农药液滴在水稻叶面的动态润湿铺展行为

doi:10.3864/j.issn.0578-1752.2024.13.007

中国农业科学 ›› 2024, Vol. 57 ›› Issue (13): 2583-2598.doi: 10.3864/j.issn.0578-1752.2024.13.007

农药液滴在水稻叶面的动态润湿铺展行为

张建桃¹^,²^,³(), 黄路生¹^,³, 刘广彬¹^,³, 兰玉彬³, 文晟³^,⁴()

¹ 华南农业大学数学与信息学院，广州 510642
² 农业农村部华南热带智慧农业技术重点实验室，广州 510642
³ 国家精准农业航空施药技术国际联合研究中心，广州 510642
⁴ 华南农业大学工程学院，广州 510642

收稿日期:2023-12-29 接受日期:2024-02-22 出版日期:2024-07-09 发布日期:2024-07-09
通信作者:
文晟，E-mail：vincen@scau.edu.cn
联系方式: 张建桃，E-mail：zhangjiantao@yeah.net。
基金资助:
广州市科技计划项目重点研发计划(2023B03J1362); 国家自然科学基金面上项目(32271985); 广东省普通高校特色创新类项目(2019KZDZX1002); 广东省自然科学基金(2022A1515011008); 高等学校学科创新引智计划(D18019)

The Dynamic Wetting and Spreading Behavior of Pesticide Droplet on Rice Leaf Surface

ZHANG JianTao¹^,²^,³(), HUANG LuSheng¹^,³, LIU GuangBin¹^,³, LAN YuBin³, WEN Sheng³^,⁴()

¹ College of Mathematics and Informatics, South China Agricultural University, Guangzhou 510642
² Key Laboratory of Smart Agricultural Technology in Tropical South China, Ministry of Agriculture and Rural Affairs, Guangzhou 510642
³ National Center for International Collaboration Research on Precision Agricultural Aviation Pesticides Spraying Technology, Guangzhou 510642
⁴ College of Engineering, South China Agricultural University, Guangzhou 510642

Received:2023-12-29 Accepted:2024-02-22 Published:2024-07-09 Online:2024-07-09

摘要/Abstract

摘要：

【目的】探究表面张力、液滴粒径和叶片倾角对农药液滴在水稻叶片近轴面、远轴面动态润湿铺展行为的影响，为通过调控农药液滴在水稻叶面的动态润湿铺展行为实现水稻施药的“减施增效”提供依据。【方法】通过调节Silwet-408的浓度配制出表面张力为21.4、33.2、43.7 mN·m^-1的Silwet-408溶液代替农药药液，利用液滴发生器生成532、627、746、830、957 μm的单液滴，对其在倾角为40°、65°、85°水稻叶片近轴面、远轴面的动态润湿铺展行为进行全因子试验。【结果】表面张力、液滴粒径、叶片倾角均显著影响(P<0.05)水稻叶面的液滴接触角变化率，且近轴面、远轴面所受影响的整体趋势基本相同，增大叶片倾角或减小液滴粒径或降低表面张力均能增大接触角变化率，促进液滴润湿铺展。其中，以降低表面张力的效果最显著，当表面张力从33.2 mN·m^-1降至与水稻叶面临界表面张力接近的21.4 mN·m^-1时，叶片近轴面的接触角(前进角和后退角)变化率分别增大7.49、6.22倍，远轴面的分别增大11.13、7.61倍，液滴的润湿性在75 s内从较差或差(80°≤接触角<100°或接触角≥100°)转变成中等或好(60°≤接触角<80°或接触角<60°)；当表面张力比水稻叶面临界表面张力大得多时，接触角变化率随叶片倾角的增大而增大，随液滴粒径的减小而增大，但叶片倾角的影响小于液滴粒径的影响，经过75 s后，几乎所有粒径的液滴仍保持较差或差的润湿性(80°≤接触角<100°或接触角≥100°)。液滴润湿滞后现象分析表明，水稻叶面的粗糙度相对较小，液滴润湿滞后现象并不严重。表面张力与水稻叶面临界表面张力接近的液滴在固-液-气三相体系动态表面张力的驱使下在叶面润湿铺展，接触角随时间的动态变化可使用模型θ=θ_e+Aexp(-Kt)进行拟合；表面张力比水稻叶面临界表面张力大得多的液滴虽能稳定地黏附在叶面上，没有出现滚落现象，但始终未突破叶面的钉扎效应和滞留阻力，无法实现润湿铺展。【结论】表面张力、液滴粒径、叶片倾角3个因素均显著影响农药液滴在水稻叶面的动态润湿铺展行为，在实际施药场景中，由于叶片倾角无法人为调节，因此可根据施药的目的调节药液的表面张力和液滴粒径进而调控液滴的动态润湿铺展行为。研究结果有助于理解农药液滴在水稻叶面动态润湿铺展的机理，并可为水稻施药场景中合理选择药液表面张力、液滴粒径提供理论支持与指导。

关键词: 农药液滴, 水稻叶面, 动态润湿铺展, 接触角, 润湿滞后, 表面张力

Abstract:

【Objective】 The objective of this study is to investigate the effects of surface tension, droplet size, and leaf angle on the dynamic wetting and spreading behavior of pesticide droplets on both adaxial and abaxial surfaces of rice leaf, and to provide a basis for realizing the “reduce application and increase efficiency” of rice spraying by regulating the dynamic wetting and spreading behavior of pesticide droplets on the rice leaf surface.【Method】 A full factorial experiment was designed to investigate the dynamic wetting and spreading behavior of single droplet on both adaxial and abaxial surfaces of rice leaf in this study. The Silwet-408 solutions with surface tension of 21.4, 33.2, and 43.7 mN·m^-1 were formulated by adjusting the concentration of Silwet-408 to replace the pesticide solutions. A droplet generator was used to produce the single droplets of 532, 627, 746, 830, and 957 μm. The leaf angles were set as 40°, 65°, and 85°.【Result】 There were significant effects of surface tension, droplet size, and leaf angle on the rate of change of droplet contact angle on the rice leaf surface (P<0.05), and the overall trend of the influences on the adaxial and abaxial surfaces was basically the same; increasing leaf angle or reducing droplet size or lowering surface tension could increase the rate of change of contact angle and promote the wetting and spreading of droplet. Among them, the effect of lowering surface tension was the most significant. When the surface tension was decreased from 33.2 to 21.4 mN·m^-1, which was close to the critical surface tension of rice leaf surface, the rate of change of the contact angle (advancing contact angle and receding contact angle) increased by 7.49 and 6.22 times for the adaxial surface, and 11.13 and 7.61 times for the abaxial surface, and the wettability of the droplets was changed from relatively poor or poor (80°≤contact angle<100° or contact angle≥100°) to medium or positive (60°≤contact angle<80° or contact angle<60°) within 75 s; when the surface tension was much larger than the critical surface tension of rice leaf surface, the rate of change of contact angle increased with the increase of leaf angle, and increased with the decrease of droplet size, but the effect of leaf angle was less than that of droplet size, and droplets of almost all particle sizes still maintained relatively poor or poor wettability (80°≤contact angle<100° or contact angle≥100°) after 75 s. In addition, the analysis of droplet wetting hysteresis phenomenon showed that the roughness of the rice leaf surface was relatively small, and the droplet wetting hysteresis phenomenon was not serious. The droplet with surface tension close to the critical surface tension of rice leaf was driven by the dynamic surface tension of the solid-liquid-gas three-phase system to wet and spread on the leaf surface, and the dynamic change of the contact angle with time could be fitted by the model θ=θ_e+Aexp(-Kt); although the droplet with a surface tension much higher than the critical surface tension of rice leaf could steadily adhere to the leaf surface without the phenomenon of roll-off, it was never able to break through the pinning effect and retention resistance of the leaf surface, and could not achieve wetting and spreading.【Conclusion】 All three factors, surface tension, droplet size, and leaf angle, significantly affect the dynamic wetting and spreading behavior of pesticide droplets on the rice leaf surface. In the actual application scenarios, since the leaf angle cannot be adjusted artificially, the surface tension and droplet size of the pesticide solution can be adjusted according to the purpose of the application to regulate the dynamic wetting and spreading behavior of the droplet. The results of this study are helpful to understand the mechanism of dynamic wetting and spreading of pesticide droplet on the rice leaf surface, and can provide theoretical support and guidance for the rational selection of surface tension and droplet size in rice pesticide application scenarios.

Key words: pesticide droplet, rice leaf surface, dynamic wetting and spreading, contact angle, wetting hysteresis, surface tension

张建桃, 黄路生, 刘广彬, 兰玉彬, 文晟. 农药液滴在水稻叶面的动态润湿铺展行为[J]. 中国农业科学, 2024, 57(13): 2583-2598.

ZHANG JianTao, HUANG LuSheng, LIU GuangBin, LAN YuBin, WEN Sheng. The Dynamic Wetting and Spreading Behavior of Pesticide Droplet on Rice Leaf Surface[J]. Scientia Agricultura Sinica, 2024, 57(13): 2583-2598.

0
/ / 推荐

导出引用管理器 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

链接本文: https://www.chinaagrisci.com/CN/10.3864/j.issn.0578-1752.2024.13.007

https://www.chinaagrisci.com/CN/Y2024/V57/I13/2583

图/表 12

图1

表1

图2

图3

表2

表3

图4

图5

图6

图7

图8

表4

参考文献 39

[1]	CHEN H B, LAN Y B, K FRITZ B, HOFFMANN W C, LIU S B. Review of agricultural spraying technologies for plant protection using unmanned aerial vehicle (UAV). International Journal of Agricultural and Biological Engineering, 2021, 14(1): 38-49.
[2]	ZHAO X, CUI H X, WANG Y, SUN C J, CUI B, ZENG Z H. Development strategies and prospects of nano-based smart pesticide formulation. Journal of Agricultural and Food Chemistry, 2018, 66(26): 6504-6512. doi: 10.1021/acs.jafc.7b02004 pmid: 28654254
[3]	康峰, 吴潇逸, 王亚雄, 郑永军, 李守根, 陈冲冲. 农药雾滴沉积特性研究进展与展望. 农业工程学报, 2021, 37(20): 1-14.
	KANG F, WU X Y, WANG Y X, ZHENG Y J, LI S G, CHEN C C. Research progress and prospect of pesticide droplet deposition characteristics. Transactions of the Chinese Society of Agricultural Engineering, 2021, 37(20): 1-14. (in Chinese)
[4]	宋玉莹, 曹冲, 徐博, 冉刚超, 曹立冬, 李凤敏, 赵鹏跃, 黄啟良. 农药雾滴在植物叶面的弹跳行为及调控技术研究进展. 农药学学报, 2019, 21(5/6): 895-907.
	SONG Y Y, CAO C, XU B, RAN G C, CAO L D, LI F M, ZHAO P Y, HUANG Q L. Research progress on bouncing behavior and control technology of pesticide droplets at plant leaf surface. Chinese Journal of Pesticide Science, 2019, 21(5/6): 895-907. (in Chinese)
[5]	ZWERTVAEGHER I K, VERHAEGHE M, BRUSSELMAN E, VERBOVEN P, LEBEAU F, MASSINON M, NICOLAÏ B M, NUYTTENS D. The impact and retention of spray droplets on a horizontal hydrophobic surface. Biosystems Engineering, 2014, 126: 82-91.
[6]	马英剑, 甄硕, 孙喆, 于萌, 赵锐, 郭鑫宇, 徐勇, 吴学民. 农药制剂研发的精细化、功能化与农业生产高效利用. 农药学学报, 2022, 24(5): 1080-1098.
	MA Y J, ZHEN S, SUN Z, YU M, ZHAO R, GUO X Y, XU Y, WU X M. Refinement and functionalization of pesticide formulation research and development and efficient utilization in agricultural production. Chinese Journal of Pesticide Science, 2022, 24(5): 1080-1098. (in Chinese)
[7]	张海艳, 兰玉彬, 文晟, 陈春玲, 许童羽, 陈盛德. 无人机旋翼风场作用下雾滴在水稻植株上的黏附量模型构建. 农业工程学报, 2022, 38(18): 40-50.
	ZHANG H Y, LAN Y B, WEN S, CHEN C L, XU T Y, CHEN S D. Modelling approach of spray retention on rice in plant protection using unmanned aerial vehicle. Transactions of the Chinese Society of Agricultural Engineering, 2022, 38(18): 40-50. (in Chinese)
[8]	ZHOU Z L, CAO C, CAO L D, ZHENG L, XU J, LI F M, HUANG Q L. Evaporation kinetics of surfactant solution droplets on rice (Oryza sativa) leaves. PLoS ONE, 2017, 12(5): e0176870.
[9]	ZHOU Z L, CAO C, CAO L D, ZHENG L, XU J, LI F M, HUANG Q L. Effect of surfactant concentration on the evaporation of droplets on cotton (Gossypium hirsutum L.) leaves. Colloids and Surfaces B: Biointerfaces, 2018, 167: 206-212.
[10]	王潇楠, 齐鹏, 于聪伟, 何雄奎. 农药雾滴雾化沉积飘失研究进展. 农药学学报, 2022, 24(5): 1065-1079.
	WANG X N, QI P, YU C W, HE X K. Research and development of atomization, deposition and drift of pesticide droplets. Chinese Journal of Pesticide Science, 2022, 24(5): 1065-1079. (in Chinese)
[11]	王穗, 彭尔瑞, 吴国星, 张天顺, 时玲, 张川, 余杨. 植物叶面农药雾滴蒸发时间研究在我国的应用. 广东农业科学, 2009(11): 104-107.
	WANG S, PENG E R, WU G X, ZHANG T S, SHI L, ZHANG C, YU Y. Application of evaporation of pesticide droplets on plant leaves in China. Guangdong Agricultural Sciences, 2009(11): 104-107. (in Chinese)
[12]	周召路, 曹冲, 曹立冬, 郑丽, 马超, 李凤敏, 黄啟良. 不同类型界面液滴蒸发特性与农药利用效果研究进展. 农药学学报, 2017, 19(1): 9-17.
	ZHOU Z L, CAO C, CAO L D, ZHENG L, MA C, LI F M, HUANG Q L. Research advances of droplet evaporation on different interfaces and the efficiency of pesticide utilization. Chinese Journal of Pesticide Science, 2017, 19(1): 9-17. (in Chinese)
[13]	OLIVEIRA R B, BONADIO PRECIPITO L M, GANDOLFO M A, OLIVEIRA J V, LUCIO F R. Effect of droplet size and leaf surface on retention of 2,4-D formulations. Crop Protection, 2019, 119: 97-101.
[14]	郑丽, 程雪健, 黄桂珍, 赵鹏跃, 曹冲, 曹立冬, 吴进龙, 黄修柱, 黄啟良. 农药兑水茎叶喷施对靶沉积剂量传递与调控研究进展. 农药学学报, 2022, 24(5): 1034-1048.
	ZHENG L, CHENG X J, HUANG G Z, ZHAO P Y, CAO C, CAO L D, WU J L, HUANG X Z, HUANG Q L. Research progress in target dose transfer and regulation of pesticides deposition by foliar spray diluted with water. Chinese Journal of Pesticide Science, 2022, 24(5): 1034-1048. (in Chinese)
[15]	张红涛, 陆军, 魏德云, 胡玉霞. 烷基聚葡糖苷液滴在黄瓜叶面的润湿状态及动态铺展行为. 农业工程学报, 2017, 33(3): 81-87.
	ZHANG H T, LU J, WEI D Y, HU Y X. Wetting state and dynamic spreading behavior of alkyl polyglycoside drop on cucumber leaf surface. Transactions of the Chinese Society of Agricultural Engineering, 2017, 33(3): 81-87. (in Chinese)
[16]	马悦, 张晨辉, 杜凤沛. 农药制剂发展趋势及前沿技术概况. 现代农药, 2022, 21(1): 1-8.
	MA Y, ZHANG C H, DU F P. Development tendency and frontier technology of pesticide formulations. Modern Agrochemicals, 2022, 21(1): 1-8. (in Chinese)
[17]	XU L Y, ZHU H P, OZKAN H E, BAGLEY W E, KRAUSE C R. Droplet evaporation and spread on waxy and hairy leaves associated with type and concentration of adjuvants. Pest Management Science, 2011, 67(7): 842-851. doi: 10.1002/ps.2122 pmid: 21370389
[18]	ZHU Y Q, GAO Y X, ZHANG C H, ZHAO X, MA Y, DU F P. Static and dynamic wetting behavior of TX-100 solution on super- hydrophobic rice (Oryza sativa) leaf surfaces. Colloids and Surfaces A: Physicochemical and Engineering Aspects, 2018, 547: 148-156.
[19]	段洁利, 蒋婷婷, 蒋寅龙, 杨洲. 香蕉叶表面特征及浸润性机理研究. 华南农业大学学报, 2023, 44(2): 314-323.
	DUAN J L, JIANG T T, JIANG Y L, YANG Z. Study on the surface characteristics and infiltration mechanism of banana leaf. Journal of South China Agricultural University, 2023, 44(2): 314-323. (in Chinese)
[20]	徐广春, 顾中言, 徐德进, 许小龙. 稻叶表面特性及雾滴在倾角稻叶上的沉积行为. 中国农业科学, 2014, 47(21): 4280-4290. doi: 10.3864/j.issn.0578-1752.2014.21.013.
	XU G C, GU Z Y, XU D J, XU X L. Characteristics of rice leaf surface and droplets deposition behavior on rice leaf surface with different inclination angles. Scientia Agricultura Sinica, 2014, 47(21): 4280-4290. doi: 10.3864/j.issn.0578-1752.2014.21.013. (in Chinese)
[21]	ZHU H P, YU Y, OZKAN H E, DERKSEN R C, KRAUSE C R. Influence of spray additives on droplet evaporation and residual patterns on wax and wax-free surfaces//An ASABE Meeting Presentation Paper Number:083752, 2008.
[22]	ZHU H P, SALYANI M, FOX R D. A portable scanning system for evaluation of spray deposit distribution. Computers and Electronics in Agriculture, 2011, 76(1): 38-43.
[23]	QIU W, GUO H B, ZHENG H, CAO Y B, LV X L, FANG J, ZHAI C Y, YU H F. CFD modelling to analyze the droplets deposition behavior on vibrating rice leaves. Computers and Electronics in Agriculture, 2022, 201: 107330.
[24]	YARNOLD G D. The motion of a mercury index in a capillary tube. Proceedings of the Physical Society, 1938, 50(4): 540-552.
[25]	徐广春, 顾中言, 徐德进, 许小龙, 董玉轩. 常用农药在水稻叶片上的润湿能力分析. 中国农业科学, 2012, 45(9): 1731-1740. doi: 10.3864/j.issn.0578-1752.2012.09.008.
	XU G C, GU Z Y, XU D J, XU X L, DONG Y X. Wettability analysis of pesticides on rice leaf. Scientia Agricultura Sinica, 2012, 45(9): 1731-1740. doi: 10.3864/j.issn.0578-1752.2012.09.008. (in Chinese)
[26]	王晓东, 彭晓峰, 陆建峰, 刘涛, 王补宣. 粗糙表面接触角滞后现象分析. 热科学与技术, 2003, 2(3): 230-234.
	WANG X D, PENG X F, LU J F, LIU T, WANG B X. Analysis of contact angle hysteresis on rough surfaces. Journal of Thermal Science and Technology, 2003, 2(3): 230-234. (in Chinese)
[27]	肖易航, 郑军, 何勇明, 刘鸿博, 龚丁. 不同润湿性液体在粗糙表面的润湿滞后现象. 中国表面工程, 2019, 32(6): 150-156. doi: 10.11933/j.issn.1007-9289.20190216001
	XIAO Y H, ZHENG J, HE Y M, LIU H B, GONG D. Contact angle hysteresis with different wetting-liquids on rough surfaces. China Surface Engineering, 2019, 32(6): 150-156. (in Chinese) doi: 10.11933/j.issn.1007-9289.20190216001
[28]	周兆兵, 张洋, 贾翀. 木质材料动态润湿性能的表征. 南京林业大学学报(自然科学版), 2007, 31(5): 71-74. doi: 10.3969/j.jssn.1000-2006.2007.05.016
	ZHOU Z B, ZHANG Y, JIA C. Describing on dynamic wettability of wood and wood-based materials. Journal of Nanjing Forestry University (Natural Sciences Edition), 2007, 31(5): 71-74. (in Chinese)
[29]	张越, 张高勇, 韩富. 新型三硅氧烷表面活性剂在低能表面的铺展机理. 化学学报, 2007, 65(5): 465-469.
	ZHANG Y, ZHANG G Y, HAN F. Spreading mechanism of new glucosamide-based trisiloxane surfactant on low-energy surface. Acta Chimica Sinica, 2007, 65(5): 465-469. (in Chinese)
[30]	ZHANG Y, ZHANG G Y, HAN F. The spreading and superspeading behavior of new glucosamide-based trisiloxane surfactants on hydrophobic foliage. Colloids and Surfaces A: Physicochemical and Engineering Aspects, 2006, 276(1/3): 100-106.
[31]	LIN J, ZHU M N, WU X, ZHENG C, LIU Z L, WANG Q Y, LU D D, HE Q Y, CHEN X Y. Microwave-assisted synthesis of trisiloxane superspreader and its superspreading behavior on plant leaves surfaces. Colloids and Surfaces A: Physicochemical and Engineering Aspects, 2016, 511: 190-200.
[32]	张晨辉, 赵欣, 雷津美, 马悦, 杜凤沛. 非离子表面活性剂Triton X-100溶液在不同生长期小麦叶片表面的润湿行为. 物理化学学报, 2017, 33(9): 1846-1854.
	ZHANG C H, ZHAO X, LEI J M, MA Y, DU F P. Wettability of Triton X-100 on wheat (Triticum aestivum) leaf surfaces with respect to developmental changes. Acta Physico-Chimica Sinica, 2017, 33(9): 1846-1854. (in Chinese)
[33]	PICKNETT R G, BEXON R. The evaporation of sessile or pendant drops in still air. Journal of Colloid and Interface Science, 1977, 61(2): 336-350.
[34]	高荣, 黄路生, 文晟, 尹选春, 张建桃. 农药液滴在玉米叶片表面铺展面积的影响因素. 农业工程学报, 2022, 38(20): 41-48.
	GAO R, HUANG L S, WEN S, YIN X C, ZHANG J T. Factors influencing the spreading areas of pesticide droplets on the surface of maize leaves. Transactions of the Chinese Society of Agricultural Engineering, 2022, 38(20): 41-48. (in Chinese)
[35]	曹军琳, 祁力钧, 杨知伦, 葛鲁振, 吴亚垒, 程一帆. 基于图像处理的雾滴沉积分布试验研究. 中国农业大学学报, 2019, 24(1): 130-137.
	CAO J L, QI L J, YANG Z L, GE L Z, WU Y L, CHENG Y F. Experimental study of droplet distribution based on image processing. Journal of China Agricultural University, 2019, 24(1): 130-137. (in Chinese)
[36]	徐德进, 徐广春, 许小龙, 顾中言. 施液量、雾滴大小、叶片倾角及助剂对农药在稻叶上沉积的影响. 西南农业学报, 2015, 28(5): 2056-2062.
	XU D J, XU G C, XU X L, GU Z Y. Effect of application volume, droplet size, rice leaf incline angle and spray adjuvant on pesticide deposition. Southwest China Journal of Agricultural Sciences, 2015, 28(5): 2056-2062. (in Chinese)
[37]	兰玉彬, 彭瑾, 金济. 农药喷雾粒径的研究现状与发展. 华南农业大学学报, 2016, 37(6): 1-9.
	LAN Y B, PENG J, JIN J. Research status and development of pesticide spraying droplet size. Journal of South China Agricultural University, 2016, 37(6): 1-9. (in Chinese)
[38]	顾中言, 许小龙, 韩丽娟. 几种植物临界表面张力值的估测. 现代农药, 2002, 1(2): 18-20.
	GU Z Y, XU X L, HAN L J. Study on the measure of the critical surface tension of plants. Modern Agrochemicals, 2002, 1(2): 18-20. (in Chinese)
[39]	屠豫钦, 李秉礼. 农药应用工艺学导论. 北京: 化学工业出版社, 2006: 33-36.
	TU Y Q, LI B L. Introduction to Application Technology of Pesticides. Beijing: Chemical Industry Press, 2006: 33-36. (in Chinese)

浓度 Concentration (mg·mL^-1)	表面张力 Surface tension (mN·m^-1)	接触角（近轴面） Contact angle (the adaxial surface) (°	接触角（远轴面） Contact angle (the abaxial surface) (°
0	72.8±0.07	132.0±0.51	118.4±0.90
0.002	43.7±0.10	127.4±0.19	115.7±0.68
0.01	33.2±0.10	108.5±0.68	83.6±0.88
0.1	21.4±0.03	24.1±1.24	20.9±1.90

	变异来源 Source of variability	平方和 Sum of squares	自由度 Degree of freedom	均方 Mean square	F	P	效应量 Effect size
水稻叶片近轴面θ_a θ_a on the adaxial surface of rice leaf	修正模型Correction model	11.178	44	0.254	142.562	<0.001	0.986
	A	0.097	4	0.024	13.610	<0.001	0.377
	B	10.637	2	5.318	2984.524	<0.001	0.985
	C	0.054	2	0.027	15.061	<0.001	0.251
	A×B	0.039	8	0.005	2.757	0.009	0.197
	A×C	0.041	8	0.005	2.863	0.007	0.203
	B×C	0.162	4	0.041	22.766	<0.001	0.503
	A×B×C	0.148	16	0.009	5.194	<0.001	0.480
水稻叶片近轴面θ_r θ_r on the adaxial surface of rice leaf	修正模型Correction model	10.266	44	0.233	198.958	<0.001	0.990
	A	0.114	4	0.029	24.385	<0.001	0.520
	B	9.739	2	4.869	4152.493	<0.001	0.989
	C	0.011	2	0.005	4.512	0.014	0.091
	A×B	0.062	8	0.008	6.648	<0.001	0.371
	A×C	0.069	8	0.009	7.338	<0.001	0.395
	B×C	0.061	4	0.015	13.070	<0.001	0.367
	A×B×C	0.209	16	0.013	11.152	<0.001	0.665
水稻叶片远轴面θ_a θ_a on the abaxial surface of rice leaf	修正模型Correction model	12.127	44	0.276	182.035	<0.001	0.989
	A	0.051	4	0.013	8.503	<0.001	0.274
	B	11.661	2	5.831	3850.864	<0.001	0.988
	C	0.063	2	0.032	20.901	<0.001	0.317
	A×B	0.075	8	0.009	6.158	<0.001	0.354
	A×C	0.056	8	0.007	4.593	<0.001	0.290
	B×C	0.125	4	0.031	20.680	<0.001	0.479
	A×B×C	0.096	16	0.006	3.954	<0.001	0.413
水稻叶片远轴面θ_r θ_r on the abaxial surface of rice leaf	修正模型Correction model	10.285	44	0.234	189.769	<0.001	0.989
	A	0.054	4	0.013	10.871	<0.001	0.326
	B	10.011	2	5.005	4063.746	<0.001	0.989
	C	0.009	2	0.005	3.777	0.027	0.077
	A×B	0.044	8	0.006	4.488	<0.001	0.285
	A×C	0.052	8	0.006	5.254	<0.001	0.318
	B×C	0.019	4	0.005	3.824	0.006	0.145
	A×B×C	0.096	16	0.006	4.881	<0.001	0.465

	试验因素 Experimental factor		样本量 Sample number	接触角变化率 The rate of change of contact angle (°·s^-1)
	试验因素 Experimental factor		样本量 Sample number	θ_a	θ_r
水稻叶片近轴面 The adaxial surface of rice leaf	液滴粒径 Droplet size (μm)	532	27	0.295a	0.306a
		627	27	0.301a	0.305a
		746	27	0.248b	0.252b
		830	27	0.246b	0.245b
		957	27	0.237b	0.241b
	叶片倾角 Leaf angle (°)	40	45	0.244b	0.263b
		65	45	0.260b	0.264b
		85	45	0.292a	0.282a
	表面张力 Surface tension (mN·m^-1)	21.4	45	0.662a	0.650a
		33.2	45	0.078b	0.090b
		43.7	45	0.056c	0.070c
水稻叶片远轴面 The abaxial surface of rice leaf	液滴粒径 Droplet size (μm)	532	27	0.288a	0.295a
		627	27	0.286a	0.290a
		746	27	0.247b	0.257b
		830	27	0.250b	0.255b
		957	27	0.246b	0.247b
	叶片倾角 Leaf angle (°)	40	45	0.247b	0.261b
		65	45	0.249b	0.265b
		85	45	0.294a	0.280a
	表面张力 Surface tension (mN·m^-1)	21.4	45	0.679a	0.654a
		33.2	45	0.056b	0.076b
		43.7	45	0.055b	0.076b

表面张力/叶片倾角 Surface tension (mN·m^-1)/Leaf angle (°)	液滴粒径Droplet size (μm)
	532	957
21.4/40	θ_a=61.50+38.03exp(-0.036t), R²=0.9931	θ_a=59.47+54.52exp(-0.031t), R²=0.9970
21.4/65	θ_a=53.69+51.56exp(-0.048t), R²=0.9858	θ_a=79.36+44.49exp(-0.063t), R²=0.9981
21.4/85	θ_a=40.25+58.90exp(-0.022t), R²=0.9772	θ_a=80.68+43.88exp(-0.062t), R²=0.9915
33.2/40	θ_a=98.81-0.207t, R²=0.9917	θ_a=118.49-0.043t, R²=0.9987
33.2/65	θ_a=95.13-0.115t, R²=0.9909	θ_a=145.18-0.056t, R²=0.9913
33.2/85	θ_a=104.46-0.084t, R²=0.9857	θ_a=108.58-0.044t, R²=0.9333
43.7/40	θ_a=110.84-0.100t, R²=0.9265	θ_a=131.38-0.040t, R²=0.9963
43.7/65	θ_a=117.17-0.016t, R²=0.7900	θ_a=119.17-0.027t, R²=0.8893
43.7/85	θ_a=107.24-0.132t, R²=0.9912	θ_a=125.43-0.041t, R²=0.7582
