OsDREB1J调控水稻籽粒大小的功能研究

doi:10.3864/j.issn.0578-1752.2025.08.001

摘要/Abstract

摘要：

【目的】AP2/ERF（APETALA2/ethylene responsive factor）超家族是一类对植物生长发育以及响应逆境胁迫起重要调节作用的转录因子，在植物中广泛存在，且成员众多。探究AP2/ERF家族基因在水稻籽粒大小调控中的功能，为水稻粒形改良提供重要的基因资源。【方法】通过同源重组法克隆OsDREB1J（LOC_Os08g43200），利用生物信息学、实时荧光定量PCR（qRT-PCR）等技术对该基因的基本特性、组织表达特性及在激素下的表达模式等进行分析；利用酵母异源表达、水稻原生质体瞬时表达、烟草瞬时表达技术分析该基因的转录活性和亚细胞定位；利用遗传转化体系获得该基因的过表达和基因敲除水稻突变体，并运用表型分析技术对其粒型进行分析。【结果】亚细胞定位结果显示，OsDREB1J定位于细胞核。生物信息学分析结果显示，该基因序列全长为711 bp，编码236个氨基酸；OsDREB1J蛋白不具有跨膜结构域，相对分子质量为27.47 kDa，理论等电点为5.54，具有AP2/ERF家族特有的AP2保守结构域。启动子元件分析发现，该基因启动子的顺式作用元件包括与激素响应、光响应、逆境胁迫响应等相关的元件。实时荧光定量PCR（qRT-PCR）分析结果显示，OsDREB1J在水稻不同组织中均有表达，无组织特异性，但在穗中的表达量最高；同时，在不同激素处理下，OsDREB1J的表达受不同程度的诱导或抑制。转录活性分析结果显示，OsDREB1J全长无转录自激活活性，但C端是转录自激活所必需的结构域。表型分析结果表明，osdreb1j突变体的粒长、长宽比、千粒重显著高于ZH11，OsDREB1J过表达转基因水稻则相反，改变OsDREB1J的表达不影响水稻籽粒的粒宽。表明OsDREB1J可能是通过调控籽粒细胞的长度而非细胞增殖和细胞扩展来影响籽粒大小的。【结论】OsDREB1J可能通过激素信号通路调控水稻籽粒大小。

关键词: 水稻, OsDREB1J, 转录因子, 籽粒大小, 亚细胞定位, 表达模式

Abstract:

【Objective】 The AP2/ERF (APETALA2/ethylene responsive factor) superfamily is a group of transcription factors that play important regulatory roles in plant growth and development, as well as in response to adverse environmental stressors. The AP2/ERF transcription factors are widely present and have many members in plants. Exploring the function of AP2/ERF family gene on grain size provides important genetic resources for regulating grain shape in rice. 【Method】OsDREB1J gene (LOC_Os08g43200) was cloned by homologous recombination, and its basic characteristics, tissue expression characteristics, and the relative expression patterns under plant hormones were analyzed by bioinformatics and qRT-PCR. The transactivation activity and subcellular localization of OsDREB1J were analyzed by yeast heterologous expression, transient expression of rice protoplasts and tobacco. The overexpression and knockout mutant transgenic rice plants of OsDREB1J were obtained by genetic transformation system, and the grain size phenotypes were analyzed by phenotypic analysis technology. 【Result】Subcellular localization analysis showed that OsDREB1J was localized in the nucleus. Bioinformatics showed that the full-length coding sequence of OsDREB1J was 711 bp, encoding 236 amino acids. OsDREB1J protein had no transmembrane structure, and the molecular weight of 27.47 kDa, the theoretical isoelectric point of 5.54, and had a conserved AP2 domain unique to the AP2/ERF family. The cis-acting elements analysis of OsDREB1J promoter showed that the promoter contained cis-acting elements related to hormone response, light and stresses response. The qRT-PCR analysis showed that OsDREB1J was expressed in different tissues of rice with no tissue specificity, and the relative expression level in panicle was the highest. At the same time, OsDREB1J was induced or reduced by different hormone. Transcriptional activation analysis showed that the full-length of OsDREB1J has no transcriptional activity, but the C-terminal fragment was sufficient for the transactivation ability. Phenotypic analysis showed that the grain length, length-width ratio and thousand grain weight of osdreb1j mutant were significantly higher than those of ZH11, OsDREB1J overexpression transgenic rice plants displayed opposite phenotypes, while changing the expression of OsDREB1J did not affect rice grain width. These results show that OsDREB1J may affect grain size by regulating cell length rather than cell proliferation and cell expansion. 【Conclusion】In conclusion, OsDREB1J may be involved in regulating rice grain size through hormone signaling pathway.

Key words: rice, OsDREB1J, transcription factor, grain size, subcellular localization, expression pattern

韦萍, 潘炬忠, 朱德平, 邵胜雪, 陈珊珊, 韦雅倩, 高维维. OsDREB1J调控水稻籽粒大小的功能研究[J]. 中国农业科学, 2025, 58(8): 1463-1478.

WEI Ping, PAN JuZhong, ZHU DePing, SHAO ShengXue, CHEN ShanShan, WEI YaQian, GAO WeiWei. The Function of OsDREB1J in Regulating Rice Grain Size[J]. Scientia Agricultura Sinica, 2025, 58(8): 1463-1478.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2025.08.001

https://www.chinaagrisci.com/CN/Y2025/V58/I8/1463

图/表 10

表1

图1

表2

图2

图3

图4

图5

图6

图7

图8

参考文献 40

[1]	WANG Y Y, LV Y, YU H P, HU P, WEN Y, WANG J G, TAN Y Q, WU H, ZHU L X, WU K X, CHAI B Z, LIU J L, ZENG D L, ZHANG G H, ZHU L, GAO Z Y, DONG G J, REN D Y, SHEN L, ZHANG Q, LI Q, GUO L B, XIONG G S, QIAN Q, HU J. GR5 acts in the G protein pathway to regulate grain size in rice. Plant Communications, 2024, 5(1): 100673.
[2]	ZOU T, ZHANG K X, ZHANG J, LIU S J, LIANG J, LIU J X, ZHU J, LIANG Y Y, WANG S Q, DENG Q M, LIU H N, JIN J H, LI P, LI S C. DWARF AND LOW-TILLERING 2 functions in brassinosteroid signaling and controls plant architecture and grain size in rice. The Plant Journal, 2023, 116(6): 1766-1783. doi: 10.1111/tpj.16464 pmid: 37699038
[3]	JI X, DU Y X, LI F, SUN H Z, ZHANG J, LI J Z, PENG T, XIN Z Y, ZHAO Q Z. The basic helix-loop-helix transcription factor, OsPIL15, regulates grain size via directly targeting a purine permease gene OsPUP7 in rice. Plant Biotechnology Journal, 2019, 17(8): 1527-1537.
[4]	LU L, DIAO Z J, YANG D W, WANG X, ZHENG X X, XIANG X Q, XIAO Y P, CHEN Z W, WANG W, WU Y K, TANG D Z, LI S P. The 14-3-3 protein GF14c positively regulates immunity by modulating the protein homoeostasis of the GRAS protein OsSCL7 in rice. Plant, Cell & Environment, 2022, 45(4): 1065-1081.
[5]	悦曼芳, 张春, 吴忠义. 植物转录因子AP2/ERF家族蛋白结构和功能的研究进展. 生物技术通报, 2022, 38(12): 11-26. doi: 10.13560/j.cnki.biotech.bull.1985.2022-0432
	YUE M F, ZHANG C, WU Z Y. Research progress in the structural and functional analysis of plant transcription factor AP2/ERF protein family. Biotechnology Bulletin, 2022, 38(12): 11-26. (in Chinese)
[6]	EL OUAKFAOUI S, SCHNELL J, ABDEEN A, COLVILLE A, LABBÉ H, HAN S Y, BAUM B, LABERGE S, MIKI B. Control of somatic embryogenesis and embryo development by AP2 transcription factors. Plant Molecular Biology, 2010, 74(4/5): 313-326.
[7]	NAKANO T, SUZUKI K, FUJIMURA T, SHINSHI H. Genome-wide analysis of the ERF gene family in Arabidopsis and rice. Plant Physiology, 2006, 140(2): 411-432.
[8]	YANG L J, XU L, GUO J Z, LI A P, QI H Y, WANG J X, SONG S Y. SNAC1-OsERF103-OsSDG705 module mediates drought response in rice. New Phytologist, 2024, 241(6): 2480-2494.
[9]	JUNG H, CHUNG P J, PARK S H, REDILLAS M C F R, KIM Y S, SUH J W, KIM J K. Overexpression of OsERF48 causes regulation of OsCML16, a calmodulin-like protein gene that enhances root growth and drought tolerance. Plant Biotechnology Journal, 2017, 15(10): 1295-1308. doi: 10.1111/pbi.12716 pmid: 28244201
[10]	LEE D K, JUNG H, JANG G, JEONG J S, KIM Y S, HA S H, CHOI Y D, KIM J K. Overexpression of the OsERF71 transcription factor alters rice root structure and drought resistance. Plant Physiology, 2016, 172(1): 575-588.
[11]	HUANG S Z, MA Z M, HU L J, HUANG K, ZHANG M X, ZHANG S H, JIANG W Z, WU T, DU X L. Involvement of rice transcription factor OsERF19 in response to ABA and salt stress responses. Plant Physiology and Biochemistry, 2021, 167: 22-30. doi: 10.1016/j.plaphy.2021.07.027 pmid: 34329842
[12]	CHALLAM C, GHOSH T, RAI M, TYAGI W. Allele mining across DREB1A and DREB1B in diverse rice genotypes suggest a highly conserved pathway inducible by low temperature. Journal of Genetics, 2015, 94(2): 231-238. pmid: 26174670
[13]	MAO D H, CHEN C Y. Colinearity and similar expression pattern of rice DREB1s reveal their functional conservation in the cold- responsive pathway. PLoS ONE, 2012, 7(10): e47275.
[14]	WEI S B, LI X, LU Z F, ZHANG H, YE X Y, ZHOU Y J, LI J, YAN Y Y, PEI H C, DUAN F Y, WANG D Y, CHEN S, WANG P, ZHANG C, SHANG L G, ZHOU Y, YAN P, ZHAO M, HUANG J R, BOCK R, QIAN Q, ZHOU W B. A transcriptional regulator that boosts grain yields and shortens the growth duration of rice. Science, 2022, 377(6604): eabi8455.
[15]	HERATH V. Small family, big impact: In silico analysis of DREB2 transcription factor family in rice. Computational Biology and Chemistry, 2016, 65: 128-139. doi: S1476-9271(16)30262-6 pmid: 27816829
[16]	WANG H H, LU S, GUAN X Y, JIANG Y, WANG B, HUA J, ZOU B H. Dehydration-responsive element binding protein 1C, 1E, and 1G promote stress tolerance to chilling, heat, drought, and salt in rice. Frontiers in Plant Science, 2022, 13: 851731.
[17]	ZHANG M X, ZHAO R R, WANG H T, REN S L, SHI L Y, HUANG S Z, WEI Z Q, GUO B Y, JIN J Y, ZHONG Y, CHEN M J, JIANG W Z, WU T, DU X L. OsWRKY28 positively regulates salinity tolerance by directly activating OsDREB1B expression in rice. Plant Cell Reports, 2023, 42(2): 223-234.
[18]	MALLIKARJUNA G, MALLIKARJUNA K, REDDY M K, KAUL T. Expression of OsDREB2A transcription factor confers enhanced dehydration and salt stress tolerance in rice (Oryza sativa L.). Biotechnology Letters, 2011, 33(8): 1689-1697.
[19]	DU F P, WANG Y X, WANG J, LI Y B, ZHANG Y, ZHAO X Q, XU J L, LI Z K, ZHAO T Y, WANG W S, FU B Y. The basic helix- loop-helix transcription factor gene, OsbHLH38, plays a key role in controlling rice salt tolerance. Journal of Integrative Plant Biology, 2023, 65(8): 1859-1873.
[20]	MA X L, ZHANG Q Y, ZHU Q L, LIU W, CHEN Y, QIU R, WANG B, YANG Z F, LI H Y, LIN Y R, XIE Y Y, SHEN R X, CHEN S F, WANG Z, CHEN Y L, GUO J X, CHEN L T, ZHAO X C, DONG Z C, LIU Y G. A robust CRISPR/Cas9 system for convenient, high- efficiency multiplex genome editing in monocot and dicot plants. Molecular Plant, 2015, 8(8): 1274-1284.
[21]	LI N, LI Y H. Signaling pathways of seed size control in plants. Current Opinion in Plant Biology, 2016, 33: 23-32. doi: S1369-5266(16)30083-8 pmid: 27294659
[22]	SUN P Y, ZHANG W H, WANG Y H, HE Q, SHU F, LIU H, WANG J, WANG J M, YUAN L P, DENG H F. OsGRF4 controls grain shape, panicle length and seed shattering in rice. Journal of Integrative Plant Biology, 2016, 58(10): 836-847.
[23]	HAO J Q, WANG D K, WU Y B, HUANG K, DUAN P G, LI N, XU R, ZENG D L, DONG G J, ZHANG B L, ZHANG L M, INZÉ D, QIAN Q, LI Y H. The GW2-WG1-OsbZIP47 pathway controls grain size and weight in rice. Molecular Plant, 2021, 14(8): 1266-1280. doi: 10.1016/j.molp.2021.04.011 pmid: 33930509
[24]	姚莎莎, 王晶晶, 王俊杰, 梁卫红. 植物激素信号通路调控水稻粒型的分子机制. 生物技术通报, 2023, 39(8): 80-90. doi: 10.13560/j.cnki.biotech.bull.1985.2023-0273
	YAO S S, WANG J J, WANG J J, LIANG W H. Molecular mechanisms of rice grain size regulation related to plant hormone signaling pathways. Biotechnology Bulletin, 2023, 39(8): 80-90. (in Chinese)
[25]	CHEN Y, SUN M Z, JIA B W, LENG Y, SUN X L. Research progress regarding the function and mechanism of rice AP2/ERF transcription factor in stress response. Acta Agronomica Sinica, 2022, 48(4): 781-790. doi: 10.3724/SP.J.1006.2022.12026
[26]	TANG N, ZHANG H, LI X H, XIAO J H, XIONG L Z. Constitutive activation of transcription factor OsbZIP46 improves drought tolerance in rice. Plant Physiology, 2012, 158(4): 1755-1768. doi: 10.1104/pp.111.190389 pmid: 22301130
[27]	REN D Y, LI Y F, ZHAO F M, SANG X C, SHI J Q, WANG N, GUO S, LING Y H, ZHANG C W, YANG Z L, HE G H. MULTI-FLORET SPIKELET1, which encodes an AP2/ERF protein, determines spikelet meristem fate and sterile lemma identity in rice. Plant Physiology, 2013, 162(2): 872-884. doi: 10.1104/pp.113.216044 pmid: 23629832
[28]	YU L, YAO M, MAO L L, MA T F, NIE Y S, MA H L, SHAO K, AN H Q, ZHAO J. Rice DSP controls stigma, panicle and tiller primordium initiation. Plant Biotechnology Journal, 2023, 21(11): 2358-2373.
[29]	LEE D Y, AN G. Two AP2 family genes, supernumerary bract (SNB) and OsINDETERMINATE spikelet 1 (OsIDS1), synergistically control inflorescence architecture and floral meristem establishment in rice. The Plant Journal, 2012, 69(3): 445-461.
[30]	LI F C, WU L, LI X, CHAI Y N, RUAN N, WANG Y, XU N, YU Z W, WANG X C, CHEN H, LU J H, XU H, XU Z J, CHEN W F, XU Q. Dissecting the molecular basis of the ultra-large grain formation in rice. New Phytologist, 2024, 243(6): 2251-2264.
[31]	DUBOUZET J G, SAKUMA Y, ITO Y, KASUGA M, DUBOUZET E G, MIURA S, SEKI M, SHINOZAKI K, YAMAGUCHI-SHINOZAKI K. OsDREB genes in rice, Oryza sativa L., encode transcription activators that function in drought-, high-salt- and cold-responsive gene expression. Plant Journal, 2003, 33(4): 751-763.
[32]	WANG Y X, XIONG G S, HU J, JIANG L, YU H, XU J, FANG Y X, ZENG L J, XU E B, XU J, YE W J, MENG X B, LIU R F, CHEN H Q, JING Y H, WANG Y H, ZHU X D, LI J Y, QIAN Q. Copy number variation at the GL7 locus contributes to grain size diversity in rice. Nature Genetics, 2015, 47(8): 944-948. doi: 10.1038/ng.3346 pmid: 26147619
[33]	SI L Z, CHEN J Y, HUANG X H, GONG H, LUO J H, HOU Q Q, ZHOU T Y, LU T T, ZHU J J, SHANGGUAN Y Y, CHEN E W, GONG C X, ZHAO Q, JING Y F, ZHAO Y, LI Y, CUI L L, FAN D L, LU Y Q, WENG Q J, WANG Y C, ZHAN Q L, LIU K Y, WEI X H, AN K, AN G, HAN B. OsSPL13 controls grain size in cultivated rice. Nature Genetics, 2016, 48(4): 447-456. doi: 10.1038/ng.3518 pmid: 26950093
[34]	MAO H L, SUN S Y, YAO J L, WANG C R, YU S B, XU C G, LI X H, ZHANG Q F. Linking differential domain functions of the GS3 protein to natural variation of grain size in rice. Proceedings of the National Academy of Sciences of the United States of America, 2010, 107(45): 19579-19584.
[35]	DUAN P G, XU J S, ZENG D L, ZHANG B L, GENG M F, ZHANG G Z, HUANG K, HUANG L J, XU R, GE S, QIAN Q, LI Y H. Natural variation in the promoter of GSE5 contributes to grain size diversity in rice. Molecular Plant, 2017, 10(5): 685-694. doi: S1674-2052(17)30098-9 pmid: 28366824
[36]	WANG S K, WU K, YUAN Q B, LIU X Y, LIU Z B, LIN X Y, ZENG R Z, ZHU H T, DONG G J, QIAN Q, ZHANG G Q, FU X D. Control of grain size, shape and quality by OsSPL16 in rice. Nature Genetics, 2012, 44(8): 950-954. doi: 10.1038/ng.2327 pmid: 22729225
[37]	HU W L, WANG R, HAO X H, LI S Z, ZHAO X J, XIE Z J, WU S, HUANG L Q, TAN Y, TIAN L F, LI D P. OsLCD3 interacts with OsSAMS1 to regulate grain size via ethylene/polyamine homeostasis control. The Plant Journal, 2024, 119(2): 705-719.
[38]	ZHOU C L, LIN Q B, REN Y L, LAN J, MIAO R, FENG M, WANG X, LIU X, ZHANG S Z, PAN T, WANG J C, LUO S, QIAN J S, LUO W F, MOU C L, NGUYEN T, CHENG Z J, ZHANG X, LEI C L, ZHU S S, GUO X P, WANG J, ZHAO Z C, LIU S J, JIANG L, WAN J M. A CYP78As-small grain4-coat protein complex Ⅱ pathway promotes grain size in rice. The Plant Cell, 2023, 35(12): 4325-4346.
[39]	GAO P, CHEN F F, LIU H T, FAN S J, ZENG J R, DIAO X, LIU Y, SONG W C, WANG S F, LI J, ZHU X B, TU B, CHEN W L, LI T, WANG Y P, MA B T, LI S G, YUAN H, QIN P. qGW11a/ OsCAT8, encoding an amino acid permease, negatively regulates grain size and weight in rice. The Crop Journal, 2024, 12(4): 1150-1158.
[40]	CUI Z B, WANG X W, DAI Y D, LI Y Y, BAN Y J, TIAN W J, ZHANG X B, FENG X Y, ZHANG X F, JIA L Q, HE G H, SANG X C. Transcription factor OsNF-YC1 regulates grain size by coordinating the transcriptional activation of OsMADS1 in Oryza sativa L.. The Plant Journal, 2024, 119(3): 1465-1480.

引物名称Primer name	正向引物Forward primer (5′-3′)	反向引物Reverse primer (5′-3′)
OsDREB1J-GFP	ACTAGTGGATCCGGTACCATGGAGAAGAACACCACCGC	CTTGCTCACCATGGTACCGCTCCACAGCTCCATTTCAG
OsDREB1J-ox	TCTCTCTCAAGCTTGGATCCATGGAGAAGAACACCACCGC	ATACCGTCACTAGTGGATCCGCTCCACAGCTCCATTTCAG
BD-DREB1J	GCCATGGAGGCCGAATTCATGGAGAAGAACACCACCGC	CCGCTGCAGGTCGACGGATCCCGCTCCACAGCTCCATTTCAG
BD-DREB1J-N	GCCATGGAGGCCGAATTCATGGAGAAGAACACCACCGC	CCGCTGCAGGTCGACGGATCCCGAGCAGCCAGGCGGAGTC
BD-DREB1J-C	GCCATGGAGGCCGAATTCATGCACGTCCCCCGCGC	CCGCTGCAGGTCGACGGATCCCGCTCCACAGCTCCATTTCAG
OsDREB1J-q	CATGACCAGCTGCCCGACGT	GTGACAGAACGGGCGACGAC
DREB1J-62-sk	CGCCGTCTAGAACTAGTGGATCCATGGAGAAGAACACCACCGC	TCGATAAGCTTGATATCGAATTCCTAGCTCCACAGCTCCATTTC
DREB1J-N-62-sk	CGCCGTCTAGAACTAGTGGATCCATGGAGAAGAACACCACCGC	TCGATAAGCTTGATATCGAATTCCTAGAGCAGCCAGGCGGAGTC
DREB1J-C-62-sk	CGCCGTCTAGAACTAGTGGATCCATGCACGTCCCCCGCGC	TCGATAAGCTTGATATCGAATTCCTAGCTCCACAGCTCCATTTC
e-EF-1α	GCACGCTCTTCTTGCTTTC	AGGGAATCTTGTCAGGGTTG

名称 Name	序列 Sequence	功能 Function	数量 Number
ACE	GACACGTATG	参与光响应的顺式调节元件 Cis-acting element involved in light responsive ness	9
Sp1	GGGCGG	光响应元件 Light responsive element	6
TATA-box	TACAAAA	转录起始位点-30附件的核心启动子元件 Core promoter element around-30 of transcription start	7
TGACG-motif	TACAAAA	茉莉酸甲酯响应元件 Cis-acting regulatory element involved in the MeJA-responsiveness	5
CGTCA-motif	CGTCA	茉莉酸甲酯响应元件 Cis-acting regulatory element involved in the MeJA-responsiveness	5
TCA-element	CCATCTTTTT	水杨酸响应元件 Cis-acting element involved in salicylic acid responsive ness	9
G-Box	TGACG	参与光反应响应的顺式作用元件 Cis-acting regulatory element involved in light responsive ness	5
ABRE	ACGTG	脱落酸响应元件 Cis-acting element involved in the abscisic acid responsive ness	6
ABRE	CGCACGTGTC	脱落酸响应元件 Cis-acting element involved in the abscisic acid responsive ness	9
ABRE	CACGTG	脱落酸响应元件 Cis-acting element involved in the abscisic acid responsive ness	6
CAAT-box	CAAAT	启动子和增强子区域的通用的顺式作用元件 Common cis-acting element in promoter and enhancer regions	5
MBS	CAACTG	拟南芥中参与干旱诱导的MYB结合位点 Arabidopsis thaliana MYB binding site involved in drought-inducibility	6
GARE-motif	TCTGTTG	赤霉素响应元件 Gibberellin-responsive element	7
TCT-motif	TCTTAC	光响应元件 Partofa light responsive element	6
