溶剂蒸发法制备丙硫菌唑微囊及其性能研究

doi:10.3864/j.issn.0578-1752.2021.04.008

摘要/Abstract

摘要：

【目的】以生物可降解材料聚(3-羟基丁酸酯-co-4-羟基丁酸酯）（P(3HB-co-4HB)）为壁材制备丙硫菌唑微囊,研究制备工艺对微囊粒径、载药量及包封率的影响,筛选出分散性好、粒径较小、载药量高的配方,并对其释放动力学、光降解、对花生白绢病菌（Sclerotium rolfsii）室内生物活性等性能进行初步研究和表征,为提高丙硫菌唑在环境中的稳定性及利用率提供理论指导和技术支撑。【方法】采用溶剂蒸发法制备丙硫菌唑微囊,通过单因素试验探究芯壁材质量比、油水体积比、乳化剂质量分数和剪切速率对微囊粒径、载药量和包封率的影响;以载药量与粒径为关键技术指标,通过L₉(3⁴)正交试验筛选出最优制备工艺参数,并对正交试验结果进行验证;通过扫描电镜（SEM）、傅里叶红外光谱（FTIR）、高效液相色谱（HPLC）和室内毒力测定对微囊的外观形貌、释放性能、光稳定性能以及对花生白绢病菌的室内生物活性进行研究。【结果】芯壁材质量比对微囊的载药量有显著影响,随着芯材质量的增大,载药量逐渐增大;油水体积比、PVA质量分数、剪切速率对微囊粒径具有显著影响,随着剪切速率与PVA质量分数的增大,微囊粒径逐渐减小,油水体积比对微囊形态及分散性影响较大。试验中各因素对微囊包封率的影响并不显著。通过L₉(3⁴)正交试验配方优化获得最佳制备工艺：芯壁材质量比1﹕5,油水体积比1﹕5,PVA质量分数2%和剪切速率12 000 r/min。在最佳制备工艺条件下制备了粒径（D₅₀）为3.32 μm、跨距为2.82,分散性良好的球形丙硫菌唑微囊,载药量为15.52%,包封率为80.24%。该微囊具有较好的缓释性能,其释放动力学符合Fick扩散规律,呈现先“突释”后“缓释”两个过程。与原药相比,丙硫菌唑微囊在水溶液中的光稳定性增强,光解半衰期延长了一倍。菌丝生长抑制试验表明其对花生白绢病菌的抑制活性与原药相当。【结论】以生物可降解材料P(3HB-co-4HB)为载体制备丙硫菌唑微囊,不同制备工艺影响微囊的载药量、分散性和粒径大小,其缓释及光稳定性能对减少农药施用量、提高农药利用率具有重要意义。丙硫菌唑微囊在花生白绢病的防治方面具有良好的应用前景。

关键词: 丙硫菌唑, 聚羟基丁酸酯, 微囊, 制备工艺, 控制释放, 花生白绢病菌

Abstract:

【Objective】The biodegradable material poly (3-hydroxybutyrate-co-4-hydroxybutyrate) (P (3HB-co-4HB)) was used as the wall material to prepare prothioconazole microcapsules. The effect of preparation process on the microcapsule size, pesticide loading and encapsulation efficiency was optimized. The microcapsules with good dispersion, small particle size, and high pesticide loading were screened out, and the preliminary researches on the release kinetics, photodegradation, and indoor biological activity on Sclerotium rolfsii were carried out. The purpose of this study is to provide a theoretical basis and technical support for improving the stability and utilization efficiency of prothioconazole in the environment.【Method】The solvent evaporation method was used to prepare prothioconazole microcapsules, and the effects of the mass ratio of core to wall material, volume ratio of oil to water, mass fraction of emulsifier and shearing speed on the particle size, pesticide loading and encapsulation efficiency of the microcapsules were investigated through a single factor test. Taking pesticide loading and particle size as the key technical indicators, the optimal preparation parameters were screened out through the L₉(3⁴) orthogonal test, which was further verified. The morphological and structural features, release performance and photodegradability of the microcapsules were determined by scanning electron microscope (SEM), fourier transform infrared (FTIR) spectrometer, and high performance liquid chromatography (HPLC). The toxicity of prothioconazole microcapsules on S. rolfsii was investigated by indoor bioassay.【Result】The mass ratio of core to wall material had a significant effect on the pesticide loading capacity of the microcapsules. As the ratio of core material increased, the loading capacity gradually increased. The volume ratio of oil to water, PVA mass fraction, and shearing speed had significant effects on the microcapsule particle size. As the shearing speed and PVA mass fraction increased, the microcapsule particle size gradually decreased. The volume ratio of oil to water had a great influence on the morphology and dispersion of microcapsules, and the influence of various factors on the encapsulation efficiency of the microcapsules was not significant. The optimal preparation parameters obtained through the L₉(3⁴) orthogonal test was as follows: the mass ratio of core to wall material of 1﹕5, volume ratio of oil to water of 1﹕5, PVA mass fraction of 2%, and shearing speed of 12 000 r/min. Under the optimal preparation process, spherical prothioconazole microcapsules with a particle size (D₅₀) of 3.32 μm and a span of 2.82 were prepared with a loading content of 15.52% and an encapsulation efficiency of 80.24%. Compared with prothioconazole technical material, the microcapsules had better sustained-release performance, and the release kinetics conformed to Fick’s diffusion law, presenting two processes of “burst release” followed by “sustained release”. The photostability of prothioconazole in the microcapsules in aqueous solution was enhanced, and the half-life of photolysis was doubled. The mycelial growth rate inhibition result showed that the fungicidal activity of prothioconazole microcapsules against S. rolfsii was equivalent to that of prothioconazole technical material.【Conclusion】Prothioconazole microcapsules with biodegradable material P (3HB-co-4HB) as a carrier were prepared, and different preparation processes affect the pesticide loading, dispersion state and particle size of microcapsules. The slow and sustained release and photostability are of great significance for reducing the amount of pesticide applied and improving the utilization efficiency of pesticide, which has potential application in control of peanut southern blight.

Key words: prothioconazole, polyhydroxybutyrate, microcapsule, preparation process, controlled release, Sclerotium rolfsii

陈歌,曹立冬,许春丽,赵鹏跃,曹冲,李凤敏,黄啟良. 溶剂蒸发法制备丙硫菌唑微囊及其性能研究[J]. 中国农业科学, 2021, 54(4): 754-767.

CHEN Ge,CAO LiDong,XU ChunLi,ZHAO PengYue,CAO Chong,LI FengMin,HUANG QiLiang. Performance Study of Prothioconazole Microcapsules Prepared by Solvent Evaporation Method[J]. Scientia Agricultura Sinica, 2021, 54(4): 754-767.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2021.04.008

https://www.chinaagrisci.com/CN/Y2021/V54/I4/754

图/表 19

图1

图2

表1

表2

表3

表4

表5

表6

表7

表8

图3

图4

图5

图6

图7

表9

图8

表10

表11

参考文献 51

[1]	SANKOH A I, WHITTLE R, SEMPLE K T, JONES K C, SWEETMAN A J. An assessment of the impacts of pesticide use on the environment and health of rice farmers in Sierra Leone. Environment International, 2016,94:458-466.
[2]	ARIAS-ESTÉVEZ M, LÓPEZ-PERIAGO E, MARTÍNEZ-CARBALLO E, SIMAL-GÁNDARA J, MEJUTO J C, GARCÍA-RÍO L. The mobility and degradation of pesticides in soils and the pollution of groundwater resources. Agriculture, Ecosystems and Environment, 2008,123(4):247-260.
[3]	PARKER J E, WARRILOW A G S, COOLS H J, MARTEL C M, NES W D, FRAAIJE B A, KELLY D E, KELLY S L. Mechanism of binding of prothioconazole to Mycosphaerella graminicola CYP51 differs from that of other azole antifungals. Applied and Environmental Microbiology, 2011,77(4):1460-1465.
[4]	程圆杰, 崔蕊蕊, 郭雯婷, 左文静, 主艳飞, 庄占兴, 范金勇. 丙硫菌唑研究开发现状与展望. 山东化工, 2018,47(6):58-61.
	CHENG Y J, CUI R R, GUO W T, ZUO W J, ZHU Y F, ZHUANG Z X, FAN J Y. A review of research progress in the development of prothioconazole. Shandong Chemical Industry, 2018,47(6):58-61. (in Chinese)
[5]	黄华树, 柏亚罗. 丙硫菌唑的全球市场与应用开发. 现代农药, 2017,16(6):45-51.
	HUANG H S, BAI Y L. Global market, application and development of prothioconazole. Modern Agrochemicals, 2017,16(6):45-51. (in Chinese)
[6]	于雪骊, 邢立国, 楼少巍. 杀菌剂丙硫菌唑施用人员健康风险评估. 农药科学与管理, 2017,38(7):37-43.
	YU X L, XING L G, LOU S W. Operators’ health risk assessment of fungicide prothioconazole. Pesticide Science and Administration, 2017,38(7):37-43. (in Chinese)
[7]	农业农村部农药检定所. 中国农药信息网. http://www.chinapesticide. org.cn/.
	Pesticide Inspection Institute, Ministry of Agriculture and Rural Affairs. China pesticide information network. http://www.chinapesticide. org.cn/.(in Chinese)
[8]	许春丽, BILAL M, 徐博, 冉刚超, 赵鹏跃, 曹冲, 李凤敏, 曹立冬, 黄啟良. 荧光介孔二氧化硅负载丙硫菌唑纳米颗粒的制备及性能研究. 农药学学报, 2020,22(2):214-224.
	XU C L, BILAL M, XU B, RAN G C, ZHAO P Y, CAO C, LI F M, CAO L D, HUANG Q L. Preparation and characterization of prothioconazole-loaded fluorescent mesoporous silica nanoparticles. Chinese Journal of Pesticide Science, 2020,22(2):214-224. (in Chinese)
[9]	李北兴, 张大侠, 张灿光, 管磊, 王凯, 刘峰. 微囊化技术研究进展及其在农药领域的应用. 农药学学报, 2014,16(5):483-496.
	LI B X, ZHANG D X, ZHANG C G, GUAN L, WANG K, LIU F. Research advances and application prospects of microencapsulation techniques in pesticide. Chinese Journal of Pesticide Science, 2014,16(5):483-496. (in Chinese)
[10]	TSUJI K. Microencapsulation of pesticides and their improved handling safety. Journal of Microencapsulation, 2001,18(2):137-147.
[11]	王安琪, 王琰, 王春鑫, 崔博, 孙长娇, 赵翔, 曾章华, 姚俊伟, 刘国强, 崔海信. 农药纳米微囊化剂型研究进展. 中国农业科技导报, 2018,20(2):10-18.
	WANG A Q, WANG Y, WANG C X, CUI B, SUN C J, ZHAO X, ZENG Z H, YAO J W, LIU G Q, CUI H X. Research progress on nanocapsules formulations of pesticides. Journal of Agricultural Science and Technology, 2018,20(2):10-18. (in Chinese)
[12]	朱峰, 许春丽, 曹立冬, 曹冲, 李凤敏, 杜凤沛, 黄啟良. 农药微囊剂及其制备技术研究进展. 现代农药, 2018,17(2):12-16.
	ZHU F, XU C L, CAO L D, CAO C, LI F M, DU F P, HUANG Q L. Research advances of pesticide microcapsule and its preparative technique. Modern Agrochemicals, 2018,17(2):12-16. (in Chinese)
[13]	冯建国, 徐妍, 罗湘仁, 严寒, 吴学民. 浅谈溶剂蒸发法制备微胶囊与农药胶囊的开发. 农药学学报, 2011,13(6):568-575.
	FENG J G, XU Y, LUO X R, YAN H, WU X M. Discussion on the solvent evaporation method for preparation of microcapsules and the development of the pesticides microcapsules. Chinese Journal of Pesticide Science, 2011,13(6):568-575. (in Chinese)
[14]	乔吉超, 胡小玲, 张团红, 管萍. 溶剂蒸发法制备药物微胶囊研究进展. 化工进展, 2006,25(8):885-889, 927.
	QIAO J C, HU X L, ZHANG T H, GUAN P. Application of solvent evaporation method in preparation of drug microcapsule. Chemical Industry and Engineering Progress, 2006,25(8):885-889, 927. (in Chinese)
[15]	THORAT GADQIL B S, KILLI N, RATHAN G V N. Polyhydroxyalkanoates as biomaterials. Medicinal Chemistry Communication, 2017,8(9):1774-1787.
[16]	陈歌, 许春丽, 徐博, 冉刚超, 曹冲, 赵鹏跃, 曹立冬, 黄啟良. 聚羟基脂肪酸酯作为农药载体的研究进展. 农药学学报, 2019,21(5/6):871-882.
	CHEN G, XU C L, XU B, RAN G C, CAO C, ZHAO P Y, CAO L D, HUANG Q L. Research progress of polyhydroxyalkylates as pesticide carriers. Chinese Journal of Pesticide Science, 2019,21(5/6):871-882. (in Chinese)
[17]	CAO L D, LIU Y J, XU C L, ZHOU Z L, ZHAO P Y, NIU S J, HUANG Q L. Biodegradable poly (3-hydroxybutyrate-co-4- hydroxybutyrate) microcapsules for controlled release of trifluralin with improved photostability and herbicidal activity. Materials Science and Engineering C, Materials for Biological Applications, 2019,102:134-141.
[18]	陈慧萍, 陈歌, 许春丽, 徐博, 曹立冬, 黄啟良. 吡唑醚菌酯微囊的制备及性能表征. 现代农药, 2020,19(1):28-31, 39.
	CHEN H P, CHEN G, XU C L, XU B, CAO L D, HUANG Q L. Preparation and characterization of pyraclostrobin microcapsules. Modern Agrochemicals, 2020,19(1):28-31, 39. (in Chinese)
[19]	FREITAS S, MERKLE H P, GANDER B. Microencapsulation by solvent extraction/evaporation: Reviewing the state of the art of microsphere preparation process technology. Journal of Controlled Release, 2005,102(2):313-332.
[20]	JELVEHGARI M, BARAR J, VALIZADEH H, SHADROU S, NOKHODCHI A. Formulation characterization and in vitro evaluation of theophylline-loaded Eudragit RS 100 microspheres prepared by an emulsion-solvent diffusion/evaporation technique. Pharmaceutical Development and Technology, 2011,16(6):637-644.
[21]	ASRAR J, DING Y, MONICA R E, NESS L C. Controlled release of tebuconazole from a polymer matrix microparticle: Release kinetics and length of efficacy. Journal of Agricultural and Food Chemistry, 2004,52(15):4814-4820.
[22]	孙广宇, 宗兆锋. 植物病理学实验技术. 北京:中国农业出版社, 2002: 141-142.
	SUN G Y, ZONG Z F. Experimental Techniques of Plant Pathology. Beijing:China Agriculture Press, 2002: 141-142. (in Chinese)
[23]	叶玉杰, 李芳, 任德全, 张永忠, 刘嵩. Origin软件拟合制剂体外释药规律的应用. 数理医药学杂志, 2014,27(1):93-94.
	YE Y J, LI F, REN D Q, ZHANG Y Z, LIU S. Application of Origin software to fit the drug release in vitro. Journal of Mathematical Medicine, 2014,27(1):93-94. (in Chinese)
[24]	RAVI P R, KOTREKA U K, SAHA R N. Controlled release matrix tablets of zidovudine: Effect of formulation variables on the in vitro drug release kinetics. AAPS PharmSciTech, 2008,9(1):302-313.
[25]	SATHE P, TSONG Y, SHAH V P. In vitro dissolution profile comparison: Statistics and analysis, model dependent approach. Pharmaceutical Research, 1996,13(12):1799-1803.
[26]	陈建海, 陈志良, 侯连兵, 刘世霆. 聚羟基丁酸酯缓释微球的制备与性能. 功能高分子学报, 2000,13(1):61-64.
	CHEN J H, CHEN Z L, HOU L B, LIU S T. Preparation and characterization of diazepam-polyhydroxybutyrate microspheres. Journal of Functional Polymers, 2000,13(1):61-64. (in Chinese)
[27]	EMBLETON J K, TIGHE B J. Polymers for biodegradable medical devices. IX: Microencapsulation studies; effects of polymer composition and process parameters on poly-hydroxybutyrate- hydroxyvalerate microcapsule morphology. Journal of Microencapsulation, 1992,9(1):73-87.
[28]	舒丹丹, 张淑娟, 金丽娜, 王铁闯, 李大吉. 乳化溶剂挥发法及在微囊化制剂中的应用. 北方药学, 2012,9(4):22-23.
	SHU D D, ZHANG S J, JIN L N, WANG T C, LI D J. Emulsion solvent evaporation method and its application in microencapsulated preparations. Journal of North Pharmacy, 2012,9(4):22-23. (in Chinese)
[29]	LI M, ROUAUD O, PONCELET D. Microencapsulation by solvent evaporation: State of the art for process engineering approaches. International Journal of Pharmaceutics, 2008,363(1/2):26-39.
[30]	LI D, LIU B X, YANG F, WANG X, SHEN H, WU D C. Preparation of uniform starch microcapsules by premix membrane emulsion for controlled release of avermectin. Carbohydrate Polymers, 2016,136:341-349.
[31]	MAIA J L, SANTANA M H, RÉ M I. The effect of some processing conditions on the characteristics of biodegradable microspheres obtained by an emulsion solvent evaporation process. Brazilian Journal of Chemical Engineering, 2004,21(1):1-12.
[32]	YAN X F, WANG Y, LIU H H, LI R H, QIAN C Q. Synthesis and characterization of melamine-formaldehyde microcapsules containing pyraclostrobin by in situ polymerization. Polymer Science Series B, 2018,60(6):798-805.
[33]	滑海涛, 李敏, 翟晓曼, 曲文岩, 折冬梅, 李凤敏, 黄啟良. 反应时间、芯壁比及表面活性剂用量对阿维菌素微囊制备的影响. 农药学学报, 2010,12(1):54-60.
	HUA H T, LI M, ZHAI X M, QU W Y, SHE D M, LI F M, HUANG Q L. Studies on the influence of polymerization time, ratio of core material to wall material and percentage of SDS on the preparation of abamectin capsule suspensions. Chinese Journal of Pesticide Science, 2010,12(1):54-60. (in Chinese)
[34]	HEISKANEN H, DENIFL P, PITKÄNEN P, HURME M. Eﬀect of preparation conditions on the properties of microspheres prepared using an emulsion-solvent extraction process. Chemical Engineering Research and Design, 2012,90(10):1517-1526.
[35]	BAHRI Z, TAVERDET J. Preparation and optimization of 2, 4-D loaded cellulose derivatives microspheres by solvent evaporation technique. Journal of Applied Polymer Science, 2007,103(4):2742-2751.
[36]	MATEOVIC T, KRIZNAR B, BOGATAJ M, MRHAR A. The inﬂuence of stirring rate on biopharmaceutical properties of Eudragit RS microspheres. Journal of Microencapsulation, 2002,19(1):29-36.
[37]	CONTI B, GENTA I, MODENA T, PAVANETTO F. Investigation on process parameters involved in polylactide-co-glycolide microspheres preparation. Drug Development and Industrial Pharmacy, 2008,21(5):615-622.
[38]	黄彬彬, 杨丰梅, 张旭溪, 钟建斌, 吴祖建, 吴刚. 多杀菌素微球制备关键工艺研究:Ⅱ. 农药学学报, 2011,13(4):402-408.
	HUANG B B, YANG F M, ZHANG X X, ZHONG J B, WU Z J, WU G. Study on key process of preparation of spinosad microsphere: Ⅱ. Chinese Journal of Pesticide Science, 2011,13(4):402-408. (in Chinese)
[39]	SHENDEROVA A, BURKE T G, SCHWENDEMAN S P. Stabilization of 10-hydroxycampthecin in poly (lactide-co-glycolide) microsphere delivery vehicles. Pharmaceutical Research, 1997,14(10):1406-1414.
[40]	HEISKANEN H, DENIFL P, PITKÄNEN P, HURME M. Effect of concentration and temperature on the properties of the microspheres prepared using an emulsion-solvent extraction process. Advanced Powder Technology, 2012,23(6):779-786.
[41]	GÜRSEL I, HASIRCI V. Properties and drug release behaviour of poly (3-hydroxybutyric acid) and various poly (3-hydroxybutyrate- hydroxyvalerate) copolymer microcapsules. Journal of Microencapsulation, 1995,12(2):185-193.
[42]	YANG Y Y, CHIA H H, CHUNG T S. Effect of preparation temperature on the characteristics and release profiles of PLGA microspheres containing protein fabricated by double-emulsion solvent extraction/evaporation method. Journal of Controlled Release, 2000,69(1):81-96.
[43]	王光磊, 陈璨, 魏文增, 王宫. 溶剂挥发法制备牛樟芝总三萜微囊的研究. 海峡药学, 2019,31(2):5-10.
	WANG G L, CHEN C, WEI W Z, WANG G. Study on preparation of microcapsule loaded total triterpene from the Antrodia cinnamomea by emulsion-solvent evaporation technique. Strait Pharmaceutical Journal, 2019,31(2):5-10. (in Chinese)
[44]	MORITA T, HORIKIRI Y, YAMAHARA H, SUZUKI T, YOSHINO H. Formation and isolation of spherical fine protein microparticles through lyophilization of protein-poly (ethylene glycol) aqueous mixture. Pharmaceutical Research, 2000,17(11):1367-1373.
[45]	O’DONNELL P B, MOGINITY J W. Influence of processing of the stability and release properties of biodegradable microspheres containing thioridazine hydrochloride. European Journal of Pharmaceutics Biopharmaceutics, 1998,45(1):83-94.
[46]	LIU B X, WANG Y, YANG F, WANG X, SHEN H, CUI H X, WU D C. Construction of a controlled-release delivery system for pesticides using biodegradable PLA-based microcapsules. Colloids and Surfaces B: Biointerfaces, 2016,14:38-45.
[47]	ROSKOS K V, MASKIEWICZ R. Degradable controlled release systems useful for protein delivery. Pharmaceutical Biotechnology, 1997,10:45-92.
[48]	刘晓旭, 侯志广, 吴敬慧, 王雪, 逯忠斌. 嘧菌酯水解动力学研究. 农业环境科学学报, 2012,31(8):1603-1607.
	LIU X X, HOU Z G, WU J H, WANG X, LU Z B. Hydrolyze kinetics and mechanism of azoxystrobin. Journal of Agro-Environment Science, 2012,31(8):1603-1607. (in Chinese)
[49]	管磊, 张鹏, 王晓坤, 任玉鹏, 郭贝贝, 刘峰. 吡唑醚菌酯在水环境中的光解及微囊化对其光稳定性的影响. 农业环境科学学报, 2015,34(8):1493-1497.
	GUAN L, ZHANG P, WANG X K, REN Y P, GUO B B, LIU F. Photodegradation of pyraclostrobin in water environment and microencapsulation effect on its photostability. Journal of Agro- Environment Science, 2015,34(8):1493-1497. (in Chinese)
[50]	VOLOVA T, ZHILA N, VINOGRADOVA O, SHUMILOVA A, PRUDNIKOVA S, SHISHATSKAYA E. Characterization of biodegradable poly-3-hydroxybutyrate films and pellets loaded with the fungicide tebuconazole. Environmental Science and Pollution Research International, 2016,23(6):5243-5254.
[51]	XU W B, LI W, XIONG W, REN Y, LIU Y P, MIAO Y Z, XU Z H, ZHANG N, SHEN Q R, ZHANG R F. Diversity-triggered deterministic bacterial assembly constrains community functions. Nature Communications, 2019,10:3833.

因素水平 Factor level	1	2	3	4
芯壁材质量比 Mass ratio of core to wall material	1﹕5	1﹕10	1﹕20
油水体积比 Volume ratio of oil to water	1﹕5	1﹕10	1﹕15	1﹕20
PVA质量分数 Mass fraction of PVA (%)	0.5	1	1.5	2
剪切速率 Shearing speed (r/min)	4000	8000	12000

水平 Level	因素Factor
水平 Level	A	B	C	D
1	1﹕15	1﹕15	0.5%	4000
2	1﹕10	1﹕10	1%	8000
3	1﹕5	1﹕5	2%	12000

PVA质量分数 Mass fraction of PVA (%)	载药量 Loading content (%)	包封率 Encapsulation efficiency (%)	粒径 D₅₀ (μm)	跨距 Span
0.5	15.58±0.83a	77.47±5.79a	4.61±0.06a	3.70b
1	15.69±0.21a	78.90±1.47a	3.46±0.06b	4.26a
1.5	15.67±0.34a	80.47±4.07a	3.21±0.06c	3.69b
2	15.12±1.69a	78.70±3.04a	2.55±0.04d	2.91c

芯壁质量比 Mass ratio of core to wall	载药量 Loading content (%)	包封率 Encapsulation efficiency (%)	粒径 D₅₀(μm)	跨距 Span
1﹕5	15.31±2.28a	77.04±7.26a	3.46±0.06b	4.26a
1﹕10	7.69±0.98b	75.99±2.10a	3.47±0.05b	4.08b
1﹕20	4.66±0.12c	71.72±2.92a	4.33±0.08a	4.22a

油水体积比 Volume ratio of oil to water	载药量 Loading content (%)	包封率 Encapsulation efficiency (%)	粒径 D₅₀(μm)	跨距 Span
1﹕5	15.38±1.34a	76.98±6.36a	3.46±0.06a	4.26c
1﹕10	15.35±0.34a	67.07±6.39a	2.65±0.01d	4.52b
1﹕15	14.82±2.36a	68.08±6.53a	3.13±0.03b	4.29c
1﹕20	14.88±1.09a	74.26±4.34a	2.90±0.08c	5.38a
