. Environmental effects of manure policy options in The Netherlands. Water Science and Technology, 2004, 49(3): 101-108. pmid: 15053104
[33]	潘瑜春, 孙超, 刘玉, 唐秀美, 任艳敏. 基于土地消纳粪便能力的畜禽养殖承载力. 农业工程学报, 2015, 31(4): 232-239.
	PAN Y C, SUN C, LIU Y, TANG X M, REN Y M. Carrying capacity of livestock and poultry breeding based on feces disposal volume of land. Transactions of the Chinese Society of Agricultural Engineering, 2015, 31(4): 232-239.(in Chinese)
[34]	沈根祥, 钱晓雍, 梁丹涛, 顾海蓉, 姚政, 钱永清. 基于氮磷养分管理的畜禽场粪便匹配农田面积. 农业工程学报, 2006, 22(S2): 268-271.
	SHEN G X, QIAN X Y, LIANG D T, GU H R, YAO Z, QIAN Y Q. Research on suitable area for cropland application of animal manure based on nutrients management of nitrogen and phosphorus. Transactions of the Chinese Society of Agricultural Engineering, 2006, 22(S2): 268-271.(in Chinese)
[35]	卢树昌, 陈清, 张福锁, 贾文竹. 河北果园主分布区土壤磷素投入特点及磷负荷风险分析. 中国农业科学, 2008, 41(10): 3149-3157.
	LU S C, CHEN Q, ZHANG F S, JIA W Z. Characteristics of soil phosphorus input and phosphorus load risk in major orchards region of Hebei. Scientia Agricultura Sinica, 2008, 41(10): 3149-3157.(in Chinese)
[36]	MA L, GUO J H, VELTHOF G L, LI Y M, CHEN Q, MA W Q, OENEMA O, ZHANG F S. Impacts of urban expansion on nitrogen and phosphorus flows in the food system of Beijing from 1978 to 2008. Global Environmental Change, 2014, 28: 192-204. doi: 10.1016/j.gloenvcha.2014.06.015
[37]	GARRETT R D, NILES M T, GIL J D B, GAUDIN A, CHAPLIN- KRAMER R, ASSMANN A, ASSMANN T S, BREWER K, DE FACCIO CARVALHO P C, CORTNER O, DYNES R, GARBACH K, KEBREAB E, MUELLER N, PETERSON C, REIS J C, SNOW V, VALENTIM J. Social and ecological analysis of commercial integrated crop livestock systems: current knowledge and remaining uncertainty. Agricultural Systems, 2017, 155: 136-146. doi: 10.1016/j.agsy.2017.05.003
[38]	付莉, 王贵云, 杜连柱, 杨柳, 张克强, 杜会英. 猪场废水施用对设施白菜地土壤氮盈余的影响. 农业现代化研究, 2021, 42(2): 215-222.
	FU L, WANG G Y, DU L Z, YANG L, ZHANG K Q, DU H Y. Effects of swine wastewater manure application on soil nitrogen surplus characteristics of facility cabbage field. Research of Agricultural Modernization, 2021, 42(2): 215-222.(in Chinese)
[39]	楚天舒, 韩鲁佳, 杨增玲. 考虑种养平衡的黄淮海小麦-玉米模式下畜禽承载量估算. 农业工程学报, 2019, 35(11): 214-222.
	CHU T S, HAN L J, YANG Z L. Livestock carrying capacity estimation in wheat-corn production model of Huang-Huai-Hai Region considering planting-raising balance. Transactions of the Chinese Society of Agricultural Engineering, 2019, 35(11): 214-222.(in Chinese)
[40]	SÁEZ J A, CLEMENTE R, BUSTAMANTE M Á, YAÑEZ D, BERNAL M P. Evaluation of the slurry management strategy and the integration of the composting technology in a pig farm - Agronomical and environmental implications. Journal of Environmental Management, 2017, 192: 57-67. doi: S0301-4797(17)30055-5 pmid: 28135588
[41]	李文哲, 徐名汉, 李晶宇. 畜禽养殖废弃物资源化利用技术发展分析. 农业机械学报, 2013, 44(5): 135-142.
	LI W Z, XU M H, LI J Y. Prospect of resource utilization of animal faeces wastes. Transactions of the Chinese Society for Agricultural Machinery, 2013, 44(5): 135-142.(in Chinese)
[42]	邓远远, 郭焱, 朱俊峰. 政府规制下畜禽养殖废弃物处理合规行为选择. 中国农业资源与区划, 2021, 42(10): 95-102.
	DENG Y Y, GUO Y, ZHU J F. Disposal of waste in livestock and poultry breeding compliance behaviors on the government regulations. Chinese Journal of Agricultural Resources and Regional Planning, 2021, 42(10): 95-102.(in Chinese)
[43]	佘磊, 姜珊, 姜彩红, 李想, 柳王荣, 苏文幸, 吴根义. 我国畜禽养殖环境管理进程及展望. 农业环境科学学报, 2021, 40(11): 2277- 2282.
	SHE L, JIANG S, JIANG C H, LI X, LIU W R, SU W X, WU G Y. Progress and prospect for environmental management of livestock and poultry breeding in China. Journal of Agro-Environment Science, 2021, 40(11): 2277-2282.(in Chinese)

警报值 Alarm value	分级指数 Classification	对环境构成污染的威胁 Environmental risk
≤0.4	Ⅰ	无 No risk
0.4-0.7	Ⅱ	稍有 A little risk
0.7-1.0	III	有 Risky
1.0-1.5	Ⅳ	较严重 Medium risk
1.5-2.5	Ⅴ	严重 Severe risk
>2.5	Ⅵ	很严重 Extremely serious risk

畜禽种类 Livestock and poultry species	养殖规模 Farming scale (×10⁴)	污染物年输出系数 Pollutant output coefficient				猪粪当量换算系数 Equivalent conversion coefficient of livestock and poultry manure
畜禽种类 Livestock and poultry species	养殖规模 Farming scale (×10⁴)	粪便Manure (kg·a^-1)	TN (kg·a^-1)	TP (kg·a^-1)	COD (kg·a^-1)
猪 Pig	69.47	1122.00	36.51	4.84	302.24	1.00
牛 Cow	21.39	8402.30	65.93	10.52	2411.40	0.50
羊 Sheep	80.14	868.70	24.10	5.14	0.46	1.03
家禽 Poultry	1270.51	43.80	1.16	0.23	20.50	1.21

县（区、市） County (district, city)	养殖规模 Farming scale (×10⁴)				耕地面积 Agricultural acreage (×10⁴hm²)
县（区、市） County (district, city)	猪Pig	牛Cow	羊Sheep	家禽Poultry	耕地面积 Agricultural acreage (×10⁴hm²)
郧阳区Yunyang	21.06	6.60	17.33	233.66	4.544
郧西县Yunxi	9.28	2.73	16.38	137.57	4.548
竹山县Zhushan	9.36	2.82	7.35	169.51	6.664
竹溪县Zhuxi	9.55	2.82	5.47	84.72	6.323
房县Fang county	10.33	1.87	27.09	191.12	3.710
丹江口市Danjiangkou	9.13	4.46	5.22	424.21	4.149
茅箭区Maojian	0.39	0.05	0.81	17.00	0.103
张湾区Zhangwan	0.37	0.04	0.50	12.72	0.204
十堰市Shiyan	69.47	21.39	80.14	1270.51	30.240

污染指标 Pollution indicator	畜禽种类Livestock and poultry species				合计 Total	负荷强度 Load intensity (t·hm^-2)
污染指标 Pollution indicator	猪Pig	牛Cow	羊Sheep	家禽Poultry	合计 Total	负荷强度 Load intensity (t·hm^-2)
粪便量Fecal production (×10⁴ t)	77.95	179.73	69.62	55.65	382.94
猪粪当量Equivalent of pig manure (×10⁴ t)	77.95	89.86	71.71	67.33	306.85	10.15
TN (×10⁴ t)	0.29	1.08	0.63	0.64	2.63	0.09
TP (×10⁴ t)	0.08	0.29	0.15	0.13	0.65	0.02
COD (×10⁴ t)	4.80	39.98	0.02	12.20	57.00	1.88

污染物 Pollutant	负荷系数 Load factor	污染源 Pollutant source				P_in (×10¹⁰ m³)	K_in
污染物 Pollutant	负荷系数 Load factor	猪Pig	牛Cow	羊Sheep	家禽Poultry	P_in (×10¹⁰ m³)	K_in
TN	P_ij (×10¹⁰ m³)	0.584	2.152	1.252	1.271	5.258
TN	K_ij	0.1110	0.4093	0.2381	0.2416		0.3385
TP	P_ij(×10¹⁰ m³)	0.834	2.866	1.504	1.271	6.474
TP	K_ij	0.1288	0.4427	0.2322	0.1963		0.4168
COD	P_ij (×10¹⁰ m³)	0.320	2.665	0.001	0.813	3.800
COD	K_ij	0.0842	0.7015	0.0003	0.2140		0.2447
	P_nj (×10¹⁰ m³)	1.737	7.684	2.757	3.354	P=15.532
	K_nj	0.1119	0.4947	0.1775	0.2160	P=15.532
